dm used for sale

GeneralUniversal machining centre; Control: Siemens 840D-Powerline ShopMill Classic Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Cross1000 mmLongitudinal1250 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 100 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machiningProd. package 40 bar/23 l/minCoolant through spindle centre form AD 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) clear-view rotating window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pumpNC rotary table with pallet changerType of Measuring system Direct measuring  ...

GeneralUniversal machining centre; Control: Siemens 840D-Powerline ShopMill Classic Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal1250 mmCross1000 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 63 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machiningProd. package 40 bar/23 l/minCoolant through spindle centre form AD 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) clear-view rotating window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pumpNC rotary table with pallet changerType of Measuring system Direct measuring s ...

GeneralUniversal machining centre; Control: 3D Control Siemens 840D powerline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal1250 mmCross1000 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 100 Tool changerApplicationUniversal Type of magazineChain Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machiningProd. package 40 bar/23 l/minCoolant through spindle centre form AD 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) clear-view rotating window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar / 90 psi) (6 water jets, 4 air jets) pumpNC rotary table with pallet changerType of Measuring system Direct measuring system ...

GeneralUniversal machining centre; Control: Siemens 840D-Powerline ShopMill Classic Technical DataRapid traverse longitudinal/transverse/vertical60/60/60 m/minFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minWorking area 1Longitudinal1250 mmCross1000 mmVertical1000 mmMiscellaneousClamping SystemHSK-A 63 Tool changerType of magazineChain ApplicationUniversal Tool changer planehorizontal Type of gripperDouble gripper Automatic swivel milling headUniversal head: automatic changeover from vertical to horizontal machiningProd. package 40 bar/23 l/minProduction package 40 bar/23 l/min / 580 psi/6 gallon/min (theoretical pump performance) tank 900 l, rotating clear-view window, scraper flight conveyor coolant through spindle centre form ADNC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 1000 x 800 mmTool magazine,chain, 60 pockets ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mmNumber of Slots 5Spindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmTool magazine, cha ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal700 mmCross700 mmVertical700 mmMiscellaneousClamping SystemHSK-A 63 CabineFull protection cabinMain driveDrive power (100% DC) 20 kWDrive power (40% DC) 20 kWSpeed range - 12000 rpmSpindle taper HSK-A 63NC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mmNumber of Slots 5Spindle taper HSK-A 63Spindle taper for HSK-A 63 to DIN 69893 (incl. adaptation working spindle, tool changer and tool magazine)4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmTool magazine, cha ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Working area 1Longitudinal560 mmVertical600 mmCross600 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMiscellaneousClamping SystemDIN ISO 7388 CabineFull protection cabinNC rotary table with pallet carrierNC rotary table with pallet carrier permissible load 500 kg / 1,100 lbs (no indexing table 360 x 1° in basic machine)Table surface 400 x 400 mmMaximum load (table centre) 500 Kg4. Axes (swivelling range) 360 x 0,001 degreeTool magazine, chain Vert., 60 pocketsTool magazine Vertical chain magazine with 60 tool pockets SK 40 or optional chosen spindle tapersMotor spindle SK 40 18,000 rpmMain drive: Integrated motor spindle SK 40 Spindle speed max. 18,000 rpmDrive power (100% DC) 28 kWDrive power (40% DC) 34 kWSpi ...

GeneralVertical-Machining centre Stealth Design; Control: CELOS with Heidenhain TNC 640 Technical DataRapid traverse longitudinal/transverse/vertical42/42/42 m/minFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minWorking area 1Cross700 mmLongitudinal1450 mmVertical550 mmIntegrated motor spindle speedMASTER®Integrated motor spindle speedMASTER® At speeds > 18.000 min-1, the use of tools with dual contact system (BIG-PLUS®) is stipulated.Drive power (100% DC) 25 kWDrive power (40% DC) 35 kWTorque (100% DC) 86 NmTableTable surface 1760 x 750 mmClamping System DIN ISO 7388-3-ADSpindle taper SK40 Tool holder DIN ISO 7388-1-ASpeed range - 20000 rpmTorque (40% DC) 130 NmSlot width 14 mmMaximum load (table centre) 1500 KgNumber of Slots 7Distance between T-Slots 100 mmCabin roofCabin roof In sheet steel design Open and close via front doorSpecial equipmentClamping pneuma ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Working area 1Longitudinal560 mmCross600 mmVertical600 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minCabineFull protection cabinDirect measuring systemDirect path measuring systemNC rotary table with pallet carrierNC rotary table with pallet carrier permissible load 500 kg / 1,100 lbs (no indexing table 360 x 1° in basic machine)Tool magazine, chain Vert., 60 pocketsTool magazine Vertical chain magazine with 60 tool pockets4. Axes (swivelling range) 360 x 0,001 degreeMaximum load (table centre) 500 KgTable surface 400 x 400 mmMotor spindle 18,000 rpmMain drive: Integrated motor spindle incl. active coolingSpindle taper CAT 40Speed range - 18000 rpmTorque (40% DC) 110 NmTorque (100% DC) 84 NmDrive power (40% DC) ...

GeneralHorizontal Machining Centre; Control: 3D Control Siemens 840D solutionline Working area 1Cross600 mmLongitudinal560 mmVertical600 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minCabineFull protection cabinDirect measuring systemDirect path measuring systemNC rotary table with pallet carrierNC rotary table with pallet carrier permissible load 500 kg / 1,100 lbs (no indexing table 360 x 1° in basic machine)Tool magazine, chain Vert., 60 pocketsTool magazine Vertical chain magazine with 60 tool pockets4. Axes (swivelling range) 360 x 0,001 degreeMaximum load (table centre) 500 KgTable surface 400 x 400 mmMotor spindle 18,000 rpmMain drive: Integrated motor spindle incl. active coolingSpindle taper CAT 40Speed range - 18000 rpmTorque (40% DC) 110 NmTorque (100% DC) 84 NmDrive power (40% DC) ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS X with Siemens SINUMERIK ONE Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/minNC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 505 x 500mm / 19.9 x 19.6 in swivel range -35 to +110°, rotary axis 360° including direct measuring system for B- and C-axis and working plane transformationTool clamping for HSK-A63Tool clamping HSK-A63 according DIN 69893 (incl. adaptation working spindle and tool magazine)Tool magazine 60 pocketsTool magazine 60 places HSK-A63 Vertical chain with double gripper incl. set up station for tool loadingChip removal package with cabin roofSwarf removal package chip conveyor Coolant - air-blast changeover Swarf con ...

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.14500 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinPackage Mill / Turn HSK-A 63Package Milling / Turning: Upgrade NC-swivel rotary table to Milling - Turning / direct drive Table plate C-axis d 680 mm / 26.8 in Speed C-axis 1.000 min-1 Integrated balancing sensor Motor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20 ...

GeneralUniversal Machining Centre in monoBLOCK construction - MPC Machine Protection Control - Chip trough with integrated coolant tank 500 l / 132 gallon; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal750 mmCross650 mmVertical560 mmTechnical DataDrive power (100% DC)25 kWDrive power (40% DC)35 kWTorque (100% DC)86 NmTorque (40% DC)130 NmSpeed range- 20000 rpmSpindle taperHSK-A 63 DIN 69893 Feed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minTool changerTool changer planevertical Type of gripperDouble gripper Number of tools60 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmMiscellaneousClamping SystemDIN 69872 Floor space/WeightWeight approx.12300 KgNC swivel rotary tableTable surface 800 x 650 (Ø 650) mmCentre bor ...

DMG MORI SEIKI DMC 635 V Ecoline CNC machining center was built in 2013. The machine, designed for precision machining of workpieces, is distinguished by its extremely stable construction made of high-quality cast iron, which perfectly dampens any vibrations and oscillations. To achieve the highest precision and accuracy, reliable components in the form of cutting tools and a high-speed spindle are used in the machining process. Tools are changed in a very short time, so that the overall milling time is significantly reduced. The DMG DMC 635 V ECO CNC vertical machining center is offered with a modern touchscreen control panel and integrated chip conveyor. To this date, the machine has only worked for 9069 hours. The DMC 635 V ECOLINE milling center weighs 3900 kg. Technical specifications of the CNC milling machine DMC 635 V ECO - number of axes: 3 (X,Y,Z) - feed in the X/Y/Z ax ...

GeneralUniversal machining centre New DMG MORI Design; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal400 mmCross400 mmVertical375 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightDimensions (L x W x H)6,21 x 6,58 x 2,69 (6,21 x 7,38 x 2,69) mWeight approx.7200 KgDie and Mold Package linearDie and Mold Package linear Dynamic package V-type Eagle timing belt for Z axisPackage Mill / TurnPackage Mill / Turn (only available for Siemens 840D solutionline) NC-Mill-turn table 450x450 mm / 17.7x17.7 in rounded down to d460 mm / 18.1 in C ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline IV HEIDENHAIN TNC 7 CharacteristicsTable surface900 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar - Chip conveyor (scraper type) with tank capacity: 200 l(left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electronic handwheAir coolant internal (through spindle centre)Air Coolant Internal (through spindle centre) switchable via M-Function maintained air wi ...

GeneralUniversal Machining Centre Vertical headstock Tool change system double gripper NC-Swivel rotary table with pallet carrier 3 pallets 500 mm x 500 mm / 19.7 in x 19.7 in T-slots according to DIN 55201-A2 linear pallet changer coolant tank 500 l / 132 gallon chip conveyor with netting band filter integrated, coolant ring jet; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmFloor space/WeightWeight approx.18300 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinNC swivel rotary table with pallet carrierTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 500 KgMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000  ...

Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal650 mmCross700 mmVertical950 mmGeneralHorizontal universal machining center; Control: CELOS with Siemens 840D sl Operate CabineFull protection cabinMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Taper cleaning brushesTaper cleaning unit with rotating brushes for spindle taper HSKNC swivel rotary table DirectDriveNC swivel rotary table direct drive Table plate: d 650 mm / 25.6 in 1 x T-slot 14 H7 / 0.55 H7 (alignment groove, table centre) 8 x T-slot 14 H12 / 0.55 H7 (clamping grooves) Permissible load: 600 kg / 1,323 lbs Rotary-axis: 80 min-1 direct drive Swivel-aKinematics a ...

GeneralTravelling column machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal3000 mmCross1100 mmVertical1050 mmFeed drives:Feed rate X / Y / Z42000/42000/42000 mm/minRapid feed X / Y / Z42/42/42 m/minNC-swivel head (B-axis)Controlled NC-swivel milling head (B-axis) with clamping in position. Continuously positioning NC swivel milling head with integrated motor spindle for 4/5 axes positioning and simultaneous machining. Swivel torque: 3,300 / 2,300 Nm // 2,433 / 1,696 ftDynamic package for DMF 300|11 linearDynamic package for DMF 300|11 linear Linear motor X-axis with 80 m/min // 262.48 ft/min Rapid speed XYZ 80 m/min // 262.48 ft/min Acceleration XYZ 8 m/s² // 26.25 ft/s² Active cooling for Linear motorToolchanger with twin-grippertoolchanger with twin-gripperType of magazine ChainNumber of tools 40CabineFull protection cabinPackage Mill / Turn 20,000 rpm, H ...

Control: SIEMENS - 840 D - - -: - - - - - - - - -: - - - - - - Milling Machine - Horizontal | DMG - DMC 60H linear The machine is in a well-maintained condition. The machine video from the production plant will be shared on request. Technical data of the machine will follow soon. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: DMC60Hlinear | DMC 60-H | DMG - DMC 60 H The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

GeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Cross650 mmLongitudinal735 mmVertical560 mmTool changerTool changer planevertical Type of gripperDouble gripper Number of tools90 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.12400 KgNC swivel rotary table integrated in rigid tableType of Measuring system Direct measuring systemTable surface 800 x 650 (Ø 650) mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mmNumber of Slots 9Rotation Speed 5. Axis 20 rpm5. Axes (swivelling range) +120/-120 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeRot ...

Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minGeneralHorizontal 5-axis universal machining centre; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal850 mmCross900 mmVertical1150 mmCabineFull protection cabinMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Taper cleaning brushesTaper cleaning unit with rotating brushes for spindle taper HSKNC swivel rotary table DirectDrive CNC swivel rotary table direct drive C-axis with pallet carrier Permissible load: 800 kg / 1,760 lbs C-axis: 80 min-1 direct drive A-axis: 15 min-1 single drive Rotation C axis: endlessly turning Swivel range A axis: +120°/-120° (replacement of base machKi ...

GeneralVertical machining center in C-frame-design New DMG MORI Design Direct Measuring system X,Y,Z; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Cross520 mmLongitudinal650 mmVertical475 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools60 TableTable surface 960 x 570 mmMaximum load (table centre) 800 KgSlot width 14 mmNumber of Slots 5Distance between T-Slots 100 mmSpindle speed 20.000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Tool magazine 60 pockets HSK-A63Tool magazine 60 pockets HSK-A63 Chain magazine with pockets and with double gripper, incl. manually direct t ...

GeneralVertical Machining centre; Control: Control SIEMENS ERGOline IV CharacteristicsTable surface1400 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z1100/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar - Chip conveyor (scraper type) with tank capacity: 220 l (left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electronic handwhAir coolant internal (through spindle centre)Air Coolant Internal (through spindle centre) switchable via M-Function maintained air with low o ...

This 5-axis DMG DECKEL MAHO DMU 70 EVO Linear was manufactured in 2009. It features a working area with X-axis travel of 750 mm, Y-axis travel of 600 mm, and Z-axis travel of 520 mm. The machine is equipped with a high-speed spindle capable of reaching 24,000 rpm and a tool magazine with a capacity of 120 positions. It includes a DMG PH 150 L8 automation. If you are looking to get high-quality machining capabilities, consider the DMG DECKEL MAHO DMU 70 EVO Linear machine we have for sale. Contact us for further details.

GeneralTraveling column machine DMG MORI Design; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal1800 mmCross700 mmVertical700 mmTool changerType of magazineChain Number of tools30 Max. tool weight6 KgMax. tool length300 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmFloor space/WeightDimensions (L x W x H)6,75 x 3,45 x 2,75 mWeight approx.14320 KgMiscellaneousClamping SystemDIN 69872 NC-swivel head (B-axis)Controlled NC-swivel milling head (B-axis) with clamping in position. Continuously positioning NC swivel milling head with integrated motor spindle for 4/5 axes positioning and simultaneous machining. Swivel range: +/- 90° Swivel speed: 40 rpmFixed tableFixed TableTable ...

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Longitudinal350 mmCross420 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWDrive power (40% DC) 8,5 kWTorque (100% DC) 41 NmTorque (40% DC) 48 NmSpeed range 20 - 15000 rpmSpindle taper BT 30Clamping System ISO 7388-3 - JD30ToolchangertoolchangerTableTable surface 740 x 420 mmNumber of tools 15Type of magazine WheelMaximum load (table centre) 400 KgPreparation NC-Devider EA510 indirectPreparation 4.th axis Lehmann EA 510.L indirect measuring System Attention: Customer specific optimisations and adjustments are not part of delivery!Chip removal package with chip conveyorChip removal package with chip conveyor conte ...

This 3-axis DMG DECKEL MAHO DMC 63 V was manufactured in 2003. It features an X-axis travel of 630 mm, Y-axis travel of 500 mm, and Z-axis travel of 500 mm. The machine is equipped with a Siemens 840D control unit and has a spindle speed of 10,000 rpm. If you are looking to get high-quality machining capabilities, consider the DMG DECKEL MAHO DMC 63 V vertical machining centre we have for sale. Contact us for further details.

This 3-axis DMG DECKEL MAHO DMC 104V linear was manufactured in 2006. It features an X-axis travel of 1040 mm, Y-axis travel of 600 mm, and Z-axis travel of 500 mm. The machine includes a robust table size of 1250 x 600 mm and a maximum table load of 800 kg. If you are looking to get high-quality machining capabilities, consider the DMG DECKEL MAHO DMC 104V linear vertical machining centre we have for sale. Contact us for further details.

This 5-axis DMG MORI DMP 70 was manufactured in 2019. It features a maximum spindle speed of 24,000 rpm and a weight of 4,250 kg, making it a robust option for precision machining. If you are looking to get high-quality machining capabilities, consider the DMG MORI DMP 70 vertical machining centre we have for sale. Contact us for further details.

Key data: 800 mm, 800 mm, 800 mm

We hereby offer you a 5-axis machining centre from DMG as follows: Basic machine data Make: DMG Type: DMU 80 P duoBlock Year of Make: 2006 Condition: Good  Control: Name: Heidenhain iTNC 530 Handwheel: Heidenhain HR 410 Technical data: • Spindle: 18000 rpm, infinitely variable • HSK-A63 interface • 120x WZW • B-axis (infinitely variable) • C-axis • Table size: 900 mm x 700 mm • Table load: max. 1400 kg • IKZ (internal coolant supply) 40 bar • Chip conveyor • Coolant tank with paper belt filter Prior sale is reserved. No liability is assumed for the technical information provided here. The legal provisions apply.

Key data: 1000 mm, 900 mm, 700 mm

We hereby offer you a 5-axis machining centre from DMG as follows: Basic machine data Make: DMG Type: DMU 100 eVo Year of Make: 2013 Condition: Very good – machine partially overhauled in 2023  Control: Name: Heidenhain iTNC 530 Handwheel: Heidenhain HR 410 Technical data: • Spindle: 18000 rpm, infinitely variable • HSK-A63 interface • 60x WZW • Swivel rotary table 950 mm x 800 mm • B-axis 5°/+110° • C-axis 360° • IKZ (internal coolant supply) 40 bar • 600 l coolant tank with paper belt filter • Chip conveyor • Rinsing gun • Blowing air through spindle center Prior sale is reserved. No liability is assumed for the technical information provided here. The legal provisions apply.

Key data: 730 mm, 560 mm, 560 mm

We hereby offer you a 5-axis machining centre from DMG as follows: Basic machine data Make: DMG Type: DMU 60 monoBlock Year of Make: 2006 Condition: Good  Control: Name: Heidenhain iTNC 530 Handwheel: Heidenhain HR 410 Technical data: • Spindle: 20-18000 rpm, infinitely variable • HSK-A63 interface • 60x WZW • Rotary table Ø 600 mm (C-axis) integrated into 1000 mm x 600 mm • B-axis (infinitely variable) • IKZ (internal coolant supply) 40 bar • 600 l cooling lubricant tank with paper belt filter • Chip conveyor • Rinsing gun • Oil and emulsion separation plant • Blowing air through spindle center Prior sale is reserved. No liability is assumed for the technical information provided here. The legal provisions apply.

This 5-axis DMG DMU 40 evo was manufactured in 2013. It features a maximum spindle speed of 18,000 rpm and a tool magazine capacity of 60 tools. The working area measures 400 x 400 x 375 mm, providing ample space for various machining tasks. If you are looking to get high-quality machining capabilities, consider the DMG DMU 40 evo vertical machining centre we have for sale. Contact us for further details.

This 5-axis DMG MORI DMU 50 3rd gen was manufactured in 2017. It features impressive axis travels of 650 x 520 x 475 mm and a maximum spindle speed of 15,000 rpm. The machine includes a tool magazine capacity of 60 positions and a robust table diameter of 630 mm. If you are looking to get high-quality machining capabilities, consider the DMG MORI DMU 50 3rd gen vertical machining centre we have for sale. Contact us for further details.

GeneralHorizontal machining centre - Horizontal milling head; Control: CELOS with Siemens 840D sl Operate Technical DataRapid traverse longitudinal/transverse/vertical60/60/70 m/minFeed rate longitudinal/transverse/vertical60000/60000/70000 mm/minWorking area 1Longitudinal800 mmCross1050 mmVertical900 mmCabineFull protection cabinDirect measuring systemDirect path measuring systemNC rotary table with pallet changerType of Measuring system Direct measuring systemTable surface 630 x 630 mmRotation speed max.4. Axis 40 rpmDistance between T-Slots 100 mmNumber of Slots 5Slot width 14 mmMaximum load (table centre) 900 KgCentre bore 50 mm4. Axes (swivelling range) 360 x 0,001 degreePackage recirculation ballscrew spindlePackage recirculating ballscrew spindle X-,Z-axis:max. feed speed: 60.000 mm/min Y-axis: max. feed speed: 70.000 mm/min (basic machine without linear drive X-, Y-, Z-axis)Motor ...

GeneralVertical-Machining centre Stealth Design; Control: CELOS X with Siemens 840D SL Operate CharacteristicsTable surface1460 x 750 mmMaximum load (table centre)1500 KgTool Magazine with40 PositionsMovement X / Y / Z1150/700/550 mmRapid feed X / Y / Z42/42/42 m/minWeight approx.12900 KgSpindle speed 20 - 12,000 rpm SK50, 288NmSpindle speed 20 - 12.000 rpm SK50 for tool taper according to DIN ISO 7388-1-A50 with power 44/32 kW // 59.0/42.9 hp with torque 288/187 Nm (40/100% DC) (differently from standard)Tool magazine 40 pocketsTool magazine 40 pockets SK50 chain magazine with pockets and double gripper, incl. manually direct loading into the tool magazineCoolant-air blast change-overCoolant - Air-blast changeover external switchable via M-FunctionAir blast through spindle centreAir blast through spindle centre activated by M function, maintained air with low oil rateInternal coolant su ...

GeneralVertical machining center in C-frame-design New DMG MORI Design Direct Measuring system X,Y,Z; Control: CELOS with Heidenhain TNC 640 Technical DataFeed rate longitudinal/transverse/vertical1-42000/1-42000/1-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minWorking area 1Longitudinal650 mmCross520 mmVertical475 mmTool changerType of magazineChain Type of gripperDouble gripper Number of tools30 TableTable surface 960 x 570 mmMaximum load (table centre) 800 KgSlot width 14 mmNumber of Slots 5Distance between T-Slots 100 mmSpindle speed 15,000 rpm, 200 NmMotor spindle speedMASTER® SK 40 Spindle speed 20 - 15,000 min-1 Output 46 kW / 30 kW (62 hp / 40 hp) Torque 200 Nm / 130 Nm (148 ft lbs / 96 ft lbs) (40 / 100 % duty cycle) BIG-PLUS® tools possibleTool magazine 30 pockets SK40Tool magazine 30 pockets SK40 Chain magazine with pockets and with double gripper,  ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline X Multi-Touch control CharacteristicsTable surface900 x 600 mmTool Magazine with60 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z42/42/42 m/minSpindle speed range 20 to 12.000 rpmSpindle speed range 20 to 12.000 rpm AC main drive:13/9 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar - Chip conveyor (scraper type) with tank capacity: 200 l(left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electronic handwheAir coolant internal (through spindle centre)Air Coolant Internal (through spindle centre) switchable via M-Func ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline IV Multi-Touch CharacteristicsTable surface900 x 600 mmTool Magazine with30 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 40 barProduction Package 40 bar Option includes: - Internal coolant supply 40 bar; - Tank capacity: 600l with papertype filter; - Chip conveyor (scraper type) with tank capacity: 200 l (left) - Bed flushing via M-Function - Coolant spray gun for swarf removal -Tool clamping buttons on the headstockTool Clamping and Unclamping Buttons placed on the Headstock CoverAir coolant internal (through spindle centre)Air Coola ...

GeneralVertical Machining Centre - Direct Measuring System X, Y, Z - Coolant air-blast changeover external switchable via M-Function; - Thermal compensation - DMG MORI NETservice; Control: DMG MORI ERGOline X Multi-Touch control Siemens CharacteristicsMovement X / Y / Z800/600/510 mmType of magazineChain Tool Magazine with30 PositionsClamping SystemDIN 69872 Spindle taperSK 40 DIN 69871 Drive power (40% DC)20 kWDrive power (100% DC)14,5 kWSpeed max.15000 rpmRapid feed X / Y / Z42/42/42 m/minTable surfaceØ 800 x 620 mmMovement C-Axis360 degreeMovement B-Axis(-15/+110) degreeType of gripperDouble gripper Production Package 20 bar with chip conveyorProduction Package 20 bar with chip conveyor Option includes: - Internal coolant supply 20 bar; - Chip conveyor (scraper type) with tank capacity: 205 l (left) - Bed flushing via M-Function - Coolant spray gun for swarf removal - External electr ...

GeneralVertical Machining centre; Control: DMG MORI ERGOline IV Multi-Touch CharacteristicsTable surface900 x 600 mmTool Magazine with30 PositionsMovement X / Y / Z600/600/510 mmRapid feed X / Y / Z30/30/30 m/minAC main driveSpindle speed range 20 to 15.000 rpm AC main drive:20/14,5 kW (40/100% DC) Tool taper SK40 DIN 69871 Tool clamping according to DIN69872Direct measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemTouch Probe Heidenhain TS 460Touch Probe HEIDENHAIN for workpiece measuring Option includes: - TS 460 Touch probe with optical signal transmission - measuring cycles - calibration ring - case for equipmentTouch probe Heidenhain TT160Touch Probe HEIDENHAIN for tool length and diameter measurement Option includes: - TT160 probe for tool measurement - measuring cycles with tool breakage monitoring - calibration tool Note: Additionally to ...

5-Axis Vertical Machining Center DMG DMC 75V LINEAR Linear Motors The machine can be viewed in working order in our warehouse in Gussago, Brescia. Mimu Machine Tools Gussago BS Italy Dmg DMC 75 Linear Heidenhain CNC iTNC 530 Tool holder HSK 63 Spindle power 35 kW Spindle speed 18,000 rpm Number of tools 60 X-axis travel 885 mm Y-axis travel 600 mm Z-axis travel 600 mm Rapid feeds X-Y-Z linear axes 90 m/min Roller guides Fourth-axis head yes Fourth-axis head type continuous Fourth-axis head degrees -10° + 110° Rotary table yes Rotary table type continuous Table size 750 mm MACHINE EQUIPMENT Precision package with optical scales on the axes New spindle line The machining center is a machine tool equipped with a numerical control capable of performing multiple mechanical operations with a single setup on Multiple surfaces of the same workpiece. It is generally equipped with multiple motio ...

GeneralUniversal milling machine with duoblock construction; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal800 mmCross1050 mmVertical850 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minTool changerApplicationUniversal Tool changer planehorizontal Type of magazineWheel Type of gripperDouble gripper Number of tools123 Coolant supply ICSCoolant supply: coolant through spindle centre form AD 40 bar/23 l/min(theoretical pump performance) rotating clear-view window Multi-jet unit at universal head, switchable from coolant to air (max. 6 bar, 6 water jets, 4 air jets) pump output (theoreticChip removalChip removal: 2 worm conveyors in the machine bed convey into a chip conveyor (scraper flight conveyor), with interval control, placed at right angles. discharge height: 950 mm /  ...

This 3-axis DMG DECKEL MAHO DMU 60 monoBlock was manufactured in 2005. It features a chip conveyor and a coolant system, ideal for complex machining tasks. If you are looking to get high-quality milling capabilities, consider the DMG DECKEL MAHO DMU 60 monoBlock machine we have for sale. Contact us for more information.

This 3-axis DMG DECKEL MAHO DMU 80T was manufactured in 2004. It features a high-speed spindle at 18,000 RPM, internal coolant supply with 40 Bar pressure, and a 32-station tool changer. The machine includes SK 40 tool holders and a Rotoclear viewing window. Ideal for demanding machining tasks, consider the opportunity to buy this DMG DECKEL MAHO DMU 80T vertical machining centre. Contact us for more information about this machine.

This DMG DECKEL MAHO DMC 60T was manufactured in 2005. A Universal machining centre, it offers robust construction and reliable performance for precision machining tasks. Consider the opportunity to buy this DMG DECKEL MAHO DMC 60T Universal machining centre. Contact us for more information.

This 5-axis DMG DECKEL MAHO DMC 125U was manufactured in 2002. A universal machining centre, it offers advanced capabilities for diverse and complex machining tasks. Consider the opportunity to buy this DMG DECKEL MAHO DMC 125U universal machining centre. Contact us for more information.

This 5-axis DMG DMC 100 H was manufactured in 2005. It features a Siemens 840D powerline control with Shopmill, a 1,000 mm travel in X, Y, and Z axes, and a speed range up to 8,000 rpm. The machine includes a HSK 100 tool holder, 270/360 tool positions, and two 800 x 800 mm pallets. Consider the opportunity to buy this DMG DMC 100 H horizontal machining centre. Contact us for more information.

This 5-axis DMG DECKEL MAHO DMU 50 eVo linear was manufactured in 2005. It features a HEIDENHAIN control, a 40bar IKZ, a 60-tool magazine, and a spindle speed of 18k rpm. The machine includes automation capabilities fully adjustable for different product formats and positioning. If you are looking to get high-quality milling capabilities, consider the DMG DECKEL MAHO DMU 50 eVo linear machine we have for sale. Contact us for more information.
