deep hole boring used for sale

HAUSER OP 3 ist eine Koordinatenbohrmaschine, ausgelegt für höchste Präzision, Genauigkeit und Zuverlässigkeit. Arbeitsvermögen: Tisch 550×320 mm, Verfahrwege X400 mm, Y250 mm, Z400 mm; Bohrleistung Stahl 20 mm; Ausbohr-Ø max. 75 mm; Tisch-Spindel-Abstand 600 mm; Spindelhub 130 mm. Technische Daten: Spindelaufnahme MK2, stufenlos 120–3000 t/min, Spindelmotor 1 CV, Anschluss 3×380 V 50 Hz, Gewicht ca.1500 kg, Abmessungen 1400×1500×2100 mm; Bohrspindelschlitten 2 Stufen. Zubehör: Digitalanzeige 2 Achsen ACU RITE III. Erreicht enge Toleranzen; Anwendungen u.a. Automobil, Uhrmacherei, Werkzeugbau, Luftfahrt, Medizintechnik. Technische Daten ohne Gewähr

KAISER BIG BOREMATIC BM 7-150 is a Ausdrehkopf, entwickelt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Arbeitsbereiche: Durchmesser 53 - 70 mm; Spindelaufnahme: BT 50. Technische Angaben: Spindelaufnahme BT 50 und Durchmesserbereich 53–70 mm. Ermöglicht das Erreichen enger Toleranzen; typisch für Automotive, Werkzeugmaschinenbau, Luftfahrt und Medizintechnik Technische Daten ohne Gewähr

HAUSER OP 2 ist eine Koordinatenbohrmaschine (Jig boring machine) für Präzision, hohe Genauigkeit und Zuverlässigkeit. Arbeitsmaße: Tisch 400×300 mm, X 200 mm, Y 200 mm, Z 250 mm; Bohrleistung Stahl 10 mm, Bohrtiefenhub 70 mm, Abstand Tisch–Spindel 320 mm; Drehzahlen stufenlos 150–3000 t/min. Technische Daten: Spindelmotor 1 CV, Anschluss 50 Hz 3x380 V, Gewicht ~700 kg, Abmessungen L1200×B1000×H1800 mm. Zubehör: Digitalanzeige 2 Achsen (PHILIPS), Bohrfutter, Satz Ausdrehköpfe, Zentriermikroskop, Satz Bohrer, Anreissgerät. Erreicht enge Toleranzen; Einsatz in Automotive, Uhrenbau, Werkzeugmaschinenbau, Luftfahrt, Medizintechnik. Technische Daten ohne Gewähr

HAUSER OP 3 ist eine Koordinatenbohrmaschine (jig boring machine) für Präzision, hohe Genauigkeit und Zuverlässigkeit. Leistungsdaten: Tisch 550×320 mm; Längsweg X 400, Querweg Y 250, Vertikalweg Z 400 mm; Bohrleistung Stahl Ø20 mm; Ausbohr-Ø max 75 mm; Abstand Tisch–Spindel 600 mm; Spindelaufnahme MK2; Bohrspindelhub 130 mm; Drehzahlen stufenlos 120–3000 rpm. Technische Daten: 3×380 V 50 Hz; Spindelmotor 1 CV; Gewicht ~1500 kg; Abmessungen L1400×B1500×H2100 mm; Vorschübe 2 Stufen (Werte nicht angegeben). Zubehör: Werkzeugschrank, Bohrfutter, Satz Bohrer, Satz Fräser. Erreicht enge Toleranzen; typische Einsatzbereiche: Automotive, Uhrentechnik, Werkzeugmaschinenbau, Luftfahrt, Medizintechnik. Technische Daten ohne Gewähr

SIP HYDROPTIC 6A ist eine Koordinatenbohrmaschine (Jig boring machine) für hohe Präzision, Genauigkeit und Zuverlässigkeit. Kapazitäten: Tisch 1100×842 mm, Last 800 kg; Wege X1000 Y795 Z800; Bohren 55 mm; Ausbohr Ø300; Spindelhub 250 mm. Daten: 18 Stufen 40–2000 t/min; Vorschub bis 300 mm/min; Eilgang 2500 mm/min; 3×380V; Spindelmotor 4 CV; Gesamt 8 CV; Gewicht 7500 kg. Zubehör: Führungen neu geschabt, DRO HEIDENHAIN. Revidiert 2020. Ermöglicht enge Toleranzen; Branchen: Automotive, Luftfahrt, Uhren Technische Daten ohne Gewähr

HAUSER 3 BA ist eine Koordinatenbohrmaschine, ausgelegt für hochpräzise Arbeiten mit großer Genauigkeit und Zuverlässigkeit. Arbeitsvermögen: Tisch 550x320 mm, 6 T-Nuten (10 mm, Abstand 40 mm), max. Werkstückgewicht 400 kg; Verfahrwege X 400 mm, Y 250 mm, Z 400 mm; Bohrleistung Stahl 20 mm; Ausbohr-Ø max. 75 mm; Abstand Tisch–Spindel 590 mm. Technische Daten: Spindelaufnahme MK 2; Spindelhub 130 mm; Drehzahlen stufenlos 60 t/min–3000 t/min; Spindelmotor 1 CV; Anschluss 3x380 V 50 Hz; Gewicht ~1100 kg; Abmessungen 1200x1150x1750 mm. Zubehör: Runddrehtisch Ø300 mm, Bohrfutter/Satz Bohrfutter, Zentriermikroskop, Lampe. Erreicht enge Toleranzen; Anwendungen: Automobil, Uhrenindustrie, Werkzeugbau, Luftfahrt, Medizintechnik. Technische Daten ohne Gewähr

HAUSER 2 BA ist eine Koordinatenbohrmaschine hoher Präzision mit ausgezeichneter Genauigkeit und Zuverlässigkeit. Kapazitäten: Tisch 450×310 mm; Wege X 350, Y 200, Z 390 mm; Spindelhub 100 mm; Tisch-Spindel 530 mm; Bohren Stahl 15 mm, Guss 18 mm; Ausbohr Ø 1–65 mm. Technische Daten: stufenlose Drehzahl 80–3000 min-¹; Bohrspindelschlitten 2 Stufen; Anschluss 3×380 V 50 Hz; Gewicht ~1035 kg; Abmessungen 1200×1000×1500 mm. Zubehör: Runddrehtisch Ø300 mm, Werkzeugschrank, Ausdrehkopf, Zentriereinrichtung, Zentriermikroskop, Lampe. Ermöglicht enge Toleranzen; typische Anwendungen: Automotive, Uhrmacherei, Werkzeugmaschinenbau, Luft-/Raumfahrt, Medizintechnik. Technische Daten ohne Gewähr

HAUSER 3 DR ist eine Koordinatenbohrmaschine von hoher Präzision, ausgelegt für hohe Genauigkeit und Zuverlässigkeit. Arbeitsumfang: Tisch 550x320 mm, max. Werkstückgewicht 400 kg; Wege X400 mm, Y250 mm, Z400 mm; Bohrleistung in Stahl 20 mm; Ausbohr-Ø max. 75 mm; Abstand Tisch-Spindel 590 mm; Spindelhub 130 mm. Technische Daten: Spindelaufnahme MK 2; Drehzahlen stufenlos 60–3000 t/min; Spindelmotor 1 CV; Anschluss 3x380 V 50 Hz; Gewicht ~1100 kg; Abmessungen L1200xB1150xH1650 mm; Vorschub 2 Gänge. Zubehör: Digitalanzeige 3 Achsen (PHILIPS), Runddrehtisch Ø380 mm. Erreicht enge Toleranzen; geeignet für Automotive, Luftfahrt, Werkzeugbau, Medizintechnik, Uhrmacherei. Technische Daten ohne Gewähr

MACHINE SPECIFICATIONS Year: 2010 Spindle Diameter: 152.1 mm Cross Travel (X Axis): 12,065 mm Vertical Travel (Y Axis): 3,251 mm Spindle Travel (W Axis): 500 mm Spindle Ram Travel (Z Axis): 1,006 mm Rotary Table Travel (C Axis): 2,019 mm Rotary Table Rotation (B Axis): 360° Automatic Tool Changer: 30 tools Rotary Table Size: 2,502 × 2,997 mm Floor Plate Dimension (1): 4,191 × 3,607 mm Floor Plate Dimension (2): 4,191 × 3,607 mm Spindle Taper: CAT 50 Maximum Spindle Speed: 2,500 RPM CNC Control: Heidenhain iTNC 530, 6-Axis Electrical: 400V / 3PH / 60Hz Country of Manufacture: Italy Approximate Weight: 52,164 kg Overall Dimensions: 18,415 × 11,201 mm × H — height to be confirmed EQUIPPED WITH: Heidenhain iTNC 530 6-Axis CNC Control Heavy-Duty CNC Rotary Table Automatic Tool Changer Two Floor Plates Coolant System Hydrauli ...

Technical details & equipment: Speed range: 20 – 5,000 rpm Table dimensions: 800 x 400 mm X-axis travel range: 600 mm Y-axis travel range: 350 mm Z-axis travel range: 600 mm Table load: 300 kg ​ Tool Changer: Equipped with two tool turrets, each with 12 places. Accessories: Chip conveyor included. Company history: The machine ran in gentle single-shift operation. Condition: The machine has been dry and protected in a closed room for 15 years. Due to the long service life, damage to the stand cannot be ruled out. Known defect: The position detection of the tool turrets is currently without function and needs to be repaired (presumably repair of the corresponding card required). With manageable effort, the machine can be restored to a very good operating condition. Important notes: The sale is made as a used machine to self-collectors. All information has been ...

The machine is in good technical condition; testing is possible by prior arrangement. It underwent a general overhaul by Retos in 2017.

x-travel: 2000 mm y-travel: 1600 mm z-travel: 800 mm control: Siemens 840 D boring spindle diameter: 150 mm bore spindle turning speed range: 4-1500 U/min Feeds, stepless (Y, Z): 1-9999 mm/min Rapid Feed Y, Z, W: 10000 mm/min Boring spindle taper: ISO 50 Milling spindle taper: ISO 60 surface area: 1600 x 2000 mm workpiece weight max.: 12500 kg total connected load: 90 kW weight of the machine ca.: 32200 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

horizontal boring - glue injection - dowel inserting Single drill and inserter which can be freely programmed Drilling depth manually adjustable Z-axis with manual setting Workpiece sizes: Length min/max: 20 / 1250 mm Width min/max: 50 / 800 mm Thickness min/max: 10 / 60 mm max. workpiecewidth with middle fence on 2 fields: 600 mm, on 1 field: 1200 mm Middle fence with pneumatic rise/fall 6 vertical pressure units Double membrane glue pump 1:1 Glue viscosity 350 mPas Dowels: 8 mm x 30 mm, 8 mm x 35 mm Controlls: Powercontrol PC85 with Woodwop software

This 6-axis DÖRRIES SCHARMANN Heavycut 1.2 TDV4 was manufactured in 1989. It features an impressive X-axis travel of 2,500 mm, Y-axis travel of 2,500 mm, and Z-axis travel of 800 mm. The machine includes a robust table size of 2,000 x 2,500 mm with a maximum table load capacity of 25,000 kg. If you are looking to get high-quality boring capabilities, consider the DÖRRIES SCHARMANN Heavycut 1.2 TDV4 boring machine we have for sale. Contact us for further details.

Pehu CNC-besturing 5500 mm invoerrolband met CNC-positionering Admission in spindle (cone x): Mk4 Max drillingdepth: 180 mm Max drillingcapacity: dia 32 mm THROAT DEPTH DRILLING-SPINDLE: 550 mm Speeds: 55 > 5000 rpm Digital read-out: Pehu CNC positioning Motor power: 3 kW

Rotating Boring Table Travel X: 2000 mm Table size: Length 1240 mm x Width 1250 mm Bench width: 1030 mm Diameter of the ball screw: Ø 70 mm 2 motors INDRAMAT: 1 travel X motor + 1 table rotation motor Supplied without electrical panel (electrical cabinet to be redone) Protector hennig in average condition Ideal part for retrofitting Total bench length: 5200 mm Width: 1900 mm Height: 900 mm Weight: approx 7 T

Sr. No.: 71809

Bluthardt, VRB 6/20 Drilling machine with coordinate table, with digital display DRO- 3 axis , Year of manufacture: 1980, very good condition, can be viewed under power Mounts SK40, quick-change system, incl. mounts MK2, MK3, MK4 , Spindle : 45 - 900 rpm , 3,4KW, right - counterclockwise rotation, Stroke: 200mm, upper part adjustment electr. 500mm Radius : 500, Coordinate table: Clamping surface 600x400m, X-660, Y-450mm To be visited under power!

Bore diameter: , mm Number of heads horizontal: , St. Number of heads vertical: , St. 2 pcs. Götzinger drilling and milling centers ---------------------------------------- For sale on behalf of a customer! 2 identical machines: One machine for left parts and one for right parts. The machines can also be used individually. The machines were controlled via window manufacturing software, but can also be operated via the machine software. Both machines are equipped identically: - Left and right drilling units for front-end drilling. - 3 units for drilling and milling for longitudinal machining. - Parts are loaded once, and the unit carrier then moves for the various machining operations. Installation length per machine approx. 6 m. Individual sale possible: Price per machine 10,000 Euro See the enclosed PDFs for more information. The data for this ad was created with ModulMWS - the softw ...

Boring heads in different designs and sizes, mainly from the manufacturer KELCH , including a device for indexable inserts, as well as various clamping devices Auction-ID: A7-49089-31

Machine number: 01123 Operating voltage: 380 V Frequency: 50 Hz Rated current: 14 A Hours read: 5128 Speed: from 12.5 to 1000 rpm Table dimensions: 1000 x 800 mm with 7 grooves Travel X-axis: approx. 600 mm Travel Y-axis: approx. 500 mm Travel Z-axis: approx. 600 mm incl. holders, a WALTER dividing head with a four-jaw chuck, diameter: 200 mm and various clamping devices Auction-ID: A7-49089-391

General Description Heavy-duty horizontal boring and milling machine manufactured by ILR , model BH 90 . Designed for precision boring, milling, drilling and machining of medium to large workpieces. Equipped with an ISO 50 spindle and large work table. Technical Details Manufacturer: ILR Model: BH 90 Machine type: Horizontal boring and milling machine Spindle taper: ISO 50 Spindle speed range: 20–2,000 rpm Working table: 920 × 1,000 mm X-axis travel: 1,000 mm Y-axis travel: 800 mm Z-axis travel: 1,000 mm Feed range: 0.03–12 mm/rev Condition Used industrial condition. Operational status, year of manufacture, serial number, installed power, machining accuracy and included tooling have not been specified and should be verified prior to operation. Weight Machine weight: 9,500 kg Auction-ID: A7-49835-4

1 boring tool Oerlikon MK5, φ 70, 6-260 5 top-mounted milling mandrels MK5 - φ 16, 22, 27,32,40mm 2 Clarkson clamp chucks 1 MK5 boring tool, adjustable, φ 60mm 2 Shots 2 milling cutters: End mill roughing/plain φ 56x100mm, / groove milling cutter 4 milling cutters: 2 roughing/plain φ 40x12o, 2 roughing cutters 1 Reduction from MK5 to SK40 Weight: approx. 70kg kg PRICE : € 600,- ex works ! A - T-slot size: approx. 21.5mm, B-35, thread M20 16 T-slot nuts 20 pcs threaded rods M20, L-120 – 400mm 3 x 2 pcs clamping claws 4 nuts long, 6 nuts, washers 2 blocks for adjustment with adjustment screw 4 blocks 80 x 60 x40mm ( underlay )

spindle diameter: 115 mm x-travel: 2000 mm y-travel: 1200 mm control: Heidenhain TNC 355 Lotse z-travel: 1200 mm w-axis: 590 mm total power requirement: 48 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 700 mm y-travel: 400 mm z-travel: 350 mm table-size: 920 x 300 mm control: konventionell tool adaptor: SK40 turning speed range: 40 - 2000 U/min quill stroke: 50 mm total power requirement: 2,4 kW weight of the machine ca.: 1,1 t dimensions: 1,4 x 1,6 x 2,1 m Equipment: - Heidenhain digital readout - Coolant system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

- 5 axes: X, Y, Z, W (axial movement of the axis), C (rotary table). - Approximate travel (X,Y,Z): 1300 x 600 x 1100 mm. - ISO 50 tool type. - Table dimensions 1200 x 1200 mm. - 30mm T-slots. - SIEMENS SINUMERIK 820 M numerical control. - Cooling system. - Security perimeter fencing included. - Rebuilt machine. - Included: - Vertical table mounted on the main table of approximately 1000 x 750 mm. - Additional vertical table of approximately 700 x 500 mm, with 22 mm T-slots. - Operating conditions of this machine: unchecked. Auction-ID: A7-48839-60

Machine already ready for transport, to be assessed on viewing day. Clamping block not included Auction-ID: A1-48649-95

BR20 , Sandvik As good as new, see photos!

A: Reamers : 5, 6, 7, 8, 2x 10, 2x12, 12,5, 2x 14, 15, 2x 16, 17, 18, 19, 2x20, 21, 22, 23, 24, 25, 28, 30, 33, - Euro 180,- B : Reamers : Diameter : 3, 5, 6, 7, 9, 10, 11 , 12, 14, 16, 18, 3x 20, 21, 22, 24, 25, 28, 35, 37, . +5 pcs , approx. 14 KG - Euro 150,- D: Adjustable reamers : 2x 11, 12, 2x 13, 2x 15, 2x18, 19, 2x20, 21, 22, 24, 25, 27, 28, 30, 33, 37, 40, 45, . 24 pcs. - Euro 200,- E : Slip-on reamers : 2 mandrels MK4 , φ 30 – 60 mm , approx. 25 attachments - Euro 240,-

Spindle diameter: 110 mm Travel: X: 1985 mm Y: 1620 mm Z: 1260 mm W: 710 mm Table surface: 1400 x 1600 mm Spindle taper: ISO 50 Control system: HEIDENHAIN TNC 426 Maximum table load: 6300 kg Feed rate: 5 m/min Working feed rate: 5 to 2500 mm/min Spindle speed: 6 to 1250 rpm Motor power: 33 kW Total power: 90 kW Table rotation: 360° Weight: 25400 kg

Machine number: 13088094 Operating voltage: 380 V Frequency: 50 Hz Drilling depth: up to 120 mm Control: HEIDENHAIN TNC 155 Table clamping surface: 780 x 230 mm Spindle speed infinitely adjustable: from 50 to 9000 rpm Drive power of the spindle motor: 3.7 kW Drilling capacity in steel: 20 mm Drilling distance of the drill head: 450 mm Travel X-axis: 420 mm Travel Y-axis: 240 mm Travel Z-axis: 120 mm Travel A-axis: +- 30000° Rapid traverse X-axis: 7 m/min Feed X-axis: 7000 mm/min Rapid traverse Y-axis: 7 m/min Feed Y-axis: 1 - 7000 mm/min Feed Z-axis: 0.02 - 0.30 mm/rev Rapid traverse A-axis: 10800°/min Feed: 1 - 10800°/min incl. built-in workshop drawer cabinet with contents of various hand tools, milling cutters, matching tool holders, collets Attention: the machine is expressly sold as untested! Reference: C.O. - Lot 23 Auction-ID: A7-49882-292

SIP 600 ist eine Koordinatenbohrmaschine hoher Präzision, genau und zuverlässig. Kapazitäten: Tisch 1100×842 mm (T16), max. Gewicht 1500 kg; Wege X1000 Y700 Z300 mm; Ø Spindel 135 mm; Durchgang Ständer 1100 mm; Spindel-Tisch 1000 mm. Daten: MK4; 40–2000 t/min; Vorschub 1–6000 mm/min; Schlitten 0,04–0,35 mm/t; 3x380V 50Hz; Spindelmotor 8 CV (5,9 kW); 12 kVA; Gewicht ~10000 kg; Maße 2930×3480×3235 mm. Zubehör: Satz Werkzeughalter. Für enge Toleranzen in Automotive, Uhrmacherei, Werkzeugmaschinen, Luftfahrt, Medizintechnik. Technische Daten ohne Gewähr

Total 14 pieces; various types; further details see photos

Total 10 pieces; unused; various types; further details see photos

Total 10 pieces; unused, different types; further details see photos

Total 10 pieces; different types; further details see photos

bore capacity in steel (diameter): 35 mm x-travel: 450 mm y-travel: 250 mm z-travel: 500 mm digital: ja Dimensions (L/W/H): 1,2 / 1,1 / 1,95. mm thread dia.: 24 mm weight of the machine ca.: 800 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Equipped with: Renovated in 2019 with a different Siemens control cabinet, several tools (see last photos) a boring spindle of Ø90 mm, Morse 5/ISO 40 taper, spindle speed of 28–1,400 rpm, spindle extension of 700–710 mm, table travels of 1,250 mm across, 1,400 mm longitudinally and 1,120 mm vertically, a table of approximately 1,800 × 1,120 mm, maximum workpiece weight of 3,000 kg, 7.5 kW main motor, front plate of Ø480 mm, weight of approx. 11,200 kg Auction-ID: A1-47363-76

spindle diameter:130 mm spindle diameter:130 mm x-travel:2190 mm y-travel:1520 mm z-travel:1000 mm w-axis:1075 mm table surface area:2000 x 1800 mm workpiece weight max.:8000 kg spindle turning speed range:4,5 x 900 U/min spindle taper: ISO:50 faceplate turning speed range:4,5 x 180 U/min faceplate diameter:785 mm rapid traverse::5000 mm/min total power requirement:40 kW weight of the machine ca.:35 t dimensions of the machine ca.:5,5 x 6,9 x 5,2 m Machine retrofit and overhould with TNC 360 Heidenhain in 2023 and stepless spindle speeds - table indexing 4 x 90° - facing head 785 mm - exhauster - various arbors and tooling

spindle diameter:150 mm x-travel:10000 mm y-travel:2500 mm bore spindle stroke:700 mm Speed of boring spindles:1,25 - 1250 U/min. ram stroke:700 mm dimension of the ram:340 x 340 mm mm spindle taper ISO:50 rapid traverse:5 m/min total power requirement:120 kW weight of the machine ca.:115 t dimensions of the machine ca.:15,1 x 10 x 6,4 m CNC control Siemens 840 Dsl completely modernized 2010 FIBRO CNC drilling work table 2500 x 2500 mm 50 to. workpiece weight Longitudinal travel 2500 mm Angular milling head 4 x 90° Universal angular milling head Panel area approx. 10000 x 5000 mm Chip conveyor and coolant device Aerostatic guides

bore capacity in steel (diameter):- mm throat:- mm bore stroke:- mm x-axis:1.800 mm y-axis:1.600 mm z-axis:1.250 mm w-axis:630 mm max. table load:5.000 kg table length:1.400 mm table width:1.600 mm spindle diameter:105 mm spindle turning speed range:3.300 U/min numbers of positions in the tool changer:40 internal coolant system feed:40 bar Splash guard around rotary table Chip Conveyor Oil cooling unit (chiller) Touch probe Renishaw RMP60 Upgrades in 2024 and 2025 Retrofit of X and Z axis ball screws at producer ? KSK Kurim CZ New linear scales Heidenhain in X and Z axis including cabling retrofit of Z axis - new Biplast V lining on guideways, hand scraped Biplast lining on Z axis new TOS Varnsdorf parts for tool clamping and automatic tool changer arm Overhaul of X, Z and Y axis feed motors at authorized Siemens service (new bearings and sensor) New Siemens hand wheel

spindle diameter:100 mm x-travel:1250 mm y-travel:1100 mm z-travel:950 mm spindle turning speed range:2500 U/min Rotary-table:1100 x 1000 mm table surface area:1000 x 1100 mm tool clamping:69871 DIN spindle stroke:630 mm spindle taper:SK50 total power requirement:22/34 kW max. workpiece weight:3000 kg weight of the machine ca.:13000 kg

spindle diameter:180 mm x-travel:6.000 mm y-travel:2.900 mm total power requirement:95 kW Machine Technical Data ·Machine weight: approx. 130 t including accessories ·Z travel (ram): 1250 mm ·W axis (spindle): 1000 mm ·Sleeve extension: 1250 mm ·Sleeve dimensions: 450 x 450 mm ·Boring spindle stroke: 1000 mm ·Boring spindle speed: 920 rpm Rotary Table: ·Motor driven rotary table ·IOS 40 ·CNC control ·2 axes B and V ·Rotary table size: 3000 x 3500 mm ·Rotary table CNC IOS 40 NC Indexing and Accuracy: ·Infinitely adjustable ·Diameter related ·Indexing: 4 x 90 degrees up to 360000 ·Angular resolution: 0.001 degrees Travel Ranges: ·Longitudinal cross travel: 1230 mm Load Capacity: ·Maximum rotary table load: 40 t Clamping Plate: ·Clamping plate: 3 x 8000 x 2000 mm

x-travel:3500 mm y-travel:2500 mm z-travel:1250 mm w-axis:800 mm bore spindle speeds:2500 U/min table load:12 t dia. of rotary table:1800 x 2200 mm numbers of positions in the tool changer:60 ? Overhauled in 2025 and 2026 ? The spindle was relubricated and new spindle bearings fitted in 2025 by technicians from TOS Varnsdorf ? 12-month warranty and guarantee on geometric accuracy Scope of repairs to the X, Z and B axes 1. Complete dismantling and cleaning of the machine bed for the X and Z axes as well as the B axis 2. Regrinding of X and Z axis guide ways at Czech manufacturer of CNC horizontal boring machines 3. Removal of the old lining from the X- and Z-axis slides and the B-axis 4. Anchoring of re-grinded X and Z axis machine bed 5. New, hand-scraped lining made from Biplast-V on the X- and Z-axis slides, and from new Biplast-V on the B-axis 6. Installation of ball screws, lin ...

spindle diameter:150 mm x-travel:3.000 mm y-travel:2.000 mm spindle stroke:700 mm dimension of the ram:340 x 340 mm ram stroke:700 mm column travel:1.500 mm high speed spindle taper ISO:50 bore spindle turning speed range:3,2 - 1.600 U/min table surface area:2.000 x 2.500 mm max. table load:25.000 kg rapid traverse speed:5/10 m/min feed speeds:1 - 1.500 mm/min faceplate speeds from - to:3,2 - 140 U/min dimensions of the machine ca.:8,4 x 6,8 x 5,9 m weight of the machine ca.:57 t total power requirement:100 kW Full B-axis Aerostatic guides Coolant system with IKZ

spindle diameter:130 mm x-travel:5000 mm y-travel:3000 mm z-travel:2000 mm The TOS Varnsdorf WHQ 13 CNC is a high-performance CNC-controlled horizontal table drill press fitted with a Siemens Sinumerik 840D CNC control system, designed for the precise machining of large and heavy workpieces. The machine is suitable for drilling, boring and milling complex components and is typically used in heavy machinery manufacturing, plant engineering, toolmaking, and in the energy and heavy industries. With generous travel ranges of 5,000 mm on the X-axis, 3,000 mm on the Y-axis and 2,000 mm on the Z-axis, the machine offers an extensive working area. The worktable, measuring 2,500 × 1,800 mm, can accommodate workpieces weighing up to 20 tonnes. The horizontal spindle achieves a speed of up to 3,000 rpm. In combination with the supplied milling head, even demanding milling operations and various ma ...

table length:2200 mm table width:2500 mm table load:16 t total power requirement:6,5 kW feed speeds:1,25 - 160 mm/min rapid traverse speed:2000 mm/min longitudinal adjustment:1500 mm weight of the machine ca.:12 t dimensions of the machine ca.:4,1 x 2,65 x 0,95 m Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt. Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt. Copyright © 2005-2024, Josef Weber. All rights reserved.

spindle diameter:150 mm x-travel:10000 mm y-travel:2500 mm bore spindle stroke:700 mm ram stroke:700 dimension of the ram:340 x 340 mm spindle taper ISO:50 Speed of boring spindles:1,25 - 1250 U/min. feed speeds infinitely variable:1 - 5000 mm/min rapid traverse:5 m/min total power requirement:120 kW weight of the machine ca.:115 t dimensions of the machine ca.:15,1 x 10 x 6,4 m with CNC SIEMENS 840 Dsl complete retrofit in 2010 FIBRO CNC rotary table 2500 x 2500 mm, 50 to. loading capacity, longitudinal movement 2500 mm, angular milling head 4 x 90° universal milling head floor plate area ca. 12000 x 6000 mm ( 72 m²) chip conveyor and coolant attachment aerostatic guideways

spindle diameter:150 mm x-travel:3000 mm y-travel:2000 mm spindle stroke:700 mm dimension of the ram:340 x 340 mm ram stroke:700 column travel:1500 mm spindle taper ISO:50 bore spindle turning speed range:3,2 - 1600 U/min table surface area:2000 x 2500 mm max. table load:25000 kg rapid speed:5 / 10 m/min feed speeds:1 - 5000 mm/min total power requirement:100 kW weight of the machine ca.:57 t dimensions of the machine ca.:8,4 x 6,8 x 5,9 m with CNC SIEMENS 840 D full B-axis aerostatic guideways facing head ( 3,2 - 140 rpm ) angular milling head 1000 Nm coolant attahcmnet with internal cooling supply

diameter:300 mm tool adaptor:40 Weight:5 kg Taper ISO 40 Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt. Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt. Copyright © 2005-2024, Josef Weber. All rights reserved.
