dorries scharmann used for sale

spindle diameter: 180 mm x-travel: 5000 mm y-travel: 3000 mm bore spindle stroke: 1000 mm ram stroke: 1000 mm dimension of the ram: 425 x 425 mm spindle taper ISO: 50 spindle turning speed - stepless: 3 - 1600 U/min feed stepless: 0 - 10000 mm/min table surface area: 3500 x 2500 mm table rotating: 360 ° table load: 50 t power capacity: 90 kW rapid traverse: 10 m/min table travel: 2500 mm table height: 1450 mm total power requirement: kW weight of the machine ca.: 125 t dimensions of the machine ca.: 11x12x6,3 m + completely electrically overhauled with new motors in 2012 and equipped with a new control Heidenhain iTNC 530! + NC-turn table 3500 x 2500 mm - 50 to cap. + ATC 60-fold + Cooling unit + chip conveyor + angle clamping plate 2400x1700x1200 mm + mecahincally and electrically in top condition! + The data for this ad was created with ModulMWS - the software solution of LogoTech o ...

x-travel: 2000 mm y-travel: 2000 mm z-travel: 1400 mm spindle stroke: 1000 mm turning speeds: 5-800 U/min Radial face slide: 700 mm Radial face slide: 2,2-115 U/min spindle taper ISO: 50 table surface area: 2000x1800 mm Table load: 14000 kg total power requirement: 42 kW weight of the machine ca.: 24,5 t dimensions of the machine ca.: 6,3x5x4,3 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 7000 mm, 1600 mm, 800 mm

Complete system with all the accessories necessary for installation and operation, Travel x = 7000 y = 1600 z = 800 / transverse stroke w = 600mm / General overhaul 2007, year of production 1991: New Siemens Sinumerik 840D control system, new drive motors, guide guides refurbished, new control cabinets. ECOCUT 1 was then operated for only a few months / Travel speed 12000 mm / min / w axis 6000 mm / min turntable TDV 2 max. workpiece weight 6t / clamping surface 1000x1000 turntable TDV 3 max. workpiece weight 12t / clamping surface 1250x1600 Accessories: 2 like new angle crank / chain tool change system / plate field / complete housing / Knoll hopper feed / suction / coolant system with belt filter All BWF fixators for the installation of machine bed and plate

SCHARMANN HEAVYCUT 2 WFT 150 CNC Floor type Boring Mill Year 1978 Spindle Diameter: 5.9" (150mm) Milling Spindle Diameter: 11.02 (280mm) Spindle Taper: CAT 50 Ram Cross Section: 11.81" x 11.81" (300x300mm) Vertical Head Travel, Y-Axis: 137.79" (3500mm) Column Travel, X-Axis: 712.59" (18000mm) Quill Travel, Z-Axis: 23.43 (595mm) Ram Travel, W-Axis: 27.6" (700mm) Z & W Axis, Combined: 51.03" (1296mm) Spindle Speeds: 5.5-1000 RPM Spindle Feed Range: 0.003-240 IPM Rapid Traverse: 396 IPM Spindle Motor: 70 HP/ 105 HP EQUIPPED WITH: Heidenhain TNC 407 CNC Controls Ram and Spindle Travel Sliding Way Covers On X-Axis Bed Right Angle Head With 1 Degree Manual Indexing Hardened Ways Re-pained recently

faceplate diameter: 4500 mm swing diameter: 5000 mm turning height: 2645 mm Control: Siemens 840 D total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Equipment: CNC control Siemens Sinumerik 840 D Direct measuring system C-axis with extension of the workpiece measurement Hydrostatic guidance of the linear axes Workpiece measurement Tool measurement Tool and process monitoring ARTIS CTM system Workroom surveillance with video camera (at the support) Processing heads with automatic tool clamping UWFK 500 Nm, +/- 90° manually pivotable Various tool holders, type 300.2 Tool magazine 24 to 72 Platu magazine pick-up plate Loading crane for the tool magazine, load capacity 500 kg Loading device with HSK, capto-, KM tool holder Machine protection device Automatic cover of the chip chute Working area protection completely closed Preparation for installing a ...

Clamping table, clamping angle, T-slot table, round table, milling machine table, turning table, cross table, cross-sliding table, boring table -Manufacturer: Scharmann, clamping table drilling table rotatable -Table surface: 1400 x 1000 mm -Travel distance: 1200 mm -Grooves: 7 pieces 22 mm -Dimensions: see photo -Total dimensions: 3410/1350/H665 mm -Weight 4600 kg

Servo motor, electric motor, DC motor, stepper motor, stepper motor, stepping motor -Manufacturer: Scharmann, DC motor from a Scharmann table boring mill -Power: 3 - 11 kW -Speed: 220 - 3200 rpm -techn. Data: see photo nameplate -Shaft: Ø 45 x 104 mm -Construction: B3 -Dimensions: 1000/550 / H450 mm -Weight: 509 kg

Servo motor, electric motor, direct current motor, direct current generator, electric motor with direct current generator -Spare part: comes from a Scharmann boring mill -Manufacturer: Kessler, electric motor with direct current generators -Three-phase motor type: DM21-16 32 kW 2880 rpm -Gl.Strom Gen. Type: G 50/42/1 6/18 kW -Gl.Strom Gen. Type: G 44/14/2 8.2 kW -Technical data: see photos nameplates -Dimensions: 1750/580/H540 mm -Weight: 886 kg

spindle diameter: . mm x-travel: 2500 mm y-travel: . mm : The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Servo motor, electric motor, DC motor, stepper motor, stepper motor, stepping motor -Manufacturer: Scharmann, DC motor with tachometer dynamo and cooling fan -Engine: Type GLF 100/13 -Voltage: 170/200V -Power: 6.5 kW -Speed: 3000 rpm -Tachometer dynamo: Hübner TDP 0.2 T-4 60V 1000/max. 9000 rpm -technical Data: see photo of nameplate -Shaft: Ø 28 x 45 mm -Design: B5 -Dimensions: 640/250/H390 mm -Weight: 57 kg

Mobile milling machine for attachment, e.g. a lathe. As good as new, almost unused condition More data according to photos

swing diameter: 2800 mm turning height: 1195 mm Control: Siemens 840 D turning speeds: 224 U/min x-travel: +-1600 mm z-travel: 1100 mm machine table: diameter: 2500 mm workpiece weight: 25000 kg power capacity: 80 kW Torque: 35900 Nm total power requirement: kW weight of the machine ca.: 66,5 t dimensions of the machine ca.: m faceplate diameter: mm Dörries 6, Machine no. V-800293 - Fixed crossbeam, no tool drive Ram -Cross section of ram: 250 x 250 mm -Travel ram: 1100 mm Equipment/accessories: -Tool changer revolver 4-times in the ram -Own filter system -BRANKAMP monitoring -REXROTH hydraulic unit -Chip conveyor -Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

swing diameter: 2400 mm turning height: 2445 mm Control: Siemens 840 D feed range: 0-18000 mm/min table diameter: 2000 mm max. table load: 17000 kg total power requirement: 100 kW weight of the machine ca.: 75 t dimensions of the machine ca.: 10.000 x 5.500 x 7.100 mm Dörries 2, machine number V-800289 with hydraulical chuck, without milling function Crossbeam: -Travel crossbeam: 1000 mm (100 mm steps) -Crossbeam support travel: ± 1350 mm Ram : -Cross section of ram: 250 x 250 mm (minimum immersion diameter:380 mm) -Travel ram: 1500 mm Equipment/accessories: -No driven tools -Tool changer/head changer 72 times -Hydraulic chuck -BRANKAMP monitoring -REXROTH hydraulic unit -Chip conveyor -Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 75 mm x-travel: 850 mm y-travel: 900 mm z-travel: 950 mm spindle taper ISO: SK 40 table-size: 1000 x 800 mm total power requirement: 16 kW weight of the machine ca.: 10,5 t dimensions of the machine ca.: 4,0 x 2,3 x 2,75 m Included - 3-axis digital display - Operation manual The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

swing diameter: 1600 mm turning height: 1285 mm Control: Siemens 840 D turning speeds: 400 U/min x-travel: +- 950 mm z-travel: 1100 mm workpiece weight: 9000 kg power capacity: 80 kW Torque: 19900 Nm table diameter: 1400 mm weight of the machine ca.: 42 t dimensions of the machine ca.: 7600 x 5200 x 5400 mm Dörries 7, Machine number V-800294 Crossbeam: -Cross beam travel: 600 mm Ram: -Ram cross section: 250 x 250 mm (immersion diameter: 340 mm) -Ram travel 1100 mm Equipment/accessories: -Tool magazine -Own filter system -BRANKAMP monitoring -REXROTH hydraulic unit -Chip conveyor -Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Inv. Num. : 4003 Type: FB 100 S Producer: SCHARMANN Created: 1969 Parameters: Digital display range: NEVAL C 80 Digital Measurement: Rod Runner NEVAL Work table length: 1100 mm Work table width: 950 mm X-axis travel: 1000 mm Y-axis travel: 1045 mm Z-axis travel: 1000 mm Machine height: 2555 mm Machine length: 4285 mm Machine width: 2915 mm Machine weight: 17 t

Scharmann FB 100 boring machine Slides and table in excellent condition, no dents. Stroke: X 1300 mm Y 1200 mm Z 2000 mm Equipped with digital display on 3 axes. Work feed on table rotation. Machine weight: 25 tons With 6 tool pallets, clamping cube 1000 mm x 900 mm x 900 mm, and angular head.

x-travel: 1600 mm y-travel: 1200 mm z-travel: 1000 mm Control: Siemens type: 880 M size of pallet: 800x1000 mm numbers of pallets: 2 : 360 ° turning speeds: 5300 U/min Table load: 3000 kg spindle taper ISO: 50 Tool changer: Pos. w-axis: 600 mm chip conveyor: spindle diameter: 125 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: 8x7x4,2 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 2400 mm y-travel: 1000 mm z-travel: 1250 mm Control: Siemens type: 840 C size of pallet: 1250x800 mm numbers of pallets: 4 : 360 ° turning speeds: 4-5800 U/min Table load: 3000 kg spindle taper ISO: 50 Tool changer: 161 Pos. chip conveyor: spindle diameter: 130 mm milling drive: 45 kW total power requirement: kW weight of the machine ca.: 39 t dimensions of the machine ca.: 8x7x4,2 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Face plate diameter 1800 mm weight approx.: 15,000 kg, Approx. Onsite Dimension. (l x w x h): 4,800 x 4,000 x 4,600 mm

Description: horizontal floory type boring machine Spindle diameter 125 mm x-travel 5600 mm y-travel 1600 mm z-travel 800 mm Spindle stroke 600 mm Spindle mount ISO 50 Spindle speeds 12 - 3000 rpm Spindle motor 40 kW Rapid traverse speed 15 m/min with CNC HEIDENHAIN iTNC 530 modernized in 2003 Tool changer 60 times Drilling work table RÜCKLE 2000 x 1800 mm max. 20 tons. workpiece weight Clamping plates 3500 x 2000 mm, 2500 x 2000 mm Coolant device z-motion: 800 mm, spindle diameter: 125 mm, x-motion: 5,600 mm, y-motion: 1,600 mm, control: CNC Heidenhain iTNC 530 modernisiert in 2003, table surface area l x w : 2000x1800 mm, spindle taper: ISO 50, turning speed range: 12-3000 rpm, total power requirement: 65 kW, weight approx.: 60,000 kg, Approx. Onsite Dimension. (l x w x h): 12,100 x 4,800 x 3,900 mm

Description: Dörries single-column vertical lathe with 2.4 m swing diameter for turning, drilling and milling operations. Components can be completely machined in a single clamping operation. Control system and Machine number Control: SIEMENS Sinumerik 840 D Machine number: ,V-800292 Geometric main dimensions Machine table diameter: 2200 mm Maximum table load: 17 tonnes Rotation diameter: 2400 mm Working height: 2145 mm , Cross-section of ram slide: 250 x 250 mm (minimum dipping diameter: 380 mm) Travelling distance of ram slide: 1500 mm Crossbeam travel: 1000 mm (100 mm steps) Cross beam support Travelling distance: ± 1350 mm Tool change path: 720 mm Machine drive Drive power main drive: 100 kW Speed range in 2 gear stages: 1.3 - 250 rpm Feed drives , Horizontal and vertical cross beam support: 0 - 18000 mm/min Cross beam adjustment speed: 400  ...

Description: Dörries single-column vertical lathe with 2.4 m swing diameter and hydraulic clamping table. Control and machine number SIEMENS Sinumerik 840 D control system Machine number: V-800289 Geometric main dimensions Machine table diameter: 2000 mm Maximum table load: 17 tonnes Rotation diameter: 2400 mm Working height: 2445 mm , Cross-section of ram slide: 250 x 250 mm (minimum dipping diameter: 380 mm) Travelling distance of ram slide: 1500 mm Cross beam support Travelling distance: ± 1350 mm Crossbeam travel: 1000 mm (100 mm steps) Crossbeam travel (100 mm steps): 1000 mm Tool change path: 720 mm Machine drive Drive power main drive: 100 kW Speed range in 2 gear stages: 1.3 - 250 rpm Feed drives , Horizontal and vertical cross beam support: 0 - 18000 mm/min Cross beam adjustment speed: 400 mm/min Milling drive Milling drive power: 37 k ...

Description: Dörries Single-column Vertical Lathe with 2.4 m swing diameter for turning, drilling and milling operations. Components can be completely machined in a single clamping operation. Control system and Serial number Control: SIEMENS Sinumerik 840 D Serial number: ,V-800288 Geometric main dimensions Machine table diameter: 2200 mm Maximum table load: 17 tonnes Rotation diameter: 2400 mm Working height: 2145 mm , Cross-section of ram slide: 250 x 250 mm (minimum dipping diameter: 380 mm) Travelling distance of ram slide: 1500 mm Crossbeam travel: 1000 mm (100 mm steps) Cross beam support Travelling distance: ± 1350 mm Tool change path: 720 mm Machine drive Drive power main drive: 100 kW Speed range in 2 gear stages: 1.3 - 250 rpm Feed drives , Horizontal and vertical cross beam support: 0 - 18000 mm/min Cross beam adjustment speed: 400 mm ...

Description: Dörries single-column vertical lathe with 2.4 m swing diameter for turning, drilling and milling operations. Components can be completely machined in a single clamping operation. Control system and Machine number Control system: SIEMENS Sinumerik 840 D Machine number: V-800291 Geometric main dimensions Machine table diameter: 2200 mm Maximum table load: 17 tonnes Rotation diameter: 2400 mm Working height: 2145 mm , Cross-section of ram slide: 250 x 250 mm (minimum dipping diameter: 380 mm) Travelling distance of ram slide: 1500 mm Crossbeam travel: 1000 mm (100 mm steps) Cross beam support Travelling distance: ± 1350 mm Tool change path: 720 mm Machine drive Drive power main drive: 100 kW Speed range in 2 gear stages: 1.3 - 250 rpm Feed drives , Horizontal and vertical cross beam support: 0 - 18000 mm/min Cross beam adjustment speed: 40 ...

Description: Dörries VCE 2800 SM F Single-column Vertical Lathe with 2.8 m swing diameter. Control system SIEMENS Sinumerik 840 D Geometric main dimensions Swing diameter: 2800 Basic turning height with fixed crossbeam: 1335 Turning height including adjustment of the grid steps: 1935 mm Cross-section of chisel slide: 250 x 250 mm , Travelling distance of chisel slide: 1100 mm Fixed Crossbar Machine table Machine table diameter: 2500 mm Maximum table load: 25 tonnes Drive power main drive: 80kW Torque on machine table: 35900 Nm Speed range in 2 gear stages: up to 224 rpm Feed drives and Cutting forces Horizontal and vertical crossbeam support: 0 - 18000 mm/min Cutting force when turning: 19000 N Tool system Vertical 4-fold Capto C6 turret Please have a look at the technical data and the layout plans in the PDF file. turning height: 1,935 mm, swing di ...

Description: Dörries single-column vertical lathe with 2.4 m swing diameter. Control and machine number SIEMENS Sinumerik 840 D control system Machine number: V-800290 Geometric main dimensions Machine table diameter: 2000 mm Maximum table load: 17 tonnes Rotation diameter: 2400 mm Working height: 2445 mm , Cross-section of ram slide: 250 x 250 mm (minimum dipping diameter: 380 mm) Travelling distance of ram slide: 1500 mm Crossbeam travel: 1000 mm (100 mm steps) Cross beam support Travelling distance: ± 1350 mm Crossbeam travel (100 mm steps): 1000 mm Tool change path: 720 mm Machine drive Drive power main drive: 100 kW Speed range in 2 gear stages: 1.3 - 250 rpm Feed drives , Horizontal and vertical cross beam support: 0 - 18000 mm/min Cross beam adjustment speed: 400 mm/min Milling drive Milling drive power: 37 kW Speed range in 2 gear stag ...
