for measuring used for sale

Thread Measuring Screw, Threaded Shackle Measuring Screw FEINMESSZEUGFABRIK SUHL Range: 25 - 50 mm M 0.5 - M 5 with protective box Dimensions: 265 x 125 x 40 mm

Threaded Measuring Screw, Threaded Shackle Measuring Screw FEINMESSZEUGFABRIK SUHL Range: 0 - 25 mm M 0.4 - M 3 with protective box Dimensions: 245 x 110 x 35 mm

Fine Gauge Internal Measuring Instrument FEINMESSZEUGFABRIK SUHL 10 - 19 mm Dimensions: 250 x 180 x 70 mm

Threaded Measuring Screw, Threaded Shackle Measuring Screw FEINMESSZEUGFABRIK SUHL Range: 0 - 25 mm M 0.4 - M 3 with protective box Dimensions: 245 x 110 x 35 mm

Thread Measuring Screw, Threaded Shackle Measuring Screw FEINMSSZEUGFABRIK SUHL Range: 25 - 50 mm M 0.5 - M 5 with protective box Dimensions: 265 x 120 x 35 mm

Threaded Measuring Screw, Threaded Bracket Measuring Screw FEINMESSZEUGFABRIK SUHL Range: 0 - 25 mm M 0.4 - M 2.5 incomplete with protective box Dimensions: 255 x 110 x 35 mm

Threaded Measuring Screw, Threaded Bracket Measuring Screw FEINMESSZEUGFABRIK SUHL Range: 50 - 75 mm M 0.7 - M 5.5 incomplete with protective box Dimensions: 300 x 130 x 35 mm

Height measuring and scribing device digital, height ripper MITUTOYO up to 600 mm 192-614 445152 Dimensions: 805 x 180 x 120 mm

Height measuring and marking device digital, height ripper MITUTOYO up to 1000 mm 192-614 Dimensions: 1230 x 290 x 150 mm

Welding Table, Straightening Table, Straightening Plate, Work Table, Clamping Table Measuring Plate, Measuring Table PAGUS Work Surface: 355 x 260 mm Working Height: 65 mm Dimensions: 355 x 260 x 65 mm

Steinheil KONTUR 408-2/D optoelectronic contour and shaft measuring system High-precision optoelectronic contour and shaft measuring system Steinheil KONTUR 408-2/D with high-quality Jenoptik optics The system is used for contactless, high-precision and fast measurement of rotationally symmetrical components (e.g. shafts, camshafts, turned parts) The device scans the measuring object without contact according to the shadow image principle. Rotational measurements are recorded with up to 1440 measuring points on the circumference per measuring point. The evaluation and quality control is carried out directly via an integrated SPC software (Statistical Process Control) based on Windows NT with clear tolerance bars and diagrams The system is housed in a closed aluminium profile housing with a transparent protective structure and is protected by professional safety light curtains ...

Welding table, straightening table, straightening plate, work table, clamping table measuring plate, measuring table PAGUS work surface: 355 x 260 mm working height: 65 mm with holder for measuring stand Ø 20 mm ! Dimensions: 355 x 260 x 65 mm

illuminated measuring device for length displays HEIDENHAIN OTM1 M5 AOL1X Dimensions: 100 x 90 x 70 mm

Welding table, straightening table, straightening plate, work table, clamping table measuring table FEINMESSZEUGFABRIK SUHL measuring range: 160 mm projection: 100 mm working surface: Ø 100 mm working height: 125 mm solid design, with dial gauge ! used, tested !' Dimensions: 210 x 270 x 420 mm

illuminated measuring device for length displays HEIDENHAIN OTM1 M5 COL5X Dimensions: 100 x 80 x 70 mm

Welding Table, Straightening Table, Straightening Plate, Work Table, Clamping Table Measuring Plate, Lapping and Control Plate PAGUS Working Surface: 800 x 800 mm Working Height: 100 mm Dimensions: 800 x 800 x 100 mm

Threaded Measuring Screw, Threaded Bracket Measuring Screw Feinmesszeugfabrik Suhl Range: 0 - 25 mm M 0.4 - M 3 with protective box Dimensions: 245 x 115 x 35 mm

Thread Measuring Screw, Threaded Shackle Measuring Screw Feinmesszeugfabrik Suhl Range: 25 - 50 mm M 0.5 - M 5 with protective box Dimensions: 265 x 120 x 35 mm

Thread Measuring Screw, Threaded Bracket Measuring Screw Feinmesszeugfabrik Suhl Range: 25 - 50 mm M 1 - M 5 with protective box Dimensions: 265 x 120 x 35 mm

Optical Dental Measuring Screw Gauge CARL ZEISS JENA module: 1.5 - 18 mm scale width: 0.02 mm with protective box Dimensions: 165 x 150 x 35 mm

Internal measuring screw, internal measuring device FEINMESSZEUGFABRIK SUHL 60 - 300 mm with protective box Dimensions: 200 x 145 x 35 mm

Internal measuring instrument, fine indicator Internal measuring instrument FEINMESSZEUGFABRIK SUHL 10 - 20 mm in wooden box Dimensions: 305 x 110 x 60 mm

Coordinate measuring machine MITUTOYO BH 305 measuring area: approx. 650 x 500 mm untested ! without measuring technology, computer, software, probe ! Dimensions: 1090 x 840 x 1900 mm

Precision measuring device, tripod with measuring screw CARL ZEISS JENA 0 - 25 mm scale width: 0.01 mm DIN 863/1 Dimensions: 155 x 115 x 70 mm

Stone measuring plate, (granite measuring plate), measuring table JOHANN FISCHER 2500 x 1200 x 500 mm center cut-out: 1150 x 425 mm with various holes with threaded insert weight approx. 3.9 ton Dimensions: 2560 x 1260 x 500 mm

U-measuring screw FEINMESSZEUGFABRIK SUHL KEILPART SUHL 300 - 400 mm DIN 863/I in wooden box used, tested ! Dimensions: 620 x 375 x 60 mm

Tolerance measuring station with dial gauge FEINMESSZEUGFABRIK SUHL tolerance measuring station measuring range: 170 mm working surface: Ø 125 mm height max: 60 mm with wooden box Dimensions: 370 x 320 x 380 mm

Measuring pins set PAGUS 10 - 13 mm 63 pins step: 0.05 mm in wooden support used ! Dimensions: 240 x 150 x 60 mm

Measuring table, measuring plate with measuring column and dial gauge holder PAGUS measuring range: 180 mm working surface: 125 x 125 mm working height: 54 mm projection: 140 mm in wooden box New ! still preserved ! Dimensions: 310 x 250 x 160 mm

Length measuring system HEIDENHAIN ULS 300C/0020 236 490-51 Measuring space: 270 mm used ! Dimensions: 490 x 45 x 85 mm

Welding table, straightening table, straightening plate, work table, clamping table measuring table FEINMESSZEUGFABRIK SUHL measuring range: 160 mm projection: 100 mm working surface: Ø 100 mm working height: 125 mm solid design ! with dial gauge and second work surface ! used, tested ! Dimensions: 210 x 270 x 420 mm

Welding table, straightening table, straightening plate, work table, clamping table measuring table FEINMESSZEUGFABRIK SUHL measuring range: 160 mm projection: 100 mm working surface: Ø 100 mm working height: 125 mm solid design, with dial gauge ! used, tested ! Dimensions: 210 x 270 x 420 mm

Welding table, straightening table, straightening plate, work table, clamping table measuring table FEINMESSZEUGFABRIK SUHL measuring range: 160 mm projection: 100 mm working surface: Ø 100 mm working height: 125 mm solid design !' with dial gauge and lighting ! used, tested !' Dimensions: 210 x 270 x 420 mm

Threaded Screw, Threaded Bracket Gauge, Threaded Screw Gauge with Fine Knife CARL ZEISS Range: 100 - 150 mm M 0.6 - M 10 Measuring Tip M 0.4 - 0.6 is missing ! with protective box used, tested ! Dimensions: 445 x 180 x 50 mm

Resolver with measuring gear, rotary detector VEM 1969.1 mikroma TS3C2 i = 1 : 5 shaft: Ø 10 mm flange: Ø 56 / 70 mm used, tested ! Dimensions: 160 x 130 x 110 mm

Measuring computer GTH / MAHR P 2024A MP 2024A 5324001 95 - 264 V 47 - 65 Hz with instruction manual ! Dimensions: 485 x 420 x 270 mm

Laser measuring head EGM GMBH Type 220/70 Item no.: XL000.346.41.00 Measuring range: 185 - 255 mm Dimensions: 210 x 130 x 55 mm

Length measuring system HEIDENHAIN LS501 Measuring space: 270 mm Connection cable: 2.8 m Spare part for Schäublin 53 milling machine ! Dimensions: 420 x 80 x 40 mm

Length measuring system HEIDENHAIN LS501 Measuring space: 770 mm Connection cable: 3.0 m Spare part for Schaublin 53 milling machine ! used, tested ! Dimensions: 920 x 80 x 40 mm

Measuring Gearbox, Resolver Measuring Gearbox, Rotary Indicator SIEMENS 6FC9320 - 2BC i = 1:5 Shaft: Ø 6 mm used, tested ! Dimensions: 145 x 90 x 90 mm

Deckel FP NC Measuring Microscope Hensold Wetzlar MZM30 with SK40 DIN Cone with Gripper Groove

Mitutoyo QUICK VISION ACTIVE 202 Optical measuring machine (Vision Measuring Machine) from the manufacturer Mitutoyo Specifications (See pictures) High efficiency No constant supervision is required. The operator can carry out other tasks. Minimisation of error sources Automatic edge detection The automatic edge detection function enables high reproducibility of measurements, regardless of the reproducibility of measurements. Image autofocus The image autofocus function enables reliable height measurements at high speed. Continuous measurement of multiple workpieces Grinding function With this function, a large number of workpieces positioned on the large number of workpieces positioned on the device are on the device in a single operation. Automatic measurement can be started after be started after rough positioning Pattern search The pattern search function automat ...

2016 Hexagon OC 322 Measuring machine The machine is in perfect working condition. The 2016 Hexagon OPTIV CLASSIC 322 is a type of coordinate measuring machine (CMM) manufactured by Hexagon Manufacturing Intelligence. This machine is used for precision measurement and quality control in manufacturing processes. PRODUCT DESCRIPTION The Optiv Classic 322 combines optical and tactile measurement in one system (optional touch-trigger probe). The system supports multi-sensor measurements using the Vision sensor (CMOS colour camera, motorised CNC zoom) and the touch-trigger probe HP-TM. The Optiv Classic 322 provides easy pallet station integration with good accessibility to the measuring table from all sides. Measurement software is PC-DMIS. FIELDS OF APPLICATION • Shop floor and inspection room • Versatile geometry measurements and GD&T analysis DESIGN Design principle : Ben ...

Centering device CENTRICATOR Scanning range inside 6 to 220 mm Scanning range outside 0 to 150 mm Scanning range plan 90 to 280 mm Clamping Shank SK 40 Weight approx. 2.4 kg

Manufacturer: VICI Designation: Optical Measuring Machine Machine Type: M909 (MTL TECNO) Year of Construction: 2022 Weight: 237 kg Electrical Supply: 230 V / 50 Hz Phases: Three-phase Included Components: - Computer System: - Fully configured computer - Pre-installed software - Security dongle for licensed software access - Accessories: - Computer Cabinet: Organized and compact for clean operations - Center Point Set: Includes interchangeable inserts for versatile measurements - Three-Jaw Precision Manual Chuck: Model PHSF 100 for secure and precise part holding Find more here - .ucymachines/ Contact us at - sales@ucymachines

Measuring column Length - height 3,000 mm Diameter 190 mm Special steel - hard chrome plated - piston rod of a hydraulic cylinder Support leg - 2,500 mm Weight approx. 560 kg

Auction-ID: A1-49997-43

Measuring range X,Y,Z 1200,1800,1000 mm Software calypso Measuring head 5 axis Vast XXT

amount: 1 STK The mechanical zero setter is the standard version of our mechanical zero setters. It has a height of 50 mm and is suitable for precisely determining the position of workpiece surfaces or tool lengths in the Z direction on milling machines or lathes. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Auction-ID: A1-50229-53
