used
CONTROLS CNC Teach In Controls SIEMENS 810 D BASIC FUNCTIONS number of spindles: 1 WORKING RANGE TURNING swing diameter (max): 420 mm worpiece length max.: 1130 mmMAIN SPINDLE spindle revolutions (min): 10 /min spindle revolutions (max): 3000 /min spindle bore diameter: 51 mmTAILSTOCK sleeve stroke: 110 mm sleeve diameter: 70 mm taper: MK 4 ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS space requirements -left/right-: 3500 mm space requirements -front/back-: 1500 mm total height: 1800 mm total weight approx.: 3500 kgMachine rarely usedFurnishing:- 3 jaw chuck D210- 4 compartments ready change holder
used
Description: Rotation diameter over bed 570 mm, over facing slide 365 mm, bed width 360 mm, main spindle head size 8, spindle diameter in front bearing 100 mm, spindle bore 62 mm, inner taper of main spindle 70 mm, main drive 19/15 kW, torque at 60 % 1800 Nm, at 100 % 1400 Nm, total speed range 3 to 2500 rpm, max. feed speed flat 5 m/min, max. feed rate 5 m/min, max. feed rate 5 m/min, max. feed rate 5 m/min, max. feed rate 5 m/min, max. feed rate 5 m/min, max. feed rate 5 m/min, max. feed rate 5 m/min, max. feed rate 5 m/min, max. feed rate 5 m/min, max. feed speed planar 5 m/min, longitudinal 10 m/min, thread pitches metric thread 0.1 to 400 mm, tailstock quill diameter 80 mm, quill stroke 190 mm, quill taper MK 5, centre angle 60°, max. turning length 1500 mm, control SIEMENS SINUMERIK 810Approx. Onsite Dimension. (l x w x h): 3,000 x 1,800 x 1,900 mm, weight approx.: 3,500 kg
used
CONTROLS CNC Teach In Controls NUM 1062 BASIC FUNCTIONS number of x/z slides: 1 live positions: no WORKING RANGE TURNING swing diameter (max): 570 mm turning diameter (max): 365 mm worpiece length max.: 1000 mmMAIN SPINDLE spindle revolutions (min): 3 /min spindle revolutions (max): 2500 /min number of gears: 2 spindle diameter: 62 mmX/Z SLIDE traverse velocity Z (min): 0 mm/min traverse velocity Z (max): 10000 mm/min traverse velocity X (min): 0 mm/min traverse velocity X (max): 5000 mm/min tool fixture: Steel Holder TAILSTOCK taper: MK 5 ELECTRICAL SPECIFICATIONS mains power supply: 35 kVA mains voltage: 400 V mains frequency: 50 HzDIMENSIONS / WEIGHTS space require ...
used
turning diameter: 700 mmturning length: 4000 mmcontrol: Pico Auto Memory centre height: 350 mmturning diameter over slide: 480 mmspindle passage: 80 mmtailstock quill taper MT: MK5 turning speeds: 1500 U/mintotal power requirement: 12,5 kWweight of the machine ca.: 6 tdimensions of the machine ca.: 5,6x1,6x2,25 mTailstock MK 5Quick change steel holderCycle control Pico Auto MemorysteadyRöhm 315 wedge bar chuckcoolant devicevarious steel holdersThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
turning diameter: 710 mmturning length: 2000 mmcontrol: Heidenhain type: Manuel Plus turning diameter over slide: 410 mmx-travel: 385 mmturning speeds: 9-1800 U/mintransmission ratio: 2 drive capacity - workpiece: 22 kWTorque: 2500 Nmspindle diameter: 160 mmspindle passage: 92 mmtotal power requirement: 49 KVAweight of the machine ca.: 5,6 tdimensions of the machine ca.: 5x2x2,2 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Cycle-controlled lathe GILDEMEISTER NEF 520 With control MANUAL PLUS 4110 Year of construction: 2005 Spindle bore: 70 mm Center width: 1000 mm Circulation O above bed : 500 mm Circulation O over face slide: 290 mm Center height: 250 mm Speed range: 10 – 3050 rpm infinitely variable With the following accessories: Slide protection with interior lighting 8-speed Sauter Revolver VDI 30 30 VDI 30 tool holders 2 driven tools VDI 30 1 collet chuck Coolant system 3 jaw chuck Röhm 0 250 mm 19 set of soft jaw inserts ICP Contour Programming Tailstock with extendable drill quill Chip pan Operating instructions
used
Cycle-controlled lathe GILDEMEISTER NEF 720 With control MANUAL PLUS 4110 Year of construction: 2001 Spindle bore: 92 mm Center width: 1500 mm Circulation O above bed : 710 mm Circulation O over face slide: 410 mm Center height: 350 mm Speed range: 36 – 1800 rpm infinitely variable With the following accessories: Slide protection with interior lighting Multifix Tool Holder Coolant system 3 jaw chuck Forkhardt 0 315 mm ICP Contour Programming Tailstock with extendable drill quill Chip pan Operating instructions
used
Control MANUAL PLUS CNC 2-axis cycle control Turning diameter 500 mm Turning length 1500 mm Turning diameter over carriage 290 mm Flat travel 260 mm Speed 2800 1/min. Tool holder at your fingertips Tailstock
used
Description: Serial number 3083947turning diameter: 400 mm, Drehlänge: 1,200 mm, turning diameter over slide: 280 mm, spindle bore: 76 mm, turning speed range: 2,000 rpm, Approx. Onsite Dimension. (l x w x h): 3,200 x 1,900 x 2,100 mm, weight approx.: 2,000 kg
used
Center height: 200 mm Center width: 1250 mm gr. Turn-Ø over bed: 400 mm Spindle bore: 55 mm Spindle holder: Camlock D1 6" mm Pick-up cone of tailstock quilts: 5 MK Spindle speeds: 1-297/1-861/1-2700 rpm electr. Connection: 400 V, 7.5 kW Space requirement: 2900 x 1800 x 1500 mm Weight: 2200 kg
used
Controls : Heidenhain Workspace Circulation diameter over bed 320 mm Circulation diameter over carriage 150 mm Center width 800 mm Working spindle Spindle holder according to DIN 55027 B6 Spindle bore 50 mm Spindle taper metric 60 Main drive Engine power at speed 1500 min-1 7 kW Spindle speed range 1st stage 0 - 1000 mm-1 Spindle speed range 2nd stage 20 - 4000 mm-1 Max. spindle torque 1.Stage 360 Nm 2nd stage 90 Nm Axis X Max. travel 190 mm Rapid traverse 5000 mm.min-1 Max. feed force 3000 N Axis Z Max. travel of the bed carriage 750 mm Rapid traverse 8000 mm.min-1 Max. feed force 5000 N Quick Release Holder Parat RD2 Max. steel diameter 25 x 25 mm Tailstock Diameter of the quill 65 mm Adjustment of the quill 120 mm Inner cone of the quill – Morse code 4 Dimensions of the machine Length 2180 mm Width 1341 mm Height 1775 mm Weight of the ...
used
control: HEIDENHAIN MANUAL PLUS M turning diameter over bed: 320 mmcentre height: 160 mmcentre distance: 800 mmturning dia. over face-slide: 150 mmspindle bore: 50 mmspindle taper: DIN 55027/B6 spindle turning speed - stepless: 0-4000 U/mintotal power requirement: 7 kWdimensions of the machine ca.: 400x160x190 cmweight of the machine ca.: 2.2 tThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Description: Center height: 260 mm Distance between centers: 1500 mm Turning diameter over bed: 530 mm Diameter over longitudinal slide: 475 mm Turning diameter over cross slide: 315 mm Bed width: 350 mm Main spindle bore STD = 80 mm Spindle holder: DIN55027 N.8 Morse taper of the main spindle: MK5 Constant cutting speed diameter 80 mm: Stage 1: 0 - 564 rpm Speed 2: 564 - 2500 rpm Feed rates: Z, X: 0 - 10000 mm/min Rapid traverse Z, X: 10 m/min Quill diameter: 82 mm Quill travel: 235 mm Morse taper in the quill: MK5 Power of the main motor: 11 kW With technical documentation as shown in the pictures Control: GE FANUC Series 0i Mate-TCApprox. Onsite Dimension. (l x w x h): 3,300 x 1,450 x 1,850 mm, weight approx.: 3,300 kg
used
Ref. -No.: 10366Manufacturer: MONFORTSYear of construction: 2000Type of control: CNCControl: EURO TURNStorage location: HalberstadtCountry of origin: DeutschlandMachine length: 5000 mmMachine width: 1970 mmMachine Height: 1800 mmX stroke: 370 mmZ - stroke: 2880 mmChuck diameter: 200/250/315 mmCentre Distance: 3040 mmSpindle Head: DIN 55027 - 8x220 Feed Capacity - Z: 18,9 kNFeed Capacity - X: 11,3 kNRapid Travel Speed X-Axis: 5 m / minRapid Travel Speed Z-Axis: 10 m / minCircumferential diameter over radial slide: 350 mmMax swing diameter: 720/630 mmtravel of the cross slide: 375 mmSpindle head max. passage for violent material: 68 mmSpindle head max. passage for bare material: 70 mmTailstock outside diameter of the quill: 110 mmTailstock maximum quill stroke: 210 mmTailstock inner cone: MK6 TypeFurther information:Additional lubricating oil tank approx. 6l
used
turning diameter: 630 mmturning length: 200 mmcontrol: MTC K turning diameter over slide rest: 360 mmturning speeds: 1800 U/min3-jaw chuck: 315 mmHolder Multifix: total power requirement: kWweight of the machine ca.: tdimensions of the machine ca.: mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
turning diameter: 800 mmturning length: 2000 mmcontrol: Monfort R&D turning diameter over slide: 520 mmspindle hollow: 88 mmtotal power requirement: 53 kWweight of the machine ca.: tdimensions of the machine ca.: 4,2x2,2x1,9 mThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Ref. -No.: 10365Manufacturer: MONFORTSYear of construction: 1997Type of control: CNCControl: MTC KStorage location: HalberstadtCountry of origin: DeutschlandMachine-No.: 178.05 Machine length: 5200 mmMachine width: 2110 mmMachine Height: 1995 mmWeight Of The Machine Ca.: 6,850 (Ohne Späneförderer und Kühlmittelbehäter) tX stroke: 455 mmZ - stroke: 2850 mmChuck diameter: 315/400/500 mmCentre Distance: 3000 mmSpindle Head: DIN 55027 - 11x290 Feed Capacity - Z: 23,9 kNFeed Capacity - X: 11,3 kNRapid Travel Speed X-Axis: 6,8 m / minRapid Travel Speed Z-Axis: 4 m / minCircumferential diameter over radial slide: 540 mmMax swing diameter: 830 mmtravel of the cross slide: 450 mmSpindle head max. passage for violent material: 88 mmSpindle head max. passage for bare material: 90 mmTailstock outside diameter of the quill: 125 mmTailstock maximum quill stroke: 200 mmTailstock inner cone: MK6 Typ ...
used
Ref. -No.: 10369Manufacturer: MONFORTSYear of construction: 2005Type of control: CNCControl: MTCK/Euro TurnStorage location: HalberstadtX stroke: 450 mmZ - stroke: 3850 mmCentre Distance: 3970 mmFeed Capacity - Z: 20,7 kNFeed Capacity - X: 10,1 kNRapid Travel Speed X-Axis: 4 m / minRapid Travel Speed Z-Axis: 5 m / minTailstock Quill Diameter: 125 mmTailstock Quill Stroke: 200 mmCircumference diameter over slideway: 830 mmCircumferential diameter over radial slide: 540 mmspindle taper diameter: 140 (Metrisch) mmQuills Morse taper: MK6 Max swing diameter: 900 mm
used
Ref. -No.: 10313Manufacturer: MONFORTSYear of construction: 2001Type of control: CNCControl: EUROTURNStorage location: HalberstadtCountry of origin: DeutschlandMachine-No.: 164 01 Machine length: 6200 mmMachine width: 2110 mmMachine Height: 1995 mmWeight Of The Machine Ca.: 7,7 tX stroke: 450 mmZ - stroke: 3850 mmChuck diameter: 315/400/500 mmTurning Diameter: 630 mmTurning Length: 3000 mmCentre Distance: 3985 mmSpindle Head: DIN 55027 - 11x290 Feed Capacity - Z: 23,9 kNFeed Capacity - X: 11,3 kNRapid Travel Speed X-Axis: 4 m / minRapid Travel Speed Z-Axis: 5 m / minTailstock Quill Diameter: 125 mmTailstock Quill Stroke: 200 mmSpace requirement: 7500 x 3500 mmCircumferential diameter over radial slide: 540 mm mmspindle taper diameter: 140 mmJaw chuck diameter: 400 mmjaw continuity: 102 mmQuills Morse taper: 6 Max swing diameter: 830 mmtravel of the cross slide: 450 mmSpindle head max. pa ...
used
Ref. -No.: 10374Manufacturer: MONFORTSYear of construction: 2000Type of control: Zyklen gesteuertControl: MONFORTS ControlStorage location: HalberstadtCountry of origin: Germany
used
Tip height: 300 mm centre distance: 1500 mm gr. Turning diameter over bed: 625 mm spindle bore: 105 mm spindle retainer: Gr. 8 mm taper of tailstock Quill: 5 MK spindle speed: 6.6-2000 RPM elect. Supply: 400 V, 15 kW space: 4400 x 2050 x 1820 mm weight: 5200 kg
used
CONTROLS CNC Teach In Controls SIEMENS BASIC FUNCTIONS design principle: flatbed number of spindles: 1 WORKING RANGE TURNING swing diameter (max): 720 mm turning diameter (max): 380 mm bar diameter (max): 108 mm worpiece length max.: 1500 mmMAIN SPINDLE spindle revolutions (min): 0 /min spindle revolutions (max): 1200 /min number of gears: 3 spindle bore diameter: 108 mmX/Z SLIDE traverse velocity Z (max): 5000 mm/min traverse velocity X (max): 5000 mm/min rapid traverse Z: 5000 mm/min rapid traverse X: 5000 mm/min tool fixture: Steel Holder TAILSTOCK distance betw. centers (max): 1500 mm sleeve stroke: 200 mm sleeve diameter: 120 mm taper: MK 6 ELECTRICAL SPECIFICATI ...
used
No. 5197: 1 Gebr. Cycles Lathe Fabr. PINACHO, type Mustang 200, Bauj. 2001
used
Ref. No. 00789 Description of the system: Cycle-controlled lathe Manufacturer: Pinacho (Metosa) Model MUSTANG 225 Year of construction 2000 Technical data CNC control FAGOR 8055 TC Center height 225mm Center width 1000mm 8-speed turret VDI 30 Accessories Fixed bezel Three-jaw chuck Soft CNC 3.06 Energized condition Stainless steel parts are currently being machined Axles ok Rotate fits on it Small drawback: Revolver swivels like on the video In this case, counterclockwise, which is also the direction that still works, which is also accurate to change – in the other direction, the turret has an offset, from the technician it was said that it would not be worth repairing it But it can be replaced or repaired. Machine is running and is currently in operation. A viewing can be arranged at any time. Submission date: Immediately after arrangement ...
used
Key data: 227 mm, 410 mm
large circumferential diameter 270 mm gr. turning diameter over carriage 150 mm X - Axis 136 mm Z - axis 410 mm Spindle nose D 1-3" CAMLOCK Collets B 32 Spindle passage 28 mm Spindle passage w/collet 24 mm Speed range 50 - 5000 rpm Trustock quill diameter 35 mm Cone in the quill 2 MK Tailstock - quill stroke 100 mm Machine weight approx. 1200 kg Machine dimensions 1.7 x 1.2 x 1.6 m Configuration Title CNC FANUC QT2 teach-in MULTIFIX A steel bracket system Previous use in laboratory.
used
- Swing diameter over bed: 490 mm - Distance between centers: 1000 mm - Swing diameter over face slide: 280 mm - Speed range: 1 - 625 / 1 - 3,000 rpm - Transmission stages: ZF - 2 - Spindle passage: 93 mm - Spindle bearing diameter: size 8 - 130 mm - Tailstock mount: MK5 - stroke 160 mm - Control: Siemens Manualturn - Total power: 17 kW - Machine weight: 3,600 kg - Dimensions (W x D x H): 3.0 x 1.8 x 2.0 m - Operating hours: 31556 h Details without jaw chuck, contour calculation option and contour handwheel, multifix mount, spindle head according to DIN 55027 Accessories Documentation, suction, no other accessories
used
Seiger SLZ 570 E Year of construction: 2004 Control: Heidenhain Manual Plus 4110 Circulation Ø above bed 570 mm Circulation Ø via face slide 340 mm Bed width 350 mm Peak Distance 2000 Tailstock quill Ø 90 mm tailstock Morse taper MK 5 Spindle bore 93 mm Spindle head according to DIN 55027 Gr. 8 Spindle Ø in front bearing 130 mm L/W/H 3.990/2.200/1.970 Main drive 25 KW Guideways and glass scale in the X-axis Safety coupling in the Z- and X-axis Long, continuous face slider with adjustable wedge strip
used
turning diameter: ca. 850 mmturning length: 6000 mmcontrol: Heidenhain 620 centre distance: 6000 mmswing diameter over bed slide: 1250 mmswing diameter max. over cross slide: 850 mmradial face slide adjustment: 680 mmspindle bore: 130 mmmain drive AC:: spindle capacity 100% / 60% ED: 37 / 52 kWmax. torque: ca. 9000 Nmturning speed range: 5 - 710 U/minfeed motor AC:: rapid traverse X-axis: 6 m/minrapid travel Y-axis: 3 m/mintailstock:: diameter of quill: 160 mmquill stroke: 315 mmquill holder (inner taper): MK 6 steady, closed: passage: 450 mmtotal power requirement: 52 kWweight of the machine ca.: 16,5 tOverall size: 9000 x 2200 x 2300 mmdimensions of the machine ca.: 12 x 4 x 2 mEquipment/accessories:- face plate diameter 1200 mm - various fixators- documentationThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 380 mm, 1000 mm
used cycle lathe Seiger SLZ360 Built in 1999 Switch-on hours approx. 20000 h Circumferential diameter over bed 380 mm Center width 1000 mm Speed range 1-4000 1/min incl. control Heidenhain manual Plus M Parat Holder Coolant system Manual
used
Control SIEMENS Swing diameter over bed 350 mm Turning diameter 180 mm Distance between centers 500 mm Spindle speed 4000 min-1 Tailstock Multifix Accessories
used
Ref. -No.: 10320Manufacturer: TOSType of control: Digitalanzeige - MitutoyoControl: KonventionellStorage location: HalberstadtCountry of origin: TschechienTip length: 1500 Centre Height: 280 mmCentre Distance: 750,1000,15000,2000 mmSpindle Bore: 56 mmSwing diameter over bed: 500 mmNumber of speed levels: 18 Circumferential diameter over the support: 320 mmCircumferential diameter over the bed recess: 560 mmBed length relieved from headstock: 300 mmUniversal chuck diameter: 250 mmDiameter of the clamping disc: 500 mmFurther information:Universal center lathe
used
: . centre distance: 2000 mmturning diameter: max. 570 mmspindle bore: 70 mmcontrol: 805 weight of the machine ca.: 3 tThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 1500 mm, 3000 mm
Control: CNC Weiler (based on Siemens Sinumerik 840 D) Turning length: 3,000 mm Turning diameter: 1500 mm Spindle bore: 165 mm Sledge travel: 790 mm Upper slide: 250 mm Spindle speed: 1 – 1120 /2 steps Tailstock quill mount: MK 6 Tailstock adjustment: 3,000 mm Swivelling C-axis, chip conveyor, clamping cylinder with clamping hydraulics, extraction system, machine platform
used
Cycle-controlled lathe WEILER E 40 With Siemens Sinumerik SL 1 cycle control Year of construction: 2013 Spindle bore: 66 mm Center width: 1000 mm Circulation O above bed : 435 mm Circulation O over face slide: 200 mm Center height: 210 mm Speed range: 1 – 3500 rpm infinitely variable With the following accessories: Slide protection with interior lighting 4-fold PARAT tool holder 20 PARAT tool holders 3 jaw chucks RÖHM Duro T 200 1 pc Rotating Lynette 0 160 mm Tailstock with extendable drill quill Coolant device Chip drip tray Operating instructions
used
Control: Manufacture: WEILER turning dia. over bed: 330 mmcentre height: 165 mmcentre distance: 770 mmturning dia. over face-slide: 160 mmspindle bore: 42 mmspindle taper: 55027/5 spindle turning speed - stepless: 1-4500 U/mintailstock quill taper MT: 3 dia. of quill: 50 mmquill stroke: 110 mmfeed - longitudinal/cross: 0.001-20 mm/minrapid traverse longitudinal: 10 m/minrapid traverse cross: 5 m/minspindle drive: 9/11 kWdimensions of the machine ca.: 1800x1200x1700 mmxmmxmmweight: 1300 kg3-jaw-chuck diameter: 160 mmmake: FORKKARDT quick change tool holder:: MULTIFIX type: B numbers of toolholders: 6 coolant: misc. accessories: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 330 mm, 750 mm
Machine is in top condition and incl. accessories ( 20 Multifix holders, 70 collets, glory chuck) , 1 - 4500 rpm, 1300 Kg, under power
used
Description: SPECIFICATIONS Lathe teacher Character: Weiler Type: E35 Control: Siemens Sinumerik 805 Year of construction: 1996 Distance between centers: 1,000 mm Center height: 210 mm Turning diameter above the bed: ø420 mm Turning diameter above the base: ø200 mm Door flap: ø58 mm 3 chuck: ø255 mm Quick change holder Machine dimensions (lxwxh): 2,300 x 1,600 x 1,700 mm Machine weight: 2,100 kgApprox. Onsite Dimension. (l x w x h): 2,300 x 1,600 x 1,700 mm, weight approx.: 2,100 kg
used
control: WEILER turning diameter over bed: 410 mmcentre height: 200 mmcentre distance: 1000 mmturning dia. over face-slide: 200 mmspindle bore: 54 mmspindle taper ISO: 55027/6 spindle turning speed - stepless: 4-3000 U/mintailstock quill taper MT: 4 diameter of quill: 65 mmquill stroke: 120 mmfeed - longitudinal/cross: 0-20 mm/minrapid traverse longitudinal and cross: 10/5 m/minspindle drive: 9/13 kWdimensions of machine: 2300x1200x1800 mmweight: 2.0 tThe data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
