cnc portal milling used for sale

CNC Control: FANUC 0M (original manual) Number of axes: 3 Axis strokes: X 1100 mm / Y 650 mm / Z 800 mm Maximum spindle speed: 8000 rpm Cooling: with coolant Spindle taper: BT40 Tool changer: automatic, 30 stations Year: 1994 Manufacturer: SUPERMAX Auction-ID: A1-46647-269

Technical details Serial number: 1000039423 Power: 21 kW Voltage: 400 VAC Full load current: 36 A Air supply: 6.5 bar Suction flow rate: 30 m/sec Dimensions: 5300 × 2300 × 2300 mm Weight: 2,500 kg Condition: Used (very few working hours) Additional notes: For further technical information, please refer to documents 1-01.pdf, 1-02.pdf and 1-03.pdf Auction-ID: A7-40554-1

CNC lathe for turning and machining metal parts. CNC control: Fanuc 16 T AA Max. turning diameter: 165 mm Turning length: 100 – 340 mm Diameter above bed: 220 mm Main spindle speed: 50 – 5,000 rpm Main spindle power: 5.5 / 7.5 kW Main spindle bar passing: 65 mm Sub-spindle speed: 50 – 5,000 rpm Sub-spindle power: 3.7 / 5.5 kW Sub-spindle bar passage: 42 mm C-axis: 0.001° Turrets: 2 Tool positions: 2 × 16 Motorized tools: 2 × 16 positions Strokes: X 175 mm / Z 240 – 680 mm Total power: 41 kVA Dimensions (mm): 3,500 × 2,800 × 2,000 Weight (kg): 5,500 Auction-ID: A1-46647-237

Capabilities: Maximum turning diameter: 420 mm (standard 290 mm) Maximum turning length (Z-axis): 635 mm Bar passage: 65 mm Spindle Bore: 79 mm Spindle: Rotational speed: 25 to 5,000 rpm Power: 21 kW (100%) / 28 kW (40%) 3-jaw hydraulic chuck (Ø approx. 200–250 mm) Turret & tooling: Sauter Turret VDI 30 (DIN 69880) Capacity: 12 stations Motorized substations C-axis (pin indexing) CNC Control: Heidenhain Turn Plus Electrical data: Power supply: 400 V / 3~ / 50 Hz Installed effective power: 44 kVA Current rating: 64 A Protection: 80 A Auxiliary voltage: 230 V Control voltage: 24 V DC Auction-ID: A1-46647-262

Machine: CNC machining center MASTERWOOD 4 WIN Year: 2010 Running axes: X 4960 mm, Y 1930 mm, Z 650 mm Digital axes: 4 + C-axis Electrospindle: 17 kW HSK63E with dimmer, dedicated cooling Tool Magazines: 10 pos. head, 16 pos. rear carriage, 18 pos. lateral Fixed heads: blade holder Ø220 + Ø350 mm HSK63F Table: 7 bar auto Belt: chip evacuation Order: Multilingual PC + Masterwindows software, mobile console, handheld remote control Security: EC Dimensions: 6800 x 2450 x 2450 mm Weight: 4300 kg Available from the beginning of November. Auction-ID: A1-46801-42

Machine: BIESSE CNC machining center Table: 3060 x 1260 x 150 mm Solenoid Spindle: 12 kW, ISO30 Cone Tool changer: 10 positions Vacuum pump: 100 m³/h Consoles: 6 with 3 ATS suction cups Drilling Head: 15 Vertical + 4 Horizontal Pins X Saw: Ø125 mm Accessories: 4-position flange, bevel gearbox, flange for aggregates Equipment: chip recovery belt, Biesse WORK software, B_NEST Auction-ID: A1-46801-23

Manufacturer: YAMAZAKI MAZAK Model: Quick Turn 20 Year: 1997 CNC Machine: Mazatrol T Plus Axes: 2 Axes (X, Z) Capacities: Max. diameter above bed: Ø 300 mm Distance between points: 446 mm X-axis stroke: 180 mm Spindle: Bore: 61 mm Max. speed: 4500 rpm Motor power: 15 kW Turret: 8 positions Dimensions per machine: 2660 x 1520 x 1879 mm Unit weight: approx. 4170 kg (total batch weight approx. 8340 kg) Condition: used Auction-ID: A1-46647-261

CNC-controller Delem DA-65R, bending pressure 1100kN, working lenght 3100mm, capacity - 7,5kW, voltage - 3PH 380 Volt, hydraulic oil - 120l Auction-ID: A7-46486-1

CNC vertical machining center for machining metal parts. CNC control: Heidenhain TNC 410 Axes: 3 axes Strokes: X 1,020 mm / Y 610 mm / Z 560 mm Table: 1,400 ×,650 mm Maximum load table: 2,000 kg Spindle taper: BT 40 Spindle speed: 10,000 rpm Spindle power: 15 kW Tool changer: 40 positions High-pressure coolant: 20 bar through spindle Equipment: Chip conveyor, 2 augers, spindle cooling, closed cab, machine lighting Auction-ID: A1-46647-247

Make: Sodick Type: CNC Die Sinking EDM Machine Model: AM3L Control: Sodick LN1 Technical data: - Working tank: Die sinking EDM - Table size: approx. 600 x 400 mm (estimated) - Axes: X / Y / Z - CNC control: Sodick LN1 Equipment: - Die-sinking EDM generator - Enclosed working area with safety guard - Control cabinet with monitor & keyboard - System 3R tooling interface - Oil unit (Oilmatic temperature regulator) - Dielectric filtration system Condition: Used Auction-ID: A7-45993-51

CNC Vertical Machining Center Order: Heidenhain TNC 426 Axes: 3 Table (mm): 1100 × 600 X/Y/Z strokes (mm): 1000 × 600 × 800 Spindle: ISO 40, max. 8,000 rpm Tool magazine: 40 positions Equipment: Chip conveyor Serial number: Notes: Used machine, Auction-ID: A1-46647-260

Hours in picture. 1999 DMG (Deckel Maho) DMU 80 T is a high-precision CNC universal milling machine. It was a staple in toolrooms and production shops at the turn of the millennium because it bridged the gap between a standard 3-axis mill and a full 5-axis machining center. In the late 90s, the "T" series stood for "Table," featuring a large fixed table with a swiveling milling head, making it incredibly versatile for large or heavy workpieces Find more here - / Contact us at -

RETROFIT of the machine in 2010, CNC control FANUC Series 18i TB, total weight 5,500 kg, filter system W & W FILTER SYSTEMS, chip conveyor SEREMETO, cooling unit EMAG HTD 720

2-axis CNC lathe with HAAS CNC Manufacturer: HAAS Model: HL-2 Year: 1997 Serial Number: 61212 Max turning diameter: 508 mm Max turning length: 610 mm Spindle Bore: 76.2 mm Max spindle speed: 3750 rpm Turret: 10 positions CNC Control: HAAS CNC Power supply: 360 / 480 V – 3 phases – 50/60 Hz Dimensions approx. (L x W x H): 3200 x 1778 x 1778 mm Weight approx.: 4082 kg Auction-ID: A1-46647-263

Manufacturer: INDEX Year: 2005 Type: Moving spindle CNC lathe with motorized tools and C-axis Numerical control: Siemens Sinumerik 840D Powerline Chuck: Ø 160 mm Max. rotation diameter: Ø 180 mm Strokes: X-axis 520 mm / Z-axis 200 mm Fast feeds: X/Z 40 / 30 m/min Moving spindle: 5,000 rpm – 13 kW (100%) / 20 kW (40% ED) – max. torque 105 Nm C-axis: 0.001° resolution Turret: 12 positions – all motorable stations – VDI 30 Motorized tools: up to 6,000 rpm – 8.5 kW Power supply: 400 V / 50 Hz / 3 phases – installed power approx. 25 kW Weight (kg): approx. 4500 Auction-ID: A1-46647-273

CNC lathe for turning and machining metal parts. CNC control: Fanuc 16 T AA Max. turning diameter: 165 mm Turning length: 100 – 340 mm Diameter above bed: 220 mm Main spindle speed: 50 – 5,000 rpm Main spindle power: 5.5 / 7.5 kW Main spindle bar passing: 65 mm Sub-spindle speed: 50 – 5,000 rpm Counter-spindle power: 3.7 / 5.5 kW Counter-spindle bar passage: 42 mm C-axis: 0.001° Turrets: 2 Tool positions: 2 × 16 Motorized tools: 2 × 16 positions Strokes: X 175 mm / Z 240 – 680 mm Total power: 41 kVA Dimensions (mm): 3,500 × 2,800 × 2,000 Weight (kg): 5,500 Serial No.: 1105-02957 Auction-ID: A1-46647-238

Machine type: CNC Die Sinking EDM Manufacturer: Sodick Model: AM35L Control: Sodick LN / LN1 control Year: n/a Serial number: n/a Working hours: n/a Table size: approx. 600 x 400 mm Axis travel (X/Y/Z): approx. 350 / 250 / 250 mm (typical for model) Process type: Die sinking EDM Generator: Sodick generator Tank: Integrated dielectric tank Control system: Sodick LN1 control with external monitor (KME) Data input: Floppy disk (2DD) interface Cooling system: External oil temperature regulator (Kanto Seiki Oilmatic) Pump system: Integrated dielectric pumps Accessories: Oil temperature unit, dielectric system, control unit Remarks: Machine in used condition. Control boots (system loading visible). Typical signs of use and dirt/oil residues. Equipped with external oil temperature control unit and dielectric system. Own mass: approx. 3,500 kg Dimensi ...

Machine type: CNC Vertical Machining Center Manufacturer: Tongtai Model: TMV-720A Control: Heidenhain CNC control Year: n/a Serial number: n/a Working hours: n/a Table size: approx. 900 x 400 mm Spindle: Vertical spindle Tool holder: SK40 (visual assumption) Tool changer: Yes, side-mounted tool rack Number of tool holders: approx. 20+ pcs included Coolant system: Yes, internal coolant nozzles Chip management: Chip conveyor installed Coolant unit: External filtration unit (Granch Filtration) Control panel: Heidenhain with manual pulse generator (MPG) Emergency stop: Yes Status light: Yes Accessories: Tool holders, coolant system, filtration unit Remarks: Machine in used condition, signs of wear and coolant residues visible. Control boots and initializes. Includes multiple tool holders and external coolant filtration system. Own mass: approx. 5 ...

Make: Sodick Type: CNC Die Sinking EDM Machine Model: AQ35LR Control: Sodick LN1 Controller model: LQ3 Technical data: - Axes: 3 (linear) - Working tank: Die-sinking EDM - Table size: approx. 600 x 400 mm (estimated) - Z-axis display visible on control Equipment: - Sodick LN1 CNC control with keyboard & monitor - Integrated dielectric system - Tooling system (Walker-Hagou fixture visible) - Electrode changer / tool rack - Pressure gauges and flushing system - Manual control pendant Condition: Used Auction-ID: A7-45993-52

CNC control Traub System TX8 D, with 1 turret with 12 tool positions, bar passage 60 mm, with fleece filter system and chip conveyor

Make: Big-Plus (Taiwan) Type: CNC Vertical Machining Center Model: 850 VMC Serial number: BM110CE01 Control: FANUC Series 0i-MD Technical data: - X / Y / Z travel: approx. 850 mm / 500 mm / 500 mm - Table size: approx. 1000 x 500 mm - Spindle speed: 10,000 rpm - Main voltage: 415 V AC - Power requirement: 20 kVA - Air required: approx. 6–8 kg/cm² Equipment: - Vertical spindle (Big-Plus spindle system) - Tool changer (carousel type) - Coolant system - Enclosed working area with sliding door - Manual pulse generator (handwheel) Control panel: - FANUC interface with display and full keyboard - Feed / rapid / spindle override controls - Emergency stop and cycle controls Condition: Used Auction-ID: A7-45993-49

CNC control Traub System TX8 F, with 1 turret with 6 tool positions and 1 turret with 6 tool positions, driven tools, bar passage 30 mm, with fleece filter system, coolant device and aut. Bar loading magazine

Type: CNC surface grinding machine Model: ABA Z&B EL 806 Year: 2003 Control: CNC control panel (integrated aba control) Working area: Magnetic clamping table Machine layout: Horizontal grinding spindle with enclosed working area Technical data: Voltage: 400 V Total power: 29 kW Machine weight: approx. 5,700 kg Equipment: - Magnetic clamping table - Enclosed grinding cabin with sliding door - Coolant system - Air filtration unit (AIRTECH) - Control panel with joystick and keypad Condition: Used, not tested Remarks: Signs of wear and corrosion visible; complete system with extraction unit Own mass: approx. 5,700 kg Dimensions (LxWxH): approx. 4000 x 2200 x 2200 mm Auction-ID: A7-45993-17

Make: Dugard Type: CNC Vertical Machining Center Model: Eagle 1000 VMC Serial number: MC97BF06 Control: FANUC Series 0i-MC Technical data: - X / Y / Z travel: approx. 1000 mm / 500 mm / 500 mm (typical for model class) - Spindle speed: 8000 rpm - Main voltage: 415 V AC - Power requirement: 20 kVA - Air required: 5–6 kg/cm² Equipment: - Vertical spindle - Tool holders included (side mounted rack) - Coolant system - Manual pulse generator (handwheel) - Enclosed working area with sliding door Control panel: - Full FANUC keyboard and display - Feed / rapid / spindle override controls - Emergency stop and cycle controls Condition: Used Auction-ID: A7-45993-48

Control: Siemens Sinumerik 840D,Filter system: KNOLL KF 400, year of manufacture 2018, chip conveyor Auction-ID: A7-46802-1

Type: CNC Vertical Machining Center Brand: EMSIL Techtrans Model: DMC2100H Control: FANUC Series 18i-MB Machine Type: Super Vertical Machining Center Axes: 3-axis (X / Y / Z) Equipment: - Enclosed working area with sliding doors - Large T-slot worktable - Automatic tool interface (tool holder included) - CNC control panel with screen and full keypad - Emergency stop - Coolant system with adjustable nozzles - Electrical cabinet integrated - Status signal tower (stack light) Displayed Data (at time of inspection): Run time: approx. 19,568 h Part count: 84,933 Condition: Used Remarks: Alarm displayed (pressure low); machine not tested; sold as seen Auction-ID: A7-45993-78

CNC control Traub System TX8 D, with 1 turret with 14 tool positions and 1 turret with 9 tool positions, driven tools, max. turning length approx. 1000 mm, bar passage 80 mm, power 73 KW, with fleece filter system and chip conveyor

CNC control Traub System TX8 I, bar passage 42 mm, max. turning length 450 mm, max. speed 8000 rpm, 2 turrets with 10 tool positions each, driven tools, chip conveyor KNOLL 240 S-1/50, filtration system/compact belt filter RESY KBF 452/500

CNC control MORI SEIKI MSX-501, 2 turrets with 16 tool positions each, driven tools, 2 spindles, bar passage 52 mm, max. speed 6000 rpm, max. turning diameter 190 mm, max. turning length 450 mm, Y-axis +/- 40 mm, machine weight 5,100 kg, chip conveyor

Key data: 800 mm, 600 mm, 500 1/min

CNC control Traub System TX8 I, bar passage 42 mm, max. turning length 450 mm, max. speed 8000 rpm, 2 turrets with 10 tool positions each, driven tools, coolant device, chip conveyor KNOLL 240 S-1/50, filtration system/compact belt filter RESY

consisting of: CNC lathe EMAG VL3 DSL, BJ. 2012, Ser. No. 103899 and CNC lathe EMAG VLY , BJ. 2012, Ser. No. 10390, each CNC control SIEMENS SINUMERIK, robot loading system with loading robot FANUC M10iA, BJ. 2012, each machine with WW ME-FI 600 filter system, Sermeto HENNIG 30 S chip extraction, EMAG cooling unit, coolant device, workpiece conveyor system and hand control panel

CNC control FANUC Series 31i MODEL B, spindle passage 20 mm, 8-axis incl. Y2 axis, main and counter spindle speed max. 8000 rpm, driven tools, machine weight 3,800 kg, with bar loading magazine FMB Minimag 20, with coolant system, filter system, extinguishing system KRAFT & BAUER and chip conveyor

CNC control FANUC Series 31i MODEL B, spindle passage 20 mm, 8-axis incl. Y2 axis, main and counter spindle speed max. 8000 rpm, driven tools, machine weight 3,800 kg, with bar loading magazine FMB Minimag 21, with coolant system, filter system, extinguishing system KRAFT & BAUER and chip conveyor

Fanuc 18i-T, live tooling, sub-spindle Max turning diameter: 390 mm Recommended turning diameter: 170 mm Max bar capacity: 65 mm X-axis travel: 205 mm Z-axis travel: 580 mm C-axis: 360° Chuck size: 210 mm Spindle nose: ASA A2-6 Spindle bore: 76 mm Spindle motor power: 15/11 kW Rapid traverse X/Z: 20/25 m/min Turret positions: 12 Bar capacity: 65 mm Coolant pump motor: 0.24 kW Electrical requirement: 25 kVA Machine height: 1740 mm Machine weight: 4240 kg Control system: FANUC FS18T-C / FS16T-C Auction-ID: A7-46053-17

turning diameter:1600 mm turning length:12000 mm control:FAGOR 8050 Used CNC Lathe with FAGOR 8050 and extensive accessories. For further technical data and accessories, pls browse the Appendix. Parallellathe WMW mod. 4 GUIDE-WAYS ¦ CNC: FAGOR 8050 ¦ bed: monolithic ¦ centres height: 800 mm ¦ centres distance: 12000 mm ¦ swing over cross-slide: 1250 mm ¦ turret: automatic 4 positions ¦ tailstock: motorized ¦ tailstock connection: hydraulic ¦ platform: diam. 1000 mm ¦ steady rests: nr.02 ¦ chip conveyor Warranty: none Take advantage of the favorable leasing and hire-purchase terms from IKB Leasing. Ask us about it.

Supply voltage: 380 V Phase: 3P Frequency: 50 Hz Rated capacity: 46 kVA Full load current: 70 A Largest motor rate: 129/10 A Interrupt capacity: 15 kA Diagram No.: W6000-270/-247-6 Serial number: 0317 Made in Japan by OKUMA Corporation Maximum machining capacity: 1000 × 800 × 810 mm Maximum workpiece size: 939.37 × 810 × 810 mm X-axis travel: 1000 mm Y-axis travel: 800 mm Z-axis travel: 810 mm Spindle center to table: 200–1010 mm Spindle end to table center: 87.8–976 mm Table pallet size: 630 × 630 mm Index positions: 360 positions Maximum table load: 1200 kg Spindle speed range: 50–10000 rpm Spindle taper: NT No.50 Spindle diameter: Ø110 mm Rapid feedrate (X/Y/Z): 30000 mm/min Jog feedrate: 1–20000 mm/min 4-axis horizontal machining center Auction-ID: A7-46053-25

Model: Rover 24XL Serial Number: 32495 Working range X: 6170 mm Working range Y: 1380 mm Working range Z: 155 mm Main motor: 7.5 kW Max rotation speed: 24,000 rpm Tool change positions: 7 Vertical drill bits: 14 Horizontal drill bits X: 4 Horizontal drill bits Y: 2 Worktop: 10 bars, 4 trolleys per bar Suction cups: also included, in good condition, spare Plane positioning: automatic Vacuum pump: Busch MM1252 AV Chip conveyor belt Auction-ID: A7-46828-1

Fanuc 21i-M control, enclosed VMC Spindle taper: BT40 Spindle speed range: 72–10000 rpm Spindle motor power: 5.5/3.7 kW Pull stud bolt type: MAS-P40T-1 Number of tools: 20 Maximum tool weight: 5 kg Maximum tool diameter: 100 mm Maximum tool length: 250 mm Tool change time (T-T): 1.2 sec Tool change time (T-C): 2.8 sec Pallet change method: Turning-table method Pallet change time: 4 sec Drilling capability: Ø22 mm Tapping capability: M18 Milling capability: 20 cc/min Machine weight: 4000 kg NC device: FANUC 21i-MA Auction-ID: A7-46053-21

turning diameter:270 -300 mm turning length:710 mm total power requirement:43 kW weight of the machine ca.:8,5 t dimensions of the machine ca.:3,16 x 2,15 x 2,15 m The machine does not include a chuck or tools ? the machine was originally purchased without these accessories. The G300 has X, Z, Y, C, SP, and driven tools. A bar feeder can be used, but the machine does not have one.

turning diameter:220 mm turning length:310 mm total power requirement:17 kW weight of the machine ca.:3,3 t dimensions of the machine ca.:2,25 x 1,63 x 1940 m greates pass round over bed:430 mm bore diameter:45 mm centre distance:687 mm slide travel radial ( X-axis ):160 mm slide travel axial ( Z-axis ):310 mm spindle turning speed range:0-6.300 U/min

turning diameter:220 mm turning length:700 / 665 mm total power requirement:17 kW weight of the machine ca.:2,6 t dimensions of the machine ca.:2,63 x 1,98 x 1,94 m greates pass round over bed:430 mm Part length max.:510 slide travel radial ( X-axis ):160 mm bore diameter:45 mm Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt. Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt. Copyright © 2005-2026, Josef Weber. All rights reserved.

turning diameter:145 mm turning length:210 mm total power requirement:40 kW swing diameter:145 mm Spindle bore sp. 1:56 mm Spindle bore sp. 2:56 mm swing diameter over face slide:145 mm greates pass round over bed:145 mm RPM Main Spindle:7.000 1/min number of workpiece supports:12 Shank diameter:25 mm C-axis RPM:2.000 1/min Chuck diameter spindle 1:140 mm Chuck diameter Spindle 2:140 mm Number of tools:12 fach St. Tool bore:VDI 25 Shank diameter:25 mm weight of the machine ca.:5.300 kg dimensions of the machine ca.:5.000 x 4.100 x 2.050 mm Slide path flat: X1, X2, X3: 220mm, 120mm ( 145mm ) Longitudinal slide travel: Z1, Z2, Z3: 320mm, 345mm, 380mm Vertical slide travel Y1: +/- 30mm Longitudinal spindle travel Z3: 380mm Clamping tube inner draw tube 46mm diameter Speed range main drive 1+2 up to 7,000 rpm Speed of driven tools up to 6,000 rpm Main and counter spindle collet chuck 1 axial ...

travel -x axis:800/1825 mm travel -y axis:800/460 mm travel -z axis:600 mm Feeding X,Y,Z up to:0 - 40/40/40 mm/min. swival range +/-:+10 bis -90 x 360 Grad Rotary-table:800 x 630 mm number of T-slots:5 T-slot - distance:125 mm T-Slots:18 mm center hole:30H7X15 mm swival range +/-:90 Grad turning speed:20 m/min. Number of axles:3-7 St. Spindle RPM:12.000 1/min max. tool weight:10 kg max. tool length:330 mm diameter of tools max.:80 mm tool changing time:4 sec CNC control with 15.1" color flat-screen 19" machine control panel PCU 50 with Intel Pentium II Windows XP 10.0 GB hard drive

turning diameter:356 mm turning length:700 mm y-axis:±60 mm spindle drive:18 kW counterspindle motor:15 kW Direct drive for driven tools:5,5 kW Motor starting torque:640 Nm Main spindle mount:A2-8 counter spindle mount:A2-6 Rod passage:80 mm main spindle speeds::4.000 U/min Drehzahl angetriebene Werkzeuge :6.000 U/min rapid traverse speed:30 m/min auf X- und Z-Achse machine weight ab.:5.800 kg 12-station turret, all positions driven C-axis on both spindles Belt-driven and infinitely variable drive on all motors Prismatic guideways on all axes Oil cooler for both spindles, manufacturer Daikin Automatic, dialog-guided programming system MAPPS Automatic monitoring of tool load and tool wear Two Renishaw measuring arms for automatic tool measurement Interfaces: USB, PCMCIA card, and RS-232 port Interface for bar feeder Automatic parts catcher Dual foot pedal for independent opening and clos ...

turning diameter:570 mm turning length:635 mm travel -x axis:220 mm travel -z axis:635 mm Torque:240 Nm feed::X: 20m/min; T: 24m/min disc turret:12 fach main spindle speeds::25-25.000 dimensions of the machine ca.:3210 x 1750 x 1750 mm weight of the machine ca.:5.300 t

turning diameter:x. 350 mm turning length:985 mm swing dia.:610 mm clamping range for bar work:77 mm speeds:350 - 4.000 U/min Torque:465 Nm spindle nose:A2 - 8" spindle bore diameter:88 mm chucking diameter:254 mm numbers of tools:12 travel -x axis:190 mm travel -z axis:1.025 mm rapid traverse X-axis:30 m/min rapid traverse Z-axis:33 m/min Tailstock Travel:1.010 mm tailstock taper MT:4

turning diameter:1070 mm turning length:8500 mm total power requirement:62 kW turning diameter over slide rest:800 mm spindle bore:128 mm max. workpiece weight between centers:8000 kg max. workpiece weight:12000 kg bore spindle turning speed range:1,120-01120 U/min tailstock quill diameter:200 mm dimensions of the machine ca.:12 x 2,8 x 2,4 m Machine equiped with Alan Bradley 9 series CNC control - SAUTER 6-postiion revolving head - 360 mm seld centering steady rest - 385 mm rotary work rest (used for gun barrels) - faceplate 800 mm - chip conveyor

turning diameter:480 mm turning length:1250 mm control:H 645 weight of the machine ca.:8 t dimensions of the machine ca.:5 x 2 x 2 m centre distance:1580 mm swing over bed:495 mm swing diameter:üb.Querschlitten ca.350 mm working area:1600 mm control:H645 connected load:50 kW

turning diameter:1600 mm turning length:3000 mm centre height:800 mm turning diameter over bed:1600 mm turning diameter over bed slide:1400 mm turning dia. over face-slide:1200 mm max. workpiece weight between centers:20 to speeds:5,6 -800 1/min transmission ratio:3 spindle bore:112 mm turret (x-stations):8 / VDI 60 travel -x axis:850 mm travel -z axis:3020 mm rapid power traverse in X-and Z direction:6 / 10 m/min power maindrive:46 kW weight of the machine ca.:22 to. dimensions of the machine ca.:7,2 x 4 (3,11) x 2,7 m tech-in lathe, flatbed, tailstock, 8-pos. BARUFFALDI turret with 4 live tools, power 9kW, 4-pos. BARUFFALDI square-headed turret horizontal, C-axis, 3-jaw hydr. chuck SMW Autoblock KNCS 800/165, dia. 800mm, quick adjustment, power cylinder with 2 pressure clamping system, chipconveyor, coolant device, accessories

bar material dia.:65 mm turning length:644 mm turning dia. over bed:600 mm turning diameter over slide:430 mm y-axis:100 (+-50) mm turning speeds:2x 5.000 1/min positive location each:2x C-Achse, 0,001° Grad Sub spindle:ja/yes turret (x-stations):2x 12 VDI 30 Pos. driven tools:2x 12 Pos. turning speeds:2x 4.000 1/min control:FANUC 18 iTB total power requirement:30 kVA weight of the machine ca.:8 t dimensions of the machine ca.:3,5 x 2,5 x 2,3 m turning- milling center with Y-axis, collet device on main and subspindle, high pressure pumps 2x 14bar, parts catcher/conveyor, barloader ENTL 10-65, chip conveyor, lot of accessories approx. 54.500 hours "machine on", 30.500 h "automatic", 14.000 h "feeding"
