dowel drilling used for sale

Paper drilling machine Nagel Citoborma 280 AB

I sell a Top Dubel drill multi-spindle drill Detel M-13, built in 2007. 3-spindle See good condition. Available the same.

Multi-stand drill Prior sale reserved - errors possible Internal Reference Number: D-1143-1

WMW BK 50 AI Admission in drilling-spindle (morse): Mk5 Max drill capacity: 50 mm Table dimensions: 490 x 530 mm SPEEDS: 45 > 1000 rpm Max drilling depth: 280 mm Motorpower: 7 kW Length: 1200 mm Depth : 770 mm Height: 2700 mm Weight: 1,7 ton

bore capacity in steel (diameter):1-13 mm The machine has a 2.2 kW spindle motor with a 2-stage gearbox for drilling and tapping. Table size is 100 x 50 cm Stroke length approx. 200 mm

bore stroke:170 mm total power requirement:3,5 kW dimensions of the machine ca.:0,75 x 1,10 m bore spindle turning speed range:30-3000 U/min bore range:diameter:4-60 mm

High precision drilling and milling machine Aciera 22 VA Good condition from school operations Year of construction approx. 1990 Table 600 x 320 mm Speed 40 - 3600 rpm Speed setting rpm 4 automatic feeds 40-280 80-560 275-1800 550-3600 Spindle diameter 65 mm Drilling spindle stroke 120 mm Spindle holder: Aciera quick-change system Automatic thread cutting Drilling capacity in solid material 25mm Max drilling capacity up to 30mm Height adjustment via hand crank Motor: 1.1 KW Lamp Some quick-change shots Dimension WxDxH 90 x 130 x 185 cm Weight approx. 800 kg Technical information subject to reservation

total power requirement:2.2 kW bore spindle turning speed range:70-4000 in 4 stufen U/min

bore capacity in steel (diameter):50-60 mm arm length:1.600 mm weight of the machine ca.:5-7 t spindle taper MT:wahrscheinlich MK5

bore capacity in steel (diameter):40 mm arm length:1250 mm workpiece height max.:1390 mm spindle taper: MT:5 table surface area:750 x 1380 mm surface area:1450 x 920 mm total power requirement:5 kW weight of the machine ca.:3000 kg dimensions of the machine ca.:2060× 930 × 2760 mm

bore capacity in steel (diameter):40 mm arm length:1250 mm workpiece height max.:1390 mm spindle taper: MT:5 table surface area:750 x 1380 mm surface area:1450 x 920 mm total power requirement:5 kW weight of the machine ca.:3000 kg dimensions of the machine ca.:2060× 930 × 2760 mm

- Infinitely variable speed control - Quickly adjustable drilling depth stop - Thread cutting device - Undervoltage triggers - Table height adjustment via rack - LED lighting in the head - Continuous/normal drilling capacity R1: 23/25 mm - Thread cutting performance (depending on slope) R1: max.M 16x1 - Spindle MK II - Drilling depth 100 mm - Projection 260 mm - Column diameter 110 mm - Usable table surface (W x L) 420 x 340 mm - T-slot size (arm): number 2, distance 125 mm - Speed display digital - Drilling depth display digital - Drill depth stop quickly adjustable - Feed by hand - Motor three-phase current 400 V - Spindle speeds infinitely variable R1 with 20-2,000 1/min Option: Coolant device: € 525,- FACTORY WARRANTY: 3 years DELIVERY: free domicile incl. packaging NOT THE RIGHT MACHINE? WE ALSO CARRY OTHER FLOTT PRODUCTS - ASK FOR A QUOTE! FAS ...

Kramatorsk Model KJ1910 serial number 1913 Swing Over Bed: 1600mm Maximum Workpiece Length: 6300mm Maximum Drilling Diameter: 991mm Spindle power: 125.00kW Spindle Speed: 1 - 320 RPM Infinitely Variable power Existing Additional Chuck workholding range: 200 - 1250mm diameter, workpiece weight capacity using two open roll supports: 60,000kg, size range in closed backrest: 200 - 800mm, size range in open backrest: 630 - 1380mm, pressure head speed range: .125 - 500 infinitely variable, pressure head spindle bore diameter: 182 mm, pressure head motor power: 75kW DC, headstock speed ranges: 3, pressure head speed ranges: 2 Machine Length: 22950mm Machine Width: 4375mm Machine height: 2670mm Weight: 101091kg Condition Good

Boring power:10 mm weight:590 kg connected load:2 kW dimensions::1500 x 1300 x 2300 mm

bore capacity in steel (diameter): 35 mm throat: 230 mm bore stroke: 125 mm spindle taper: ISO 40 spindle turning speed range: 115 - 1750 U/min : 560 mm : 175 mm table surface area: 1000 x 240 mm max. distance between table and spindle-nose: 375 mm connected load frequency: 400 V total power requirement: 0,85/1,5 kW weight of the machine ca.: 0,95 t dimensions of the machine ca.: 1,3 x 1,2 x 2,1 m Domestic equipments: automatic feed and handwheel. Drill chuck with MK4 holder Digital depth display Left / right switch. Emergency stop switch Pivot head swiveling Spindle protection. Small toolbox Machine base and X-axis feed optional. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Standard equipment - Thread cutting device - Control panel with OLED display - robust, high-quality drill head hood - LED lighting - quickly adjustable and ergonomic drilling depth stop - infinitely variable speed control via rotary knob - thermal overload protection - Spindle stop - Drilling protection with electr. Hedge - Connection cable with CEE plug - mechanical feed of the Z-axis - incl. electromagnetic coupling for 3 feed speeds - Drill cross with push button - in thread cutting mode: right-left SPECIFICATIONS Continuous/normal drilling performance (mm) R1 - 27/32 (in E335/ST60) (100) R2 - 25/30 (in E335/ST60) (70) R3 - 30/35 (in E335/ST60) (200) Thread cutting capacity max.: R1= M24x3, R2= M20x2.5, R3= M30x3.5 Spindle MK III Drilling depth: 125 mm Projection: 300 mm Column diameter: 125 mm Usable table surface (W x D): 590 x 450 mm Speed display digit ...

2 Head Paper Drilling Machine

I sell a drill with cutting units COMEC FM0V8 2000, built in 1997. Working width max. 2000mm Configuration: 0 motors from below 1+1 motors from sides / angular adjustable 2 motors from behind / head angular adjustable 3 motors from above / head angular adjustable 4 pieces of material prints from above 2 cut saws from above / head angular adjustable Atypical 5-spindle drill heads Including 3 x 15mm / 2 x 25mm. Dubel heads in the price. Very good addition. Available the same.

bore capacity in steel (diameter):10 mm throat:210 mm bore stroke:100 mm total power requirement:0,7 kW weight of the machine ca.:302 kg dimensions of the machine ca.: 620 x 800 x 1950 mm Table dimensions:350 x 250 mm spindle speeds::250, 355, 710, 1000, 1400, 2000, 2500 U/min

bore capacity in steel (diameter):50 mm total power requirement:7,8 kW weight of the machine ca.:1720 kg dimensions of the machine ca.:1200 x 770 x 2700 mm number of spindle speeds:45 - 1000 mm surface area:630 x 500 mm

3-spindle deep hole drill -without electrics- Year of construction 1998 / rebuilding 2014

checked & cleaned double head standing model - foot pedal operated heavy duty construction adjustable side rulers several paper drills drilling chuck drill diameter 3 - 20 mm hole distance min 55mm / max 430mm required tools 380 Volt / 0,55 kW / 1,7 A

bore capacity in steel (diameter):50 mm total power requirement:7,8 kW weight of the machine ca.:1720 kg dimensions of the machine ca.:1200 x 770 x 2700 mm number of spindle speeds:45 - 1000 mm surface area:630 x 500 mm

throat:640 mm total power requirement:1,6 kW weight of the machine ca.:450 kg dimensions of the machine ca.:1000 x 600 x 2100 m table-size:455 x 380 mm chuck::MK 3 working area:355 x 280 mm

bore capacity in steel (diameter):55 mm arm length:1600 mm total power requirement:4 kW weight of the machine ca.:5,5 t dimensions of the machine ca.:2800 x 980 x 3000 mm

Single head Floor model with foot pedal heavy design adjustable side stops Several paper drills Drill holder 380 volts / 0.55 kW / 1.7 A

Double head Standing model with hand lever adjustable side stops Several paper drills fixed hole spacing standard 80 mm

arm length:1600 mm weight of the machine ca.:5,5 t dimensions of the machine ca.:2800 x 980 x 3000 mm

Radial drilling machine used for drilling and milling Manufacturer: COLLET & ENGELHARD GmbH Type: BUV 1600 Year of construction: 1976 horizontally and vertically swivelling head Drilling capacity: 50 mm Travel arm: approx. 800 mm max column travel: 1000 mm Speed: 14 to 710 rpm Spindle stroke approx. 300 mm 380 V Dimensions: approx. 2600 x 1300 x 3000 mm Changes and errors in the technical data, information and prices as well as prior sale reserved.

Iberdrill Gear Column Drill Series T, TL25 drilling capacity for steel (ST 60) at continuous power S1: D25mm drilling capacity for grey cast iron (GG 20) with continuous power S1: D30mm thread cutting capacity for steel (ST 60) with continuous power S1: M 18 thread cutting capacity for grey cast iron (GG 20) with continuous power S1: M 22 Tool holder in the spindle: MK 3 spindle stroke (drilling depth): 120 mm Motor power spindle: 0.82/1.2 kW Drive: 8-speed gearbox with pole-shiftable motor Speed adjustment: manual Speed range for 50 Hz motor, n=1,500/3,000 rpm, pole switchable 65 -125 -185 - 365 - 540 - 1,055 - 1,560 - 3,060 rpm Feed: 300 mm x 270 mm Column diameter: 100 mm Distance spindle center / column (projection) 250 mm Machine weight (net) 250kg Gross weight 310kg Dimensions transport packaging (LxWxH) 2.14m x 0.6m x 0.8m Gearbox ...

bore diameter: 50 mm throat: 3000 mm workpiece height: max. 200 mm total power requirement: 75 kW weight of the machine ca.: 27 t dimensions of the machine ca.: m Brand: CMA Type: GRD50 CNZ 13030 Year of make: 2010 Capacity: 50 mm X: 3.000 mm Y: 13.000 mm Z: 400 mm Spindle taper: N: 3.000 Power : 75 kW Speed: 3.000 RPM Machine weight: 27.000 kg Tap capacity: M30 Drilling depth: 150-200 mm Bed: 13,000 x 3,000 mm Max. workpiece weight: 1,500 kg /m2 Tool changer: 12 pieces External spindle cooling Chip conveyor Can be seen working at a external location The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Specifications Model: 25 lpv Tool holder: MK3 Pinole stroke: 110mm Projection: 400mm Drive: 3 phase motor with 2 motor stages and V-belt drive Speeds 14 / 35 – 65 – 70 – 125 – 130 – 200 – 250 – 335 – 400 – 570 - 670 – 1140 – 990 – 1980 rpm Table dimensions: LxW 330x330mm Machine dimensions: LxWxH 410x700x1830mm On the machine, we installed a new motor and renewed the entire electrical system with the step and motor circuit breaker as well as the cables.

- Thread cutting device - Control panel with OLED display - LED lighting - Quickly adjustable and ergonomic drilling depth stop - Infinitely variable speed control via central rotary knob - Thermal overload protection - Spindle stop - Drilling protection with electr. Hedge - Connection cable with Schuko plug SPECIFICATIONS - Spindle: B16 - Drilling depth: 60 mm - Projection: 220 mm - Column Ø: 70 mm - Spindle/work surface: 140 – 315 mm - Drill head height adjustment: by hand - Speed display: Digital - Drilling depth display: Digital - Feed (mm/revolution): by hand - Spindle speeds infinitely variable: 60 – 6,000 1/min - Continuous/normal drilling capacity: 10/12 mm - Thread cutting performance (depending on slope): M6 - FACTORY WARRANTY: 3 years (single shift) - OPTION Drilling package (No. 296570) Machine vice Flott [felix] 80 and quick-release drill c ...

Standard equipment: robust, high-quality and inclined rotary hood for easy reading of the speed LED lighting quickly adjustable and ergonomic drilling depth stop infinitely variable speed control Connection cable with SCHUCO plug (1.2 m) Undervoltage outlets Drilling protection with electr. Hedge thermal overload protection Emergency Stop Impact Button Weight in kg: 44 Motor kW: 0,45 AC 230 V Speed 1/min: 250-3000 Drilling capacity mm: - Steel Ø 12 mm - Aluminium Ø 20 mm - Softwood Ø 40 mm - Drilling depth 60 mm - Projection 220 mm - Saeulen diameter 70 mm - usable table area (W x L) 300 x 250 mm - T-groove size number 2, distance 100 mm Dimensions width 14/26 mm - Spindle B 16 - Speed display digital - Drilling depth display: scale - Drill depth stop: quickly adjustable stop ring - Feed: by hand - FACTORY WARRANTY: 3 years - free domicile incl. packa ...

Spindle speed infinitely variable electronic 40-4000 1/min Spindle: MK 2 Table height adjustment with rack Thread cutting performance max M12 Setting the thread cutting depth via digital depth display digital speed display digital drilling depth display Drilling depth stop via stop ring Feed / by hand Table height adjustment with rack Continuous/normal drilling capacity steel Ø 15 mm / 18 mm Drilling depth 70 mm Projection 220 mm Mouth diameter 70 mm Usable table area (W x L) 300x250 mm Machine dimensions (W x D x H) 420x520x850 mm Weight 65 kg max distance spindle/table/foot 300/ 370/ 420 mm Motor AC with frequency converter 230 V , 0.54 kW OPTION Drilling package B16 (No. 296570) - Vice felix 80 - Quick-release drill chuck 1-13 mm Price: € 539,- Factory warranty: 3 years Free domicile including packaging (Germany only) Delivery time: immediately from ...

bore capacity in steel (diameter): 20 mm throat: 195 mm bore stroke: 80 mm boring spindle: MK 2 table surface area: 320 x 300 mm total power requirement: 0,75 kW weight of the machine ca.: 0,072 t dimensions of the machine ca.: 0,7 x 0,4 x 1,1 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 25 mm throat: 175 mm bore stroke: 50 mm : 16 mm spindle taper: ISO 30 spindle turning speed range: 50 - 3000 U/min : 380 mm : 175 mm table surface area: 700 x 180 mm connected load frequency: 230 V max. distance between table and spindle-nose: max. 320 mm total power requirement: 0,75 kW weight of the machine ca.: 150 Kg dimensions of the machine ca.: 670 x 550 x 910 m Drilling and milling machine with large table Digital display SINO 3-axis. Digital display quill stroke. 2 speed levels. Left/Right switch Pan head left/right 90° spindle protection. incl. tool box with various tools The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

bore capacity in steel (diameter): 30 mm throat: 200 mm bore stroke: 70 mm : 16 mm spindle taper: MK3 spindle turning speed range: 50 - 3000 U/min : 565 mm : 220 mm table surface area: 840 x 210 mm connected load frequency: 400 V max. distance between table and spindle-nose: max. 470 mm total power requirement: 1,1 kW weight of the machine ca.: 230 Kg dimensions of the machine ca.: 0,75 x 1,05 x 1,3 m Drilling and milling machine with large table Digital display SINO 3-axis. Digital display quill stroke. 2 speed levels. Left/Right switch Pan head left/right 90° Recording MC 3 - B16. Drill chuck 3 - 16 mm. spindle protection. Machine stand. incl. tool box with various tools The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Bohrleistung in Stahl (-Ø: 45 mm throat: 1250 mm workpiece height max.: 1100 mm swival range +/-: 360 ° height adjustment: 745 mm base plate surface area: 1450 x 920 mm Bohrspindel-Ø/ Aufnahme: 90 mm / MK 5 bore spindle stroke: 355 mm max. torque on the spindle: 250 Nm feed power: 14000 N turning speed range: 20 - 1200 U/min feed range: 0,063 - 0,63 mm/U power capacity: 3,7 kW weight of the machine ca.: 3,0 t dimensions of the machine ca.: 2,1 x 0,9 x 3,3 m • cube table 650 x 650 x 500 mm, • coolant device The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Bohrleistung in Stahl (-Ø: 50 mm throat: 1500 mm workpiece height max.: 1380 mm Bohrleistung in Guß (-Ø: 60 mm Abstand Spindelmitte bis Säule: 320 - 1250 mm swival range +/-: 180 ° base plate surface area: 2640 x 1000 mm max. torque on the spindle: 310 Nm Bohrspindel-Ø/ Aufnahme: 75 mm /MK 5 bore spindle stroke: 310 mm spindle turning speed range: 28 - 2500 U/min feed:: 0,05 - 2 mm/U power capacity: 4 kW weight of the machine ca.: 4,3 t cube table 500 x 500 x 500 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Work spindle, drill spindle, Tool spindle, HSK 50, AD80mm, Mapal, mint condition Special price We still have several identical and other such devices, but the amount is ending. Buy more than 1 piece, there is still a great discount. If you have a VAT number, we will gladly issue you an invoice without VAT. Mint condition! The part was purchased from a spare parts warehouse of a company, was there for a long time in stock but never in operation and is in a completely mint condition. Work spindle, drilling spindle, tool spindle from Mapal, - tool holder HSK 50, incl. flinger ring and cover ring, - Length bearing body 149 x D 80mm, 5 roller bearings AD 80mm, - Incl. Rotex coupling with gear rim drive side for shaft D35mm, - Overall dimensions: 305mm x D 80mm, 8kg, Functional guarantee! We cannot provide a conventional guarantee and warranty for second-hand parts. Howev ...

Working spindle, drilling spindle, tool spindle, HSK 63, AD80mm, Mapal, as good as new Special price We still have several identical and other such devices, but the amount is ending. Buy more than 1 piece there is still a great discount. If you have a VAT number, we will be happy to issue you with an invoice without VAT. As good as new! The part was bought from a spare parts warehouse of a company, has been in stock there for some time but has never been in operation and is completely new Working spindle, drilling spindle, tool spindle from Mapal, - Tool holder HSK 63, incl. centrifugal ring and cover ring - Length of bearing body 149 x D 80mm, 5 rolling bearings AD 80mm, - Incl. Rotex coupling with gear rim drive side for shaft D35mm - Overall dimensions: 305mm x D 80mm, 8kg Functional guarantee! For second-hand parts, we cannot provide a conventional guarantee and w ...

Continuous/standard drilling capacity (mm) 20/23 (in E335/ST60) Thread cutting capacity (depending on pitch) M12 Spindle MK II Drilling depth (mm) 100 Projection (mm) 240 Column diameter (mm) 82 Usable work surface (W x L) (mm) 340 x 280 T-slot size (arm), distance (mm), dimension width (mm) Number 2, 125, 13/26 Speed display digital Digital drilling depth display Drilling depth stop quickly adjustable stop ring Feed (mm/revolution) by hand Table height adjustment with rack Motor three-phase current 400V with frequency converter (kW) 1.5 Spindle/work surface distance (mm) 160 – 880 Machine dimensions without packaging (mm) 355 x 705 x 1825 Machine dimensions with packaging (mm) 572 x 936 x 2142 Weight (kg) 195 Standard accessories: Thread cutting device Control panel with OLED display Robust, high-quality drill head hood with ergonomically inclined front LED li ...

Dear customers currently we offer you a refurbished columns or column drilling machine from F. Zimmermann for sale. The special feature of the machine is the work table adjustable in 3 levels. Here are the other technical data of the machine: Speeds: 100 - 2,250 rpm Work light MK3 recording (new) Swivel radial: 360° Swivel axisial: 2x 90° Quill stroke: 160 mm Projection column spindle center: 500mm Table: 490 x 400 mm Centering disc Ø: 55 mm H7 working height swivel table: 715 mm working height base plate: 1,215 mm Base plate and table with T-slot 12 mm Dimensions: 600 x 1,120 x 1,930 mm Power: 1.5 kW Weight: approx. 500 kg After the overhaul, the machine has a completely new electrical system including engine brake, is painted light grey in RAL 7035 and comes with a drill set. We look forward to your questions and inquiries! If you have any questions, please ...

Radial drill Manufacturer: Archdahle

Sell a TBT quill block, Condition new. Pinol block has never been installed. Original price is 30.800,00 Euro net. .VB

Continuous/normal drilling capacity 18/20 mm Threading capacity M12 (depending on pitch) Lockers MK II Drilling depth 100 mm Projection 240 mm Column diameter 82 mm Usable work surface W x L 340 x 280 mm T-slot size (arm), distance (mm), dimension width (mm) Number 2, 125, 13/26 Speed indicator: Digital Drilling depth indicator: Digital Drilling depth stop: quickly adjustable stop ring Manual drill feed Table height adjustment with rack Motor three-phase current – frequency-controlled, 230 V, 0.75 kW Spindle speeds infinitely variable 30 – 3000 1/min Table work surface: 155 - 415 mm Footwork: 155 – 550 mm Machine dimensions: 355 x 705 x 1065 mm Weight: 170 kg Optional accessories: Drill package 3: with [felix] 2.0 100 Machine vice Flott [felix] 100, Quick-change drill chuck 3-16 mm (accuracy 0.17 mm), Kegeldorn MK 2 B18 and reducing sleeve MK 2 to Mk 1 � ...

bore capacity in steel (diameter): 16 mm throat: 185 mm bore stroke: 50 mm : 20 mm spindle taper: MK 2 spindle diameter: mm spindle turning speed range: 100-1500 / 200-3000 U/min : 175 mm : 280 mm table surface area: 500 x 180 mm connected load frequency: 230 V total power requirement: 0,85 kW weight of the machine ca.: 0,12 t dimensions of the machine ca.: 0,86 x 0,6 x 0,9 m Drilling and milling machine - Cross Support - Cabinet - Swivel spindle head left / right 90 ° - Feed via hand crank The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

offer 22326 Specifications: - Drilling capacity in steel ST 60 35 mm - Drilling capacity in steel ST 60 40 mm - Drilling spindle holder MK 4 - Drilling spindle stroke 170 mm - Projection 345 mm - Rotary table with 2 T-slots 550 mm - distance table – drilling spindle 650 mm - distance base plate – drilling spindle 1000 mm - Feed rates 0.09 - 0.16 - 0.28 mm/rev - AZ transmission continuously variable with manual transmission - Drilling spindle speeds infinitely adjustable 40 - 720 rpm -Right. - Left-hand rotation - Drive 400 V / 2.5 kW -Lighting - Coolant device - Space requirement approx. W 750 x H 1950 x D 1000 mm - Weight approx. 700 kg

offer 22054 Specifications: - Drilling capacity - in steel 15 mm - - in aluminium 18 mm - Drilling spindle holder MK 2 - Drilling depth 70 mm - Projection spindle / column 180 mm - Drilling spindle speeds 80 - 4000 rpm - Drive 400 V 0.45 / 0.75 kW - height-adjustable drilling table 280 x 240 mm - Distance drilling spindle / table approx. 360 mm - Distance drilling spindle / base plate approx. 410 mm - Space requirement approx. W 280 x H 1700 x D 600 mm - Weight approx. 85 kg - with : - Quick-change drill chuck 1 - 13 mm - Machine vice - div. Gebr. HSS drill 5 - 15 mm
