dmg siemens used for sale

CATEGORY — 5 Axis MANUFACTURER — DMG MORI MODEL — DMU 85 MONOBLOCK STOCK NUMBER — ONY100000587 MODEL YEAR — 2013 CONTROL PANEL — SIEMENS 840 D SOLUTIONLINE AXIS STROKE — X 935 MM / Y 850 MM / Z 650 MM ROTARY AXIS MOVEMENTS — A +/- 120 ° / C 360 ° SPINDLE SPEED — 18.000 MIN/-1 POWER CAPACITY-MAIN SPINDLE — 35 kW (40% ED) MAX. TORQUE — 135 Nm (40% ED) TOOL HOLDERS — SK 40 NUMBER OF TOOLPOSITIONS — 30 TABLE SURFACE AREA — 1.000 X 750 MM ( d 850 X 750 MM) MAX. TABLE LOAD — 1.000 KG TOTAL POWER REQUIREMENT — 46 KVA WEIGHT OF THE MACHINE — 13.500 KG DIMENSIONS OF THE MACHINE — 3.15 X 3.92 X 3.21 M

Inv. Num. : 8008 Type: DMG DMU 50 eco Producer: Deckel Maho Gildemeister Created: 2010 Parameters: Control system: Siemens Sinumerick 810D Switch-on hours: 56933 h Operating hours: 25670 h Number of axles: 5 pieces Number of stacking positions: 16 Maximum spindle speed: 8000 1/min X-axis travel: 500 mm Y-axis travel: 450 mm Travel Z axis: 400 mm Equipment: ShopMill

DMG MORI NRX 2000™ CNC Lathe TECHNICAL FEATURES: Year: 2017 NC Type: MITSUBISHI M730UM Maximum diameter Machinable: 150 [mm] X-axis travel: 100 [mm] Z-axis travel: 220 [mm] X1 Axis Fast Feed Speed: 30000 [mm/min] Fast feed speed X2 axis: 30000 [mm/min] Z1 axis fast feed speed: 30000 [mm/min] Z2 axis fast feed speed: 30000 [mm/min] Spindle Nose: JIS A2-5 Maximum length Machinable Spindle 1: 100 [mm] Maximum length Machinable Spindle 2: 100 [mm] Maximum speed Spindle 1: 6000 [rpm] Maximum speed Spindle 2: 6000 [RPM] Turret Turning Tool Power 1: 1.5 [kW] Turret 2 rotating tool power: 1.2 [kW] Number of posts - Turret 1 : 10 Maximum speed Rotating Tools - Turret 1: 10000 [RPM] Number of posts - Turret 2: 10 Maximum speed Rotating Tools - Turret 2: 10000 [RPM] Installed power: 38 [kVA] Supply voltage: 400 [V] Working time: 12270 [h] Weight: 5700 [Kg] EQUIPMEN ...

GeneralMulti-Axis Machine; Control: Control F31iB with CELOS CharacteristicsMax. Turning Length300 mmMax machining diameter320 mmSpeed max.6000 rpmSpindle speed 2nd Spindle max.6000 rpmWeight approx.8000 KgMovements X / Z210/810 mmCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and pGuide bushGuide Bushing If the bar material diameter is smaller than the spindle diameter, place an duracon bushing inside the spindle to prevent vibrations. (including the guide spacer) The customer should machine the guide bushing to the required diameter asLeft Spindle) KITAGAWA 8in. Hollow Chuck B208A521B (SK-OP)(Left Spindle) KITAGAWA 8in. Hollow Chuck B208A521B Three-jaw hydraulic chuck ...

GeneralMulti-Axis Machine; Control: Control F31iB with CELOS CharacteristicsMax machining diameter320 mmMax. Turning Length300 mmSpeed max.6000 rpmSpindle speed 2nd Spindle max.6000 rpmMovements X / Z210/810 mmWeight approx.8000 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and pGuide bushGuide Bushing If the bar material diameter is smaller than the spindle diameter, place an duracon bushing inside the spindle to prevent vibrations. (including the guide spacer) The customer should machine the guide bushing to the required diameter asLeft Spindle) KITAGAWA 8in. Hollow Chuck B208A521B (SK-OP)(Left Spindle) KITAGAWA 8in. Hollow Chuck B208A521B Three-jaw hydraulic chuck ...

GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal400 mmCross400 mmVertical375 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mWeight approx.7200 KgPackage Mill / TurnPackage Mill / Turn NC-Mill-turn table 450x450 mm / 17.7x17.7 in rounded down to d460 mm / 18.1 in C-axis direct drive, speed max.1,200 rpm Integrated balancing system Motorspindle 20-20,000 rpm power 35/25 kW (40/100% ED) tool taper HSK-A63 according D ...

GeneralCTX beta 1250 4A Two spindle turning centre with - partial hollow clamping device for main spindle and counter spindle internal diameter of draw tube Ø67 mm (2.63 in) x 700 mm (27.55 in) deep - 2 C-axes and spindle brakes (hydr.) - 2 12 fold Sauter star turrets reception VDI 40, DIN 69880-40 with precision interface (Trifix) and tool drive connection/drive acc. DIN 5480 - Y-axis, slide I - counter spindle slide; Control: CELOS X with Siemens 840D SL Operate Headstock, leftClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle diametre on front bearing130 mmSpindle bore87 mmDrive power (100% DC)25 kWTorque (100% DC)280 NmSpeed range0-5000 rpmC-Axis Speed2000 rpmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWC-Axis Speed2000 rpmTorque (100% DC)280 NmSlide 1Longitudina ...

x-travel:600 mm y-travel:700 mm z-travel:60 mm tool taper:SK40 magazine place:30 Stück table surface area:630 mm 5axis-CNC-Milling Machine Make: DMG Type: DMU 60 P YOM: 2004

GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmTechnical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperHSK-A 63 Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minClamping SystemHSK-A 63 Rapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring systemSpindle speed 15,000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 21 kW / 16 kW (28 hp / 21.5 hp) Torque 111 Nm / 85 Nm (82 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 x 19.6 in swivel range -35 to +110° ...

GeneralTraveling column machine; Control: CELOS X with HEIDENHAIN TNC7 Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minWorking area 1Longitudinal2000 mmCross800 mmVertical850 mmTool changerType of magazineChain Number of tools50 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmSwivelhead, B-axisControlled NC swivel milling head 12,000 rpm (B-axis) with clamping in position Continuously positioning NC- swivel milling head with integrated motor spindle for 4/5 axes positioning and simultaneous machining. Swivel speed: 50 rpm Swivel range: ±12Clamping System HSK-A 100Spindle taper HSK-A 100Speed range 20 -12000 rpmTorque (40% DC) 288 NmTorque (100% DC) 187 NmDrive power (40% DC) 44 kWDrive power (100%  ...

x-travel: 1135 mm y-travel: 1050 mm z-travel: 710 mm 0: dia 1240 x 690 mm control: Heidenhain TNC 640 : : 15000 min/-1 : 35 kW tool taper: SK 40 work table:: table surface area: 1050 x 860 mm max. table load: 2000 kg : : 30 pos. tool taper: SK 40 change-time chip to chip: 6 sec feeds:: : 40 m/min feed speeds: 40000 mm/min total power requirement: - kW weight of the machine ca.: 18 t dimensions of the machine ca.: 5,1 x 3,99 x 3,4 m 5-Axis Machine equipped with: - CNC Control Heidenhain TNC 640 - universal Milling Head (B-Axis +30/-130°) - NC- rotary Table dia 800mm (C-Axis) - BMF coolant and filtration system. - electr. Handwheel The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

travel -x axis: 500 mm travel -y axis: 450 mm travel -z axis: 400 mm c-axis: 360 b-axis: 0 - 108 ° surface area: d: 500 x 380 mm control: HEIDENHAIN - iTNC530 number of spindle speeds: 20 - 18.000 U/min numbers of positions in the tool changer: 60 tool taper: HSK 63 5-axis simultaneous machining center | DMG - DMU 50 eVo linear equipped with NC swivel rotary table, 60-way tool changer, double gripper, ITC (40 bar) and chip conveyor. Additional equipment: - Infrared probing system Heidenhain TS 640 - Laser tool measurement system - Belt filter system The machine is in a well-maintained condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: DMU50Evo | DMU50 Evo | 50Evo The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmTechnical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperHSK-A 63 Clamping SystemHSK-A 63 Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring systemSpindle speed 15,000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 21 kW / 16 kW (28 hp / 21.5 hp) Torque 111 Nm / 85 Nm (82 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 x 19.6 in swivel range -35 to +110° ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS X with HEIDENHAIN TNC7 Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minIntegrated motor spindle speedMASTER®Drive power (100% DC) 25 kWClamping System HSK-A 63Spindle taper HSK-A 63Speed range - 20000 rpmTorque (40% DC) 130 NmTorque (100% DC) 86 NmDrive power (40% DC) 35 kWNC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformationTool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine)Tool magazine 30 pockets HSK-A63Tool magaz ...

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Cross420 mmLongitudinal700 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWClamping System ISO 7388-3 - JD30Spindle taper BT 30Speed range 20 - 15000 rpmTorque (40% DC) 48 NmTorque (100% DC) 41 NmDrive power (40% DC) 8,5 kWToolchangertoolchangerType of magazine WheelNumber of tools 25Integrated swivel rotary table simultaneousIntegated swivel rotary table 5-Axis simultaneous mode! Torque drives incl. direct measuring in A- and C-Axis Swivel range A-Axis -120 / + 100 degrees Max. load C-axis 100kg Table diameter C-Axis d290mm Rotary joint, 4-channels Inclusive Software packageProduction package band filter ICS 40b ...

GeneralHSC-Precision Centre - Active chiller for main spindle and linear drives - Active chiller for electrical cabinet - Direct absolute measuring system with air purge - Coolant-airblast changeover - MPC (Machine Protection Control); Control: CELOS X with HEIDENHAIN TNC7 Technical DataSpindle taperHSK-E 50 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minTool changerApplicationVertical Type of magazineChain Type of gripperDouble gripper Number of tools60 Working area 1Longitudinal450 mmCross580 mmVertical460 mmSpecial equipmentFischer spindle 40,000 rpm with wave cooling 5-axis design Tool magazine 60 places HSK-E50 Production package high chip volume with IKZ (chip conveyor, rinsing gun, rotating viewing panel, AR flushing, IKZ 40 bar/600 1) Oil Mist Separator AFS BlowinSpecial equipmentPreparation aut ...

travel -x axis: 880 mm travel -y axis: 630 mm travel -z axis: 630 mm control: HEIDENHAIN - TNC 426M number of spindle speeds: 12.000 U/min numbers of positions in the tool changer: (2 x 16) 32 Tool bore: SK 40 surface area: 1.250 x 700 mm table load: 600 kg Milling machining centers - universal | DMG - DMU 80T equipped with B axis The machine is in good condition. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: 80 T | 80-T The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Year of construction: 2011 Fully automatic with manual options Intuitive input of automatic measurement cycles Wear-free and maintenance-free linear motors Flexible control console From manual to fully automatic Low distortion even under the maximum permissible load thanks to its high installed weight FEM-optimised and thermally stable cast iron construction RFID – data carrier system Customer-specific data storage Measurement processes with integrated data retrieval and storage Integration of all popular RFID systems The read / write head can be positioned automatically and manually for all popular tool holder systems Technikal data Length and diameter up to 1,000 mm Max. tool diameter for measuring according to snap gauge principle 100mm Maximum tool weight 160 kg Tool holder SK50 (additional holders availale from company HAIMER/Microset) Concentricity at the spind ...

Highlights - CNC FANUC 32i - 6 linear axes - 2 programming channels - 2 electrospindles - C-axis standard for main spindle and sub-spindle - 25 Vehicle positions - 4 radial driven tools for slides 1 - 4 radial driven tools for slides 2 - Machining on the main spindle possible with 2 tools at the same time Technical description I-A1023 GILDEMEISTER SPRINT 20|8 CNC Swiss Automatic Lathe CNC CNC FANUC 32i TECHNICAL DATA MAIN SPINDLE Turning diameter max.: 20 mm Stroke Z1: 60 mm 180 (with option I-C1002) Max. speed: 10,000 rpm Nominal drive power S1: 2.2 kW SUB-SPINDLE Turning diameter max.: 20 mm Stroke X2: 220 mm Stroke Z2: 170 mm Max. speed: 10,000 rpm Nominal drive power S1: 1.5 kW CNC-CONTROLLED AXES Rapid traverse speed: 32 m/min Max. acceleration: 5 m/s2 Feed force (S1) axes Z1, Z2, X1, X2: 150 daN Feed force (S1) axis Y1: 370 daN Feed force  ...

Highlights − Linear actuator for maximum precision, dynamics and cost-effectiveness − 6 + 2 axes, 2 Y-axes as standard − 2 tools in use at the same time − Thanks to the conversion kit, the machine can be used as an adjustable spindle stick Technical description I-J10010 GILDEMEISTER SPRINT 20|8 linear CNC Swiss Automatic Lathe TECHNICAL DATA: MAIN SPINDLE Turning diameter max.: 20 (25 option) mm Stroke Z 1: 80 mm Max. speed: 10,000 rpm Nominal drive power: S1 3.7 kW SUB-SPINDLE Turning diameter max.: 20 (25 option) mm Stroke Z 2: 300 mm Max. speed: 10,000 rpm Nominal drive power S1: 3.7 kW CNC-CONTROLLED AXES Rapid traverse speed: 40 (30) m/min (Y1 only) Acceleration max. X1: 10 m/s2 Feed force (S1) axis Z1,Z2,X2,Y2: 250 daN Feed force (S1) axis Y1: 500 daN Linear axis feed force X1: 60 daN SLIDE 1 Stroke X 1: 50 mm Stroke Y 1: 350 mm 6 P ...

Inv. Num. : 9057 Type: CTX 310 Producer: DMG MORI Created: 2004 Parameters: Control system: SINUMERIK 840 D Maximum turning length: 450 mm Max. turning diameter: 200 mm Maximum turning diameter over bed: 330 mm Maximum turning diameter over support: 260 mm Maximum length of travel in the X-axis: 160 mm Maximum feed in the Z-axis: 450 mm Maximum spindle speed: 6000 1/min Weight: 3950 kg

GeneralCNC Turning Centre; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways710 mmTransverse stroke260 mmLongitudinal stroke1345 mmClamping chuck diameter max.315 mmWork spindle (left)Spindle bore91 mmSpindle diametre on front bearing140 mmMain drive 1Drive power (100% DC)22 kWSpeed range- 4000 rpmTorque (100% DC)410 NmMax. torque (40% DC)525 NmAccuracy at point stopping0,001 degreeTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.-6000 rpmPower max. (100% DC)10 kWFloor space/WeightDimensions (L x W x H)5,4 x 2,07 x 2,6 mWeight approx.7800 KgTechnologie cycle alternating speedTechnology cycle for the application of an alternating speed for vibration sensitive set-ups (Only in conjunction with Siemens control)Chuck rinsing device, outsidechuck rinsing device, outside (main spindle)Main s ...

Key data: 600 mm, 500 mm, 500 mm

CNC 5-Axis Vertical Machining Center DMG Mori DMU 60 eVo Year of construction 2017 Heidenhain TNC 640 ERGOline 2-axis NC swivel rotary table Table size 600 × 500 mm Table load max. 400 kg Table NC Rotary Axis C-Axis 360° Table NC swivel axis B-axis -5° / +110° X 600 mm Y 500 mm Z 500 mm Spindle holder SK 40 BIG PLUS Spindle drive power 25 / 35 kW AC Spindle speeds up to 20,000 rpm. 120 tool magazine slots Operating hours 47,589 Spindle hours 28,638 Offer number MV-6512

Key data: 750 mm, 600 mm, 520 mm

CNC 5-Axis HSC Vertical Machining Center DMG DMU 70 eVo Linear NEW DESIGN Year of construction: 2011 Heidenhain iTNC 530 2-axis NC swivel rotary table Table size Ø 700 x 500 mm Table load max. 350 kg C-axis rotation 360° x 0.001° Swivel axis B-axis 120° x 0.001° X 750 mm Y 600 mm Z 520 mm Spindle drive motor 25/35 kW Spindle speeds max. 18,000 rpm. 60-fold tool magazine positions Tool holder HSK-A63 Electrified tour of the factory Offer number MV-6513

CNC milling and turning center Machine type: DMG Mori CLX 450 TC with Robo2go Control: Siemens 840 D sl Operate Slimline Year of manufacture: 2023 TECHNICAL DATA: Max. turning length: [mm] 1,100 Turning diameter: [mm] 400 Main spindle ISM 65 Speed range: [1/min.] 5,000 Drive power: [kW] 14 / 17 Torque: [Nm] 275 / 345 Spindle Nose: A2-8 Bar Passage: [mm] 67 C-axis CNC spindle swivel for milling and milling Filming Max. speed: [1/min.] 12,000 Drive power: [kW] 8.8 / 10.5 Torque: [Nm] 73 / 90 Tool holder: HSK 63 Tool positions: 30 Sub-spindle ISM 65 Spindle Nose: A2-8 Max. speed: [1/min.] 5,000 Drive power: [kW] 14 / 17 Torque: [Nm] 275 / 345 C-axis X-axis: [mm] 750 EUR 395,000 Y-axis: [+/- mm] 100 Z-axis: [mm] 1,100 B-axis +/- 120 mm Features: Chip conveyor Direct Path Measurement System Chip rinsing gun 3-jaw chuck [mm] SMW-Autoblok BBD 250/78 3-ja ...

CONTROLS   CNC controls HEIDENHAIN MILL PLUS WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 5   X-axis travel: 500 mm   Y-axis travel: 420 mm   Z-axis travel: 380 mm SPINDLE / HEAD   spindle revolutions (max): 18000 /min   tool fixture: HSK A63 AXIS DRIVES   feed velocity (max): 20000 mm/min   rapid traverse: 50000 mm/min TOOL MAGAZINE   number of positions: 60 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 2500 mm   space requirements -front/back-: 2600 mm   total height: 2440 mm   total weight approx.: 6000 kg ATTACHMENTS   zero-point workholding system: yes   chip conveyor: yes   coolant  ...

x-travel: 800 mm y-travel: 700 mm z-travel: 600 mm turning speeds: 12000 1 U/min : control: Heidenhain total power requirement: 59 kW weight of the machine ca.: 10,6 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

travel -x axis: - mm travel -y axis: - mm travel -z axis: - mm B-axis swival range +/-: -90° / +12 ° C-axis: 360 ° control: HEIDENHAIN - Millplus number of spindle speeds: 12.000 U/min numbers of positions in the tool changer: 60 tool taper: SK40 NC rotary table diameter: 600 mm fixed clamping table: 1.000 x 600 mm max. table load: 500 kg 5-axis simultaneous machining center | DMG - DMU 60 monoBlock equipped with ITC (40bar), a 60-way tool changer, NC - rotary table, Renishaw measuring probe and chip conveyor. Additional equipment information: - NC swivelling head B-axis - NC rotary table C-axis integrated in the fixed table - Direct position measuring system in X/Y/Z (glass scales) - Extraction system - 3D Quickset - Handwheel HR 410 The machine is in a well-maintained condition and can be inspected at any time under power. The machine video from the production plant will be shared  ...

travel -x axis: 3.000 mm travel -y axis: 560 mm travel -z axis: 720 mm control: Siemens - 840D number of spindle speeds: 18.000 U/min numbers of positions in the tool changer: 100 tool taper: HSK 63 Milling machining centers - vertical | DMG - DMF 300 Linear The machine has exclusively processed aluminum is in a well-maintained condition and can be inspected at any time under power. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: DMF300Linear | DMF300 | DMF-300 Linear | DMF-300Linear The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

travel -x axis: 3.000 mm travel -y axis: 560 mm travel -z axis: 720 mm control: Siemens - 840D number of spindle speeds: 18.000 U/min numbers of positions in the tool changer: 100 tool taper: HSK 63 Milling machining centers - vertical | DMG - DMF 300 Linear The machine has exclusively processed aluminum is in a well-maintained condition and can be inspected at any time under power. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: DMF300Linear | DMF300 | DMF-300 Linear | DMF-300Linear The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Working area 1Longitudinal700 mmCross420 mmVertical380 mmGeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWDrive power (40% DC) 8,5 kWClamping System ISO 7388-3 - JD30Spindle taper BT 30Speed range 20 - 10000 rpmTorque (40% DC) 48 NmTorque (100% DC) 41 NmIntegrated swivel rotary table simultaneousIntegated swivel rotary table 5-Axis simultaneous mode! Torque drives incl. direct measuring in A- and C-Axis Swivel range A-Axis -120 / + 100 degrees Max. load C-axis 100kg Table diameter C-Axis d290mm Inclusive Software package Sinumerik Mdynamics 5-axRotary joint, 4 channelsRotary joint for integrated swivel rotary table with torque drives 4- channe ...

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross420 mmVertical380 mmMain driveDrive power (100% DC) 6 kWDrive power (40% DC) 8,5 kWTorque (100% DC) 41 NmTorque (40% DC) 48 NmSpeed range 20 - 15000 rpmSpindle taper BT 30Clamping System ISO 7388-3 - JD30ToolchangertoolchangerNumber of tools 15Type of magazine DiskIntegrated swivel rotary table simultaneousIntegated swivel rotary table 5-Axis simultaneous mode! Torque drives incl. direct measuring in A- and C-Axis Swivel range A-Axis -120 / + 100 degrees Max. load C-axis 100kg Table diameter C-Axis d290mm Rotary joint, 4-channels Inclusive Software packageRotary joint, 6 channelsRotary lead thr ...

Manufacturer: DMG MORI Model: CTV 250 DF Year of Manufacture: 2019 Type of Machine : Power skiving machine / CNC Turning Center Max spindle speed: 6,000 rpm Secondary spindle speed: 7,000 rpm Machine weight: 7,000 kg Power supply: 400 V, 50 Hz, L1-L2-L3-N-PE phase Power consumption: 65 kVA Max current: 95 A Fuse: 100 A / 1.00 kA Max voltage: 440 V Control voltage: 230 V / 24 V Spare parts are available for sale separately Find more here - / Contact us at -

x-travel: 1.135 mm y-travel: 1.050 mm z-travel: 750 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: max. 14.000 min/-1 power capacity - main spindel: 19 kW max. Torque: 100 Nm tool taper: HSK-A 63 table surface area: 1.400 x 1.050 mm max. table load: 2.500 kg max. workpiece sizes: 1.400 x 1.240 mm max. workpiece height: 750 mm tool magazin:: number of toolpositions: 30 pos. tool taper: HSK-A 63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 160 mm max. tool length: 365 / 395 mm max. tool weight: 8,0 kg change-time chip to chip: 6,1 sec feeds:: feed speeds: max. 40.000 mm/min rapid traverse: 40 m/min Accelaration: 6 m/s² Feed force ( X / Y / Z ): 14 / 20 / 14 kN total power requirement: 44 kVA weight of the machine ca.: 14,4 t dimensions of the machine ca.: 6,0 x 5,0 x 3,3 m Documents: Chip conveyor: Coolantsystem: high pressure coolan ...

turning diameter:356 mm turning length:705 mm control: CELOS M730 UM MAPPS swing dia.:742 mm standard turning diameter:275 mm travel -x axis:260 mm travel -y axis:100 ( ±50) mm travel -z axis:795 mm rapid travel - longitudinal/face:30 / 30 m/min Rapid travel B-axis (parts transfer subspindle):734 m/min Spindle 1 RPM:4000 1/min Spindle 1 Power:15/18,5/18,5 kW Spindle 1 Torque:409/505 /599 Nm Spindle 1 max. bar diameter:80 mm Spindle 2 RPM:4500 1/min Spindle 2 power:7,5/11 kW turret stations / rotary tool stations:20 / 20 BMT40 speed of driven tools:10000 1/min :3.7/5,5/5,5 kW torque rotary tools:14 / 24 Nm total power requirement:38 kVA weight of the machine ca.:6,3 t dimensions of the machine ca.:4 (9) x 2,1 x 2,2 m Parts catcher:Sp. 1 und Sp. 2 Spindle 1 Chuck:Kitagawa B 210 (250 mm) Spindle 2 Chuck:Kitagawa B 206 (160 mm) Tool presetter:Spindle 1 & 2 High precision Turning and Millin ...

turning diameter:670 mm turning length:1540 mm control:F31iB5 Celos Fanuc 35iB5 swing diameter max. over bed cover:700 mm Travel turret No.1 (milling spindle) x/y/z:495 / ± 150 / 1562(+164) mm Rotation B-axis:-30° / +210° Rapid traverse feeds turret 1 (milling head) x/y/z:40/40/40 m/min RPM milling spindle:12000 1/min power capacity - milling spindle:20,2/18,8 kW Torque of milling spindle:120 / 44 Nm tool taper milling spindle:Coromant Capto C6 Tool magazine for milling spindle (turret 1):76 Tool change time tool/tool, milling spindle:1,25 s Spindle 1 RPM:3000 1/min Spindle 1 Power:36 / 30 / 25 kW C-axis spindle 1:0,001 ° Bar capacity spindle 1:102 mm Spindle 2 RPM:4000 1/min Spindle 2 power:26 / 22 / 15 kW C-axis spindle 2:0,001 ° Bar capacity spindle 2:80 mm dimensions of the machine ca.:7,8 x 3,6 x 2,9 m Linear scales on axis:X, Y programmable steady:KLU-A530 & SLU-X3.2 Spindle 1 ...

x-travel:560 mm y-travel:560 mm z-travel:660 mm control:Celos Siemens 840D SL Operate ERGOline Multitouch turning speeds:20 - 20.000 1/min spindle drive:25/ 35 kW max. torque on the spindle:86 / 130 tool taper:HSK-A63 Number of tool station:60 diameter of tools max.:70 mm Tool diameter with no neighbouring tools:170 mm tool length - max.:450 mm weight of tools max.:12 kg numbers of pallets:2 Pallet dimension:400 x 400 mm max. workpiece diameter:630 mm workpiece height max.:900 mm table load:400 kg rapid travel x/y/z:60 m/min Feed x/y/z:60 m/min internal coolant system feed:70 bar weight of the machine ca.:8,5 t dimensions:3200 x 4800 x 2900 mm Renishaw probe (spindle):Vorbereitung / preparation only Horizontal machining center with Siemens - Celos control, full b-axis, tool magazine with 123 pos. HSK-A 63, coolant through spindle 40 bar. The machine has just received a new milling spind ...

x-travel:780 mm y-travel:560 mm z-travel:560 mm weight of the machine ca.:10 t Number of axles:5 St. spindle turning speed range:20-12.000 U/min numbers of tools in magazin:30 tool taper:SK 40 surface area:500 x 630 mm Round Table B-Axis

x-travel:1.250 mm y-travel:880 mm z-travel:800 mm spindle turning speed range:1 - 10.000 U/min high speed spindle taper ISO:50 table-size:1.250 x 1.000 mm max. workpiece weight: 2.000 kg feed speeds infinitely variable:1 - 30.000 mm/min rapid traverse speed:40 m/min weight of the machine ca.:16 t dimensions of the machine ca.:7,2 x 4,4 x 2,9 m

DMG DMC 200 U duoBLOCKYear of manuf. : 2007 Control : Heidenhain iTNC 530 Speed : 12000 rpmMovement X/Y/Z : 1800/2000/1100 mmTool holder : HSK 100 ____________Description:In General:Year of manufacture:2007Control system:Heidenhain iTNC 530Travel distances X/Y/Z:1,800/2,000/1,100 mmRotational speed:12,000 rpmMedia feed-through:Blast air + cooling lubricantSpindle:Technology:Motor spindleSpeed:12,000 rpmPower:44 kWTorque:288 NmTool holder:HSK 100NC swivel head:Technology:Universal milling headB-axis:0°-180°NC rotary table:Technology:Rotary table with pallet carrierC-axis:360°Clamping surface:1,600 x 1,400 mmMax. table load:4,000 kgHolding torque:approx. 17,000 NmTool magazin:Technology:Chain magazineNumber of stations:120Tool changer:Double gripperEquipment:Position sensors:Direct scales in all axesChip disposal:Chip conveyorCoolant supply:Internal c oolant system, 40 barAu ...

with 15 cards + Rack S5 187U with 10 extension cards. Scope of supply shown on the picture.

Properties Used MULTI PANEL Simatic dimensions: Total height with monitor: 1,620 mm Height without monitor: 1,100 mm Control cabinet Height: 500mm Width: 540mm Depth: 240mm > b > monitor Height: 310mm Width: 400mm 1 STK. in stock

Siemens Spare Parts

Control cabinet The offer includes complete control cabinet containing a flat grinding machine with 2 x room cooler Control: Siemens Type: Sinumerik 3 G 1 x Sinumerik 3 G, 6FC 3742-OHA-Z, 24V DC, 100W 1 x SIMOVERT P 6SC6025-1AA01, type D165 D165/25 M5REQ, no. 3203572, output 1 x 25/50A DS 1 x SIMOREG transistor plate, type 6RB 2025-2EA00, ed.: 2 x 25/50A 200V Various circuit breakers, transformers, etc. Sold only to commercial enterprises. All information without guarantee

Siemens PLC CPU rack 115U 943B 6ES5 943-7UB11 Power supply 6Es5 951-7LB21 CPU 115U 943B 6ES5 943-7UB11 CP 523 COMMUNICATION PROCESSOR 6ES5 523-3UA11

Manufacturer: Siemens Type: 1LA6 186-4AA71 22.0 kw

The Siemens three-phase asynchronous motor is unused, therefore as good as new! Name: Asynchronous Motor Manufacturer: Siemens Type: 1PH72282HF0101BB9-Z Year built: 2011 Hours of operation: 0 Std. Empty weight: weight 870 kg Construction form: V5 Dimensions: length: 1500 mm, width 600 mm, height 700 mm Speed: 1500 / 1750 / 2000 rpm Operating voltage: 340 /395 /450 V Type of protection: 55 IP Description: three-phase asynchronous motor/squirrel-cage motor Technical documentation: yes (PDF) Performance: 160 / 179 / 196 kW Frequency: 51 /59 /67 Hz Rated current: 350 / 342 /332 A. Torque: 1750 /2000 Nm Message: max. coolant temperature: 40°C, max. speed: 4500 rpm Price: on request

Siemens Sinumerik 3G, 6FC 3741-OMA-Z Not checked for functionality. Sold only to traders! All information without guarantee

Siemens Simoreg, 6 RB 2025-2EA00, Type D165 G200/25 M5REQ Not checked for functionality. Sold only to traders!

Siemens Simovert, P SC6025-1AA01, Type D165 D165/25 M5REQ Not checked for functionality. Sold only to traders!
