edm used for sale

This Exeron EDM 310 MF 20 Erosion machine was manufactured in the year 2008 in Germany. It is equipped with an Exeron control unit. The machine was fully retrofitted in 2023 with 6 month warranty.

Tapping chucks, thread chucks, tapping chucks, tapping attachments -with slip clutch -Integrated reversing gear with fast reverse -Counter holder for the return is missing -Thread sizes: M5-M20 -Recording: MK4 -Dimensions: 380/95 mm -Weight: 4.3 kg

Tapping chucks, thread chucks, tapping chucks, tapping attachments -with slip clutch -Integrated reversing gear with fast reverse -Thread sizes: M5-M20 -Recording: MK4 -Dimensions: 380/95 mm -Weight: 4.1 kg

Description: Serial number: 01123 Operating voltage: 220 V Frequency: 50 Hz Connection: 1.5 kVA Dimensions of the magnetic clamping plate: 160 x 90 mm Incl. three-axis digital display Approx. Onsite Dimension. (l x w x h): 1,100 x 500 x 1,000 mm, weight approx.: 200 kg

Type: Die-sinking EDM machine Number: 21958 Category: Die-sinking EDM machines / EDM Manafacture: Makino Model: EDAF 3 Year of construction: 2016 Travel: 450 x 350 x 350 mm [ X x Y x Z ] Table size X: 700 mm Table size Y: 500 mm max. workpiece size X: 850 mm max. workpiece size Y: 650 mm max. workpiece size Z: 400 mm max. workpiece weight: 800 kg C-axis Linear scales (X,Y,Z) Control Hyper i Super Spark iV Super Surface Super Edge (incl. MF 4) Super Surface Graphite EROWA Robot Interface (A-Type)

Key data: 400 mm, 300 mm, 250 mm

Type: Wire EDM Machine Ident Number: 22606 Category: Wire EDM Machines / EDM Manufacturer: Sodick Model: SLC 400 G Premium + Year of construction: 2015 Travel: 400 x 300 x 250 mm [ X x Y x Z ] max. workpiece weight: 500 kg U / V axis: 150 x 150 mm Cutting in a water bath Radiator Working tank 850 x 610 mm Taper +/- 25° at tool height 130 mm Control SPW

Key data: 500 mm, 350 mm, 250 mm

Type: Wire EDM Machine Ident Number: 22604 Category: Wire EDM Machines / EDM Manufacturer: Sodick Model: VZ 500 L Year of construction: 2010 Travel: 500 x 350 x 250 mm [ X x Y x Z ] max. workpiece size X: 960 mm max. workpiece size Y: 670 mm max. workpiece size Z: 245 mm max. workpiece weight: 850 kg with automatic wire threading Cutting in a water bath U/V axes +/- 80 x 80 mm Taper 15° at 120 mm height Control LN2W

Key data: 500 mm, 400 mm

Type: Die-sinking EDM machine Ident Number: 22409 Category: Die-sinking EDM machines / EDM Manufacturer: Charmilles Model: ROBOFORM 350 GammaTec Year of construction: 2006 Travel: 350 x 250 x 300 mm [ X x Y x Z ] Table size X: 500 mm Table size Y: 400 mm max. workpiece weight: 500 kg Electrode changer: 16-fold C-axis

Key data: 500 mm, 400 mm

Type: Die-sinking EDM machine Ident Number: 22607 Category: Die-sinking EDM machines / EDM Manufacturer: Charmilles Model: ROBOFORM 35P Year of construction: 2002 Travel: 350 x 250 x 300 mm [ X x Y x Z ] Table size X: 500 mm Table size Y: 400 mm max. workpiece size X: 780 mm max. workpiece size Y: 400 mm max. workpiece size Z: 300 mm max. workpiece weight: 500 kg max. electrode weight: 50 kg Tool changer: 16-speed C-axis Generator: 64 amps lowerable container Erowa ITS50 Clamping Head

Key data: 750 mm, 550 mm

Type: Die-sinking EDM machine Ident Number: 22605 Category: Die-sinking EDM machines / EDM Manufacturer: Sodick Model: AG 60 L Year of construction: 2012 Travel: 600 x 420 x 370 mm [ X x Y x Z ] Table size X: 750 mm Table size Y: 550 mm max. workpiece weight: 1500 kg Electrode changer: 6-fold Control: LN2 Quill clamping fixture: EROWA ITS Working container: 950 x 740 x 450 mm

Key data: 750 mm, 550 mm

Type: Die-sinking EDM machine Ident Number: 22603 Category: Die-sinking EDM machines / EDM Manufacturer: Sodick Model: AQ 55 L Year of construction: 2007 Travel: 500 x 400 x 350 mm [ X x Y x Z ] Table size X: 750 mm Table size Y: 550 mm Electrode changer: 32-fold Working basin: 950 x 725 x 410 mm Quill clamping fixture: EROWA

Description: Various workshop equipment: .  , - N.1 Workbench with wooden top , 100 kg, 700x1000x1000 mm. - N.3 ionization units , 600 kg, ,2500x1200x2000 mm ( 3 ionization units each 1000 x 800x2000 mm, with tanks 200x1000 mm). - N.1 Electrical cabinet , 80 kg, 800x1200x1200 mm. - N.1 GALILEO ,ERGOTEST COMP 25 hardness tester, 100 kg, 600x250x1000 mm - , N.1 Chiller MTA TAE051 ,year 2001 , ,215 kg, ,1600x800x1600 mm (400 V, 50 Hz, 14 A, 7.8 kW, IP54, refrigerant  ,R407C, Maximum pressure 26 bar, maximum temperature 65°) - , N.1 FAC electric pallet truck , 800 kg, 1800x800x2000 mm (With battery charger) - N.2 workshop chest of drawers ,AMOS , 160 kg, 1400x750x1050 mm (each 80 kg, ,700x750x1050 mm) - N.1 MECATOOL workbench with drawers, 100 kg, 1400x800x1300 mm (including drawers) - N.1 Hydraulic equipment for handcrafted package  ...

SICK S30B-3011BA Safety Laser Scanner Characteristics Sensor version without system connector Indoor application Protective field range 3 m Warning field range 8 m (at 15% remission) Distance measuring range 30 m Type of Field Theorem Triple Field Theorem Number of Field Sets 1 Number of fields 3 Number of monitoring cases 1 Scan angle 270° Resolution (configurable) 30 mm, 40 mm, 50 mm, 70 mm, 150 mm Angular resolution 0.5° Response time 80 ms 1) Protective field surcharge 100 mm Number of multiple evaluations 2 ... 16, Configurable Automatic reset delay 2 s... 60 s, configurable Safety-related parameters Type Type 3 (IEC 61496) Safety integrity level SIL2 (IEC 61508) Category Category 3 (EN ISO 13849) Performance Level PL d (EN ISO 13849) PFHD (Mean Probability of Hazardous Failure per Hour) 8.0 x 10-8 TM (service life) 20 years (EN ISO 13849) Function  ...

SICK S30B-3011BA Safety Laser Scanner Characteristics Sensor version without system connector Indoor application Protective field range 3 m Warning field range 8 m (at 15% remission) Distance measuring range 30 m Type of Field Theorem Triple Field Theorem Number of Field Sets 1 Number of fields 3 Number of monitoring cases 1 Scan angle 270° Resolution (configurable) 30 mm, 40 mm, 50 mm, 70 mm, 150 mm Angular resolution 0.5° Response time 80 ms 1) Protective field surcharge 100 mm Number of multiple evaluations 2 ... 16, Configurable Automatic reset delay 2 s... 60 s, configurable Safety-related parameters Type Type 3 (IEC 61496) Safety integrity level SIL2 (IEC 61508) Category Category 3 (EN ISO 13849) Performance Level PL d (EN ISO 13849) PFHD (Mean Probability of Hazardous Failure per Hour) 8.0 x 10-8 TM (service life) 20 years (EN ISO 13849) Function  ...

Wire EDM machine SODICK A 600 manufactured in 1997. Technical parameters of the SODICK A 600 EDM machine: - table travel (X axis): 600 mm - table travel (Y axis): 400 mm - Z axis travel: 270 mm - maximum dimensions of the processed part (width x depth x height): 800 x 550 x 260 mm - maximum weight of the workpiece: 900 - auxiliary table travel (U axis x V axis): 70 x 70 mm - wire diameter: 0.1 ~ 0.3 mm - maximum wire speed: 250 mm / sec. - wire tension: 0.2 ~ 2.8 kgf - cutting inclination at an angle: + -15 degrees per 100 mm of thickness - height from the floor to the surface of the working table: 1000 mm - machine tool dimensions (width x depth x height): 2188 x 2645 x 2100 mm - machine tool weight: 3700 kg

PLUNGE EDM MACHINE AEG 443 B C AXIS X-AXIS STROKE: 1000 MM Y-AXIS STROKE: 600 MM Z-AXIS STROKE: 500 MM

PLUNGE EDM MACHINE CDM ROVELLA MODEL: ZENIT P1 STROKE X: 1500 MM STROKE Y: 1000 MM STROKE Z: 500 MM C AXIS 10-POSITION TOOL CHANGER MAX ELECTRODE WEIGHT: 2,500 KG MAX. WORKPIECE WEIGHT: 12,000 KG SUPPORT SURFACE: 2000 X 1200 MM TUB SIZE: 3000 X 1500 X 1075 MM CONTROL: HEIDENHAIN MOD. 406

PLUNGE EDM MACHINE AEG ELBOMAT 333 P ALEXTA DISPLAYED X-AXIS STROKE: 414 MM Y-AXIS STROKE: 292 MM Z-AXIS STROKE: 360 MM

PLUNGE EDM MACHINE AEG ELBOMAT 402 M DISPLAYED GHIBLI X-AXIS STROKE: 290 MM Y-AXIS STROKE: 160 MM Z-AXIS STROKE: 150 MM TABLE: 550 X 400 MM MAX HEIGHT PIECES: 300 MM MAX SIZE PIECES: 750-545 MM

PLUNGE EDM MACHINE AEG ELBOMAT 944 X-AXIS STROKE: 818 MM Y-AXIS STROKE: 326 MM Z-AXIS STROKE: 305 MM

HITACHI WIRE EDM MACHINE MODEL MS 250 H-CUT 8Q X-AXIS STROKE: 1030 MM Y-AXIS STROKE: 810 MM Z-AXIS STROKE: 530 MM

PLUNGE EDM MACHINE CDM ROVELLA MODEL: BF600 STROKE X: 600 MM STROKE Y: 400 MM STROKE Z: 350 MM CONTROL: HEIDENHAIN SUPPORT SURFACE: 800 X 550 MM TUB SIZE: 1400 X 870 X 500 MM

table length: 500 mm table width: 350 mm ampere: 65 A Control: AGIEVISION 5 CNC total power requirement: 20 kW weight of the machine ca.: 4000 kg dimensions of the machine ca.: m A G I E (Switzerland) CNC - Controlled Wire Cutting EDM Machine Model AGIECUT PROGRESS V 3, Year 2007 Working range, X Y Z (=height) 500 x 350 x 426 mm Wire head, U-V axis (helical/taper cuts) + / - 30 °/ +/- 70 mm Resolution of axes 0.0001 mm Speed for positioning the axes up to 3 m/Min. Tolerances (If machine is new) 4 µ Workpiece dimensions, L x W x H max. 1.050 x 650 x 420 mm Max.weight of workpiece with/w.o. Dieelektricum 400/800 kg Clamping System Universal Beams with fixing holes Cutting wire Ø 0.2 – 0.33 mm Size of wire roll up to 25 kg Cutting speed of wire  ...

Dieburg Pronto 5035 CNC Die-sinking EDM machine

Wire diameter: 50 mm Speed: 50 rpm Number of rolls: 0   CNC Brand: _Unknown / Other ARD Facile A Controller EDM SINKER Seperate coolant tank IMEA ISTEMA head Collet device with collets X-Axis:     300mm Y-Axis:     250mm Z-Axis:     300mm Table Length:600mm Table Width:360mm Length:     2600mm Width:      2400mm Height:     2600mm Weight:     4500kg

table length: 850 mm table width: 550 mm ampere: 70 A control: CNC MITSUBISHI 32bit axis stroke (X,Y,Z): 550 / 850 / 450 mm weight of the machine ca.: 6 t dimensions of the machine ca.: 2,4 x 2,65 x 2,68 m Spark Erosion Machine / Cavity Sinking EDM Machine The machine is in a very good condition. Equipment / Eccessories: - Y-travel at electrode change and loading position: 1180 mm - integrated C-axis working head speed adjustable: 10/20 rpm - integrated C-axis / working head measuring resolution: 0.001 mm - load capacity without changer: 50 kg - load capacity with changer: 10 kg - max. head load: 200 kg - max. distance tool carrier plate to work table: 585 cm - min. distance tool carrier plate to work table: 125 mm - working tank: - lifting tank dimensions (W x D x H ): 800 x 1100 x 480 mm - dielectric height programmable/automatic: 440 mm - filter cartridge version: cartridges integr ...

Electronic module SEIBU SLB-210B no.: 500 spare part for SEIBU EDM machine EW 600 J ! used, tested ! Dimensions: 215 x 200 x 30 mm

Electronic Module, PLC Power Supply TDK TRM042 Ue: 100 V AC Ua1: 5 V 15 A DC Ua2: 15 V 1.6 A DC Ua3: 5 V 1.6 A DC spare part for SEIBU EDM machine EW 600 J !, among others used, checked ! Dimensions: 200 x 100 x 130 mm

Electronic module SEIBU SLB-211B no.: 0276 spare part for SEIBU EDM machine EW 600 J ! used ! Dimensions: 215 x 200 x 30 mm

Electronic Module, Step Driver FES UD-250A - 2- 5V ( UD-250A-2-5V ) Art. No.: 8072 - 6508 100 V AC spare part for SEIBU EDM machine EW 600 J ! used, tested ! Dimensions: 200 x 115 x 130 mm

Electronic module SEIBU SLB-210C no.: 501 spare part for SEIBU EDM machine EW 600 J ! used, tested ! Dimensions: 210 x 200 x 30 mm

Electronic Module, Power Supply, Dual Power Supply SHINDENGEN CY12005 Ua: 10.8 - 13.2 V DC CY242R5 Ua: 21.6 - 26.4V DC Ue: 90 - 129 V AC spare part for SEIBU EDM machine EW 600 J !, among others used, checked ! Dimensions: 200 x 150 x 100 mm

Electronic module, control board HBC - FUNKTECHNIK 72.07.001.B coding: 2719 spare part for SEIBU EDM machine EW 600 J ! used, tested ! Dimensions: 150 x 110 x 10 mm

Electronic module, Display SEIBU Toshiba TC4030BP TSC 7126CPL ( TSC7126CPL ) DANAM 8717 ( DANAM8717 ) spare part for SEIBU EDM machine EW 600 J !, among others used, checked ! Dimensions: 135 x 70 x 25 mm

Electronic module SEIBU 9155 4215 B ( 91554215B ) no.: 3183 spare part for SEIBU EDM machine EW 600 J ! used ! Dimensions: 120 x 80 x 10 mm

Electronic module, relay board HBC - FUNKTECHNIK 72.05.001.B 12x relay NAIS 12 V DC spare part for SEIBU EDM machine EW 600 J !, among others used, checked ! Dimensions: 120 x 140 x 30 mm

Control panel, electronic module SEIBU Control panel EW 600 ( EW600 ) spare part for SEIBU EDM machine EW 600 J ! used ! Dimensions: 355 x 95 x 55 mm

Electronic Module, Servo Module YASKAWA ELECTRIC CPCR-FR02 BY22 ( CPCR-FR02BY22 ) spare part for SEIBU EDM machine EW 600 J ! used, tested ! Dimensions: 225 x 95 x 155 mm

Filter module, mains filter SOSHIN Type: 33 BCQ75PP2K-01 spare part for SEIBU EDM machine EW 600 J ! used ! Dimensions: 200 x 55 x 85 mm

Control and programming panel, electronic module, switch Board SEIBU Control and programming panel EW 600 ( EW600 ) spare part for SEIBU EDM machine EW 600 J ! used, tested ! Dimensions: 570 x 105 x 440 mm

Elektronikmodul MD, Maschinenfabrik Dieburg GmbH A5600-0 6403 04 005600 00 spare part for EDM machine MD PRONTO 5040 ! used ! Dimensions: 240 x 233 x 45 mm

Servo controller, servo control ESR POLLMEIER BN 5608 BN6508.1014 319111 Input: 220 V AC max. 1.6 A spare part for EDM machine MD PRONTO 5040 ! used, checked ! Dimensions: 215 x 105 x 180 mm

Elektronikmodul MD, Maschinenfabrik Dieburg GmbH A602-2 6403 04 000 602 02 spare part for EDM machine MD PRONTO 5040 ! used ! Dimensions: 235 x 233 x 31 mm

Electronic module, power level A-606 MD, Maschinenfabrik Dieburg GmbH A660-1 6403 30 004660 01 Spare part for EDM machine MD PRONTO 5040 ! used, tested ! Dimensions: 235 x 233 x 40 mm

Electronic module MD, Maschinenfabrik Dieburg GmbH A695-0 6403 04 00469500 spare part for EDM machine MD PRONTO 5040 ! used ! Dimensions: 433 x 265 x 100 mm

Electronic module, power level A-608 MD, Maschinenfabrik Dieburg GmbH A680-1 6403 30 004680 01 Spare part for EDM machine MD PRONTO 5040 ! used, tested ! Dimensions: 235 x 233 x 40 mm

Electronic module MD, Maschinenfabrik Dieburg GmbH A8112-1 6403 04 008112 01 spare part for EDM machine MD PRONTO 5040 ! used, tested ! Dimensions: 235 x 183 x 20 mm

Electronic module, power level A-640 MD, Maschinenfabrik Dieburg GmbH A640-1 6403 30 003640 01 spare part for EDM machine MD PRONTO 5040 ! used, tested ! Dimensions: 235 x 233 x 35 mm

Elektronikmodul MD, Maschinenfabrik Dieburg GmbH A5104-1 6403 30 005104 01 spare part for EDM machine MD PRONTO 5040 ! used, tested ! Dimensions: 235 x 178 x 15 mm

Monitor, TFT-LCD Display Module NEC NL8060BC26-17 Resolution: 800 x 600 Screen: 211.2 x 158.4 mm Screen diagonal: 10.4 spare part for EDM machine MD PRONTO 5040 !, among others used, checked ! Dimensions: 262 x 208 x 80 mm
