double arm used for sale

pressure:200 t distance between columns:1100 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1100 mm table surface area:1000 x 1000 mm pressure of drawing cushion in table:63 t stroke of drawing cushion in table:250 mm die cushion area:800 x 750 mm table height over floor:800 mm ram surface:1000 x 1000 mm Speed down:400 mm/s speed up:250 mm/s working speed:22 - 56 mm/s power requirement:45,0 kW weight:24,0 t dimensions (WxDxH):2,4 x 1,5 x 5,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic

pressure:200 t stroke:30 - 160 mm no. of strokes:40 - 120 /min distance between columns:1500 mm distance between oil collecting pans:1300 mm distance table/ram, max. stroke up, adjustment up:860 mm hole in the table:550 x 300 mm table surface area:1250 x 1250 mm table height over floor:1000 mm column travel -side:600 x 530 mm ram surface:1250 x 1000 mm ram adjustment:125 mm Material width of feeder:30 - 500 mm Material thickness feeder:0,5 - 3,0 mm feeding length:0 - 999,9 mm power requirement:50,0 kW weight:34,0 t dimensions (WxDxH):4,0 x 1,7 x 5,2 m clutch-/ brake combination:pneumatisch, Ortlinghaus overload protection in ram:hydraulisch ram adjustment:automatisch stroke adjustment:automatisch ram counterbalance:pneumatisch roll feed:Weingarten, WE 60 Option: NEW electrical controls:Siemens S7-1500 F

pressure:500 t distance between columns:1220 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1600 x 1200 mm pressure of drawing cushion in table:320 t stroke of drawing cushion in table:150 mm drawing cushion surface in table:750 x 625 mm pressure of drawing cushion in ram:180 t stroke of drawing cushion in ram:100 mm drawing cushion area in ram:750 x 625 mm ram surface:1600 x 1200 mm table height over floor:800 mm speed down:665 mm/s speed up:530 mm/s working speed:34 - 100 mm/s quantity of oil:2000 l power requirement:180,0 kW weight:40,0 t Dimensions (WxDxH):3,2 x 2,4 x 7,5 m Depth of foundation pit:4,1 m Height above floor:5,55 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:315 t distance between columns:1750 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:1200 mm table surface area:1600 x 1500 mm pressure of drawing cushion in table:125 t stroke of drawing cushion in table:200 mm die cushion area:1200 x 1400 mm table height over floor:750 mm ram surface:1640 x 1500 mm power requirement:55,0 + 11,0 kW weight:29,5 t dimensions (WxDxH):3,2 x 4,5 x 5,8 m Height above floor:5,1 m German Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 drawing cushion in table:hydraulisch cutting impact absorption:hydraulic

Pressure:63 t distance between columns:1000 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:850 mm table surface area:980 x 500 mm table height above floor:850 mm ram surface:130 mm speed down:400 mm/s speed up:461 mm/s working speed:14 - 97 mm/s power requirement:15,0 kW Weight:5,0 t Dimensions (WxDxH):2,0 x 1,6 x 3,9 m depth stop:mechanical foundation pit:not necessary

Pressure:160 t distance between columns:1250 mm stroke:500 mm distance table/ram, max. stroke up, adjustment up:700 mm Table area:1200 x 800 mm table height over floor:850 mm die cushion pressure in table:63 ? t die cushion stroke in table:200 mm die cushion area:780 x 650 mm side window:300 mm ram surface:1000 x 800 mm speed down:400 mm/s speed up:400 mm/s working speed:106 mm/s oil volume:1800 l power capacity:2 x 30,0 kW weight:16,7 t Dimensions (WxDxH):2,45 x 2,35 x 4,5 m

Pressure:150 t stroke:fix 80 mm no. of strokes:30 - 150 /min distance between columns:930 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:880x1300/1500x600 mm hole in the table:760 x 180 mm table height over floor:1270 mm column travel -side:650 mm ram surface:920x1000/1300x600 mm weight:27,5 t Dimensions (WxDxH):3,1 x 1,8 x 4,3 m WITHOUT feeder:can be offered optionally

pressure:100 t distance between columns:770 mm stroke:400 mm distance table/ram, stroke up:800 mm Table area:770 x 900 mm table height above floor:850 mm die cushion pressure in table:40 t die cushion stroke in table:200 mm die cushion area in table:600 x 600 mm side window:600 mm ram surface:770 x 900 mm speed down:62 mm/s speed up:350 mm/s working speed:17,5 mm/s oil volume:700 l power requirement:42,0 kW weight:9,0 t Dimensions (WxDxH):2,6x 2,0 x 3,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic

pressure:315 t distance between columns:1800 mm stroke:400 mm Distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1800 x 1000 mm table height over floor:900 mm die cushion pressure in table:80 t die cushion stroke in table:100 mm Die cushion area in table:1300 x 600 mm side window:600 mm ram surface:1800 x 1000 mm speed down:400 mm/s speed up:300 mm/s working speed:15 - 80 mm/s oil volume:1700 l power requirement:55,0 kW weight:27,5 t dimensions (WxDxH):3,1 x 2,2 x 4,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 die cushion in table:hydraulic foundation pit:not necessary

pressure:320 t distance between columns:1530/1370 mm stroke:320 mm distance table/ram, stroke up:830 mm table surface area:1500 x 650 mm die cushion pressure in table:12,5 t table height over floor:1100 mm side window:570 mm ram surface:1240 x 650 mm capacity of ejector in table:12,5 t speed down:450 mm/s speed up:440 mm/s working speed:63,6 mm/s oil volume:2100 l power requirement:2 x 45,0 kW weight:27,0 t dimensions (WxDxH):4,0 x 2,3 x 4,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic drawing cushion in ram:hydraulic ram interlocking:hydraulic Option: NEW electrical controls:Siemens S7-1500 F

pressure:160 t distance between columns:1580/1360 mm stroke:320 mm distance table/ram, max. stroke up, adjustment up:830 mm table surface area:1460 x 850 mm table height over floor:1100 mm side window:870 mm ram surface:1400 x 850 mm speed down:540 mm/s speed up:520 mm/s working speed:26 - 85 mm/s oil volume:2100 l power requirement:45,0 kW weight:22,6 t dimensions (WxDxH):4,0 x 2,3 x 4,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:hydraulisch

pressure:160 t distance between columns:1600/1420 mm stroke:345 mm distance table/ram, max. stroke up, adjustment up:830 mm table surface area:1460 x 850 mm table height over floor:1100 mm side window:770 mm ram surface:1410 x 850 mm speed down:540 mm/s speed up:520 mm/s working speed:26 - 85 mm/s oil volume:2100 l power requirement:45,0 kW weight:23,0 t dimensions (WxDxH):4,0 x 2,3 x 4,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:hydraulisch

pressure:620 t distance between columns:2250 mm stroke:1250 mm Distance table/ram, max. stroke up, adjustment up:1600 mm table surface area:2200 x 1280 mm ram surface:2200 x 1500 mm table height over floor:800 / 1000 mm column travel -side:750 mm feed down:10 - 250 mm/sec feed up:10 - 500 mm/sec working feed:1 - 24 mm/sec oil volume:2000 l power capacity:45,0 + kW weight:42,0 t Dimensions (WxDxH):3,7 x 2,6 x 6,8 m German Safety: permitted for manual loading:CE-sign foundation pit:not necessary

pressure:120 t distance between columns:430 mm stroke:125 mm distance table/ram, stroke up:400 mm table surface area:430 x 450 mm table height over floor:860 mm side window:230 mm ram surface:250 mm working speed:10 mm/s power requirement:11,0 kW weight:2,5 t dimensions (WxDxH):1,6 x 1,3 x 2,4 m German Safety: permitted for manual loading:CE-sign

Pressure:250 t stroke:30 mm no. of strokes:60 - 500 /min Distance between columns:1500 mm distance table/ram, max. stroke up, adjustment up:390 mm table surface area:1580 x 1100 mm hole in the table:1270 x 300 mm table height over floor:1470 mm side window:600 mm ram surface:1500 x 900 mm ram adjustment:100 mm material width:500 mm material thickness:0,5 - 1,5 mm coil weight:6,5 t coil internal diameter:420 - 560 mm coil external diameter:1500 mm power capacity:45,0 kW Weight:44,0 t Dimensions (WxDxH):3,3 x 1,8 x 4,5 m clutch:pneumatisch ram adjustment:motorisch double decoiler:LH 2-1,5-500 straightening machine:R 500 roll feed:mechanisch; Schuler, WK 8-500

pressure:500 t distance between columns:1910 mm stroke:500 mm Distance table/ram, max. stroke up, adjustment up:700 mm table surfache without cutting impact cushions:1910 x 1360 mm table surfache with cutting impact cushions:1600 x 1360 mm table height over floor:800 mm ram surface:1600 x 1270 mm Side window:600 mm speed down:400 mm/s speed up:330 mm/s working speed:10 - 28 mm/s oil volume:1200 l power requirement:60,0 kW weight:40,0 t Dimensions (WxDxH):3,6 x 2,5 x 5,0 m height over floor:4,5 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 cutting impact cushioning:hydraulic ram interlocking:hydraulic

pressure:200 t distance between columns:1400 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:1300 x 1100 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:150 mm die cushion area:700 x 700 mm capacity of ejector in ram:10 t ejector stroke in ram:50 mm table height over floor:930 mm side window:770 mm ram surface:1300 x 1100 mm speed down:400 mm/s speed up:410 mm/s working speed:20 - 50 mm/s return capacity:30 t oil volume:1350 l power requirement:70,0 kW weight:23,0 t dimensions (WxDxH):4,5 x 3,0 x 3,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic ejector in ram:hydraulic foundation pit:not necessary

Pressure:1000 t distance between columns:4100 mm stroke:1200 mm Distance table/ram, stroke up:2100 mm Table surface area:4000 x 2200 mm pressure of drawing cushion in table:360 t Die cushion stroke in table:300 mm Die cushion area in table:3500 x 1600 mm Die cushion pressure in ram:100 t Die cushion stroke in ram:160 mm Die cushion area in ram:3250 x 1600 mm Ram surface:4000 x 2200 mm Side window:1300 mm Oil volume:8000 l Power capacity:300,0 kW Dimensions (WxDxH):5,75 x 4,3 x 9,55 m Height above floor:7,7 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact cushioning:hydraulic

Pressure:1600 t distance between columns:4100 mm slide stroke:1450 mm Distance table/ram, stroke up:2750 mm distance table/blank holder, stroke up:2200 Table surface area:4000 x 2200 mm ram pressure:1000 t Pressure of blank holder:600 t stroke of blankholder:1000 mm blank holder surface:4050 x 2200 mm Ram surface:3200 x 1650 mm pressure of drawing cushion in table:360 t Die cushion stroke in table:300 mm die cushion area:3500 x 1600 mm Side window:1100 mm Oil volume:9000 l Power capacity:390,0 kW Weight:250,0 t Dimensions (WxDxH):5,95 x 4,3 x 10,5 m Height above floor:8,6 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable

Pressure:800 t distance between columns:3250 mm stroke:1100 mm Distance table/ram, stroke up:1900 mm Table surface area:3100 x 1900 mm pressure of drawing cushion in table:300 t Die cushion stroke in table:300 mm Die cushion area in table:2500 x 1800 mm Die cushion pressure in ram:80 t Die cushion stroke in ram:200 mm Die cushion area in ram:2200 x 1000 mm Ram surface:3100 x 1900 mm Side window:900 mm Oil volume:4700 l Power capacity:200,0 kW Dimensions (WxDxH):4,95 x 3,3 x 10,2 m Height above floor:7,05 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact absorption:hydraulic

Pressure:800 t distance between columns:2560 mm stroke:1050 mm Distance table/ram, stroke up:1870 mm Table surface area:2500 x 1730 mm pressure of drawing cushion in table:300 t Die cushion stroke in table:395 mm Die cushion area in table:2300 x 1300 mm Ram surface:2500 x 1730 mm Die cushion pressure in ram:63 t Die cushion stroke in ram:150 mm Side window:1000 mm Oil volume:4300 l Power capacity:200,0 kW Dimensions (WxDxH):4,1 x 2,8 x 10,0 m Height above floor:7,0 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable

Pressure:600 t distance between columns:2600 mm stroke:900 mm Distance table/ram, max. stroke up, adjustment up:1600 mm Table surface area:2500 x 1730 mm pressure of drawing cushion in table:250 t Die cushion stroke in table:400 mm Die cushion area in table:2300 x 1300 mm Die cushion pressure in ram:63 t Die cushion stroke in ram:160 mm Die cushion area in ram:1900 x 1300 mm Ram surface:2500 x 1730 mm Side window:1100 mm Oil volume:3500 l Power capacity:200,0 kW Dimensions (WxDxH):4,1 x 2,8 x 9,6 m Height above floor:6,4 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact absorption:hydraulic

Pressure:800 t distance between columns:3550 mm stroke:1100 mm Distance table/ram, max. stroke up, adjustment up:1900 mm Table surface area:3500 x 1800 mm pressure of drawing cushion in table:350 t Die cushion stroke in table:280 mm Die cushion pressure in ram:80 t Die cushion stroke in ram:160 mm Ram surface:3500 x 1800 mm Side window:1900 mm Weight:100,0 t Floor Space (WxD):5,3 x 4,3 m Height above floor:7,3 m Height below floor:5,0 - 6,0 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact cushioning:hydraulic sliding table:without rails for moving table

pressure:500 t stroke:fix 300 mm no. of strokes:20 - 70 Hub/min distance between columns:3100 mm side window:1400 mm distance table/ram, max. stroke up, adjustment up:1000 mm Table area:2800 x 1600 mm ram surface:2800 x 1450 mm ram adjustment:100 mm power requirement:90,0 kW weight:100,0 t Dimensions (WxDxH):5,75 x 3,2 x 7,8 m height above floor:6,4 m height beneath floor:1,4 m clutch:pneumatic; Ortlinghaus ram adjustment:motoric overload protection in ram:hydraulic ram counterbalance:pneumatic

pressure:160 t distance between columns:1360 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1300 x 900 mm table height over floor:950 mm side window:640 mm ram surface:1300 x 900 mm power requirement:45,0 kW weight:16,0 t Dimensions (WxDxH):2,5 x 2,1 x 4,1 m cutting impact cushioning:hydraulic

pressure:600 t distance between columns:3640 mm stroke:350 mm no. of strokes:11 - 44 /min Distance table/ram, max. stroke up, adjustment up:1550 mm table surface area:3600 x 2500 mm sliding table:3600 x 2500 mm ram surface:3600 x 2500 mm Side window:2200 mm ram adjustment:400 mm material width coil line:500 - 1950 mm Material thickness at 1200 mm material width:0,6 - 2,5 mm Material thickness at 1850 mm material width:0,6 - 2,0 mm Material thickness at 1950 mm material width:0,6 - 1,75 mm Coil weight:35,0 t coil internal diameter:610 mm coil external diameter:900 - 1900 mm no. of straightening rolls:13 straightening roll diameter:50 mm Stack height:400 mm stacking dimensions - station 1+2 (L x W):150-2000 x 250-2000 mm stations:2 power requirement:112,0 + 35,0 kW Weight:390,0 t Dimensions (WxDxH):7,3 x 5,1 x 15,0 m Height above floor:9,1 m Height below floor:5,9 m clutch-/ brake combinat ...

pressure:315 t distance between columns:1290 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:950 mm table surface area:1250 x 1100 mm pressure of drawing cushion in table:125 t stroke of drawing cushion in table:300 mm die cushion area:900 x 900 mm Capacity of ejector in ram:20 t Stroke of ejector in ram:250 mm table height over floor:800 mm ram surface:1250 x 1100 mm oil volume:1200 l power requirement:40,0 kW weight:22,0 t dimensions (WxDxH):2,6 x 1,6 x 5,2 m height over floor:4,05 m drawing cushion in table:hydraulic ejector in ram:hydraulic cutting impact cushioning:hydraulic

pressure:315 t distance between columns:2350 mm distance table/ram, max. stroke up, adjustment up:1200 mm distance between cutting impact cushioning:1600 mm Distance table/ram, stroke up:1200 mm stroke:800 mm table surface area:2060 x 1260 mm table height over floor:750 mm Die cushion pressure in table:100 t Die cushion stroke in table:400 mm die cushion area:1250 x 1000 mm side window:780 mm ram surface:2200 x 1500 mm Capacity of ejector in ram:63 t speed down:500 mm/s speed up:310 / 410 mm/s working speed:20 - 73 mm/s quantity of oil:3900 l power requirement:80,0 + 45,0 kW weight:55,0 t Dimensions (WxDxH):4,6 x 2,7 x 7,2 m Height above floor:6,0 m Height below floor:1,2 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 die cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:hydraulic cutting impact absorption:hydraulic

Pressure total: 250 ton Ram stroke: 70 / 250 mm Slide adjustment: 160 mm Ejector in ram: 20 ton Ejector stroke in ram: 10 mm Shut height (stroke down, adjustment up): 520 mm Free lateral opening F-B: 1.300 mm Table surface area : 1.600 x 1.600 mm Slide area: 1.600 x 1.600 mm Number of strokes: 0 - 50 s.p.m. Required power: 33 kW Height over floor approx.: 5.500 mm Weight of machine approx.: 58 ton Roll feeder Material width: 1250 mm Material thickness: 0,3 - 1,6 mm Control: Siemens S7
