distance between columns used for sale

pressure:160 t distance between columns:1340 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1300 x 900 mm table height over floor:930 mm side window:600 mm ram surface:1300 x 900 mm speed down:367 mm/s speed up:390 mm/s working speed:58 mm/s power requirement:30,0 kW weight:15,0 t Dimensions (WxDxH):2,5 x 2,2 x 4,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary

nominal force:2500 t stroke:600 mm cycle time:13 - 18 s distance between columns:1720 mm Distance table/ram, max. stroke up, adjustment up:2600 mm table surface area:1720 x 1800 mm allowed max. force:4000 t blow die to die:5000 t ram surface:2100 x 1320 mm capacity of ejector in table:40 t ejector stroke in table:250 mm ejector surface area in table:900 x 820 mm capacity of ejector in ram:6 t ejector stroke in ram:40 mm spindle diameter:425 mm power requirement:900,0 kW weight:335,0 t Dimensions (WxDxH):3,4 x 4,6 x 9,7 m height over floor:8,3 m fully-automated forging line:to produce axle shaft

pressure:250 t distance between columns:1125 mm stroke:250 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1100 x 900 mm pressure of drawing cushion in table:63 t stroke of drawing cushion in table:100 mm die cushion area:700 x 400 mm table height over floor:960 mm side window:700 mm ram surface:1080 x 900 mm oil volume:1000 l power requirement:35,0 kW weight:23,0 t Dimensions (WxDxH):2,5 x 2,3 x 4,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick foundation pit:not necessary

pressure:100 t distance between columns:1230 mm stroke:20 - 200 mm no. of strokes:20 - 60 /min distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1050 x 750 mm table height over floor:760 mm side window:540 mm ram surface:1000 x 750 mm ram adjustment:100 mm power requirement:18,0 kW weight:20,5 t Dimensions (WxDxH):2,8 x 1,9 x 4,3 m infinitely variable drive:PIV clutch:pneumatic overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:motoric

pressure:160 t distance between columns:880 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:830 x 1000 mm hole in the table:265 x 365 mm table height over floor:850 mm side window:610 mm ram surface:860 x 1000 mm power requirement:55,0 kW weight:14,7 t Dimensions (WxDxH):2,2 x 2,0 x 4,3 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 depth stop:motoric adjustable table:motoric foundation pit:not necessary

pressure:500 t distance between columns:2400 mm stroke:400 fix mm no. of strokes:13 - 23 /min Distance table/ram, max. stroke up, adjustment up:1600 mm table surface area:2300 x 1800 mm column travel -side:1600 mm ram surface:2170 x 1800 mm ram adjustment:300 mm total power requirement:110,0 kW Weight:135,0 t Dimensions (WxDxH):3,35 x 4,85 x 7,0 m clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric

pressure:300 t distance between columns:2500 mm stroke:350 mm distance table/ram, max. stroke up, adjustment up:1280 mm table surface area:2500 x 1500 mm table height over floor:850 mm side window:900 mm ram surface:2500 x 1500 mm speed down:300 mm/s speed up:240 - 450 mm/s working speed:23 - 44 mm/s oil volume:3000 l power requirement:132,0 kW weight:54,0 t Dimensions (WxDxH):3,25 x 3,2 x 4,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:SITEMA

Pressure:100 t distance between columns:910 mm stroke:600 mm distance table/ram, stroke up:1000 mm table surface area:1340x680 / 910x1085 mm hole in the table:700 x 510 mm table height over floor:800 mm side window:680 mm ram surface:1230x680 / 910x1000 mm capacity of ejector:7,5 t ejector stroke:150 mm power requirement:15,0 kW weight:9,5 t Dimensions (WxDxH):2,3 x 1,9 x 3,6 m light guard:Sick blank holder / ejector in ram:hydraulisch

pressure:200 t distance between columns:1800 mm stroke:710 mm Distance table/ram, max. stroke up, adjustment up:1100 mm table surface area:1600 x 1300 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:250 mm die cushion area:1400 x 1080 mm table height over floor:800 mm side window:1300 mm ram surface:1660 x 1300 mm speed down:400 mm/s speed up:410 mm/s working speed:14,3 - 49,7 mm/s power requirement:46,0 kW weight:25,0 t Dimensions (WxDxH):3,65 x 3,3 x 5,4 m height over floor:5,05 m height beneath floor:0,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard at front and back:Sick drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical

pressure:50 t distance between columns:1750 mm stroke:500 mm Distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1700 x 750 mm table height over floor:800 mm side window:650 x 750 mm ram surface:1700 x 750 mm power requirement:11,0 kW weight:11,0 t Dimensions (WxDxH):2,1 x 1,15 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary

pressure:030 t stroke:8 - 40 mm no. of strokes:100 - 600 /min distance between columns:325 mm distance table/ram, max. stroke up, adjustment up:250 mm table surface area:540 x 300 / 325 x 395 mm hole in the table:315 x 110 mm table height over floor:1000 mm column travel -side:290 mm ram surface:250 mm material width of feeder:120 mm material thickness of feeder:3,0 mm feed length:60 mm power requirement:5,5 kW weight:2,6 t Dimensions (WxDxH):1,5 x 1,2 x 2,2 m clutch:pneumatic roll feed:mechanical, Bruderer BBV 120/60

pressure:500 t distance between columns:2240 mm stroke:1180 mm distance table/ram, max. stroke up, adjustment up:1800 mm table surface area:2050 x 1800 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:380 mm drawing cushion surface in table:1800 x 1200 mm pressure of drawing cushion in ram:122 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:1800 x 1200 mm ram surface:2215 x 1800 mm table height over floor:500 mm speed down:400 mm/s speed up:10 - 400 mm/s working speed:10 - 100 mm/s depth of the foundation:3,0 m power requirement:122 + 75 + 64,5 kW weight:110,0 t Dimensions (WxDxH):3,6 x 2,2 x 8,5 m height over floor:6,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table and ram:hydraulic

pressure:500 t distance between columns:3200 mm stroke:1250 mm distance table/ram, max. stroke up, adjustment up:1810 mm table surface area:3000 x 1900 mm pressure of drawing cushion in ram:150 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:2400 x 1200 mm ram surface:3160 x 1900 mm speed down:400 mm/s speed up:250 mm/s working speed:18 - 58 mm/s height over floor:6,5 m power requirement:90,0 + 36,5 kW weight:110 t German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic

pressure:800 t distance between columns:3010 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:1350 mm table surface area:3000 x 1800 mm table height over floor:500 mm side window:1500 x 1400 mm ram surface:3000 x 1800 mm speed down:300 mm/s oil volume:900 l height over floor:5,4 m height beneath floor:2,1 m power requirement:200,0 kW weight:80,0 t Dimensions (WxDxH):5,2 x 2,6 x 7,5 m ram interlocking:in TDC depth stop:mechanical

nominal force:315 t stroke:300 mm no. of strokes:36 /min distance between columns:540 mm distance table/ram, max. stroke up, adjustment up:750 mm table surface area:530 x 630 mm blow die to die:630 t Allowed max. force:500 t ram surface:450 x 560 mm spindle diameter:180 mm power capacity:18,0 kW weight:13,0 t Dimensions (WxDxH):2,5 x 2,0 x 4,0 m

pressure:100 t distance between columns:1060 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:1250 mm table surface area:1000 x 700 mm pressure of drawing cushion in table:40 t stroke of drawing cushion in table:200 mm die cushion area:Ø 250 mm table height over floor:950 mm side window:580 x 750 mm ram surface:1000 x 700 mm oil volume:700 l power requirement:47,0 kW weight:13,0 t Dimensions (WxDxH):2,2 x 1,8 x 5,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanical; motoric adjustable ram interlocking:SITEMA

pressure:160 t distance between columns:2050/1900 mm stroke:15 - 170 mm no. of strokes:15 - 40 /min distance table/ram, max. stroke up, adjustment up:690 mm table surface area:1600 x 800 mm side window:800 mm ram surface:1620 x 700 mm ram adjustment:140 mm power requirement:15,0 kW weight:24,0 t Dimensions (WxDxH):3,3 x 2,3 x 5,3 m height over floor:4,8 m height beneath floor:0,5 m clutch:pneumatic ram adjustment:motoric ram counterbalance:pneumatic

pressure:500 t stroke:40 - 160 mm no. of strokes:32 / 48 /min distance between columns:1620 mm distance table/ram, max. stroke up, adjustment up:660 mm table surface area:1600 x 1300 mm table height over floor:750 mm column travel -side:400 x 430 mm ram surface:1400 x 1200 mm ram adjustment:120 mm pressure of drawing cushion in table:60 t stroke of drawing cushion in table:100 mm drawing cushion surface in table:1300 x 810 mm material width of feeder:1000 mm material thickness of feeder:- 6,0 mm feed length:350 mm height beneath floor:0,3 m power requirement:44,0 / 66,0 kW weight:56,0 t Dimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 m height beneath floor without drawing cushion:0,3 m height beneath floor with drawing cushion:1,0 m clutch-/ brake combination:pneumatic; Desch overload protection in ram:mechanical ram counterbalance:pneumatic ram adjustment:motoric drawing cushion in table:pneum ...

pressure:500 t stroke:40 - 160 mm no. of strokes:32 / 48 /min distance between columns:1620 mm distance table/ram, max. stroke up, adjustment up:660 mm table surface area:1600 x 1300 mm table height over floor:750 mm column travel -side:400 x 430 mm ram surface:1400 x 1200 mm ram adjustment:120 mm material width of feeder:1000 mm material thickness of feeder:- 6,0 mm feed length:350 mm power requirement:44,0 / 66,0 kW weight:56,0 t Dimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 m height beneath floor:0,3 m pneumatic clutch-brake combination:Desch Mechanical pincers feed:Obru, BVK 3.10.3

pressure:500 t stroke:40 - 160 mm no. of strokes:32 / 48 /min distance between columns:1620 mm distance table/ram, max. stroke up, adjustment up:660 mm table surface area:1600 x 1300 mm table height over floor:750 mm column travel -side:400 x 430 mm ram surface:1400 x 1200 mm ram adjustment:120 mm pressure of drawing cushion in table:60 t stroke of drawing cushion in table:100 mm drawing cushion surface in table:1300 x 810 mm material width of feeder:1000 mm material thickness of feeder:- 6,0 mm feed length:350 mm power requirement:44,0 / 66,0 kW weight:56,0 t Dimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 m height beneath floor without drawing cushion:0,3 m height beneath floor with drawing cushion:1,0 m pneumatic clutch-brake combination:Desch drawing cushion in table:pneumatic Mechanical pincers feed:Obru, BVK 3.10.3

pressure:040 t stroke:8 - 50 mm no. of strokes:50 - 300 /min distance between columns:600 mm distance table/ram, max. stroke up, adjustment up:285 mm table surface area:590 x 500 mm hole in the table:590 x 40 - 100 mm table height over floor:860 mm column travel -side:280 mm ram surface:590 x 380 mm ram adjustment:80 mm material width of feeder:150 mm power requirement:7,5 kW clutch:pneumatic ram adjustment:motoric pincer feed:mechanical

pressure:160 t stroke:160 fix mm no. of strokes:30 - 120 /min distance between columns:1190 mm distance table/ram, max. stroke up, adjustment up:735 mm table surface area:1200 x 1000 mm hole in the table:500 x 300 mm table height over floor:900 mm side window:600 mm ram surface:1000 x 800 mm ram adjustment:125 mm material width of feeder:550 mm material thickness of feeder:0 - 6,0 mm feed length:350 mm material cross-cut:1100 mm² Feed speed:50 m/min power requirement:45,0 kW weight:25,0 t dimensions (WxDxH):2,3 x 2,1 x 4,7 m infinitely variable drive:PIV overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic pincer feed:mechanisch, RS 350/550 SL 90

pressure:315 t distance between columns:1620 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1600 x 1100 mm pressure of drawing cushion in ram:20 t stroke of drawing cushion in ram:100 mm drawing cushion area in ram:300 x 300 mm side window:600 x 1100 mm table height over floor:750 mm ram surface:1600 x 1100 mm oil volume:1500 l power requirement:110,0 kW weight:35,0 t dimensions (WxDxH):4,65 x 2,61 x 5,5 m height over floor:5,05 m height beneath floor:0,45 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic ram interlocking:pneumatic cutting impact cushioning:hydraulic

pressure:60 t distance between columns:650 mm stroke:220 mm distance table/ram, max. stroke up, adjustment up:410 mm table surface area:600 x 525 mm pressure of drawing cushion in table:5 t stroke of drawing cushion in table:80 mm table height over floor:900 mm side window:200 mm ram surface:560 x 490 mm dimensions (WxDxH):1,9 x 1,3 x 2,7 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick FGS 600 drawing cushion in table:hydraulic foundation pit:not necessary

pressure:2000 t distance between columns:975 mm stroke:400 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1015 x 1050 mm table height over floor:800 mm capacity of ejector in table:6,3 t ejector stroke in table:100 mm capacity of ejector in ram:65 t ejector stroke in ram:100 mm ram surface:975 x 1050 mm return capacity:150 t speed down:235 mm/s speed up:250 mm/s working speed:5 - 20 mm/s oil volume:4000 l height over floor:3,65 m height beneath floor:3,75 m power requirement:194,0 kW weight:105,0 t dimensions (WxDxH):5,0 x 6,5 x 7,4 m

pressure:100 t distance between columns:1000 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:650 mm table surface area:980 x 700 mm pressure of drawing cushion in table:4 x 10 / 1 x 20 t stroke of drawing cushion in table:180 mm table height over floor:800 mm side window:400 mm ram surface:1000 x 700 mm speed down:500 mm/s speed up:450 mm/s working speed:60 mm/s power requirement:40,0 kW dimensions (WxDxH):1,5 x 1,4 x 4,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:4 x 10 t + 1 x 20 t, getrennt einschaltbar foundation pit:nicht erforderlich

pressure:200 t distance between columns:970 mm stroke:360 mm Distance table/ram, max. stroke up, adjustment up:630 mm table surface area:1000 x 800 mm capacity of ejector:10 t ejector stroke in table:160 mm table height over floor:850 mm side window:400 mm ram surface:1000 x 800 mm speed down:420 mm/s speed up:410 mm/s working speed:50 mm/s oil volume:1240 l return capacity:24 t power requirement:45,0 + 15,0 kW weight:16,0 t dimensions (WxDxH):2,7 x 2,5 x 4,3 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 ram interlocking:mechanisch foundation pit:nicht erforderlich

nominal force:160 t stroke:140 mm no. of strokes:85 /min distance between columns:400 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:400 x 450 mm table height over floor:800 mm Allowed max. force:230 t ram surface:400 x 320 mm spindle diameter:125 mm power requirement:7,35 kW weight:5,0 t dimensions (WxDxH):1,7 x 1,2 x 2,9 m

pressure:150 t distance between columns:300 mm stroke:180 mm distance table/ram, max. stroke up, adjustment up:300 mm table surface area:570x180 / 300x410 mm table height over floor:875 mm side window:180 mm ram surface:180 mm speed down:250 mm/s speed up:160 mm/s working speed:6 - 12 mm/s oil volume:250 l power requirement:11,0 kW weight:2,4 t dimensions (WxDxH):1,3 x 1,3 x 2,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 foundation pit:nicht erforderlich

pressure:200 t distance between columns:1050 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:450 mm table surface area:1000 x 1200 mm table height over floor:850 mm side window:500 mm ram surface:1050 x 870 mm speed down:300 mm/s speed up:300 mm/s working speed:18 - 36 mm/s power requirement:37,0 kW weight:16,0 t dimensions (WxDxH):4,0 x 3,6 x 3,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulisch cutting impact cushioning:hydraulisch foundation pit:nicht erforderlich

pressure:100 t distance between columns:1180 mm stroke:1 - 120 mm no. of strokes:90 /min distance table/ram, stroke up:470 mm table surface area:1100 x 700 mm table height over floor:800 mm side window:400 mm ram surface:740 x 350 mm ram adjustment:100 mm power requirement:37,0 kW weight:11,0 t dimensions (WxDxH):2,3 x 2,0 x 3,5 m knuckle-joint press:hydraulisch angetrieben T-slots in table and ram acc. to specification:auf Anfrage foundation pit:nicht erforderlich

Pressure:630 t distance between columns:1600 mm stroke:fix 250 mm no. of strokes:20 /min distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1550 x 1200 mm table height over floor:800 mm side window:620 mm ram surface:1360 x 1200 mm ram adjustment:160 mm height over floor:5,9 m height beneath floor:0,6 m power requirement:32,0 kW weight:59,0 t dimensions (WxDxH):3,0 x 2,2 x 6,5 m clutch:pneumatisch overload protection in ram:hydraulisch ram adjustment:motorisch ram counterbalance:pneumatisch

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive overload protection in ram:hydraulic ram adjustment:motoric tool changing unit:2 x

pressure:160 t distance between columns:1380 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:1250 x 850 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:150 mm die cushion area:450 x 450 mm table height over floor:900 mm side window:250 x 400 mm ram surface:1350 x 850 mm speed down:400 mm/s speed up:350 mm/s working speed:50 mm/s oil volume:1850 l power requirement:58,0 + 11,0 kW weight:24,1 t dimensions (WxDxH):2,85 x 2,15 x 4,6 m German Safety: permitted for manual loading:CE-sign die cushion / ejector in table:hydraulic depth stop:motoric adjustable

pressure:40 t distance between columns:495 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:300 mm table surface area:490 x 400 mm hole in the table:50 mm table height over floor:950 mm side window:155 mm ram surface:150 mm speed down:480 mm/s speed up:480 mm/s working speed:20 mm/s oil volume:115 l power requirement:7,5 kW weight:2,2 t dimensions (WxDxH):1,35 x 1,1 x 2,2 m depth stop:mechanisch foundation pit:nicht erforderlich

Pressure:200 t distance between columns:1910 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1900 x 1150 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:300 mm die cushion area:1500 x 950 mm table height over floor:800 mm side window:1000 mm ram surface:1900 x 1100 mm return capacity:36 t speed down:400 mm/s speed up:170 mm/s working speed:30,5 mm/s oil volume:1500 l height over floor:4,85 m height beneath floor:2,6 m power requirement:45,0 kW weight:38,0 t dimensions (WxDxH):3,05 x 2,8 x 5,55 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic

pressure:300 t distance between columns:1220 mm stroke:1000 mm distance table/ram, max. stroke up, adjustment up:1200 mm table surface area:1200 x 1000 mm pressure of drawing cushion in table:115 t stroke of drawing cushion in table:400 mm die cushion area:1100 x 860 mm table height over floor:900 mm side window:550 x 1000 mm ram surface:1200 x 1030 mm speed down:400 mm/s speed up:350 mm/s working speed:12 - 31 mm/s oil volume:1080 l power requirement:36,0 + 19,0 kW weight:22,0 t dimensions (WxDxH):2,5 x 2,5 x 6,3 m height over floor:5,4 m height beneath floor:0,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick hydraulic safety block and pump:Fabrikat Rexroth

pressure:40 t distance between columns:500 mm stroke:150 mm distance table/ram, max. stroke up, adjustment up:300 mm table surface area:480 x 400 mm hole in the table:50 mm table height over floor:950 mm side window:150 mm ram surface:150 mm speed down:480 mm/s speed up:480 mm/s working speed:20 mm/s oil volume:160 l power requirement:7,5 kW weight:2,6 t dimensions (WxDxH):1,1 x 1,4 x 2,4 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 light guard:Sick depth stop:mechanical foundation pit:not necessary

pressure:200 t distance between columns:1100 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1100 mm table surface area:1000 x 1000 mm pressure of drawing cushion in table:63 t stroke of drawing cushion in table:250 mm die cushion area:800 x 750 mm table height over floor:800 mm ram surface:1000 x 1000 mm Speed down:400 mm/s speed up:250 mm/s working speed:22 - 56 mm/s power requirement:45,0 kW weight:24,0 t dimensions (WxDxH):2,4 x 1,5 x 5,9 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic

pressure:40 t distance between columns:620 mm stroke:975 mm distance table/ram, max. stroke up, adjustment up:940 mm table surface area:590 x 1000 mm table height over floor:770 mm ram surface:590 x 1000 mm side window:470 mm max. tool weight:2,5 t max. capacity of swivelling ram plate:1,5 t Speed down:0 - 50 mm/s Speed up:0 - 34 mm/s Working speed:0 - 10 mm/s oil volume:150 l power requirement:9,5 kW weight:3,2 t dimensions (WxDxH):2,0 x 2,4 x 3,0 m

pressure:500 t distance between columns:1220 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1600 x 1200 mm pressure of drawing cushion in table:320 t stroke of drawing cushion in table:150 mm drawing cushion surface in table:750 x 625 mm pressure of drawing cushion in ram:180 t stroke of drawing cushion in ram:100 mm drawing cushion area in ram:750 x 625 mm ram surface:1600 x 1200 mm table height over floor:800 mm speed down:665 mm/s speed up:530 mm/s working speed:34 - 100 mm/s quantity of oil:2000 l power requirement:180,0 kW weight:40,0 t Dimensions (WxDxH):3,2 x 2,4 x 7,5 m Depth of foundation pit:4,1 m Height above floor:5,55 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:125 t distance between columns:2100 mm stroke:1000 mm Distance table/ram, max. stroke up, adjustment up:1300 mm Table area:2230 x 1300 mm die cushion pressure in table:63 t die cushion stroke in table:60 mm surface of drawing cushion:1000 x 900 mm table height above floor:1050 mm side window:1000 mm ram surface:2100 x 1000 mm speed down:50 mm/s speed up:50 mm/s working speed:10 mm/s oil volume:410 l height above floor:5,95 mm power requirement:22,0 kW Weight:31,0 t Dimensions (WxDxH):3,1 x 1,7 x 5,95 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic foundation pit:not necessary

pressure:315 t distance between columns:1750 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:1200 mm table surface area:1600 x 1500 mm pressure of drawing cushion in table:125 t stroke of drawing cushion in table:200 mm die cushion area:1200 x 1400 mm table height over floor:750 mm ram surface:1640 x 1500 mm power requirement:55,0 + 11,0 kW weight:29,5 t dimensions (WxDxH):3,2 x 4,5 x 5,8 m Height above floor:5,1 m German Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 drawing cushion in table:hydraulisch cutting impact absorption:hydraulic

Pressure:63 t distance between columns:1000 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:850 mm table surface area:980 x 500 mm table height above floor:850 mm ram surface:130 mm speed down:400 mm/s speed up:461 mm/s working speed:14 - 97 mm/s power requirement:15,0 kW Weight:5,0 t Dimensions (WxDxH):2,0 x 1,6 x 3,9 m depth stop:mechanical foundation pit:not necessary

Pressure:160 t distance between columns:1250 mm stroke:500 mm distance table/ram, max. stroke up, adjustment up:700 mm Table area:1200 x 800 mm table height over floor:850 mm die cushion pressure in table:63 ? t die cushion stroke in table:200 mm die cushion area:780 x 650 mm side window:300 mm ram surface:1000 x 800 mm speed down:400 mm/s speed up:400 mm/s working speed:106 mm/s oil volume:1800 l power capacity:2 x 30,0 kW weight:16,7 t Dimensions (WxDxH):2,45 x 2,35 x 4,5 m

Pressure:150 t stroke:fix 80 mm no. of strokes:30 - 150 /min distance between columns:930 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:880x1300/1500x600 mm hole in the table:760 x 180 mm table height over floor:1270 mm column travel -side:650 mm ram surface:920x1000/1300x600 mm weight:27,5 t Dimensions (WxDxH):3,1 x 1,8 x 4,3 m WITHOUT feeder:can be offered optionally

pressure:100 t distance between columns:770 mm stroke:400 mm distance table/ram, stroke up:800 mm Table area:770 x 900 mm table height above floor:850 mm die cushion pressure in table:40 t die cushion stroke in table:200 mm die cushion area in table:600 x 600 mm side window:600 mm ram surface:770 x 900 mm speed down:62 mm/s speed up:350 mm/s working speed:17,5 mm/s oil volume:700 l power requirement:42,0 kW weight:9,0 t Dimensions (WxDxH):2,6x 2,0 x 3,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic
