four column press used for sale

Jessinegg + Urban, Stroke 300, Lift: 300, table 450x370, 1300kg

Hydropneumatic TOX column press, special design, equipped with TOX powerhouse type X-K 095.3030.400.61. Stable steel frame, large work table with tool holder, upper crossbeam with integrated pressing/joining unit. Suitable for joining, pressing and assembly processes in series production. Pressing unit: TOX Pressotechnik Type powerhouse: X-K 095.3030.400.61 Serial number: 811193.4 Hydropneumatic column press with work table and T-slot holder. Technical data: Operating pressure: 6 bar force (estimated, TOX standard): At Ø 95 mm and 6 bar → ≈ 42–45 kN Final force ΔV (oil volume): 376 ml Functional principle: pneumohydraulic (TOX booster) Stroke: approx. 60 mm total movement (typical 30 mm rapid stroke + 30 mm force zone) Auction-ID: A7-49816-11

Single-column press - With table base - Various press accessories Pressure 2 t Projection 150 mm Stroke 150 mm Table surface 310 x 250 mm Drive power 2.0 kW Machine weight approx. 0.6 t Dimensions approx. 1.2 x 0.8 x 1.7 m Condition: unchecked (6) Auction-ID: A7-50084-44

Offer 26244 Technical data: - Max. pressing force 63 t - Max. ram stroke 500 mm - Lifting speed 200 mm/sec - Return 400 m/min - Installation height 800 mm - Projection to the middle of the ram 360 mm - Plunger clamping surface 530 x 460 mm - Plunger clamping pin 40 mm - Table size 750 x 560 mm - Table bore / breakthrough 180 mm - Table height above floor 700 mm - Oil capacity approx. 300 ltr - Drive 380 V / 11 kW - Space requirement approx. W 1150 x H 3100 x D 1750 mm - Weight approx. 4300 kg

Offer 26245 Technical data: - Max. pressing force 100 t - Max. ram stroke approx. 500 mm - Lifting speed 25 mm/sec. - Return 125 mm/min - Installation height approx. 800 mm - Projection to the middle of the ram 380 mm - Pusher clamping surface 530 x 400 mm - Plunger clamping pin 40 mm - Table size 750 x 560 mm - Table hole / through hole in the table 200 mm - Table height above floor 720 mm - Oil capacity approx. 200 ltr - Drive 400 V / 11 kW - Space requirement approx. W 1150 x H 2980 x D 1850 mm - Weight approx. 4600 kg

pressure: - t distance between columns: - mm stroke: - mm total power requirement: - kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

MODEL SL-150 Power t 150 Motor power kw 4 Piston stroke mm 250 Working speed mm/s 3.1 Return speed mm/s 4 Head displacement mm 1,000 Front light mm 1,500 Side light mm 340 Max. vertical span mm 955 Bed light mm 405 Total front mm 2,150 Total side mm 1.180 Total height mm 2.805 Weight kg 2.350 STANDARD DESCRIPTION: The S-series hydraulic presses are specially designed for extraction, casing and straightening work. They work with a hydraulic pressure of less than 320 bar, which guarantees greater durability of the entire hydraulic system. STRUCTURE: They consist of an electro-welded structure with four uprights with open sides. They are equipped with a movable bed that allows it to be positioned at different heights. The fixing is done by means of two pins located at the bottom of the bed. The raising and lowering system is carried out by means of cha ...

STANDARD FEATURES: Power 50 t Motor power 1.5 kw Working speed 2.25 mm/s Return speed 4.50 mm/s Maximum pressure 500 bar Piston stroke 150 mm Spindle stroke 120 mm Front light 800 mm Side light 160 mm Max. vertical span 1,020 mm Bed light 205 mm Total front 1,090mm Total side 900 mm Total height 2,000 mm Weight 295 Kg. Specially designed for extraction, bushing, straightening, etc. The hydraulic presses of the S series consist of a four-pillar electro-welded structure with open sides. They have a movable base that allows it to be positioned at different heights. The fixing is by means of two pins located at the bottom of the bed. The raising and lowering system is by means of chains driven by the cylinder of the press. SD Models: are fixed head. Double-acting cylinder with chrome-plated plunger and anti-wear guides. It is equipped with a removab ...

TJF-GARNET SPECIAL HYDRAULIC PRESS: Hydraulic press with double upright equipped with two side cylinders joined by a plate for the pre-pressing and pressing of rotors and stators, and a central cylinder for the extraction of the mandrel and stalling of the rotor shaft, as well as the extraction of shafts in case of repair. It has a removable table for the stacking and handling of rotors and stators. MAIN CYLINDERS 150 TN.  2 hydraulic cylinders of 75 Tn. of power each, with a stroke of 1200 mm joined by a grooved plate, with a central bore of 250 mm in diameter.  Maximum useful height cylinder plate of 1550 mm.  Minimum useful height cylinder plate of 350 mm. ABSTRACTION CYLINDER  1 central cylinder of 80 Tn of power with 1200 mm stroke.  Prepared to adapt abstraction clamp, end of threaded stem to M 35,150 x 40 in length.  Maximum useful height ...

Key data: 400 t

The following machines are involved: Müller-Weingarten ZE 400-16.19, 400 t double column press, approx. 1,600 × 1,300 × 1,400 mm, year of construction 1963, conversion 1991. Müller-Weingarten ZE 400-20.13.2, 400 t double column press, approx. 2,000 × 1,300 × 1,200 mm, year of construction 1977, conversion 1991.

pressure:800 t distance between columns:2900 mm stroke:350 mm Controls:SIEMENS PRESS DESIGN:. - frame design : H-frame :. - Drive type : mechnical :. - openings in uprights : yes :. - number of cushions:0 - opening in table : yes :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):800 to PRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - rectangular breakthrough (width):2000 mm - rectangular breakthrough (front-back):1800 mm - height above floor level:850 mm RAM:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /min RAM (MECHAN. PRESS):. - ram adjustment:350 mm TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):2900 mm - Free passage between side columns (width):2560 mm ...

pressure:40 t throat:220 mm stroke:8 / 88 mm table pass:ø- abgesetzt 225/200 mm ram head dimension:400 x 250 mm distance table/ram:228 mm stroke adjustable from - to:30 - 140 mm ram adjustment:63 mm thickness of bolster:80 mm no. of strokes:70 Hub/min total power requirement:5,5 kW weight of the machine ca.:2600 kg dimensions of the machine ca.:1100 x 1300 x 2300 mm Documents:vorhanden

pressure:250 t passage width:1280 mm stroke:bis 500 mm total power requirement:47 kW weight of the machine ca.:23 t dimensions of the machine ca.:2200 x 1850 x 4600 mm table surface area:1250 x 1000 mm dayligth:800 mm daylight between the side columns:520 x 750 mm table height above floor:1000 mm Documents: vorhanden

pressure:063 t throat:250 mm stroke:8 - 100 mm no. of strokes:56 / 84 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:710 x 500 mm hole in the table:320 mm table height over floor:800 mm passage to the back:320 mm ram surface:450 x 280 mm ram adjustment:63 mm weight:4,1 t dimensions (W x D x H):1,35 x 2,0 x 2,6 m overload protection in ram:mechanical

pressure:200 t distance between columns:2100 mm stroke:550 mm Distance table/ram, stroke up:1800 mm table surface area:2000 x 2800 mm table height over floor:760 mm ram surface:2000 x 2000 mm Side window:2000 mm feed down:400 mm/s power requirement:51,0 kW weight:33,0 t dimensions (WxDxH):3,25 x 3,5 x 5,4 m Height above floor:5,4 m foundation pit:not necessary

pressure:200 t distance between columns:2100 mm stroke:550 mm Distance table/ram, stroke up:1800 mm table surface area:2000 x 2800 mm table height over floor:760 mm ram surface:2000 x 2000 mm Side window:2000 mm feed down:400 mm/s power requirement:52,0 kW weight:33,0 t Dimensions (WxDxH):3,25 x 3,5 x 5,4 m Height above floor:5,4 m foundation pit:not necessary

pressure:400 t distance between columns:3250 mm distance table/ram, max. stroke up, adjustment up:1000 mm stroke:800 mm table surface area:3250 x 1400 mm table height over floor:1250 mm die cushion capacity:170 t die cushion stroke:200 mm die cushion area:1800 x 1000 mm distance between cutting impact cushioning:2610 mm side window:800 mm ram surface:3250 x 1400 mm return capacity:51 t speed down:300 mm/s speed up:300 mm/s working speed:16 - 33 mm/s quantity of oil:2900 l power requirement:100,0 kW weight:70,0 t Dimensions (WxDxH):4,9 x 3,1 x 7,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact absorption:hydraulic

pressure:400 t distance between columns:1250 mm stroke:250 fix mm no. of strokes:45 /min distance table/ram, max. stroke up, adjustment up:825 mm table surface area:1000 x 900 mm column travel -side:400 x 700 mm ram surface:1000 x 900 mm ram adjustment:100 mm capacity of ejector in table:40 t ejector stroke:160 mm power capacity:270,0 kW weight:44,0 t Dimensions (WxDxH):2,4 x 3,6 x 7,2 m height over floor:6,4 m

pressure:125 t stroke:25 fix mm no. of strokes:70 - 700 /min distance between columns:1150 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:1150 x 1000 mm hole in the table:900 x 220 mm side window:650 mm ram surface:990 x 850 mm ram adjustment:60 mm material width:250 mm material thickness:2,5 mm power requirement:46,5 kW weight:29,5 t roll feed:mechanical, Schuler, WK 8-250

Pressure:080 t throat:380 mm stroke:8 - 112 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:472 mm table surface area:840 x 610 mm table height over floor:800 mm passage to the back:520 mm ram surface:650 x 400 mm ram adjustment:70 mm power capacity:7,5 kW weight:6,9 t Dimensions (WxDxH):1,1 x 2,15 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical ram counterbalance:pneumatic clutch-/ brake combination:pneumatic

pressure:250 t distance between columns:930 mm stroke:200 mm Distance table/ram, stroke up:600 mm table surface area:900 x 860 mm die cushion capacity:100 t die cushion stroke:50 mm die cushion area:350 x 400 mm table height over floor:950 mm side window:380 x 380 mm ram surface:850 x 700 mm feed down:400 mm/s feed up:400 mm/s working feed:30 mm/s oil volume:350 l power capacity:45,0 kW weight:11,5 t Dimensions (WxDxH):2,0 x 1,2 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic depth stop:mechanical foundation pit:not necessary

pressure:1000 t distance between columns:3030 mm stroke:350 mm Distance table/ram, max. stroke up, adjustment up:1400 mm table surface area:3000 x 2000 mm table height over floor:430 mm side window:1450 x 1400 mm ram surface:3000 x 2000 mm speed down:300 mm/s speed up:340 mm/s working speed:18 - 44 mm/s return capacity:120 t oil volume:4400 l width with platform:4950 mm power capacity:2 x 90,0 + 10,0 kW weight:87,0 t Dimensions (WxDxH):4,35 x 3,65 x 7,55 m height over floor:6,05 m height beneath floor:1,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:200 t distance between columns:1650 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1200 mm table surface area:1600 x 1250 mm die cushion capacity:80 t die cushion stroke:300 mm die cushion area:1300 x 900 mm table height over floor:800 mm ram surface:1600 x 1250 mm oil volume:ca. 2000 l power capacity:43,0 kW weight:25,0 t Dimensions (WxDxH):2,9 x 2,3 x 5,8 m height beneath floor:0,85 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20

pressure:350 t distance between columns:1350 mm stroke:900 mm distance table/ram, max. stroke up, adjustment up:1300 mm table surface area:1300 x 1000 mm pressure of drawing cushion in table:100 t stroke of drawing cushion in table:380 mm die cushion area:350 x 285 mm capacity of ejector in ram:25 t ejector stroke in ram:200 mm table height over floor:750 mm ram surface:1300 x 1000 mm speed down:500 mm/s speed up:160 - 470 mm/s working speed:16 - 44 mm/s drawing speed:57 - 160 mm/s return capacity:32 t oil volume:1700 l power requirement:91,0 kW Dimensions (WxDxH):3,75 x 2,8 x 7,2 m height over floor:5,28 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:in TDC foundation pit:necessary

Pressure:063 t throat:250 mm stroke:8 - 100 mm no. of strokes:120 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:700 x 500 mm hole in the table:250 mm table height over floor:800 mm passage to the back:320 mm ram surface:450 x 280 mm ram adjustment:63 mm weight:4,5 t Dimensions (WxDxH):1,6 x 2,0 x 2,8 m overload protection in ram:mechanical

Pressure:500 t distance between columns:1550 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1200 x 1300 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:150 mm die cushion area:950 x 950 mm table height over floor:1245 mm side window:1250 mm ram surface:1200 x 1300 mm speed down:750 mm/s speed up:780 mm/s working speed:105 mm/s oil volume:4000 l power requirement:263,0 kW weight:45,0 t Dimensions (WxDxH):3,3 x 3,3 x 6,1 m height over floor:6,1 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic cutting impact cushioning:motoric adjustable

Pressure:315 t distance between columns:1350 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1200 x 1300 mm table height over floor:1245 mm side window:1250 mm ram surface:1200 x 1300 mm speed down:750 mm/s speed up:680 mm/s working speed:180 mm/s oil volume:2000 l power requirement:150,0 kW weight:35,0 t Dimensions (WxDxH):3,3 x 3,3 x 5,5 m height over floor:5,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact cushioning:motorisch verstellbar ram interlocking:hydraulisch

pressure:160 t distance between columns:1340 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1300 x 900 mm table height over floor:930 mm side window:600 mm ram surface:1300 x 900 mm speed down:367 mm/s speed up:390 mm/s working speed:58 mm/s power requirement:30,0 kW weight:15,0 t Dimensions (WxDxH):2,5 x 2,2 x 4,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary

pressure:063 t stroke:70 fix mm no. of strokes:15 - 60 /min distance between columns:1340 mm width between oil collecting pans:1180 mm distance table/ram, max. stroke up, adjustment up:328 mm table surface area:1260 x 700 mm hole in the table:1000 x 100 mm table height over floor:1000 mm column travel -side:470 mm ram surface:1300 x 650 mm ram adjustment:100 mm power requirement:27,5 kW weight:13,7 t Dimensions (WxDxH):3,4 x 2,1 x 3,4 m clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric

Pressure:063 t throat:250 mm stroke:10 - 100 mm no. of strokes:120 /min distance table/ram, max. stroke up, adjustment up:380 mm table surface area:700 x 500 mm hole in the table:180 x 140 mm table height over floor:700 mm ram surface:360 x 275 mm ram adjustment:60 mm power requirement:5,5 kW weight:3,8 t Dimensions (WxDxH):1,9 x 1,7 x 2,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:hydraulic overload protection in ram:mechanical

pressure:150 t throat:400 mm stroke:30 - 150 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1000 x 750 mm hole in the table:320 x 200 mm table height over floor:800 mm ram surface:800 x 600 mm ram adjustment:85 mm weight:10,0 t Dimensions (WxDxH):1,4 x 2,2 x 3,1 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic ram counterbalance:pneumatic

pressure:250 t distance between columns:1125 mm stroke:250 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1100 x 900 mm pressure of drawing cushion in table:63 t stroke of drawing cushion in table:100 mm die cushion area:700 x 400 mm table height over floor:960 mm side window:700 mm ram surface:1080 x 900 mm oil volume:1000 l power requirement:35,0 kW weight:23,0 t Dimensions (WxDxH):2,5 x 2,3 x 4,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick foundation pit:not necessary

pressure:250 t throat:450 mm stroke:36 - 126 mm no. of strokes:40 /min distance table/ram, max. stroke up, adjustment up:525 mm table surface area:1000 x 750 mm hole in the table:400 x 360 mm table height over floor:1000 mm ram surface:600 x 500 mm ram adjustment:111 mm power requirement:19,0 kW weight:13,5 t Dimensions (WxDxH):1,3 x 3,2 x 3,35 m clutch:pneumatic overload protection in ram:mechanical ram adjustment:motoric

pressure:100 t distance between columns:1230 mm stroke:20 - 200 mm no. of strokes:20 - 60 /min distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1050 x 750 mm table height over floor:760 mm side window:540 mm ram surface:1000 x 750 mm ram adjustment:100 mm power requirement:18,0 kW weight:20,5 t Dimensions (WxDxH):2,8 x 1,9 x 4,3 m infinitely variable drive:PIV clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric

pressure:160 t distance between columns:880 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:830 x 1000 mm hole in the table:265 x 365 mm table height over floor:850 mm side window:610 mm ram surface:860 x 1000 mm power requirement:55,0 kW weight:14,7 t Dimensions (WxDxH):2,2 x 2,0 x 4,3 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 depth stop:motoric adjustable table:motoric foundation pit:not necessary

Pressure:250 t throat:450 mm stroke:8 - 135 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:635 mm table surface area:1250 x 850 mm hole in the table:355 mm table height over floor:950 mm passage to the back:660 mm ram surface:790 x 610 mm ram adjustment:120 mm power requirement:18,5 kW weight:14,0 t Dimensions (WxDxH):1,5 x 2,8 x 3,65 m German Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 clutch:pneumatisch overload protection in ram:mechanisch ram counterbalance:pneumatisch

pressure:500 t distance between columns:2400 mm stroke:400 fix mm no. of strokes:13 - 23 /min Distance table/ram, max. stroke up, adjustment up:1600 mm table surface area:2300 x 1800 mm column travel -side:1600 mm ram surface:2170 x 1800 mm ram adjustment:300 mm total power requirement:110,0 kW Weight:135,0 t Dimensions (WxDxH):3,35 x 4,85 x 7,0 m clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric

pressure:300 t distance between columns:2500 mm stroke:350 mm distance table/ram, max. stroke up, adjustment up:1280 mm table surface area:2500 x 1500 mm table height over floor:850 mm side window:900 mm ram surface:2500 x 1500 mm speed down:300 mm/s speed up:240 - 450 mm/s working speed:23 - 44 mm/s oil volume:3000 l power requirement:132,0 kW weight:54,0 t Dimensions (WxDxH):3,25 x 3,2 x 4,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:SITEMA

pressure:150 t throat:450 mm stroke:115 fix mm no. of strokes:45 /min distance table/ram, max. stroke up, adjustment up:400 mm table surface area:2250 x 1090 mm table height over floor:900 mm passage to the back:1900 mm ram surface:1900 x 900 mm ram adjustment:100 mm power requirement:16,0 kW weight:19,5 t Dimensions (WxDxH):3,0 x 2,3 x 3,9 m

pressure:200 t distance between columns:1800 mm stroke:710 mm Distance table/ram, max. stroke up, adjustment up:1100 mm table surface area:1600 x 1300 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:250 mm die cushion area:1400 x 1080 mm table height over floor:800 mm side window:1300 mm ram surface:1660 x 1300 mm speed down:400 mm/s speed up:410 mm/s working speed:14,3 - 49,7 mm/s power requirement:46,0 kW weight:25,0 t Dimensions (WxDxH):3,65 x 3,3 x 5,4 m height over floor:5,05 m height beneath floor:0,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard at front and back:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical

pressure:50 t distance between columns:1750 mm stroke:500 mm Distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1700 x 750 mm table height over floor:800 mm side window:650 x 750 mm ram surface:1700 x 750 mm power requirement:11,0 kW weight:11,0 t Dimensions (WxDxH):2,1 x 1,15 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary

pressure:015 t throat:200 mm stroke:4 - 70 mm no. of strokes:140 /min distance table/ram, max. stroke up, adjustment up:310 mm table surface area:430 x 395 mm hole in the table:165 x 160 mm table height over floor:560 - 735 mm table adjustable:175 mm ram surface:160 x 130 mm ram adjustment:80 mm power requirement:1,2 kW weight:0,9 t Dimensions (WxDxH):1,0 x 1,25 x 1,8 m clutch:Drehkeil overload protection in ram:mechanical

pressure:030 t stroke:8 - 40 mm no. of strokes:100 - 600 /min distance between columns:325 mm distance table/ram, max. stroke up, adjustment up:250 mm table surface area:540 x 300 / 325 x 395 mm hole in the table:315 x 110 mm table height over floor:1000 mm column travel -side:290 mm ram surface:250 mm material width of feeder:120 mm material thickness of feeder:3,0 mm feed length:60 mm power requirement:5,5 kW weight:2,6 t Dimensions (WxDxH):1,5 x 1,2 x 2,2 m clutch:pneumatic roll feed:mechanical, Bruderer BBV 120/60

pressure:100 t throat:350 mm stroke:6 - 100 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:400 mm table surface area:850 x 700 mm hole in the table:470 x 150 mm table height over floor:855 mm ram surface:450 x 300 mm ram adjustment:80 mm power requirement:7,5 kW weight:5,0 t dimensions (WxDxH):1,5 x 2,3 x 2,6 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical

pressure:500 t distance between columns:2240 mm stroke:1180 mm distance table/ram, max. stroke up, adjustment up:1800 mm table surface area:2050 x 1800 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:380 mm drawing cushion surface in table:1800 x 1200 mm pressure of drawing cushion in ram:122 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:1800 x 1200 mm ram surface:2215 x 1800 mm table height over floor:500 mm speed down:400 mm/s speed up:10 - 400 mm/s working speed:10 - 100 mm/s depth of the foundation:3,0 m power requirement:122 + 75 + 64,5 kW weight:110,0 t Dimensions (WxDxH):3,6 x 2,2 x 8,5 m height over floor:6,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table and ram:hydraulic

pressure:500 t distance between columns:3200 mm stroke:1250 mm distance table/ram, max. stroke up, adjustment up:1810 mm table surface area:3000 x 1900 mm pressure of drawing cushion in ram:150 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:2400 x 1200 mm ram surface:3160 x 1900 mm speed down:400 mm/s speed up:250 mm/s working speed:18 - 58 mm/s height over floor:6,5 m power requirement:90,0 + 36,5 kW weight:110 t German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic

pressure:800 t distance between columns:3010 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:1350 mm table surface area:3000 x 1800 mm table height over floor:500 mm side window:1500 x 1400 mm ram surface:3000 x 1800 mm speed down:300 mm/s oil volume:900 l height over floor:5,4 m height beneath floor:2,1 m power requirement:200,0 kW weight:80,0 t Dimensions (WxDxH):5,2 x 2,6 x 7,5 m ram interlocking:in TDC depth stop:mechanical

pressure:100 t distance between columns:1060 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:1250 mm table surface area:1000 x 700 mm pressure of drawing cushion in table:40 t stroke of drawing cushion in table:200 mm die cushion area:Ø 250 mm table height over floor:950 mm side window:580 x 750 mm ram surface:1000 x 700 mm oil volume:700 l power requirement:47,0 kW weight:13,0 t Dimensions (WxDxH):2,2 x 1,8 x 5,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical; motoric adjustable ram interlocking:SITEMA

pressure:160 t distance between columns:2050/1900 mm stroke:15 - 170 mm no. of strokes:15 - 40 /min distance table/ram, max. stroke up, adjustment up:690 mm table surface area:1600 x 800 mm side window:800 mm ram surface:1620 x 700 mm ram adjustment:140 mm power requirement:15,0 kW weight:24,0 t Dimensions (WxDxH):3,3 x 2,3 x 5,3 m height over floor:4,8 m height beneath floor:0,5 m clutch:pneumatic ram adjustment:motoric ram counterbalance:pneumatic

pressure:500 t stroke:40 - 160 mm no. of strokes:32 / 48 /min distance between columns:1620 mm distance table/ram, max. stroke up, adjustment up:660 mm table surface area:1600 x 1300 mm table height over floor:750 mm column travel -side:400 x 430 mm ram surface:1400 x 1200 mm ram adjustment:120 mm pressure of drawing cushion in table:60 t stroke of drawing cushion in table:100 mm drawing cushion surface in table:1300 x 810 mm material width of feeder:1000 mm material thickness of feeder:- 6,0 mm feed length:350 mm height beneath floor:0,3 m power requirement:44,0 / 66,0 kW weight:56,0 t Dimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 m height beneath floor without drawing cushion:0,3 m height beneath floor with drawing cushion:1,0 m clutch-/ brake combination:pneumatic; Desch overload protection in ram:mechanical ram counterbalance:pneumatic ram adjustment:motoric drawing cushion in table:pneum ...
