flexo printing used for sale

Number Of Colours: 8 // Printing Width: 430 mm

Printing Width: 1050 mm // Web Width: 1120 mm

Producer : Windmöller & Hölscher Type : QMS 8510 dismantled and stored Colours : 4 colors, CI With doctor blades Print width : 800 mm Repeats : from 23 – 80 cm There are approx. 300 air sleeves with the machine - size unknown Speed : 150 metres/minute Un-/rewinder : max. 1.000 mm With length slitting Cliché is 2.84 mm thick Find more here - /

A complete 8-color Fischer & Krecke flexographic printing system is available. Number of colors: 8, max. print width: 1250mm, max. material width: 1300mm, repeat print length min./max.: 320mm/800mm, max. mechanical speed: 360m/min, printable materials: PET (min. 12µm)/PP/OPP/LDPE/laminate materials. Inks: solvent-based, drying: thermal oil. Roll diameter: 800mm, core diameter: 76mm/152mm. Including BST Video Web Inspection System Premius, cleaning system Flexpress AutoClean (ACA), viscosity control Bloss Viscolor 1300, automatic roll change and rewind Flying Splice as well as an additional chill roll with a diameter of 460mm. Documentation available. On-site inspection is possible.

A 4-color central cylinder printing system WDB Systemtechnik is available. Printing units: 4, ink type: UV, max. material width: 650mm, max. printing width: 600mm, printing length range: 300mm–800mm, max. printing speed: 250m/min, material types: PET/OPP/aluminum/laminate/composite materials, material thickness range: 20µm–150µm, max. unwind and rewind roll diameter: 1000mm, operating hours: 28h, printed length: approx. 57000m. System components: unwind and rewind unit, corona, UV dryer, drying channel, IR heater, cooling unit, and supply and exhaust air fan. Including lamination unit. Documentation available. An on-site inspection is possible.

Manufacturer: Schiavi / BOBST Model: Rigel Year of Manufacture: 2001 Colors: 8 Print possibilities: 4+4 Materials: LDPE, HDPE, BOPP, CPP, PET, ALU, PAPER, BIO Gearless: No Checked up: 2022 by BOBST technicians both mechanic and electric parts Max Speed: 300m/min Fast Sleeve Change: Yes Fast Sleeve Anilox Change: Yes Computer Supervision: Yes Web Width: 1320mm Print Width: 1290mm Min Print Repeat: 430mm Max Print Repeat: 1200mm Unwinder Type: Double Turret Automatic Flying Splice Winder Type: Double Turret Automatic Flying Splice Max Reel Diameter Unwinder: 800mm Max Reel Diameter Winder: 800mm Drying: Thermal Oil Video camera: Yes (FIFE) Corona Treatment: Yes (Cason) for conductive and non-conductive materials Web Guides: In and out (BST) Viscosity Control: Gama (not in use, must be repaired) Inking System: Ceramic Anilox + Chambered Doctor Blades Anilox Sleeves ...

em510 , built in 2007 3 x printing units with dual drive, max. printing width 510 mm 3 x punching station (2 x with adjustable counter-punching cylinders (Spilker Variabase)) Cliché cylinders (1/8"): 3 x 88, 3 x 92, 3 x 96, 3 x 100, 3 x 108, 3 x 116, 3 x 120, 3 x 140 Magnetic cylinders (1/8"): 2 x 96, 3 x 100, 3 x 108, 3 x 116, 3 x 120, 4 x 140, 3 x 176, 3 x 184, 2 x 192, 1 x 222 13 anilox rollers (cm3): 4.1; 5.04; 6; 6; 6.3; 6.09; 8; 8.25; 9.58; 13; 13.51; 16.57; 30 2 x new anilox rollers 3 x sleeve holders z=88 for coating (with assembly station) Screen printing unit Laminating station 2 x grid winders on rails (up and down) 3 x Uviterno UV system (240 W/cm) 2 x NIR drying modules for aqueous systems (Lambda technology) Corona system 2Kw (SIT) Web edge control: E&L (2 x ultrasonic sensors, 1 x line sensor) Video: E&L Elscan Outfeed conveyor for individual labels Doub ...

Manufacturer: Comiflex Model: Vale 1208 Year of Manufacture: 2011 Machine Type : 8-Colour Gearless Flexographic Printing Machine Number of colours: 8 Condition: Immaculate, manufacturer-serviced only, full service history available Print Specifications - Material width: 1280 mm - Print width: 1200 mm - Minimum repeat length: 380 mm - Maximum repeat length: 840 mm - Machine speed: 300 m/min Anilox Rolls (8 included) - Face length: 1260 mm - Engrave length: 1240 mm - Outside diameter (OD): 171.88 mm - Inside diameter (ID): 149.722 mm Sleeves (8 included) - Inside diameter (ID): 114.708 mm - Face length: 1210 mm Ink and Registration Systems - Ink pump: Phonematic with autowash system - Camera and registration system: FIFE Find more here - / Contact us at -

8-color format: 1270 mm<br><br><br><br<br>br>

7 color<br><br><br>Still in operation: Yes<br>Available: immediately

Size: Max: 1.700 x 1.150 mm min: 520 x 600 mm Equipments: Vacuum Feeder Vacuum Dust Cleaner No 4 Flexo-Printing Units Bottom Printing With Ceramic Rolls & Chamber Doctor Blade Side track printing Units Electric Running Register Automatic Stacker Max. Sheet Size 1.700 x 1.150 mm Min. Sheet Size 520 x 600 mm Max. Speed 9.000 Sheets per Hour

Format: 740 x 1040 mm<br><br><br><br>br>Verf Gbar: Short-term

8-color format: 70 x 100 cm<br><br><br><><<br>Verf Gbar: Instant

4-color R23240/17 SHIKI label press Model: PC 45 M Built: 1992 Web width: 280 mm Availability: instantly 3 - coloured or 4 - coloured (optional) Printing width: 270 mm, min. 50 mm max. feed: 7, approx. 180 mm Accessories: Rolling unit for rollers up to 100 cm in diameter Winding unit for small rolls pneumatic remaline hole on both sides Speed: 7000 cycles/h max. Products: Hole edge adhesive labels, adhesive labels, hole edge cardboard labels, tickets with and without printing - can punch, print, embosse, number, perforate, punch Available: immediately

Format: 700 x 1020 mm R26060/18 SAKURAI screen printing machine Model: SCA 102 Built: 1989 max. print size: 700 x 1020 mm Availability: instantly automatic screen printing line high speed cylinder Special version: min: 500 x 350 mm Sheet transfer station can be folded on one side optical front edge control mechanical double-arch control via friction rollers pneumatic squeegee pressure control and sieve clamping PERFECTION high-performance dryer 1120/4: Inlet width 1100mm, 2 warm and 2 cooling zones with UV dryer MIRUS forklift model SV Etc. Available: immediately

8-colours web width 342.6 mm 9 printing stations, 8 for watercolours straight toothed 1 UV (glue) station redeveloped and further expanded for printing on packaging monofilm from 30" expanded and further expanded for printing on adhesive label material up to 200 Ceramic anilox cylinder, for 120/18 to 140/10 140/17, 160/15, 180/12, 95/15, 200/5, 255/10, 300/10, 315/11, 345/8, 500/17 Colouring roller for full-surface colouring Cutting device for longitudinal sections Etc. Still in operation: Yes Available: immediately

<br><br><br>Still in operation: Yes<br>Verf Gbar: Immediately

<br><br><br>Still in operation: Yes<br>Verf Gbar: Immediately

4-color format: 212 x 360 mm<br><br><br>Still in operation: Yes<br>

<br><br><br>Still in operation: Yes<br>Available: immediately

<br>Original numbering work for Heidelberg MO<br><br><br>

<br><br><br>Still in operation: Yes<br>Available: immediately

<br><br><br><br>Available: immediately

<br><br><br>Still in operation: Yes<br>Available: immediately

<br><br><br>Still in operation: Yes<br>Available: immediately

<br><br><br>Still in operation: Yes<br>Available: immediately

<br><br><br>Still in operation: Yes<br>Available: immediately

8 color size 70 x 100 cm<br><br><br><br>Available: immediately

M. No.: 821301-10002 Equipment / further information: Hardware • OptiPrint™ Media Cleaner • Driven roller feed system with media flanges • Driven reel system with media flanges • Baskets • Rear and front media sensor • Hard disk (2 GB job space) Interface • Control panel with 8 buttons. • 4x20 character liquid crystal display. • English display language. • Metric or English units. Functionality • 16 user configurations. • Automatic alignment system. • Up to eight colors/job • OptiTrac Save Ribbon • Right side of the tape • OptiTrac colors: mirror silver and gold Cut: • Concatenation and curve smoothing to achieve better cutting quality. • OptiCut drag motion optimization. • Overlap for easy weeding. • Multiple reprint function (up to 999). • Flash Eproms With 5 cassettes and various ribbons Operating instructions
