deckel dmg used for sale

Tool Milling Machine Deckel FP2E -Extremely smooth running + fully functional -Automatic feeds + rapid traverse in X + Z axis -Machine with sliding head means larger Y-travel -Travel X/Y/Z 400x200x400mm -Speed range 40-2000 rpm -Tool holder ISO 40 -Vertical horizontal milling device -Vertical head swivel with drilling quill -Angle table -Various tool holders -Documentation Dimensions: LxWxH 1.5x1.7x1.8 meters / Weight 1500Kg

Tool milling machine DECKEL FP 2 LB from university in well-maintained original condition -3 - Axis digital display "ACURITE" -Travel X/Y/Z 795x300x400mm -Automatic feeds / rapid traverses in all 3 axes (18 pieces) -Spindle speeds 40-2000 rpm (18 pieces) -Horizontal + vertical milling device - ISO 40 - Tool holders -Table clamping surface 1000x440mm -Table clamping surface with additional table 1000x700mm -Vertical head swivel with drilling quill -Coolant device -Various tool holders -Machine light -Documentation Dimensions: LxWxH 2.5x2.4x1.8 meters / Weight 2200Kg

Tool Milling Machine DECKEL FP 3 Heidenhain Digital Display -Well-maintained original condition -Travel X/Y/Z 500x300x400mm -Feeds / rapid traverses in all 3 - axes -Tool holder ISO 40 -Speed range 40 - 2000 rpm -Vertical / horizontal milling device -Angle table -Coolant device -Central lubrication -Chip tray -Documentation Dimensions: LxWxH 1.7x1.2x1.8 meters / Weight 1350 kg

A Deckel CNC universal milling machine is offered. Travel X/Y/Z: 700mm/600mm/550mm, quill stroke: 80mm, milling head swivel range: +/-90°, spindle power: 12kW, max. spindle speed: 6300rpm, feed torque X/Y/Z: 13Nm/13Nm/21Nm, feed rate X/Y/Z: 6m/min, rapid traverse X/Y/Z: 6m/min, tool holder: SK40, measuring resolution: 0.001mm, 4th axis resolution: 0.001°, max. slide load: 1000kg, number of T-slots: 1, T-slot width: 14H7mm, mounting holes for table accessories: M12, control: Deckel Dialog 11. Machine weight: approx. 3900kg, electrical cabinet weight: approx. 475kg, 5110mm/4654mm/2335mm, floor space X/Y: approx. 6200mm/5700mm, floor load: 3500kg/m². Documentation available. Inspection by appointment possible.

X-axis: 880 mm, Y-axis: 630 mm, Z-axis: 630 mm, table dimensions: 1250 × 700 mm, table load capacity: approx. 500 kg, B-axis (milling head): manually or NC swiveling up to 103°, maximum spindle speed: 12,000 rpm, power: 15 kW, torque: 130 Nm, tool holder: SK 40, tool magazine capacity: 32 positions, control system: Heidenhain TNC 430 MillPlus, length: 4073 mm, width: 3323 mm, height: 2375 mm, weight: approx. 9.5 t. An on-site inspection is possible.

x-travel: 600 mm y-travel: 700 mm z-travel: 600 mm Control: Heidenhain Millplus total power requirement: kW weight of the machine ca.: 9 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

surface area: 420 800 mm no. of flutes: 9 groove width: 12 / Abstand 45 mm weight of the machine ca.: 110 kg dimensions of the machine ca.: 10,50,3 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 800 mm y-travel: 300 mm z-travel: 400 mm total power requirement: 3 kW weight of the machine ca.: 2,,2 t dimensions of the machine ca.: 2,522 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding wheel diameter: - mm power requirement: 1 kW total power requirement: 1 kW weight of the machine ca.: 0,16 t dimensions of the machine ca.: 1,20,81,5 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

control: Dialog 4 type of control: CNC Fräsen The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 600 mm y-travel: 500 mm z-travel: 500 mm total power requirement: 7,5 kW weight of the machine ca.: 5,5 t Working range: Longitudinal stroke X axis 600 mm Vertical stroke Y axis 500 mm Cross stroke Z axis 500 mm Clamping size of angle table 530 x 900 mm Max. weight of workpiece on table 450 kg Distance from table to vertical spindle, min./max. 120 / 620 mm Distance from table to horizontal spindle, min./max. 156 / 656 mm Tool taper SK 40 Spindle speeds 0 - 6,300 rpm Feeds X, Y and Z Axes, max. 2 - 10,000 mm/min Quick feed X, Y and Z Axes 10,000 mm/min Spindle drive 8 kW Total electrical load, approx. 15 kW - 400 V - 50 Hz Weight, approx. 5,500 kg Accessories / Special Features DIALOG 11 CNC Control in 4 axes with all the usual options, cycles, and subprograms. Graphic display and electronic hand wheel. Vertical milling head can be pushed up manually so that the  ...

x-travel: 2050 mm y-travel: 520 mm z-travel: 520 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC control Heidenhain TNC 430 2x 32-fold tool changer coolant device 2x chip conveyor measuring feeler The hole X-axis travel is 2050mm. You can work in one move 2 meters. A dividing wall is also with the machine. Then the X-travel will be split. Technische Daten / technical details: X-Weg / X-travel 2050 mm Y-Weg / Y-travel 520 mm Z-Weg / Z-travel 520 mm Spindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 12000 UpM /rpm Werkzeugwechselmagazinplätze / number of tool places in changer 2x 32 Antriebleistung Spindel / drive capacity spindle 36 kW Gewicht ca. / weight 12800 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are  ...

x-travel: 600 mm y-travel: 700 mm z-travel: 600 mm Control: Siemens type: Millplus Table dimensions: 630x500 mm tool taper: ISO 40 Cooling through the spindle: 40 bar Tool changer: 60 Pos. no. of tables: 2 chip conveyor: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Milling head automatically swivels horizontally/vertically The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward ...

x-travel: . mm y-travel: . mm z-travel: . mm control: SIemens type: 840 D ECOLINE Shopmill table surface area: mm workpiece weight: kg Tool changer: 30 Fach spindle taper ISO: Spindle capacity: KW turning speeds: U/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: . m Workpiece width: Max. 550 mm Workpiece length: Max. 1300 mm Workpiece height: Max. 600 mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible b ...

x-travel: 1040 mm y-travel: 600 mm z-travel: 500 mm feed: 30 m/min control: Siemens type: 840 D table surface area: 1250x600 mm table load: 800 kg Tool changer: 30 Fach spindle taper ISO: SK 40 Spindle capacity: KW turning speeds: 12000 U/min total power requirement: 24 kvA weight of the machine ca.: 8,8 t dimensions of the machine ca.: . m Chip Conveyor Quick-Clamping System The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look ...

x-travel: . mm y-travel: . mm z-travel: . mm control: SIemens type: Shopmill 840 D table surface area: mm workpiece weight: kg Tool changer: 30 Fach spindle taper ISO: Spindle capacity: KW turning speeds: U/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: . m Workpiece width: Max. 550 mm Workpiece length: Max. 1300 mm Workpiece height: Max. 600 mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appoin ...

x-travel: 630 mm y-travel: 560 mm z-travel: 560 mm spindle turning speed range: 12000 U/min milling-head swivable +/-: control: Heidenhain type: Mill Plus table surface area: 1000x600 mm : elktr. coolant: chip conveyor: kW total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Spinel hours 2070 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Te ...

x-travel: 500 mm y-travel: 300 mm z-travel: 380 mm spindle stroke: 100 mm turning speeds: 40-2000 U/min Table area: 380x800 mm Feed: 10-500 mm/min Feed: 10-500 mm/min Rapid movement: 1500 mm/min spindle taper: ISO: 40 digital readout: Elesta total power requirement: 3 kW weight of the machine ca.: 1,1 t dimensions of the machine ca.: 1,2x1,2x1,7 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your  ...

x-travel: 880 mm y-travel: 630 mm z-travel: 630 mm Control: Heidemhain type: 426/430 spindle speed:: 18000 spindle taper: HSK 63 surface area: 1250x700 mm Rotary table: 700 mm Table load: 1000 kg b-axis: Schwenkopf 0,001 ° c-axis: 0-360° Rundtisch 0 B-axis C-axis Air blow through the spindle HSK 63 Electronic handwheel The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The da ...

x-travel: 560 mm y-travel: 500 mm z-travel: 450 mm table surface area: 900x520 mm turning speeds: 4000 U/min tool taper: SK 40 Control: Heidenhain type: TNC 355 : elec. coolant: total power requirement: kW weight of the machine ca.: 2,7 t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the sof ...

spindle taper ISO: 40 x-travel: 710 mm y-travel: 600 mm z-travel: 445 mm Control: Heidenhain type: TNC355 mm table surface area: 1000x550 mm turning speeds: 6300 U/min quill stroke: 80 mm Feed: 1-3600 mm/min rapid traverse: 6 m/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The dat ...

The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 800 mm y-travel: 650 mm z-travel: 550 mm control: Heidenhain Millplus tool taper: SK40 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Serial Number: 71201389 with angle table 900 x +640 25-station tool changer magazine Coolant treatment Interior lighting The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad  ...

x-travel: 400 mm y-travel: 400 mm z-travel: 400 mm control: Grundig Contour tool taper: SK40 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Serial number: 198224 with fixed angle table Machine lighting Coolant treatment The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solu ...

x-travel: 1060 mm y-travel: 710 mm z-travel: 710 mm Control: Heidenhain type: ITNC 530 spindle speed:: . spindle taper: SK 40 surface area: 1500x795 mm Table load: 550 kg feed motor: 20-15000 kW Rapid movement: 30000 mm/min round table: 800 mm diameter: 800 mm table turning speeds: 15 U/min milling-head swivable +/-: Tool changer: 32 paper filter: The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Yo ...

x-travel: 1035 mm y-travel: 560 mm z-travel: 510 mm Control: Heidenhain type: iTNC 530 table surface area: 1400x650 mm workpiece weight: 1000 kg Tool changer: . spindle taper ISO: SK40 Spindle capacity: 10 KW turning speeds: 8000 U/min total power requirement: 20 kVA weight of the machine ca.: . t dimensions of the machine ca.: . m Serial number: 15425033554 Chip conveyor 2 hydraulic vises Operating hours: 53005 Spindle hours: 12233 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers  ...

x-travel: 1170 mm y-travel: 500 mm z-travel: 370 mm table load: 2 t spindle turning speed range: 25 - 2500 U/min feeds: 4 - 2000 mm/min rapid traverse:: 4000 mm/min taper ISO: 40 total power requirement: 12,5 KVA weight of the machine ca.: 4 t dimensions of the machine ca.: 2,3 x 1,9 x 1,75 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created wit ...

x-travel: 1.600 mm y-travel: 1.250 mm z-travel: 1.000 mm size of pallet: 1.000 x 1.250 mm control: SIN840D power capacity at 40 % load: 38,00 KW spindle turning speed - stepless: 20 - 10.000 U/min power capacity at 100 % load: 25,00 kW max. torque at 40% / 100% load: 288 / 187 Nm tool taper: SK50 feed X/Y/Z/-axis: 20 - 15.000 mm/min rapid traverse X/Y/Z: 60,00 m/min B - axis: -150° / +80° x 0,001 ° feed B-axis: 3.600 ° / min C-axis: 360 x 0,001 ° Rapid motion C- axis: 1 - 3.600 U / min. table load: 3.000 Kg tool magacine with: 240 tool diameter: 110 mm wotkpiece diameter with 2 vacant positions: 250 mm tool length - max.: 650 mm weight of tools max.: 15,00 kg total power requirement: 75,00 kW weight of the machine ca.: 55,00 t dimensions of the machine ca.: 12,50 x 8,00 x 4,20 m 5-axis machining center with control SIEMENS Sinumerik 840D incl. ShopMill electronical handwheel operati ...

Key data: 400 mm, 150 mm, 340 mm

Lid FP 1, Year of construction approx. 1983 / Overhauled by Arnold approx. 2012 3 axis digital display, Travel X/Y/Z 400/150/340 mm, Table size 600 x 210 mm, T-slots: 4 T - groove width: 12 mm Spindle speeds:: 20 - 2000 rpm Speed levels working spindle: 12 Feed stages: 10 Spindle holder: MK 4 Quill stroke vertical: 60 mm Machine weight approx.: 0.8 t

DMF260/11 → Year of manufacture: 2011 Heidenhain TNC 530 Spindle SK 40 – 18,000 rpm Machine hours: 54,877 Spindle hours: 21,845 Condition: second-hand However, it is currently still in use and will be available in 2027 Find more here - .ucymachines/ Contact us at - sales@ucymachines

x-travel: 500 mm y-travel: 300 mm z-travel: 380 mm table surface area: 800 x 420 mm table load capacity: 400 kg tool taper: ISO 40 spindle turning speed range: 40 - 2000 U/min feeds longditudinal/cross/vertical: 10 - 500 mm/min rapid traverse: 1500 mm/min main drive: 3 kW weight of the machine ca.: 1,3 t dimensions of the machine ca.: m 3-axis digital readout (Heidenhain) Adjustable vertical milling head with quill adjustment Additional horizontal spindle REPAR 2 safety device (www.repar2.com) Machine light Anti-vibration mounts The machine is sold without a vise or tooling. Transport dimensions: The machine is loaded onto a heavy-duty pallet, Dimensions: 1800 x 1100 x 2100 mm (length x width x height) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

electric motors: DECKEL FP 3 2803 / FP 4 2 power capacity: 1,58 / 1,4 kW volt: 163 / 175 V ampere: 10,8 / 9,3 A weight of the machine ca.: 100 kg dimensions of the machine ca.: 0,80,60,4 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1200 mm y-travel: 400 mm z-travel: 370 mm Control: Retrofit Dialog 11 - 7.07 table surface area: 1400 555 mm total power requirement: 5 kW weight of the machine ca.: 2,5 t dimensions of the machine ca.: 332,2 m Packing: 3 m Retrofit by FPS Alternate NC - Rotary Table available The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 700 mm y-travel: 560 mm z-travel: 450 mm total power requirement: 3 kW weight of the machine ca.: je 2,5 t dimensions of the machine ca.: je 332,5 m Bundle 6 x KF 3 S The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

control: Dialog 3 / 4 type of control: CNC Fräsen The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

surface area: 440 x 1000 mm no. of flutes: 5 groove width: 16 mm total power requirement: - kW weight of the machine ca.: 210 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 290/300 mm y-travel: 150/160 mm z-travel: 330/340 mm total power requirement: kW weight of the machine ca.: 675 kg dimensions of the machine ca.: 2700 x 2500 mm The machine was overhauled by the company Harich in 2017. Machine number: 57330/08 Technical data: Table longitudinal movement (motorized/manual): 290/300 mm Spindle head transverse movement (motorized/manual): 150/160 mm Support vertical movement (motorized/manual): 330/340 mm Angle table clamping surface: 600 x 210 mm Spindle speeds: 40 – 2000 rpm Tool holder: Standard taper 40 Motor power: 1.5/1.9 kW Feed rate range (infinitely variable): 5 – 500 mm/min Rapid traverse: 1200 mm Equipment: 3-axis digital readout (Heidenhain) Vertical milling spindle with quill adjustment Additional horizontal spindle REPAR 2 safety device (www.repar2.com) Operating manual The machine will be loaded onto a Euro-pallet, total height: ...

x-travel: 730 mm y-travel: 560 mm z-travel: 560 mm control: iTNC 530 Heidenhain NC-Swivle milling head:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 10 / 15 kW max. Torque: 130 / 87 Nm tool taper: HSK-A63 swivellable: NC: +30 / -120 ° work table:: table surface area: 1.000 x 600 mm T-slots: 9x 14 x 63 mm NC-Rotary table:: table diameter: 600 mm rotatable: C: 360 ° max. table load: 500 kg tool magazin:: number of toolpositions: 60 pos. tool taper: HSK-A63 total power requirement: 40 kVA weight of the machine ca.: ca. 11,0 t dimensions of the machine ca.: 4,5 x 4,5 x 3,5 m Documents: Chip conveyor: Coolantsystem: high pressure coolant: 20 bar Coolant through spindle: AD turning milling head: NC NC-rotary table: elektr. hand wheel: test probe: TS 640 Heidenhain elektr. hand wheel: iTWC 530 tool setting: BLUM Laser 3D quickSET: Signal lam ...

x-travel: 1.000 mm y-travel: 1.000 mm z-travel: 1.000 mm Control: 840 D Siemens Main spindle:: turning speed range - main spindle: 20 - 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 Nm tool taper: HSK-A63 NC-Swivle milling head:: swivellable: B: -30 / +180 ° swivle time: 1,2 s pallet changer:: numbers of pallets: 2 size of pallet: 1.000 x 800 mm max. workpiece weight: 1.500 kg rotatable: C: 360 ° tool magazin:: number of toolpositions: 180 pos. tool taper: HSK-A63 total power requirement: 78 kVA weight of the machine ca.: 27,0 t dimensions of the machine ca.: 8,0 x 7,0 x 3,4 m Documents: Chip conveyor: Coolantsystem: through spindle coolant: pallet changer: Automatic Tool Changer: full splash guard: Rotary screen: elektr. hand wheel: 5 Axis - CNC Machining Center Universal DECKEL MAHO - DMC 100 U duoBLOCK - Swivel-Milling-Head (B-Achse) - NC-Rota ...

x-travel: 630 mm y-travel: 560 mm z-travel: 560 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: 20 - 12.000 min/-1 power capacity - main spindel: 15 / 10 kW max. Torque: 125 Nm tool taper: MAS BT 40 swivellable: B: 103 ° feed:: feed speeds: 20 - 10.000 mm/min rapid traverse X-axis: 26 m/min rapid traverse Y-axis: 26 m/min rapid traverse Z-axis: 20 m/min Resolution: 0,001 mm input unit: 0,001 mm work table:: surface area: 1.000 x 600 mm rotary table dia.: 600 mm number of T-slots: 8 / 1 T-slot - width: 14 H12 / 14 H7 T-slot - distance: 63 mm max. table loading capacity: 350 kg rotatable: C: 360 ° Tool-Presetter:: number of toolpositions: 24 pos. max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. tool length: 315 mm max. tool weight: 8 kg total wight: max. 100 kg total power requirement: 26 kVA weight of the machine ca.: 6,7 t di ...

x-travel: 630 mm y-travel: 560 mm z-travel: 560 mm control: iTNC 530 Heidenhain NC-Swivle milling head:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 10 / 15 kW max. Torque: 130 / 87 Nm tool taper: HSK-A63 swivellable: NC: +30 / -120 ° work table:: table surface area: 1.000 x 600 mm T-slots: 9x 14 x H7 max. table load: 700 kg tool magazin:: number of toolpositions: 60 pos. tool taper: HSK-A63 total power requirement: 49,7 kVA weight of the machine ca.: ca. 11,0 t dimensions of the machine ca.: 4,5 x 4,5 x 3,5 m Documents: Chip conveyor: Coolantsystem: high pressure coolant: turning milling head: elektr. hand wheel: Rotary screen: paper band filter: Spray gun: exhaust fan: indexing attachment: EA-733.20 Tailstock: CNC - MachiningCenter Universal DECKEL MAHO - DMU 60 monoBLOCK - 4 axes (+ NC dividing head) - Swivel-Millinghead - Spind ...

x-travel: 800 mm y-travel: 800 mm z-travel: 800 mm Control: iTNC 530 Heidenhain Main spindle:: Max. rpm: 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 / 82 Nm tool taper: HSK-A63 swivellable: B: 0 - 190 ° swivle time: 1,2 s NC-Rotary table:: table diameter: 900 x 700 mm max. table load: 1.400 kg rotatable: C: 360 ° tool magazin:: number of toolpositions: 40 pos. tool taper: HSK-A63 change-time chip to chip: ca. 5,0 sec feeds:: rapid traverse ( X / Y / Z ): 60 m/min rapid traverse: B: 30 m/min rapid traverse: C: 30 m/min feed speeds: max. 60.000 mm/min total power requirement: 64 kVA weight of the machine ca.: 14,0 t dimensions of the machine ca.: 6,5 x 6,5 x 3,5 m Documents: Coolantsystem: high pressure coolant: through spindle coolant: 40 bar turning milling head: NC-rotary table: Tool Magazine: Chip conveyor: tool monitoring: BLUM Laser elektr. h ...

x-travel: 750 mm y-travel: 600 mm z-travel: 520 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: 20 - 18.000 min/-1 power capacity - main spindel: 35 / 25 kW max. Torque: 130 / 87 Nm tool taper: HSK-A63 NC-Tilting round table:: table surface area: 700 x 500 mm Swivel range B-Axis: 0 - 180 ° Swivel range C-Axis: 0,001 ° max. table load: 350 kg center hole: 30 H6 mm T-slots: 7x 14H7 x 63 mm table turning speeds: 21,5 rpm tool magazin:: number of toolpositions: 32 pos. max. tool length: 315 mm max. tool diameter: 105 mm max. tool-dia with free toolbox: 130 mm max. tool weight: 6,0 kg feeds:: rapid traverse ( X / Y / Z ): 50 / 50 / 50 m/min feed speeds: 20.000 mm/min Feed force: X / Y / Z: 8 / 8 / 7 kN total power requirement: 50 kVA weight of the machine ca.: 8,5 t dimensions of the machine ca.: 6,5 x 3,5 x 3,5 m Documents: Chip-Tray: Coolantsystem: ...

x-travel: 2.200 mm y-travel: 560 mm z-travel: 720 mm control: iTNC 530 Heidenhain turning speed range - milling: 20 ~ 12.000 U/min power capacity - milling spindle: 35 / 25 kW tool taper: SK 40 tool piece magazine with: 100 pos. table surface area: 2.600 x 600 mm rapid traverse X-axis: 100 m/min rapid traverse Y-axis: 50 m/min rapid traverse Z-axis: 50 m/min max. tool diameter: 80 mm max. tool-dia with free toolbox: 130 mm max. tool length: 300 mm max. tool weight: 6 kg max. table load: 2.200 kg total power requirement: kW weight of the machine ca.: 12 t dimensions of the machine ca.: 7,0 x 4,2 x 2,7 m Chip conveyor: Coolantsystem: interface 4. axis: 4. axis: 560 mm Seperating wall: oil mist extraction: Tailstock: 350 mm / MK 5 elektr. hand wheel: through spindle coolant: 40 bar Travelling column milling machine DECKEL MAHO - DMF 220 Linear - new spindle installed (April 2024) - in ...

x-travel: 800 mm y-travel: 800 mm z-travel: 800 mm Control: iTNC 530 Heidenhain Main spindle:: Max. rpm: 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 / 82 Nm tool taper: HSK A63 swivellable: B: 0 - 190 ° swivle time: 1,2 s NC-Rotary table:: table diameter: 900 x 700 mm max. table load: 1.400 kg rotatable: C: 360 ° tool magazin:: number of toolpositions: 60 pos. tool taper: HSK A63 change-time chip to chip: ca. 5,0 sec feeds:: rapid traverse ( X / Y / Z ): 60 m/min rapid traverse: B: 30 m/min rapid traverse: C: 30 m/min feed speeds: max. 60.000 mm/min total power requirement: 64 kVA weight of the machine ca.: 14,0 t dimensions of the machine ca.: 6,0 x 6,5 x 3,2 m Documents: Coolantsystem: high pressure coolant: through spindle coolant: 40 bar turning milling head: NC-rotary table: Tool Magazine: Chip conveyor: test probe: Heidenhain TS 640 tool mo ...

x-travel: 880 mm y-travel: 630 mm z-travel: 630 mm control: iTNC 530 Heidenhain Main spindle:: turning speed range - main spindle: max. 18.000 min/-1 power capacity - main spindel: 28 / 19 kW max. Torque: 121 / 82 Nm tool taper: HSK-A 63 swivellable: B: +30° / -120 ° NC-Rotary table:: table surface area: Ø 700 / 1.250 x 700 mm max. table load: 650 kg rotatable: C: 360 ° max. workpiecediameter: 850 mm max. workpiece height: 550 mm tool magazin:: number of toolpositions: 32 pos. tool taper: HSK-A 63 max. tool diameter: 80 mm max. tool-dia with free toolbox: 160 mm max. tool weight: 8,0 kg change-time chip to chip: 10 sec feeds:: feed speeds: max. 30.000 mm/min rapid traverse: 30 m/min Accelaration: 5 m/s² total power requirement: 48 kVA weight of the machine ca.: 14,0 t dimensions of the machine ca.: 6,5 x 5,0 x 2,9 m Documents: Chip conveyor: Coolantsystem: test probe: Heidenh ...

x-travel: 2.200 mm y-travel: 560 mm z-travel: 720 mm control: 840 D Powerline ShopMill Siemens Main spindle:: turning speed range - main spindle: 20 - 12.000 min/-1 power capacity - main spindel: 35 / 25 kW max. Torque: 130 / 87 Nm tool taper: SK 40 internal coolant system feed: 40 bar work table:: table surface area: 2.600 x 600 mm max. table load: 2.200 kg number of T-slots: 6 T-slot - width: 18 H7 mm T-slot - distance: 100 mm Tool-Presetter:: number of toolpositions: 30 pos. max. tool length: 300 mm max. tool weight: 6 kg max. tool diameter: 80 / 125 mm feeds:: feed speeds: 20.000 mm/min input unit: 0,01 mm rapid traverse ( X / Y / Z ): 100 / 50 / 50 m/min measuring system: Resolution: 0,001 mm total power requirement: 60 kVA weight of the machine ca.: 12,5 t dimensions of the machine ca.: 6,0 x 3,7 x 2,9 m Documents: Chip conveyor: Coolantsystem: high pressure coolant: throu ...

x-travel: 300 mm y-travel: 150 mm z-travel: 340 mm table-size: 600x260 mm spindle taper ISO: 40 spindle turning speed range: 40-2000 U/min weight of the machine ca.: 700 kg Visit us on www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 710 mm y-travel: 600 mm z-travel: 455 mm Control: Dialog 4 turning speeds: 6300 U/min tool taper: SK40 quill stroke: 80 mm table-size: 550 x 1000 mm table load: 0,6 t weight of the machine ca.: 4 t X-axis travel: 710 mm Y-axis travel: 600 mm Z-axis travel: 455 mm Control system: Dialog 4 Spindle speed: 6,300 rpm Tool holder: SK 40 Quill stroke: 80 mm Table size: 550 × 1,000 mm Table load capacity: 600 kg Machine weight: approx. 4 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 640 mm y-travel: 600 mm z-travel: 500 mm Control: SIEMENS 810D powerline table dimensions: 850 x 630 mm table load capacity: 600 KG tool magacine with: 30 Plätzen spindle turning speed range: 12.000 U/min total power requirement: 42 kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 3,50 x 3,30 x 3,60 m Tool breakage / measurement BLUM Electronic handwheel 3 leveling elements chip conveyor coolant / belt filter system Interlit SPB 3/600 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
