double mitre saw used for sale

Double head eyeletting machine Hang 87 D Serial-No. 31583

General SKU204U042 LocationBarneveld MakeWerner & pfleiderer Sizes Screw diameter70 mm Main Features Motor108 KW L/D23 Specified Features - Double screw extruder MaterialNichrome 2.4869 Double screw extrudercheck Screw diameter70 mm L/D23 Co-rotatingcheck Water coolingcheck AC-motorcheck 108kW, 330Volt, 1500rpm With variable speed drivefrequency controller Screw speed198 rpm Exchangeable segmentscheck ( not included) Information TypeZSK 70F175E Mach.No.231783 Year of construction1996 ( gearbox 2017) With switchgearcheck Sizes switchgear1,25x0,7x2,15 m Floorspace4,6x2 m Total height1,7 m Weight6400 kg Extra Specificationsinlet: 142x130 mm - there are 2 screw shafts present - no screw segments present - no extruder head present SpicesPlastic & polymersCatalysts & fillersFeed additivesSolventsDouble screw extrudersDetergent & surf.Other pharmaceuticsCosmeticsOr ...

General SKU235U235 LocationBarneveld CEcheck MakeIlchmann Main Features Motor3 KW Length6525 mm Inlet diameter350 mm Specified Features - Horizontal screw conveyor MaterialStainless steel 1.4571 (316Ti) Horizontal conveyor screwcheck Trough-typecheck Double shaftcheck Diameter200 mm (2x) Length6525 mm Between inlet and outlet5880 mm Shaft diameter108 mm (x) Pitch200 mm Inlet630x350 mm Outlet350x350 mm Max. temperature90 °C With adjustable packing glandscheck Motor3 kW, 220-230 volt / 380-400 volt, 1456 rpm Screw speed31 rpm With coverscheck Information TypeDTSF 2x200x6.525 Mach.No.CRO 0348 Year of construction2014 Floorspace8,3x5,1 m Total height0,49 m Weight1250 kg Extra SpecificationsCapacity: max. 5 m³/hSpicesPlastic & polymersHorizontal screw conveyorsCatalysts & fillersFeed additivesPaper & otherSolventsDetergent & surf.Other pharmaceuticsCosmetic ...

Mitre Cold Circular Saw EISELE Type VMS-III-S-PVTyp No. 430 Fabr. No. 2371 Year of construction 1991Saw range at 90 (round) 120 mmSaw range at 90 (flat) 150 x 110 mmSaw range at 45 (round) 100 mmSaw range at 45 (flat) 120 x 100 mmSaw blade diameter 350 mmSaw blade speed 17 + 34 rpm. Mitre cut 45 to the left, 90 and up to 30(60) to the right, infinitely variableMotor power 2 and 2.6 kWNerg connection 380 volts, 50 Hz- two cutting speed levels over 2 motor speeds-

Mitre cold circular saw BERG & SCHMID type MKS 350Year of construction approx. 1980Saw range at 90 Around 110 mmSaw area at 90 Rectangle 160 x 90 mmSaw area at 90 Square 95 x 95 mmSaw area at 45 Round 95 mmSaw area at 45 Rectangle 120 x 90 mmSaw area at 45 Square 80 x 80 mmSaw blade diameter max. 350 mmSaw blade speed 28 and 56 rpm. Motor power approx. 1.8 / 2.5 kW pole-switchableMains connection 380 volts, 50 Hz- motor with 2 electrically switchable speeds- infinitely variable

automatic double mitre saw OMS SALVARANI INVINCIBILE OK 330 CE standard : Yes n.02 motors . power Hp 3 each one blades diam.mm.330 max. useful cutting length mm.3000 max. useful cutting width 90° mm. 165 max. useful cutting width 45° mm. 115 max. useful cutting heigth mm.115 volt. 380/50 weigth kgs.650

2-spindle cross-cut saw for series production for precise shortening of materials. The machine can be manufactured in different versions depending on the specification and requirements. Specifications: Motor power: 2.2kW / 3kW Material length: 500 - 1500 mm Possibility to tilt the discs: YES Machine manufactured on request

Auction-ID: A7-45209-5

I sell a double mitre saw without scoring with continuous COMEC TD2400 + CA. Working width 250 to 2400mm. Max. saw profile 80 x 100mm Angular setting of each head: Radial +50° / - 50° Axial +45°/ - 45° Saw blade diameter fi.350/30mm Motor power 1.85KW + 1.85KW Magazine for elements. Ejection back to operator Condition as good as new. Fully operational and ready to go. Possible to check. Available soon. With CE and complete documentation.

Code: 0323 Brand: SML - ITALY Model: SILVER P 35/EL - CE Standard Electronic double mitre saw for cutting wood, frames, pvc, aluminium, plastics and various materials - CE Standard Technical data: Oleo-pneumatic head lowering Max cutting length mm 5200 Min cutting length mm 50 Cutting height mm 100 Max cutting width mm 170 Blade diameter mm 350 F30 Motor Hp 3 each - Rpm 3000 Electronic head positioning programmer Bimanual blade lowering control Pneumatic pressures for workpiece clamping N° 2 suction ports diameter mm 60 Working pressure 7 bar Overall dimensions mm 6300 x 1000 x 1600 h Weight kg 1100

Code: 0370 Brand: HAFFNER - GERMANY Model: DGS 187 - CE Standard Double mitre saw with tilting blades for cutting wood, aluminum, pvc and various materials - CE Standard Technical data: Blades diameter mm 500 F 30 N° 2 motors each Kw 2,2 - Rpm 2800 Cutting length max mm 3400 Cutting length min mm 230 Blades inclination 45° - 90° Electronic positioning cutting length of left cutting unit Hydropneumatic saw feed Pneumatic workpiece clamping Control panel double buttons Electronic head positioning programmer N° 2 suction ports diameter mm 120 Compressed air 6 bar Overall dimensions mm 4600 x 1300 x 1650 h Weight kg 550

PART NUMBER: 7540 Specifications: - max disc diameter 350mm - spindle diameter 30mm - up/down adjustable dial - electric brake - shield guard - max cutting height for the blade 350mm - 100mm - min saw spacing 250mm - max saw blade spacing (edge saw blade spacing) 2500mm - max cutting length 2170mm - electric saw spacing - with a scorer - max scorer disc 130mm - spindle diameter 20mm - power of the scoring motors 2×0.75kW - main motor power 2x4kW - bottom bracket motor power 0.37kW - 2 types of rotation speed 3000,4500 rpm - extraction spigot diameter 2x120mm, 2x80mm - total dimensions length/width/height 4500x3000x1600mm - weight about 1100kg Advantages: – Polish production – electric saw spacing – DTR documentation – very good condition – used double saw Net price: 32900 PLN Net price: 7651 EUR depending on the price 4.30 EUR (Prices ...

Manufacturer: Düspohl, Type: DEA 150, Year: ca.1995, Control: hand, Pneumatical clamping system: yes, Schnitthöhe min-max mm: 120, Schnitttiefe min-max mm: ca.150 -150, Power saw engine kW: ca.3, Action controlled: yes, Saw blade diameter max mm: 350, rotations controlled: 4500, Year :ca.1995

Manufacturer: Unbekannt, Year: ca.1985, Saw blade tiltable up to °: 45-90 und Schifterschnitt, Schnitttiefe min-max mm: 90, Schnittlänge min-max mm: ca.3500, Power saw engine kW: 0,75, Width adjustment manually: yes, Action controlled: yes, Saw blade diameter max mm: ca.250, rotations controlled: ca.4500, Vacuum clamping system: Pneumatisch, FREE TEXT: Hydropneumatischer Vorschub Sägen, Year :ca.1985

Manufacturer: Haffner, Type: DGS 202E 6000, Program control: yes, Pneumatical clamping system: yes, Saw blade tiltable up to °: 45-90, Schnittlänge min-max mm: 400-6000, Power saw engine kW: 2,2, Width adjustment by engine: yes, Saw blade diameter max mm: ca.500, rotations controlled: 2850,

Manufacturer: WMS, Type: 20051, Year: 2001, Control: Hand, Pneumatical clamping system: yes, Saw blade tiltable up to °: 90-45, Schnitthöhe min-max mm: ca.100, Schnitttiefe min-max mm: 400, Schnittlänge min-max mm: 2110, Width adjustment by engine: yes, Saw blade diameter max mm: 450, Hauptmotorsäge kW: 4, rotations controlled: 2860, Year :2001

Manufacturer: Doppelgehrungssäge, Type: DKG 400 A, Year: ca.1984, Control: Hand , Pneumatical clamping system: yes, Saw blade tiltable up to °: 45-90, Schnitthöhe min-max mm: ca. 70, Schnitttiefe min-max mm: 100, Schnittlänge min-max mm: 3500, Power saw engine kW: 3 KW,100 Hz, Width adjustment by engine: yes, Action controlled: yes, Saw blade diameter max mm: 300, rotations controlled: 4500, Bohreinheit Horizontal: 100, On customer order: inkl. Bohrstation, Year :ca.1984

Manufacturer: Doppelgehrungssäge, Type: DKG 400 A, Year: 1984, Control: Hand / Teilautomatik, Pneumatical clamping system: yes, Saw blade tiltable up to °: 45-90, Cutting hight max mm: ca. 70, Cutting lenght max mm: 2500, Power saw engine kW: 3, 100 Hz, Width adjustment manually: yes, Width adjustment by engine: yes, Action controlled: yes, Saw blade diameter max mm: 300, rotations controlled: 4500, Exhaust diameter mm: 100, inkl. Bohrstation, Year :1984

Manufacturer: Düspohl, Type: DGK 400, Year: 1980, Control: Hand, Pneumatical clamping system: yes, Saw blade tiltable up to °: 45 - 90, Cutting hight max mm: ca. 70, Max. cutting depth in mm: 150-2600, Max. cutting depth in mm: 150-2600, Power saw engine kW: 2,2, Width adjustment manually: yes, Saw blade diameter max mm: 300, rotations controlled: 5800, Exhaust diameter mm: 100, Year :1980

Manufacturer: Haffner, Type: DGS 124, Bauyeshr : 1994, Pneumatical clamping system: yes, Sägeblätter schwenkbar bis ° : 45-90-45, Schnitthöhe max mm : ca.150, Schnittlänge max mm : 200, Schnittlänge max mm : 200, Power saw engine kW: 2,9, Width adjustment by engine: yes, Saw blade diameter max mm: 500, rotations controlled: 2800, Year :1994

Saw blade diameter: 2x400mm, max. cutting length: 4000mm, cutting angle: +/-45°. Documentation available. On-site inspection is possible.

An NC mitre saw Omga S.p.A. is available. Speed: 3000 rpm, saw blade diameter: 300 mm, saw blade bore: 30 mm, max. cutting height: 60 mm, max. cutting width: 60 mm, max. feed: 1250 mm, angle adjustment: 45°/30°/22.5°, machine dimensions X/Y: approx. 5600 mm/1250 mm. Documentation available. On-site inspection is possible.

SPECIFICATIONS: Saw blade spacing: max. 2800 mm Tilt: 0° - 90° Saw blade: Ø 350 mm Installed power: 2.2 kW x 2

SPECIFICATIONS: Saw blade spacing: max. 2400 mm Tilt: 0° - 45° Saw blade: Ø 200 mm Equipped with multi-function display Installed power: 1.18 kW x 2

A double mitre saw from the Chinese manufacturer Mange Jixie with digital display is available. Power: 4.8kW, pressure: 0.8MPa, cutting length range: 480mm-6000mm, saw blade outer diameter: 500mm, inner diameter: 300mm, blade thickness: 4.2mm, number of teeth: 120, feed rate: 2-3m/min, blade speed: 2840rpm, weight: approx. 1800kg. An on-site inspection is possible.

Code: 0246 Brand: OMGA Model: TR 2B NC - CE Standard Automatic double mitre saw with numerically controlled positioner for cutting frames, wood profiles, furniture, wooden window frames, doors, plastic materials, and various - CE standard Technical data: Numerically controlled positioner: allows cutting lists to be stored and the moving head to be positioned automatically Cutting length 3500 mm Blade diameter 350 F 30 mm Motors each 2,2 Kw Rpm 3000 Cutting width 170 mm Cutting height at 90° 102 mm N° 2 vertical pneumatic pressers Suction mouth diameter 80 mm Compressed air 6-7 bar Overall dimensions mm 4400 x 1000 x 1500 h Weight kg 600

Code: 0252 Brand: MA BREVETTI Model: JUNIOR 275 Pneumatic double mitre saw for 45° + 45° cuts at both ends, in frames and mouldings of any shape and kind Technical data: Blade diameter mm 275 F30 Max cutting capacity: Width 70 mm - Height 90 mm Production rate approx. 700/800 cuts Motors n° 2 - 2 Hp each - rpm 2800 Power supply V.380/50 Operating pressure 6 bar Suction port diameter 100 mm Overall dimensions mm 850 x 700 x 1400 mm Weight kg 265

A double mitre saw Emmegi (Pressta Eisele) is available. Saw blade diameter: 500mm, saw heads: 2, saw head swivelling range: 90°-45°, cutting length range: 250mm-5000mm, max. cutting height: 350mm, max. cutting width: 160mm. Machine dimensions X/Y/Z: approx. 5750mm/1250mm/1700mm, weight: approx. 1250kg. Documentation available. An on-site inspection is possible.

Code: 0228 Brand: OMS SALVARANI Model: 300 INVINCIBILE Pneumatic double croscutting machine for cutting wood, frames, fixtures, joinery, furniture, and various other materials Technical data: Working length mm 3000 Blade diameter mm 300 Motor power Hp 2,5 - Rpm 3000 Manual movement of the 2 heads Cutting from 0 to 45° right and left Pneumatic pedal for lowering the heads N° 2 pneumatic clamps for locking workpieces N° 2 suction ports diameter mm 50 Compressed air 6 bar Overall dimensions mm 4000 x 700 x 1250 h Weight kg 520

A Schüco double miter saw for aluminum profiles is available. Saw units: 2, max. cutting length: 6000mm, saw blade diameter: 500mm, bore: 32mm, max. miter angle: 22.5°, fixed stops: 90°/45°/22.5°, min. cutting length: 300mm. Machine dimensions X/Y/Z: approx. 7500mm/1800mm/2000mm, weight: approx. 2200kg. Documentation available. An on site inspection is possible.

OMS SALVARANI double miter saw model OK 350 SUPER: - useful opening 3200mm - adjustable blades D=350mm - Total power kw 8.3 , volt 380 - year 1995, machine to CE standards

Cutting range at 90°: Ø 340 / Flat W 500 x H 340 mm Miter: 60°L - 90° - 60°R; Stepless belt speed 26/86; Hydraulic vice Saw blade dimensions: 4380x34x1.10 mm 950 kg Recent Showroom Machine

Cutting range at 90°: Ø 340 / Flat W 500 x H 340 mm Miter: 60°L - 90° - 60°R; Stepless belt speed 26/86; Hydraulic vice Saw blade dimensions: 4380x34x1.10 mm Total weight 950 kg Original packaging, extensive accessories

Pilos ARG 300 plus E.S.A.F Double mitre band saw 45°-90°-45°-60° Inclusive: Frequency-controlled saw blade drive Belt tension indicator Electronic height adjustment of the saw frame

Metal Band Saw Machine Pilous ARG 235 plus Double mitre 90° -45° +45° +60° Round: 235 165 185 115 Square: 230 145 160 80 Rectangle: 280x180 185 x 80 185 x 100 115 x 80 Main motor 400 V, 50 Hz, 0.9/1.4 kW Pump motor 400 V, 50 Hz, 0.05 kW Saw blade speed 35/70 m/min. Height of material contact surface: 900 mm Coolant tank approx. 15 l Weight 295 KG Delivery Austria & Germany by freight forwarder or pick-up possible.

Metal Band Saw Machine Pilous ARG 260 plus E Double mitre 90° -45° +45° +60° Round: 260 180 200 125 Square: 240 160185 105 Rectangle: 300x185 190x105 185x195 125 x 105 Main motor 400 V, 50 Hz, 0.9/1.4 kW Pump motor 400 V, 50 Hz, 0.05 kW Saw blade speed 35/70 m/min. Height of material contact surface: 900 mm Coolant tank: approx. 15 l Weight 310 KG Delivery Austria & Germany by freight forwarder or pick-up possible.

Max. cutting length: 4,500 mm Max. saw blade diameter: 550 mm Automatic length positioning and angle adjustment via program control Motorized adjustment for swivelling on both sawing units, allowing angles between 45 and 90 degrees to be directly controlled New network-compatible control system in 2019 Minimum quantity spraying device Weight: approx. 2200 kg

Type USK 1710 Payload 150 kg Measurements (91-171)x60x(59-82 cm) Table size 60x46 cm Weight 15,5 kg

Type KAP 255XJL Cutting height 45?-90?: 80 mm Cutting height swing 45?: 40 mm Cutting lenght 90?: 430 mm Cutting lenght tilt 45?: 310 mm Motor power S1 1,8 kW Saw blade speed 4800 rpm HM-saw blade teeth 254x30x3 mm Transport dimensions 850x520x410 mm Weight 20 kg

Graule ZS 200N Cutting and miter circular saws Motor 400 V / 3.0 kW Speed 2800 rpm Cutting length 420 mm (at 90°) Cutting height 200 mm (at 90°) Miter range: horizontal 45°-90°-20° Miter range: vertical 60° -90°-45° Saw blade s. 520 mm Suction nozzle 100 mm Weight 310 kg G&GA-ZS200N-3KW Underframe optional

Auction-ID: A1-44897-101

Auction-ID: A1-44897-100

Mitre saw Brand: Graule Type: H8 J2 169 saw blade Ø 250mm swivable saw blade 45 °

Mitre saw Brand: Hebö Type: TA 131 Year: 1999 technical data: adjustable +/- 45° 400 V, 50Hz saw blade Ø approx. 400 mm 2 clamping cylinder extended workpiece support left- / right side each 840 mm 2 stops Note: The specifications and descriptions are a copy of the order confirmation at that time. Datas are for information and are not binding.

AUTOMATIC DOUBLE MITRE SAW model OMGA TR 2B N oleo second hand machine in Excellent working condition , like new for cutting wood, frames, pvc, aluminium, plastics and various materials CE compliant machine: YES oil pneumatic downstroke of the blade groups alternate or simultaneous blade descent inclination of cutting blade groups + / - 45° bimanual control from the control panel n.02 motors . power Hp 3 each one blades diam. mm. 350 max. useful cutting length mm.2800 min. useful cutting length mm.320 max. useful cutting width 90° mm. 170 x 102 H max. useful cutting width 45° mm. 110 x 102 H volt. 380/50 weigth kgs. 600

Speed 40/80 1/min, incl. inlet and outlet

Saw blade diameter: 450mm, cutting width: 4mm, saw blade type: HM/HSS, mounting hole: 50mm, fastening screws: 4, pitch circle fastening screws: 80mm, screw diameter: M12. Saw blade feed speed: 3.5m/min, rapid return: 4.5m/min, feed speed: 10m/min/20m/min, cut-off length single stroke: 10mm/1000mm, double stroke: 2000mm, turntable tilt: +/-90°. Machine dimensions X/Y/Z: approx. 2700mm/1450mm/1900mm, weight: approx. 1500kg. Documentation available. On-site inspection is possible.

Saw blade diameter: 275mm, cutting range round (90°): 100mm, cutting range flat (90°): 160mm/80mm, speed: 40rpm - 80rpm. On-site inspection is possible.
