driven used for sale

Control: FANUC Number of axles: 7 Complete with IEMCA GENIUS 118 bar loader Main spindle: - Max. diameter bar: 12 (15) mm - Maximum speed rpm: 12,000 - Driving performance (S2: 30 min/ S1) kW 3.7 / 2.2 Spindle counter: - Maximum turning diameter: 12 (15) mm - Maximum speed rpm: 12,000 - Driving performance (S2: 30 min/ S1) kW 3.7 / 2.2 Aces: - Maximum rapid translation of the axes m / min 40 - Maximum acceleration of the axes m / s2 10 - Translation path X1 (linear) / Y1/ Z1 mm 30/ 195/ 120 - Translation path X2 / Y2 / Z2 mm 180/-/ 180 Tool holder trolley 1: - Tool holder system: linear - Number of fixed/driven tools: 5 / 4 - Cross section of the joint for fixed tools: 10 x10 mm - Drive power for driven tools (S3 40% / S1): kW 1.1 / 0.55 Tool holder sliding carriage 2: - Tool holder system: linear - Number of fixed/driven tools: 8/ 5 - Cross se ...

turning diameter: 175 mm turning length: 186 mm control: Sinumerik 840 D Siemens swing diameter over slide rest: 185 mm max. bar capacity: 65 mm Spindle left Unit: spindle nose: DIN 55 026 KK6 spindle bearing diameter: 100 mm spindle bore: 73 mm bar diameter: 65 mm chucking diameter: 175 mm turning speed range - spindle: max. 4.500 U/min drive capacity - spindle motor: 12 / 15 kW max. Torque: 193 Nm Spindle right Unit: spindle nose: DIN 55 026 KK6 spindle bearing diameter: 100 mm max. chucking diameter: 175 mm turning speed range - spindle: max. 6.500 U/min drive capacity - spindle motor: 9 / 11 kW max. Torque: 140 Nm Number of Turret: 2 pos Traverse X-Axis 1: 235 Traverse Z-Axis 1: 270 Traverse X-Axis 2: 235 mm Traverse Z-Axis 2: 680 rapid traverse X-axis: 24 m/min rapid traverse Z-axis: 24 m/min feed power: X = 7.000 N feed power: Z = 7.000 N numbers of turret head positions: 2 x 12  ...

Description: Item contents: Tool holder Straight driven EWS No. 40 3025 G300 i=1:1 (7 pieces) Tool holder Straight driven GMP No. 803 300.1010 i=1:1 (1 piece) Tool holder Angle Driven EWS no. 60.3023 G300 RV i=1:1 (6 pieces) Tool holder angle driven Heimatec no. 8 030 2609 (3 pieces) Holder for boring bar holder EWS no. 17.3040 G300 V (8 pieces) Holder for MKD GMP no. 803 300.9000 i=1:1 (1 piece) Angle holder for collet chuck ER 32 EWS no. 31.3032 G300 RLV (6 pieces) Swivel holder Heimatec no. 1.3023 G300 RL (4 pieces) Swivel holder EWS no. 1.3020 / 16 (11 pieces) Multiple holder 20 mm no. 8 274 24 000 (1 piece) Cut-off holder EWS no. 32.3032 CTX RL ÜK (1 piece) Stop EWS no. 25.500 G300 RL (1 piece) weight approx.: 115 kg, Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 300 mm

Description: EMCO Hyperturn 110 - SM2 - 1700 , Serial number and Control Serial number: H1114020734 Control system: SIEMENS Sinumeric 840D sl Working area Rotation diameter over bed: 720 mm Max. turning diameter: 710 mm Distance between the spindle noses: 1700 mm Traverse paths Traverse path X1 axis: 340 mm Traverse path X2 axis: 300 mm Traverse path Z1 axis: 1340 mm Traverse path Z2 axis: 1340 mm Traverse path counter spindle: 1360 mm Main spindle with C-axis , (Counter spindle specifications are identical) Angular resolution: 0.001° Spindle nose (DIN 55026): A2-11 Bore in the drawtube with clamping cylinder in mm: 110 x 1000 deep Bore in the spindle: 125 mm Bearing inside diameter in front bearing: 190 mm Bearing inside diameter in rear bearing: 170 mm Workpiece weight in the chuck max.: 500 kg Two tool turrets (specification per turret) Too ...

:HBM-130XL spindle diameter:130 mm x-travel:2000 mm y-travel:1800 mm z-travel:(ohne Gegenhalter) 2000 mm U-axis:250 mm W-axis (spindle longitudinal):900 mm max. torque on the spindle:3136 Nm B-axis (table):360x1 ° rapid speed:X/Y/Z/W: 2500 mm/min table load:10 t table-size:1800 x 1600 mm T-slots:11 Stk. T-slot - width:28 mm transmission ratio:4 Stk. spindle speed:4-800 1/min spindle taper:50 ISO faceplate:Drehmoment: 4900 Nm faceplate:2.5-125 1/min faceplate:Umdrehung stufenlos einstellbar faceplate:Ø:750 mm weight of the machine ca.:29300 kg main drive:15 kW Machine size (LxWxH):7030x4665x3800 mm 2-Axis DRO :von NEWALL f. X- und Y-Achse Technical Offer of HBM-130 ? Powerful servo spindle motor and four spindle speed rang, stepless in each range. much lower maintenance and 80% failure rate reduced ? High rigidity spindle could insure the strong machining ? Worktable 4x90° position  ...

:HBM-130 | HBM-130L | HBM-130XL spindle diameter:130|130|130 mm x-travel:1600|2000|2000 mm y-travel:1400|1800|1800 mm z-travel:2000 mm U-axis:250 mm W-axis (spindle longitudinal):900 mm max. torque on the spindle:3200 Nm B-axis (table):360x1 ° rapid speed:X/Y/Z/W: 2500 mm/min table load:8|10|10 t table-size:1600 x 1400|1800 x 1600|2200 x 2000 mm T-slots:9/11/12 Stk. T-slot - width:28 mm transmission ratio:4 Stk. spindle speed:4-800 1/min spindle taper:50 ISO faceplate:Drehmoment: 4900 Nm faceplate:2.5-125 1/min faceplate:Umdrehung stufenlos einstellbar faceplate:Ø:750 mm weight of the machine ca.:22,5|24,5|25,5 t main drive:22 kW Machine size (LxWxH):6995/3647/342|7030/4665/3800|7030/4665/3800 mm PLC control:Siemens S7 servo motors:von Siemens/Fanuc/Fagor Technical Offer of HBM-130 ? Powerful servo spindle motor and four spindle speed rang, stepless in each range. much lower mainten ...

CNC multi-tasking lathe NAKAMURA SUPER NTX-S Reference No.: 18038 Mfg. year 2007 S/No. V300901 FANUC 16i-TB Luckbei-dialog system supercap Maximum turning diameter -Upper turret 390 mm -Lower turret 300 mm Maximum turning length 1,100 mm Max cash working capacity 65 mm Milling spindle AC 18.5/11 kW Milling spindle maximum speed 12,000 rpm Capto C6 Servo controlled B-axis, 230° Y-axis 160 mm ATC with 40 tools Main and sub spindle AC 22/18.5 kW Main and sub spindle maximum speed 4.500 rpm 12/24-station turret, all stations for driven tools Maximum speed of driven tools 3,600 rpm 2 off. 3-jawchuck 210 mm, SCHUNK Coolant tank 250 liters High pressure pumps Swarf conveyor 1 set of toolholders for lower turret -static 9, 3-driven weight 19,000 kg CE-mark

Stock# U2301-1 Second hand stainless steel contact parts twin shaft planetary dissolver by Molteni type TM5 RP.SV. Mixer has stainless steel jacketed mixing pan with internal diameter 207 mm x depth 213 mm. Total volume of pan is 7 l, working volume about 5 l. Mixing pan has side wall bottom discharge outlet. Mixer has two agitators with toothed discs and one wall scrapper. Toothed discs have diameter 100 mm and are driven by vari speed gearbox and two speed el. motor 1.75/1.4 kW, 2800/1400 rpm, 380 V, 50 hz, in EEx-d II B T4. Working rotation of disc agitators manually adjustable in range from 300 up to 4800 rpm. Wall scrapper is driven by el motor 0.26 kW, 1360 rpm, 220/380 V, 50 hz (design EEx-d II B T5) through reducer with ratio i= 44.77, what gives output rotation at 32 rpm. Agitators are risen by hydraulical device driven by el. motor 0.26 kW, 1360 rpm, 220/380 V, 50 hz, EEx-d II ...

This machine can be considered as an ultimate solution for the production of concrete elements providing the one to choose numerous options as an additional upgrade to the machine that can make production even more efficient: Filling box on servo drives Filling boxes both from the coarse mix and face mix powered with 2 servo motors create fast movement back and forth contributing reliable filling of the mould. As for the coarse mix device filling box it is additionally equipped with an agitator (driven by the hydraulic cylinder) for equal and fast filling. Servo vibration Hi-dynamic Servo vibration system transmits power for the high compaction with the just right consumption of electrical power to vibration table consisted of impact and ledge bars and thus providing top-quality paving stones, blocks, curbstones as well as any other products which modern demanding market requires ...

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: SIEMENS 840 D Technical data Number of axis total: 7 Number of spindles: 2 Number of revolvers: 2 Spindle nose: DIN 55026 A4 Spindle hole: 32 mm Travels: X1: 180 mm X2: 195 mm Z1: 340 mm Z2: 440 mm Y1: +40/-40 mm Y2: +40/-25 mm Y axis: 70 (-30/+40) mm Turret slide: number: 2 Number of positions turret 1: 16 Number of positions turret 2: 12 Driven tools turret 1: 16 Driven tools turret 2: 12 Spindle speeds: 6000 rpm Power of driven tools: 6 kW Spindle nose: VDI: 25 DIN 69880 Main spindle: C axis Spindle speeds: stepless up to: 8000 rpm Back spindle mobile: max. speed: 8000 rpm Power of back spindle: 12 kW Spindle motor: 7 - 9 kW Air connect: 6 bar Voltage 50 Hz 3x: 400 Volt Total power required: 25 kVA Total power required: 20 kW Machine ...

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: FANUC Operating hours: 2330 Technical data Number of spindles: 2 Number of revolvers: 2 Distance spindle nose: 250 - 870 mm Maximum turning length: 160 mm Max. turning diameter: 130 mm Turret carriage: Carriage 1: Longitudinal travel (Z-axis): 200 mm Longitudinal travel (X-axis): 180 mm Transversal travel (y-axis): +/-30 mm Carriage 2: Longitudinal travel (X-axis): 180 mm Cross travel (z-axis): 620 mm Y axis: +/-30 mm Number of positions turret 1: 12 Number of positions turret 2: 12 Driven tools turret 1: 6 Driven tools turret 2: 6 Spindle speeds: 3600 rpm Power of driven tools: 3.7 / 2.2 kW Main spindle: Internal spindle diameter: 42 mm Spindle speeds: stepless up to: 5500 rpm Spindle power: 7.5 kW Back spindle: Spindle hole: 40 mm max. sp ...

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: GE FANUC Series 18i-T Operating hours: 11069 Technical data Number of spindles: 2 Number of revolvers: 2 Distance spindle nose: 560 mm Turret slide: Number of positions turret 1: 12 Number of positions turret 2: 12 Driven tools turret 1: 6 Driven tools turret 2: 6 Spindle speeds: 100 - 3000 rpm Tool shank cross section: 20 mm Power of driven tools: 1.5 / 3.7 kW Max. drill capacity: 25 mm Indexing time: 0.4 sec Upper turret head: X axis: 175 mm Z axis: 305 mm Lower turret head: X axis: 132 mm Y axis: 340 mm Z axis: 155 mm Main spindle: Spindle nose: ASA 5" Spindle hole: 52 mm Inner taper type: DIN 6343 Max. bar diameter: 41 mm Max. turning diameter: 200 mm Maximum turning length: 300 mm C axis (spindle,resolution): 0.001 ° Spindle speed ...

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: NUM Technical data Spindle hole: 43 mm Carriage 1: Longitudinal travel (Z-axis): 240 mm Transversal strocke (X axis): 150 mm Transversal travel (y-axis): 100 mm Carriage 2: Longitudinal travel (X-axis): 340 mm Cross travel (z-axis): 340 mm Y axis: 100 mm Turret slide: Number of positions: 16 Number of positions turret back side: 8 Driven tools turret 1: 16 Back spindle: Voltage 50 Hz 3x: 400 Volt Total power required: 17 kW Various accessories: High pression colant device Paper filter facility Oil mist extractor Bar feeder: LNS Interface serial port RS 232 Chip conveyor Toolholders Set of toolholders Driven tool holder radial (nbr.): 5 Driven tool holder axial (nbr.): 9 Tool holder fix (nbr.): 6 Tool holder (number): 6

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: GE FANUC Series 18i-T Operating hours: 0 Technical data Centre height: 275 mm Distance between centres: 600 mm Swing over cross-slide: 150 mm Swing over bed: 600 mm Turning length: 610 mm Carriage: Longitudinal travel (Z-axis): 600 mm Transversal strocke (X axis): 460 mm Resolution: 0.001 mm Turret slide: number: 1 "DUPLOMATIC" Number of positions turret 1: 12 Fixed tools turret 1: 6 Driven tools turret 1: 6 Inner cone diameter: 20 x 20 mm Inner cone DIN: VDI 30 Taper in spindle: Camlock: A2-6 Inner taper type: B 32 / B 45 / F 48 Collet bore: 24 / 36 / 42 mm C axis Spindle speeds: stepless up to: 4000 rpm Inner taper type: F66 Internal spindle diameter: 60 mm Feeds: stepless longitudinal from: 0 mm/min up to: 5000 mm/min transversal ...

Control: SIEMENS SINUMERIK 840 D Operating hours: 29500 Technical data Number of axis total: 4 Number of spindles: 2 Distance spindle nose: 580 mm Swing over cross-slide: 100 mm Swing over bed: 145 mm Spindle hole: 50 mm Turning diameter: 100 mm Bar diameter with collet: 36 mm Clamping chuck diameter: 140 mm Carriage 1: Longitudinal travel (Z-axis): 320 mm Transversal strocke (X axis): 220 mm Carriage 2: Longitudinal travel (X-axis): 345 mm Cross travel (z-axis): 120 mm Turret slide: number: 2 Number of positions turret 1: 12 Number of positions turret 2: 12 Driven tools turret 1: 12 Driven tools turret 2: 12 Spindle speeds: 30/6000 rpm Spindle speeds: 30/6000 rpm Power of driven tools: 2.1 kW Plage vitesse de rotation rad./axial: 30/6000 rpm Collet bore: 36 mm Spindle speeds: stepless from: 40 rpm up to: 8000 rpm Back spindle: max. speed: 40/8000 rpm Power of back spindle: 26/21 kW st ...

Key data: 175 Traub, 650 TX8i-S

Turning diameter: 175 mm Turning length: 650 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 12   CNC Brand: Traub CNC Model: TX8i-S X-Axis:          175mm Y-Axis:          40mm Z-Axis:          650mm Spindle bore:    65mm Speedrange:      5000Rpm Spindle power:   24kW Subspindle speeds:7000Rpm Subspindle bore: 42mm Subspindle power:28kW Length:          6.500 mm  Width:           2.400 mm  Height:          2.400 mm  Weight:          10.000 kg  Upper left turret: Positions 10 Driven station 10 X/Z Stroke 175 / 650 Y Stroke 40 Vdi 30 Speeds 6000 Rpm Lower right turret Positions 10 Driven station 10 X/Z S ...

: 50 mm roll diameter: 150 mm revolutions per minute: 10 U/min adjustments: 120 mm total power requirement: 1,5 kW weight of the machine ca.: 430 kg dimensions of the machine ca.: 1,2 x 0,8 x 1,75 mm The PB 50-3 H is a hydraulic profile bending machine: we produce thisprofilebender in Europe and deliver it directly from our stock. This hydraulic profile bending machine has a shaft diameter of 50 mm and 3 driven rolls. It is easy to switch between working with two or three driven rolls via the gearshift on the side of the machine. Operation of the profile bender is done by a foot pedal and with the pedals you choose the turning direction of the rolls. Our PB 50-3 H has a handpump to adjust the position of the upper / centre roll with hydraulics. The position of this upper roll can be read out on a scale and on the digital display (0,1 mm). Furthermore, our Profi Bend machines can work in  ...

3″ x .125″ Oto Mills – Someron HF Tube Mill Make (Entry Section): Oto Mills, Make (Forming & Sizing): Somenor, Maximum Pipe Diameter: 76mm, Wall Thickness: 0.8mm – 3mm, Shaft Diameter: 60mm Direction: Right to Left. Abbel Jib Crane, Mandrel Uncoiler, Weight Capacity: 10,000Lb, Powered Mandrel Expansion. Automatic Shear & End Welder, Hydraulic Shear, Automated Torching Head, Vertical Otto Mills Accumulator with DC Motor Drive, Driven Entry & Exit Guiding Rolls, Driven Entry Pinch Rolls, Adjustable Edge Guides, 5-Roll Coil Flattener. Forming Mill with Six Forming Stands, Seven Side Stands, Individual Gear Boxes, Universal Drive, Complete Set of Second Rafted Forming Stands, Motor: 60HP DC Drive. Welding Section with Emmedi 200Kw High Frequency Welder, 3-Roll Mechanical Squeeze Box, ID Scarfing Head, Powered Bead Re-Winder, Extended Cooling Section. Sizing Mill with Four (4) Sizi ...

CNC lathe make MONFORTS type DNC 5Year 1995 with C-axis and driven tool stationsCircumference diameter: 560 mmNumber of revolvers: 2Travel distance Z1 / Z 600/600 mmTravel X1 / X 260/260 mmMax. Spindle distance: 1460 mmSpindle passage: 85 mmSpindle flange: A8 / A8feed drivesRapid traverse Z1 / Z 15/15 m / minRapid traverse X1 / X 12/12 m / minFeed force Z1 / Z 11900/11900 NFeed force X1 / X 6600/6600 NNumber of revolvers: 2Number of tools per turret: 12Straight shank: 40 mmTurning tool shank: 25 x 25 mmSpeed range: 5 - 4000 rpm.Drive power: 18/24 kWWith:- CNC control SIEMENS 840 C- C axis- 2 tool turrets with driven tool stations- without driven tools- 2 opposite spindles- 1 set of tool holders- Chip conveyorSingle-layered run!usedPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors except ...

Type: LT200-MY Twin Star Year of construction: 12/2006 Commissioning: 2007 Control: OSP – P200L Delivery time: ex stock The lathe is in very good general condition. Due to the basic and additional equipment, this used machine is versatile. With the automatic bar feeder, the double turret equipment, the additional Y-axis and the parts catcher, the machine produces your workpieces completely independently. From start to finish. Due to the equipment with main and counter spindle, production can be economically effective and fast. Machinery Collet chuck SMW on both sides Main and counter spindle Y-axis Conveyor Bar loading magazine Turbo 5-55 Parts catcher - B-turret with swivel ejection to the collection box (at the door). Onward transport by internal parts conveyor belt. Technical details Swing diameter: mm 400 turning diameter: mm 210 turning length: mm 960 2 tool ...

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: SIEMENS SINUMERIK 840C Technical data Number of spindles: 2 Number of revolvers: 2 Spindle hole: 65 mm Turning diameter: 200 mm Turning length: 400 mm Turret slide: Number of positions turret 1: 14 Number of positions turret 2: 14 Driven tools turret 1: 14 Driven tools turret 2: 14 Spindle speeds: 6000 rpm Power of driven tools: 5.5 kW Inner cone DIN: 69 880 Indexing time: 0.4 sec Upper turret head: X axis: 155 mm Y axis: 120 mm Z axis: 400 mm Lower turret head: X axis: 105 mm Z axis: 400 mm Main spindle:: HAINBUCH Internal spindle diameter: 60 mm Spindle speeds: stepless up to: 6000 rpm Back spindle:: HAINBUCH max. speed: 6000 rpm Internal spindle diameter: 60 mm Spindle diameter: 160 mm Back spindle stroke: 445 mm Rapid traverse X: 22.5 m ...

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: SIEMENS SINUMERIK Technical data Number of spindles: 2 Number of revolvers: 2 Spindle hole: 65 mm Turning diameter: 200 mm Turning length: 400 mm Turret slide: Number of positions turret 1: 14 Number of positions turret 2: 14 Driven tools turret 1: 14 Driven tools turret 2: 14 Spindle speeds: 6000 rpm Power of driven tools: 5.5 kW Inner cone DIN: 69 880 Indexing time: 0.4 sec Upper turret head: X axis: 155 mm Y axis: 120 mm Z axis: 400 mm Lower turret head: X axis: 105 mm Z axis: 400 mm Main spindle: Internal spindle diameter: 60 mm Spindle speeds: stepless up to: 6000 rpm Back spindle: max. speed: 6000 rpm Internal spindle diameter: 60 mm Spindle diameter: 160 mm Back spindle stroke: 445 mm Rapid traverse X: 22.5 m/min Rapid traverse Z: 45 ...

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Technical data Max. turning diameter: 20 mm Turning length: 320 mm Max. drilling diameter: 12 mm Max. threading diameter: 10 M (Metric) Internal spindle diameter: 24 mm Spindle speeds: stepless from: 200 rpm up to: 8000 rpm Independent carriage: Number of positions: 3 + 5 number of driven tools: 3 Back spindle:: Ø 32 mm speeds: from: 200 rpm up to: 5000 rpm Spindle positioning increment: 15 ° Turret slide: number of tools: 10 number of driven tools: 10 Rapid traverse: X axis (longitudinal): 20000 mm/min C axis (spindle,resolution): 1 ° Voltage 50 Hz 3x: 400 Volt Spindle motor: 3.7/5.5 kW Total power required: 8 kVA Machine´s weight about: 2400 kg Overall dimensions machine: Length: 2800 mm Width: 1370 mm Height: 1800 mm Various accessories:  ...

Stock# U2416 Used dissolver by Oliver+Batlle S.A.(ES) type DISPERMIX 50 designed for work on vacuum. Machine has non-corrosive shaft with working length 144.5 cm. Shaft is belt driven by el motor 40 kW, 1470 rpm, 380/660 V, 50 hz. Ex design of motor (ExeG). Mechanical adjustment of shaft rotation. Shaft is equipped with stainless steel toothed disc, with diameter 350 mm. Rising and lowering of agitator in range 110 cm and is driven hydraulically. Machine has also lid cover, with diameter 108.5 cm, for work on vacuum, rised and lowered by two hydraulical actuators. Together with mixer there are: - vacuum pump Pfeiffer Vacuum model Hena 200, output up to 240 m3/h, driven by el motor 5.5 kW. - stainless steel mixing pan with volume 500 l. Mounted on 4 leg, no bottom discharge outlet. - local control panel integrated with two hydraulic devices.

Turning diameter: 0 mm Turning length: 0 mm Turret positions: 0 Positions ATC: 0   Number controlled axis: 0   CNC Brand: 0 CNC Model: 0 Control: FANUC Series 16i-T Technical data Number of axis total: 9 Number of spindles: 2 Max. turning diameter: 205 mm Machining diameter max.: 12 mm Spindle speeds: stepless up to: 12000 rpm C axis (spindle,resolution): 0.01 ° Independent carriage: Number of positions: 5 number of driven tools: 3 Spindle speeds (turning tools): 6000 rpm Power of driven tools: 0.5 kW Back spindle: up to: 12000 rpm C axis (spindle,resolution): 0.01 ° Turret slide: number: 1 number of tools: 8 number of driven tools: 8 Spindle motor: 5.5 kW Power of back spindle: 3.7 kW Machine´s weight about: 3400 kg Overall dimensions machine: Length: 2670 mm Width: 1375 mm Height: 1600 mm Various accessories: Bar feeder Manufacturer: LNS Parts catcher Workpiece conveyor Lamp Coo ...

CNC controller: SINUMERIK 810D with ShopTurn Capacity: X-axis travel mm: 300 Z-axis travel mm: 1.050 Turning length mm: 1.050 Max. turning diameter mm: ø 465 Swing over bed mm: ø 680 Swing over cross-slide mm: 465 Bar work capacity mm: ø90 Upper turret: Number of tool slots St .: 12 (6x driven) Speed ​driven tools RPM: 4.000 Main spindle: Speed ​spindle rpm: 3.250 Drive power spindle kW: 33/22 (40%/100% DC) Spindle bore mm: 102,5 Spindle nose: Flat flange (220h5) Maximun torque Nm: 420 (100% DC) Tailstock: Tailstock travel mm: 850 Holder: MK5 Equipment: part catcher Workarea light Foot switch for chuck or collet system Driven tools included Working time hours Spindle 1: 72.059 Rated power kVA: 50 Basic machine dimensions / weight: Length mm: 5.300 Width mm: 2.230 Height mm: 2.010 Weight kg: 8.100

WEINIG / GreCon Short Wood Finger-jointing Line Ultra TT Data of the system: • Wood inlet length (min. - max.) 150 - 1000 mm (1300 mm) • Reference timber inlet length at the finger-jointing line 400 mm • The length of the wood to be processed must be at least 25 percent longer than the width of the wood to be processed • Wood thickness (min. - max.) 20 - 80 mm • Reference wood thickness 28 mm • Wood width (min. - max.) 40 - 205 mm • Reference wood width 90 mm • Reference wood cross-section 28 mm x 90 mm • Wood outlet length (min. - max.) 3000 - 6100 mm • Reference wood outlet length 6100 mm • Tine profile (length) 10 – 11 mm • Max. wood cross-section for processing softwoods (with specified tine length) 100 cm² • Max. wood cross-section for processing hardwoods (with specified tine length) 80 cm² • Glue type PVAC • Species: Softwood / ...

Manufacturer: Gildemeister Type: Twin 65 with counter spindle & automation. Year of construction: 2010 Control: Siemens 840D powerline Circulation diameter above bed: 250 mm Flat travel carriage 1: 300 mm Longitudinal travel carriage 1: 650 mm Perpendicular Y-axis: ± 40 Flat travel slide 2: 180mm Longitudinal carriage 2: 650mm Rod passage max: ø 65 Drive power:40/100% 25/37 KW Speed range from – to: 20-5000 rpm Weight approx.: 10.000 kg Equipment: 2x star turret: 12x Driven tools: 12x VDI 40 2 turrets (all stations driven) Tool carrier: 12x VDI 40 2 turrets (all stations driven) Tailstock: Yes + counter spindle MK 4 Quill mounting: Yes Chip Conveyor: Yes Accessories: -Y-axis. -Coolant tank: 980l / 80 bar. -Coolant device for lower turret 8/20/80 bar. -Belt filter system -Mechanical oil mist separators 600m³ with contamination indi ...

turning diameter: max. 42 mm turning length: ca. 120 mm control: 160i-TB Fanuc Main spindle:: max. usable bar diameter: 42 mm Max. speed main spindle: 6.500 min/-1 power capacity - main spindel: 7,5 / 5,5 kW C-Axis: 0,001 ° Subspindle:: max. usable bar diameter: 42 mm Max. Speed Subspindle: 6.500 min/-1 power capacity - Sub spindle: 7,5 / 5,5 kW C-Axis: 0,001 ° slide I:: x-axis: 65 mm y-axis: 350 mm z-axis: 120 mm rapid traverse: 30 m/min Accelaration: 5/10 m/s² feed power: max. 350 daN Tool Slide I:: number of toolpositions: 10 (6+4) pos. Number of fixed tools: 6 pos. Number of driven toolspositions: 4 pos. collets: ESX 20 slide II:: x-axis: 265 mm z-axis: 320 mm rapid traverse: X: 18 / Z: 30 m/min Accelaration: 5 m/s² feed power: max. 350 daN Slide Y2:: y-axis: 326 mm rapid traverse: 30 m/min Accelaration: 5 m/s² feed power: max. 350 daN Tool Slide II:: number of toolpositi ...

GeneralIntegrated Mill Turn Center; Control: Control F31iB5 with CELOS CharacteristicsSwing- Ø, max.700 mmSpeed max.12000 rpmSlewability of B-Axis±120 degreeMovements X / Z / Y675/1562/300 (±150) mmMilling spindle upper side1 Bar diametre80 mmMax. Turning Length1530 mmSpeed max.4000 rpmMax machining diameter670 mmDrive power tool spindle5,5/3,7 kWDrive power milling spindle28/23 kWDrive power main spindle18,5/15 kWMovements X / Z200/1542 mmLower Turret10 PositionsNumber of Toolmagazine positions38 Weight approx.18500 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and p(Left Spindle) through-spindle hole dia. 91 mm, 4,000min-1 (STD)(Left Spindle) Through-spindle Hol ...

Manufacturer DOOSAN Model PUMA 700 LM Year 2005 CNC FANUC 21i TD Capacities Ø Swing over bed 1.030 mm. Ø swing over saddle 800 mm Max turning diameter 900 mm. Max turning length 3.200 mm. C Axis and Driven Tools INCLUDED Chuck size 24” Bar working diameter 164mm. Travels and feedrates X travel 470 mm. Z travel 3.235 mm. Rapid traverse rate X/ Z Axis 12/10 m/min Main spindle Max spindle speed 1500 rpm Speed ranges 2 Main spindle power 75/60 kW Main spindle torque 11.004 Nm Spidle nose A1 – 15 C Axis. Positioning Precision 0,001º Turret No of tool stations 12 Turret tool size 32 x 32 mm Max boring bar size 80 mm. Turret Indexig Time 0.25 s. Rotary tool motor power 11 kW Max rotary tool speed 3.000 rpm. Tailstock Tailstock travel 3.135 mm. Quill diameter 160 mm Quill travel 150 mm Quill bore taper #6 Equipment 3 Jaw-Hydraulic chuck Ø600 mm I ...

Key data: 700 mm

CNC lathe GILDEMEISTER CTX gamma 1250 With control control Siemens 840 D SL with Shop Turn Year of construction: 2009 Travel in X: 480 mm Travel in Z: 1300 mm Spindle bore: 102 mm Turning diameter max. 700 mm Speed range: max. 2500 rpm With the following accessories: Slide protection with interior lighting (automatic sliding hood operation) 12-speed turret with 12 driven tool stations 50 tool holders VDI 50 3 Driven Angle Heads, 2 Driven End Heads C Axis & Spindle Brake (Hydr.), Partial Hollow Clamping Device Tension Tube 104 mm 3 Jaw chuck SMW Autoblock hydraulic (0 500) Direct Displacement Measuring System (X Axis) Tailstock with quill Signal light 4 coloured DMG Netservice on board Coolant system 980 l 8/20 bar with belt filter system Conveyor Coolant spray gun Operating instructions

Manufacturer GEMINIS Model GHT-4 720 x 3000 Year 2004 CNC FAGOR 8055 TC/B Capacities and feeds Max. swing over bed 720 mm. Max. swing over cross slide 470 mm. Height of centres from flat guide 366 mm. Distance between centres 3.000 mm. C Axis and driven tools INCLUDED Fast feedrate X/Z axis 8.000 mm/min Work feedrate X/Z axis 8.000 mm/min Headstock Main spindle bore diameter 92 mm. Main spindle nose DIN-55027-11 Spindle diameter on front bearing 150 mm. Spindle speed 0-1600 Spindle automatic ranges 2 Main spindle power 17 / 20,5 kW Spindle torque 1590 / 1920 Nm Tailstock Ø Tailstock Quill 100 mm Tailstock travel 200 mm Taper Morse 6 Bed Width 430 mm. Height up to flat guide 775 mm. Turret Turret type Sauter VCI50 Ø400 mm. Driven tool position at turret 8 Driven tool power 5.5 kW Additional equipment 3 jaw auto-centering chuck SHW Autoblock 315 BH  ...

control: Siemens 840-D tool taper: HSK & VDI 40 - - -: - - - - - - Vertical Turning Machine EMAG - VTC 250 DUO DD with ITC (7-30 bar) and driven tools Additional equipment: - Workpiece grippers on all 3 turrets - 12-position disc turret for driven tools and VDI 40 tool holders, - 12-station disc turret with cross-slot and VDI 40 tool holders, - 12-station disc turret for driven tools and VDI 40 tool holders, - NC steady rest, self-centering, - headstock below, - tailstock below, - chip conveyor - Knoll unit 1.500 l, - OP10: Three-jaw chuck Rhöm KFD-N 220/3, - OP20: Hainbuch Spanntop pull-back BZI65, - Live tool for axial and radial machining, - Tool holder with Capto 5 quick change system, - Artis as tool and process monitoring, The machine is in a well-maintained condition and can be inspected at any time under power. A machine video from the production plant will be shared on reques ...

Oto mills 127mm x 5mm HF Tube Mill with Packaging Line Make: Oto Mills Year New: 2000 Tube Diameter: 38mm – 127mm Wall Thickness: 0.9mm – 5mm Speed: 100 meters per minute Direction: Right to Left Material Strength: 360 – 510 MPa Tooling: 17 sets, Round, Square, Rectangular Entry Coil Car Floor Standing V-Type Design Powered Traverse & Lift Mandrel Uncoiler Powered Expansion Powered Hold – Down Roll Sliding Base Feed-Up Motor Shear & End Welder TIG Power Supply Mechanical Shear Driven Pinch Rolls Coil Straightening Machine Horizontal Accumulator Entry & Exit Pinch Rolls Coil Feeding Unit Variable Speed Drive Forming Mill Shaft Diameter: 80mm Eight (8) Forming Stands Seven (7) Side Forming Stands Horizontal & Vertical Stand Adjustment Individual Gear Boxes Universal Drive Variable Speed DC Motor Drive 300Kw High Frequency Welder 3-Roll Adj ...

This MORI SEIKI ZL-203SMC Lathe was manufactured in the year 2002. It is equipped with 3 axis, 2 turrets (static positions and driven tools) and a spindle speed of 4000 rpm. It will be delivered with a chip conveyor belt, cooling tank, automatic workpiece unloading system, 3 axial driven tools, 2 radial driven tools, 3 boring bar holders, detachable presetting arm and a collet chuck.

angular steel - leg outwards: -- mm double T-iron on the x-axis: -- mm U-iron on the x-axis: -- mm : 50 mm : 150 mm throat: 120 mm total power requirement: 1,5 kW weight of the machine ca.: 0,36 t dimensions of the machine ca.: 1,1 x 0,8 x 1,4 m The PB 50-3 is a profile bending machine with manual adjustment of the top roller via a handwheel. The profile bending machine can be used in vertical and horizontal working position and are equipped with three driven rollers. The change between two or three driven rollers is done simply by the side handle of the machine. - Manual adjustment of the top roller with a handwheel - Vertical and horizontal work possibility - 3 driven rollers - Supplied with a standard roller set - Foot pedal The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Cut-to-length line Delta-Alcos 72”x0.5”x60,000Lb (A3770) Make: Delta / Alcos Material Width: 36" - 72" Thickness Capacity: .048" - .530" Weight Capacity: 60,000Lbs Coil ID: 16" - 24" Coil OD: 72" Yield Strength: 50,000PSI Direction: Right to Left Coil Storage Conveyor Entry Coil Car Hydraulic Lift and Traverse Cone Uncoiler DC Motorized Brake Sliding Base Wichita Cooled Brake Powered Hold-Down Roll Hydraulic Peeling Table Powered In & Out Set of Driven Pinch Rolls Delta Corrective Plate 4-Hi Leveler Number of Work Rolls: 9 Work Roll Diameter: 8" Work Roll Width: 82" Powered Up & Down Back-Up Flights DC Motor & Drive Delta Corrective 4-Hi Leveler Number of Work Rolls: 19 Work Roll Diameter: 4" Work Roll Width: 82" Motorized Back-Up Flights Powered Work Roll Adjustment DC Motor & Drive Alcos Mechanical Shear Down Cut Shear Driven Entry Pinch Rolls  ...

turning diameter: max. 320 mm turning length: 450 mm control: 32 i S Fanuc centre height: 190 mm turning diameter over bed: 320 mm turning dia. over face-slide: 260 mm Main spindle:: turning speed range - main spindle: max. 5.000 min/-1 power capacity - main spindel: 11 / 7,5 kW max. Torque: 115 / 86 Nm usable bar diameter: max. ( 52 ) mm spindle bore: 68,5 mm spindle diameter in front bearing: 100 mm C-Axis: 360 x 0,01 ° axis stroke:: travel -x axis: 160 mm travel -z axis: 450 mm turret:: number of toolpositions: 12 pos. tool taper: VDI 30 Shank diameter: 20 x 20 mm Number of driven toolspositions: 6 pos. max. speed driven tool stations: 5.000 min/-1 power capacity - driven tool-stations: 3,7 kW Tailstock:: tailstock adjustment: 400 mm intake pressure max.: 4.000 N feeds:: rapid traverse: X: 20 / Z: 30 m/min Feed force ( X / Z ): 4,5 kN total power requirement: 24 kVA weight of th ...

For sale: Multi-axis CNC lathe from Hyundai-Wia type LM 1600TTSY + LNS 3-meter bar magazine type Alpha 552. Beautiful versatile CNC lathe with lower and upper turret with 12 positions and intermediate positions each. The upper turret is additionally equipped with a Y-axis with a displacement of 100 mm (+50, - 50 mm). The machine is equipped with two identical spindles with a bar passage of 51 mm and a maximum speed of 6,000 rpm. The maximum turning diameter is 230 mm and the maximum turning length is 705 mm. Driven tool holders can be stored in all positions! The maximum speed on the driven tool is 5,000 rpm. The main motor power on both spindles is 15/11 kW and they are built-in spindle motors! The machine is also equipped with an automatic tool presetting device, a workpiece collecting device, a workpiece extractor for the right spindle, a workpiece discharge conveyor for the finished  ...

Number of sanding units: 2 st. sanding width: 190 mm Sanding height max.: 4-150 mm Hess Junior single wood sander --------------------------------- basic structure: Stable, heavy welded construction made of thick-walled rectangular hollow profiles with additional, statically calculated bracing for optimal vibration damping. Staggered grinding units with large dimensioned Belt drive drums for slip-free belt travel. Two-point suction for direct and airborne dust extraction with integrated blow-off device. grinding units in heavy steel plate construction as the basis for vibration-damped, quiet belt run. All guides as a ball linear set on hardened and polished waves. Lasting precision thanks to protection against dust and dirt of the sphere linear sets. Contact roller and sanding pad in a balanced ratio to the grinding belt grain load. The large dimensioned drive drums guarantee the full tr ...

DMG Gildemeister CTX 320 Linear V6 CNC lathe with Y-axis, driven tools and second spindle CNC control Siemens 840D Powerline Turning diameter 240 mm Spindle bore diameter 51 mm Spindle speed 6000 rpm Spindle motor 20/16 kW X-axis travel 141 mm Y-axis travel: 32 mm Z-axis travel 450 mm W-axis travel 380 mm Minimum indexing of the main spindle of the C-axis 0.001° minimum indexing of the C-axis auxiliary spindle 0.001° Number of tools on turret 12 Number of driven tools 12 Spindle speed driven tools 5000 rpm Tool holder DIN 69880-30 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail.

Roller conveyor, roller conveyor, driven roller conveyor, roller conveyor -Pneumatically driven with centering unit -stable execution -electrically powered -Drive motor: 0.18 kW 76 rpm - Conveyor speed: 25.05 m/min -Roll width: 1000 mm -Conveyor length: 1400 mm -Diameter roller: 105 mm -Rollers: rubberized -Diameter shaft: 25 mm -Conveyor height: 960 mm adjustable -driven: via belt -Number: 3x roller conveyors available -Price per piece -Dimensions: 1400/1150/H960 mm -Weight: about 230 kg

turning diameter: 210 mm turning length: 580 mm control: 840 D Siemens centre height: 190 mm turning diameter over bed: 330 mm turning dia. over face-slide: 260 mm Main spindle:: turning speed range - main spindle: max. 4.000 min/-1 power capacity - main spindel: 10 / 7,5 kW max. Torque: 115 / 86 Nm spindle bore: 68,5 mm max. usable bar diameter: 51 mm C - Axis: 0,001 ° axis stroke:: travel -x axis: 185 mm travel -z axis: 455 mm turret:: number of toolpositions: 12 pos. tool taper: VDI 30 Driven Tool Stations:: 6 pos. Tailstock:: tailstock adjustment: 400 mm intake pressure max.: 4.000 N feeds:: rapid traverse: X: 20 / Z: 30 m/min Feed force ( X / Y / Z ): 4,5 kN total power requirement: 21 kW weight of the machine ca.: 3,2 t dimensions of the machine ca.: 8,0 x 2,2 x 2,0 m Documents: Chip conveyor: Coolantsystem: Tailstock: parts catcher: C-axis: driven tool stations: Signa ...

Key data: 210 mm, 400 mm

Okuma LT 2000 EX 2T 2M 2Y Big Bore Steuerung/ Control : OSP P 200 L , kein IGF One Touch Advance Year of manufacture / YOM : 09/ 2011 Power On : approx. 13000 [h] Spindle running time : [h] : Location: Availability /: from stock Sweden Condition / technical condition : 9 / 10 TECHNISCHE DATEN / TECHNICAL DATA: Max. turning length / max turning length : [mm] 700 Hauptspindel / Main Spindle Turning dia : [mm] 210 Max. turning dia over bed : [mm] 400 max. RPM/ spindle speed : [1/min.] 6000 Spindle bore / spindle bore : [mm] full clamping cylinder Drive power / spindle power : [kW] 22/15 max. rotation speed 6000 rpm Travel XA / XB axis : 205 mm Travel ZA / ZB axis : 700 mm Travel W axis : 730 mm Travel YA / axis : 95 mm Travel YB / axle : 95 mm C-axis : 2 x 0.001 degrees/degree Counter spindle / subspindle max. speed/ spindle speed : [1/min.] 6000 S ...

GeneralTwo spindle Swiss turning automatic lathe; Control: Fanuc 310is Working areaBar diameter max.42 mmChanging kit from steady to sliding headstockChanging kit from steady to sliding headstock including application bush type Dunner B236 and bush-spindle syncronismDrive for support for back workingDrive for support for back working operation (slide 2) power 0.55 KWDouble tool h. for ext.machining on rev.Double tool holder for external machining on revolver for shaft 16x16Double drill hold. on rev.cyl.junct.d.25Double drill holder on revolver with cyl. junction diam.25mmRad.driven mill.-drill.unit on rev.Radial driven milling and drilling unit on revolver with junction for collet ESX/ER 20 ratio 1:1 speed max. 5000 rpmDouble axial driver drill.-mill.-unit on rev.Double axial driven drilling and milling unit on revolver with cyl. junction for collet ESX/ER 20 ratio 1:1 speed max. 5000 r ...

GeneralCNC Swiss type lathe with Fanuc control; Control: FANUC 310 iTB Working areaTurning diameter33 mmDrive for support for back workingDrive for support for back working operation (slide 2) power 0.55/1.1 KWRad.driven mill.-drill.unit on rev.Radial driven milling and drilling unit on revolver with junction for collet ESX/ER 20 ratio 1:1 speed max. 5000 rpmDouble tool h. for ext.machining on rev.Double tool holder for external machining on revolver for shaft 16x16Double axial driver drill.-mill.-unit on rev.Double axial driven drilling and milling unit on revolver with cyl. junction for collet ESX/ER 20 ratio 1:1 speed max. 5000 rpmSpecial equipmentHinged belt chip conveyor with Discharge height 1200 mm Self-regulating guide bush Double cone Double turret drill holder with cyl. holder 25 mm Surcharge for cooling system 600 l Pump 8 and 20 bar, paper belt filter Bushing double cone 0_18 ...

GeneralTwo spindle Swiss turning automatic lathe; Control: Fanuc 310is Working areaBar diameter max.42 mmChanging kit from steady to sliding headstockChanging kit from steady to sliding headstock including application bush type Dunner B236 and bush-spindle syncronismDrive for support for back workingDrive for support for back working operation (slide 2) power 0.55 KWAxial drilling unit for back work.oper.Axial drilling unit for support for back working operation (slide 2) with 2 rot.spindles, junction for collet ESX/ER 20 and 2 cyl.junction diam.25mmDouble tool h. for ext.machining on rev.Double tool holder for external machining on revolver for shaft 16x16Double drill hold. on rev.cyl.junct.d.25Double drill holder on revolver with cyl. junction diam.25mmRad.driven mill.-drill.unit on rev.Radial driven milling and drilling unit on revolver with junction for collet ESX/ER 20 ratio 1:1 sp ...

STAR SV-38R CNC turning centre built in 2015 in Japan, stands out for its unparalleled flexibility and broad functionality, which makes the machine ideal for complex applications in many industries t.e. automotive or aerospace. With the help of two spindles (main spindle and sub-spindle) with C-axis, the STAR SV 38R CNC lathe performs precision machining of inclined surfaces, including front and back angle holes in up to 11 axes. Both spindles of the machine are driven by reliable, high-power motors, which is used for the versatile use of cutting tools taken from the tool holder or the 10-position turret tool head. A special system for guiding the end of the Z-axis spindle through the headstock also guarantees high rigidity and stability at the cutting point. The STAR SV38R lathe is offered with an extensive range of equipment, including an FMB turbo 5-55 / 3200 A bar feeder, workpie ...

turning diameter: 410 mm turning length: 800 mm greates pass round over bed: 700 mm control: Heidenhain ERGOline spindle passage: 0 mm spindle speed:: 25- 5000 U/min spindle motor: 25 kW max. torque on the spindle: 280 Nm no. of tools in turret 1: 12 VDI 40 driven stations: 12 VDI 40 speed of driven tools: 4000 U/min drive milling spindle: 5,6/ 11,3 kW y-axis: +/- 60 mm sup spindle: 15 kW Spindlespeed subspindle: 20- 6000 U/min rapid traverse: 30/22,5/30 m/min tail stock: Gegenspindle/Subspindle range L-W-H: 4,7 x 2,7 x 2,0 mm weight of the machine ca.: 6,5 t CNC lathe with driven tools, Y- axis and sub spindle - 3 jaw chuck SMW 315 BH main spindle - 3 jaw chuck SMW 250 BH sub spindle - chipconveyor - oil mist collector LTA - automatic door - coolant pistol The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
