dm used for sale

BAZ DMG Deckel V75linear (ca.16000 spindle hours) BJ 2005

Key data: 800 mm, 700 mm, 600 mm

CNC Universal – Milling & Drilling Machine DECKEL MAHO DMU 80 P hi-dyn With track control Heidenhain iTNC 530 Year of Make: 2004 Travel: X 800 Y 700 Z 600 Speed range: 0 – 8,000 rpm infinitely variable ( SK 50 ) With the following accessories: NC rotary table 900 mm x 700 mm clamping surface Automatic Swivel Milling Head ( HORIZONTAL + VERTICAL ) Universal tool changer with 30 magazine positions as double gripper ( SK 50 ) Full protection cabin with sliding doors and interior lighting Electronic handwheel IKZ – 40 bar Chip conveyor Rotoclear Operating mode 3 + 4 3-Piece Height Adjustable Machine Shoes Swarf Spray Gun Operating Instructions

CONTROLS   CNC continuous-path control 3D MILLPLUS IT V600 WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 3   X-axis travel: 500 mm   Y-axis travel: 450 mm   Z-axis travel: 400 mm TABLE   table surface (left-right): 700 mm   table surface (front-back): 500 mm   workpiece load (max): 500 kg SPINDLE / HEAD   spindle revolutions (min): 20 /min   spindle revolutions (max): 10000 /min   tool fixture: ISO SK 40   drive power: 13 kW AXIS DRIVES   traverse velocity X (max): 24000 mm/min   traverse velocity Y (max): 24000 mm/min   traverse velocity Z (max): 24000 mm/min TOOL MAGAZINE   number of positions: 30   tool diameter max.: 80 mm   - with free neighbour positions: 130 mm   tool length max.: 300 mm   tool weight max.: 6 kg   tool changing time: 8 s ATTACHMENTS   European CE standards: yes No cooling system; the machine i ...

CONTROLS   CNC controls SIEMENS SOLUTION LINE WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 3   X-axis travel: 600 mm   Y-axis travel: 560 mm   Z-axis travel: 510 mm TABLE   table surface (left-right): 900 mm   table surface (front-back): 560 mm   workpiece load (max): 600 kg SPINDLE / HEAD   spindle revolutions (min): 20 /min   spindle revolutions (max): 12000 /min   tool fixture: ISO SK 40   drive power S6 40%: 13 kW   drive power S1 100%: 9 kW   spindle torque S6 40%: 82 Nm   spindle torque S1 100%: 54 Nm AXIS DRIVES   traverse velocity X (max): 20000 mm/min   traverse velocity Y (max): 20000 mm/min   traverse velocity Z (max): 20000 mm/min   rapid traverse X: 30000 mm/min   rapid traverse Y: 30000 mm/min   rapid traverse Z: 30000 mm/min TOOL MAGAZINE   number of positions: 30   tool diameter max.: 80 mm   - wi ...

turning diameter: 600 mm turning length: 1200-1280 mm control: Fanuc 210 : 400 mm spindle bore: 90 mm : 3000 U/min spindle drive motor: 18-36,5 kW x-travel: 320 mm z-travel: 1250 mm : 8 Stationen tail stock: MK5 tool taper: VDI 40 machine weight ab.: 5000- 5500 kg weight of the machine ca.: 3000 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 500 mm y-travel: 450 mm z-travel: 400 mm Control: SIEMENS 840 D control: Powerline Shop Mill table surface area: ø 630 x 500 mm table swivelling +/-: 110/5 Grad spindle taper: SK 40 spindle turning speed - stepless: 20 - 10.000 U/min spindle drive: 13 kW max. torque on the spindle: 82 Nm feed speeds: max. 20.000 mm/min rapid traverse: 24 m/min no. of tools in magazin: 30 wotkpiece diameter with 2 vacant positions: max. 130 mm tool length - max.: 290 mm weight of tools max.: 6 kg total power requirement: 17 kVA weight of the machine ca.: 4,05 t dimensions of machine L x W x H: 2,21 x 2,12 x 2,15 m = 5-axis machining center (5 axis simultaneously) with 2-axis NC swivelling rotary table - only 9.609 spindle hours - - the machine was used for sample and prototype production, 3D machine model for kinematic simulation in a CAM programming system (available in IGES and STEP format ...

This 3-axis DMG DECKEL MAHO DMU 105 V Linear was manufactured in 2004. It features a robust CNC control system, HEIDENHAIN iTNC 530, and has a machine weight of approximately 12,200 kg. The required installation space is 5,700 × 4,700 mm, making it suitable for various machining tasks. If you are looking to get high-quality machining capabilities, consider the DMG DECKEL MAHO DMU 105 V Linear vertical machining centre we have for sale. Contact us for further details.

BAZ Cover Maho DMC 635V ecoline BJ 2013

turning diameter: max. 240 mm turning length: 470 mm control: 840 D sl Operate 4.8 Celos greates pass round over bed: 500 mm swing diameter over slide rest: 290 mm centre distance: 780 mm Main spindle:: turning speed range - main spindle: max. 6.000 min/-1 power capacity - main spindel: 13 / 14 kW max. Torque: 171,5 / 192 Nm inner draw tube diameter: 52 mm C-Axis: 0,001 ° spindle diameter in front bearing: 100 mm spindle nose: FL 140H5 Subspindle:: Spindle speed range subspindle: max. 6.000 min/-1 power capacity - Sub spindle: 12,6 / 16,2 kW max. Torque: 48 / 62 Nm inner draw tube diameter: 37 mm C-Axis: 0,001 ° spindle diameter in front bearing: 90 mm spindle nose: FL 140H5 turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. tool taper: VDI 30 Spindle speed - driven tool stations: max. 5.000 min -1 power capacity - driven tool-stations: 4,18 kW max. T ...

Key data: 640 mm, 600 mm, 500 mm

Spindle speed: 12,000 min/1 Spindle hours: 21600h Control: Siemens Year of Make: 2004 3D Buttons Tool holder SK40 30 tool positions

Manufacturer/ Type: Deckel Maho, DMU 60 P hi-dyn, 5 Axis Milling Machine Year of Make: 2002 Information: Tool changer for 60 SK 40 holders, Mill Plus control, Current condition: The Y axis is out of round by 0.03mm, the machine is not working at the moment because the hard drive has to be replaced Availability: Immediately Accessories: 3D probe, machine manual

Stock number: PC1388, Material: Stainless acid proof steel AISI 316, In stock: Yes, Amount in stock: 1 pc., Item: Centrifugal pump, Construction: On leg stand, Motor: 5.5 kW - 380 Volt - 2910 rpm, Theoretical capacity: Max 60,000 l/h, Stage: 1, Working pressure : Max 3.8 bar, Dimensions inlet: Ø 2, Dimensions outlet: Ø 2, Other: Flushed shaft seal

GeneralTraveling column machine; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical50000/50000/50000 mm/minRapid traverse longitudinal/transverse/vertical50/50/50 m/minWorking area 1Longitudinal2000 mmCross800 mmVertical850 mmTool changerType of magazineChain Number of tools40 Max. tool weight8 KgMax. tool length400 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets130 mmSwivelhead, B-axisControlled NC swivel milling head 15,000 rpm (B-axis) with clamping in position Continuously positioning NC- swivel milling head with integrated motor spindle for 4/5 axes positioning and simultaneous machining. Swivel speed: 50 rpm Swivel range: ±12 Drive power (100% DC) 16 kWDrive power (40% DC) 21 kWTorque (100% DC) 85 NmTorque (40% DC) 111 NmSpeed range 20 - 15000 rpmSpindle taper SK40 Tool holder D ...

GeneralUniversal Milling Machine Stealth Design; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal550 mmCross450 mmVertical420 mmTechnical DataFeed rate longitudinal/transverse/vertical30000/30000/30000 mm/minRapid traverse longitudinal/transverse/vertical30/30/30 m/mininlineMASTER® spindlespeed range 20 - 15.000 min-1 SK40 suitable for BIG-PLUS® tools Drive power (100% DC) 14,5 kWDrive power (40% DC) 20,3 kWTorque (100% DC) 84 NmTorque (40% DC) 121 NmSpeed range 20 - 15000 rpmSpindle taper HSK-A 63 Clamping System HSK-A 63 Toolchanger with set up station for tool loadingNumber of tools 30

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Longitudinal350 mmCross420 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minIntegrated swivel rotary table simultaneousIntegated swivel rotary table DMP 35 version 5-Axis simultaneous mode! Torque drives incl. direct measuring in A- and C-Axis Swivel range A-Axis -120 / + 100 degrees Max. load C-axis 100kg Table diameter C-Axis d290mm Rotary joint, 6-channels Inclusive So Tool magazine 25 placesTool magazine 25 places (suitable for inclusion in the tool spindle) Max. tool length 150 mm Chip-to-chip time 1.6 sec Note: machine width increases to 1410 mm! Spindle speed 24,000 rpmSpindle 24,000rpm with tool taper ISO 7388-2 - J30 BT30 / BBT 30 (BIG PLUS ...

General2 spindles automatic lathe - 2 cross slides - Main and counter spindle - Y axis on slide 1 - Y axis on slide 2 - C axis on main spindle - C axis on counter spindle - Chip tank with coolant system and coolant pump - Part unloading chute; Control: Numeric control Fanuc 32i Working areaBar diameter max.20 mmConveyor belt for finished workpiecesConveyor belt for finished workpieces outside the machine Special equipmentEmulsion kit Special equipment980-liter emulsion tank. 8/20 bar + cooler

Control Heidenhain TNC 124 Travel X/Y/Z: 500 x 400 x 400 mm Spindle speed 4,500 min-1 Tool holder SK 40 Manual rotary table with swivel axis 700 x 500 mm

x-travel: 885 mm y-travel: 600 mm z-travel: 450 mm b-axis: +20/-110 ° c-axis: 360 ° spindle speed:: 18.000 U/min spindle drive: 15 kW Tool adapter: HSK-A63 table diameter: 600 mm Tools changer: 30 fach/tools chip conveyor: kW Internal cooling system: 401 bar Control: HEIDENHAIN iTNC 640 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m DMG HSC 70 – 5-Axis Machining Centre - 5-axis machining centre with linear motors - HEIDENHAIN iTNC 640 - Portal-type construction - Electrospindle with 18,000 rpm - 30-tool automatic tool changer - Probes included for tool and workpiece measurement - Internal coolant supply at 40 bar pressure - BLUM laser tool measurement system - DMG TS649 workpiece measuring probe The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 700 mm y-travel: 550 mm z-travel: 500 mm control: TNC 426 table-size: 900 x 550 mm taper ISO: SK 40 speeds: 18000 U/min total power requirement: 50 kW weight of the machine ca.: 7 t dimensions of the machine ca.: 3,3 x 2,43 x 2,98 m DECKEL MAHO DMC 70 V Hi-dyn machining center featuring: 30-station tool changer Chip conveyor Oil mist filtration system Transport dimensions: 650 x 243 x 297 cm, 8 tonnes The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 640 mm, 640 mm, 640 mm

Vertical machining center Travel x/ y/ z = 640/640/640 mm Work table 850 x 600 mm Rapid traverse x/y/z 70/ 40/ 40 m/min Spindle speed up to 12,000 1/min Motor power 40/100 % 19/ 13 KW Torque 40/100 % 100/ 70 Nm Tool magazine 30-fold Tool holder SK 40 - Coolant system - Chip conveyors - Internal coolant supply - CNC control Heidenhain iTNC530

GeneralVertical Machining Center; Control: Control M730UM with CELOS CharacteristicsTable surface1350 x 600 mmMaximum load (table centre)1200 KgSpeed max.12000 rpmDrive power (100% DC)22 kWDrive power (25% DC)37 kWTool Magazine with30 PositionsSpindle taperBT 40 Movement X / Y / Z1050/530/510 mmRapid feed X / Y / Z30/30/30 m/minDimensions (L x W x H)3,02 x 2,98 x 2,61 mWeight approx.7000 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 " ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and p High-torque spindle 12,000min-1, 37/ 22 kW (#40)High-torque Spindle 12,000 min-1, 37/22 kW (#40) Motor spindle powerMASTER® Spindle speed: 12,000 min-1 Output: 37/22 kW (50/30 HP) (10%ED/cont) Torque: 360/177 Nm (265.52/130. ...

GeneralHorizontal machining center; Control: Siemens S840Dsl with CELOS CharacteristicsSpeed max.-20000 rpmDrive power (100% DC)25 kWDrive power (40% DC)42 kWTable size400x400 mmSwivelling range360x1 degreeMaximum load (table centre)400 KgMax. work piece diameter630 mmMax. work piece height900 mmPalett changer with2 PalletMovement X / Y / Z560/560/660 mmRapid feed X / Y / Z60/60/60 m/minTool Magazine with60 PositionsSpindle taperHSK-A 63 Max. tool length450 mmDimensions (L x W x H)2,68 x 4,19 x 2,54 mWeight approx.8500 KgPreparation for Center Through-spindle coolant systemCenter Through-Spindle Coolant System It can supply coolant through the holes of the spindle and tool. The coolant supply path to the tool tip is a center-through type. Effective for removing chips, cooling a machining point and prolonging a tool life. Spindle Taper HSK-A63Spindle Taper HSK-A63 This specification uses ...

GeneralHorizontal machining center; Control: Siemens S840Dsl with CELOS CharacteristicsSpeed max.-15000 rpmDrive power (100% DC)30 kWDrive power (40% DC)46 kWTable size400x400 mmSwivelling range360x1 degreeMaximum load (table centre)400 KgMax. work piece diameter630 mmMax. work piece height900 mmPalett changer with2 PalletMovement X / Y / Z560/560/660 mmRapid feed X / Y / Z60/60/60 m/minTool Magazine with60 PositionsSpindle taperHSK-A 63 Max. tool length450 mmDimensions (L x W x H)2,68 x 4,19 x 2,54 mWeight approx.8500 KgHigh-torque spindle 46 /30 kW, 15,000 min-1High-torque spindle 46 /30 kW, 15,000 min-1 (SIEMENS) Preparation for Center Through-spindle coolant systemCenter Through-Spindle Coolant System It can supply coolant through the holes of the spindle and tool. The coolant supply path to the tool tip is a center-through type. Effective for removing chips, cooling a machining poin ...

GeneralHorizontal machining center Chip conveyor (ejection to the rear) Coolant gun for setup station side Oil skimmer Sludge collecting function inside coolant tank In-machine measuring system (spindle) touch sensor (Renishaw OMP60) + workpiece setter Tool breakage detection system Manual pulse generator (separate type) Full closed loop control (Scale feedback); Control: Control F31iB with CELOS CharacteristicsSpeed max.-12000 rpmDrive power (100% DC)30 kWTable size630 x 630 mmSwivelling range360 x 1 degreeMaximum load (table centre)1500 KgMax. work piece diameter1050 mmMax. work piece height1300 mmPalett changer with2 PalletMovement X / Y / Z1050/900/1030 mmRapid feed X / Y / Z60/60/60 m/minTool Magazine with60 PositionsSpindle taperBT 50 Weight approx.18750 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 " ERGOline Touch ® control with m ...

GeneralHorizontal machining center Chip conveyor (ejection to the rear) Coolant gun for setup station side Oil skimmer Sludge collecting function inside coolant tank In-machine measuring system (spindle) touch sensor (Renishaw OMP60) + workpiece setter Tool breakage detection system Manual pulse generator (separate type) Full closed loop control (Scale feedback); Control: Control F31iB with CELOS CharacteristicsSpeed max.-12000 rpmDrive power (100% DC)30 kWTable size630 x 630 mmSwivelling range360 x 1 degreeMaximum load (table centre)1500 KgMax. work piece diameter1050 mmMax. work piece height1300 mmPalett changer with2 PalletMovement X / Y / Z1050/900/1030 mmRapid feed X / Y / Z60/60/60 m/minTool Magazine with120 PositionsSpindle taperHSK-A 100 Weight approx.18750 KgCELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 " ERGOline Touch ® control w ...

Year of construction: 2016 CNC controller: CELOS with SIEMENS 840D sl operate 21,5" ERGOline Control with Multi-Touch Screen Axes X-axis travel mm: 800 Y-axis travel mm: 1050 Z-axis travel mm: 850 C-axis degrees: 360º (0,001) B-axis degrees: -30º/180º (0,001) Feed rates m/min: 60 Rapid traverse m/min: 60 Acceleration in the axes m/s2: 7 Milling/turning table nc: Table dimensions mm: Ø900x700 Max. workpiece weight kg: 1800 Table rotation speed rpm: 40 Spindle Spindle speed rpm: 18000 Spindle drive power kW: 35/25 (40/100%ED) Spindle torque Nm: 130/86 (40/100%ED Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 600 Tool system Tool holder: HSK-A 63 Tool magazine slots: 63 Tool changer: Double gripper With free neighboring places mm: 120 With occupied neighboring places mm: 80 Max. Tool Length mm: 650 Max tool weight kg: 15 Chip-to-chip time ...

Manufacturer DMG Model DMU 160P Year 2002 CNC HEIDENHAIN iTNC-530 Table Dimensions of the Work Table 1,500 x 1,250 mm. Maximum weight allowed on table 4,000 kg. Table Rotation (C-Axis) 0.001º (Continuous) Routes and advances Longitudinal course (X-axis) 1,600 mm. Cross Span (Y-Axis) 1,250 mm Vertical course (Z Axis) 1,000 mm. Horizontal Automatic Swivel Head / Vertical (A-axis) 0.001º (continuous) Fast Axis Feed 60,000 mm/min SK-40 Spindle Cone DIN 69871 Speed range 20-18,000 rpm Main Motor Power 28 kW Equipment Automatic tool loader INCLUDED Positions in tool loader 60 Coolant tank capacity 200 l. HEIDENHAIN optical rulers INCLUDED Chip conveyor INCLUDED HEIDENHAIN HR-410 Portable Steering Wheel 3D-Rot INCLUDED Measuring probe piece HEIDENHAIN TS-631 M function for coolant Internal/external INCLUDED Prepared for internal cooling INCLUDED Mode 4 op ...

Stock number: PC1394, Material: Stainless acid proof steel AISI 316, In stock: Yes, Amount in stock: 1 pc., Item: Centrifugal pump, Construction: On leg stand, Motor: 4 kW - 220/380 Volt - 2850 rpm, Theoretical capacity: Max 40,000 l/h, Stage: 1, Working pressure : Max 3.6 bar, Dimensions inlet: Ø 2½, Dimensions outlet: Ø 2

CNC Universal – Machining Center DECKEL MAHO DMU 40 eVo NEW DMG Design with track control Heidenhain iTNC 530 HSCI Year of Make: 2012 Travel: X 400 Y 400 Z 375 Speed range: 20 – 18,000 rpm infinitely variable With the following accessories: NC swivel rotary table 450 mm x 400 mm incl. table cooling 30-fold tool changer with double gripper 3 D probe Renishaw PP 60 optical Electronic handwheel Operating mode 4 Heidenhain Table Pushbutton TD 110 ( Length Measurement ) IKZ 40 bar with paper belt filter Scraper Chip Conveyor Bed Wash Active cooler for control cabinet Spindle Cooling: Water Circulation Cooling Direct displacement measuring system Rinsing gun for chip rinsing Rotoclear Oil mist extraction 3-Piece Height Adjustable Machine Shoes Operating Instructions Signal light 4 colour

DMN Westighouse, type AL 200 SD, inlet and outlet 200 mm, housing and rotor in full stainless steel 1.4408 - Flange connection DIN PN 10, rotor volume 10.5 litres, direct drive SEW 0.55 KW, output speed 20 rpm

Year of construction: 2007 CNC controller: Heidenhain MillPlus IT FD Axes X-axis travel mm: 1250 Y-axis travel mm: 1000 Z-axis travel mm: 1000 C-axis degrees: 360º (0,001) B-axis degrees: 0º/190º Feed rates m/min: 60 Rapid traverse m/min: 60 Milling/turning table nc: Number of pallets: 2 Table dimensions mm: Ø1100 Max. workpiece weight kg: 2000 Table rotation speed rpm: 500 max. torque Nm: 5600 Spindle Spindle speed rpm: 8000 Spindle drive power kW: 28/19(40/100%DC) Spindle torque Nm: 727/492(40/100%DC) Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 980 Tool system Tool holder: HSK-A 100 Tool magazine slots: 120 Chip-to-chip time s: 5 Equipment Electronic Handwheel Chip conveyor Internal cooling lubricant supply Rotating inspection windows Rinsing gun Operating mode 4 blowing air through spindle center selectable via M-function Mi ...

x-travel: 2.600 mm y-travel: 700 mm z-travel: 700 mm control: Celos 840 D SL Operate Siemens Main spindle:: turning speed range - main spindle: 20 - 20.000 min/-1 power capacity - main spindel: 35 / 25 kW Torque: 130 / 86 Nm tool taper: HSK-A63 b - axis: +-100 ° work table:: table surface area: 2.900 x 700 mm max. table load: 2.150 kg tool magazin:: number of toolpositions: 120 pos. tool taper: HSK-A63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. tool length: 300 mm max. tool weight: 6,0 kg feeds:: rapid traverse ( X / Y / Z ): 40 m/min feed speeds: max. 40.000 mm/min feed power: max. 8 kN total power requirement: 67 kVA weight of the machine ca.: 16,24 t dimensions of the machine ca.: 8,0 x 5,6 x 2,9 m Chip conveyor: Coolantsystem: 980 L high pressure coolant: 80 bar through spindle coolant: Rotary screen: 2x Signal-Light: paper band filter: test probe ...

x-travel: 650 mm y-travel: 520 mm z-travel: 475 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 465 mm axis distance: 1.150 mm control: Siemens 840D centre height: 360 mm Swivel range via X-slide: 465 mm chuck diameter: 250 mm travel -x axis: 300 mm travel -z axis: 1.050 mm rapid power traverse in X-and Z direction: 30 m/min Max. workpiece weight – chuck: 150 kg Max. workpiece weight – tailstock: 350 kg Max. workpiece weight – steady and tailstock: 600 kg weight of the machine ca.: 7,5 t dimensions of the machine ca.: 2,5 x 5,3 x 2,2 m Equipment/Accessories: - 12-station tool turret (VDI 40 mount) - With 6 driven tool stations (VDI 40 coupling) - Hinged chip conveyor - Reinforced coolant pump (12 bar) - Hydraulic 3-jaw chuck (D 315 mm) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 1250 mm, 1000 mm, 1000 mm

Refurbished by DMG in 2011 Control: HEIDENHAIN iTNC 530 Tool holder SK50 with tool storage for 60 tools Max. spindle speed: 8,000 1/min 30kW spindle with swivelling milling head (B-axis) Infrared probes NC rotary table with pallet change Total weight: 24,000 kg Table load: 2,000 kg

x-travel: 1035 mm y-travel: 560 mm z-travel: 510 mm Control: Heidenhain iTNC530 total power requirement: siehe Dok. kW weight of the machine ca.: ca.5,2 t dimensions of the machine ca.: siehe Dok. m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Year of construction: 2004 CNC controller: Heidenhain MillPlus IT FD Axes X-axis travel mm: 1250 Y-axis travel mm: 880 Z-axis travel mm: 800 C-axis degrees: 360º (0,001) B-axis degrees: -30º/180º Milling/turning table nc: Number of pallets: 2 Table dimensions mm: Ø1100 Maximum workpiece size (D x H) mm: H=1600 Max. workpiece weight kg: 2000 Table rotation speed rpm: 400 Spindle Spindle speed rpm: 10000 Spindle drive power kW: 44/32(40%ED/cont) Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 900 Tool system Tool holder: HSK-A 100 Tool magazine slots: 120 Equipment Electronic Handwheel Chip conveyor Infrared probe Internal cooling lubricant supply Rotating inspection windows Rinsing gun Operating mode 4 Tool measuring arm Mist collector Machine running times Under power: 92687 Spindle Working: 40245 Basic machine dimensions / weigh ...

CNC Machining Center DMG 1035 V ecoline 2010 Siemens 810 D / Shopmill Travel distances : X-axis : 1035mm Y-axis : 560mm Z-axis : 510mm Working spindle : Tool holder SK 40 Speed range max. 10000 rpm Tool magazine : 20 magazine slots Table design : Rigid table 1200 x 560 mm - Chip conveyors - IKZ 20 Bar

General2 spindles automatic lathe - 2 cross slides - Spindle and counter spindle - Y axis on slide 1 - Y axis on slide 2 - C axis on main spindle - C axis on counter spindle - Chip tank with coolant system and coolant pump - Tape unloading workpiece; Control: Fanuc 32i Working areaBar diameter max.32 mmChanging kit from steady to sliding headstockChanging kit from steady to sliding headstock including application bush type Dunner J9 and bush-spindle syncronism Additional charge for belt type chip conveyorAdditional charge for belt type chip conveyor, compatible with shaft-unloading-device Specific chip removol systems (for example: scraping blades chip conveyors, with additional filtering systems) are recommended in case of short chip material machinin Counter spindle collet cleaningCounter spindle collet cleaning with coolant Spindle liner for main spindleSpindle liner tube for main sp ...

Key data: 935 mm, 850 mm, 650 mm

Commissioning 2013 with RS 3 rotary storage tank (3 pallets) Control: Heidenhain iTNC 530 HSCI Approx. 60 tools - SK40 IKZ (internal coolant supply) Total weight: 14,000 kg Spindle speed (max.): 18,000 rpm Number of slots in tool magazine: 60 Table load: 1,000 kg Heidenhain Infrared Probes Blum Laser Measurement 3D Quickset Air Cleaner electric handwheel

GeneralHorizontal Machining Centre; Control: Fanuc F31iB CharacteristicsSpeed max.-14000 rpmDrive power (100% DC)11 kWDrive power (40% DC)18,5 kWTable size400x400 mmSwivelling range360x1 degreeMaximum load (table centre)400 KgMax. work piece diameter630 mmMax. work piece height900 mmPalett changer with2 PalletMovement X / Y / Z560/560/630 mmRapid feed X / Y / Z50/50/50 m/minTool Magazine with40 PositionsSpindle taperBT 40 Max. tool length400 mmDimensions (L x W x H)2,36 x 3,92 x 2,72 mWeight approx.9600 KgSpecial equipmentJ-011462 Tool holder taper for BT-40 tool holders J-011460 Max. spindle speed 14,000 rpm, 18.5/11 kW J-011470 Scraper-type chip conveyor with drum filter, rear discharge J-007252 CTS (DIN Form B) coolant supply through the spindle J-011461 40-station tool Special equipmentJ-001212 Coolant gun for the operator side J-003686 Manual pulse generator, handwheel (separate typ ...

General2-Axes Universal Turning Center with driven tools, C-axis; Control: DMG MORI Slimline Multi-Touch Working areaSwing diameter over guide ways950 mmClamping chuck diameter max.500 mmWork spindle (left)Spindle bore141 mmSpindle diametre on front bearing200 mmMain drive 1Drive power (100% DC)33 kWDrive power (40% DC)50 kWSpeed range- 2000 rpmTorque (100% DC)1125 NmMax. torque (40% DC)1700 NmC-Axis Speed-200 rpmSlide 1Longitudinal stroke1300 mmTransverse stroke435 mmTool holder 1Number of tool stations12 Shank diametre according to DIN 6988050 mmNumber of driven tools12 Speed max.-4000 rpmPower max. (40% DC)12,5 kWFloor space/WeightDimensions (L x W x H)4,07 x 2,74 x 2,20 (5,33 x 2,74 x 2,20) mWeight approx.10000 KgElectronic handwheelManual movement of individual axes in various increments DMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines wit ...

GeneralUniversal milling and turning machining centre with duoBLOCK construction; Control: CELOS X with HEIDENHAIN TNC7 Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal800 mmCross1050 mmVertical850 mmTool changerApplicationUniversal Type of magazineWheel Tool changer planehorizontal Type of gripperDouble gripper Number of tools183 Motor spindle HSK-A63 20.000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (95 ft lbs / 63 ft lbs) (40 / 100 % duty cycle) Taper cleaning brushesTaper cleaning unit with rotating brushes for spindle taper HSK Stop block + 3-point-supportStop block + 3-point-support Design according to DECKEL MAHO Standard Tool magazine, wheel, 183 pocketsTool magazine wheel maga ...

DMF 4G110 – Mechanical Guillotine Shear The DMF 4G110 is a compact and robust mechanical guillotine shear designed for accurate straight cutting of sheet metal. The machine is suitable for small and medium-sized fabrication workshops, maintenance departments and industrial production facilities. Technical specifications - Manufacturer: DMF - Model: 4G110 - Machine type: Mechanical guillotine shear - Cutting length: 1,100 mm - Cutting capacity: 4 mm mild steel - Cutting system: Mechanical - Application: Straight cutting of sheet metal Who needs this machine? - Sheet metal fabrication companies: Cutting steel sheets into smaller components and blanks. - Machine manufacturers: Producing covers, brackets, panels and machine components. - Steel construction companies: Preparing steel plates for welding and fabrication. - Maintenance workshops: Manufacturing replacement ...

DMF 4G110 – Mechanical Guillotine Shear 1100 x 4 mm The DMF 4G110 is a compact and robust mechanical guillotine shear designed for accurate straight cutting of sheet metal. The machine is suitable for small and medium-sized fabrication workshops, maintenance departments and industrial production facilities. Technical specifications - Manufacturer: DMF - Model: 4G110 - Machine type: Mechanical guillotine shear - Cutting length: 1,100 mm - Cutting capacity: 4 mm mild steel - Cutting system: Mechanical - Application: Straight cutting of sheet metal Who needs this machine? - Sheet metal fabrication companies: Cutting steel sheets into smaller components and blanks. - Machine manufacturers: Producing covers, brackets, panels and machine components. - Steel construction companies: Preparing steel plates for welding and fabrication. - Maintenance workshops: Manufacturing ...

Ref. -No.: 10287 Manufacturer: DMG Year of construction: 2010 Type of control: CNC-Steuerung Control: Heidenhain Mill Plus Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2100 mm Y-Travel: 2100 mm Z-Travel: 1250 mm Machine length: 11.000 mm Machine width: 5.000 mm Machine Height: 3.500 mm Max. Workpiece diameter: 2500 mm Max. Workpiece Weight: 6.000 kg Max. rotary table diameter: 1.850 O Table speed range: 250 min/-1 Tool Taper: HSK-A100 Tool Piece Magazine With: 183 Pcs./pcs. Spindle Speed: 12.000 RPM Max. Torque On The Boring Spindle: 288 Nm Max. Torque: 2.000 Nm Feed Speeds X/Y/Z Axis: 30.000 mm / min Max. Workpiece height: 1.460 mm axes: 5 Further information: Turning and milling center incl. pallet changing system Gear spindle Coolant treatment system, with belt filter, 710 x 50mm 1 Knoll 600S2 chip conveyor 2 Losma oil mist extraction units 1 steel platform ...

Ref. -No.: 10468 Manufacturer: DECKEL MAHO Year of construction: 2000 Control: Heidenhain Millplus Storage location: Halberstadt Country of origin: Japan Machine-No.: 111xxxxxxxx X-Travel: 800 mm Y-Travel: 700 mm Z-Travel: 600 mm Number of T-slots: 9 / 14 Clamping Area: Ø 900 x 630 mm T - slot spacing: 63 mm Tool Taper: SK 40 Tool changer: 30 Spindle Speed: 12.000 RPM Max. Torque: 2659 Nm Operating hours: 67.452 H Center hole: Ø 50 mm Holding torque: 4500 Nm Max. rotation of the table top: 10,7 rpm Feed: 3600 °/min. Resolution of the measuring system: 0,001 ° NC rotary table: 800 kg NC swivel rotary table: 600 kg Further information: - Clamping table 900 x 630 mm - Chip conveyor, sheet metal technology - Belt filter system, manufacturer Interlit - Type SK 200-760 - Oil mist separator - Set of tool holders, - Workbenches - 2x 6 drawers - Vise - Jaw width 125 mm - Roller shutter cabine ...

Ref. -No.: 10659 Manufacturer: DECKEL MAHO Year of construction: 2012 Type of control: CNC Control: Haidenhein iTNC 530 Storage location: Halberstadt Country of origin: Germany Machine-No.: 1541XXX X-Travel: 835 mm Y-Travel: 510 mm Z-Travel: 510 mm Number of T-slots: 5 Max. Tool Weight: 6 kg Max. Tool Length: 250 mm Max. Tool Diameter: 80 mm Tool change time: 1,6 s T - groove width: 14 mm T - slot spacing: 100 mm Tool Taper: SK40 Numbers Of Tools In Magazin: 30 Spindle Speed: 12000 RPM Max. Torque: 130 / 87 Nm Turning Speed Range - Stepless: 30 mm / min Total Power Requirement: 35 kW Dimensions Of The Machine Ca.: 4,5 x 3,5 x 2,7 m Weight Of The Machine Ca.: 5 t Changeover time chip - chip: 6 sec Feed rate: 1 - 20.000 (X / Y / Z) High pressure cooling: 20 bar Further information: The machine can be inspected while powered on by prior arrangement.

Manufacturer: DMG Model: CTX 310 ecoline Year: 2012 Condition: Used Stock number: 9648 Switch-on hours: 59017 h Hours: 28313 h Maximum turning length: 450 mm Max. turning diameter: 200 mm Maximum turning diameter over support: 260 mm Maximum length of travel in the X-axis: 182 mm Maximum feed in the Z-axis: 465 mm Maximum spindle speed: 5000 1/min Weight: 3200 kg Equipment: Bar Feeder
