faceplate used for sale

faceplate diameter: 4500 mm swing diameter: 5000 mm turning height: 2645 mm Control: Siemens 840 D total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Equipment: CNC control Siemens Sinumerik 840 D Direct measuring system C-axis with extension of the workpiece measurement Hydrostatic guidance of the linear axes Workpiece measurement Tool measurement Tool and process monitoring ARTIS CTM system Workroom surveillance with video camera (at the support) Processing heads with automatic tool clamping UWFK 500 Nm, +/- 90° manually pivotable Various tool holders, type 300.2 Tool magazine 24 to 72 Platu magazine pick-up plate Loading crane for the tool magazine, load capacity 500 kg Loading device with HSK, capto-, KM tool holder Machine protection device Automatic cover of the chip chute Working area protection completely closed Preparation for installing a ...

Machining capacity -Maximum swing diameter above the guide ways: 2500 mm (98.42 in); -Maximum swing diameter above the saddle: 2100 mm (82.67 in); -Distance between centers: 7600 mm (299.21 in); -Maximum weight between centers: 20 tons. Faceplate -Faceplate diameter: Ø2200 mm (86.61 in); -Turning speed range: 150 rpm ; -Main motor power: 60/75 kW ( 80/100 HP); C axis -C axis: continue 360°; -Milling spindle motor power: 11/15 kW (14/20 HP); Standard Accessories: -FANUC 0i CNC; -Heidenhain linear scales; -Faceplate, 1 piece; -Tool turret with 12 posts for milling tools, 1 piece; -Partial enclosure with chip conveyor; -Centralized hydraulic and lubrication unit; -Electrical devices: 380V, 3 phases, 50 Hz; -Levelling devices for foundation, 1 set.

Machining capacity - Maximum workpiece diameter: 6300 mm; - Maximum height of workpiece to be machined: 4600 mm; - Maximum weight of workpiece: 150000 kg; Faceplate - Faceplate diameter: 6000 mm; - Turning speed range: 30 rpm; - Main motor power: 125 kW; - C axis: 0-360°/min.; Cross rail - Cross rail vertical travel: 3500 mm; - Feed of cross rail: 1000 mm/min.; - Motor power: 18.5 kW; Turning and Milling RAM, 1 piece - Vertical RAM travel, Z1 axis: 2400 mm; - Horizontal RAM travel, X1 axis: 7200 mm; - RAM octagonal section: 310x310 mm; - Maximum milling speed: 3000 rpm; - Maximum milling power: 30 kW; - Maximum torque: 800 Nm; - Milling spindle taper: ISO-50 (DIN69871/DIN69872); - X1/ Z1axes rapid feed: 6000 mm/min; Turning RAM, 1 piece - Vertical RAM travel, Z2 axis: 2400 mm; - Horizontal RAM travel, X2 axis: 7200 mm; - RAM octagonal section: 310x310  ...

Sale of a second-hand horizontal boring machine UNION model BFT-80/2, year of manufacture 2003: axis travel: 1000 x 1000 x 1600 mm - spindle diameter: 80 mm -cone: ISO 40 - max. diameter of boring faceplate: 800 mm - diameter of the hole to be machined without faceplate: 450 mm - spindle extension: 500 mm - faceplate diameter: 500 mm - turntable height: 915 mm - size of the table clamping surface: 1120 x 1000 mm - table load: 2500 kg Delivery time - ready for shipment

faceplate diameter: 2000 mm swing diameter: 2400 mm turning height: 1800 mm x-axis: 2000 mm y-axis: 2000 mm z-axis: 1200 mm ram adjustment: 1200/1500 mm faceplate turning speed range -stepless-: 2,3 - 250 U/min boring spindle drive: 27 kW milling drive motor: 27 kW spindle turning speed - stepless: 0-1200 U/min tool magazin:: 12 fach tool taper: 50 ISO control: Siemens 840 D sl chip conveyor: 2 workpiece weight: 15 t total power requirement: 61/92 kW weight of the machine ca.: 56 t dimensions of the machine ca.: 10 x 10 x 7 m m Machine type: CNC carousel lathe Machining Center - Vertical Rectangular ram head suitable for turning, milling, drilling, drilling and Threading. The machine was overhauled and modernized in 2014 automatic 12-fold tool changer C-axis driven tools • Tappet, hydrostatic bearing completely overhauled • Hyfraukik overhauled • Drives and ball screws renewed •  ...

:YS-VL-1000 | YS-VL-1200 | YS-VL-1600 | YS-VL-2000 faceplate diameter:1000|1250|1600|2000 mm swing diameter:1350|1600|2000|2500 mm turning height:1070|1350|1350|1700 mm max. turning diameter:1150|1350|1800|2300 mm table load:4|5|8|10 t table rotation speed:2 - 600 | 2 - 300 | 2 - 250 | 2 - 200 U/min max. torque on the faceplate:10000|12500|18500|54000 Nm Travel of Ram (vertical):800 | 900 | 900 | 1000 mm Travel of ram (horiz.):1350 | 1475 | 1650 | 2275 mm ram head dimension:230 x 230|250 x 250|250 x 250|280 x 280 mm rapid power traverse in X-and Z direction:10/12|10/12|10/12|10/10 m/min feeds:0,1 - 50 mm/U feed speeds:0 - 1260 mm/min Tool changer:12 (C-Achse mit 16) drive capacity - spindle motor:37/45| 37/45 (60/75 opt.)| 37/45 (60/75 opt.)| 37/45 (60/75 opt.) kW Machine height: 5330 |5500 |5500|6600 mm machine length:4600 |4700 |5050| 4950 mm machine width:5500 |5800 |6300|7320 mm weig ...

:YS-VL-3000 faceplate diameter:3000 mm swing diameter:3500 mm turning height:1650 mm max. turning diameter:3400 mm table load:40 t table rotation speed:2-40/41-120 U/min max. torque on the faceplate:64500 Nm Travel of Ram (vertical):1000 (1400 opt.) mm Travel of ram (horiz.):2775 mm ram head dimension:280x280 mm rapid power traverse in X-and Z direction:10/10 m/min feeds:0,1 - 50 mm/U feed speeds:0 - 1260 mm/min Tool changer:12 (C-Achse mit 16) tool taper:SK50/BT50 drive capacity - spindle motor:60/75 (75/100) kW Machine height:6700 mm machine length:6100 mm machine width:8700 mm weight of the machine ca.:69000 kg repeating accuracy:0,005 mm hydraulic motor:3,75 kW servo motor X-axis:7 kw servo motor Z-axis:7 kw coolant pump drive:2,2+1,1 kW :150 kva CNC controller:Siemens/Fanuc/Fagor coolant system:700 Liter automatic tool changer:16-fach 4-jaw faceplate Ø:s. oben CNC controls from:Sie ...

faceplate diameter:4000 mm swing diameter:5000 mm turning height:2500 mm max. turning diameter:5000 mm table load:40 t table rotation speed:0,1-80 (2-stufig) U/min max. torque on the faceplate:108000 Nm Travel of Ram (vertical):1800 mm Travel of ram (horiz.):-2500~+2900 (aus Tischmitte) mm ram head dimension:300x300 mm spindle speed:10-2500 (2-stufig) 1/min spindle taper:50 SK rapid power traverse in X-and Z direction:10/10 m/min feed speeds:1-3000 mm/min Cross rail travel :1680 mm Tool changer:12-fach für rechten Stößel (für Drehwerkzeuge) Tool changer:60-fach für linken Stößel (für Fräswerkzeuge) tool taper:SK50/BT50 Machine height:s. Anlage mm machine length:s. Anlage mm machine width:s. Anlage mm drive capacity - spindle motor:18,5/22 kW coolant pump drive:3 kW servo motor X-axis:9 kw servo motor Z-axis:9 kw table drive:100 kW :300 kva positioning accuracy:0,01/500 mm repeat ...

faceplate diameter:1800 mm swing diameter:2000 mm turning height:1170 mm z-axis:1000 mm cross rail adjustment - vertical:800 mm faceplate speeds::2,5 - 280 workpiece weight:12 t feeds:1 - 6000 mm/min max. torque on the faceplate:50000 Nm total power requirement:85 kW weight of the machine ca.:41 t dimensions of the machine ca.:5,6 x 4,8 x 4,6 m Machine retrofit and overhould in 2005 with SIEMENS 840 D powerline control - 6 jaw hydraulic power chuck - tool changer for 12 tools - chip conveyor, coolant attachment, splash housing - various tool holders

Faceplate speed level 1: 0.005 0.25 Faceplate speed level 2: 0.019 1.02

Plan copy lathe make RAVENSBURG type K 600 KHKom. -No: 8792 built in 1972Technical specifications:Turning diameter over bed: 1000 mmTurning diameter over facing slide: 600 mmfor face plates up to: 800 mm dia.max.distance between faceplate and support: 600 mmLongitudinal feed: 1 - 170 mm / minPlan feed: 1 - 170 mm / minMain spindle diameter: 166.68 mmSpindle bore: 80 mm12 spindle speeds: 1.7 - 600 rpm.gr. torque on the faceplate: 500 mkggr. workpiece weight: 500 kgDrive power: 22 kWWeight approx: 5.8 tExternal dimensions L x W x H approx .: 3500 x 2000 x 2000 mmWith- swiveling control panel- separate control cabinet- hydr. Copier- Thyristor drive- separate hydraulicsWITHOUT the lining shown!used, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be plea ...

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Carrousel lathes FKD 40 CNC with Y axis and CNC swivel head (A axis) Faceplate diameter 4000mm Rotating diameter: 8000mm Rotating height: 3000mm Ram: 300mm x 300mm Stroke: 3000mm X axis: travel distance 5000mm Z axis: travel distance 2000mm Y axis: travel distance 6000mm W-axis: travel distance 1500mm C-axis in faceplate-table A axis in milling head Control unit: Siemens 840 Dsl Tool changer: 60 pockets PickUp Station: 5 pockets

Spare parts for Tischbohrwerk VO / Stankoimport / Gertner, Fuhrmeister & CO E.g. complete spindle SK50 Ball screw spindles from the three axes Electric motors, 3 x feed motor, spindle motor complete control Siemens or control cabinet Control Panel with digital device Glass scales Detachable faceplate diameter 360 mm Radial movement of the faceplate-support 100 mm Converter / transformer Angle drilling head Dividing head Spindle diameter ø 110 mm tool holder ISO 50 Technical data of the original machine Travel along approx. 1.000 mm cross travel approx. 1.600 mm of vertical stroke 1,000 mm Longitudinal movement of retractable spindle 710 mm Speed range 10-1,250 RPM Main engine 11kw Speeds 10-1,250 RPM in 22 gear stages Extensive documentation of machine including operating instructions, description, electrical documentation, etc. More photos on request

Technical data: -Lifting capacity 2000 kg -max load capacity horiz. 3500 kp -Faceplate hub 1750 x 1750 mm -Drehkreuzverängerungen -Faceplate geared motor Tiltable 0-90 ° -Rotation Electr. adjustable 0.2-1.5 m / min -Right - left rotation - welding current transmission 1200 A -400 V - table height in horiz drive. Position with frame approx. 2070 mm -Table height at horiz. Position without stand approx. 940 mm -Space requirement approx. B 1650 x H 1130 / 940 x H 2500 mm -Weight approx. 2.2 t

Technical data: -Capacity approx. 200 kg -Throat depth 800 mm -Working height in horizontal position approx. 1000 mm -Mot boom. left + right swivel - arm arm manually Tiltable -Mot face plates. left + right rotatable - faceplate speed infinitely variable - faceplate diameter 300 mm - adjustable control panel with control make ESAB, type 6 PTF, BJ. 97 - space requirement approx. B H 1100 x 1300 X 1600 mm -Weight approx. 300 kg

Technical data: -Load capacity 300 kg -Faceplate diameter 500 mm -Faceplate in grid levels of tilt - rotation Electr. infinitely variable approx. 0-1.2 m / min -Sweat power 650 A -Drive 220 V / 0.09 kW -Table height in horizontal position approx. 650 mm -Re + reverse - space requirement approx. B H 800 x 650 X 700 mm -Weight approx. 180 kg

Technical data: -max load capacity 250 kg -Faceplate dimensions 500 mm -Faceplate you. Swiveling via Handwheel 0-135 ° -Rotation infinitely variable 0,01-4 U/min -Right - + reverse - transmission welding current approx. 400 A -Drive 220 V 1,1 kW -Table height in horizontal position approx. 800 mm -Space requirement approx. B H 600 x 500 X 1100 mm -Weight approx. 200 kg

turning diameter over bed: 1250 mm turning diameter over slide rest: 1000 mm turning length: 11000 mm total power requirement: kW weight of the machine ca.: 49 t dimensions of the machine ca.: m Center height 720 mm Center distance 11000 mm Turning diameter over bed 1250 mm Turning diameter over slide 1000 mm Workpiece weight max 12 to Speed 3-315 rpm - stepless Motor power 55 kW (DC) Equipment 1 position indicator HEIDENHAIN | Type ND 780 for 1 axis 1 four-jaw faceplate Ø 1000 mm 1 fixed steady rest 1 ring steady rest with four-jaw faceplate Ø 920 mm 1 Autom. 4-pos. tool holder 1 Chip conveyor 1 Machine lamp 1 Coolant device Operating key | operating manual The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 400 mm Bore diameter: 125 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Unused 4-jaw faceplate with individually adjustable jaws. Size 8 / DIN 55029 (Camlock), max. speed 800 rpm. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Main characteristics: faceplate diameter - 2800 mm, The diameter of the installed product is 3200 mm, Workpiece weight - 16000 kg., The height of the installed product above the faceplate - 1600 mm, Machine weight - 43,000 kg.

turning diameter over bed: 3050 mm turning diameter over slide rest: 2500 mm turning length: 21200 mm Control: Siemens type: 840D turning speeds: 0,236-60 U/min faceplate: 3000 mm main drive motor: 200 kW tailstock quill diameter: 900 mm roll stand: steady: 1200 mm steady: 1200 mm steady: 750 mm steady: 750 mm with live steady: 2000 mm faceplate: 2000 mm Thickness: 330 mm workpiece weight: 200 t total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 3050 mm turning diameter over slide rest: 2500 mm turning length: 21200 mm Control: Siemens type: 840D turning speeds: 0,236-60 U/min faceplate: 3000 mm main drive motor: 200 kW tailstock quill diameter: 900 mm roll stand: steady: 1200 mm steady: 1200 mm steady: 750 mm steady: 750 mm with live steady: 2000 mm faceplate: 2000 mm Thickness: 330 mm workpiece weight: 200 t total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 3200 mm swing diameter: 5100 mm turning height: 2505 mm cross rail - adjustment: 1500 mm max. ram stroke: 1250 mm slide adjustment: 2000 mm control: Siemens 8 T tool changer: 16 STK table load: 60 t faceplate turning speed range -stepless-: 0,8-100 U/min feed: 0,0 1-1000 mm/min rapid traverse: 6000 mm/min drive of main spindle: 75 kW weight of the machine ca.: 70 t dimensions of the machine ca.: 9,3 x 6,1 x 6,0 m machine is in an excellent condition with div. acessories (photos available) machine can be equipped with latest electrics and Siemens CNC control SINUMERIK 840D sl for additional costs. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1000 mm swing diameter: 1400 mm turning height: 1400 mm control: SIEMENS 850M total power requirement: 125 kW weight of the machine ca.: 38 t dimensions of the machine ca.: m Stocknumber 1020042 Type of machine CNC VTL Make PIETRO CARNAGHI Type AC 10 CNC Build in 1987 Type of control Siemens 850 M/E Faceplate diameter 1000 mm Max. Swing diameter 1400 mm Turning height max. 1400 mm Total Power (KW) totaal 125 Lenght (mm) 11000 Width (mm) 8000 Height (mm) 6000 Weight 38000 kg Additional information with driven tools with pallet changer The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter:8000 mm swing diameter:10000 mm turning height:4500 mm workpiece weight:120/200 t table speeds:0.2-16 U/min (2 Stufen) max. torque on the faceplate:200/460 k.Nm slide stroke:vertikal: 2300 mm slide stroke:horizontal: 5300 mm cross section of ram:300x300 mm Max. cutting force of tool head :links: 63 kN / rechts: 80 kN Cross rail travel :2000 mm rapid feed cross beam:300 mm/min feed stepless:X-Achse: 1-500 mm/min main drive:110 kW weight of the machine ca.:270 t Machine size (LxWxH):14000x10000x9000 mm control:Siemens 828D/Siemens 840D worktool support (A-axis):2 Stück :1 Stück Rams:1 Stück konventioneller und 1 Stück CNC-Stößel CE-design:inkl. Zertifikat European electric:Schneider, Siemens, ABB oder ähnlich Servo motors:von Siemens SPS machine control:von Siemens CNC controls from:Siemens/Fanuc/Fagor for more information please check attached pdf file on the ri ...

faceplate diameter: 2200 mm swing diameter: 2500 mm turning height: 1600 mm Control: Siemens chip conveyor: total power requirement: 100 kW weight of the machine ca.: 35 t dimensions of the machine ca.: m vertical lathe with two RAM, faceplate Ø 2000 mm, SPS supported control for storable cycles, RAM/channel 1 two Capto recordings C8 with Internal tool cooling, RAM/channel 2, two Capto mounts C8 with internal tool cooling, Chip conveyor / spindle Z-axis as new / without KSS Filter unit / 3 glass scales are missing / control panel is disconnected but complete and OK, a 90 degree angle is missing from the control panel arm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 3200 mm turning diameter over slide rest: 2400 mm turning length: 15000 mm faceplate diameter: 2600 mm control: Siemens 840 Dsl workpiece weight max.: 80000 kg accuracy +/-: bis/up to: 0,01 mm spindle motor: 110 kW faceplate speeds from - to: 0-50 U/min total power requirement: - kW weight of the machine ca.: 60 t overhauled and modernized 2009 & 2012/2013 equipped with: - CNC control Siemens 840D SL - 2 supports with 1 controller each - 4-jaw face plate - 2 hydraulic steady rests - hydraulic tailstock Machine is dismantled and stored. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1130 mm swing diameter: 1500 mm turning height: 1100 mm faceplate diameter: mm swing diameter: mm total power requirement: 30 kW weight of the machine ca.: t dimensions of the machine ca.: m Brand: STANKO TYPEL 1512 Build in: 1977 with pneumatick 3-jaw stuck 1130 mm max. turning diameter 1500 mm max. turning height 1100 mm Motor 30 KW The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 3200 mm swing diameter: 3200 mm turning height: 2000 mm workpiece weight: 50.000 kg cross travel of ram-slide: 1900 mm slides vertical travel: 1250 mm swival range +/-: -15/+40 Grad faceplate turning speed range: 0,66-62,1 U/min total power requirement: 70 kW weight of the machine ca.: 90 t dimensions of the machine ca.: 5100x9300x7200 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 450 mm bore: 120 mm faceplate - height: 120/165 mm short taper: Din 55022 7 Gr. 11 Four-jaw face plate. Short taper - design, according to DIN 55022/27, size 11, with 6 studs, reversible top jaws, Baking individually via threaded spindles only individually adjustable. Machine dealer with own stock of 1600 m². The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1250 mm swing diameter: 1600 mm turning height: 1000 mm faceplate diameter: 1250 mm grinding diameter: 00 mm grinding height: 1000 mm control: Siemens 840 C total power requirement: 60 kW weight of the machine ca.: 47 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

- Work piece maximum diameter: 8500 mm; - Distance between columns: 8500 mm; - Work piece maximum diameter through gantry travel: 11000 mm; - Work piece maximum height: 6000 mm; - Work piece maximum weight on faceplate: 100 tons; Table-Faceplate - Diameter: 6000 mm; - Speeds range (continuously variable): 0-50 rpm; - 4 x 40 kW main motor FANUC make: 160 kW; Fixed table - Dimensions: 3x2000x6000 mm; Gantry - Horizontal travel Y axis: 11800 mm; - Feeds range (continuously variable): 10000 mm/min; Cross rail - Vertical travel W axis: 5200 mm; - Feed range (continuously variable): 0 ÷ 250 mm/min; - Feed motor power: 50 kW; Vertical Rail Head (turning and milling operations) - Vertical ram travel (Z axis): 2700 mm; - Rapid feed speed for Z axis: 10000 mm/min; - Ram cross section: 450x450 mm; - Milling motor power: 40 kW; - Millin ...

turning diameter over bed: 2235 mm turning diameter over slide rest: 2997 mm turning length: 12200 mm Control: SIEMENS faceplate diameter: 2000 mm total power requirement: 300 hp weight of the machine ca.: / t required space: / m HOESCH MFD CNC HEAVY DUTY LATHE WITH SIEMENS CONTROL Faceplate 2006mm. Centre Height 1,499mm Swing Over Saddle 2235mm. Swing Over Bed 2997mm. Turning Length 12192mm. Min/Max Workpiece Held In Chuck Ø457/1600mm. Maximum Workpiece Weight110 Ton. Speed Range 0.5- 140rpm (300hp Motor). Feed Range 0.0118-7.08/Rev. Steady Capacity Ø356-902mm. Copying Depth 508mm lnductive. Maximum Cutting Force 30,000Nm. Twin Barrel Steady Capacity Ø356- 902mm, 50 Ton Capacity, Roller Type. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Faceplate, faceplate chuck, four-jaw chuck, facing chuck -Face plate: chuck size Ø 500 mm -Receptacle: short cone 8 (Ø 136-139 mm) -Hole circle: Ø 172 mm -Through hole: Ø 80 mm -Groove width: 20 mm -Weight: 86 kg

x-travel: 3000 mm y-travel: 800 mm z-travel: 1100 mm Control: total power requirement: 60 kW weight of the machine ca.: 15 t dimensions of the machine ca.: 7,0 X 6,0 X 4,0 m For sale is a Matec 30 HV machine number 569 built in 2003. The machine is expected to be released in August 2024 and can be used under Electricity can be visited. The machine has been serviced every year and is technical in a good condition. Manufacturer: Matec Maschinenbau Type: 30HV Machine number: 569 Year of construction: 11/2003 Control: Bosch Type 3 Osa control x-travel 3,000 mm y-travel 800 mm z-travel 1100 mm Main spindle: Type DMS 112 speed range - main spindle max. 12,000 min/-1 Drive power - main spindle 30 kW Max. Torque 190 Nm Tool holder HSK 63 A Drilling capacity steel approx. 60mm Milling capacity approx. 500 cm³ Thread cutting M30 Feeds: Rapid traverse (X / Y / Z) 30 m/min Feed speed 30,000 mm/m ...

spindle diameter: 100 mm x-travel: 1600 mm y-travel: 1120 mm z-axis: 1250 mm : 900 mm : 1.250 x 1.250 mm : 360 ° turning speeds: 7,1 - 1.120 U/min table load: 3,0 t : 50 : 2,8 m/min feed: 18- 900 mm/min power capacity - milling spindle: 11 kW transmission ratio: 23 max. torque on the spindle: 3.350 Nm faceplate: Ø 600 mm radial face slide travel: 215 mm faceplate turning speed range: 7,1 - 224 U/min total power requirement: 15 kVA : 14 t range L-W-H: 6,0 x 2,6 x 3,0 m conv. hori. borer in good condition with facing plate - facing plate - 3 axis digital scale - turning table - table support - coolant system - some equipment The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

:HBM-110L spindle diameter:110 mm x-travel:900 mm y-travel:900 mm z-travel:1400 mm W-axis (spindle longitudinal):600 mm U-axis:Planschieber: 180 mm B-axis (table):360x1 ° table load:5 t table-size:1100x960 mm T-slots:22 Stk. spindle speed:22 Stufen, 8-1000 1/min spindle taper:50 ISO rapid speed:(X / Y / Z / W) 2500 mm/min speed - faceplate:4-200 (18 Stufen) 1/min torqe of face plate:1960 Nm dia of faceplate:600 mm movement of facing slide:180 mm weight of the machine ca.:11500 kg main drive:7,5 kW Machine size (LxWxH):4910x 2454x2750 mm 2-Axis DRO :für X- und Z-Achse (von NEWALL)

:KDM-12 | KDM-16 | KDM-20 | KDM-23 faceplate diameter:1000|1400|1800|2000 mm swing diameter:1250|1600|2000|2300 mm turning height:1000 (opt. 1400)|1000 (opt. 1400)|1250 (opt. 1650)|1250 (opt. 1650) mm table speeds:5 - 200 (2-360 opt.)|5 - 160 (2 - 300 opt.)|3,2 - 100 (2-200 opt.)|3,2 - 100 (2-180 opt.) 1/min transmission ratio:4 (variabel in jeder Stufe) max. workpiece weight:4|6|8|10 t max. torque on the faceplate:20|25|25|25 KN rapid feed of tool post:8000|3000|3000|3000 mm/min feed speeds:0.1 - 500 mm/min Max. cutting force of tool head :18|25|30|30 KNm Travel of Ram (vertical):600|800 (1000 opt.)|800 (opt. 1000)|800 (opt. 1000) mm Travel of ram (horiz.):850|1000|1115|1400 mm Cross rail travel :600|850/1000 (optional)|890/1240 (optional)|990/1240 (optional) mm power maindrive:22/30|30/37|37/45|37/45 kW weight of the machine ca.:9|12,5|18,5|20,5 t Machine size (LxWxH):2360x2277x3403|26 ...

:KDM-K 25 | KDM-K 28 | KDM-K 31 | KDM-K 35 faceplate diameter:2250|2830|3150|3500 mm swing diameter:2500|2800|3100|3500 mm turning height:1600/2000/2500 |2000/2500 |2000/2500 |2000/2500 mm max. torque on the faceplate:63000 Nm max. workpiece weight:10/16 t table speeds:0,5-80 |0,5-80 |2-63 |2-50 1/min Travel of Ram (vertical):1000/1250|1000/1250|1000/1250|1000/1250/1600 mm Travel of ram (horiz.):1400|1600|1700|1800 mm rapid traverse X-axis:3 m/min cross section of ram:200x255 mm rapid feed cross beam:350 mm/min power maindrive:55 kW Weight approx.:32/35/37|35/38/40|36/40/42|43/45 t face plate:siehe oben Rams:2 Stk. CNC controls from:Siemens/Fanuc turret:4-/6-fach, elektrisch

:KDM-K 40 | KDM-K 50 faceplate diameter:3150/3500|4000/4500 mm swing diameter:4000|5000 mm turning height:2500/3150/4000|2500/3150/4000 mm max. torque on the faceplate:100000 Nm max. workpiece weight:32/50/83 t table speeds:2 ? 40 1/min Travel of Ram (vertical):1300/1600/2000 mm Travel of ram (horiz.):2250 | 2800 mm rapid traverse X-axis:3|4 m/min cross section of ram:200x255 mm rapid feed cross beam:350 mm/min power maindrive:55|75 kW Weight approx.:58/75/115 |58/75/115 t face plate:siehe oben Rams:2 Stk. CNC controls from:Siemens/Fanuc turret:4-/6-fach, elektrisch
