deckel maho gildemeister used for sale

CNC Lathe Gildemeister CTX 200 Series 2 Immediately free from location: CNC Lathe Gildemeister Type CTX 200 Series 2 Built in 2001 Operating hours 39,000 CNC Control Heidenhain 4290 TP Turning diameter 210 mm Turning length 305 mm Reiststock revolver 12 driven tools Conveyor Bar loading magazine Max travel plan 160 mm Max travel length 350 mm Spindle speeds up to 5000 rpm 2 simultaneous axes with C axis 1 controlled spindle 12 driven tools Collet pliers with hydr. Hollow clamping device up to 43 mm Workpiece pick-up device up to 56 mm very many tools

Machine details Bearing number 1105-03132 Machine type CNC lathe - slantbed machine Made GILDEMEISTER Type CTX 400 Built in 2000 Control type CNC Warehouse FRANCE Country of origin Germany Delivery time SOFORT Freight base from location, free loading truck Technical details Turning diameter 570 mm Turning length 635 mm Control Heidenhain CNC Pilot 4290 Turning diameter over bed slide 420 mm Spindle speeds - infinitely 25-5000 rpm Number of driven tools 6 mm Drive 5 kW Information CNC Heidenhain Pilot 4290 C-axis with 5 FESTE vdi holders 1 3 BAKE FOOD 1 X SPAENEFOERDERER WITH REITSTOCK + LNS STANGEN VORCHUB

Guildmaster CTX 210 2005 Turning diameter: 290mm Turning length: 300mm Orbital diameter over bed: 380mm Main spindle Speed range: 20-6000 min/-1 Max Torque: 79/72Nm max. feed diameter: 165mm Spindle diameter in front bearing: 90mm Rod diameter: max. 45mm C-axis: 0.04° Holding moment: C:112Nm Tool turret: Number of powered tools: 12 pos. Shank diameter: 30mm Speed range: max. 5000 rpm Clamping diameter driven tools: max. 16mm Travel X-axis: 160mm Z-axis: 305mm Riding pole travel: 370mm Feeds: Rapid response: X 20 m/min Rapid response: Z 30 m/min Rapid response: C 100 m/min

GILDEMEISTER NEF Plus 500 CNC lathe was manufactured in 1997. The machine, designed for precision machining of workpieces with a maximum diameter of 500 mm, has two spindles (main spindle and sub-spindle) of high speed and power, which will improve even the most intensive machining. The installed GRUNDING CNC controller with colour screen and control panel also allows for cycles to control. The total weight of the machine is approximately 3000 kg. Technical specifications of the GILDEMEISTER NEF Plus 500 lathe - CNC control: GRUNDIG - maximum turning diameter (over bed): 500 mm - maximum turning diameter (over saddle): 290 mm - maximum turning length: 1500 mm - main spindle rotational speed range: 80-2800 rpm - main spindle passage: 70 mm - main spindle drive power: 11 kW - maximum sub-spindle rotational speed: 5000 rpm - sub-spindle drive power: 7.5 kW - total power require ...

Turning diameter 320 mm Turning length 450 mm Control HEIDENHAIN Circulation diameter over slide 260 mm Travel - x 160 mm Travel - z 450 mm Speed range - main spindle 5,000 rpm Drive power - main spindle 11 / 7.5 kW Max Torque 76 / 112 Nm Turret head (x-fold) 12 pos

Key data: 500 mm, 450 mm, 6000 1/min

1 used CNC lathe Make Gildemeister Model CTX 320 V5 Linear Year of manufacture 2004 Control Siemens 840 D ( ShopTurn ) Workspace: Max. circulation diameter over bed 500 mm Circumferential diameter via X-carriage 300 mm Turning length 450 mm Bar passage 60 mm Chuck diameter 170 mm Chuck diameter sub-spindle 165 mm Plane stroke 160 mm Rapid traverse X/Z axis 60/45 m/min Power main drive (100% ED) 16 kW Speed range 6000 rpm Power sub-spindle (100% ED) 7.5 kW Speed range 6000 rpm Number of tool stations 12 Cylindrical shank diameter 30 mm Number of driven tools 12 Drive power (40% ED) 10 kW RPM, max. 5000 min-1 C-axis speed range 0 - 200 min-1 C-axis positioning 0.001 degrees Connected load, total approx. 32 kVA Net weight with chip conveyor approx. 4300 kg Machine with chip conveyor L x W x H 3890 x 1555 x 1890 mm Accessories: Conveyor Pa ...

Key data: 350 mm, 700 mm, 4000 1/min

Machine Details Stock number 1105-04023 Machine Type: CNC Lathe - Inclined Bed Machine Make GILDEMEISTER Type NEF400 / 840D Shopturn Year of construction 2006 Condition Control type: CNC Control Siemens 840D Shopturn Storage location FRANCE Country of origin Germany Delivery time immediately Freight base from Dreieich warehouse Price Technical details Turning diameter 350/270 mm Turning length 700 mm Control Siemens 840D Shopturn Circumferential diameter max. over bed cover 400 mm Travel - z 700 mm Spindle bore 65 mm Spindle speeds max. 4000 rpm Tool holder VDI 30 Turret head 12 pos. Three-jaw chuck diameter 200 mm Spindle holder A6 DIN55026 Pick-up cone in the tailstock quill MK 3 Drive power 15/12 kW Operating voltage 400 V Machine weight approx. 3.0 t Information - Control: Siemens 840D Shopturn - Tool holder VDI 30 APPROX. 12 PIECES - Coolant de ...

Year built 2004 OTHER TECHNICAL DATA POWER OF ROTATING TOOLS 4 Kw MACHINE EQUIPMENT Tool holder set supplied DIMENSIONS AND WEIGHT Length 3000 mm Width 2500 mm Height 2010 mm Weight 6700 Kg

Machine Type: CNC Lathe Manufacturer: GILDEMEISTER Type CTX 500 S2 Year of construction 1998 Control CNC Pilot Heidenhain Country of origin Germany Delivery time by arrangement Freight base from location Technical details Turning diameter max. 445 mm Turning length 1,000 mm Control CNC Pilot Heidenhain Circumferential diameter 680 mm Main spindle: Speed range – main spindle 18 - 3,600 rpm/-1 Drive power – main spindle 23 kW Max. torque 650 Nm Spindle nose 220h5 Chuck diameter 315 / 400 Spindle bearing diameter 140 mm Spindle bore 107 mm Tool turret: Number of tool positions 12 pos. Tool holder 40 DIN69880 Travel: x-travel 320 mm z-travel 1,097 mm Tailstock: Quill stroke 120 mm Tailstock mount MK 5 Quill pressure 14 kN Feeds: Rapid traverse X : 24 / Z : 30 m/min Feed force X: 8 / Z: 15 kN Total power requirement 58 kVA Machine weight approx ...

control: 840 C control: 2x 840 D : Kühlmittelsystem chip conveyor: ja kW generator - rated current: 95,00 A connected load: 65,00 kW The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control: Siemens 840D Solution line, Auto bar loader: Top Automazioni XF 375

turning diameter: 400 mm turning length: 600 mm control: swing diameter: 600 mm spindle bore: 73 mm chip conveyor: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

GILDEMEISTER TWIN 65 CNC automatic lathe was built in 2005 in Germany by GILDEMEISTER Drehmaschinen GmbH. The machine is used for precise, multi-axis machining of workpieces with complex geometries. To increase overall production efficiency, a combination of two spindles and two 12-position turrets with excellent technical specifications are used inside the large working area. Both spindles feature a C-axis with a high indexing accuracy of ± 0.002 mm, which facilitates complex machining operations that require precise positioning of the workpiece. All this is complemented by an intelligent SIEMENS CNC control with an intuitive interface. The GILDEMEISTER CNC turning center weighs 10000 kg. Technical specifications of the GILDEMEISTER TWIN 65 CNC lathe General data - number of axes: 8 (X1, X2, X3, Y1, B, Z1, Z2, Z3) - feed in the X1/X2/X3 axis: 300/180/175 mm - feed in the Y1/B ax ...

CNC controller: SIEMENS SINUMERIK 840D-ERGOLINE Capacity X-axis travel mm: 725 Y-axis travel mm: ± 50 Z-axis travel mm: 300 Turning length mm: 160 Max. turning diameter mm: ø: 250 Swing over bed mm: ø: 320 Tool magazine Magazine places: 16 Tool holder: VDI-30 Tool length max. mm: 390 Tool diameter max. mm: 140 Lower turret Number of tool slots St .: 12 Speed driven tools RPM: 4.000 Drive power driven tools kW: 11,7 Milling function: Yes Main spindle Speed spindle rpm: 5.000 Drive power spindle kW: 11,7 (40% ED) Maximun torque Nm: 280 / 360 (100% / 40% ED) Coolant system Tank capacity liter: 980 L High-pressure bar: 8 / 20 Equipment Chip conveyor CE conformity Coolant gun Air blast / coolant switch-over Internal coolant supply Paper band filter Automatic workpiece magazine loader - 16 positions x ø 220 Working time hours ...

CNC lathe GILDEMEISTER CTX 420 linear With Siemens 840 D powerline controller Year of Make: 2006 Max. rotatable diameter: 324 mm Max. rotatable length: 600 mm Max. circumferential diameter: 680 mm Spindle bore: 79 mm Max. spindle speed: 4500 rpm With the following accessories: Slide protection with interior lighting 12-speed turret with 12 driven stations Y axis , C axis Tool measuring device Parts collection facility 3 jaw chuck hydraulic 0 210 mm with foot switch Hydraulic Collet Chuck Hainbuch IRCO Breuning RBK 10012 Bar Feeder Signal lamp Tailstock with quill Conveyor Oil mist extraction Coolant system with IKZ and belt filter system Operating instructions

Tool holder, milling holder, milling tool -Intake: SK50 5 pieces -Sizes: see pictures -Price: complete -Dimensions box: 400/300/H270 mm -Weight: 42.1 kg

Tailstock, counter bearing for dividing head, dividing attachment -Tailstock comes: from a Gildemeister lathe -Tip height: 270 mm -Quill: electrically driven -Foot switch -Recording: MK5 -Number: 1x tailstocks available -Price: per piece -Dimensions: 820/250/H400 mm -Weight: 136 kg

Boring head, spindle head, drilling head, grooving drill head, grooving head, spindle drilling head, boring head, spindle tool -Adjustment: SK50 -Tool holder: M20 -Price: for both recordings -Weight: 16 kg

Hydraulic power pack, hydraulic pump, hydraulic pump -Hydraulic unit comes from a Gildemeister lathe -Drive: 1.1 kw -Speed: 1410 rpm -Max. Pressure: 25 bar -Liter output: l/min -Filter -Hydraulic tank -Dimensions: 500/680/H660 mm -Weight: 98 kg

4x compound slide - Pos.1; Pos.2; Pos.4; Pos.5 4x indipenden feed - Pos.1; Pos.2; Pos.4; Pos.5 threading device 1x threading spindle pick-up spindle broaching device set of cams set of collets bar-loader Cucchi Giovanni (YOM 2004)

turning diameter: 210 mm turning length: 580 mm control: 840 D Siemens centre height: 190 mm turning diameter over bed: 330 mm turning dia. over face-slide: 260 mm Main spindle:: turning speed range - main spindle: max. 4.000 min/-1 power capacity - main spindel: 10 / 7,5 kW max. Torque: 115 / 86 Nm spindle bore: 68,5 mm max. usable bar diameter: 51 mm C - Axis: 0,001 ° axis stroke:: travel -x axis: 185 mm travel -z axis: 455 mm turret:: number of toolpositions: 12 pos. tool taper: VDI 30 Driven Tool Stations:: 6 pos. Tailstock:: tailstock adjustment: 400 mm intake pressure max.: 4.000 N feeds:: rapid traverse: X: 20 / Z: 30 m/min Feed force ( X / Y / Z ): 4,5 kN total power requirement: 21 kW weight of the machine ca.: 3,2 t dimensions of the machine ca.: 8,0 x 2,2 x 2,0 m Documents: Chip conveyor: Coolantsystem: Tailstock: parts catcher: C-axis: driven tool stations: Signa ...

Multi-spindle lathe (8 spindles) max. rod diameter 16 mm Guide tubes 4,000 mm Conveyor

turn - diameter over facing slide: 450 mm turning diameter over bed: 830 mm turning diameter: mm turning length: 3000 mm control: Siemens total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 8-axis DMG GILDEMEISTER Sprint 32 linear was manufactured in 2003. It features a turning length of 120 mm and a turning diameter of 32 mm. The machine is equipped with a Fanuc 160i-B control and offers impressive spindle speeds of up to 8000 rpm. If you are looking to get high-quality multi-spindle turning capabilities, consider the DMG GILDEMEISTER Sprint 32 linear machine we have for sale. Contact us for further details.

Control: SIEMENS 840D Max.turning length: 450 mm Max swing diametr over bed/Slide: 500 mm/375mm Workpiece diametr: 246 mm Material passage through the spindle: 0 mm Rotation speed(max.) 6000 rpm Quick Change Toolposts:12 Taper ? VDI30 Coolant tank:175l M

Key data: 205 mm, 650 mm

For sale: Gildemeister CNC lathe type Sprint 65 Linear equipped with a Fanuc 310I control. This CNC lathe is equipped with 2 equal spindles with a bar passage of 65 mm. The machine also has three turrets with 12 positions where you can place driven holders in any position! The upper turret is equipped with a Y-axis with a displacement of 80 mm ( (+50, - 30 mm). The turning diameter is 205 mm. The maximum turning length is 650 mm. The movement X1, X2, X3 is 165mm, the Z1 axis movement is 220mm, the Z2 axis movement is 150mm, and the Z3 axis movement is 768mm. The W2 axis movement is 690 mm and the maximum rapid traverses are 30 meters/min. The maximum speed of both spindles is a speed of 5,000 rpm and both spindles have a full C-axis. The tool holder holder on all turrets is VDI-30. The machine is also equipped with a hinged belt chip conveyor with right ejection and the machine has an Ir ...

Control: Heidenhain Max.turning length: 450 mm Max swing diameter over bed/slide: 500 mm/375mm Workpiece diametr: 246 mm Material passage through the spindle: 0 mm Rotation speed(max.) 6000 rpm Quick Change Toolposts:12 Taper ? VDI30 Coolant tank:175l Ma

Key data: 320 mm, 750 mm

Manufacturer: Gildemeister Model N.E.F. 320 K Year of construction 2004 Condition Used Siemens control system Specifications Circulation diameter 320 mm Turning length 750 mm Speed range - main spindle 3500 rpm Drive power - main spindle 9 kW Bar diameter 50 mm Tool holder Multifix size B Tailstock mount MK 5 Rapid traverse X / Z 8 / 10 m/min Machine weight approx. 2.5 t Space requirement approx. 2500 x 1800 x 1885 mm Accessories: 3 Jaw chuck Forkardt 200 Tool package Documentation

Turning diameter 80 mm Bar diameter 20 mm Spindle speed 10000 rpm X1, Y1, Z1, X2,Z2 axes Controller Fanuc FANUC 160iB LNS barfeeder

Gildemeister Sprint 65 Linear CNC lathe (with 2nd spindle, 3 turrets and Y-axis) Diameter of spindle bore 65 mm Spindle speed 5,000 rpm Spindle motor 25/20 kW Spindle speed counter spindle 5,000 rpm X-axis movement 165 / 165 / 165 Movement Y-axis 80 mm Z-axis travel 220 / 150 / 650 mm Movement of the W-axis (counter spindle to the main spindle) 690 mm C-axis indexing 0.0001° Number of towers 3 Number of tools on turret 12 (3x 12) Tool cone VDI 30 Bar Feeder LNS Quick Load Servo 65 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other listings for a full overview of our stock.

Control Siemens ... Sinumerik 840 D Turning diameter ... 365mm Rotation length ... 450mm Inclined bed Spindle bore ... 52mm Tool turret ... 12/6 Spindle speed ... 0-6000/min. Main engine power ... 12/16kW Axis C ... 360° Max. rod diameter ... 60mm L x W x H ... 4000 x 1640 x 1730mm Machine weight ... 3500kg The machine is in good condition, possible to test under electricity.

Gildemeister Sprint 65 Linear CNC lathe (with 2nd spindle, 3 turrets and Y-axis) Diameter of spindle bore 65 mm Spindle speed 5,000 rpm Spindle motor 25/20 kW Spindle speed counter spindle 5,000 rpm X-axis movement 165 / 165 / 165 Movement Y-axis 80 mm Z-axis travel 220 / 150 / 650 mm Movement of the W-axis (counter spindle to the main spindle) 690 mm C-axis indexing 0.0001° Number of towers 3 Number of tools on turret 12 (3x 12) Tool cone VDI 30 Bar Feeder LNS Quick Load Servo 65 If you have any questions about the machine, as well as an appointment for a viewing, please contact us by phone or e-mail. Feel free to check out our other listings for a full overview of our stock.

DMG GILDEMEISTER CTX ALPHA 300 CNC turning center was built in 2008. The machine, designed for machining workpieces with a maximum diameter of 500 mm, is equipped with state-of-the-art technical solutions that guarantee extraordinary accuracy and precision. Machining is performed inside a large, fully illuminated workspace by a reliable spindle and high-quality cutting tools taken from a 12-position turret. In turn, the operator is provided with a state-of-the-art touchscreen control panel with a perfectly optimised FANUC CNC controller. High reliability, precision and structural stability make the GILDEMEISTER CTX ALPHA 300 CNC lathe the perfect choice for even the most intensive production work. The total weight of the machine is approximately 4350 kg. Technical data of the DMG GILDEMEISTER CTX ALPHA 300 lathe - maximum turning diameter: 500 mm - maximum cutting diameter: 200 mm  ...

DMG GILDEMEISTER CTX 510 CNC turning center was built in 2008. Designed for machining workpieces with a maximum diameter of 465 mm, the machine features a fully illuminated workspace, a high-speed spindle and high-end cutting tools. The extremely stable design combined with the perfectly optimised SIEMENS CNC control ensures maximum process efficiency, even during the most intensive production work. The DMG CTX 510 CNC lathe weighs 7500 kg. Technical specifications of the DMG GILDEMEISTER CTX 510 lathe - maximum turning diameter: 465 mm - maximum swing diameter: 680 mm - maximum swing diameter above cross guideway: 465 mm - maximum external diameter of clamped workpiece: 400 mm - feed in the X/Z axis: 300/1050 mm - rapid traverse in X,Z axis: 30 m/min - maximum spindle rotational speed: 3500 rpm - spindle passage: 97 mm - spindle drive power (40%/100% DC): 42/31 kW - chuck s ...

turning diameter:500 mm turning diameter over bed:500 mm turning dia. over base-slide:290 mm centre distance:1000 mm centre height:250 mm z-travel:1350 mm speeds:10 - 3000 U/min

DMG GILDEMEISTER CTX 410 CNC lathe built in 2006 is an extremely powerful machine designed for precision machining of workpieces with a maximum diameter of 320 mm. The machining process is performed inside a large, fully illuminated workspace using reliable components in the form of cutting tools and a high-speed spindle. The specially designed inclined bed effectively dampens all vibrations and oscillations, resulting in better quality of the machined surface and increased tool life. The offered DMG CTX 410 CNC turning center is also equipped with an integrated chip conveyor and a perfectly optimised, intuitive HEIDENHAIN CNC control. The total weight of the machine is approximately 6000 kg. Technical specifications of the DMG GILDEMEISTER CTX 410 turning center - CNC controller: HEIDENHAIN - turning diameter: 320 mm - turning length: 600 mm - feed in the X/Z axis: 250/635 mm -  ...

General: Year of construction 2006 Management Heidenhain plus IT Travel X 150 mm Z 650 mm Y 80 mm Program duration 10,600 h Spindle: Spindle speed 5,000 rpm Spindle bore 65 mm Turning diameter over face slide 375 mm Turning length 635 mm Revolver: Tool holder VDI30 Number of stations 12-fold with AGW Dimensions and weight: Dimensions 5,000 mm x 2,500 mm x 2,800 mm Weight approx. 5,800 kg

Control: Siemens 840 D powerline Accessories: Tool holder bar loading magazine Fully functional and still under power, can be visited at any time

Number of axes : 6 - Number of spindles : 2 MAIN COPDLE - Max. rod diameter : 25 [mm] - Travel : 160 [mm] - Spindle speed : 8000 [rpm] - Minimum C-axis resolution : 0.0001 [degrees] SUB-SPINDLE - Max. rod diameter : 25 [mm] - Number of turrets : 1 UPPER TURRET HEAD - Number of positions : 7 - Number of motorized positions : 7 - Travel X : 100 [mm] - Travel Z : 270 [mm] - Driven tools speed : 6000 [rpm] BUSHING HOLDER 1 - Number of positions : 8 - Number of motorized positions : 3 - Driven tools speed : 6000 [rpm] - Travel X/Y : 220/30 [mm] COUNTER MACHINING - Number of positions : 3 ELECTRICAL SUPPLY - Supply voltage : 400 [V] Accessories - Control : Fanuc 18 iT - Interface : RS232 / PCMCIA - Driven guide bush - Parts removal - Coolant tank - Hydraulic Bar Loading Magazine Brand/Type : - FMB Turbo 3-26

Specifications: Main spindle: Max. turning diameter: 33 mm Max. speed: 8000 1/min Drive power: 5.5 kW Drive power at 60% ED: 7.5 kW Slide 1: Carriage path Z1: 320 mm Slide path X1: 50 mm Carriage path Y1: 255 mm Rapid traverse speed: 30 m/min Ball screw diameter: 25 mm Tool holder slide 1: Number of tools fixed with tool shank 16 x 16: 5 pieces Slide 2: Slide path X2: 165 mm Carriage path Z2: 200 mm Rapid traverse speed: 30 m/min Ball screw diameter: 30 mm Tool holder slide 2: Number of stations for turret with integrated spindle: 8 pieces Number of axially driven tools (integrated): 8 pieces Coolant pan, approx.: 400l Coolant pump, max. capacity: 80 l/min Dimensions (LxWxH), approx.: 2460 x 1510 x 1750 mm Equipment: - CNC control Fanuc iT - Workpiece unloading system - IEMCA bar loading magazine - 5-item tool carrier plate for carriage 1 - Elec ...

Key data: 65 mm, 300 mm

Machine Details Stock-No. 1105-04031 Type of machine CNC Lathe Make GILDEMEISTER Type MF Sprint 65 V Year of manufacture 1998 Type of control CNC Storage location FRANCE Country of origin Germany Delivery time immediately Freight basis ex Warehouse Price Technical details turning diameter 65 mm turning length 300 mm control SIEMENS 840C Additional information CNC-automatic lathe with with 6 - axis, 4 stations for live tools,in 1 revolver WITH bar loader, bar length up to 3000mm Chip Conveyor

Please see the pictures for details
