MAGNUS Q 800 PLATESETTER -Serial Number: M80100 ( September 2006 – Only one owner) -Model: Kodak Magnus 800 (Quantum SquareSpot) -Machine Configuration: SCU Autoloader max capacity 100 plates with tray and automatic paper removal and bridge connection -Imaging Head: KODAK SquareSpot / Quantum THERMAL imaging head / GMCE -Laser head model TH 2 -Plate Format: Supports B1 formats / minimum size 318 x 305 mm - maximum size 950 x 1163 mm -Plate Handling / Automation: Single-cassette unit (autoloader) ; refillable during use, automatic cassette selection per job. Typical cassette capacity: up to ~100–110 plates (variable by thickness). -Approx 120.000 plates done -Resolution and screening: Supports common resolutions of 2400 dpi; compatible with Kodak advanced screening -Integrated punching system -Software/workflow integration: RIP Kodak Printconsole, Kodak Workflow serv ...
Technical specifications: Data format: TIFF or LEN Maximum supported plate size: 1200 × 900 × 1.14 mm Imaging resolution: 2000–4000 ppi Optics: R Optics Maximum screen ruling: 200 lpi Tonal range: 1–99% Optics configuration: Optics 15 Productivity: 1.5 m²/h Dimensions & Weight: Width: 2090 mm Depth: 1168 mm Height: 1223 mm Weight: approx.1500 kg Electrical Data: Power supply: 1/N/PE, 220–240 V AC Frequency: 50/60 Hz Power consumption: 2.6 kW Building fuse: 16 A Residual current protection: >30 mA Grounding required Included Equipment: • Exhaust system • Vacuum pump • Compressor • Monitor • Keyboard • Mouse • Built-in software
- Single Autoloader - 204.000 plate exposures - APOGEE Prepress - Prinect Shooter - PlateStacker
Heidelberg Suprasetter A75 ATL Gen III 4 up Age: 2010 Productivity: 17/22 plates per hour Max. format: 676 x 760 mm Min. format: 240 x 240 mm Total Exposure: 171.873 pieces Total punches: 171.718 pieces 64 Diodes Resolution: 2540 dpi For Thermal Plates Meta Dimension 2017 Autoloader Punching Device Stacker Advand PST 26 With Dongle
ICTP 2000, built 2010, with navigator RIP for windows 2000/2003/ XP, Dell Optiplex 760 hardware, CD manuals, cleaning kit, dongle and repro materials such as ifinisher, liguid dot reserve drying lamps, etc. In very nice kept condition. Available immediately. Can ship worldwide.
Screen PlateRite 4300E, Year 2008 only approx. 20K plates done RIP York Workflow Inlinepunch 425 Azura C95 Clean out unit Available: at short term
Screen 4300 E year 2006 16 diodes Plate Winding Cycles 136.843 exposure time 7,835 h PC with RIP Harlequin good condition
Min. plate format: 240 x 240 mm Max. plate format: 676 x 760 mm - SCL - MCL - Inline punching - Stacker PST 26C - incl. RIP
CTP thermal plates 58000 plates hand feeding plate stacker Server Workstation TIFF shooter
AGFA Acento E (Screen 4100 E) year 2006 16 diodes plate winding cycles 66.600 exposure time 5,800 h PC with ApogeeX good condition
Agfa Avalon N4-30 PT-R4600E, Year 2018 only approx.16K plates done Apogee Workflow RIP Inline punch Stacker ST 95EX Azura C95 Clean out unit Etc. Available: at short term
Presstek Dimension Exel with external Affinity chilling unit, AMS -air management system, Dell Dimension computer, serial tools, connecting cables and some repro materials. Very clean and maintained. Available immediately.
CTP Computer-to-Plate Imagesetter For Thermal Plates 830nm, 2xLaser Heads, Solution: 2400, 2540 dpi, Format: Max. 790x1030mm, Min. 370x323mm, Plate Thickness: 0.15-0.35mm, Speed: 23 Plates/Hour
Max. plate size: 676 x 530 mm Plate thickness: 0,15 - 0,3 mm - Hand feed - Bridge - Developer unit - Workstation
Automatic plate loader Plate processor Automatic delivery. Stacker Program and Dongle Monthly contract serviced
All Rip and Software Included, 2400 dpi, Formats: Min. 324x660mm, Max. 370x830mm, PST 26 Compact Stacking Delivery, 16 Diods Laserhead, Infrarot 830nm thermal, chemical free thermal CTP with Autofeeding
Max. plate size: 676 x 530 mm Plate thickness: 0,15 - 0,3 mm - Hand feed - Bridge - Developer unit - advant PST 26 compact Stacker - incl. Shooter - incl. RIP
- MCU Magnus 400 II Platesetter (3 cassettes) - ca. 62.000 plate exposures - suitable for GTO / SM 52 / SM 74 plates - for processless plates - Inline punch Bacher 425 mm - Plate Stacker ADVANT PST 26 - Shooter - without RIP
Machine complete with PC, RIP, etc.
