drawing used for sale

pressure:63 t throat:325 mm stroke:560 mm distance table/ram, max. stroke up, adjustment up:700 mm table surface area:640 x 640 mm pressure of drawing cushion in table:25 t stroke of drawing cushion in table:200 mm die cushion area:450 x 450 mm table height over floor:800 mm ram surface:560 x 560 mm oil volume:450 l power requirement:15,0 kW weight:7,0 t dimensions (WxDxH):1,2 x 2,0 x 3,1 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic

pressure:100 t throat:320 mm stroke:160 mm distance table/ram, max. stroke up, adjustment up:480 mm table surface area:630 x 550 mm hole in the table:200 mm table height over floor:860 mm ram surface:560 x 450 mm oil volume:500 l power requirement:30,5 kW weight:6,4 t dimensions (WxDxH):1,6 x 2,0 x 2,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact cushioning:hydraulic depth stop:mechanical

pressure:500 t distance between columns:1220 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1600 x 1200 mm pressure of drawing cushion in table:320 t stroke of drawing cushion in table:150 mm drawing cushion surface in table:750 x 625 mm pressure of drawing cushion in ram:180 t stroke of drawing cushion in ram:100 mm drawing cushion area in ram:750 x 625 mm ram surface:1600 x 1200 mm table height over floor:800 mm speed down:665 mm/s speed up:530 mm/s working speed:34 - 100 mm/s quantity of oil:2000 l power requirement:180,0 kW weight:40,0 t Dimensions (WxDxH):3,2 x 2,4 x 7,5 m Depth of foundation pit:4,1 m Height above floor:5,55 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:63 t throat:280 mm stroke:160 mm Distance table/ram, max. stroke up, adjustment up:360 mm table surface area:560 x 490 mm hole in the table:125 mm table height above floor:860 mm ram surface:280 x 280 mm power requirement:22,0 kW weight:3,6 t dimensions (W x D x H):0,8 x 1,7 x 2,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:315 t distance between columns:1750 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:1200 mm table surface area:1600 x 1500 mm pressure of drawing cushion in table:125 t stroke of drawing cushion in table:200 mm die cushion area:1200 x 1400 mm table height over floor:750 mm ram surface:1640 x 1500 mm power requirement:55,0 + 11,0 kW weight:29,5 t dimensions (WxDxH):3,2 x 4,5 x 5,8 m Height above floor:5,1 m German Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 drawing cushion in table:hydraulisch cutting impact absorption:hydraulic

Pressure:63 t distance between columns:1000 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:850 mm table surface area:980 x 500 mm table height above floor:850 mm ram surface:130 mm speed down:400 mm/s speed up:461 mm/s working speed:14 - 97 mm/s power requirement:15,0 kW Weight:5,0 t Dimensions (WxDxH):2,0 x 1,6 x 3,9 m depth stop:mechanical foundation pit:not necessary

Pressure:160 t distance between columns:1250 mm stroke:500 mm distance table/ram, max. stroke up, adjustment up:700 mm Table area:1200 x 800 mm table height over floor:850 mm die cushion pressure in table:63 ? t die cushion stroke in table:200 mm die cushion area:780 x 650 mm side window:300 mm ram surface:1000 x 800 mm speed down:400 mm/s speed up:400 mm/s working speed:106 mm/s oil volume:1800 l power capacity:2 x 30,0 kW weight:16,7 t Dimensions (WxDxH):2,45 x 2,35 x 4,5 m

pressure:100 t distance between columns:770 mm stroke:400 mm distance table/ram, stroke up:800 mm Table area:770 x 900 mm table height above floor:850 mm die cushion pressure in table:40 t die cushion stroke in table:200 mm die cushion area in table:600 x 600 mm side window:600 mm ram surface:770 x 900 mm speed down:62 mm/s speed up:350 mm/s working speed:17,5 mm/s oil volume:700 l power requirement:42,0 kW weight:9,0 t Dimensions (WxDxH):2,6x 2,0 x 3,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic

pressure:315 t distance between columns:1800 mm stroke:400 mm Distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1800 x 1000 mm table height over floor:900 mm die cushion pressure in table:80 t die cushion stroke in table:100 mm Die cushion area in table:1300 x 600 mm side window:600 mm ram surface:1800 x 1000 mm speed down:400 mm/s speed up:300 mm/s working speed:15 - 80 mm/s oil volume:1700 l power requirement:55,0 kW weight:27,5 t dimensions (WxDxH):3,1 x 2,2 x 4,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 die cushion in table:hydraulic foundation pit:not necessary

pressure:320 t distance between columns:1530/1370 mm stroke:320 mm distance table/ram, stroke up:830 mm table surface area:1500 x 650 mm die cushion pressure in table:12,5 t table height over floor:1100 mm side window:570 mm ram surface:1240 x 650 mm capacity of ejector in table:12,5 t speed down:450 mm/s speed up:440 mm/s working speed:63,6 mm/s oil volume:2100 l power requirement:2 x 45,0 kW weight:27,0 t dimensions (WxDxH):4,0 x 2,3 x 4,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic drawing cushion in ram:hydraulic ram interlocking:hydraulic Option: NEW electrical controls:Siemens S7-1500 F

pressure:160 t distance between columns:1580/1360 mm stroke:320 mm distance table/ram, max. stroke up, adjustment up:830 mm table surface area:1460 x 850 mm table height over floor:1100 mm side window:870 mm ram surface:1400 x 850 mm speed down:540 mm/s speed up:520 mm/s working speed:26 - 85 mm/s oil volume:2100 l power requirement:45,0 kW weight:22,6 t dimensions (WxDxH):4,0 x 2,3 x 4,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:hydraulisch

pressure:160 t distance between columns:1600/1420 mm stroke:345 mm distance table/ram, max. stroke up, adjustment up:830 mm table surface area:1460 x 850 mm table height over floor:1100 mm side window:770 mm ram surface:1410 x 850 mm speed down:540 mm/s speed up:520 mm/s working speed:26 - 85 mm/s oil volume:2100 l power requirement:45,0 kW weight:23,0 t dimensions (WxDxH):4,0 x 2,3 x 4,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:hydraulisch

pressure:100 t throat:360 mm stroke:500 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:900 x 560 mm table height over floor:710 mm ram surface:630 x 400 mm speed down:200 mm/s speed up:200 mm/s power requirement:17,0 kW weight:5,0 t Dimensions (WxDxH):1,2 x 1,9 x 3,3 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:620 t distance between columns:2250 mm stroke:1250 mm Distance table/ram, max. stroke up, adjustment up:1600 mm table surface area:2200 x 1280 mm ram surface:2200 x 1500 mm table height over floor:800 / 1000 mm column travel -side:750 mm feed down:10 - 250 mm/sec feed up:10 - 500 mm/sec working feed:1 - 24 mm/sec oil volume:2000 l power capacity:45,0 + kW weight:42,0 t Dimensions (WxDxH):3,7 x 2,6 x 6,8 m German Safety: permitted for manual loading:CE-sign foundation pit:not necessary

pressure:120 t distance between columns:430 mm stroke:125 mm distance table/ram, stroke up:400 mm table surface area:430 x 450 mm table height over floor:860 mm side window:230 mm ram surface:250 mm working speed:10 mm/s power requirement:11,0 kW weight:2,5 t dimensions (WxDxH):1,6 x 1,3 x 2,4 m German Safety: permitted for manual loading:CE-sign

pressure:500 t distance between columns:1910 mm stroke:500 mm Distance table/ram, max. stroke up, adjustment up:700 mm table surfache without cutting impact cushions:1910 x 1360 mm table surfache with cutting impact cushions:1600 x 1360 mm table height over floor:800 mm ram surface:1600 x 1270 mm Side window:600 mm speed down:400 mm/s speed up:330 mm/s working speed:10 - 28 mm/s oil volume:1200 l power requirement:60,0 kW weight:40,0 t Dimensions (WxDxH):3,6 x 2,5 x 5,0 m height over floor:4,5 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 cutting impact cushioning:hydraulic ram interlocking:hydraulic

pressure:200 t distance between columns:1400 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:1300 x 1100 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:150 mm die cushion area:700 x 700 mm capacity of ejector in ram:10 t ejector stroke in ram:50 mm table height over floor:930 mm side window:770 mm ram surface:1300 x 1100 mm speed down:400 mm/s speed up:410 mm/s working speed:20 - 50 mm/s return capacity:30 t oil volume:1350 l power requirement:70,0 kW weight:23,0 t dimensions (WxDxH):4,5 x 3,0 x 3,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic ejector in ram:hydraulic foundation pit:not necessary

Pressure:1000 t distance between columns:4100 mm stroke:1200 mm Distance table/ram, stroke up:2100 mm Table surface area:4000 x 2200 mm pressure of drawing cushion in table:360 t Die cushion stroke in table:300 mm Die cushion area in table:3500 x 1600 mm Die cushion pressure in ram:100 t Die cushion stroke in ram:160 mm Die cushion area in ram:3250 x 1600 mm Ram surface:4000 x 2200 mm Side window:1300 mm Oil volume:8000 l Power capacity:300,0 kW Dimensions (WxDxH):5,75 x 4,3 x 9,55 m Height above floor:7,7 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact cushioning:hydraulic

Pressure:1600 t distance between columns:4100 mm slide stroke:1450 mm Distance table/ram, stroke up:2750 mm distance table/blank holder, stroke up:2200 Table surface area:4000 x 2200 mm ram pressure:1000 t Pressure of blank holder:600 t stroke of blankholder:1000 mm blank holder surface:4050 x 2200 mm Ram surface:3200 x 1650 mm pressure of drawing cushion in table:360 t Die cushion stroke in table:300 mm die cushion area:3500 x 1600 mm Side window:1100 mm Oil volume:9000 l Power capacity:390,0 kW Weight:250,0 t Dimensions (WxDxH):5,95 x 4,3 x 10,5 m Height above floor:8,6 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable

Pressure:800 t distance between columns:3250 mm stroke:1100 mm Distance table/ram, stroke up:1900 mm Table surface area:3100 x 1900 mm pressure of drawing cushion in table:300 t Die cushion stroke in table:300 mm Die cushion area in table:2500 x 1800 mm Die cushion pressure in ram:80 t Die cushion stroke in ram:200 mm Die cushion area in ram:2200 x 1000 mm Ram surface:3100 x 1900 mm Side window:900 mm Oil volume:4700 l Power capacity:200,0 kW Dimensions (WxDxH):4,95 x 3,3 x 10,2 m Height above floor:7,05 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact absorption:hydraulic

Pressure:800 t distance between columns:2560 mm stroke:1050 mm Distance table/ram, stroke up:1870 mm Table surface area:2500 x 1730 mm pressure of drawing cushion in table:300 t Die cushion stroke in table:395 mm Die cushion area in table:2300 x 1300 mm Ram surface:2500 x 1730 mm Die cushion pressure in ram:63 t Die cushion stroke in ram:150 mm Side window:1000 mm Oil volume:4300 l Power capacity:200,0 kW Dimensions (WxDxH):4,1 x 2,8 x 10,0 m Height above floor:7,0 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable

Pressure:600 t distance between columns:2600 mm stroke:900 mm Distance table/ram, max. stroke up, adjustment up:1600 mm Table surface area:2500 x 1730 mm pressure of drawing cushion in table:250 t Die cushion stroke in table:400 mm Die cushion area in table:2300 x 1300 mm Die cushion pressure in ram:63 t Die cushion stroke in ram:160 mm Die cushion area in ram:1900 x 1300 mm Ram surface:2500 x 1730 mm Side window:1100 mm Oil volume:3500 l Power capacity:200,0 kW Dimensions (WxDxH):4,1 x 2,8 x 9,6 m Height above floor:6,4 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact absorption:hydraulic

Pressure:800 t distance between columns:3550 mm stroke:1100 mm Distance table/ram, max. stroke up, adjustment up:1900 mm Table surface area:3500 x 1800 mm pressure of drawing cushion in table:350 t Die cushion stroke in table:280 mm Die cushion pressure in ram:80 t Die cushion stroke in ram:160 mm Ram surface:3500 x 1800 mm Side window:1900 mm Weight:100,0 t Floor Space (WxD):5,3 x 4,3 m Height above floor:7,3 m Height below floor:5,0 - 6,0 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact cushioning:hydraulic sliding table:without rails for moving table

pressure:60 t throat:400 mm stroke:600 mm Distance table/ram, stroke up:700 mm Table surface area:1120 x 700 mm table height over floor:850 mm Ram surface:700 x 700 mm Oil volume:275 l Power capacity:7,5 kW Weight:7,3 t Dimensions (WxDxH):1,6 x 2,0 x 3,7 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20

pressure:63 t throat:270 mm stroke:160 mm Distance table/ram, max. stroke up, adjustment up:360 mm table surface area:560 x 490 mm hole in the table:280 x 190 mm table height above floor:850 mm ram surface:450 x 360 mm oil volume:360 l power requirement:23,0 kW weight:4,6 t dimensions (W x D x H):1,2 x 1,8 x 2,9 m

pressure:40 t throat:285 mm stroke:500 mm Distance table/ram, stroke up:630 mm table surface area:560 x 560 mm pressure of drawing cushion in table:16 t stroke of drawing cushion in table:200 mm die cushion area:425 x 425 mm table height over floor:800 mm ram surface:450 x 450 mm power requirement:11,0 kW weight:4,0 t dimensions (WxDxH):1,15 x 1,8 x 2,85 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 light guard:Sick

pressure:160 t distance between columns:1360 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1300 x 900 mm table height over floor:950 mm side window:640 mm ram surface:1300 x 900 mm power requirement:45,0 kW weight:16,0 t Dimensions (WxDxH):2,5 x 2,1 x 4,1 m cutting impact cushioning:hydraulic

pressure:315 t distance between columns:1290 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:950 mm table surface area:1250 x 1100 mm pressure of drawing cushion in table:125 t stroke of drawing cushion in table:300 mm die cushion area:900 x 900 mm Capacity of ejector in ram:20 t Stroke of ejector in ram:250 mm table height over floor:800 mm ram surface:1250 x 1100 mm oil volume:1200 l power requirement:40,0 kW weight:22,0 t dimensions (WxDxH):2,6 x 1,6 x 5,2 m height over floor:4,05 m drawing cushion in table:hydraulic ejector in ram:hydraulic cutting impact cushioning:hydraulic

Pressure:40 t throat:330 mm stroke:250 mm distance table/ram, max. stroke up, adjustment up:450 mm table surface area:800 x 500 mm hole in the table:100 mm table height over floor:900 mm ram surface:100 mm Speed down:406 mm/s Speed up:393 mm/s Working speed:14 mm/s oil volume:350 l power requirement:7,5 kW weight:4,6 t dimensions (WxDxH):1,3 x 2,3 x 3,4 m German Safety: permitted for manual loading:CE-sign depth stop:mechanical

pressure:40 t throat:300 mm stroke:630 mm Distance table/ram, stroke up:900 mm Table surface area:620 x 520 mm Hole in the table:150 mm table height over floor:600 mm Ram surface:150 mm Power capacity:15,0 kW Weight:4,5 t Dimensions (WxDxH):1,0 x 1,9 x 3,0 m German Safety: permitted for manual loading:CE-sign

pressure:315 t distance between columns:2350 mm distance table/ram, max. stroke up, adjustment up:1200 mm distance between cutting impact cushioning:1600 mm Distance table/ram, stroke up:1200 mm stroke:800 mm table surface area:2060 x 1260 mm table height over floor:750 mm Die cushion pressure in table:100 t Die cushion stroke in table:400 mm die cushion area:1250 x 1000 mm side window:780 mm ram surface:2200 x 1500 mm Capacity of ejector in ram:63 t speed down:500 mm/s speed up:310 / 410 mm/s working speed:20 - 73 mm/s quantity of oil:3900 l power requirement:80,0 + 45,0 kW weight:55,0 t Dimensions (WxDxH):4,6 x 2,7 x 7,2 m Height above floor:6,0 m Height below floor:1,2 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 die cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:hydraulic cutting impact absorption:hydraulic

pressure:160 t throat:450 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:580 mm table surface area:1000 x 1000 mm die cushion capacity:20 t die cushion stroke:300 mm ram surface:700 x 750 mm feed down:400 mm/s feed up:400 mm/s table height over floor:1350 mm die cushion area:Ø 350 mm power capacity:55 + 11 kW weight:19,5 t Dimensions (WxDxH):1,5 x 3,5 x 4,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulisch depth stop:mechanisch
