DGENCE F421

3DGence INDUSTRY F421 – Industrial FFF printer for high-performance polymers | Used, Used industrial 3D printer for PEEK, ULTEM™, PEKK and other high-performance materials, The 3DGence INDUSTRY F421 is one of the most powerful FFF industrial 3D printers for demanding high-temperature polymers. With a heated chamber up to 195 °C, print head temperatures up to 500 °C and a large build volume of 380 × 380 × 420 mm, it is designed for use in medicine, aviation, automotive, and industrial manufacturing., Technical specifications, - Manufacturer: 3DGence, - Model: INDUSTRY F421, - Technology: FFF (Fused Filament Fabrication), - Condition: Used, - Commissioning: March 2024, - Estimated operating hours: approx. 3,000 h, - Estimated filament consumption: about 15 km, - Volume: 380 × 380 × 420 mm (60.648 cm³), - Layer resolution (min.): 50 µm, - Print heads: double extruder with cleaning system, - Filament diameter: 1.75 mm, - Max. Druckkopftemperatur: 500 °C, - Max. Bed Temperature: 180 °C, - Max. chamber temperature: 195 °C (active heating), - Max. chamber temperature: 50 °C, - Printing speed: up to 400 mm/s, - Connection: 230 V / max. 4,600 W, - Communication: Ethernet, Wi-Fi, USB, - Software: 3DGence Slicer 4.0, - Filtration: three-stage ULT filtration unit, Compatible materials, PEEK, ULTEM™ (1010/9085), PEKK, PC, ASA, PA6, HIPS as well as carbon fiber- and glass fiber-reinforced composites. Thanks to the modular print head system (exchangeable M-Series modules), material-specific print profiles can be swapped directly on the device – without retooling., scope of delivery, - INDUSTRY F421 3D Printer – 1 piece., - Pressure module M500+ – 1 piece., - Pressure module M280 – 1 piece., - Material Management System (MMS) – 1 pc., - Borosilicate glass print bed INDUSTRY F421 – 1 piece., - Stainless steel/PEI heat bed sheet – 1 pc., - Stainless steel container with handles – 1 piece., - Vortex – Support Cleaning Station – 1 pc., - VXL EX ( cleaner ) – 5 pcs., - UPS unit for INDUSTRY F421 – 1 pc., - External filtration unit for INDUSTRY F421 – 1 pc., The configuration is complete and production-ready. With two pressure modules (M500+ for high-temperature materials such as PEEK/ULTEM, M280 for engineering materials such as PC/ASA/PA6), the machine is usable for a wide range of materials without any additional accessories. The Vortex cleaning station for soluble support structures as well as the Material Management System are also included., Note on operating hours meter, In December 2024 the NC mainboard and the SD card had to be replaced. The machines internal counters therefore show a very low level and do not reflect actual usage. According to the previous owner, about 3,000 operating hours and around 15 km of filament were processed by the time of sale – which corresponds to intensive, productive use for a startup in March 2024., Special features, The heated filament chamber with four material bays (2 model + 2 support material) enables automatic spool switching during printing. The integrated Smart Material Manager (NFC) automatically detects filament type, color, weight and remaining quantity. Auto-calibration by tensometry reduces maintenance effort to a minimum. The three-stage filtration system retains macro- and nano-particles as well as VOCs and solvent fumes., Ideally suitable for, Companies that have so far relied on service providers for PEEK- or ULTEM-component parts and want to bring production in-house – at a fraction of the new price and with ready-to-use full equipment., Price on request., Interested? Submit your inquiry now about the LayerByLayer machinery market.
seller offer No. resale 700-2026-fdm
