double column machining used for sale

Manufacturer: HEAD / KENT Model: CUV-10 (KMV 10) Year: 1999 Robust CNC vertical machining center, Meehanite cast iron construction, suitable for machining single parts and small to medium series. Numerical control: FANUC OMD Structure: Meehanite cast iron Turcite B-coated slides Rigid thread Portable electronic crank Full protective guard Sprinkler system Work light and end-of-cycle lamp Toolbox Races: X: 1,020 mm Y: 510 mm Z: 510 mm Distance between spindle nose and table: 105 to 740 mm Table: Dimensions: 1,200 × 600 mm T-slots: 18 mm – 3 grooves Max. permissible load: 1,000 kg Spindle: Speed: 30 – 7,500 rpm Transmission: ZF gearbox – 2 ranges Cone: BT 40 Engine power: 11 kW Feeds: Fast feed (X,Y,Z): 24 m/min Working feed: 1 – 10,000 mm/min Tool changer: Capacity: 20 tools Max. tool weight: 6 kg Bidirectional selection Machine dimensions: 2,880 × 2,420 × 2,980 mm Floor space ...

CNC control: Heidenhain TNC 530 Machine 5 simultaneous axes Strokes: X = 730 mm, Y = 560 mm, Z = 560 mm Spindle speed: up to 12,000 rpm Cone: SK40 Feeds: 20 – 20,000 mm/min Fast feeds: 30 m/min Table: 1000 x 600 mm Max load table: 800 kg Tool changer: 24 / 30 positions Machine hours≈ 31,481 h Spindle hours≈ 25,087 h Lots sold as is, unchecked, without tools or tool holders. Auction-ID: A1-50714-4011

x-travel: 762 mm y-travel: 460 mm z-travel: 460 mm table surface area: 1.000 x 460 mm control: Okuma OSP 20 M rapid traverse: 40/40/32 m/min table load: 0,7 t turning speed range: 12000 U/min power capacity - milling spindle: 22/18,5 kW max. torque on the spindle: 198 Nm no. of tools in the magazine: 32 Stück internal coolant system feed: 20/43 bar tool taper: BT 40 weight of the machine ca.: 6,8 t dimensions: 2.22 x 2,9 x 2,75 m CNC- vertical machining centre with internal coolant First installation 2014 - coolant through the spindel 15 bar, 20 ltr/min - air throug the spindle - chip conveyor - signal lamp - Dual tool change arm - external electric hand weel - tool lenght measuring and toolbreak detection - filter system - X- axis in gantry style - spindle oil cooler - thermal compensation spindel and bed - USB and Ethernet port - Hi-Cut Pro high speed control - 100 Zero offsets - thre ...

- Total installed power approx. 22 KW. - Usable working area approx. 4000 x 1400 mm. - Maximum travel speed in x-y-z directions: 100-100-25 m/min. - Axis C. - Tool magazine with 6 positions. - Electrospindle: power 11 KW-max. 24000 rpm, automatic tool change, for HSK F63 tool holder. - Adjustable saw group. - Vertical holes in the x-axis direction: 10. - Vertical holes in the y-axis direction: 8. - Horizontal holes in the x-axis direction: 2 + 2. - Horizontal holes in the y-axis direction: 1 + 1. - Remote control panel. - 8 benches with 8 suction cups in total. - Vacuum pump NASH_ELMO 2BL2141-2AH50-4A-Z with a capacity of 100 m³/h. - Operating conditions of this machine: unchecked. - This item is delivered loaded by truck. The costs of disassembly and loading are those specified as additional costs. Auction-ID: A7-50834-26

- Usable working area approx. 5000 x 1400 mm. - Axis C. - Tool magazine with 18 positions. - Electrospindle: power 7.50 KW, automatic tool change, for HSK F63 tool holder. - Vertical holes in the x-axis direction: 11. - Vertical holes in the y-axis direction: 11. - Horizontal holes in the x-axis direction: 1 + 1. - Horizontal holes in the y-axis direction: 1 + 1. - Edging unit with edge loader for 2 coils. - IMA numerical control. - 8 benches. - Lifting modules for heavy parts. - SIEMENS 2BL1100-2NC00-1S-Z vacuum pump, 2.35 KW motor. - Tools (10) and add-ons (3) that appear in the photographs are included. - Operating conditions of this machine: unchecked. - This item is delivered loaded by truck. The costs of dismantling and loading are those that are specified as additional costs. Auction-ID: A7-50834-18

- Total installed power approx. 15 KW. - Usable working area approx. 2900 x 1000 mm. - Passage height on panel 180 mm. - X-axis travel: 3300 mm, y-axis travel: 1280 mm, z-axis travel: 200 mm. - Maximum travel speed in x-y-z directions: 67-67-22 m/min. - Electrospindle with manual tool change. - Saw group for grooving in the direction of the X-axis. - Vertical holes in the x-axis direction: 5. - Vertical holes in the y-axis direction: 6. - Horizontal holes in the x-axis direction: 1 + 1 (HEAD IS MISSING). - Horizontal holes in the y-axis direction: 1 + 1. - ESA KVARA 6 numerical control. - Remote control panel. - 6 benches with 14 suction cups in total. - BECKER vacuum pump. - Operating conditions of this machine: unchecked. - This item is delivered loaded by truck. The costs of disassembly and loading are those specified as additional costs. Auction-ID: A7-50834-14

- Total installed power approx. 60 KW. - Dimensions of the aluminium work table approx. 6700 x 1570 mm. - Z-axis travel 340 mm. - Tool magazine with 12 positions. - Electrospindle: power 7.50 KW-max. 18000 rpm, automatic tool change, for HSK F63 tool holder. - Vertical holes in the x-axis direction: 5. - Automatic lubrication. - Numerical control NUM. - Remote control panel. - BECKER VTLF 250 vacuum pump with a capacity of 248 m³/h. - Operating conditions of this machine: unchecked. - This item is delivered loaded by truck. The costs of disassembly and loading are those specified as additional costs. Auction-ID: A7-50834-1

gantry machining center, year 2005, CNC TNC 530. Used machine. More info & price on IndustrialBuyer.

5-axis machining center, year 2010, CNC 840 D SL. Used machine. More info & price on IndustrialBuyer.

horizontal machining center, year 2022, CNC Professional 5. Used machine. More info & price on IndustrialBuyer.

table: 1270 x 510 mm, traverses: 1000 x 510 x 520 mm, spindle speed: 25 - 4000 rpm, spindle motor power: 11/7.5 kW, tool magazine: ATC20, Auction-ID: A1-50601-9

table size: 550 mm, axis travel: X: 800 mm, Y: 800 mm, Z: 700 mm, A: 360 degrees, taper: BT50, maximum spindle speed: 10,000 rpm, tool magazine: 60 cups, maximum workpiece weight: 800 kg Auction-ID: A1-50601-11

Lehmann two-axis CNC rotary table (4th and 5th simultaneous axis) D 200 On pallet 1200 x 800x 500 mm transport dimensions Auction-ID: A7-50850-11

5-axis machining center, year 2016, 30592 operating hours, CNC Professional 5. Used machine. More info & price on IndustrialBuyer.

- Vertical drilling unit with 16 drilling spindles in the X direction - Vertical drilling unit, with 15 drilling spindles in the Y-direction - Vertical drilling unit, with 13 drilling spindles in the Y-direction (grid 25 mm) - Horizontal drilling unit with 6 drilling spindles - Horizontal drilling unit with 2 drilling spindles. - Main spindle 7.5/10 kW - (S1/ S6 operation HSK F63, incl. liquid circulation cooling with integrated CNC axis rotating 360 degrees incl. torque support. - Automatic tool change magazine for 8 seats (plate changer) - HOMATIC - 2000 IPC with WoodWOP 4.0 programming software - Pillar extension Y-direction 120 mm and K-table 1500 mm - Incl. 2 adapter units, see photos

USED AKIRA SEIKI PERFORMA V2.5XP MACHINING CENTER Year: 2011 Table dimensions: 910 x 400 mm Weight allowed on the table: 960 Kg Spindle power: 15 kW Spindle speed: 12,000 rpm Axis travel: X=760 - Y=445 - Z=520 mm Cone type: BT 40 Tool changer: 28 tools Equipped with 1 MITSUBISHI M70 CNC 1 Center coolant 1 Chip conveyor Auction-ID: A1-50950-1

Program run 5700 h, spindle hours 4800 h, spindle holder ISO 40, internal coolant supply, Heaxgon touch probe, without NC clamp Auction-ID: A1-50626-15

HAAS VF2SS VERTICAL MACHINING CENTER NEW Serial No.: 1166625 Year: 2020 Number of spindle hours: 1,000 hours Table Table dimensions: 914 x 356 mm Table weight: 680 kg Spindle Maximum spindle speed: 15,000RPM option Spindle taper: BT 40 Axes Axis travel: X=762 - Y=406 - Z=508 mm Fast feeds: X=35.6 - Y=35.6 - Z=35.6 m/min Tool magazine Tool changer: 30 tools Maximum tool weight: 5.4 Kg Equipped with 1 HAAS CNC 1 Spindle center coolant system 1 Chip conveyor Auction-ID: A1-50950-22

USED MORI SEIKI NHX 5000 HORIZONTAL MACHINING CENTER Year: 2011 4 Axis Table Table dimensions: 500 x 500 mm Weight allowed on the table: 500 kg Maximum rotational diameter to be machined: 800 mm Maximum height to be machined: 1000 mm Indexing time: 1.49 seconds Spindle Spindle speed: 12,000 rpm Spindle cone: BT 40 Front bearing diameter: 80 mm Axes B-axis : 360,000 positions Axis travel: X=730 - Y=730 - Z=680 mm Fast feed: X - Y - Z = 60,000 mm/min Tool magazine Tool holder type: BT 40 Tool changer: 60 tools Tool-to-tool change time: 0.9 seconds Maximum tool weight: 12 Kg Pallets Number of pallets: 2 Pallet change time: 9 seconds Dimensions of the machine: 3100 x 4855 x H2850 mm Machine weight: 11,100 kg Equipped with 1 CN MORI SEIKI M730BM 1 Set of tool holders 1 Watering by shower 1 Hydro fluid high-pressure unit 1 Automatic centering and measuring system1 Tool break detector  ...

CNC – Transl. Machining Centre Inv. No. 10.653MM Make UNISIGN Model Univers 4 Control Siemens Sinumerik 810D Travel X (Longitidinal) 1,600 mm Y (Cross) 400 mm Z (Spindle Height) 400 mm Taper ISO 40 Table 700 x 400 mm Load 600 kg Distance Spindle Nose to Table 150-550 mm R.P.M. 9.000 Main spindle kW 14 Rapid Traverse X,Y,Z 5-28,000 mm/min. Feed rate X,Y,Z 28,000 mm/min. A.T.C. 44 pos. Auction-ID: A1-50718-20

USED FAMUP MMV 160-65 MACHINING CENTER Serial No.: M-165.027.07 Year: 2007 Spindle Spindle speed: 12000 rpm Spindle power: 35/22.5 kW Spindle taper: ISO 40 Axes Axis stroke: X=1600 - Y=650 - Z=600 mm Table Dimensions: 2000 x 650 mm Max. weight on the table: 2000 kg Tool magazine Tool changer: 30 tools Equipped with 1 FANUC 18i-MB CNC Coolant in the center 1 Chip conveyor Dimensions and weight Machine: 4300x2500xH3060mm - Conveyor: 5500x2050mm - 3 pallets: 900x2350mm - 1100x2500mm - 1300x2200mm - total weight: 14000 kg Auction-ID: A1-50950-14

X-axis travel: 810mm, Y-axis travel: 610mm, Z-axis travel: 610mm, rapid traverse: 30m/min, tool holder: SK40/DIN 69871A, pull stud: DIN 69872A, tool changer: 32 tools, program memory expansion: 64MB (ATA memory card), machine color: RAL 7035/5008, mains voltage: 400V, mains connection: 3/PE~ (three-phase AC with protective earth), mains frequency: 50/60Hz, operating current (I_B): 50A, rated current (I_N): 50A, programming interface: Siemens ShopMill, max. spindle speed: 8,000rpm, screen: 10.4-inch color display, control system: Siemens 810DE PowerLine, operating hours: 37,506h, including documentation. On-site inspection is possible.

POS POSmill C 1050Year of manuf. : 2012 Control : Heidenhain iTNC 530 HSCI Speed : 10000 rpmMovement X/Y/Z : 1050/530/630 mmTool holder : SK40 ____________Description:General:Tool magazine:24 stationsRapid traverse X/Y/Z:24 m/minMachine weight:7,800 kgSpindle:Technology:Belt spindleSpeed:10,000 rpmTool holder:SK40Fluid delivery:Blow air through the spindle + cooling lubricant through the spindle (IKZ)Work table:Work surface:1,150 x 560 mmTable load capacity (max.):700 kgTravel ranges X/Y/Z:1,050 x 530 x 630 mmFeatures/Accessories:Chip Management:Chip ConveyorCooling Management:IKZ SystemSetup Mode:Electronic HandwheelProbe:Tool Probe (Hexagon)

The machine is in good technical condition; it can be tested by prior arrangement.

CNC HORIZONTAL MACHINING CENTER Inv. No. 12.178MM Make TOYODA Model LINEAM III Control MELDAS M650 Year 2004 TABLE Pallet size 450 x 450 mm Max. load on pallet 400 kg Table indexing increment 0.001 degrees STROKE X-Axis stroke 630 mm Y-Axis stroke 630 mm Z-Axis stroke 700 mm Distance from spindle center to top of pallet 50 – 680 mm Distance spindle nose /center rotary index table 50 – 680 mm FEED RATE Rapid feed rate X,Y 120 m/min Rapid feed rate Z 60 m/min Rapid feed rate B 120 m/min Cutting feed rate X,Y,Z 0,1 – 60 m/min SPINDLE RPM spindle 300 – 20,000 min-1 Spindle taper HSK-A63 Coolant Through spindle ATC Tool holder Special HSK-A63 2 Face contact tool Tool magazine storage 40 pcs Tool change time 2.5 sec. DRIVE MOTOR Spindle drive motor Ac 45/30 kW MACHINE WEIGHT & POWER REQUIREMENTS Machine weight 15.000 kg Power requirement 96 kVA ACCESSORIES: Spindle linear mo ...

- Includes cabinet and electronic components. - Operating conditions of this item: unchecked. - This item is delivered loaded by truck. The costs of disassembly and loading are those specified as additional costs. Auction-ID: A7-50834-66

USED SERRTECH M1 VERTICAL MACHINING CENTER Serial No.: M1.005.06 Year: 2006 Table Table dimensions: 1200 x 600 mm Spindle Spindle speed: 12,000 RPM Spindle taper: LV 40 Axes Axis stroke: X=1000 - Y=600 - Z=640 mm Tool magazine Tool changer: 30 tools Footprint Machine dimensions: 4450 x 2770 x H2450 mm Machine weight: 9,000 kg Equipped with 1 FANUC 18i-MB NC 1 HP pump 1 Chip conveyor Dimensions and weight 5000x2750xH2790mm - 1 pallet weight 9000 kg Auction-ID: A1-50950-69

• CNC machining centre • Serial number 0-250-06-1632 • Total installed power approx, 18 KW • Useful working area approx, 2750 x 1000 mm • Travelling way X-axis: 3455 mm, Y-axis: 1480 mm, Z-axis: 260 mm • Maximum travel speed in the axes direction x-y-z: 80-60-20 m/min • Tool magazine with 8 positions •  Electrospindle: power 7,50 KW-max, 24000 rpm, automatic tool change, for HSK F63 tool holder, liquid cooled • Milling / saw group with 1,50 KW motor • Saw unit to groove • Vertical drilling spindles in X-axis direction: 11 • Vertical drilling spindles in Y-axis direction: 8 • Horizontal drilling spindles in X-axis direction: 3 + 3 • NUM 1040 numerical control • Software Windows 95 / HOMAG WOODWOP • 6 consoles with 2 vacuum suction cups each • 6 lifting modules for heavy workpieces • BECKER KVT 3,100 vacuum pump with capacity 100 m ...

- Mobile bridge. - Total installed power approx. 40 KW. - Dimensions of the work table approx. 3650 x 1560 mm. - Z-axis travel: 250 mm. - Maximum workpiece height 150 mm. - Programmable maximum speed in x-y-z directions: 75 -75 -15 m/min. - Tool magazine with 10 positions. - Electrospindle: power 8.50 KW, automatic tool change, for HSK F63 tool holder. - Saw group for grooving in the direction of the X-axis. - Vertical holes in the x-axis direction: 9. - Vertical holes in the y-axis direction: 5. - Horizontal holes in the x-axis direction: 1 + 0. - Horizontal holes in the y-axis direction: 1 + 1. - Remote control panel. - 8 suction cups are included. - 2 x BECKER VTLF 2.250/0 vacuum pumps with a capacity of 244 m³/h each. - Cutting tools and accessories are included. - Operating conditions of this machine: unchecked. - This item is delivered loaded by truck. The cost ...

- Total installed power 31.50 KW. - Usable working area approx. 2910 x 1310 mm. - Passage height on panel 200 mm. - X-axis travel: 3100 mm, y-axis travel: 1750 mm, z-axis travel: 300 mm. - Programmable maximum speed in x-y-z directions: 25-25-15 m/min. - Tool magazine with 8 positions. - HSD ES919 electrospindle: 8KW-max power. 24000 rpm, automatic tool change, for ISO 30 tool holders. - Grooving saw group. - ISAC SAB 2001 E numerical control. - Windows software. - 6 benches. - 4 lifting modules for heavy parts. - 1 x BECKER U 4.165 SA/K vacuum pump with a capacity of 160 m³/h. - 1 x BECKER KVT 3.140 vacuum pump with a capacity of 132 m³/h. - 1 x PUSKA air tank, capacity 150 litres. - Operating conditions of this machine: unchecked. - This item is delivered loaded by truck. The costs of dismantling and loading are those that are specified as additional costs. Auction- ...

• Serial number AA1/013786 • Working table dimensions 3050 x 1200 mm • Panel passage height 280 mm • Travelling way X-axis: 4420 mm, Y-axis: 1720 mm, Z-axis: 400 mm • Maximum travel speed in the axes direction x-y-z: 105-80-25 m/min • Tool magazine with 12 positions •  Electrospindle: power 11 kW, max, 18000 rpm, automatic tool change, for HSK F63 tool holder, liquid cooled • Saw unit with 2,20 kW motor • Vertical drilling spindles in X-axis direction: 5 • 2 heads for horizontal drills • NUM POWER 1040 numerical control • Software Windows / Xilog Plus • RIETSCHLE VTB 250 vacuum pump with capacity 250 m³/h • Operating conditions of this machine: unchecked. • This item is delivered loaded on truck. Dismantling and loading costs are specified as additional costs. Auction-ID: A7-50834-34

Table size 900x560mm, 24 pieces tool holder (empty), 24kVa, with air filter Auction-ID: A1-50476-1

- Includes: - 6 JOUCOMATIC pneumatic cylinders. - Approximately 34 solenoid valves. - Pressure regulator with pressure gauge and filter. - Operating conditions of these items: unchecked. - This item is delivered loaded by truck. The costs of dismantling and loading are those that are specified as additional costs. Auction-ID: A7-50834-69

- Includes: - 2 control pedals, transformers, resistors, relays, limit switches, power supply, valves and various accessories. - Operating conditions of these items: unchecked. - This item is delivered loaded by truck. The costs of dismantling and loading are those that are specified as additional costs. Auction-ID: A7-50834-65

x-travel:800 mm y-travel:410 mm z-travel:510 mm control:Fanuc 10 MA rapid travel x/y/z:20/20/15 mm/min table surface area:1100 x 450 mm tool taper:BT 40 tool magazin::30 BT 40 max. tool length:250 mm max. tool weight:8 kg power requirement:7,5/5,5 kW turning speed range:6000 1/min weight of the machine ca.:6,3 t Under offer is a complete CNC tool shop, which will be given up due to old age of owner. The Mori Seiki is still highly accurate. All existing tool holders, tools, drills, vices etc. come with the machine. All measuring devices also come with the machine. Upon request orders for parts to be made can be passed on to new owner. This is a low cost all inclusive opportunity for a "Startup"

x-travel:1100 mm y-travel:600 mm z-travel:510 mm control:Heidenhain iTNC 530 table-size:1050 x 600 mm table load:500 kg spindle taper:SK 40 turning speeds:10000 1/min power capacity at 100 % load:9 kW rapid travel x/y/z:24 m/min feed:24 m/min Tool changer:40 SK 40 dimensions of the machine ca.:4,3 x 2,6 x 2,25 m weight of the machine ca.:8,8 t POS mill 1100 vertical machining center in very good condition from 2009 Options: - parts measuring M&H receiver without probe - external hand wheel Heidenhain HR 410 - Air supply through spindle - air gun - paperfilter system with coolant through spindle 40 bar -

x-travel:1400 mm y-travel:1200 mm z-travel:1350 mm control:MSX- 701 Mapps III table surface area:800 x 800 mm rapid traverse:50 m/min table rotating:360.000 x 0,001 B-Achse ° table load:2,0 t numbers of pallets:2 turning speed range:8000 1/min power capacity - milling spindle:37 kW no. of tools in the magazine:60 Stück tool taper:HSK-A 100 weight:31 t dimensions:5,9 x 3,48 x 3,68 m Equipment: - Thru-the-spindel coolant system Mayfran Consep 2000 70 bar with chipconveyor - Helical cutting + Synchronized tapping - Parts program memory 1 MB - Knoll 70 bar high pressure and filter system - Electrostatic oil dust collector LTA - elect. hand wheel - renishaw probe - abso- scale i X/Y/Z- axis - 5 free m- funktions - 48 extra off sets - dual ballscrews on X/Y/Z- axis

x-travel:560 mm y-travel:560 mm z-travel:660 mm control:Celos Siemens 840D SL Operate ERGOline Multitouch turning speeds:20 - 20.000 1/min spindle drive:25/ 35 kW max. torque on the spindle:86 / 130 tool taper:HSK-A63 Number of tool station:60 diameter of tools max.:70 mm Tool diameter with no neighbouring tools:170 mm tool length - max.:450 mm weight of tools max.:12 kg numbers of pallets:2 Pallet dimension:400 x 400 mm max. workpiece diameter:630 mm workpiece height max.:900 mm table load:400 kg rapid travel x/y/z:60 m/min Feed x/y/z:60 m/min internal coolant system feed:70 bar weight of the machine ca.:8,5 t dimensions:3200 x 4800 x 2900 mm Renishaw probe (spindle):Vorbereitung / preparation only Horizontal machining center with Siemens - Celos control, full b-axis, tool magazine with 123 pos. HSK-A 63, coolant through spindle 40 bar. The machine has just received a new milling spind ...

x-travel:630 mm y-travel:600 mm z-travel:650 mm control:MSC 502 (Fanuc 16) Spindle RPM:12000 1/min spindle drive:22 / 18,5 kW rapid travel x/y/z:32 m/min Pallet dimension:500x500 mm numbers of pallets:2 table load:0,5 t working diameter:max. 610 mm Number of tool station:60 BT40 max. tool length:360 mm max. tool weight:12 kg tool changing time:1,3 sec B-axis positioning (non continuous):1 total power requirement:50 kVA weight of the machine ca.:14 t dimensions of the machine ca.:3,3 x 5,8 x 3,2 m spindle load monitor:Typ C This horizontal machining center comes with a pallet changer with 2 pallets, and has the following options: ATC 60 tool stations, High pressure coolant trough spindle interface,

x-travel:630 mm y-travel:630 mm z-travel:630 mm control:Unipro 90 Pallet changer 2x:400 x 500 workpiece - installed height:800 mm max. clampable workpiece diameter:720 - 850 mm spindle taper::SK 40 spindle turning speed - stepless:10 - 8000 1/min Spindle power:20 / 30 kW Spindle Torque:95/143 Nm tool magazin::80 SK 40 total power requirement:55 kW weight of the machine ca.:11 t Machine with Unipro 90 control for 5 axis - twin palette changer - tool magazine 80 HSK-A 63 - coolant device with coolant through spindle 7 pressure levels - full A & B-axis - chip conveyor

x-travel:600 mm y-travel:580 mm z-travel:530 mm distance spindle center to column:630 mm distance spindle center to table:100-600 mm milling feed range:1-10.000 mm/min max. table load:200/100 kg max. tool weight:8 kg positioning accuracy:+/- 0,01 mm :8000/15000 1/min spindle drive:7,5/11,5 /5,5 kW repeating accuracy:+/- 0,008 mm weight of the machine ca.:7,4 / 7,65 t Brand-new CNC vertical machining center with CNC control FANUC or HEIDENHAIN Warranty: 12 months More information can be found in the Appendix.

x-travel:1000 mm y-travel:1150 mm z-travel:700 mm table-size:900 mm table load:1500 kg spindle speeds:10.000 1/min spindle drive:Motorspindel von Cytec CS34-180-A 34&42KW/160&200 Nm spindle taper:A100 HSK T-slots:18mm/7/100 mm milling feed range:20.000 mm/min rapid traverse feeds:X/Y/Z: 24 m/min diameter of tools max.:150 mm workpiece length:300 mm weight of tools max.:20 kg weight of the machine ca.:15 t dimensions of the machine ca.:s. Katalog m CNC controller:Heidenhain iTNC-640 HSCI-Steuerung cnc rotary table:von Cytec; mit Ø900mm; 800 1/min Drehmomenttisch (AS3347) + HSK-T63/100 Spindel & ATC + TNC-640 Fräsdrehzahlregelung B-axis:Fräskopf, 0-180° c-axis:0,001° automatic tool changer:HSK-A/T100; 60 fach Scales:in X/Y/Z von Heidenhain mit Druckluft inner coolant:20

x-travel:630 mm y-travel:560 mm z-travel:560 mm weight of the machine ca.:6,5 t Number of axles:5 St. spindle turning speed range:18.000 U/min numbers of tools in magazin:24 tool taper:SK 40 Round Table B-Axis

x-travel:800 mm y-travel:400 mm z-travel:350 mm total power requirement:44 kW weight of the machine ca.:8,8 t dimensions of the machine ca.:6,1 x 4,1 x 3,3 m tool taper:HSK63 number of spindle speeds:36-12.000 Number of tools:2 x 21 St. rotary table diameter:1340 mm

x-travel:600 mm y-travel:770 mm z-travel:675 mm A-Axis travel:-180 ... +45 ° b-axis:360,000 ° spindle drive:40 / 52 (100% / 40% ED) kW spindle turning speed range:10000 U/min Tool bore:HSK-A63 numbers of tools in magazin:40 total power requirement:47 kW weight of the machine ca.:13 t including additional tool magazine ZM 182 1 spindle , 5 axes

x-travel:630 mm y-travel:630 mm z-travel:500 mm number of spindle speeds:0 - 15000 spindle motor:32 kW size of pallet:500 x 500 mm b-axis:36000 x 0,001 ° no. of workpieces in the magazine:61 Stück tool taper:HSK 63 weight of the machine ca.:15 t Single-Spindle Mechanical processing cylinder head VR6

x-travel:1000 mm y-travel:800 mm z-travel:1100 mm weight of the machine ca.:20 t dimensions of the machine ca.:6,80 x 3,0 x 3,20 m Tool bore:SK50 Tool taper:HSK-A 100 turning speed range:45-6.000 U/min size of pallet:630x800 mm change time of pallets:21 sec Mechanical processing of cylinder heads and cylinder crankcases Machines have been in single-shift operation since 2013 Service and maintenance intervals were adhered to

x-travel:1000 mm y-travel:800 mm z-travel:1100 mm weight of the machine ca.:15,2 t Tool bore:SK50 Tool taper:HSK-A 100 turning speed range:45-6.000 U/min size of pallet:630x800 mm change time of pallets:21 sec Mechanical processing of cylinder heads and cylinder crankcases Machines have been in single-shift operation since 2013 Service and maintenance intervals were adhered to

spindle speed::max. 12000 tool taper:HSK 80 . b-axis:360 x 0,001 ° worktool support (A-axis):+40 / -95 ° weight of the machine ca.:25 500 Kgs. x-travel:800 mm y-travel:700 mm z-travel:630 mm dimensions of the machine ca.:6200 x 3000 x 3200 mm pallet size::500 x 500 mm no. of tools in the magazine:61 Nos. Weight approx.:23,5 t Horizontal Machining Center with CNC Control System SIEMENS 840 C in well maintained condition. Single spindle

x-travel:800 mm y-travel:950 mm z-travel:1020 mm weight of the machine ca.:17 t dimensions of the machine ca.:6 x 3 x 3,2 m Diameter of the table:770 mm max. table load:800 kg tool taper:HSK-A63 max. tool length:465 mm no. of tools in magazin:60 spindle turning speed range:12.000 U/min feed power:8 kN kp power capacity:25/35 kW 5 axis G550-1024 HSK A-63 Grob (Bezeichnung G550-1024) 1 spindle
