134,633 used machines on RESALE, but how to find them? Machine Search
pressure: 400 t chamfer lenght: 4050 mm distance between columns: 3550 mm control: CYBELEC ModEva 10 S total power requirement: 47 kW weight of the machine ca.: 30.400 kg dimensions of the machine ca.: 6000x3000x3450 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Used CNC Internal Cylindrical Grinding Machine Danobat Overbeck ID-400 Year of construction 2021 Siemens 840D SL CNC control Center height / factory specification: 230 mm Actual measured tip height: 270 mm Internal grinding diameter 200 mm Grinding length 200 mm Max. workpiece length including clamping system 400 mm X-axis stroke 425 mm Resolution min. 0.0001 mm Feed speed 1 ~ 25,000 mm/min Linear motor Z-axis stroke 475 mm Resolution min. 0.0001 mm Feed speed 1 ~ 25,000 mm/min Linear motor Workpiece weight including chuck max. 500 kg HVX high-frequency grinding spindle, 7 kW, 75,000 rpm PREPARED for HVX high-frequency grinding spindle, 3 kW, 90,000 rpm Machine bed made of natural granite Cooling unit for cooling the linear motor drives, torque motors, spindles and the electrical control cabinet. Cooling lubricant Complete machin ...
Optical Profile Projector PRAZIS PO-400-VD Year of construction: 1991 Useful table dimensions: 260 x 240 mm Scale axis X - Y + scale on W axe Diameter of the projection disc: Ø 400 mm Supplied with: 1 optical magnifier 10 x 1 optical magnifier 20 x 1 optical magnifier 50 x Length: 1000 mm Depth: 900 mm Total height: 1700 mm Weight: approx 400 KG
The machine is in good technical condition; testing is possible by prior arrangement. X-axis travel: 850 mm; Y-axis travel: 700 mm; Z-axis travel: 500 mm. Table dimensions (LxW): 10; load capacity: 2000 kg. Rapid traverse (XYZ/BC): 35 m/min. Spindle head: HSK-A63; speed: 0–18,000 rpm; spindle motor power: 20 kW. Tool positions: 38. Control system: Heidenhain TNC 640. Air through spindle. Heidenhain TS460 touch probe. Electronic handwheel. Approx. 20 HSK-A63 tool holders (in the changer). Manual cabin roof. Preparation for mist extraction system. Wash-down gun. Original HERMLE + Heidenhain documentation.
Lg.Nr. 26301 Technical data: - Saw blade diameter up to 400 mm - Cutting range with saw blade diameter 400 mm - at 90° to around 130 mm - Square 120 mm -flat 305 x 40 mm - or 240 x 85 mm - Mitre adjustable left + right 0 - 90 ° - at 45° to around 130 mm - flat 245 x 30 mm - or 180 x 70 mm - Feed speed of the saw blade - Infinitely adjustable 0 - 10 m/min - Saw blade cutting speed 13 / 26 m/min - Saw drive 400 V / 1.7 / 2.6 kW - Hydraulic drive 400 V / 0.75 kW - hydr. Material vise with hand crank for fine adjustment - Infinitely adjustable clamping pressure - 2 pieces of hydraulic retainers - Micro spray coolant device - Original discharge - roller conveyor with dimension stop 4000 mm - Roller conveyor feeder 2000 mm - Space requirement approx. W 900 x H 1800 x D 1050 mm - Weight approx. 950 kg
Panel saw Type: CLASS SI 400 Manufacturer: SCM Year: 2023 panel sizing capacity: 3200 × 3200 mm sliding carriage length: 3200 mm cutting width with parallel fence: 1270 mm maximum main saw blade diameter: 400 mm maximum cutting height at 90°: 140 mm maximum cutting height at 45°: 97 mm blade tilting: up to 45° main saw blade speed: 3000 / 4000 / 5000 rpm scoring saw blade speed: 8500 rpm main motor power: 7 kW scoring motor power: 1.3 kW machine weight: approx. 1070 kg EQUIPMENT independent scoring unit professional 3200 mm SCM sliding carriage eccentric clamp extendable frame for angular cuts parallel fence with micrometric adjustment direct main motor start dust extraction from main unit and overhead guard CE safety equipment Machine in good condition, fully functional, under power Find more here - .ucymachines/ Contact us at - sales@ucymachines
Number of spindles: 5 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 mm Feed motor: 4 kW Feed speed: 5-30 m/min. Control: Memory-Funktion Weinig Powermat 400 with HSK/Powerlock, axial/radial CNC controlled ---------------------------------------------------------------------- This machine is currently being refurbished at our facility! Pictures taken before dismantling and currently during the processing phase! Brief Summary: ---------------------------------------------------------------------- - 5 spindles with 8,000 rpm - 4 x HSK/Powerlock - Axially and radial CNC adjustments of the spindles via control - CNC-controlled adjustment and positioning of the feed - Table tops with guide blades at spindles 2 and 3. - Includes Weinig/Neumann RF 15 return conveyor system Detailed Description: ----------------------------------------------------------------- ...
faceplate diameter: 4000 mm swing diameter: 4600 mm turning height: 2650 mm workpiece weight: 100 t max. torque on the faceplate: 178,4 kNm faceplate speeds from - to: 1,8- 80 U/min feed stepless: 0,1 - 6000 mm/min z-axis: 1500 mm Control: Siemens 880T drive motor: 100 kW ram head dimension: 300 x 300 mm x-axis: R: 2500 / L: 2500 mm y-axis: 2900 mm z-axis: R: 200 / L: 1500 mm ram head dimension: 300 x 300 mm total power requirement: 69 kW weight of the machine ca.: - t dimensions of the machine ca.: 17,5 x 10.5 m - CNC control Siemens 880T - Coolant system - Chip Conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Griggio Unica 400 sliding table saw Manufacturer: Griggio Type: Unica 400 Year: 2010 M-Nr.: MC00101468 Main saw: ø400 mm, saw height: 125 mm, tilting: 0-45° Saw height setting, tlting: electric with digital counter Rotation speed: Cutting Heigt: 0-125 mm electric with digital reading Saw tilting: 0 – 45° electric with digital reading Motor: 7.5 KW Scoring saw: 0.75 KW, ø125 Sliding Table: 3.200 mm Cutting Width: 1.250 mm electric with digital reading on the fence Cross cut fence: 2.200 – 3.300 mm Side table: steel with angle prefix, productsupport and easy loading roll Dust extraction: Top: ø80 mm, bottom: ø120 mm Weight: 820 KG Condition: Full Functionaly
Vollautomatische Seitenschweißmaschine zur Verpackung von Produkten – unabhängig von ihrer Länge – mit Volleinschlag und ohne Folienüberlappung. Mit neuem Querstempel. Fully automatic side sealing machine for packaging products – regardless of their length – with full wrap and without film overlap. With new cross seal bar. Vollautomatische Seitenschweißmaschiene mit Einschweißtunnel - Fully-Automatic Side Sealer Kallfass Universa 400 - Mini 400 Year 2004 - Serial-No. M 05.04.226 Anlage bestehend aus / System consisting of: Handanlage / Hand fed Station MGZ 400 Seitenschweißmaschiene / Fully-Automatic Side Sealer Kallfass Universa 400 Einschweißtunnel / Shrink tunnel Kallfass Mini 400 Technische Daten / Technical Data: Länge Querstempel / Length of cross seal bar 450mm Verpackungsleistung [Takte/min] / Production speed max. up to 85 packs/min Produktlänge / P ...
Description Item # 9385 - SEMI-AUTOMATIC CHOCOLATE MOULDING LINE Manufactured by SELMI mould size 275 x 175, Speed around 4-6 moulds per minute including: SELMI Loader 275, year 2018 including scraper and mould vibration SELMI TOP temperer, year 2008, SELMI TUN cooling tunnel, year 2017, with upper deck dropping on to return belt for additional 2-pass cooling belt width 320mm tunnel 10m long: (1m infeed; 3 x 270cm covered sections; 1m outfeed) including refrigeration system
Litz LU 400Year of manuf. : 2016 Control : Heidenhain TNC 640 Speed : 12000 rpmMovement X/Y/Z : 400/350/350 mm____________Description:Spindle:Technology:DirectdriveSpeed:12.000 rpmPower (max.):13 kWTorque (max.):95 NmTaper:SK40NC-Swivelroundtable:B-Axis:-50°/+110°C-Axis:360°Clampin gsurface:ø450 mmTableloading (max.):200 kgIn general:Toolmagazine:48 StationsRapid travers in X/Y/Z:48 m/minEquipment/Accessory:Positionsensor:Direct Scales in X/Y/ZChipmanagement:Chip conveyorCoolingmanagement:Internal cooling unit with filter and High-pressure, 30 barWorkpiecemeasurement:Touch probe, Heidenhain TS740Toolmeasurement:Laser, Renishaw NC4 TXSetup operations:Electronic HandwheelFurther Equipment:SpindlechillerFurther Accessory:Misc. used Toolholder
Hydraulic reservoir, hydraulic tank, aluminum reservoir for hydraulic pump, hydraulic unit -Hydraulic tank: Hydraulic tank for hydraulic unit -Hydraulic tank: with level and temperature indicator -Motor mount: Ø 120 mm / bolt circle Ø 145 mm M6 -Individual components: see photos -Dimensions: 490/400/H515 mm -Weight: 25 kg.
The machine is equipped with a tailstock, a 12-station tool turret as well as a collet chuck, incl. chip conveyor
Additional technical specifications: • Support surfaces right and left: 4000 mm each • operating voltage. 3 x 400 V
CONTROLS CNC controls WORKING RANGE -CUBIC- X-axis travel: 650 mm Y-axis travel: 450 mm Z-axis travel: 130 mm TABLE table surface (left-right): 770 mm table surface (front-back): 630 mm workpiece load (max): 500 kg ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS total weight approx.: 4550 kg -work area protection -exhaust system with electrostatic air filter -fire protection system (to be assessed by a qualified body) -automatic paper tape filtration unit 1x grinding motor 22 S, speed 4500 - 22500 [rpm], for EX23 collets - part number: 181561 1x 45 S grinding motor, speed 9000 - 4500 [rpm], for EX19 collets - reference: 144017 1x 80 S grinding motor, speed 40000 - 80000 [rpm], for F6 collets - reference: 144021 1x grinding motor for slot grinding (motor + belt are included) - reference: 144022 3x grindin ...
cutting diameter: 400 mm capacity 90 degrees: flat: 500 x 400 mm saw band length: 6220 x 41 x 1.3 mm speed: 15.0 - 150 m/min work height max.: 750 mm workpiece weight: ca. 250 - 300 kg/m Control: MEBA NC coolant tank capacity: 80.0 ltr. oil volume: 30.0 ltr. power capacity: 5.5 kW weight of the machine ca.: ca. 2250 kg range L-W-H: 3100 x 1620 x 2150 mm Current list price: approx. 50.000 euros Special price available upon request Features: - MEBA - Fully automatic two-column linear guide system Fully automatic machine for 90° cuts only - User-friendly NC dialog control With plain-text display 5.7-inch CE panel Program memory with 50 programs, each with 20 steps - Automatic material feed Minimum cutting diameter .. Ø 5.0 mm Residual piece length without bundle clamping .. manual 25.0 mm Residual piece length without bundle clamping .. automatic 110 mm Automatic movement of the ...
vertical machining center, year 1999, CNC MITSUBISHI MSC-802M. Used machine. More info & price on IndustrialBuyer.
Feltracon Industrial melon peeling machine The Feltracon is an industrial melon peeling machine designed for efficient peeling of whole melons in fruit processing facilities. The machine removes the rind from melons quickly and consistently preparing the fruit for further processing such as cutting portioning or packaging The system is built for hygienic operation in food production environments and is suitable for continuous industrial use
CONTROLS CNC controls FANUC 310 IS WORKING RANGE -CUBIC- number of processing axes (excl parallel axes): 5 X-axis travel: 600 mm Y-axis travel: 410 mm Z-axis travel: 460 mm rotating range A-axis from: -30 ° rotating range A-axis up to: 120 ° TABLE clamping surface diameter: 350 mm SPINDLE / HEAD spindle revolutions (max): 12000 /min drive power: 18 kW AXIS DRIVES rapid traverse: 4800 mm/min TOOL MAGAZINE number of positions: 30 DIMENSIONS / WEIGHTS space requirements -left/right-: 3000 mm space requirements -front/back-: 2400 mm total height: 1980 mm total weight approx.: 7500 kg Operating hours: 35`000h Inklusieve: Vices see picture
Product: Sylysia 350, Gasil 23 D, Precarb 800, Calcilit, Benzophenone (partially lumpy), Lo-Vel 8100, Syloid 7000, bulk density: 0.08-0.73kg/l, particle size: powder, product temperature: 5-30°C, moisture: dry, consistency: free-flowing, non-sticky and non-agglomerated, system capacity: according to customer-provided container handling, operating mode: 3-shift operation, installation location: indoors/heated, ambient temperature: 5-30°C, power supply: 400V, 3Ph,N, 50Hz, control voltage: 24VDC, compressed air supply: 4-6bar, oil-free, max. surface temperature: 200°C, with documentation. An on-site inspection is possible, not connected to power.
cutting diameter: 315 mm capacity 90 degrees: flat: 400 x 250 mm capacity 90 degrees: square: 270 x 270 mm capacity 45 degrees: flat: RE 300 x 280 mm capacity 45 degrees: round: RE 280 mm capacity 45 degrees: square: RE 280 x 280 mm capacity 45 degrees: flat: LI 280 x 200 mm capacity 45 degrees: round: LI 250 mm capacity 45 degrees: square: LI 220 x 220 mm capacity 60 degrees: round: 180 mm capacity 60 degrees: square: 140 x 140 mm turning speed range:: 35 + 70 m/min saw band length: 3460 x 34 x 1.1 mm work height max.: 870 mm voltage: 400 V engine output: ca. 3.0 kW weight of the machine ca.: 550 kg range L-W-H: 2150 x 1400 x 1420 mm The MBS 400 DG model is a precision horizontal band saw designed for universal use. Key features of this machine include a swiveling saw frame for double miter cuts from -45° to 60°, as well as a hydraulic cylinder for precise lowering via a control valve ...
cutting diameter: 410 mm capacity 90 degrees: flat: 540 x 300 mm capacity 90 degrees: square: 300 x 300 mm capacity 45 degrees: flat: RE 400 x 210 mm capacity 45 degrees: round: RE 400 mm capacity 45 degrees: square: RE 260 x 260 mm capacity 45 degrees: flat: LI 380 x 170 mm capacity 45 degrees: round: LI 340 mm capacity 45 degrees: square: LI 260 x 260 mm capacity 60 degrees: round: 260 mm capacity 60 degrees: square: 175 x 175 mm turning speed range:: 45 + 90 m/min saw band length: 4290 x 34 x 1.1 mm work height max.: 866 mm voltage: 400 V engine output: ca. 3.0 kW weight of the machine ca.: 606 kg range L-W-H: 2340 x 1430 x 1460 mm The MBS 600 DG is a precision horizontal band saw designed for universal use. Key features of this machine include a swiveling saw frame for double miter cuts from -45° to 60°, as well as a hydraulic cylinder for precise lowering via a control valve. Feat ...
cutting diameter: 410 mm capacity 90 degrees: flat: 540 x 300 mm capacity 90 degrees: square: 300 x 300 mm capacity 45 degrees: flat: RE 400 x 210 mm capacity 45 degrees: round: RE 400 mm capacity 45 degrees: square: RE 260 x 260 mm capacity 45 degrees: flat: LI 380 x 170 mm capacity 45 degrees: round: LI 340 mm capacity 45 degrees: square: LI 260 x 260 mm capacity 60 degrees: round: 260 mm capacity 60 degrees: square: 175 x 175 mm turning speed range:: 20 - 80 m/min saw band length: 4290 x 34 x 1.1 mm work height max.: 865 mm voltage: 400 V engine output: ca. 3.0 kW weight of the machine ca.: 686 kg range L-W-H: 2340 x 1430 x 1550 mm The MBS 600 DGA-V model is a semi-automatic double-miter band saw for miter cuts up to 60°. The infinitely variable cutting speed and the hydraulic vise make for comfortable operation. Thanks to its solid construction, this model guarantees precise cuts wh ...
Technical data: Welding punch: 450mm permanently heated Punch passage height: max. 150mm Punch Transition: Length Compensation Longitudinal welding: permanently heated welding wedge Foil: Half tube approx. 12-80μm max diameter 400mm Max. film roll width: max. 600mm Conveyor belt: inlet and outlet 400mm wide Product output: up to 85 cycles/min Transport speed: 10-30m/min Working height adjustable: 780-930mm Overall length: 1950mm Overall width: 1650mm Overall height: 1850mm Control Panel: Sytron Colour: Kallfass anthracite Rated Power/ Rated Current: 3.5KVA / 5.1A Power connection: 400Volt DS/ 50Hz with protective conductor
Labeler Manufacturer: HERMA Type H 400 8 L Serial No. 20923342 Left-hand device with detaching edge with spring-loaded roller angled 75° (see drawing) Running direction from left to right
X=3700mm Y=1440mm, Z=150mm Moving speed: X: 80 m/min, Y: 80 m/min, Z: 20 m/min 8 supports with vacuum cups, pneumatic clamping 8 fences at the rear 8 fences in front 2 left fences and 2 right fences 6 rails for panel loading with pneumatic lifting Positioning the vacuum cups using a laser 1 connection for templates Vacuum pump with flow rate 100 m3/h Configuration V25,H8X/6Y, N1 X-Y 90?, F1-HSK63-15KW,F1-HSK63-9KW, C axis, W14 rear Main motor 15 kW, 1250-24000 rpm, air-cooled, 360? C-axis, C-axis interpolation axis, HSK 63 mounting C axis extension for flex-5 aggregate Main motor 9 kW, 1250-24000 rpm, air cooled, HSK 63 mounting Tool changer operating in X direction with 14 positions, rear mounted 2 x 4 vertical X drilling pins, 2 x 3 vertical Y drilling pins 14 horizontal drilling spindles 90? groove saw X-Y direction PC 85 power control software with: Woodwop: workshop-oriented program ...
turning diameter:640 / 400 mm turning length:1500 mm control:Siemens 840 D Powerline Travel turret No.1 (milling spindle) x/y/z:550 / 180 (±90) / 1585 mm Swivle angle milling spindle (B-axis):±120° interpol. ° Rapid traverse feeds turret 1 (milling head) x/y/z:40/24/60 m/min RPM milling spindle:12000 1/min power capacity - milling spindle:12 / 23 kW Torque of milling spindle:100 Nm Tool magazine for milling spindle (turret 1):120 HSK-A 63 Tool change time tool/tool, milling spindle:1,6 s Spindle 1 RPM:4000 1/min Spindle 1 power:36/ 45 kW Spindle 1 Torque:730 Nm Spindle 1 max. bar diameter:90 Spindle 2 RPM:4000 1/min Spindle 2 power:36 / 45 kW Spindle 2 torque:730 Nm Spindle 2 max. bar diameter:90 c-axis:0,001 ° Travel turret 2 x:225 mm Travel Turret 2 z:1595 mm RPM of rotary tools turret 2:4000 1/min no. of tools in turret 2:12 VDI 40 high-pressure pump:20 bar total power requiremen ...
x-travel:600 mm y-travel:580 mm z-travel:530 mm distance spindle center to column:630 mm distance spindle center to table:100-600 mm milling feed range:1-10.000 mm/min max. table load:200/100 kg max. tool weight:8 kg positioning accuracy:+/- 0,01 mm :8000/15000 1/min spindle drive:7,5/11,5 /5,5 kW repeating accuracy:+/- 0,008 mm weight of the machine ca.:7,4 / 7,65 t Brand-new CNC vertical machining center with CNC control FANUC or HEIDENHAIN Warranty: 12 months More information can be found in the Appendix.
pressure:250 t table length:4000 mm table width:3000 mm Controls:SIEMENS SIMATIC C7 PRESS DESIGN:. - frame design : 4 column :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):250 to PRESS TABLE:. - clamping surface (left-right):4000 mm - clamping surface (front-back):3000 mm - tool weight max.:100000 kg - number of T-slots:12 - distance between T-slots:375 mm - height above floor level:390 mm RAM:. - clamping surface (left-right):4000 mm - clamping surface (front-back):3000 mm - number of T-slots:12 - distance between T-slots:375 mm - stroke:2900 mm - tool weight max.:50000 kg RAM (HYDR. PRESS):. - number of main-cylinders:1 - approximation velocity max.:180 mm/s - working velocity max.:50 mm/s - restoring force of ram:95 to TOOL ASSEMBLY DIMENSIONS:. - distance table - ram max.:2750 mm - distance between columns (H-frame):4100 mm - Free passage be ...
rotor dia:30-500 mm hobbing length:500-1000 mm total power requirement:80 kW weight of the machine ca.:15 t dimensions of the machine ca.:3,6 x 2,5 x 3,0 m max. module:8 Max. module Et milling = 12 Max. module hobbing = 12 Max. axial travel = 110 to 1100mm Max. cutter speed = 300rpm Max. cutter displacement tangential = -350 to -55mm Max. table speed = 100rpm Table drive: torque motor Filter system: chip conveyor is for magnetic materials, belt filter is for all suspended matter that floats in the oil Including milling mandrel
swing diameter:400 mm turning height:950-1500 mm Turning length:210 mm x-travel:310 mm z-travel:350 mm spindle drive:48 kW spindle turning speed range:20-3500 U/min weight of the machine ca.:11 t dimensions of the machine ca.:4,5 x 3,5 x 2,7 m
swing diameter:400 mm turning height:950-1500 mm Turning length:210 mm x-travel:310 mm z-travel:350 mm spindle drive:48 kW spindle turning speed range:20-3500 U/min weight of the machine ca.:11 t dimensions of the machine ca.:4,5 x 3,5 x 2,7 m
x-travel:500 mm y-travel:400 mm z-travel:330 mm table-size:710 x 410 mm spindle taper ISO:40 quill stroke:100 mm control:HEIDENHAIN TNC 335 B table load:180 kg no. of flutes:8 groove width:14/25 mm tool taper:SK 40 speeds::20 - 3000 U/min feeds:infinitely variable1-1250 mm/min rapid traverse:5000 mm/min total power requirement:13 kW weight of the machine ca.:2500 kg dimensions of the machine ca.:2000 x 2800 x 2300 mm Year:ca. 1984 Zusatzinformationen ? Schile-Elektroschrank mit CNC-Steuerung Heidenhain TNC 355 ? Starrer Winkeltisch 710 x 400mm ? Spritzschutzverkleidung / Halbkabine ? Kopf nach Skala präzise drehbar über Kurbel ? Kopf komplett wegschwenkbar für horizontal Spindel
x-travel:1190 mm total power requirement:25 kW feeds::3 - 2000 mm/min weight of the machine ca.:4,3 t table-size:1600 x 400, 5 Spannbacken mm dimensions of the machine ca.:4000 x 3600 x 2200 mm speeds:45 - 1800 U/min y-travel:530 mm z-travel:540 mm tool taper:ISO 50 control cabinet:940 kg
x-travel:500 mm y-travel:400 mm z-travel:330 mm table-size:400 x 710 mm spindle taper ISO:40 quill stroke:100 mm control:HEIDENHAIN TNC 335 table load:180 kg no. of flutes:8 groove width:14/45 mm tool taper:ISA 40 speeds::20 - 3000 /28- 4000 U/min feeds:infinitely variable1-1250 mm/min rapid traverse:5000 mm/min total power requirement:13 kW weight of the machine ca.:2500 kg dimensions of the machine ca.:2000 x 2800 x 2300 mm Documents:inkl. Zusatzinformationen ? Schile-Elektroschrank mit CNC-Steuerung Heidenhain TNC 355 ? Starrer Winkeltisch 710 x 400mm ? Spritzschutzverkleidung / Halbkabine ? Kopf nach Skala präzise drehbar über Kurbel ? Kopf komplett wegschwenkbar für horizontal Spindel
x-travel:500 mm y-travel:250 mm z-travel:325 mm table-size:400 x 200 mm T-slots:10/ 20 mm T-slots:4 St workpiece height max.:300 mm template table:380 x 380 mm speeds::2500 - 20000 U/min no. of turning speeds:3 total power requirement:0,25 kW weight of the machine ca.:430 kg dimensions of the machine ca.:1000 x 1200 x 1500 mm
saw blade diameter:400 mm cutting diameter:400 mm material:Vollmaterial 20 - 130 mm material:Walzprofile 40 - 120 mm material diameter from - to::Rohr u. Profilfrohr bis 100 x 14 mm sawblade width:4 mm total power requirement:5,1 kW weight of the machine ca.:1850 kg dimensions of the machine ca.:3300 x 1630 x 1960 mm Documents:vorhanden
x-travel:600 mm y-travel:580 mm z-travel:580 mm numbers of pallets:2 pallet size::400 x 400 mm max. workpiece weight:400 kg spindle taper ISO:40 spindle speeds::35 - 12000 feed speeds:1 - 50000 mm/min rapid speed:50 m/min total power requirement:25 kW weight of the machine ca.:12 t dimensions of the machine ca.:3,6 x 3,6 x 2,9 m with CNC SEICOS 16 M ( FANUC base ) autom. toolchanger 61-pockets pallet indexing 1° chip conveyor and coolant attachment exhauster clamping cube and diverse toolholders
turning diameter:480 mm turning length:800 mm total power requirement:30 kW turning diameter over bed slide:240 spindle bore:65 mm disc turret:12 fach rapid travel range:20 / 10 m/min weight of the machine ca.:4,5 t dimensions of the machine ca.:4 x 2,2 x 2,1 m with CNC TRAUB TX 8 H C-axis driven tooling, 6 positions 3,5 kW / 4000 rpm power chuck coolant attachment, chip conveyor diverse toolholders
pressure:400 t distance between columns:3250 mm distance table/ram, max. stroke up, adjustment up:1000 mm stroke:800 mm table surface area:3250 x 1400 mm table height over floor:1250 mm die cushion capacity:170 t die cushion stroke:200 mm die cushion area:1800 x 1000 mm distance between cutting impact cushioning:2610 mm side window:800 mm ram surface:3250 x 1400 mm return capacity:51 t speed down:300 mm/s speed up:300 mm/s working speed:16 - 33 mm/s quantity of oil:2900 l power requirement:100,0 kW weight:70,0 t Dimensions (WxDxH):4,9 x 3,1 x 7,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 cutting impact absorption:hydraulic
pressure:400 t distance between columns:1250 mm stroke:250 fix mm no. of strokes:45 /min distance table/ram, max. stroke up, adjustment up:825 mm table surface area:1000 x 900 mm column travel -side:400 x 700 mm ram surface:1000 x 900 mm ram adjustment:100 mm capacity of ejector in table:40 t ejector stroke:160 mm power capacity:270,0 kW weight:44,0 t Dimensions (WxDxH):2,4 x 3,6 x 7,2 m height over floor:6,4 m
material width:400 mm coil weight:3,0 t material thickness:0,5 - 4,0 mm coil internal diameter:460 - 530 mm coil external diameter:1500 mm no. of straightening rolls:9 straightening roll diameter:50 mm no. of lower support rolls:12 no. of upper support rolls:10 diameter of support rolls:90 mm material cross-cut:1600 mm² speed of coil line:0 - 20 m/min power requirement:35,0 kW weight:10,5 t dimensions (WxDxH):10,0 x 2,5 x 2,9 m straightening machine:KRE 50.400/9 adjustment of straightening rolls :motoric insertion wedge:hydraulic adjustable decoiler:3000.1 snubber roll:hydraulic expansion:hydraulic sideway adjustment:motoric pivoting:manual roll feed:Servo; WVE 160/400 intermittant lifting:hydraulic
Pressure:063 t throat:400 mm stroke:16 - 90 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:350 mm table surface area:1000 x 750 mm hole in the table:260 x 140 mm table height over floor:710 mm ram surface:600 x 220 mm ram adjustment:50 mm weight:4,3 t dimensions (WxDxH):1,1 x 2,6 x 2,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatisch overload protection in ram:mechanisch ram counterbalance:pneumatisch
pressure:400 t throat:520 mm stroke:20 - 200 mm no. of strokes:30 /min distance table/ram, max. stroke up, adjustment up:680 mm table surface area:1600 x 1000 mm table height over floor:715 mm passage to the back:1000 mm ram surface:1300 x 800 mm ram adjustment:130 mm power requirement:38,0 kW weight:41,0 t dimensions (WxDxH):2,1 x 2,6 x 4,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic, Ortlinghaus overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic
pressure:400 t stroke:280 mm no. of strokes:56 Hub/min distance table/ram, max. stroke up, adjustment up:680 mm table surface area:560 x 750 mm allowed max. force:600 t blow die to die:800 t spindle diameter:200 mm ram surface:560 x 560 mm height over floor:4,1 m power requirement:37,0 kW weight:12,0 t dimensions (WxDxH):2,2 x 2,0 x 4,25 m
pressure:400 t distance between columns:1100 mm stroke:250 mm no. of strokes:25 - 75 /min distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1100 x 965 mm capacity of ejector in table:30 t ejector stroke of ejector in table:80 mm capacity of ejector in ram:3 t stroke of ejector in ram:60 / 70 mm ram surface:980 x 800 mm column travel -side:800 mm ram adjustment:20 mm power capacity:80,0 + 5,5 kW weight:47,0 t Dimensions (WxDxH):3,5 x 3,3 x 6,0 m weight of switch cabinet:1,4 t dimensions of electrical cabinet (WxDxH):4,9 x 0,5 x 2,6 m ejector in ram:hydraulic
pressure:160 t throat:400 mm stroke:30 - 200 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:600 mm table surface area:1000 x 770 mm table height over floor:810 mm hole in the table:360 mm Passage to the back:450 mm ram surface:710 x 450 mm ram adjustment:110 mm power requirement:15,0 kW weight:10,5 t Dimensions (WxDxH):1,7 x 2,0 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:hydraulic overload protection in ram:mechanical ram counterbalance:pneumatic
maximum number of results exceeded
please refine your search
