135,040 used machines on RESALE, but how to find them? Machine Search
used
Manufacturer: REIDEN Model: BFR 24 Type of machine: 5-axis universal machining center Year of construction: 2011 Condition: very good condition Technical Details - Controller: Siemens 840D sl - Axes: 6 axes, simultaneous machining possible - Travel paths: X 4000 mm, Y 1000 mm, Z 1200 mm - B-axis: plus or minus 120 degrees - C-axis: 360 degrees - Spindle: SK50 recording, power 45 kW, speed up to 7,000 rpm - Tool magazine: 320 slots - Tool holders: approximately 500 SK50 tool holders - Pallet changer: with 3 pallets - IKZ: 70 bar - Measuring probe: Blum measuring probe - Fixed table: 1600 x 2350 mm - Magnetic and vacuum clamping plate: 1050 x 2240 mm - Chip conveyor included - Various hydraulic lines renewed in 2023 Find more here - .ucymachines/ Contact us at - sales@ucymachines
This 3-axis Huron KX20 vertical machining centre was manufactured in 2002. It features an impressive X-axis travel of 1,200 mm, Y-axis travel of 900 mm, and Z-axis travel of 500 mm. With a spindle speed of 18,000 RPM and a tool magazine with 30 positions, this machine is designed for high-speed performance in molds, dies, and aerospace components. If you are looking to get high-quality machining capabilities, consider the Huron KX20 machine we have for sale. Contact us for further details.
200623,792 h11 mapprox. 12,100 mmapprox. 2,350 mmapprox. 800 mm+/- 98°Rotary axis45 m/min24 m/min10,000 mm/minWater-cooled, rated power 20 kW from 12,000 rpm, integrated swivel and rotary axis, left/right rotationInfinitely variable up to 24,000 rpmBWO 930, in mobile control desk34 kW400 V / 50 Hz24 V80 A5 bar100 barTravelling gantry design with drive on both sides (gantry drive)HydraulicFor aluminium sheets / plates10 support traverses, 4 hydraulically swivelling workpiece stops, NC support-traverse positioningCoolant spray system with minimum-quantity mistingNC data format; 3D data converted via STEP files and CAD/CAM software08.12.20222019-2023: milling motor and Z-axis ball screw replaced; hollow shaft drive incl. brake replaced; safety screens renewed; harmonic drive replaced; Z-axis motor replaced; water recooling unit renewed; new oil mist extraction; controller assembly and X/U- ...
A Reichenbacher CNC 5-axis twin-head machining center for the door manufacturing industry is available. Spindle power: 15kW, Speed: 24000rpm, Tool interface: HSK-F63, Tool positions: 60, Milling spindle spacing: 1040mm, Spindle housing dimension: 150mm, Travel X/Y/Z: 5100mm/2100mm/2650mm, Tool change stroke: 550mm, Max. travel speed X/Y/Z: 60m/min/90m/min/20m/min, Clamping beam speed: 40m/min. Vacuum support rails: 2, Vacuum cups: 2×30, Stop stroke: 150mm, Stop pin diameter: 30mm, Through-feed stop 1/2: 300mm/700mm, Max. veneer overhang: 5mm, Max. veneer thickness: 5.5mm. Workpiece length range: 800mm-3200mm, Workpiece width range: 600mm-1400mm, Workpiece thickness range: 38mm-72mm, Max. workpiece weight: 200kg. Chip conveyor belt width: 700mm, Infeed roller conveyor dimensions X/Y: 6000mm/1600mm, Outfeed roller conveyor dimensions X/Y: 6350mm/1600mm. Overall system dimensions X/Y/Z: ap ...
x-travel: 650 mm y-travel: 650 mm z-travel: 680 mm dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
As good as new (until 2 years ago) top model of the Accord series. Operating hours are absolutely real and include a week of SCM training on the machine. There is no record from SCM that the machine has ever given an error message after commissioning. Approx. 80 vacuum suction cups + device for compressed air clamps. CNC Machining Center SCM Type accord 40 fx Offer type: Used machine General condition: very good - as good as new, already dismantled! Availability: immediately Location: in the warehouse Year of manufacture: 2023 - 126 operating hours Working field X-Y = 6360 x 1905 mm, Z = 350 mm OF0158 Usable clearance height Z = 350 mm with H50 suction cups OF0165 Axis travel speed of Accord 40 fx version PRO-SPEED OF0168 Pendulum operation OF0169 Automatic lubrication of axles OF0299 TELESOLVE remote maintenance via 450328 eye-M PRO control console with integrated ...
A Primacon CNC high-precision vertical machining center for machining small workpieces in the medical sector is available. Axis travels X/Y/Z: 240mm/240mm/240mm, table dimensions X/Y: 350mm/300mm, max. table load: 60kg, spindle speed: 40000rpm, tool holder: HSK-25, feed rate: 12m/min, rapid traverse: 12m/min, positioning accuracy: +/-0.001mm, repeatability: +/-0.0005mm. Machine dimensions X/Y/Z: approx. 1900mm/1600mm/2200mm, weight: approx. 1000kg, control: Heidenhain. The spindle is occasionally not clamped correctly during the tool change process. The ventilation hose of the Z-axis rubs against the A-axis block. Documentation available. An on-site inspection is possible.
travel -x axis: 600 +50 mm travel -y axis: 500 mm travel -z axis: 500 mm c-axis: 360 ° b-axis: -5 / +110 ° surface area: d: 500 x 380 mm control: Siemens 840D sl number of spindle speeds: 20 - 14.000 U/min tool taper: SK40 5-axis simultaneous machining center | DMG - DMU 50 eVo linear equipped with NC Drehschwenkrundtisch, tool changer, ITC and chip conveyor. Additional equipment: - probing system - 3D QuickSet - tool measurement The machine is in a well-maintained condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: DMU60Evo | DMU60 Evo | 60Evo The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
CONTROLS CNC controls HEIDENHAIN MILL PLUS WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 5 X-axis travel: 500 mm Y-axis travel: 420 mm Z-axis travel: 380 mm SPINDLE / HEAD spindle revolutions (max): 18000 /min tool fixture: HSK A63 AXIS DRIVES feed velocity (max): 20000 mm/min rapid traverse: 50000 mm/min TOOL MAGAZINE number of positions: 60 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 2500 mm space requirements -front/back-: 2600 mm total height: 2440 mm total weight approx.: 6000 kg ATTACHMENTS zero-point workholding system: yes chip conveyor: yes coolant unit: yes band filtration unit: yes through spindle coolant attachment: yes closed cabin: yes European CE standards: yes Total spindle h ...
SW BA 222iYear of manuf. : 2022 Control : Siemens 840 Dsl Movement X/Y/Z : 200/350/300 mmTool holder : HSK 40 ____________Description:In General:Year of manufacture:2022Control system:Siemens 840 DslTravel ranges X/Y/Z:200/350/300 mmSpeed:25,000 rpmTool holder:HSK 40Spindle:Technology:2 motorised spindlesSpindle centre distance:200 mmSpeed:25,000 rpmTool holder:HSK 40Double-swivel mount:Technology:A-axis or U-axis with counter-bearingDrive:Direct drive (torque motors)Loading module:Technology:Industrial robotsManufacturer:FanucModel:LR Mate 200iDGripper:Double gripperWorkpiece marking:Needle embossing station (DMC)Workpiece feed:Technology:L-shaped infeed and outfeed conveyorWorkpiece carriers:20Dimensions:190 x 150 x 15Workpiece capacity:20Dimensions:220 x 160 x 240 mmEquipment:Tool magazine:40 positions (2 × 20)Position measurement systems:Direct on all axesChip removal:Chip con ...
A Deckel Maho 5-axis CNC universal machining center is offered, including an Interlit compact filtration system for the coolant supply. 1) Deckel Maho DMU 70 eV 5-axis CNC universal machining center, year of manufacture: 2003, X/Y/Z travels: 750mm/600mm/520mm, B-axis: approx. 180°, C-axis: 360°, rapid traverse X/Y/Z: 50m/min, feed rate: approx. 20m/min, max. spindle speed: approx. 18000rpm, spindle power: approx. 25kW, max. rated power: approx. 35kW, spindle torque: approx. 87Nm, tool holder: SK40, table dimensions X/Y: approx. 700mm/500mm, max. table load: approx. 200kg, tool magazine: 32, weight: approx. 8500kg. 2) Interlit SUK 200-900 compact filtration system, year of manufacture: 2003, filter area: 0.2m², filling volume: 900l. Inspection by prior arrangement is possible.
DMF260/11 → Year of manufacture: 2011 Heidenhain TNC 530 Spindle SK 40 – 18,000 rpm Machine hours: 54,877 Spindle hours: 21,845 Condition: second-hand However, it is currently still in use and will be available in 2027 Find more here - .ucymachines/ Contact us at - sales@ucymachines
CONTROLS CNC controls ROEDERS WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 3 .. among of them simultaneous CNC axes: 3 X-axis travel: 500 mm Y-axis travel: 450 mm Z-axis travel: 300 mm SPINDLE / HEAD spindle revolutions (max): 42000 /min tool fixture: HSK A40 TOOL MAGAZINE number of positions: 40 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 3500 mm space requirements -front/back-: 3000 mm total height: 2750 mm total weight approx.: 9500 kg ATTACHMENTS zero-point workholding system: yes central lubrication system: yes closed cabin: yes European CE standards: yes Equipment: - Renishauw OMP400 - Megatool base clamping plate - Control update 2022 Special features: - Hydrostatic X, Y & Z axes - Coordinate grindi ...
max. workpiece length: 4500,6000 mm profile spindle: 4 Stück main drive: 30 kW Weinig Conturex C226 Machining Center ---------------------------------------------- For sale on behalf of a client, includes software (Klaes) and tooling (Oertli) for IV68/IV78/IV92 and Wood/Alu 68–92 systems. Machine still is electrically connected. Technical specifications and window cross-sections available upon request! ---------------------------------------- Price of the above-mentioned machine available upon request! ---------------------------------------- Dismantling and reinstallation available upon request! (Technical specifications provided by the manufacturer – subject to change/no liability assumed!) All prices are net, plus statutory VAT. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 1016 mm y-travel: 610 mm z-travel: 760 mm total power requirement: ? kW weight of the machine ca.: 7,5 t dimensions of the machine ca.: 4 x 3 x 3,2 m Table clamping surface 1,270 x 590 mm max. table load 1,350 kg feed rate 15,000 mm/min rapid traverse 20 m/min Tool holder ISO 40 24-position tool changer Chip conveyor IKZ Preparation for IR - measuring probe ( Renishaw ) SELCA control The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 800 mm y-travel: 900 mm z-travel: 620 mm Control: Heidenhain TNC 640 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Milling-turning machining center The machine is being sold in a defective condition. The rotary tilting table needs to be repaired. Spindle torque: 253NM / 12000min-1 / HSK 63 Travel paths: 800/900/620mm Control: Heidenhein TNC 640 Turning function: 4000Nm / 750rpm / diameter 800mm / max. 2000kg Pallet changer: 6-pos, Pallet weight max 1 ton (pallet + workpiece) Tool changer: 60 places (expandable to 120 places) incl. spare spindle incl. pallets optional: 4-jaw chuck SMW Autoblok Operating hours: 3469 h (Jan. 2025) X-axis travel: 800 mm Y-axis travel: 900 mm Z-axis travel: 620 mm X-axis rapid traverse: 50 m/min Y-axis rapid traverse: 50 m/min Z-axis rapid traverse: 50 m/min Torque: 253 Nm Control manufacturer: Heidenhein ...
x-travel: 1600 mm y-travel: 1250 mm z-travel: 1600 mm B-axis (table): 360.000 x 0,001° deg milling-head swivable +/-: (HV) 360.000° deg pallet size:: 1000 x 800 mm table load: 3000 kg tool taper: SK 50-B Plananlage 125 spindle turning speed range: max. 8000 U/min transmission ratio: 2 spindle drive: (100/40 % ED) 37/50 kW feeds x/y/z -stepless: 30000 mm/min max. torque on the spindle: 1410/2000 (100/40 % ED) Nm total power requirement: 100 kVA weight of the machine ca.: t dimensions of the machine ca.: 11555 x 7998 x 5050 mm Universal machining center 5 axes simultaneously Original purchase price: EUR 1.295.000,- First machine installation in September 2011. A geometry measurement report (dated 30. August 2025) is available. Equipment: CNC-control Siemens 840D Solution Line Separate handheld control unit, wired, Siemens HT-2 2-station pallet changer with safety light barrier 110-posit ...
travel -x axis: 1800 mm travel -y axis: 520 mm travel -z axis: 520 mm tool taper: SK 40 table load: 3 t tool piece magazine with: 30 Plätze spindle drive: 22 kW max. torque on the spindle: 220 Nm Machine in very good condition + Loading door windows have been replaced + Linear guide carriages on X and Y axes have been replaced - Heidenhain iTNC 426-M control system - Partition wall for pendulum operation - Chip conveyor - Filter system - Spindle up to 8000 rpm - Rapid traverse x/y/z: 30/30/30 m/min - Year of manufacture 2001 Control on: 93212:52:14 Machine on: 82284:39:36 Program run: 42385:36:11 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 2000 mm y-travel: 500 mm z-travel: 500 mm Control: Siemens 840 D feeds - fine adjustment: 1-8000 mm/min table-size: 2120 x 500 mm table load capacity: 2000 kp rapid traverse X-axis: 40 m/min rapid traverse Z-axis: 20 m/min tool taper: HSK 63 A spindle turning speed - stepless: 0-15000 U/min spindle motor: 20 kW spindle bearing diameter: 70 mm tool diameter: 63 /126 mm tool magazin:: 40 Stk weight: 12 t total power requirement: 65 kVA weight of the machine ca.: t dimensions of the machine ca.: m X-axis travel: 2,000 mm Y-axis travel: 500 mm Z-axis travel: 500 mm Control system: Siemens 840 D Feed rate (fine adjustment): 1 – 8,000 mm/min Table size: 2,120 × 500 mm Table load capacity: 2,000 kg Rapid traverse (X-axis): 40 m/min Rapid traverse (Z-axis): 20 m/min Tool holder: HSK-A63 Spindle speed range (infinitely variable): 0 – 15,000 rpm Spindle drive: 20 kW Spindle bearing ...
x-travel: 640 mm y-travel: 600 mm z-travel: 500 mm Control: SIEMENS 810D powerline table dimensions: 850 x 630 mm table load capacity: 600 KG tool magacine with: 30 Plätzen spindle turning speed range: 12.000 U/min total power requirement: 42 kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 3,50 x 3,30 x 3,60 m Tool breakage / measurement BLUM Electronic handwheel 3 leveling elements chip conveyor coolant / belt filter system Interlit SPB 3/600 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 1000 mm y-travel: 800 mm z-travel: 800 mm control: SIN840D speeds: 10 - 10.000 U/min feed range: 1 - 36000 mm/min B - axis: 360 x 1 ° repeating accuracy: + / - 3 surface area: 2 x 500 x 630 mm tool diameter: 100 mm workpiece length: 650 mm workpiece weight max.: 40 kg tool taper DIN 69871: SK 50 workpiece weight: 800 kg tool magacine with: 100 Plätzen wotkpiece diameter with 2 vacant positions: 325 mm Chip to chip time: ca. 8,00 sec. change time of pallets: ca. 12,00 sec total power requirement: 65,00 kW weight of the machine ca.: 20,00 t dimensions of the machine ca.: 7,80 x 3,50 x H3,40 m Horizontal machining center with SIEMENS SIN840D control. NC-rotary table, chip conveyor, coolant-unit, coolant through the spindle Magazine with 2 cassette à 50 pockets. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 730 mm y-travel: 730 mm z-travel: 880 mm total power requirement: 46 kW weight of the machine ca.: 15 t required space: 5.5x3.0x2.8 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 1016 mm y-travel: 610 mm z-travel: 760 mm total power requirement: ? kW weight of the machine ca.: 7,5 t dimensions of the machine ca.: 3 x 2,5 x 3,2 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 760 mm y-travel: 460 mm z-travel: 560 mm control: Sinumerik 840 D PL - Shop total power requirement: 19/28 kW weight of the machine ca.: 13 t dimensions of the machine ca.: 12 Lademeter m Movie: https://www.youtube.com/watch?v=W7csFFlodrQ No. 4100 Bar machining center 5 axes DECKEL MAHO DMC 60 S Working area: 760 x 460 x 560 Drive: 19/28 kW Control: Sinumerik 840 D - Powerline Shopmill NC swivel milling head (B-axis) -120/+30° 60-fold tool magazine with taper cleaning NC rotary axis (A-axis) with collet chuck Spanntop 65, Tailstock, hydraulically lowerable, NC bar loader 1100 mm Workpiece pick-up device with discharge belt Production package with coolant tank 600 l, INTERLIT SKA 200-760 - IKZ 40 bar through spindle center Chip conveyor, Rotating inspection window BLUM tool measuring system Oil mist extraction Operating mode 4 HSK-A 63 spindle Speed range up to 18,000 min-1 Fe ...
x-travel: 640 mm y-travel: 600 mm z-travel: 500 mm control: Siemens 840 D total power requirement: 19 kW weight of the machine ca.: 8 t dimensions of the machine ca.: 5 x 4 x 3 m No. 5312: Vertical machining center DECKEL MAHO type DMC 64 V linear year of construction 2007 Working area: 640 x 600 x 500 mm Drive power: 13/19 kW Equipment: Table 850 x 600 mm ( WITHOUT the clamping devices shown ) Preparation 4th axis Production package / IKZ 40 bar: BFA 600 cooling lubricant cleaning system Integrated spiral chip conveyor Separate scraper belt chip conveyor documentation Miscellaneous: Spindle ISO 40 Speed range 1-12,000 min-1 Space requirement see sketch Transport dimensions approx. 6.5 loading meters Weight approx. 8.8 tons The machine is ready for operation with wear and tear due to age and use. Short video: https://www.youtube.com/watch?v=sDkgx4BYXeY Special price ex works EXW - free l ...
max. workpiece length: 4400 mm profile spindle: 1 Stück main drive: 19,2 kW Control: Beckhoff CNC machining center MASTERWOOD 4 WIN --------------------------------------------------------- Specially designed for a rational and flexible wooden window u. door production HIGHLIGHTS: - Different tool magazines for optimal tool loading - Simultaneous loading of 4 workpieces - Patented clamping system for optimal processing of the workpieces - CNC controlled work table with automatic positioning of beams and Stretcher - Automatic re-clamping for changing between external and internal profiling - INTEGRATED window construction software, i.e. the machine does not have to (but can of course) can be controlled from the office with external industry software. - strong motor with 19.2 kW HSK-63 E Please note that this stock machine is with us in Oberkochen and is already equipped with many useful ...
CONTROLS CNC controls HEIDENHAIN ITNC 620 WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 3 .. among of them simultaneous CNC axes: 3 X-axis travel: 1000 mm Y-axis travel: 550 mm Z-axis travel: 550 mm TABLE table surface (left-right): 1100 mm table surface (front-back): 550 mm workpiece load (max): 800 kg SPINDLE / HEAD spindle type: vertical spindle revolutions (max): 10000 /min tool fixture: ISO SK 40 drive power: 13.5 kW AXIS DRIVES feed velocity (max): 10000 mm/min rapid traverse X: 36000 mm/min rapid traverse Y: 36000 mm/min rapid traverse Z: 36000 mm/min TOOL MAGAZINE magazin type: disc magazine number of positions: 30 tool diameter max.: 76 mm tool length max.: 250 mm tool weight max.: 6 kg ELECTRICAL SPECIFICATIONS mains power supply: 15 kVA DIMENSIONS / WEIGHTS ...
CONTROLS CNC controls SIEMENS 840 D SL WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 X-axis travel: 210 mm Y-axis travel: 270 mm Z-axis travel: 360 mm SPINDLE / HEAD spindle revolutions (max): 40000 /min tool fixture: HSK A40 TOOL MAGAZINE number of positions: 64 AUTOMATIC WORKLOAD EQUIPMENT workpiece manipulator: articulated robot number of store positions: 32 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS total weight approx.: 9000 kg ATTACHMENTS chip conveyor: yes coolant unit: yes band filtration unit: yes closed cabin: yes Operating hours: Spindle 1: 4050 h, Spindle 2: 11,114 h Internal cooling 70 bar Fanuc Automation Robot M-10IA Integrated workpiece changing device Knoll coolant tank Knol KF 400/900
CONTROLS CNC controls SIEMENS 840D SL 4.8 WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 4 X-axis travel: 210 mm Y-axis travel: 270 mm Z-axis travel: 360 mm SPINDLE / HEAD spindle revolutions (max): 40000 /min tool fixture: HSK A40 TOOL MAGAZINE number of positions: 72 AUTOMATIC WORKLOAD EQUIPMENT workpiece manipulator: articulated robot number of store positions: 36 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 8500 mm space requirements -front/back-: 2500 mm total weight approx.: 6000 kg ATTACHMENTS central lubrication system: yes chip conveyor: yes coolant unit: yes through spindle coolant attachment: yes European CE standards: yes -Siemens tool management with retooling -Fanuc Automation Robot M-10IA ...
x-travel: 1270 mm y-travel: 508 mm z-travel: 635 mm control: Haas table surface area: 1320 x 457 mm rapid traverse: 20 m/min table load: 800 kg turning speed range: 7500 1/min power capacity - milling spindle: 11 kW no. of tools in the magazine: 20 Stück tool taper: SK 40 weight of the machine ca.: 6,2 t dimensions: 3,8 x 2,8 x 2,8 m Vertical machining center CSM 2 A control system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
INDEX G 200 ist ein CNC Dreh-Fräs-Bohrcenter, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Kapazitäten: Drehdurchmesser 200 mm, Drehlänge 400 mm, Spindelbohrung 42 mm, Spindeldurchlass 60 mm; 2 Spindeln, 2 Revolver (14 Pos./Kopf, 14 angetriebene Werkzeuge). Technische Daten: Oberer Revolver X155 Y±60 Z400, unterer X105 Z400; Drehzahlen bis 6300 min-¹; Spindelleistung 20/29 kW, Spindelmotor 39 kW; angetr. Werkzeuge 5,5 kW; Gegenspindel 13/22 kW, Hub 445 mm; Eilgänge X23 Z45 Y8 m/min; Gewicht ~4800 kg; Abmess. 2500×2400×2700 mm. Zubehör: LNS MINI-SPRINT S2-42 Belader (Stangen bis 4000 mm), 3-Backenfutter, 2 Spannzangenfutter, Satz Spannzangen, Lampe, Werkzeugschrank, RS232, Werkstückentferner, Späneförderer, Bandförderer, Fußschalter, Werkzeughalter, rotierendes Sichtfenster. Erreicht enge Toleranzen; geeignet für Automotive, Luftfahrt, Medizintechnik, U ...
INDEX G 200 COMPACT is a CNC Dreh-Fräs-Bohrcenter, für Präzision, hohe Genauigkeit und Zuverlässigkeit. Kapazitäten: Ø200 mm, Länge 400 mm, Spindelbohrung 65 mm, Stangenlänge bis 3200 mm. Daten: 2 Spindeln, 2 Revolver (14 Pos.), bis 6000 min-¹, angetr. Werkz. 5,5 kW, Eilgang X23/Z45/Y8 m/min, Leistung 40 kW, Gewicht 4280 kg, Abm. 2500×2000×2200 mm. Zubehör: Satz Spannzangen, Lampe, Ölnebelabsaugung, LNS HYDROBAR SPRINT, Späneförderer, RS232, ZOLLER. Für enge Toleranzen; Automotive, Uhren, Werkzeugbau, Luftfahrt, Med. Technische Daten ohne Gewähr
CARNAGHI PIETRO AFT 16 TM/SH ist ein CNC Dreh-, Fräs- und Schleifzentrum, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Kapazität: Planscheibe Ø1000 mm, Schwingdurchmesser 1650 mm, Drehhöhe 1100 mm; X ±1010, Y 600, Z 1250, C 360°. Werkzeugmagazin 40 Plätze, 2 Paletten, Tischbelastung 3000 kg. Daten: Fräsgeschw. 10–3000 t/min (31 kW, 1000 Nm); Tisch 5–800 t/min (60 kW); Vorschub 0.1–3000 mm/min; Eilgang 10 m/min; 3×400V 50Hz; Gesamtleistung 196 kW; Gewicht ~35000 kg. Zubehör: Kühlmitteleinrichtung, Satz Werkzeughalter, Späneförderer, Palettenwechsler. Für enge Toleranzen; geeignet für Automotive, Luftfahrt, Medizintechnik. Technische Daten ohne Gewähr
NZX 1500/800SY ist ein CNC Dreh-Fräs-Bohrcenter mit hoher Präzision, großer Genauigkeit und Zuverlässigkeit. Kapazitäten: 2 Drehspindeln, 2 Revolver, Schwingdurchmesser 800 mm, max. Drehdurchmesser 320 mm, Stangendurchmesser max. 52 mm; Verfahrwege Z 810 mm, X 210 mm, Y 110 mm (je Schlitten). Technische Daten: Drehzahlen 0–6000 t/min, Spindelleistung 22/18.5 kW, Leistung angetriebene Werkzeuge 7.5/5.5 kW, Spindelnase JIS A2-5, Spindelbohrung 61 mm; Eilgänge X 30 m/min, Z 50 m/min, Y 20 m/min; Maschinengewicht ~8100 kg; Abmessungen L4396×B2835×H2320 mm. Zubehör: direktes Messsystem X-Achse, Beleuchtung, Kühlmitteleinrichtung, Kühlmittel durch die Gegenspindel, Lader-Schnittstelle, Teilefänger, Teileförderband, Späneförderer. Erreicht enge Toleranzen; geeignet für Automotive, Luftfahrt, Medizintechnik, Uhrmacherei und Maschinenbau. Technische Daten ohne Gewähr
INDEX ABC 65 ist ein CNC Dreh-Fräs-Bohrcenter von INDEX, ausgelegt für hohe Präzision, Genauigkeit und Zuverlässigkeit. Kapazitäten: 2 Spindeln, 2 Revolver; Spindelbohrung 65 mm; Spindeldurchmesser 140/110 mm; Verfahrwege Z300 X140 Y100 mm; Revolverpositionen 10/9 (Rückseite 8). Daten: Hauptspindel stufenlos 0–6000 min-¹, 25/35 kW, Drehmoment 80/120 Nm; Gegenspindel 6000 min-¹, 5/9 kW; angetriebene Werkzeuge 7.5/9 kW; Schaft 45 mm; Indexzeit 0,4 s; Eilgänge X30/Z50 m/min; Anschluss 3x400 V 50 Hz; Gesamtleistung 41 kW; Gewicht ~6500 kg; Maße 3600×1280×1950 mm. Zubehör: Kühlmittel 300 l, Hochdruck 80 bar, Papierfilter, Beleuchtung, Spannzangenaufnahme, USB, Förderband, Späneförderer, Werkzeughaltersatz. Erreicht enge Toleranzen; geeignet für Automotive, Uhrmacherei, Luftfahrt, Medizintechnik und Werkzeugbau. Technische Daten ohne Gewähr
MAZAK INTEGREX 400-3S ist ein CNC Dreh-Fräs-Bohrcenter, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Arbeitsraum: Spitzenweite 1500 mm, Drehdurchmesser 760 mm, Drehlänge 1524 mm, Stangendurchmesser 102/77 mm, Werkzeugmagazin 40 Plätze (Ø max 90 mm, L 400 mm). Technische Daten: Hauptspindel A2-8 stufenlos 35–3300 t/min 30 kW 1200 Nm; Gegenspindel A2-8 35–4000 t/min 26/22 kW 500 Nm; Frässpindel CAPTO C6 15–12000 t/min 18.5 kW 120 Nm. Verfahrwege X630 Y±115 Z1585 mm; Vorschub 0–8000 mm/min; Eilgang X/Z 38 m/min Y26 m/min; Gewicht ~13300 kg; Aufstellfläche 5110x2196 mm; Höhe 2798 mm. Zubehör: Kühler 444 l (15 bar Frässpindel), Forkhardt 3-Backenfutter Ø400/315 mm, Linearmaßstab X, RS232, PCMCIA, Späneförderer, synchrones Gewindebohren, Fußpedal. Erreicht enge Toleranzen; Branchen: Automotive, Luftfahrt, Medizintechnik, Maschinenbau, Uhren. Technis ...
INDEX G 160 ist ein CNC Dreh-Fräs-Bohrcenter für hohe Präzision, Genauigkeit und Zuverlässigkeit. Kapazitäten: 2 Spindeln, Drehdurchmesser 200 mm; 3 Revolver je 10 Positionen (unterer Revolver 10). Techn.: 6000 t/min, stufenlos 0–5000 t/min, Spindel 27 kW, angetr. Werkzeuge 8 kW, C-Achse Auflösung 0,001°, Anschluss 3×400 V, Gesamtleistung 43 kW; Gewicht ~7500 kg; Abm. 3200×2100×2100 mm. Zubehör: Späneförderer, Fußpedal. Eignet sich für enge Toleranzen; Branchen: Automotive, Luftfahrt, Medizintechnik, Uhrenbau, Maschinenbau. Technische Daten ohne Gewähr
OKUMA MAC TURN 350-W ist ein CNC Dreh-Fräscenter mit 2 Spindelstöcke, ausgelegt auf Präzision, hohe Genauigkeit und Zuverlässigkeit. Kapazitäten: Dreh-Ø 530 mm (über Planschlitten), 550 mm (über Bett); Spindelbohrung 62 mm; Drehlänge 1625 mm; Z 1670 mm, X 505 mm, Y ±95 mm (190 mm). Daten: 9 Achsen; C-Achse 360° Auflösung 0,001°; B-Achse Schwenk 210° Auflösung 1°; Spindeldrehzahl bis 5000 t/min; Fräserdrehzahl 6000 t/min; Spindelmotor 22/15 kW. Zubehör: Werkzeugwechsler 44 Plätze, Späneförderer. Ermöglicht enge Toleranzen; Anwendungen: Automotive, Luftfahrt, Medizintechnik und Präzisionsfertigung. Technische Daten ohne Gewähr
WILLEMIN MACODEL 408S2 ist ein Bearbeitungs- und Drehzentrum für Stangen mit hoher Präzision, hoher Genauigkeit und Zuverlässigkeit. Verfahrwege X 250 mm, Y 200 mm, Z 310 mm; B-Achse -100°/+30°; Auflösung 0.0001; Stangendurchmesser Ø32 mm; Werkzeugmagazin 24 Plätze; Werkzeuglänge 95 mm, Gewicht max 1 kg; Werkzeugwechsel 0,8 s; Ø bei freien Nachbarplätzen 80 mm. Spindelaufnahme HSK E-25, stufenlos bis 75'000 t/min; Anschluss 50 Hz 3x400 V; Gesamtleistung 16 kVA; Maschinengewicht ca. 2300 kg; Abmessungen L1840 x B2450 x H1385 mm. Ausstattung: Werkstücktaster Renishaw OMP 40-2, Werkzeugbruchkontrolle BLUM Nano NT, Kühleinrichtung, Ölnebelabsaugung, Kühlmittelfilter, Feuerlöschanlage. Erreicht enge Toleranzen; geeignet für Uhrenindustrie, Medizintechnik, Luftfahrt, Automotive und Werkzeugbau. Technische Daten ohne Gewähr
SCHAUBLIN 202 TG-CNC W25-0127 ist ein CNC Dreh-Fräs-und Schleifzentrum für Präzision, hohe Genauigkeit und Zuverlässigkeit. Kapazitäten: 3 Achsen, Spitzenhöhe 60 mm, Z 300 mm, X 150 mm, Spannzangendurchlass 19 mm (W25), Auflösung 0,0001 mm, C-Achse 0,0001°. Daten: Spindel bis 7000 min-¹, Leistung 5/6 kW, Drehmoment 26,1/35,1 Nm, Eilgang 20 m/min, Anschluss 3×400 V 50 Hz, Gewicht ~3000 kg, Abmessungen 1930×1300×2040 mm. Zubehör: Kühlung, Ethernet, Späneförderer, Teilefänger, Lader LNS Express 112+, Spülpistole, Feuerlöschanlage. Ermöglicht enge Toleranzen; Branchen: Automotive, Uhrenbau, Werkzeugmaschinen, Luftfahrt, MedTech. Technische Daten ohne Gewähr
max. workpiece length: 4100 mm profile spindle: 8 Stück main drive: 16 kW Control: SIEMENS Working Process Wooden Window Production Line -------------------------------------------------- Sale on behalf of the client, ex-site. System can be viewed while still in operation! System comprising: Item 1: Infeed conveyor following the planer (planer NOT included) Item 2: Working Process Sapiens, Year of Mfg. 2011 (end-grain milling and drilling) - Spindle 1: 10 kW, HSK-E63, A/C-axis - Spindle 2: 10 kW, HSK-E63, A/C-axis - Spindle 3: 16 kW, HSK-E63, C-axis - Spindle 4: 16 kW, HSK-E63, C-axis Item 3: Transport system to LOGOS SCH Item 4: Working Process LOGOS SCH, Year of Mfg. 2008 (end-grain and longitudinal milling and drilling) - Spindle 1: 16 kW, HSK-E63 - Spindle 2: 16 kW, HSK-E63, C-axis - Spindle 3: 10 kW, HSK-E63, C-axis, A-axis - Spindle 4: 3 kW, fixed configuration, for 2 tools (e.g., ...
5 Axis CNC Turning and Milling Center Okuma Multus B550-C 2000 Control: OSP-P300SA-H Year of Make: 2019 Internal machine no. 71 Travels: X-axis: 925 mm Y-axis: 520 mm Z-axis: 2,215 mm Center width: 2,000 mm Turning Ø over bed: 830 mm Spindle bore: 112 mm Tool holder HSK-A100 40-fold tool changer Programmable tailstock with hydraulic quill Facilities - Hinged belt chip conveyor Interlit ISF - Full-clamping cylinder - 6-Jaw Power Chuck SMW Ø 500 IEP - - Hand Dishwashing Gun - Drum – trough filter TMF300/980/20 - IFS filter system IFE 5000 - Robot interface Type E - One Touch IGF - Software for input fineness 0.1μm - Software package for simultaneous 5-axis machining VTM-1200YB and VTM-2000YB - In process measuring with Renishaw probe for X/Z-C axis - Automatic zero point displacement in the z-axis main spindle - High-precision C-axis - Rotation funct ...
Version: T1-T1C-T5C-T6CN2, tool magazine: RACK T95, number of tool positions: 95, workpiece dimensions for parts longer than 3500mm: width: 50-140mm, thickness: 50-92mm, tool identification: chip, Balluff, extraction hoods: automatic movement for machining long parts, control: Siemens 840 D SL. Equipment: transport system, 1x motorized roller conveyor, 6000mm with pusher device. Loading system: motorized roller conveyor, length: 3880mm, with single pusher device, 2x motorized central structure, with driven belts, 3000x2000mm, speed: 15m/min, power: 0,37kW, 1x small motorized central structure, with driven belts, 1500x2000mm, speed: 15m/min, power: 0,37kW, 1x liftable roller conveyor, length: 3800mm, power: 0,37kW, 1x liftable roller conveyor, length: 2290mm, power: 0,37kW. Parking system: 1x motorized roller conveyor, length: 3070mm, with single pusher device, speed: 60m/min, power: 0,37 ...
5-axis machining center Hedelius ACURA 65 Control: TNC 640 Year of Make: 2017 Internal machine no. 72 Travels: X-axis: 700 mm Y-axis H / V: 650 / 465 mm Z-axis: 600 mm Swivel table: Ø 650 x 540 mm Swivel range: +30° to -115° Interference circle diameter: Ø 700 mm Table load: 500 kg Mount: DIN 69893-1 HSK-A63 Tool magazine: 65 – compartment Spindle speed: 50 - 18,000 rpm ZeroClamp 4-way 3D Probe M&H 25.50 5-axis simultaneous machining ACURA Handheld control unit HR 250 3D Mold Making Coordination ACURA KinematicsOpt TNC640 Collision Monitoring ACURA/TNC Compressed air on the spindle head Coolant system 1250l IKZ 25bar Chip conveyor Exhaust air filter Laser light barrier for tools ACURA
This 3-axis FORMAT4 c-express 920 classic was manufactured in 2018. It features a maximum workpiece dimension of 3000 mm in the X direction and 920 mm in the Y direction, with a robust clamping collet system for CNC through-feed technology. The machine is equipped with 6 vertical and 9 horizontal drilling spindles, allowing for versatile drilling, sawing, and milling operations. If you are looking to get high-quality wood machining capabilities, consider the FORMAT4 c-express 920 classic machine we have for sale. Contact us for further details.
X-axis: 640mm, Y-axis: 600mm, Z-axis: 500mm, feed force (40% duty cycle) X-, Y-, Z-axis: 7000N, max. feed speed X-, Y-, Z-axis: 40m/min, rapid traverse speed Y-, Z-axis: 40m/min, rapid traverse speed X-axis: 70m/min, ball screw diameter/pitch Y-, Z-axis: 40/15mm, number of magazine pockets: 30, position coding: fixed-position coding, max. tool loading weight: 90kg, max. diameter of standard tools: 100mm, max. diameter of special tools with adjacent positions free: 140mm, max. tool length: 300mm, max. tool weight: 6kg, table clamping surface: 850x600mm, T-slots: DIN 650-14, loading height (top edge of table): 850mm, max. load: 600kg, connected load: 39kVA, control: Heidenhain iTNC 530, length: 2500mm, width: 4100mm, height: 3000mm, weight: 7,74t, operating hours: 60.366h. With documentation.
BUDERUS CNC 235 – CNC Grinding and Machining Center Machining / Spindle 2 machining areas / channels Max. machining length: 150 mm Max. swing diameter: Ø 310 mm Workpiece spindle speed: 0–3,000 rpm Spindle bore: Ø 45 mm Workpiece spindle positioning via C-axis Table speed X/Z: 0–30 m/min Motor Spindle WMZ / DVS Type: GS 205-045/17 Year of manufacture: 2014 Automation Automatic workpiece feed / conveyor system Coolant / Filtration System LIQUI-Filter GmbH System: UR1060 / MW260 / Gamma 13 Tank capacity: 2,400 l Year of manufacture: 2015 Cooling System HYFRA gamma 13-F-S Cooling capacity: 13 kW at 32 °C Year of manufacture: 2015 Measuring Technology JENOPTIK post-process measuring technology Year of manufacture: 2018 Supply Data 3 × 400 V / 50 Hz Installed power: approx. 45 kW Compressed air requirement: 15 Nm³/h at 5 bar
Key data: 1020 mm, 510 mm, 560 mm
For sale; Etasis Etamill VL-1000 machining center in very good condition. Equipped with cooling by the spindle, The latest Fanuc control 0i Plus with Manual Guide i, chip conveyor, Renishaw TS27R, etc.
A KERN 5-axis CNC machining center with EROWA Robot Compact is offered. Travel X/Y/Z: 500mm/500mm/400mm, simultaneous 5-axis machining, hydrostatic guideways in the X and Y axes, swivel range: -10° to +110°, feed rate X/Y/Z: 30m/min, max. acceleration: 10m/s², max. spindle speed: 40000rpm, spindle power: 37kW, max. torque: 12000rpm, tool taper: HSK-E40, tool magazine: 50, tool change time: approx. 3s, control: Heidenhain iTNC 530 smart.TNC, laser tool measurement, workpiece touch probe, EROWA PowerChuck P, EROWA Robot Compact year of manufacture 2013 with 70 magazine positions, including 55 positions ITS 72 and 15 positions ITS 148, max. transfer weight pallet incl. workpiece: 30kg, automatic loading and unloading of the magazine also possible during machining, machining medium: oil, belt filter system and max. high-pressure supply 80bar, oil mist extraction system and fire extinguish ...
This 5-axis Hamuel Reichenbacher ECO-NT was manufactured in 2011. It features a working envelope of 4,845 mm and 5,440 mm in the X-axis, 1,630 mm in the Y-axis, and 1,000 mm in the Z-axis. The machine is equipped with a powerful spindle speed of up to 60,000 rpm and a versatile tool changer with 12 positions. If you are looking to get high-quality milling capabilities, consider the Hamuel Reichenbacher ECO-NT vertical machining centre we have for sale. Contact us for further details.
