front used for sale

The new 19-inch Rack PC SIMATIC IPC847C is equipped with the latest 2010 Intel Core processor technology (Intel Core i). The high computing power and PCI-Express technology make the IPC847C the perfect platform for high-performance applications, such as in measurement technology in test benches or in industrial image processing. The SIMATIC IPC847C also offers maximum system availability, expandability and compactness in 19" IPC technology: - optimal storage space utilization and data security with RAID5 - optional redundant power supply (AC) - Extensive diagnostic and monitoring options - Universal use for industrial workstation and server applications - Variety of integrated interfaces and expansion slots - Lower installation depth for installation in space-saving control cabinets of only 500mm depth The Rack PC is available as a control cabinet device for horizontal and ver ...

General2-Axes Universal Turning Center with driven tools, C-axis, Y-axis and counter spindle - Direct measuring system for X / Y axis; Control: DMG MORI SLIMline® Multi-Touch control Working areaSwing diameter over transverse guideway370 mmSwing diameter over guide ways700 mmTurning diameter400 mmBar diameter max.80 mmSlide 1Transverse stroke276 mmLongitudinal stroke755 mmY axis, vertical+/- 60 mmRapid traverse in X30 m/minRapid traverse in Z30 m/minRapid traverse in Y22,5 m/minMain drive 1Drive power (100% DC)17 kWDrive power (40% DC)25,5 kWSpeed range- 4000 rpmTorque (100% DC)283 NmMax. torque (40% DC)426 NmC-Axis Speed-200 rpmTorque of C-Axis (holding torque)426 NmWork spindle (left)Spindle noseA2-8 Bar diametre80 mmSpindle diametre on front bearing130 mmMain drive 2Drive power (100% DC)13 kWDrive power (40% DC)14 kWSpeed range- 5000 rpmTorque (100% DC)171 NmMax. torque (40% DC)192 N ...

GeneralTwo spindle turning/milling centre with - Main and counter spindle; Control: CELOS with Siemens 840D sl Operate Tool holder 2Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)10 kWTool magazineNumber of tools24 Max. tool length230 mmMax. tool diameter80 mmMax. tool weight7 KgTurning-milling spindleSpindle taperHSK-A 63 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment1000 NmSwivelling range+/-110 degreeSlide 2Longitudinal stroke1200 mmTransverse stroke195 mmSlide 3Longitudinal stroke1200 mmSlide 1Longitudinal stroke1200 mmTransverse stroke490 mmY axis, vertical+/- 100 mmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWDri ...

GeneralTwo spindle turning/milling centre with - Main and counter spindle; Control: CELOS with Siemens 840D sl Operate Tool holder 2Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)10 kWTurning-milling spindleSpindle taperHSK-A 63 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment1000 NmSwivelling range+/-110 degreeTool magazineNumber of tools24 Max. tool length230 mmMax. tool diameter80 mmMax. tool weight7 KgSlide 3Longitudinal stroke1200 mmSlide 2Longitudinal stroke1200 mmTransverse stroke195 mmSlide 1Longitudinal stroke1200 mmTransverse stroke490 mmY axis, vertical+/- 100 mmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWDri ...

GeneralTwo spindle turning centre with - partial hollow clamping device for main spindle and counter spindle internal diameter of draw tube Ø67 mm (2.63 in) x 700 mm (27.55 in) deep - 2 C-axes and spindle brakes (hydr.) - 2 12 fold Sauter star turrets reception VDI 40, DIN 69880-40 with precision interface (Trifix) and tool drive connection/drive acc. DIN 5480 - Y-axis, slide I - Counter spindle slide with NC-cross stroke and tailstock; Control: CELOS with Siemens 840D sl Operate Headstock, leftClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle diametre on front bearing130 mmSpindle bore87 mmDrive power (100% DC)25 kWTorque (100% DC)280 NmC-Axis Speed2000 rpmSpeed range0-5000 rpmHeadstock, rightClamping chuck Ø315 mmSpindle bore87 mmSpindle nose diameter170h5 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWC-Axis Speed2000 rpmTorque (100% DC)280 NmS ...

spindle tilting: + 45,5° bis -45,5° ; height adjustment: electrically; tilting adjustment: electrically; fence adjustment: electrically ; altitude display: digital; swivel angel display: digital; fence display: digital; spindle: MK 5; speeds: stepless 900 †12000min¯¹; power consuption: 7,5 kw; motor brake: yes, automatically; suction connection: 3 x 100 mm, 1 x 120 mm; machine length: 2540 mm; machine width: 1195 mm; weight: 950 kg; Highly stable steel gray cast iron construction Large work table made of gray cast iron Electric spindle drive 7.5 kW with maintenance-free direct drive guarantees maximum precision through maximum smoothness Maximum power is already available from 3400 min¹ Precision aggregates and high own weight Rapid table insert, infinitely manually adjustable to tool diameter (optionally electronically positionable) Standard with righ ...

turning diameter: 36 mm turning length: 100 mm control: Traub TX 8i turning speeds: 6300 U/min c-axis: 0,001 turret (x-stations): 12 angetrieben turning speeds: 6000 U/min x-axis: 370 mm z-axis: 250 mm y-axis: +/- 20 mm gripping station: 36 mm turning speeds: 6300 U/min c-axis: 0,001 0 collet unit: 2x Hainbuch HSP/GSP SK 6970 ZW/G load magazine: FMB turbo 5-42 chip conveyor: ja / yes kW total power requirement: 33 kW weight of the machine ca.: 4 t dimensions of the machine ca.: 3,4 x 1,22 x 1,7 + FMB m parts conveyor: ja / yes front attachment: 5(7) rear station: 5 (4 angetrieben) CNC automatic lathe Traub TNK 36, year 2005, with bar feeder FMB turbo 5-42 This turning-milling centre is in a very good condition and equipped with 2x Y- axes and driven tools on 3 tool carriers. Tool carrier 1 = turret 12-fold driven, Y-axis +/-20mm Tool carrier 2 = front attachment 5 stations (4 driven) Too ...

Biosan chamber The chamber was purchased in 2017, efficient, not used. The UVC/T-M-AR is a chamber designed for clean work with DNA samples. The chamber provides protection against contamination. The UVC/T-M-AR model is a table-top model, made of a metal frame and a stainless steel work surface. The chamber is equipped with an open UV lamp installed in the upper part of the chamber. UV radiation from an open lamp disinfects the working surface by deactivating DNA / RNA fragments within 15-30 minutes of exposure. A digital timer controls the exposure time. The white light lamp provides proper illumination of the work surface. The chamber is equipped with a flow UV antibacterial lamp, which ensures continuous decontamination inside the chamber during operation. This lamp is recommended for working with DNA/RNA amplicons. The UV recirculator contains a lamp, a fan and dust filter ...

sheet width: 3050 mm plate thickness: 12,0 mm ST plate thickness: 8,0 mm VA no. of strokes: 7 - 14 Hub/min down holder: 18 Stück cutting angle: 0,5 - 3,0 ° work height max.: 930 mm back stop - adjustable: 1000 mm Number of working hours: 18.822 h total power requirement: 22,5 kW weight: 8.500 kg range L-W-H: 4180 x 2030 x 2210 mm Furnishing: - Robust hydraulic, link-guided guillotine shears - Electro-motor backgauge with analogue display Fine adjustment via hand wheel, front left - Control panel, front left - manual cutting gap adjustment, from behind - electro-hydraulic cutting angle adjustment - Front finger protection - Stable front support table - 1x side stop with T-slot and millimeter scale - 3x support arms - 1x free moving footswitch - User manual (PDF) Machine link : http://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machineno=1008 -9325234 The data for this ad was c ...

Number of spindles: 6 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 mm Feed motor: 4 kW Feed speed: 5-30 m/min. Control: Weinig PowerCom Weinig Powermat 500 for window production --------------------------------------------- Machine will be checked at our warehouse Short summary: --------------------------------------------- 6 Spindles with 8,000 rpm and 7.5 KW 5 x HSK/Powerlock Window package with glazing bead separation Spindles axially and radially CNC controlled right and upper spindles with common pneumatic timing for Glazing bead cutting Large control Powercom with touchscreen Detailed description: --------------------------------------------- Tool arrangement No. 018 for window production Technical specifications: --------------------------------------------- Working width 20 - 230 mm (at tool cutting circle 93 - 125 mm) Working height 8 - 120  ...

Modular labeling machine 10 heads Modular labeling machine Cold glue 4 stations Front back seal L neck ring self adhesive 3 stations Front back neck ring Bottles round square Label stations nr N 3 self adhesive stations N 3 Cold glue stations Central diameter 960 Plates nr 10 Length of the labels min max 10 150 Height of the label min max 15 200 Container diameter height min max 30 80 mm Altezza min max 100 400 mm Plate transmission Motorized plate Optical centering Yes Special inlet stars No 3 multi format in out stars D 50 120 mm Industria 4 0 yes predisposed other request Double screw input in phase Max speed request 6 500 bph Modular labeling machine basic machine composition 1 System built according to CE regulations 2 Machine operation via PLC Schneider 3 Touch screen control panel for labeler functions installed on a mobile and rotating support 4 Automatic variation of production  ...

sheet width: 3100 mm plate thickness: 6.0 mm thickness at Niro-steel: 4.0 mm distance between columns: 3120 mm down holder: 16 Stück oil volume: 200 ltr. cutting angle: 1° 30 no. of strokes: 15 Hub/min control: ENC 100 table width: 500 mm throat: 50.0 mm Number of working hours: 912 h total power requirement: 15.0 KW weight: 7650 kg range L-W-H: 3810 x 2200 x 2050 mm from a maintenance workshop () very good / well-maintained condition (as new) with only 912 operating hours current new price ~ 45.000 euros Special price on request -------------------------------------------------- NC electro-hydraulic swing cutting shear with DURMA ENC 100M control manual cutting gap adjustment Incl. pneumatic sheet metal holding device for thin sheet metal cuts -------------------------------------------------- Furnishing: - robust electro-hydraulic swing cutting shears - including DURMA ENC 1 ...

sheet width: 2540 mm plate thickness: 3.25 mm throat: 100 mm no. of strokes: 60.0 Hub/min back stop - adjustable: 530 mm voltage: 400 V engine output: 7.5 kW weight: 2450 kg range L-W-H: 3600 x 1000 x 1560 mm Furnishing: - robust electric motorized guillotine shears - stable, front support/work table - Front control panel - including emergency stop button - manual back gauge up to approx. 700 mm - adjustable by handwheel, with analogue mm scale display - 1x front side stops - 3x front support arms - manual cutting gap adjustment - Cut/lift confirmation by foot pedal - 1x freely movable foot switch - rear sheet metal slide - User manual (PDF) Machine link: http://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machineno=1008 -9325320 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Containers for sweeping, mowing, watering and washing 2-broom system with individual broom control Mower Just over 600 hours ENGINE Perkins 3-cylinder 4-stroke diesel Displacement 1131 cm³ Power 19.7 kW (27 hp) Torque 70.2 Nm Nominal speed 3000 rpm Water cooling Fuel tank capacity 27 l Hydrostatic drive, infinitely variable speed control, four wheels of the same size Maximum speed 27 km/h Hydraulic service brake on the front axle, acts on all four wheels via the hydrostatic drive, mechanical parking brake on the front axle by means of two drum brakes HYDRAULICS 1st circuit infinitely variable up to 33 l/min 2nd circuit up to 58 l/min Hydraulic oil quantity 19 l Lifting capacity front 500 kg WEIGHT Including driver with 75 kg, depending on tyres and equipment Curb weight 1101 kg Permissible total weight 2000 kg Permissible axle load front 1190 kg / rear 1190 kg Drawba ...

bore capacity in steel (diameter): 16.0 / 20.0 mm throat: 240 mm bore stroke: 100 mm spindle taper: 2 MK table:: 280 x 340 mm turning speeds: 130 - 2000 U/min column diameter: 90.0 mm flute distance: 125 mm T-slots: 2 x 14.0 mm total power requirement: 0.37 / 0.70 kW weight: 125 kg range L-W-H: 500 x 600 x 1900 mm Furnishing: - manual spindle feed - including thread cutting function - continuous speed adjustment (variomatic) - Digital drilling depth display at the front - Digital speed display at the front - Work table height adjustable via hand crank & T-slots - V-belt drive - pole-changing motor - EMERGENCY stop button at the front - Front main/toggle switch - User manual (PDF) Machine link: http://mhp.logotech.de/hpm/v7/Datenblatt/datenblatt.php?machineno=1008 -9103752 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

PRESS DESIGN   drive system: hydraulic   frame design: H-frame, monoblock   openings in uprights: yes   number of suspensions: 2   table cushion: yes PRESS FORCES   total force (nominal): 650 to PRESS TABLE   table surface (left-right): 3000 mm   table surface (front-back): 1800 mm SLIDE   slide force: 630 to   table surface (left-right): 3000 mm   table surface (front-back): 1800 mm   stroke: 1000 mm SLIDE (HYDR. PRESS)   approximation velocity max.: 200 mm/s   working velocity min.: 7 mm/s   working velocity max.: 15 mm/s   return velocity max.: 120 mm/s   return force: 65 to DIE CUSHION (TABLE CUSHION)   cushion force: 250 to   stroke: 400 mm   cushion plate surface (left-right): 2500 m ...

CONTROLS   electronic controls PRESS DESIGN   frame design: 4 column PRESS FORCES   total force (nominal): 400 to PRESS TABLE   table surface (left-right): 1200 mm   table surface (front-back): 800 mm SLIDE   slide force: 400 to   table surface (left-right): 1200 mm   table surface (front-back): 800 mm   stroke: 500 mm SLIDE (HYDR. PRESS)   approximation velocity max.: 290 mm/s   working velocity min.: 25 mm/s   return velocity max.: 290 mm/s   return force: 35 to TOOL ASSEMBLY DIMENSIONS   shut height (stroke down, adjustment up), BDC: 1100 mm ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 2255 mm   space requirements -front/b ...

MATEC forklift blades are robust and easy to build and can be attached to almost any commercial lyklift. With a fuse bolt, the tilting device can be blocked for special inserts. The front shutter flap can be mounted on any shovel. The interchangeable scraper is suitable for planing work such as removing ice, repelling soil, gravel or feed, etc. - Bucket width 1950 mm - Bucket depth type 1: 1000 mm, shovel depth type 2: 1330 mm - Bucket height without attachment 450 mm - Weight approx. 220 kg - Payload 2000 kg - Steel sheet 4 mm industrial lypainted - Fork shoes axle distance 800 mm - Fork tine width max. 170 mm - Fork thickness max. 60 mm - 4 lifting eyelets for krange slopes - Tilting device for cable pull with lifter and spring reset, securing bolt Options at extra cost: - Type 2 shovel depth 1330 mm Total price € 1590.00 - Front shutter € 590.00 - hydr. Liftin ...

Compact tractor with selectable four-wheel drive, infinitely variable hydrostatic travel drive, Diffentialsperre, 3-cyl.-Kubota diesel engine, 15 kw/20 HP EZ 5/95, only about 350 hours of operation, cabin, heating, power steering, turf tyres, Front hitch, front PTO, 2 x hydraulic connections front. Rear three point linkage, rear PTO 540/1,000 rpm. Complete with vehicle and good battery! Needs service, otherwise good machine. Price ex. export € 7.900 / / in Germany plus 19% VAT price € 9.401,- Equipment optional at extra charge available, E.g. snow blade, broom, centrifugal spreader roller spreader. We supply used winter maintenance technology - Holzhäcksler - engines and more - see photos!

Stock# U2284 Used stainless steel paddle mixer for continous work by Gloucester Material Handling Ltd (UK) with total volume 2700 l. Internal diameter of mixing chamber 1100 mm x 2840 mm length. Top feeding inlet has dimensions: 300 mm x 300 mm. Bottom front outlet has dimensions 300 mm x 440 mm. Mixer is equipped with stainless steel mixing shaft with welded 21 paddles. Front and back walls are bolted. Front wall is equipped with mechanical sealing of shaft. Back wall has standard sealing of shaft. Mixer had been running with electric motor 55 kW, 1500 rpm - but motor is not included. Mixer is equipped with gearbox and new mechanical sealing. No control panel included. Technical drawings of mixer and shaft are included. Mixer had been running in food production with reported output about 8-12 tons per hour. Machine is mounted on 6 stainless steel legs.

Key data: 500

Automatic under-table crosscut saw The complete unit consists of the automatic under-cutting saw (UKS 600 HA), a feed line with a new automatic positioning insert (TigerStop TS 6.0 L / 2019) and a run-off runway. 1. Automatic under-cutting saw UKS 600 HA - Working height: 800 mm - Diameter connection socket for suction chip catcher (machine): 120 mm - Diameter connection socket for suction contact hood: 120 mm - Suction speed: 20 m/sec - Suction capacity: 2000 m3/h - Diameter saw blade: 500 mm - Diameter saw blade bore: 80 mm - Saw blade overstand at 500 mm saw blade: 160 mm - Cutting speed at 500 mm saw blade: 78 m/sec - Short stroke for small wood cross-sections up to 240 x 120 mm (up to 36 strokes/min) - Long stroke for larger cutting widths up to 600 x 120 mm (up to 18 strokes/min) - Automatic protective hood and holding device - Cut triggering via two-hand control ...

GeneralVertical Machining Centres; Control: Control F0iMF CharacteristicsTable surface1400 x 560 mmMovement X / Y / Z1100/560/510 mmSpindle taperBT 40 Tool Magazine with60 PositionsDrive power (25% DC)15 kWDrive power (100% DC)11 kWSpeed max.12000 rpmMaximum load (table centre)1000 KgRapid feed X / Y / Z36/36/30 m/minDimensions (L x W x H)3,19 x 2,76 x 2,94 (3,82 x 3,58 x 3,01) mWeight approx.5500 KgStandard spindle 12,000 min-1, 15/ 11 kWStandard Spindle 12,000 min-1, 15/ 11 kW Spindle speed: 12,000 min-1 Output: 15/13/11 kW (20/17.33/15 HP) (25%ED/30min/cont) Torque: 119/70/57 Nm (87.76/51.62/42.04 ft·lbf) (25%ED/30min/cont)Spindle Taper 7/24 Taper #40/ Grip MAS Spindle Taper 7/24 Taper #40/ Grip MAS This specification uses the spindle No. 40 7/24 taper / Grip MAS tool holder. The grip type and retention knob type of ATC are specified separately.Retention Knob: Special (Center-Throug ...

Nominal force: 4000 tons Slider's undershoot to BDC: 10 mm Slider stroke: 630 mm Frequency of continuous strokes per min: 10 The highest frequency of single strokes per min: 7 Closed height: 1180 mm Adjustment of closed height: 200 mm Slider's dimensions: -From left to right: 5000 mm -From front to back: 2000 mm Dimensions of the plate of the die: -From left to right: 5000 mm -From front to back: 2000 mm Capacity of the main drive: 250 kW Overall dimensions: -From left to right: 7640 mm -From front to back: 5980 mm -Height above floor level: 10490 mm

Parts made of compact tractor Shibaura SP 1840 (manual gearbox) with engine damage, e.B. cabin, rear axle gearbox, four-wheel drive front axle, three-point gear, steering, electrical parts, fairings, mask, wheels, front PTO gearbox, front lift, defective engine (cylinder head damage) etc.

Bore diameter: variabel mm Number of heads horizontal: 3 St. Number of heads vertical: 4 St. Dimensions (length / width): 4800 x 1600 x 2400 mm weight: 1500 kg Götzinger Power Drill Type BF 297 With the Götzinger PowerDrill you can, depending on the type and design: Griffoliven drill on the loose frame part or for finished wings, with multi-spindle drilling head, quick-change, also for milling of the lock case for WK 2 or intermediate gear Ecklager drill on loose frame part, with Mehrspindelbohrkopf, quick-change, corner-oriented over stop or custom made (tilt window) Drill vertically from above for fitting, pre-drill for clip on loose frame part Milling vertically from above for pushers, profile cylinders, 3-D hinges Horizontal drilling with 2 drilling units, different drilling diameters, Dowel drill front and long side, plywood / fighter, sprouts, Corner connection, front door etc. M ...

Bore diameter: variabel mm Number of heads horizontal: 3 St. Number of heads vertical: 4 St. Götzinger Power Drill in special version with dübelleim and press-in station With the Götzinger PowerDrill, you can choose: - Drill the front and long sides - Doweling of doors, seatings, fighters - The drilling patterns are freely programmable - You can: Grip handle and corner bearing, with quick-change Multi-spindle drilling heads - You can: lock casings, pusher and PZ as well as 3D tapes and drill - The machine has a horizontal and a vertical milling unit - A simple control lets you create drilling and milling programs, Save and recall POWER DRILL - drilling and milling machine Universal drilling machine for drilling olives, corner bearings, dowel work On the front and the front, milling, lock boxes, tapes, etc. Base in stable design, covered with sheet metal Table top 1800 x 200 mm  ...

working length: mm Working width: mm Working height: mm TGT Robby 420 universal, the glass mounting device for working without Effort The TGT Robby 420 420 universal is battery powered and its Telescoping movements, crane arm forward (work 1,25 m in front of the wheels), adjust large discs sideways exactly (100 mm to the right 100 mm to the left), and the lift head to Tilt 60 ° and turn 180 ° upwards, are using a Cable remote control made. Equipped with an Accusauganlage carrying capacity approximately 500 kg the TGT Robby 420 universal is the safe response aid. Of course, the lift head can also be rotated 360 ° manually. moreover The lift head can be equipped with an articulated joint (Turn the disc completely sideways) to drive through narrow doors to be able to. The TGT Robby 420 universal is also with a strong front-wheel drive equipped, so the effor ...

Displacement 3.33 ltr., power 55 kw/74 hp 36/36 speed manual transmission with hydraulic reversing gear and powershift stage Vmax 40 km/h All-wheel drive can be switched on, automatically engaged during braking, Differential lock both axles (front self-locking) Front power lift FOLGER Cat. II + + ports dw Hydraulic connections 3 x dw at the rear Tyres 320/85 R20 AS (12.4 R20 glue) front, co-steering fenders Tyres 420/85 R30 AS (16.9 R30 glue) rear Rotating 6 work lights, auxiliary main headlights for winter service use Air-sprung Grammer Comfort driver's seat with armrests Air conditioning, Recirculation, Radio, Passenger seat PTO 540/540E, speed accumulator, with external switch on the rear fender Rear power lift Cat. II with high-speed hooks, Automatic pull mouth, height adjustable in grid rail Glass roof cabin with sun visor, interior spies, exterior mirrors ca ...

ully automatic wood copy milling machine make REICHENBACHER type KS225Make -No: 1182, year of construction 10/1994 with Siemens OP 393 III controlSimultaneously mills and grinds two small parts with complicated shapes, such as tobacco pipes, golf club heads, sports pistol grips, wooden shift levers, etc.Technical specifications:machine constructionStable frame construction in a closed, against dust andNoise-encapsulated housing. Upper area of the front with gas pressure springHinged door, with security window.machine equipmentTo craft 2 copies of a model at once, you have:2 milling spindles each with a milling head dia. 240 mm (equipped with HS steels), via flat belts jointly driven by motor 2.2 kW; number of milling spindles 7200 rpm; Direction of rotation right.2 grinding units each with a 120 mm wide endless grinding belt, together with a 0.75 kW motor driven; belt speed 13 m/s; wi ...

WSM Stationary screwdriving unit screwdriving station Assembly of parts for car radios and navigation systems and for testing them. The assembly station is surrounded by a protective enclosure. The service doors are equipped with interlocking monitoring switches. The doors are locked in automatic mode and can only be opened when the automazik stop or in manual mode after pressing the doors on the control panel. When the door is open, automatic operation cannot be started. Functional sequence The station is equipped with the pre-assembled assembly via the transfer belt. The work steps of the automatic station with a run of a WT are described below. In normal operation, all 3 stations work in parallel. - Positioning the WT with the pre-assembled assembly in St.2.1 - Lowering the wearer with the scanner and the vision sensor - Scanning of the 3 codes (front panel, fro ...

Hassia Redatron G2 PE flat foil bag filling for soil, peat, mulch, etc., used, good condition, in operation until 10/2021 + Belt feeder (drain-saturated, time-controlled), with chains and dosing plate for soil and peat (and topsoil) + PE flat film bagging Hassia Redatron G2 (incl. shaped shoulder) + Trigger tape Bag formats: + Common sizes for earth and peat possible + Roll sizes for 8L to 80L possible (we can establish contacts with film producers) + punched carrying handle possible + Side fold possible + Moulded shoulder available (we check) or can be retrofitted individually at any time Documentation available. Space requirement approx. 4.0 x 4.0 m, height approx. 6.5 m. The current location of the plant (dismantled) is Visbek, Germany. A riser conveyor should be added as a feeder for the belt feeder. In addition, one could consider adding a short piece of v ...

TECHNICAL DATA SHEET CNC – Travelling column milling machine Make PARPAS Type SHARK One Control HEIDENHAIN iTNC 530 HSCI Year of construction 2016 Travel Longitudinal movement (X-axis) 3,500 mm Transverse movement (Y-axis) 1,083 mm Vertical movement (Z-axis) 1,074 mm Clamping table Clamping surface 4,000 x 1,000 mm Threaded holes with fitting seat Feeds X-, Y- and Z-axis, infinitely variable 2 - 30,000 mm/min. Rapid traverses in X / Y / Z 30 m/min feed force of the axes 10,000 N 2-axis milling head 2-axis milling head TUB-E92 with drive viaTorque motors for 5-axis simultaneous machining Power at 100 % ED 29 kW Speed range, infinitely variable 0-18,000 min-1 torque 92 Nm Rotational speed axis A/C 60 min-1 Tool holder HSK 63A – DIN 69893 Clamping force A-, C-axis 2,300/4,000 Nm Automatic tool changer ATC Tool stations 30 places  ...

Spindle swivel: Yes -45 to 45Â; Height adjustment: electric; Swivel adjustment: electric; Stop adjustment: manual; Height display: digital; Swivel angle indicator: digital; Milling stop indicator: mechanical counter; Spindle diameter: 30 mm; Speeds: 3000, 4500, 6000, 8000, 10000 rpm; Power consumption: 7 kW; Engine braking: Yes, automatic; Suction port: 1 x 120mm, 2 x 80mm; Machine length: 2500mm; Machine width: 1250mm; Weight: 510kg; Stable steel-grey cast iron construction Dynamically balanced milling unit anchored to the work table Particularly robust construction Smooth running thanks to precision units and high dead weight Standard with clockwise-counterclockwise rotation and electronic locking when changing direction 5 Speeds from 3000 - 10000 min ̄¹ Speed change is easy and convenient from the machine side Standard with MK 4 interchangeable spindle system La ...

BOVONE BISELLATRICE 471 glass beveling machine was manufactured in Italy in 2012. The machine designed to meet even the most diverse customer requirements, proves ideal for the precise machining of even the smallest glass sheets with a thickness of up to 25 mm. Made from the highest quality cast iron, the body of the glass bevelling machine guarantees high reliability, efficiency and stability during the working process. Flat and oblique glass edges are ground using 12 grinding wheels (including felt, diamond and peripheral grinding wheels), the configuration of which enables operation at very high working speeds. The total weight of the machine is 4400 kg. Technical specifications of the BOVONE BISELLATRICE 471 glass bevelling machine - maximum glass thickness: 25 mm - minimum glass thickness: 3 mm - minimum glass dimensions: 35×35 mm, 25×500 mm - number of spindles: 12 - work ...

(Schloemann) Beche DGH 40 Ton ( Revamped by Schuler group 2019) Manufacturer: BECHE (Schloemann) Type: DGH 40 YOM: Revamped 2019 Machine Number: 2412-HW Including 12 Ton Wellman manipulator Impact work: 40,000 mkg Total bar lift.:1.250 mm Maximum number of strokes:80 Pro Minute Average score: 6 Pro Minute Air consumption per ten blow Blow in . m in required air at the strongest hit: 6.8 Cold Air Compressor performance in m3/min: 41 Cold Air Compressor performance in m3/min:27 Hot air (160° C) Power requirement of the compressor in hp:260 Cold Air Power requirement of the compressor in hp:180 Cold Air Air tank capacity:30 m3 Steam consumption per hit with the strongest hit:3.5 kg Steam consumption per minute (saturated steam):21 kg Clear width between the guides: 1200 mm Maximum singing sounds: 2700 mm Lowest overall height of the dies without dovetail: 575 mm O ...

pressure: 200 t chamfer lenght: 4100 mm distance between columns: 3150 mm stroke - stepless adjustable: 200 mm column arm: 300 mm table height: 1090 mm dayligth: 450 mm working feed: 9,0 mm/sec return speed: 80,0 mm/sec Control: NC ATL 550 hydraulic: 265 bar voltage: 380 V total power requirement: 18,7 kW weight: 15000 kg range L-W-H: 4400 x 1900 x 3000 mm Furnishing: - NC controlled hydraulic press brake, with torsion shaft - with ATLANTIC NC control ATL 550 Positioning of backgauge ( X ) Depth setting positioning ( Y1+Y2 ) Possibility of programming different programs Storage capacity max. 200 programs - max. 400 sentences Pivoting control panel, front left - electric backgauge, on ball screws with 2 stop fingers, manually adjustable - manual table crowning, with analogue display Adjustment at the front left, with a hand crank - divided deer foot upper tool 85° - reversible Mul ...

WEINIG / GreCon Short Wood Finger-jointing Line Ultra TT Data of the system: • Wood inlet length (min. - max.) 150 - 1000 mm (1300 mm) • Reference timber inlet length at the finger-jointing line 400 mm • The length of the wood to be processed must be at least 25 percent longer than the width of the wood to be processed • Wood thickness (min. - max.) 20 - 80 mm • Reference wood thickness 28 mm • Wood width (min. - max.) 40 - 205 mm • Reference wood width 90 mm • Reference wood cross-section 28 mm x 90 mm • Wood outlet length (min. - max.) 3000 - 6100 mm • Reference wood outlet length 6100 mm • Tine profile (length) 10 – 11 mm • Max. wood cross-section for processing softwoods (with specified tine length) 100 cm² • Max. wood cross-section for processing hardwoods (with specified tine length) 80 cm² • Glue type PVAC • Species: Softwood / ...

pressure: 300 t chamfer lenght: 3100 mm distance between columns: 2550 mm column arm: 500 mm ram stroke speed: 140 mm/sec return speed: 150 mm/sec work speed: 10,0 mm/sec work stroke: 320 mm dayligth: 590 mm table height: 905 mm oil volume: 400 ltr. voltage: 400 Volt working pressure: 283 bar Number of working hours: ~ 21.835 h total power requirement: 23,0 kW weight: 18.250 kg Dimensions (HxWxD): 4550 x 2250 x 3050 mm current new price ~ 135.000 euros -------------------------------------------------- Press brake with special equipment increased installation height increased cylinder stroke as well as increased bending beam speeds -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T (touch screen) 2D graphic touch screen programming mode 17 high-resolution color TFT Complete Windows application suite Delem Modusys compatibility (module  ...

Gernep labelling machine type Labetta 4 / 3 / 10 640 A year of manufacturing: 2013 capacity: 7.500 bph work direction: right to left rotation: clockwise Stainless steel bottom frame instead off standard carbon steel bottom frame Format parts for: - 33 cl Vichy – Longneck – 30 cl BNR ; Neck, front and back label. - 2 different front label format parts 33 cl longneck; - 75 cl Bierre Belge bottle Corked; Neck, front and back label. Air driven glue pumps replaced by electrical driven glue pumps. Introduction wraparound labeler 2020, less wet glue labels since then. Incidental residual wet glue labels ran still May 2022 (remaining stocks) - machine conserved. Machine still in bottle line for conveyor use only, but stilll able to run. The machine is still in production until the mid of November 2023

Hörger SKU 1500 Artificial Grass Cleaning Device Artificial Grass Cleaner SKU for sand-filled or granule-filled artificial grass. The artificial turf cleaner consists of a cleaning attachment in the front attachment and a tank-pump unit in the rear attachment. The rear tank is divided into a fresh water and a dirty water area. The PTO-driven high-pressure pump sucks in the fresh water and transports it via hoses to the front of the front cleaning attachment. Due to the large working brush diameter of 500 mm, the machine can be used for three different working procedures are carried out. 1. Maintenance cleaning: Depending on weather conditions, every 14 days to monthly; Coarse dirt and dust that has settled in the meantime as well as pole abrasion are removed. 2. Intensive cleansing with loosening: About every 3 months; Coarse dirt is removed, fine particles consis ...

Hörger SKU 1500 Artificial Grass Cleaning Device Artificial Grass Cleaner SKU for sand-filled or granule-filled artificial grass. The artificial turf cleaner consists of a cleaning attachment in the front attachment and a tank-pump unit in the rear attachment. The rear tank is divided into a fresh water and a dirty water area. The PTO-driven high-pressure pump sucks in the fresh water and transports it via hoses to the front of the front cleaning attachment. Due to the large working brush diameter of 500 mm, the machine can be used for three different working procedures are carried out. 1. Maintenance cleaning: Depending on weather conditions, every 14 days to monthly; Coarse dirt and dust that has settled in the meantime as well as pole abrasion are removed. 2. Intensive cleansing with loosening: About every 3 months; Coarse dirt is removed, fine particles consis ...

Fully automatic Saddle stitcher Configuration: Fully automatic from feeder to trimmer • 1 cover folder feeder • 1 horizontal sheet feeder • 6 vertical sheet feeders • Control panel with main operating point • Stitching machine with wire feed gear • Trimmer with trimmer feed • Compensating stacker RIMA RS-14 Technical specifications: Maximum format untrimmed 320 - 350 x 460 mm Maximum trimmed format 340 x 450 mm Maximum cutting thickness (single use) 12 mm cutting thickness (double use) 1/2x punch knife width Maximum staple thickness 6 mm Maximum trimming front trimming 50 mm Maximum trimming head and foot trimming 50 mm Stitching heads max. 4 Hohner narrow stitching heads staple length of the vertical feeders approx. 250 mm (depending on the paper) Arch opening vacuum suction cups at least 6 mm rear fold, 8 mm front fold, Sheet opening gripper max. 20  ...

GeneralMilling Specification; Control: Control M730UM with CELOS CharacteristicsMax machining diameter278 mmDimensions (L x W x H)2,82 x 2,09 x 2,15 mDrive power tool spindle5,5/5,5/3,7 kWDrive power main spindle11/15/15 kWRapid feed X / Z30/30 m/minInput precision of C-axis on Mainspindle0,001 degreeMovements X / Z260/590 mmRotary tool spindle speed10000 rpmNumber of tool stations12 Speed max.6000 rpmBar diameter max.52 mmSwing- Ø, max.755 mmMax. Turning Length192 mmWeight approx.4900 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and pHigh-output spindle (Left Spindle) 15/ 11 kW, 6,000 min-1(Left Spindle) High-Output Spindle 15/11 kW (20/15 HP), 6,000 min-1 The NLX ...

GeneralCNC Turning Centre with C axis and tool drive; Control: Control M730UM with CELOS CharacteristicsMax machining diameter356 mmDimensions (L x W x H)2,82 x 2,09 x 2,15 mDrive power tool spindle5,5/5,5/3,7 kWDrive power main spindle15/22/22 kWRapid feed X / Z30/30 m/minInput precision of C-axis on Mainspindle0,001 degreeMovements X / Z260/590 mmRotary tool spindle speed10000 rpmNumber of tool stations12 Speed max.-5000 rpmBar diameter max.65 mmSwing- Ø, max.755 mmMax. Turning Length510 mmWeight approx.5000 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and pHigh-output spindle (spindle 1) 22/ 15 kW, 5,000 min-1The NLX 2000 adopts a highly reliable main spindle de ...

GeneralCNC Turning Centre with C axis and tool drive; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways700 mmTurning diameter410 mmTransverse stroke300 mmLongitudinal stroke850 mmMax. Turning Length800 mmClamping chuck diameter max.315 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)33 kWC-Axis Speed-200 rpmSpeed range20 - 4000 rpmTorque (100% DC)580 NmTorque of C-Axis (holding torque)225 NmAccuracy at point stopping0,01 degreeTool holder 1Shank diametre according to DIN 6988040 mmNumber of tool stations12 Number of driven tools12 Speed max.-4000 rpmPower max. (40% DC)11,3 kWFloor space/WeightWeight approx.6500 KgDimensions (L x W x H)3,99 x 2,69 x 1,99 mTechnologie cycle alternating speedTechnology cycle for the  ...

GeneralCNC Turning Centre with C axis and tool drive; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways700 mmTurning diameter410 mmTransverse stroke300 mmLongitudinal stroke850 mmMax. Turning Length800 mmClamping chuck diameter max.315 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)33 kWSpeed range20 - 4000 rpmC-Axis Speed-200 rpmTorque (100% DC)580 NmTorque of C-Axis (holding torque)225 NmAccuracy at point stopping0,01 degreeTool holder 1Number of driven tools12 Shank diametre according to DIN 6988040 mmSpeed max.-4000 rpmNumber of tool stations12 Power max. (40% DC)11,3 kWFloor space/WeightWeight approx.6500 KgDimensions (L x W x H)3,99 x 2,69 x 1,99 mTechnologie cycle alternating speedTechnology cycle for the  ...

GeneralCNC Turning Centre with C axis and tool drive; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways700 mmTransverse stroke300 mmTurning diameter410 mmMax. Turning Length800 mmLongitudinal stroke850 mmClamping chuck diameter max.315 mmBar diameter max.65 mmMain drive 1Drive power (100% DC)25 kWSpeed range25 - 5000 rpmTorque (100% DC)280 NmC-Axis Speed-200 rpmTorque of C-Axis (holding torque)225 NmAccuracy at point stopping0,01 degreeWork spindle (left)Diametre of spindle nose170h5 mmSpindle noseFlat flange Spindle bore87 mmSpindle diametre on front bearing130 mmFloor space/WeightDimensions (L x W x H)4,46 x 1,88 x 2,30 mWeight approx.6500 KgTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.-4000 rpmPower max. (40% DC)11,3 kWTechnologie cycle alternating speedTechnology cycle for the  ...

General2-Axes Universal Turning Center with driven tools, C-axis, Y-axis and counter spindle - Direct measuring system for X / Y axis; Control: DMG MORI SLIMline® multi-touch control Working areaSwing diameter over guide ways700 mmSwing diameter over transverse guideway370 mmBar diameter max.80 mmTurning diameter400 mmSlide 1Longitudinal stroke755 mmTransverse stroke276 mmY axis, vertical+/- 60 mmRapid traverse in X30 m/minRapid traverse in Z30 m/minRapid traverse in Y22,5 m/minMain drive 1Drive power (100% DC)17 kWDrive power (40% DC)25,5 kWSpeed range- 4000 rpmTorque (100% DC)283 NmMax. torque (40% DC)426 NmC-Axis Speed-200 rpmTorque of C-Axis (holding torque)426 NmWork spindle (left)Spindle noseA2-8 Bar diametre80 mmSpindle diametre on front bearing130 mmWork spindle (right)Spindle noseA2-6 Bar diametre50 mmSpindle diametre on front bearing100 mmMain drive 2Drive power (100% DC)13 kW ...

It is used in rubber and plastics mixing, warming mixing, sheeting mixing, etc. III Equipment specification XK400×1000 mixing mill 1. Main technical specification NO. Item Main technology data and feature A Main technology data 1 Roll diameter 400mm 2 Roll working length 1000mm 3 Roll linear speed Front:14.85m/min Rear:18.85m/min 4 Speed ratio of rolls 1:1.27 5 Max roll space 10mm 6 Compound feeding capacity 25kg-35kg 7 Motor power 37KW,n=980r/min，IE3 8 Dimensions 4400X1710X1850mm 9 Gross weight 8500kg B Feature of main machine 1 Roll size(mm) Ф400×1000 material alloy chilled hard cast iron, surface hardness HS70±2,Surface roughness: Ra0.2 Bearing type Adopt the aligning roller bearing, copper pressure ring, bearing taper 1:12 type Front roll is drilled roll and rear roll is drilled roll, can pass cooling water, e ...

GeneralTurning-milling centre - partial hollow clamping device - drawtube ID 68 mm - C-axis and spindle brake (hydraulically) - upper compound slide with turning-/ milling spindle, reception HSK-A63, DIN 69893 with 3-fold Hirth-coupling 1°-Indexing to lock the spindle during turning operations - Y-axis - B-axis interpolating with hydraulically locking - tool magazine 1 x 60-fold, shelf magazine with tool changer and handling unit, additional 4 tool loading stations; Control: Sinumerik 840D powerline Technical DataDrive power (100% DC)13,2 kWDrive power (40% DC)22 kWTorque (40% DC)100 NmSpeed range20-12000 rpmB axis, slide 1Swivelling range+/- 120 degreeSlide 3Transverse stroke1500 mmRapid traverse Z36 m/minSlide 2Longitudinal stroke1400 mmTransverse stroke225 mmRapid traverse X24 m/minRapid traverse Z40 m/minSlide 1Longitudinal stroke1585 mmTransverse stroke550 mmY axis, vertic ...
