cnc press brake used for sale

A Beyeler press brake, today Bystronic, is available. Working length: 4100mm, press force: 2250kN, max. stroke: 400mm, throat depth: 250mm, installation height: 917mm, rapid traverse down/up: 150mm/s, working speed: 10mm/s, hydraulic pressure: 315bar, oil volume: 815l, max. oil temperature: 65°C, power: 30kW, max. upper tool weight: 400kg, max. workpiece weight: 13kg. Machine dimensions X/Y/Z: approx. 5500mm/2300mm/3350mm, weight: approx. 22000kg, operating hours: approx. 35000h. Including numerous upper tools, blades and lower tools. Documentation available. On-site inspection is possible.

Type of press: 2-cylinder synchronized press, pressing force: 125t, rated pressing force: 110t, bending length: 3000mm, ram stroke: 360mm, installation height: 540mm, distance between frames: 2550mm, hydraulic pressure: 256bar, weight: approx. 12000kg, control system: Cybelec DNC 7000 Graphic. Including various tools. The control system and the screen were renewed in mid/late 2025. An on-site inspection is possible.

Press brake, bending machine, bending machine, swing bending machine, die bending machine -Machine: can be viewed while powered on -CNC press brake: with 3 axes and laser safety system -Working width: 3200 mm -Pressure force: 125 tons -Max. stroke of the bending beam: 160 mm -Distance between the stands: 2700 mm -Backgauge travel: 590 mm -Backgauge: 2 axes electronically movable, 1 axis manually movable Accessories: see pictures -Installation dimensions: 2140/5195/H2530 mm -Transport dimensions: 1680/5195/H2530 mm -Weight: 9300 kg

A CNC press brake Amada is available. Press force: 800kN, bending length: 2500mm, press beam length: 2570mm, distance between uprights: 2125mm, throat depth: 420mm, max. stroke: 350mm, installation height: 620mm, table width: 60mm, table height: 960mm. Machine dimensions X/Y/Z: approx. 3300mm/1600mm/2750mm, weight: approx. 6100kg, control system: Amada. Documentation available. An on-site inspection is possible.

Hydraulic CNC press brake EHT for sale. Press force: 1100kN, bending length: 3050mm, min./max. table-ram distance: 280mm/600mm, rapid approach speed: 100mm/s, working speed: 2mm/s-8mm/s, return speed: 100mm/s, backgauge adjustment range: 5-1000mm, backgauge adjustment speed: 200mm/s, backgauge vertical adjustment: +/-10mm, safety distance between tooling and operating elements: 120mm, stopping time: 75ms, stopping distance: 11mm, Control system: DAK 90. Machine weight: 8500kg. Documentation available. Inspection by appointment possible.

LOIRSAFE CNC hydraulic press brake Model No.: PHSE-90/30/26 Year of manufacture: 2005 Serial number: 15.629 Bending force: 900 kN / 90 t Folding length: 3,050 mm Travel: 150 mm Main motor power: 5.5 kW Power supply: 400 V, three-phase, 50 Hz Full-load current: 17.5 A Machine weight without tooling: 5,000 kg Maximum tooling weight: 200 kg Maximum approach speed: 100 mm/s Maximum working speed: 10 mm/s Stopping Time: 64 ms Equipped with CNC control Pedal drive Auction-ID: A7-49809-4

Used, untested. Maximum stroke: 350 mm Loading conditions: Is loaded onto the truck Forklift and crane available Auction-ID: A7-50094-8

Y1; Y2; X;R axis Die displacement with handwheel 4 pcs striking fingers hydraulic punch clamp WILA hydraulic die clamping system Amada 2 pcs support arms Safe 2-hand / foot operation Various stamps and dies Auction-ID: A7-50158-2

Auction-ID: A7-50346-17

Year: 2018 Control System: Delem DA-66T Number of Axes: 6 (Y1 + Y2 + X + R + Z1 + Z2) Operating Hours: 2,442 h Power: 15.8 kW Press Force: 120 tons Maximum Working Width: 3,100 mm Column Gap: 2,550 mm Backgauge Depth: 750 mm Max Stroke: 260 mm Crowning System: CNC-controlled Punch Holder: Standard (European-style) Tools Included: Yes Options: Finger safety guard Documentation: Available CE Certificate: Yes Video available Auction-ID: A1-40982-6

Brand: Metaleen Tools & Equipment (visible on the frame of the machine). Type: WE67K-160T/3200. Year of manufacture: 2025, deduced from the serial number/order date. Serial number: 2025040195. Capacity t: 160 tons. Working length mm: 3200 mm. Control, brand, type: Delem DA-53T-[N], serial number 244400017, Delem PN D8087-007, software version V1.8.23, produced by Delem, Eindhoven (NL). Auction-ID: A3-46126-11241

Auction-ID: A1-40982-141

Can't refer to press brake. Since X and R axis are stuck. Auction-ID: A1-40982-135

Discharge m 420mm, distance between frame: 2700mm, equipped with Fiesslet AKAS Iii 150 S/HS protection. Includes 1 tool drawer cabinet and various segment bending knives; Auction-ID: A1-49889-17

maximum stroke: 350mm, extension: 450mm, between frame: 3240mm, equipped with Fiesslet AKAS Iii 150 S/HS protection; with 2 pallets of various chamfering tools. Auction-ID: A1-49889-12

Extension: 420mm, distance between frame: 3760mm, equipped with Fiesslet AKAS Iii 150 S/HS protection Auction-ID: A1-49889-15

New hydraulic press brake. Pressing force: 125Tn. Working lenght: 3200mm. Distance between housings: 2650mm. Stroke of the ram: 120mm. Distance between table and ram: 415mm. Depth of throat: 320mm. Motor power: 7,5kw. Weight: 7850Kgs. Dimensions: 3300x1800x2690mm. CE.

Hydraulic press brake. Working length: 3.000mm. Pressing force: 200Tn. Back gauge.

The press brake HAMMERLE BM 200-3100 press brake was built in 1996. The folding machine was serviced regularly. Technical parameters of the press: - control: INFINITRON - number of NC axes: 11 - pressure: 200 tons - bending length: 3100 mm - working stroke: 400 mm - distance between the body walls: 3240 mm - maximum distance between the table and the bumper: 965 mm - voltage: 3 x 400 Volt - control voltage: 24 V = - total power: 28 kW - deflection arrow compensation - total machine width: 4400 mm - total height of the press: 3400 mm - weight of the press: 16 600 kg

pressure: 160 t chamfer lenght: 4000 mm distance between columns: 3060 mm control: FORTRON CNC 10 H 4 throat: 280 mm stroke: 250 mm dayligth: 500 mm table length: 4050 mm table width: 280 mm feed down: 70 mm/sec feed up: 68,4 mm/sec working feed: 9 / 3,5 mm/sec operating pressure: max. 205 bar oil volume: 400 l total power requirement: 19,5 kW weight of the machine ca.: 20,8 t Total weight including accessories: 22 t dimensions of machine L x W x H: 4,8 x 1,88 x 2,93 m dimensions of switch cabinet: 1,6 x 0,5 x 2,25 m Acc.: programmable back gauge, upper and lower dies, table extensions The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 200 t chamfer lenght: 3000 mm distance between columns: 2560 mm dayligth: 450 mm throat: 450 mm adjustment of stroke: 240 mm horn length over column outer edge each: 175 mm table length: 3050 mm table width: 280 mm table height over floor: 820 mm electrics - voltage/frequency: 220/50 V/Hz control: CYBELEC, DNC60 stroke: 250 mm operating pressure: 150 bar total power requirement: kW weight of the machine ca.: 15 t dimensions of the machine ca.: L:4,0 x B:3,2 x H:3,44 m • hydraulical press brake, • new control CYBELEC DNC60 (in 2005), • lower part of the machine moves down 500 mm to the floor, at the moment the machine is mounted on a double-T-support, • prism and upper part of the machine in 3000 mm length The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 1500 kN chamfer lenght: 3550 mm distance between columns: 3044 mm Control: Cybelec 34 PS-CN column arm: 350 mm max. ram stroke: 220 mm dimensions of the machine ca.: 3200 x 4200 x 2100 m sheet support: hinten / back number of support arms: 2, verschiebbar / adjust. die shift: hydraulical tool clamping: upper tool quick change system: crown: 3 sets of tools included The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Stop for press brake, bending machine, guillotine shear, drive shaft -Drive shafts: for stop, from press brake EHT type EHP 11-40, 2 pieces -Length: 515 mm -Hole: Ø 25 mm -Price: complete -Dimensions: Ø 50 x 515 mm -Weight 5.1 kg/pc.

Bending tool, die, upper knife, upper tool, straight tool, die tool, seam closing tool -Tool: for press brake, die tool -Measures: see drawing in the photos -Dimension: 3060/20 / H79 mm -Weight.: 30.3 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool: split, for press brake -Tool angle: 90° -Drawing: in the photos -Dimension: 33 x 170 mm -Length: 1485 mm (1 x 855/630 mm each) -Weight: 44.6 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool: split, for press brake -Tool angle: 90° -Drawing: in the photos -Dimension: 29 x 171 mm -Length: 1570 mm (1x 650/500/420 mm each) -Weight: 41.2 kg

Bending tool, die, upper knife, upper tool, deer foot tool, deer foot tool for press brake -Tool: for press brake -Angle: 90° -Dimensions: 55 x 133 mm, see drawing in the photos -Length: 365 mm -Weight: 9.8 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Dimensions: 10 x 88 mm -Length: 2000 mm -with: storage box -Weight: 13.2 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Thickness: 25/13 mm -Drawing: with the pictures -Total length: 400 mm -Total height: 108 mm -Weight: 6.5 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool: split, for press brake -Tool angle: 60° -Drawing: in the photos -Dimension: 25 x 165 mm -Length: 3562 mm (each 1 x 1818/800/387/190/122/85/60/55/45 mm) -Weight: 124 kg

Bending tool, die, lower knife, lower tool, prism tool -Tool for: press brake -Groove: W/D 9 x 12, 5 x 8, 17 x 20 mm -Length: 3 x 835 mm, 1 x 272 mm -Width/height: 60 mm -Drawing: with the pictures -Weight: 67.5 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool for: closing folds -Recording: 25 mm -Drawing: in the photos -Dimension: 40 x 130 mm -Length: 495 mm -Weight: 12.5 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool: 26° -Drawing: in the photos -Dimension: 13 x 180 mm -Length: 45 mm -Weight: 0.7 kg

Bending tool, die, lower knife, lower tool, prism tool -Tool for: press brake -Prisms: 90° 12 mm -Drawing: in the photos -Length: 4200 mm (2 x 2100 mm) -Dimension: 20 x 75 mm -Weight: 44 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Thickness: 25/13 mm -Drawing: with the pictures -Total length: 400 mm -Total height: 120 mm -Price: per piece -Number: 2 pieces -Weight: 13 kg

Bending tool, die, lower knife, lower tool, prism tool, reversible prism, 1-part die block for die bending machine, die tool, hemming tool -Tool: for press brake, die / hemming tool -Measures: see drawing in the photos -Dimensions: 150/101 / H75 mm / 150/77 / H159 mm -Weight: 7.2 kg / 11.4 kg

Bending tool, die, lower knife, lower tool, prism tool, reversible prism, 1-part die block for die bending machine, die tool, hemming tool -Tool: for press brake, die / hemming tool -Measures: see drawing in the photos -Dimensions: 150/101 / H77 mm / 150/77 / H160 mm -Weight: 6.9 kg / 11.2 kg

Bending tool, die, lower knife, lower tool, prism tool, reversible prism, 1-part die block for die bending machine -Tool: for press brake, 12 pieces -Prisms: 25 ° x 10 mm -Drawing: in the photos -Lengths: see parts list in the photos -Dimensions total: 30/79/2917 mm -Weight: 47 kg

Bending tool, die, upper knife, upper tool, straight tool, die tool, seam closing tool -Tool: for press brake, 6 pieces -Tool: for closing folds -Drawing: in the photos -Dimension: 20 x 70 x 495 mm -Price / fee: complete -Length total: 2970 mm -Total weight: 31.3 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool: for press brake, 14 pieces -Tool angle: 25° -Drawing: in the photos -Dimension: 25 x 158 mm -Length total: 2615 mm (lengths see parts list photo) -Weight: 47.3 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Thickness: 25/13 mm -Drawing: with the pictures -Total length: 400 mm -Total height: 99 mm -Price: per piece -Number: 2 pieces -Weight: 9.7 kg

Bending tool, die, upper knife, upper tool, tool for press brake -divided -Dimensions: 31.007.2101 -Height: 86 mm -Length: 2x100 mm -Dimensions: 21.002.01.01 -Height: 155 mm -Length: 2x100 mm -Packed: in wooden box -Weight: 11.9 kg

Tool trolley for bending tool, die, upper knife, upper tool, straight tool -Tool trolley for the: Tool for a press brake -with several compartments -Dimensions: 1165/720/H1000 mm -Weight: 208 kg

Stop, depth stop, length stop for press brake, bending machine, guillotine shear... -Recording with: Slotted hole -Length (unit of measurement): approx. 300 mm - Fine-tuning -Quantity: 2 available Price: complete -Dimensions: 2x 410/320/H120 mm -Weight: 28 kg

Bending tool, die, upper knife, upper tool, straight tool -Transfer in current condition as seen -Tool for: press brake -Tool: 45° -Thickness: 25 mm -Total length: 600 mm -Total height: 195 mm -Weight: 20 kg

Bending tool, die, lower knife, lower tool, prism tool -Tool for: press brake -Prisms: R14.5 mm -Square: 101 x 71 mm -Total length: 552 mm -Weight: 26 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Thickness: 25/13 mm -Drawing with the pictures -Total length: 200 mm -Total height: 188 mm -Weight: 6 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Thickness: 25 mm -Drawing with the pictures -Total length: 303 mm -Total height: 171 mm -Weight: 10 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Radius: R8 -Thickness: 60/25 mm -Drawing with the pictures -Total length: 569 mm -Total height: 176 mm -Weight: 30 kg

Bending tool, die, upper knife, upper tool, straight tool -Tool for: press brake -Tool as: die -Thickness: 25/40 mm -Drawing with the pictures -Total length: 599 mm -Total height: 68 mm -Weight: 28 kg
