Simultaneous machining of outer contours as well as the welding beads
on the top and bottom
Two cutter positions for freely configurable cutter sets
Thanks to spring-loaded groove blades, optimum groove pattern on
convex and concave profile surfaces
Adjustable drawer pulls in even heavy and high profile elements (e.g.
front doors) precisely and safely
No twisting of the profiles due to horizontal and vertical clamping
Milling cutter diameters of up to 260 mm possible for profiles with
extreme installation depths
Standard blow-off device, thus no inaccuracies due to the fixing of
chips
Versatile thanks to individually switchable grooving knives and
milling cutters as V51245061 well as individual and quickly
interchangeable milling cutter combinations
Outer dimensions min. frame size 290 x 290 mm
Inner dimensions min. frame size 160 x 160 mm
Profile height max. 200 mm
Profile height min. 25 mm
Milling cutter diameter max. 260 mm
Milling spindle speed 3,200 1/min
