cycle used for sale

A cycle-controlled CNC lathe Böhringer is available. Swing diameter over bed/faceplate: 570mm/365mm, center height: 280mm, bed width: 360mm, travel X: 345mm, cross slide dimensions X/Y: 260mm/680mm, bed slide guide length: 520mm, speed: 2500rpm, feed: 50mm/rev, rapid traverse X/Z: 10m/min/5m/min, quill stroke: 190mm, center angle: 60°, max. workpiece weight: 400kg/1000kg/1600kg. Documentation available. An on-site inspection is possible. Expected to be available July 2026.

Max. turning length 1500 mm, feed rate 10 m/min, circulation diameter over bed 475-550 mm, circulation diameter over face slide 260 mm, incl. assortment of spare parts Auction-ID: A1-46781-27

Universal lathe with cycle control VDF Boehringer VDF 400 DUS Control: Siemens Sinumerik 840 Year of Make: 2014 Internal machine no. 57 Turning length: 1,000 mm Turning diameter over bed / face slide: 420 / 235 mm Displacement of face slides: 250 mm Max. speed: 10 – 3,000 rpm Accessories: - Bezel - Suction - 3- Jaw chuck Schunk 250-62 - Tool holder

Excellent condition - Fully operational - Loading / Transport possible!

Cycle lathe Weiler E 50/1 Year of Make: 1997 Technical data Manufacturer: HAMLET Type: E 50 / 1 Year of Make: 1997 Tip height: 280 mm Center width: 1,000 mm Swing diameter: 500 mm Circumferential diameter over bed: 570 mm Circumferential diameter over support: 340 mm Spindle speeds: 0 - 2,500 rpm Lining: available Auction-ID: A1-46872-35

-Hamlet -E50/1 -No.: 474 -Year: 1996 -Operating hours: approx. 22,400 -Voest-Alpine Steinel control (whereby the control is probably via sep. desktop PC) -Incl. chip conveyor, various tool holders and tools Shipping available on request. Sale only to tradespeople. Indicated purchase price = Net plus 19% VAT = €9,282.00 Gross

turning diameter:570 mm turning length:1000 mm dimensions of the machine ca.:3,25 x 2,03 x 1,95 m Tool disc turret for 8 tools with VDI 30. Not for power tools machine manual, technical documentation; Accessories: 3-jaw chuck, various tool holders Video is available

turning diameter:500 mm turning length:1500 mm spindle motor:16 kW Spindle RPM:1 - 2500 1/min taper in tailstock MT:5 tailstock quill stroke:160 mm tailstock quill diameter:70 mm total power requirement:22 kW weight of the machine ca.:3,2 t dimensions of the machine ca.:3,2 x 1,8 x 1,4 m Machine with Heidenhain Manual plus control - Multifix quick tool change device - 3-jaw chuck - sliding splash door - various accessories.

turning diameter:570 mm turning length:- mm control:- Diameter of rotation above the bed slide:360 mm Maximum width:2.000 mm revolutions per minute:max. 2500 U/min :11 kW max. longitudinal feed:7,5 m/min max. transverse feed:7,5 m/min rapid traverse longitudinal:12 m/min rapid traverse cross:15 m/min Pinole diameter:95 mm Pinolenhub:220 mm Pinolen intake: MK 5 weight of the machine ca.:2,97 t dimensions of the machine ca.:3,8m x 1,3m x 2m m Technical description: - Tool turret - automatic - 8-fold (see also options) - CAPTO Revolver Disc - Machine bed - made of perlite casting GG-26 - high stiffness due to strong ribbing - Bed slides - guideways hardened and ground - automatic lubrication of the bed rail - Reitstock - manual - Quick clamp - Operator station - two movable handwheels on the operator panel - a movable handwheel - Control - "Siemens 828 D" CNC control - Siemens "Comfort" (in ...

turning diameter:500 mm turning length:1500 mm Technical Specifications: ·Turning diameter over cross slide: 290 mm ·Spindle bore: 71 mm ·Speed range: 3?2,800 rpm ·Rapid traverse speed: 10 / 5 m/min ·Feed rate: 1?2,000 mm/min ·Total power requirement: 22 kW ·Machine weight: approx. 3.2 t ·Space requirement: approx. 3.0 × 1.6 × 2.0 m

turning diameter:830 mm turning length:4.000 mm turning diameter over bed slide:540 spindle bore:130 mm turning speed range:2 - 1.600 U/min rapid speed:4/5 m/min feed speeds:1 - 2.000 mm/min total power requirement:55 kW dimensions of the machine ca.:7 x 2,2 x 2 m weight of the machine ca.:7,5 t

turning diameter:500 mm turning length:1000 mm control:MANUAL PLUS Grundig total power requirement:24 kVA weight of the machine ca.:2650 kg dimensions of the machine ca.:2500 x 1750 x 1850 mm swing diameter over face slide:290 mm chuck:Ø max. 260 mm cross movement:260 mm spindle head:DIN 55027 Größe 8 spindle bore diameter:70 mm rapid travel - longitudinal/face:8 /6 m/min spindle speeds::8 - 2800 tailstock travel:180 mm tailstock quill taper MT:5 Documents:vorhanden

turning diameter:500 mm turning length:1000 mm control:MANUAL PLUS Grundig total power requirement:24 kVA weight of the machine ca.:2650 kg dimensions of the machine ca.:2500 x 1750 x 1850 mm swing diameter over face slide:290 mm chuck:Ø max. 260 mm cross movement:260 mm spindle head:DIN 55027 Größe 8 spindle bore diameter:70 mm rapid travel - longitudinal/face:8 /6 m/min spindle speeds::8 - 2800 tailstock travel:180 mm tailstock quill taper MT:5

turning length:2000 mm control:- total power requirement:25 kW weight of the machine ca.:3 t dimensions of the machine ca.:3800 x 1800 x 1850 mm swing over bed:500 mm swing diameter over face slide:280 mm control:Zyklen-Steuerung Heidenhain bed width:350 mm Documents:vorhanden

turning diameter:230 mm turning length:810 mm centre distance:1.000 mm turning diameter over bed:460 mm spindle passage:56 mm chucking diameter:200 mm turret head:8 x VDI 30 Pos. turning speeds:3.100 1/min max. workpiece weight:570 kg spindle motor:18 kW dimensions of the machine ca.:3,7 x 1,9 x 1,8 m weight of the machine ca.:2,9 t teach-in lathe, PARAT tooling-system, hand operated collet chuck, 3 jaw chuck, 4 toolholders

turning diameter:1000 / 700 mm turning length:3000 mm face slide travel:600 mm turning diameter over slide:700 mm turning speeds:1-1.800 1/min transmission ratio:2 spindle:46 (60%) kW spindle bore:132 mm quill stroke:280 mm workpiece weight max.:2.560 kg total power requirement:38 kW weight of the machine ca.:6 t dimensions of the machine ca.:5 x 2,6 x 1,9 m teach in lathe, PARAT tooling system, SCHUNK ROTA NC 500-160 hydr. power chuck, tailstock, chipconveyor

turning diameter:830 mm turning length:4000 mm turning diameter over bed slide:540 mm spindle bore:130 mm turning speed range:2 - 1600 U/min rapid speed:4 / 5 m/min feed speeds:1 - 2000 mm/min total power requirement:55 kW weight of the machine ca.:7,5 t dimensions of the machine ca.:7 x 2,2 x 2 m with Teach In controll R&D MTC-K MULTIFIX toolpost size D coolant attachment

turning diameter:500 mm turning length:1500 mm turning diameter over bed slide:290 spindle bore:71 mm turning speed range:3 - 2800 U/min rapid speed:10 / 5 m/min feed speeds:1 - 2000 mm/min total power requirement:22 kW weight of the machine ca.:3,2 t dimensions of the machine ca.:3,0 x 1,6 x 2 m with Teach In controll R&D MTC-K PARAT toolpost 1 fixed steday dia. 100 mm 4 jaw face plate dia. 500 mm coolant attachment

turning diameter:800 mm turning length:2965 mm max. turning dia. over saddle:520 mm spindle bore:92 mm turning speed range:3 - 1800 U/min spindle head:Größe 11 total power requirement:37 kW weight of the machine ca.:6,5 t dimensions of the machine ca.:5,2 x 2,2 x 1,9 m Teach In Control MTC-K 3-jaw chuck ROTAS Dia. 400 mm face plate RÖHM Dia. 630 mm 4-station toolholder system PARAT 1 fixed steady coolant attachment and chip conveyor

turning diameter:1250 mm turning length:6000 mm spindle bore:130 mm Turning rate:5 - 710 U/min. turning diameter over bed slide:850 total power requirement:37/52 kW weight of the machine ca.:16 t dimensions of the machine ca.:12 x 4 x 2 m Teach In Controll HEIDENHAIN 1 fixed steady

Working range Center distance: 1,500 mm Travel over bed: 570 mm Travel over cross slide: 340 mm Cross slide travel: 290 mm Bed width: 350 mm Spindle Spindle head DIN 55027 size 8 Spindle bore: 93 mm Speed range: 1–3,000 rpm Main drive: 20 kW AC motor Tailstock Quill diameter: 90 mm Quill stroke: 180 mm Mounting: MK 6 Feed Feed force X: 7,000 N Feed force Z: 10,000 N Rapid traverse X: 7 m/min Rapid traverse Z: 10 m/min Machine Weight: approx. 3.6–3.9 t Dimensions: approx. 3,300 × 1,800 × 1,900 mm Equipment Heidenhain Manual Plus cycle control Heidenhain AC servo drives ZF two-speed gearbox (electrically switched) 3-jaw wedge bar chuck Ø250 mm Face plate Ø500 mm Fixed steady rest Tailstock with live center Multifix tool holder Parat 4-station turret Reinforced coolant pump Machine feet Accessories Multifix tool holder package Various turning holders Measuring equip ...
