cnc step used for sale

Specifications: Manufacturer: 3M ESPE Type: Lava CNC 500 Control: Beckhoff Year of Make: 2008 Compressed air: 6.5 bar Rated power: 1 kW Rated mains frequency: 50/60 Hz Weight Weight: 620 kg Condition Condition: Used Functional: Tested and fully functional

Specifications: Manufacturer: 3M ESPE Type: Lava CNC 500 Control: Beckhoff Year of Make: 2008 Compressed air: 6.5 bar Rated power: 1 kW Rated mains frequency: 50/60 Hz Weight Weight: 620 kg Condition Condition: Used Functional: Tested and fully functional

OFFER - KRÜSIMATIC from Krüsi G1 4 axis system 1 used carpentry machine from KRUeSI type Kruesimatic G1 Year of manufacture 2005 Can be operated with all carpentry programs such as Catwork, SEMA, Lockrichs, S & S, Nut Reiner, etc. 4 axis system with dovetail cutter Task / Editing from right to left 6 Side processing without having to turn the wood! Total length approx. 18 m Weight 5.5 t BTL controlled for interface to the office or of course manual input on the machine. To increase the cutting performance, the feed rate is frequency-controlled and can be optimized for many cross-cut cuts Platform height without floor shaft 920 mm Sections fall into mobile box incl. chips The system only needs to be connected to the electrical cabinet with plugs Max. wood cross-section - 200mm x 320 mm Plant set up and ready for demonstration Available IMMEDIATELY The entire system ha ...

Siemens Sinumerik 840D control, incl.: abrasive processing, hydraulic unit and portable loading system for loading and unloading the machine, Technical specifications:, Tip distance: 600mm, tip height: 180mm, maximum grinding diameter: 355mm, maximum workpiece weight: 150kg, maximum Z-axis speed: 11 m/min, minimum Z-axis speed: 0.01 m/min, maximum X-axis speed: 7.5 m/min, minimum X-axis speed: 0.01 m/min, External/internal grinding spindle:, Grinding wheel standard (Øa x b x Øi): 600 x 80 x 304.8 mm, Grinding wheel circumferential speed: 5 - 50 m/s, Power consumption of grinding spindle motor: 11 kW, Workpiece spindle:, Taper bore workpiece headstock: MK 5, Power consumption: 2.7 kW, Tailstock:, Taper hole center point: MK 4, Coolant reservoir: 2000 liters, lubricating oil: 30 liters, hydraulic oil: 60 liters, Operating voltage: 400 volts, 3 phases, Mains frequency: 50 Hz, Total weight ...

CONTROLS   CNC controls HEIDENHAIN TNC 426 WORKING RANGE -CUBIC-   number of processing axes (excl parallel axes): 3   X-axis travel: 500 mm   Y-axis travel: 350 mm   Z-axis travel: 610 mm TABLE   table surface (left-right): 920 mm   table surface (front-back): 380 mm SPINDLE / HEAD   spindle revolutions (min): 50 /min   spindle revolutions (max): 18000 /min   tool fixture: ISO SK 30 TOOL MAGAZINE   number of positions: 24 ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 2000 mm   space requirements -front/back-: 1700 mm   total height: 3000 mm   total weight approx.: 3200 kg ATTACHMENTS   chip conveyor: no   coolant unit: yes   through spindle coolant attachment: no   closed cabin: yes   European CE standards: yes Machine in TOP condition - Power ON :    a ...

CONTROLS   CNC controls SIEMENS 840 C WORKING RANGE (DOUBLE DISC GRINDER)   Grinding wheel diameter: 457 mm   grinding width max. - throughfeed grinding: 80 mm   material thickness max. - throughfeed grindin: 20 mm   grinding width max. - plunge cut grinding: 205 mm   material thickness - plunge cut grinding: 80 mm GRINDING SPINDLE 1   drive power: 23 kW GRINDING SPINDLE 2   drive power: 23 kW COMPONENT-FEEDER   Feeder Design: rotary Feeder   feeder velocity max.: 240 mm/min   feeder velocity min.: 20 mm/min Scope of delivery: - Machine - emulsion tank new in 2012 Measuring control IONIC 17A

spindle turning speed range: 170 - 18000 U/min weight of the machine ca.: 7,5 t dimensions of the machine ca.: 5,00 x 4,00 x 2,20 m --> Control conversion (2014) to Siemens Sinumerik 840D Solutionline --> Technical data Grinding diameter: 20 - 300 mm --> Oscillation diameter: 350 (500) mm --> Workpiece length: 300 (1300) mm --> Recommended grinding depth up to: 300 mm --> Grinding table stroke Z-axis (total): 650 (950) mm --> Resolution: 0.001 mm --> Rapid traverse: 12 m/min-1 --> Grinding stroke speed: 0 - 9.99 m/min-1 --> Feed rate: 0 - 99.99 m/min-1 --> Step feed value during reversal: 0 - 0.999 mm --> Grinding table stroke X-axis (total): 150 mm --> Resolution: 0.001 mm / Ø --> Rapid traverse: 5 m/min-1/R --> Grinding stroke speed: 0 - 5 m/min-1/R --> Feed rate: 0 - 99.99 m/min-1/R --> Step feed value during reversal: 0 - 0.999 mm / Ø --> Swivel capability of the workpiece headsto ...

Key data: 4020 mm, 1 mm

with material thickness adjustment, hydraulics on the left side of the machine, without roller shears, bending beam with removable attachment rail approx. 8mm, 3 stop fingers, control on the swivel arm, Machine is repaired, checked, cleaned by a professional and is then fully functional. Test run is carried out. Working length: 4020 mm Sheet thickness max. steel: 1.5 mm Sheet thickness max. aluminium: 2.5 mm Sheet thickness max. VA: 0.8 mm Back gauge (max.): 1000 mm Projection: 1000 mm Colour: blue Total power requirement: 16 A Approx. space required: 6000 x 2000 x 1900 mm Weight approx.: 5000 kg Upper beam stroke (opening width): 200 mm without roller scissors Number of stands: 5 pieces Bending angle (max.): 145 degrees Machine Number: 0040-01

x-travel: 6000 mm y-travel: 630 mm z-travel: NC-Schwenkkopf mm Control: total power requirement: -- kW weight of the machine ca.: 19,5 t required space: -- m Condition: Used Specification: Vertical CNC machining center Chiron MILL 6000 high speed with NC swivel head Year of manufacture 2004, completely overhauled in 2013 by the manufacturer Chiron - Siemens 840D (PCU50, NCU572.4) - NC swivel head - Long part machining up to max.: 6,000 mm - Machining of the front side, horizontal with swivel head right/left - Pendulum machining via center partition wall max.: 1,773 mm - 4 hydraulic double vices - High-speed package: - Motor spindle D 12,000 rpm, 140 Nm - Travel distance X: 6,000 mm / Y: 630 mm - Rapid traverse in X/Y/Z: 60 m/min - Production package: - Crown belt conveyor, ejection height 1,050 mm - IKZ preparation - KNOLL VRF250 vacuum rotary filt ...

Distance between points: 1000 mm, Height of points: 180 mm, Max. diameter to be rectified: 355 mm, Max. piece weight between points: 300 Kg, Max. weight with plate: 125 Kg, Transverse travel of the carriage (X axis): 350 mm, X-axis speed: 0.01 / 6.000 mm/min, X-axis Resolution: 0.0001 mm, X-axis measurement system: Digital ruler, Longitudinal travel of the carriage (Z axis): 1.300 mm, Z-axis speed: 0.01 / 15,000 mm/min, Z-axis resolution: 0.0001 mm, Z-axis measurement system: Digital ruler, Working wheel dimensions (od x id x width): Ø500 x Ø203 x 80 mm, Main engine power: 7,5 Kw, Angle of rotation of the grinding head: -30º / +210º, Workhead rotation speed: 10 / 800 rpm, Workpiece holder head cone: MORSE 5, tailstock cone: MORSE 4, Ø of the tailstock shank: 60 mm, Course of the counterpoint reed: 40 mm, Control type (CNC/manual): CNC, CNC brand: FAGOR, CNC model: 8040-T, Dimensions ...

spindle diameter: 200 mm x-travel: 16200 mm y-travel: 5250 mm z-axis: 1600 mm w-axis: 1990 mm spindle turning speed range: 0,9 - 930 U/min feeds: 6000 mm/min rapid traverse: 6000 mm/min dimension of the ram: 520 x 520 mm main drive motor: 77 kW Control: Heidenhain TNC 530 tool taper: ISO 60 total power requirement: 180 kVA weight of the machine ca.: - t dimensions of the machine ca.: 20 x 12 x 8 m 2008 modernised with new electrics, motors and controls equipped with: - Control Heidenhain TNC 530 - Rotary Table SEA60 3500 x 4000mm, 60t - coolant system - chip conveyor - angular milling head - without floor plates The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 1000 mm gear width: 630 mm max. module: 16 min. module: 1 wheel diameter with counterstay: 800 mm max. number of teeth: 999 clamping length: 1060 mm workpiece weight: 1500 kg max.helical angle: 45 ° grinding spindle drive: ca. 20 kW Control: Opal / Siemens total power requirement: 70 kW weight of the machine ca.: 17,5 t - CNC control Opal / Indramat with Siemens S5 PLC - paperbandfilter - oil mist exhauster - complete covering The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3100 mm plate thickness: 6,0 mm thickness at Niro-steel: 4,0 mm distance between columns: 3100 mm down holder: 14 Stück oil volume: 150 ltr. cutting angle: 1,2 ° no. of strokes: 18 Hub/min control: CYBELEC CybTouch total power requirement: 11,0 kW weight: 6300 kg range L-W-H: 4.000 x 2.100 x 1.640 mm -------------------------------------------------- electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. Can be fol ...

cutting diameter: 305 mm capacity 90 degrees: flat: 350 x 200 mm capacity 90 degrees: square: 260 mm capacity 45 degrees: flat: 230 x 200 mm capacity 45 degrees: round: 250 mm capacity 45 degrees: square: 230 mm capacity 60 degrees: flat: 170 x 100 mm capacity 60 degrees: square: 155 mm capacity 60 degrees: round: 175 mm turning speed range:: 18 – 110 m/min dimensions of saw-band: 3.375 x 27 x 0,90 mm work height max.: 880 mm Control: total power requirement: 1,5 / 1,8 kW weight of the machine ca.: 840 kg dimensions of the machine ca.: 1.900 x 1.850 x 2000 mm Furnishing : - miter left 45 ° automatic operation - miter left 60 ° semi-automatic operation (cuts without programming) - Material height sensor (automatic cut start detection) - Frame and gear from a single source - very quiet cut and very low vibration - Chip tray can be removed (disinfection) - Shockproof and ergonomic cont ...

sheet width: 3100 mm plate thickness: 6,0 mm distance between columns: 3.100 mm down holder: 14 Stück no. of strokes: 16 - 24 Hub/min oil volume: 150 ltr. cutting angle: 0,5 - 1,5 ° thickness at Niro-steel: 4,0 mm column arm: 350 mm engine output: 11,0 kW weight of the machine ca.: 7.060 kg range L-W-H: 4100 x 2200 x 2190 mm -------------------------------------------------- electr. / hydraulic CNC guillotine shears - guided by a backdrop with CYBELEC CNC touch screen control with electr. / hydr. Cutting gap and cutting angle adjustment -------------------------------------------------- Furnishing: - CNC guiding guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, including s ...

sheet width: 3100 mm plate thickness: 13,0 mm thickness at Niro-steel: 8,0 mm down holder: 14 Stück no. of strokes: 11 - 20 Hub/min oil volume: 310 ltr. cutting angle: 0,05 - 2,0 ° throat: 350 mm table height: 900 mm total power requirement: 22,0 kW weight of the machine ca.: 13.300 kg range L-W-H: 5.110 x 2.570 x 2.400 mm -------------------------------------------------- heavy electr. / hydraulic CNC guillotine shears - guided by a backdrop with CYBELEC CNC touch screen control with electr. / hydr. Cutting gap and cutting angle adjustment -------------------------------------------------- Furnishing: - CNC guillotine guiding shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, includi ...

sheet width: 3100 mm plate thickness: 10,0 mm thickness at Niro-steel: 6,0 mm down holder: 14 Stück no. of strokes: 13 Hub/min oil volume: 260 ltr. cutting angle: 2,0 ° throat: 350 mm engine output: 22,0 kW back stop - adjustable: 1.000 mm weight: 10.575 kg. range L-W-H: 4,05 x 2,5 x 2,17 m -------------------------------------------------- heavy electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment -------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. Can be folded up at max.trav ...

sheet width: 3100 mm plate thickness: 6,0 mm thickness at Niro-steel: 4,0 mm down holder: 14 Stück no. of strokes: 20 Hub/min cutting angle: 1,2 ° control: CYBELEC CybTouch work height max.: 800 mm oil volume: 150 ltr. total power requirement: 11,0 kW weight: 5500 kg range L-W-H: 4.000 x 2.410 x 1.640 mm ------------------------------------------------- electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment ------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. Can be folded up at ma ...

sheet width: 4100 mm plate thickness: 6,0 mm thickness at Niro-steel: 4,0 mm down holder: 18 Stück no. of strokes: 15 Hub/min oil volume: 150 ltr. cutting angle: 1,2 ° control: CYBELEC Cybtouch back stop - adjustable: 1000 mm work height max.: 800 mm engine output: 11,0 kW weight: 8.100 kg. range L-W-H: 5000 x 2410 x 1650 mm ------------------------------------------------- electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment ------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws autom. C ...

sheet width: 2100 mm plate thickness: 6,0 mm ST 42 thickness at Niro-steel: 4,0 mm VA cutting angle: 1,2 Grad no. of strokes: 28 Hub/min oil volume: 150 ltr. down holder: 11 Stück control: CYBELEC CybTouch engine output: 11,0 kW back stop - adjustable: 1.000 mm table height: 800 mm weight: 4.500 kg range L-W-H: 3.010 x 2.100 x 1.640 mm ------------------------------------------------- electr. / hydraulic CNC swing cut shears with CYBELEC CNC touch screen control with electr. / hydr. Kerf adjustment ------------------------------------------------- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Quantity Cutting length limitation Material preselection, including sheet thickness Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) on ball screws ...

sheet width: 3100 mm plate thickness: 6,0 mm distance between columns: 3.100 mm down holder: 14 Stück no. of strokes: 16 - 24 Hub/min oil volume: 150 ltr. cutting angle: 0,5 - 1,5 ° thickness at Niro-steel: 4,0 mm column arm: 350 mm engine output: 11,0 kW weight of the machine ca.: 7.060 kg range L-W-H: 4,1 x 2,2 x 2,19 m -------------------------------------------------- electr. / hydraulic CNC guillotine shears - guided by a backdrop with CYBELEC CNC touch screen control with electr. / hydr. Cutting gap and cutting angle adjustment -------------------------------------------------- Furnishing: - CNC guillotine guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 Backgauge preselection - X axis Cutting gap adjustment Number of pieces Cutting length limitation Material preselection, including s ...

Key data: 8000 mm, 3 mm

Machine is in stabillier welded construction with 9 columns, 9 clamping cylinders and 36 coupling joints K38 mounted on a base frame The machine has the following equipment: CNC 8000 Control with Touch Screen TFT Color Display 17 Inch Attachment rail, brush table, upper beam with water seam groove Oil filling, fastening and levelling material, emergency stop rail via the Full length of the machine, integrated emergency stop operation in the foot pedal for upper and lower Bending beam, 2nd foot pedal for 2-man operation, upper bolster protection 2 short-part clamping fingers Machine is repaired, checked, cleaned by a professional and is then fully functional. Test run is carried out. Working length: 8000 mm Sheet thickness max. steel: 3.0 mm Sheet thickness max. aluminium: 4.0 mm Sheet thickness max. VA: 2.0 mm Back gauge (max:.) 1150 mm Back gauge (min.): 150 mm Colo ...

Band Saw Machine Metallkraft BMBS 300x 320 CNC BJ 2022

Key data: 2500 mm, 8000 mm

Poreba TZB-250 CNC Heavy Duty Modular Lathe Fanuc Oi-TF CNC Control with MPG Pendant (Retrofit 2015), 78.74” 4-Jaw Face Plate Type Chuck, 98.42” Swing Over Bed, 314.96” Maximum Turning Length, 125.98” Maximum Swing Over Gap, Spindle Speeds 0.5-1000 RPM, 4.13” Spindle Bore, 4-Way Tool Post, 35,275 Lbs. Approx. Weight Capacity (Unsupported), Power Tailstock, Open Steady Rest, 75 HP Spindle Motor, S/N 1132 070

G+H precision external cylindrical grinding machine RS 600 CNC / P for machining multiple diameters in a single setup, in plunge or oscillating mode. Grinding table driven by a digital servo axis, ball screw with a 10 mm pitch, axis speed 0.01 mm/min - 15 m/min, positioning via linear scale, resolution 0.001 mm, V-flat slide guide, guideways are Turcite-B coated. Disc feed support driven by a digital servo axis, ball screw with a 5 mm pitch, axis speed 0.01 mm/min - 10 m/min, positioning via linear scale, resolution 0.0005 mm, V-flat slide guide, guideways are Turcite-B coated. Workpiece headstock with digital servo spindle, positionable with initiator for detecting the reference mark, adjustable 0-1000 rpm; 2.7 kW power, MK5 taper bore, max. grinding diameter 260 mm. Tailstock with hydraulically operated quill, fine adjustment of cylindricity, max. center distance 600 mm. Center height  ...

Centerless grinding machine - centerless Ghiringhelli M100 CNC 1A 400x100mm wheel CN 1 axis plunge + through feed grinding The machine can be seen working in our warehouse in Gussago BS. Mimu(dot)com machine tools Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers, cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc., During centerless plunge grinding, the workpiece is ground in one pass, thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece, to work which is given to them with the aid of a tool., The through-feed grinding or also through grinding and longitudinal grinding: pieces, to be worked proceed uninterruptedly with axial feed through the rectification gap., Wheel width: 100, Wheel diam ...

: 300 mm : 300 mm : 300 x 260 mm saw band length: 3920 x 34 x 1,1 mm table height: 780 mm band speed: 20 - 100 m/min total power requirement: 3,7 kW weight of the machine ca.: 1,65 t dimensions: 2,0 x 2,05 x 1,7 m Unused display machine 2-column high-performance automatic band saw from the SBS series • Modern SNC 20 control system for CNC models • Frequency-controlled saw drive • Work light • Powered chip brush • Hydraulic band tensioning • Clamping pressure adjustment • Double vise (before and after the band) • Creep speed for positioning • Bundle tensioning, electrically and hydraulically prepared • Chip conveyor The SNC 20 control system allows for convenient and uncomplicated input of up to 20 different sawing tasks (length and quantity). When the target dimension is entered, the control system automatically calculates the saw waste and the number of feeds. In add ...

Manufacturer: KASTO Model: Twin A 4 AU CNC Year of Manufacture: 2004 Cutting Capacity: 400 mm x 400 mm (Ø 400 mm) Technical Specifications - Cutting Range Round: 400 mm - Cutting Range Square: 400 x 400 mm - Material Feed per Stroke (automatic): 600 mm - Multiple Feed Length: 99,999 mm - Cutting Speed: Stepless, 20–130 m/min - Total Drive Power: 7 kW - Saw Motor Power: 4 kW - Speed Reduction: Stepless adjustable - Material Height: 100 mm - Saw Blade Dimensions: 5700 x 41 x 1.3 mm - Shortest Cutting Length (automatic): 6 mm - Shortest Remnant Length (automatic): 80 mm - Voltage: 380V / 50Hz - Machine Dimensions (LxWxH): 2415 x 2400 x 1720 mm - Weight: 2200 kg Special Accessories - Coolant system - CNC control - Idle run monitoring - Machine roller table - Band tension control - Height measurement system - Light barrier - End stop Optional Roller Conveyors: - Roller Conveyor 30 ...

Underground lathe for reprofiling train wheels without necessary disassembly. Machine is in excellent condition.

gasleiding: Ø50 x 3,91 mm stalen buis: Ø60 x 3 mm roestvrijstalen buis: Ø60 x 2 mm koper/alu buis: Ø64 x 4 mm massieve staaf: Ø35 mm massieve rechthoekige staaf: 60 x 10 mm vlakke staaf (hard): 60 x 16 mm platte staaf (gemakkelijk): 60 x 30 mm doosdoorsnede: 60 x 30 x 4 mm maximale straal: 200 mm buigsnelheid: 1,25 amp; 2,5 rpm video klik hier Length: 900 mm Depth: 400 mm Height: 1100 mm Weight: 140 kg

spindle diameter: 130 mm x-travel: 3500 mm y-travel: 2000 mm z-travel: 1250 mm w-axis: 800 mm b-axis: 360 ° table:: 1800 x 2200 spindle turning speed range: 3000 U/min feed range: 4 - 3000 mm/min table load: 12 t spindle taper ISO: 50 spindle motor: 37 kW rapid traverse: 10 m/min Control: Heidenhain iTNC 530 b-axis: 360 ° total power requirement: ca 70 kW weight: 36 t range L-W-H: 8 x 8 x 3,5 m equipped with: - CNC control Heidenhein iTNC 530 & handwheel - clamping table 1800 x 2200mm, 12t -- full B-axis with 360,000 positions - coolant - IKZ 20bar & extern cooling - BLUM TC 60 Taster - without chip conveyor ca 11500 Spindle Hours The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

max. wheel diameter: 420 mm gear width: 120 mm max. module: 8 min. module: 0,5 control: BWO 783 no. of strokes: 32 - 800 Hub/min stroke: 0-137 mm table diameter: 400 mm table bore diameter: 125 mm total power requirement: 50 kW weight of the machine ca.: 9 t dimensions of the machine ca.: 5,3 x 3,9 x 3,5 m CNC control Heckler und Koch BWO 783 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

upper amp; lower Wila tooling 5 axes: X / X´ / R / Z1 / Z2 Capacity: 50 ton x 2550 mm Backgauge: CNC Control: TS3 Passage between uprights: 2550 mm Max stroke: 265 mm Max distance between table -- ram: 515 mm Locking speed: 90 mm/sec Working speed: 20 mm/sec Returning speed: 90 mm/sec Electric motor (power): 9 kW Length: 3400 mm Depth: 1850 mm Height: 2820 mm Weight: 5 ton

max. wheel diameter: 2500 mm gear width: 980 mm max. module: 34 min. module: 2 grinding stroke stepless adjustable: 1000 mm root circle dia. min.: 180 mm number of teeth: frei wählbar max.helical angle: 0 - 35 ° grinding slide stroke: 20 / 200 U/mm grinding wheel peripheral speeds:: 35 / 45 m/s grinding wheel diameter: 340 / 435 mm grinding motor: 22 kW pressure angle: 12,5 - 30 ° table diameter: 1300 mm table load capacity: 10000 kp table bore diameter: 300 mm depth of hole: 300 mm roll feed: 0 - 1000 m/min table diameter: 1300 mm workpiece weight: 10000 kg clamping length: 2760 mm clamping height: 420 - 590 mm table bore diameter: 280 mm depth of hole: 300 mm Control: BWO H+K CNC 785 total power requirement: 79 kVA weight of the machine ca.: 40 t dimensions of the machine ca.: 7,3 x 7,9 x 4,5 m - 10 axis CNC control BWO H+K CNC 785 (2nd Generation from 2009) - integrated measurement ...

max. wheel diameter: 620 mm gear width: 90 mm max. module: 12 min. module: - no. of teeth: 6 - 100 pivoting angle: 0 - 90 Grad spindle taper: metr. 100 milling head speed: 28 - 56 U/min connected load: 18 kVA Control: total power requirement: 14 kW weight of the machine ca.: 12 t 2020 Retrofit with new control/electrical system) - CNC control NTC (Fanuc) (German/English) - electric handwheel - new motors/ electrics - various change wheels - chip conveyor - coolant system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: SK 30 mm x-travel: 420 mm y-travel: 240 mm Control: Heidenhain TNC 355 total power requirement: 10 kW weight of the machine ca.: 1,4 t dimensions of the machine ca.: 2 x 2 x 2 m No. 5356 Vertical drilling and milling machine FEHLMANN Picomax 51 CNC 3 Working area: 420 x 240 x 120 / 450 Drive: 4 kW Control: Heidenhain TNC 355 Table 720 x 280 mm / 120 kg load Spindle holder Speed range 55 - 9,000 min-1 Space requirement approx. 3 x 2 x 2.4 m Weight approx. 1,500 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: Linsinger Type of Machine : CNC Saw Find more here - .ucymachines/ Contact us at - sales@ucymachines

Haco TSX 3100 x 6 mm CNC Cutting length: 3100 mm Max sheet thickness st 45: 6 mm Strokes/min: 8 > 14 str/min Backgauge: 750 mm Adjustable cuttingedge: 0,5 > 3° Electric motor (power): 7,5 kW Length: 3880 mm Depth: 1650 mm Height: 1700 mm Weight: 4,5 ton Number of sheet holders: 18x

Boven- en onderrol worden aangedreven (planetaire tandwielkast) Conische buiging Automatische gelijktijdige balancering Onderste rol excentrische balk Number of rolls: 4 rolls - 2 roll driven Roll capacity cold: 3100 x 32 mm Roll dia upside: 410 mm Dia under roll - side rolls: 370 - 300 mm Power needed: 25 HP Weight: 19 ton

- Two-roller technology - 180° arrangement of wheels - Closed work area with coolant and lubricant equipment - Hydraulic roundabout centering device - Gearbox with oil circulation lubrication -Temperature Specifications: Workpiece diameter (max.): 360 mm Blank diameter (max.): 380 mm Workpiece length (max.): 600 mm Center width (max.): 1,340 mm Tip width (min.): 200 mm Tool holder DIN 55026: Gr. 11 Force per axis (transverse) (max.): 117 kN Axle force (longitudinal)/feed axle (max.): 140 kN Stroke (transverse): 190 mm Stroke (longitudinal): 690 mm Feed axis speed: (max.) 1.8 m/min Rapid traverse (longitudinal): 7.0 m/min Adjustment roller (axial): 0-20 mm Stroke ejector: 380 mm Ejector force: 26 kN Tailstock stroke: 800 mm Tailstock force: 5-19 kN Speeds (infinitely adjustable): 6-231-387 min-1 25-850-1,550 min-1 Main drive (DC motor): 33  ...

Boring mill Manufacturer: TOS Type: WHQ 13.8 CNC Year of Make: 2000 CNC control: Heidenhain iTNC 530 Completely overhauled in 2022 Report available Travel: X/Y/Z: 3,500 x 2,500 x 1,250 mm Table length: 2,200 mm Table width: 1,800 mm Max. workpiece weight: 1,200 kg Spindle Ø: 130 mm Spindle speed max.: 3,000 rpm Spindle motor power: 37 kW Dimensions: LxWxH approx.: 7,500 x 6,950 x 4,000 mm Weight: 40 tons.

Inv. Num. : 8852 Type: SKJ 8 CNC Producer: TOS Created: GO 2006 Parameters: Control system: MEFI CNC 859 Table diameter: 780 mm Motor power: 40 kW Max. workpiece diameter: 1050 mm Max. workpiece height: 630 mm Max. workpiece weight: 2000 kg Weight: 9000 kg Equipment: Ant electric drives

Key data: 6400 mm, 1 mm

used Jorns double bending machine, with the following equipment: - 4 pneum. Clamping finger with short-part clamping finger - Attachment rail - Foot control - Sheet metal cassettes - Upper beam with rebate groove - Hydr. Material thickness adjustment - Clamp and angle stop (Matic) Machine is repaired, checked, cleaned by a specialist and is then fully functional. Test run is carried out. Working length 6400 mm Sheet thickness max. steel 1.5 mm Sheet thickness max. aluminium 2.0 mm Sheet thickness max. VA 1.0 mm Back gauge (min.) 15 mm Back gauge (max.) 1125 mm Colour anthracite/light grey Total power requirement 20 A Dimensions 7332 x 3721 x 2040 mm Weight 9250 kg Upper beam stroke (opening width) 200 mm Bending angle (max.) 145 degrees Crowning manual without roller scissors Number of stands 5 pieces Insertion depth 1150 mm Machine number K13036

CNC vertical lathe Type: SKIQ 12 CNC Manufacturer: TOS Year: 1986 Modernization: 2002 Control: Mefi CNC 856 Clamping plate diameter: 1250 mm Maximum turning diameter: 1700 mm Maximum workpiece height: 1335 – 1785 mm Maximum workpiece weight: 12000 kg Clamping plate speed: 2.5 – 500 rpm Main motor power: 40 kW Tool magazine: 15 positions Slide stroke (Z): 1000 mm Vertical crosshead movement: 800 – 1250 mm Slide dimensions: 180 × 200 mm Dimensions: 6100 × 5050 × 5255 mm Machine weight: 27000 kg In good condition, fully functional Find more here - .ucymachines/ Contact us at - sales@ucymachines

Dimensions (L/W/H): 6700x3350x1500 mm Weight: 1000 kg Total power requirement: 9 kw The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 600 mm grinding width: 350 mm workpiece height: mm total power requirement: 7,5 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: 390 mm grinding length: 650 mm centre height: 200 mm workpiece weight: max. 250 kg x-axis: 380 mm z-axis: 1150 mm sanding disc diameter: 400 mm peripheral speed: 20-50 m/sec workpiece spindle stepless: 1 - 650 U/min tailstock quill taper MT: 4 quill stroke: 45 mm dia. of quill: 50 mm total power requirement: 22 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

4 assen: Y1 / Y2 / X / V Laserbeveiliging voor en achter Capacity: 250 ton x 4100 mm Backgauge: CNC Control: Cadman Touch-B Passage between uprights: 3150 mm Max stroke: 250 mm Max distance between table -- ram: 500 mm Depth of throat: 350 mm Table width: 250 mm Locking speed: 80 mm/sec Working speed: 10 mm/sec Returning speed: 80 mm/sec Electric motor (power): 30 kW Length: 5545 mm Depth: 1990 mm Height: 3380 mm Weight: 23 ton

Key data: 8020 mm, 3 mm

with hydraulic scissors, emergency stop rail, attachment rail, control on the swivel bracket, radius adjustment. The connection Hydraulic power unit is behind the machine. Machine is repaired, checked, cleaned by a specialist and is then fully functional. Test run is carried out. Working length: 8020 mm Sheet thickness steel: 3.0 mm Sheet thickness aluminum: 4.0 mm Sheet thickness front: 1.5 mm Back gauge (max.): 1000 Radius: 1020 Colour: grey/blue Total power requirement: 46 A Space requirement: 10,000 x 2,300 mm Insertion depth: 1000 Machine weight: 8000 kg Oberwangenhub: 200 Roller shears: 3.0mm Number of stands: 10 with cutting device for cutting to length/ Öffnungsweite_ h 200 Max. bending angle: 143 crowning without underbeam adjustment Back gauge (min,) 15 Machine number: 09488-01/K19149

Haco ERM 320 ton x 6100 mm CNC Capacity: 320 ton x 6100 mm Backgauge: CNC Control: 2D Touch Passage between uprights: 5050 mm Max stroke: 250 mm Max distance between table -- ram: 500 mm Depth of throat: 330 mm Locking speed: 80 mm/sec Working speed: 8 mm/sec Returning speed: 100 mm/sec Electric motor (power): 22,5 kW Length: 6500 mm Depth: 1980 mm Height: 3700 mm Weight: 33 ton
