129,275 used machines on RESALE, but how to find them? Machine Search
The machine is in good technical condition, after prior agreement it is possible to test it. with the Siemens Shopturn system, including the feeder, the machine is fully equipped. BASIC PARAMETERS Working space max. turning Ø: ≈ 410–500 mm max. length: 800 mm distance between spindles: approx. 1020 mm swing diameter above the bed: ~700 mm realistic: ideal for shafts, flanges, bodies up to ~800 mm Travels (axes) X: ~480 mm Y: 100 mm Z: ~800–845 mm B axis: 110 (5-axis machining) C axis: 360 (indexing + interpolation) this makes it a full-fledged turn-mill (not a classic lathe) Spindles main spindle speed: ~5000 rpm power: ~25–34 kW passage: approx. 76–87 mm counter spindle speed: ~6000 rpm milling spindle (main difference compared to a classic lathe) speed: up to 12,000 – 20,000 rpm power: ~19–22 kW taper: HSK-A63 or Capto C6 allows: milling drilling tapping 5-axis simultane ...
CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgGeneralVertical Machining Center; Control: Control SIEMENS 828D Mechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)4th Axis package4th Axis package Option includes: - rotary table type EA-510.L NE with indirect measuring system - electrical and pneumatic preparation - software preparation to work with rotary table - cycle TRACYL which allows to define contour on the cylinder - swSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwhe ...
Key data: 400 mm, 620 mm
Machine Details Stock-No. 1105-04057 Type of machine CNC Lathe - Inclined Bed Type Make DMG MORI Type CLX 450 V4 Year of manufacture 2020 Type of control CNC Storage location FRANCE Country of origin - Delivery time to be agreed Freight basis ex site Technical details turning diameter 680 mm turning length 600 mm control Sinumerik 840 SLIMLINE turning diameter 680 mm Greates Pass Round Over Bed 650 mm Spindle diameter in front bearing 130 mm Spindle Bore 80 mm Spindle Taper 140H5 X-AXIS 220 mm Z-AXIS 810 mm tool taper VDI 40 Tailstock Adjustment 600 mm tension force 4 kN total power requirement 21 kW weight of the machine approx. 5.3 t dimensions of the machine approx. 3.8 x 3.0 x 2.1 m Accessories Documents Chip conveyor Coolant system Turret Additional information CNC Turning and Milling Center DMG MORI -CLX 450 V4 CNC DMG MORI SIEMENS SLIMLINE ...
GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmRapid feed X / Y / Z24/24/24 m/minDimensions (L x W x H)3,07 x 2,67 x 2,84 mMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)4th Axis package4th Axis package Option includes: - rotary table type EA-510.L NE with indirect measuring system - electrical and pneumatic preparation - software preparation to work with rotary table - cycle TRACYL which allows to define contour on the cylinder - swSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Air coolant external and internalAir coolant ex ...
x-travel: 730 mm y-travel: 730 mm z-travel: 880 mm total power requirement: 46 kW weight of the machine ca.: 15 t required space: 5.5x3.0x2.8 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
GeneralHSC-Precision Centre - Active chiller for main spindle and linear drives - Active chiller for electrical cabinet - Direct absolute measuring system with air purge - Coolant-airblast changeover - MPC (Machine Protection Control); Control: 3D-control Heidenhain iTNC 530 HSCI Technical DataSpindle taperHSK-E 50 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minWorking area 1Cross580 mmLongitudinal450 mmVertical460 mmTool changerType of magazineChain ApplicationVertical Type of gripperDouble gripper Number of tools30 Rigid tableRigid table, clamping area 460 x 600 mm / 18,11 x 23,62 inch Loading weight max. 600 kg / 1322 lbsSpindle speed up to 40,000rpm with Shaft CoolingSpindle speed 20 up to 40,000 rpm within shaft cooling for tool taper HSK-E50 DIN 69893 AC-Main drive with 19,5/15 kW (100/40%DC) 14,5 ...
The machine can be viewed on site by appointment. Subject to changes and errors in the technical data and specifications, and prior sale!
GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mmNumber of Slots 5Spindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmTool magazine, cha ...
GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mmNumber of Slots 5Spindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmTool magazine, cha ...
GeneralHorizontal machining centre - Horizontal milling head; Control: CELOS with Siemens 840D sl Operate Technical DataRapid traverse longitudinal/transverse/vertical60/60/70 m/minFeed rate longitudinal/transverse/vertical60000/60000/70000 mm/minWorking area 1Longitudinal800 mmCross1050 mmVertical900 mmCabineFull protection cabinDirect measuring systemDirect path measuring systemNC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 630 x 630 mmRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mmMaximum load (table centre) 900 KgCentre bore 50 mm4. Axes (swivelling range) 360 x 0,001 degreePackage recirculation ballscrew spindlePackage recirculating ballscrew spindle X-,Z-axis:max. feed speed: 60.000 mm/min Y-axis: max. feed speed: 70.000 mm/min (basic machine without linear drive X-, Y-, Z-axis)Motor ...
GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Working area 1Longitudinal560 mmVertical600 mmCross600 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMiscellaneousClamping SystemDIN ISO 7388 CabineFull protection cabinNC rotary table with pallet carrierNC rotary table with pallet carrier permissible load 500 kg / 1,100 lbs (no indexing table 360 x 1° in basic machine)Table surface 400 x 400 mmMaximum load (table centre) 500 Kg4. Axes (swivelling range) 360 x 0,001 degreeTool magazine, chain Vert., 60 pocketsTool magazine Vertical chain magazine with 60 tool pockets SK 40 or optional chosen spindle tapersMotor spindle SK 40 18,000 rpmMain drive: Integrated motor spindle SK 40 Spindle speed max. 18,000 rpmDrive power (100% DC) 28 kWDrive power (40% DC) 34 kWSpi ...
used
Working areaTurning diameter500 mmDistance between spindles1435 mmMax. Turning Length1100 mmGeneralTurning/milling center with turning length 1100 mm - mounting HSK-A 63 DIN 69893 - B-axis ±120 - Y-axis ±100 mm - 60-fold chain magazine - Absolute, direct path measuring systems in X-, Y- and Z-axis - Hydraulically movable tailstock with foot pedal - Double switch filter - Electric handwheel - DMG MORI IoT connector - Clamping pressure adjustment on the control - 5-axis simultaneous machining; Control: CELOS X with Siemens SINUMERIK ONE Main drive 1Drive power (100% DC)14 kWDrive power (40% DC)17 kWSpeed range- 5000 rpmTorque (100% DC)275 NmMax. torque (40% DC)345 NmTurning-milling spindleSpindle taperHSK-A 63 DIN 69893 Spindle speed-15000 rpmDrive power (40% DC)22,5 kWDrive power (100% DC)19 kWTorque (100% DC)85 NmTorque (40% DC)120 NmFloor space/WeightDimensions (L x W x H)5,77 x 2,33 ...
GeneralVertical Machining Centres; Control: DMG MORI SLIMline® Multi-Touch control CharacteristicsTable surface900 x 560 mmMaximum load (table centre)600 KgDrive power (100% DC)9 kWSpeed max.12000 rpmDrive power (40% DC)13 kWDimensions (L x W x H)3,03 x 3,49 x 2,94 (5,8 x 5,5 x2,94) mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z600/560/510 mmSpindle taperSK 40 DIN 69871 Max. torque82 NmTool Magazine with30 PositionsTorque (100% DC)54 NmWeight approx.5200 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable data exchange between the IoTconnector and CELOS APPs such as the NETservice. The integrated firewall with automatic updates ensures the hSafety Package for Power FailureSafety Package for Power ...
used
GeneralUniversal machining centre; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical80000/80000/80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minWorking area 1Longitudinal800 mmCross650 mmVertical550 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightDimensions (L x W x H)6,56 x 7,98 x 3,05 mWeight approx.12000 KgIntegrated motor spindle speedMASTER®Drive power (100% DC) 25 kWDrive power (40% DC) 35 kWTorque (100% DC) 86 NmTorque (40% DC) 130 NmSpeed range -20000 rpmSpindle taper SK40 - BIG-PLUSClamping System DIN ISO 7388Dynamic package DMU 80 eVo linearDynamic package for DMU 80 eVo linear linear drive X/Y-axis with ...
This 3-axis DMG DECKEL MAHO 1035V was manufactured in 2006. It features an X-axis travel of 1,035 mm, Y-axis travel of 560 mm, and Z-axis travel of 510 mm. The machine is equipped with a Heidenhain iTNC 530 control unit and has a tool magazine capacity of 30 positions. If you are looking to get high-quality machining capabilities, consider the DMG DECKEL MAHO 1035V vertical machining centre we have for sale. Contact us for further details.
General2-Turret Shaft Lathe; Control: Control F32iB CharacteristicsMax machining diameter120 mmWeight approx.3000 KgDrive power main spindle5,5/3,7/3,7 kWRapid feed X / Z20 / 30 m/minMovements X / Z60 / 580 mmLower Turret6 PositionsRapid feed X / Z20 / 30 m/minMovements X / Z60 / 580 mmUpper Turret6 PositionsSpeed max.-3500 rpmMax. Turning Length535 mmDimensions (L x W x H)1,65 x 1,67 x 1,5 mTailstock spindle travel check (4 positions)Tailstock Spindle Travel Check (4 Positions) The tailstock spindle stroke range can be detected by connecting the tailstock spindle and air cylinder with scale function.Foot switch for tailstockFoot switch for tailstock The tailstock spindle is moved in and out with a foot switch.Coolant gunCoolant Gun The magnet type coolant gun is attached to the machine front. Pressing the coolant gun button on the operation panel activates the coolant pump, and depressi ...
GeneralCNC Turning Centre; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways620 mmTransverse stroke260 mmLongitudinal stroke795 mmClamping chuck diameter max.315 mmWork spindle (left)Spindle bore91 mmSpindle diametre on front bearing140 mmMain drive 1Drive power (100% DC)22 kWSpeed range- 4000 rpmTorque (100% DC)410 NmMax. torque (40% DC)525 NmAccuracy at point stopping0,001 degreeTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.-6000 rpmPower max. (100% DC)10 kWFloor space/WeightDimensions (L x W x H)3,99 x 2,03 x 2,2 mWeight approx.6500 KgTechnologie cycle alternating speedTechnology cycle for the application of an alternating speed for vibration sensitive set-ups (Only in conjunction with Siemens control)Chuck rinsing device, outsidechuck rinsing device, outside (main spindle)Main s ...
Inv. Num. : 8243 Type: DMU 60 P Producer: DMG Generated: Parameters: Work table length: 1000 mm Work table width: 600 mm Number of axles: 5 pieces X-axis travel: 600 mm Y-axis travel: 525 mm Travel Z axis: 500 mm Speed: 12000 1/min Machine weight: 4000 kg
CNC vertical machining center Type: MCX 600 V Manufacturer: DMG MORI Year: 2017 X: 600 mm Y: 560 mm Z: 510 mm Max spindle speed: 12000 rpm Max workpiece high: 630 mm Max workpiece length: 900 mm Max workpiece width: 560 mm Max workpiece weight: 600 kg Machine weight: 4700 kg In very good condition, worked few hours, under power Find more here - / Contact us at -
GeneralUniversal machining centre; Control: Siemens 840D-Powerline ShopMill Classic Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal1250 mmCross1000 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 63 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machiningProd. package 40 bar/23 l/minCoolant through spindle centre form AD 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) clear-view rotating window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pumpNC rotary table with pallet changerType of Measuring system Direct measuring s ...
GeneralUniversal machining centre; Control: 3D Control Siemens 840D powerline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal1250 mmCross1000 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 100 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machiningProd. package 40 bar/23 l/minCoolant through spindle centre form AD 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) clear-view rotating window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pumpNC rotary table with pallet changerType of Measuring system Direct measuring system ...
GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque64 NmTorque (100% DC)43 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.10000 rpmWeight approx.5600 KgSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872
GeneralVertical-Machining centre Stealth Design; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Longitudinal1450 mmCross700 mmVertical550 mmTableTable surface 1760 x 750 mmMaximum load (table centre) 2000 KgSlot width 14 mmNumber of Slots 7Distance between T-Slots 100 mmSpindle speed 15,000 rpm, 200NmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle)Tool magazine 60 pockets HSK-A63Tool magazine 60 pockets HSK-A63 Chain magazine with pockets and with double gripper, incl. manually direct tool loading into the tool magazineInternal coolant supply package 80 bar / 980 lInternal coolant supply package 80 bar / 98 ...
GeneralVertical Machining Center; Control: Control SINUMMERIK ONE CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque64 NmTorque (100% DC)43 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.10000 rpmWeight approx.5600 KgSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic HandwheelSpecial equipment4th. axis Lehmann
GeneralTwo spindle turning/milling centre with - Main and counter spindle; Control: CELOS with Siemens 840D sl Operate Tool holder 2Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)10 kWTool magazineMax. tool length230 mmNumber of tools24 Max. tool diameter80 mmMax. tool weight7 KgTurning-milling spindleSpindle taperHSK-A 63 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment1000 NmSwivelling range+/-110 degreeSlide 3Longitudinal stroke1200 mmSlide 2Longitudinal stroke1200 mmTransverse stroke195 mmSlide 1Longitudinal stroke1200 mmTransverse stroke490 mmY axis, vertical+/- 100 mmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWDri ...
GeneralVertical-Machining centre Stealth Design; Control: CELOS with Heidenhain TNC 640 Technical DataRapid traverse longitudinal/transverse/vertical42/42/42 m/minFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minWorking area 1Cross700 mmLongitudinal1450 mmVertical550 mmIntegrated motor spindle speedMASTER®Integrated motor spindle speedMASTER® At speeds > 18.000 min-1, the use of tools with dual contact system (BIG-PLUS®) is stipulated.Drive power (100% DC) 25 kWDrive power (40% DC) 35 kWTorque (100% DC) 86 NmTableTable surface 1760 x 750 mmClamping System DIN ISO 7388-3-ADSpindle taper SK40 Tool holder DIN ISO 7388-1-ASpeed range - 20000 rpmTorque (40% DC) 130 NmSlot width 14 mmMaximum load (table centre) 1500 KgNumber of Slots 7Distance between T-Slots 100 mmCabin roofCabin roof In sheet steel design Open and close via front doorSpecial equipmentClamping pneuma ...
GeneralVertical-Machining centre Stealth Design; Control: CELOS X with Siemens 840D SL Operate CharacteristicsTable surface1460 x 750 mmMaximum load (table centre)1500 KgTool Magazine with40 PositionsMovement X / Y / Z1150/700/550 mmRapid feed X / Y / Z42/42/42 m/minWeight approx.12900 KgSpindle speed 20 - 12,000 rpm SK50, 288NmSpindle speed 20 - 12.000 rpm SK50 for tool taper according to DIN ISO 7388-1-A50 with power 44/32 kW // 59.0/42.9 hp with torque 288/187 Nm (40/100% DC) (differently from standard)Tool magazine 40 pocketsTool magazine 40 pockets SK50 chain magazine with pockets and double gripper, incl. manually direct loading into the tool magazineCoolant-air blast change-overCoolant - Air-blast changeover external switchable via M-FunctionAir blast through spindle centreAir blast through spindle centre activated by M function, maintained air with low oil rateInternal coolant su ...
GeneralVertical machining center in C-frame-design New DMG MORI Design Direct Measuring system X,Y,Z; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Longitudinal650 mmCross520 mmVertical475 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools30 TableTable surface 960 x 570 mmMaximum load (table centre) 800 KgSlot width 14 mmNumber of Slots 5Distance between T-Slots 100 mmSpindle speed 15,000 rpm, 200 NmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle) BIG-PLUS® tools possibleTool magazine 30 pockets SK40Tool magazine 30 pockets SK40 Chain magazine with pockets and with double gripper, ...
GeneralVertical machining center in C-frame-design New DMG MORI Design Direct Measuring system X,Y,Z; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Cross520 mmLongitudinal650 mmVertical475 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 TableTable surface 960 x 570 mmMaximum load (table centre) 800 KgSlot width 14 mmNumber of Slots 5Distance between T-Slots 100 mmSpindle speed 20.000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Tool magazine 60 pockets HSK-A63Tool magazine 60 pockets HSK-A63 Chain magazine with pockets and with double gripper, incl. manually direct t ...
CharacteristicsTable surface1460 x 750 mmMaximum load (table centre)1500 KgTool Magazine with30 PositionsMovement X / Y / Z1150/700/550 mmRapid feed X / Y / Z42/42/42 m/minWeight approx.12900 KgGeneralVertical-Machining centre Stealth Design; Control: CELOS X with Siemens 840D SL Operate Spindle speed 15,000 rpm, 200 NmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle) BIG-PLUS® tools possibleTool magazine 30 pockets SK40Tool magazine 30 pockets SK40 Chain magazine with pockets and with double gripper, incl. manually direct loading into the tool magazineCoolant-air blast change-overCoolant - Air-blast changeover external switchable via M-FunctionAir blast through spindle centreAir blast through spindle centre activated by M function, maintained air with low oil rat ...
GeneralVertical Machining Centres; Control: DMG MORI SLIMline® Multi-Touch control CharacteristicsMaximum load (table centre)800 KgDimensions (L x W x H)3,3 x 2,7 x 2,94 mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z800/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with30 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmTable surface1100 x 560 mmWeight approx.5550 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SysteminlineMASTER® spindle 12.000 rpminlineMASTER® spindle 12.000 rpm Spindle speed range 20 to 12.000 rpm Tool Taper SK40 DIN69871 with BIG PLUS inteface Tool clamping according to DIN69872 Power: 13kW (40% DC) / 9kW (100% DC) Torque: 83 Nm (40% DC) / 57 Nm (100% DC) bearings oil-air lubrSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872NC-D ...
General2-axes universal turning center with driven tools, C-axis and Y-axis; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over bed650 mmSwing diameter over X linear guideways370 mmMax machining diameter320 mmClamping chuck Ø250 mmX travel250 mmY travel+/-50 mmZ travel550 mmDistance between spindle noses800 mmMain drive 1Type of main driveAC Drive power (100% DC)12,6 kWDrive power (40% DC)14 kWSpeed range-5500 rpmTorque (100% DC)171 NmC-Axis Speed100 rpmMax. torque (40% DC)192 NmTorque of C-Axis (holding torque)168 NmWork spindleSpindle diametre on front bearing120 mmSpindle noseA2-6 Spindle bore73 mmBar diameter max.65 mmTool holder 1Number of tool stations12 Number of driven tools12 Speed max.6000 rpmPower max. (40% DC)4,6 kWDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable d ...
General2-axis universal turning machine with - partiall hollow clamping device (hydr.) inner draw tube Ø 52 mm - C-axis and spindle brake (hydr.) - 12 stations circle revolver Sauter reception acc. VDI 30, DIN 69880-30 with tool drive Connection/drive acc. DIN 5480 Direct measuring system, glas scale in X-axis - tailstock; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTransverse stroke190 mmLongitudinal stroke525 mmClamping chuck diameter max.210 mmWork spindle (left)Spindle noseFlat flange Spindle bore73 mmDiametre of spindle nose140h5 mmSpindle diametre on front bearing100 mmMain drive 1Drive power (100% DC)13 kWSpeed range20 - 6000 rpmTorque (100% DC)171 NmC-Axis Speed-300 rpmTorque of C-Axis (holding torque)192 NmTool holder 1Number of tool stations12 Shank diametre according to DIN 6988030 mmNumber of driven tools12 Speed max.-500 ...
General2-axes universal turning center with driven tools, C-axis and Y-axis; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over bed650 mmSwing diameter over X linear guideways370 mmMax machining diameter320 mmClamping chuck Ø250 mmX travel250 mmY travel+/-50 mmZ travel550 mmDistance between spindle noses800 mmMain drive 1Type of main driveAC Drive power (100% DC)12,6 kWDrive power (40% DC)14 kWSpeed range-5500 rpmTorque (100% DC)171 NmMax. torque (40% DC)192 NmC-Axis Speed100 rpmTorque of C-Axis (holding torque)168 NmWork spindleSpindle noseA2-6 Spindle diametre on front bearing120 mmSpindle bore73 mmBar diameter max.65 mmTool holder 1Number of tool stations12 Speed max.6000 rpmNumber of driven tools12 Power max. (40% DC)4,6 kWDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable d ...
General2-axes universal turning center with driven tools, C-axis and Y-axis; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over bed650 mmSwing diameter over X linear guideways370 mmMax machining diameter320 mmClamping chuck Ø250 mmX travel250 mmY travel+/-50 mmZ travel550 mmDistance between spindle noses800 mmMain drive 1Type of main driveAC Drive power (40% DC)14 kWDrive power (100% DC)12,6 kWSpeed range-5500 rpmTorque (100% DC)171 NmC-Axis Speed100 rpmMax. torque (40% DC)192 NmTorque of C-Axis (holding torque)168 NmWork spindleSpindle noseA2-6 Spindle diametre on front bearing120 mmSpindle bore73 mmBar diameter max.65 mmTool holder 1Number of tool stations12 Number of driven tools12 Speed max.6000 rpmPower max. (40% DC)4,6 kWDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable d ...
General2-axes universal turning center with driven tools, C-axis and Y-axis; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over bed650 mmSwing diameter over X linear guideways370 mmMax machining diameter320 mmClamping chuck Ø250 mmX travel250 mmY travel+/-50 mmZ travel550 mmDistance between spindle noses800 mmMain drive 1Type of main driveAC Drive power (100% DC)12,6 kWDrive power (40% DC)14 kWSpeed range-5500 rpmTorque (100% DC)171 NmMax. torque (40% DC)192 NmC-Axis Speed100 rpmTorque of C-Axis (holding torque)168 NmWork spindleSpindle noseA2-6 Spindle diametre on front bearing120 mmSpindle bore73 mmBar diameter max.65 mmTool holder 1Number of tool stations12 Number of driven tools12 Speed max.6000 rpmPower max. (40% DC)4,6 kWDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable d ...
Working areaSwing diameter over bed650 mmSwing diameter over X linear guideways370 mmMax machining diameter320 mmClamping chuck Ø250 mmX travel250 mmY travel+/-50 mmZ travel550 mmDistance between spindle noses800 mmGeneral2-axes universal turning center with driven tools, C-axis and Y-axis; Control: CELOS with Siemens 840D sl Operate Main drive 1Type of main driveAC Drive power (100% DC)12,6 kWDrive power (40% DC)14 kWSpeed range-5500 rpmTorque (100% DC)171 NmMax. torque (40% DC)192 NmC-Axis Speed100 rpmTorque of C-Axis (holding torque)168 NmTool holder 1Number of tool stations12 Number of driven tools12 Speed max.6000 rpmPower max. (40% DC)4,6 kWWork spindleSpindle noseA2-6 Spindle diametre on front bearing120 mmSpindle bore73 mmBar diameter max.65 mmDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable d ...
General2-axes universal turning center with driven tools, C-axis and Y-axis; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over bed650 mmSwing diameter over X linear guideways370 mmMax machining diameter320 mmClamping chuck Ø250 mmX travel250 mmY travel+/-50 mmZ travel550 mmDistance between spindle noses800 mmMain drive 1Type of main driveAC Drive power (100% DC)12,6 kWDrive power (40% DC)14 kWSpeed range-5500 rpmTorque (100% DC)171 NmMax. torque (40% DC)192 NmC-Axis Speed100 rpmTorque of C-Axis (holding torque)168 NmWork spindleSpindle noseA2-6 Spindle diametre on front bearing120 mmSpindle bore73 mmBar diameter max.65 mmTool holder 1Number of tool stations12 Number of driven tools12 Speed max.6000 rpmPower max. (40% DC)4,6 kWDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable d ...
General2-axes universal turning center with driven tools, C-axis and Y-axis; Control: CELOS with Siemens 840D sl Operate Main drive 1Type of main driveAC Drive power (100% DC)12,6 kWDrive power (40% DC)14 kWSpeed range-5500 rpmTorque (100% DC)171 NmMax. torque (40% DC)192 NmC-Axis Speed100 rpmTorque of C-Axis (holding torque)168 NmWorking areaSwing diameter over bed650 mmSwing diameter over X linear guideways370 mmMax machining diameter320 mmClamping chuck Ø250 mmX travel250 mmY travel+/-50 mmZ travel550 mmDistance between spindle noses800 mmWork spindleSpindle noseA2-6 Spindle diametre on front bearing120 mmSpindle bore73 mmBar diameter max.65 mmTool holder 1Number of tool stations12 Number of driven tools12 Speed max.6000 rpmPower max. (40% DC)4,6 kWDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable d ...
General2-axis universal turning machine with - partiall hollow clamping device (hydr.) inner draw tube Ø 52 mm - C-axis and spindle brake (hydr.) - 12 stations circle revolver Sauter reception acc. VDI 30, DIN 69880-30 with tool drive Connection/drive acc. DIN 5480 Direct measuring system, glas scale in X-axis - tailstock; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTransverse stroke210 mmLongitudinal stroke525 mmClamping chuck diameter max.210 mmMain drive 1Drive power (100% DC)13 kWSpeed range20 - 6000 rpmTorque (100% DC)171 NmC-Axis Speed-300 rpmTorque of C-Axis (holding torque)192 NmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose140h5 mmSpindle bore73 mmSpindle diametre on front bearing100 mmTool holder 1Number of tool stations12 Shank diametre according to DIN 6988030 mmNumber of driven tools12 Speed max.-500 ...
GeneralCNC Turning Centre; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways710 mmClamping chuck diameter max.315 mmLongitudinal stroke1345 mmTransverse stroke260 mmWork spindle (left)Spindle bore91 mmSpindle diametre on front bearing140 mmMain drive 1Drive power (100% DC)22 kWSpeed range- 4000 rpmTorque (100% DC)410 NmMax. torque (40% DC)525 NmAccuracy at point stopping0,001 degreeTool holder 1Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.-6000 rpmPower max. (100% DC)10 kWFloor space/WeightWeight approx.7800 KgDimensions (L x W x H)5,4 x 2,07 x 2,6 mPlug-in board with 2x4 free in-/outputsInputs / outputs programmable via M-functions, consisting of: 8 inputs 4 outputs, 2 amperes 4 outputs, potential-freeExcentric turning and milling operationExcentric turning and milling operation (only with Sie ...
used
Max. workpiece diameter 400 mm Max. workpiece length 800 mm Max. bar capacity diameter 80 mm Max. X-axis stroke276 mm Max. Z-axis stroke 755 mm Controller Siemens Spindle speed 4000 rpm With C axis
used
With C and Y axis Max. workpiece diameter 366 mm Max. workpiece length 708 mm Max. bar capacity diameter 105 mm Max. X-axis stroke 260 mm Max. Y-axis stroke 120 mm Max. Z-axis stroke 795 mm Controller Siemens
General2 spindles automatic lathe - 2 cross slides - Main and counter spindle - Y axis on slide 1 - Y axis on slide 2 - C axis on main spindle - C axis on counter spindle - Chip tank with coolant system and coolant pump - Part unloading chute; Control: Numeric control Fanuc 32i Working areaBar diameter max.20 mmCounter spindle collet cleaningCounter spindle collet cleaning with coolantChanging kit from steady to sliding headstockChanging kit from steady to sliding headstock including application bush type Dunner B260 and bush-spindle syncronismAdditional charge for belt type chip conveyorAdditional charge for belt type chip conveyor, compatible with shaft-unloading-device Specific chip removol systems (for example: scraping blades chip conveyors, with additional filtering systems) are recommended in case of short chip material machininOil mist filter for emulsion or oilOil mist filter fo ...
GeneralVertical Machining centre; Control: DMG MORI ERGOline IV HEIDENHAIN TNC 7 CharacteristicsTable surface900 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar - Chip conveyor (scraper type) with tank capacity: 200 l(left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electronic handwheAir coolant internal (through spindle centre)Air Coolant Internal (through spindle centre) switchable via M-Function maintained air wi ...
GeneralVertical Machining centre; Control: DMG MORI ERGOline X Multi-Touch control CharacteristicsTable surface900 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z42/42/42 m/minSpindle speed range 20 to 12.000 rpmSpindle speed range 20 to 12.000 rpm AC main drive:13/9 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar - Chip conveyor (scraper type) with tank capacity: 200 l(left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electronic handwheAir coolant internal (through spindle centre)Air Coolant Internal (through spindle centre) switchable via M-Func ...
GeneralVertical-Machining centre Stealth Design; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Longitudinal1450 mmCross700 mmVertical550 mmTableTable surface 1760 x 750 mmMaximum load (table centre) 2000 KgSlot width 14 mmNumber of Slots 7Distance between T-Slots 100 mmSpindle speed 20.000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Tool magazine 30 pockets HSK-A63Tool magazine 30 pockets HSK-A63 Chain magazine with pockets and with double gripper, incl. manually direct tool loading into the tool magazineInternal coolant supply package 40 bar / 600 lInternal coolant supply package 40 bar / 600 l conte ...
Control: Siemens Sinumerik 840 D Travel: X-axis: 800 mm Y-axis: 1,050 mm Z-axis: 850 mm Mount: HSK 100 Tool magazine: 60-fold Gear spindle: 8,000 rpm Workpiece diameter max.: 900 mm Max. workpiece height: 1,450 mm Conveyor Coolant device with low-bed filter Coolant supply through the spindle 2-fold pallet changer 3-D Probe (Renishaw) Blum Laser Aspirator
swing diameter: 640 mm max. turning passage: 640 mm control: Simens 840 D Powerline - - - - - Main spindle - - - - -: - - - - - - bar material dia.: 65 mm chuck diameter: 200 - 315 mm spindle bore diameter: 80 mm diam. of main spindle in forward position: 120 mm --- Subspindle ---: - - - - - - bar material dia.: 65 mm chuck diameter: 315 mm spindle bore diameter: 80 mm forward bearing diameter: 120 mm - - - - - General data - - - - -: - - - - - - spindle distance: 1.500 mm turning length: 1.185 mm Main-/Counter -spindle turning speeds: 5.000 U/min driven tools turning speeds: 12.000 U/min Slide cross: X1, Y1: 550 / 180 mm Slide cross: Z1: 1.185 mm Slide cross: B1: 240 ° Slide cross: X2: 180 mm Slide cross: Z2: 1.050 mm Slide cross: Z3: 1.150 mm CNC Turning- and Milling Center | DMG GILDEMEISTER - GMX 250 linear equipped with main/counter spindle, chip conveyor, tool changer, a turret fo ...
Control Heidenhain ... TNC 530 Clamping table surface ... 600x1000mm Axis X ... 630mm Axis Y ... 560mm Axis Z ... 560mm Spindle speed ... 0-12000 rpm controlled axes ... 5 cooling HSK 63 Table diameter ... 600mm Magazine spaces ... 24 Main engine power ... 15/10kW Max. workpiece weight ... 500kg The machine is in good condition, possible to test under power.
