cnc milling machine used for sale

x-travel:1660 mm y-travel:760 mm z-travel:660 mm weight of the machine ca.:8700 t dimensions of the machine ca.:4.320 x 3.380 mm distance spindlenose - table min./max.:808 mm distance work spindle /surface of the table:155 - 815 mm Machine height:2850 mm floor space required (w/o switchgear cabinet):4.320 x 3.380 mm spindle motor:11 (10 Minuten) /7,5 (30 Minuten)/ 5,5 (Dauerbetrieb) kW tool taper:SK 40 Spindle RPM:40 - 7.000 (Standard ) / 40 - 10.000 ( Option ) 1/min surface area:2.000 x 760 mm max. table load:1.000 kg feeds X-axis:1 - 5.000 mm/min rapid traverse X-axis:24.000 m/min rapid traverse Y-axis:24.000 feeds Y-axis:1 - 5.000 mm/min feeds Z-axis:1 - 5.000 mm/min rapid traverse Z-axis:20.000 m/min

spindle diameter:150 mm x-travel:10000 mm y-travel:2500 mm bore spindle stroke:700 mm Speed of boring spindles:1,25 - 1250 U/min. ram stroke:700 mm dimension of the ram:340 x 340 mm mm spindle taper ISO:50 rapid traverse:5 m/min total power requirement:120 kW weight of the machine ca.:115 t dimensions of the machine ca.:15,1 x 10 x 6,4 m CNC control Siemens 840 Dsl completely modernized 2010 FIBRO CNC drilling work table 2500 x 2500 mm 50 to. workpiece weight Longitudinal travel 2500 mm Angular milling head 4 x 90° Universal angular milling head Panel area approx. 10000 x 5000 mm Chip conveyor and coolant device Aerostatic guides

x-travel:6500/13150 mm y-travel:4000 mm z-travel:1250 mm w-axis:2250 mm table surface area:5500/12150 x 3000 mm max. workpiece weight:70.000/105.000 kg ram head dimension:480 x 510 mm milling spindle motor:63 kW max. torque on the spindle:3300 Nm tool taper:DIN 39871 AD ISO 50 milling head speed:6,3 - 4000 U/min feed speeds:1 - 24000 mm/min w-axis:1 - 6000 mm/min distance between columns:3500 mm passage:3000 mm total power requirement:120 kW weight of the machine ca.:245 t dimensions of the machine ca.:29,0 x 7,7 x 8,1 m Machine is in nearly new condition and was completely modernized in 2020! With CNC SIEMENS 840 D Automatic tool magazine for 153 tool positions Automatic milling head magazine for 6 milling heads Machining module ? straight ? straight long ? Machining module ? angle standard ? 4000 rpm, 144 x 2.5°, ISO 50 Machining module ? narrow angle extended ? 40 kW, 4000 rpm, 1800  ...

bore capacity in steel (diameter):5 - 30 mm x-travel:450 mm y-travel:380 mm total power requirement:1,4 / 2,2 kW weight of the machine ca.:1.100 kg dimensions of the machine ca.:1.000 x 1.400 x 2.900 mm gear box:85 - 2.000 U/min spindle diameter:72 mm bore depth:700 mm throat:300 mm spindle taper MT:3 T-slots:3 x 16/25 mm table-size:700 x 300 mm spindle turning speed range:85/170/250/355/475/710/1000/2000 U/min motor speeds::705/1425 Year:ca. 1975

spindle diameter:180 mm x-travel:6.000 mm y-travel:2.900 mm total power requirement:95 kW weight of the machine ca.:130 mit Zubehör t z-travel:1.250 Ram mm w-axis:1000 Spindel mm ram stroke:1250 mm dimension of the ram:450 x 450 mm bore spindle stroke:1000 mm bore spindle turning speed range:920 1/min powered rotary table: IOS 40 CNC 2 Achsen B u.V Rotary-table:3000 x 3500 mm Rotary-table: CNC-IOS 40 NC mm stepless adjustable, relative to diameter:Index 4x 90° -360000 Winkel =0,001 Grad mm travel - cross:Längs 1230 mm table load of rotary table max.:40 Tonnen clamping plate:3 x 8000 x 2000 mm CNC Ram-Type Floor Boring and Milling machine, dismantled and stored The headstock sliding guides were recoated and scraped.

spindle diameter:150 mm x-travel:10000 mm y-travel:2500 mm bore spindle stroke:700 mm ram stroke:700 dimension of the ram:340 x 340 mm spindle taper ISO:50 Speed of boring spindles:1,25 - 1250 U/min. feed speeds infinitely variable:1 - 5000 mm/min rapid traverse:5 m/min total power requirement:120 kW weight of the machine ca.:115 t dimensions of the machine ca.:15,1 x 10 x 6,4 m with CNC SIEMENS 840 Dsl complete retrofit in 2010 FIBRO CNC rotary table 2500 x 2500 mm, 50 to. loading capacity, longitudinal movement 2500 mm, angular milling head 4 x 90° universal milling head floor plate area ca. 12000 x 6000 mm ( 72 m²) chip conveyor and coolant attachment aerostatic guideways

x-travel:6500/13150 mm y-travel:4000 mm z-travel:1250 mm w-axis:2250 mm table surface area:5500/12150 x 3000 mm max. workpiece weight:70.000/105.000 kg ram head dimension:480 x 510 mm milling spindle motor:63 kW max. torque on the spindle:3300 Nm tool taper:DIN 39871 AD ISO 50 milling head speed:6,3 - 4000 U/min feed speeds:1 - 24000 mm/min w-axis:1 - 6000 mm/min. distance between columns:3500 mm passage:3000 mm total power requirement:120 kW weight of the machine ca.:245 t dimensions of the machine ca.:29,0 x 7,7 x 8,1 m The machine is in mint condition and was generally overhauled in 2020! with CNC SIEMENS 840 D autom. tool magazine for 153 tool stations autom. milling head magazine for 6 heads milling heads - straight - straight extended length - milling head -angular head standard - 4000 rpm, 144 x 2,5°, ISO 50 milling head -angular small extended length -40 kW, 4000 rpm, 1800 Nm,  ...

Auction-ID: A7-46472-22

CNC flame cutting machine BACH type ACW 2500Flame cutting machine with CNC control NBS 400Masch. No. 14 561-06 Year of manufacture 2006Cutting area 2500 x 6500 mmRaceway length 8000 mmTrack width 3345 mmHeight of the raceway 650 mm2x Machine cutting torchwith burning table; used

Machine number: 3728-87 Grinding length 2000 mm (Roll grinding machine)

Lathe - cycle VOJUS Turntec controlled 63 bearing no 1105-02244 make VOJUS type Turntec 63 built in 1999 State second-hand machine control CNC SIEMENS 840 D storage France origin SK delivery immediately cargo base EX WORK technical details turning diameter 630 mm turning length 3000 mm control SIEMENS 840 D spindle bore 110 mm spindle speeds infinitely 2500 revs/min rapid traverse - longitudinal/plan 10/5 m / min dimensions L W H 3000 x 1800 x 1790 mm turning diameter over support 420 mm overall power demand 26 kW machine weight approx. 4,5 t description CNC - control SIEMENS 840 D SHOP TURN MULTI FIXED HOLDER 1 open, revolving bezel TURNING DIAMETER OVER SLIDE 420 MM BED 6300 TURNING LENGTH 3000 MM 2500 U/MIN

MAZAK laser cutting machine STX510 MKIII 4kW TOP CONDITION - LIKE NEW - ONLY 700 RUNNING HOURS year: 2012 refurbished, MAZAK lasercutting machine with 2500W table size: 3000mm x 1500mm machine dimension 2,9m x 7,3m chip conveyor LAN / USB connection automatic nozzle change fast piercing in heavy materials piercing sensor plasma sensor for stainless steel cutting burning sensor for mild stelle cutting full covered machine table FE: 22mm VA: 15mm ALMG: 10mm plastics possible to cut incl. software incl. exhauster option: warranty, setup, training option: fully automatic loading/unloading CELL system

TOP STATE - OVERHAUL IN 2016! Year of construction: 2001 2D table format: 2500 x 1250 3D Max processing size: 900 mm x 2150 mm x 300 mm Power: 2000W Control: FANUC incl. cooler incl. 2D programming software + chamfer module + tube/profile module incl. training incl. commissioning incl. quick penetration incl. ball roller table with 3D cutting head incl. CNC tube axle tube and profile up to 160 mm diameter plates, chamfering 3D molded parts, tubes and profiles FE: up to 15mm Oxide-free VA: up to 8mm designed for high pressure cutting up to 20 bar no foundation required! Optional automatic loading and unloading by Mazak FMS48 is available always regularly serviced with warranty / commissioning / training

Technical data: Double column vertical turret lathe CNC control Siemens 802 D Weight 66 to 63 kw Dimensions 13,600 x 9,800 x 6,750 mm Faceplate diameter 3,500 mm Maximum workpiece height 2000 mm Max support adjustment 30 ° Maximum workpiece diameter 4,000 mm Maximum workpiece diameter with page support 3,750 mm Number of support 2 Max turning height 1,400 mm Maximum workpiece weight 25 to Max speed 30/min Min. speed 1/min

The LVD EHT DELTA 1250 RS TK turret punching machine was built in 1999. It is equipped with a MNC 32000 CNC control. The punching machine has a maximum pressure of 20 tons and allows the processing of a sheet with dimensions of 1250×1250 mm and a thickness of 4.5 / 6 mm. The machine performs a maximum of 650 beats per minute. The press is equipped with a hydraulic system, a turret with four stations (A, B, C, D) and a clearance adjustment sensor G8823142. Technical parameters: – CNC control: MNC 32000 – maximum pressing force: 20 tons – sheet dimensions X x Y: 1250 x 1250 mm – sheet thickness: 4.5 / 6 mm – maximum number of strokes: 650 1 / min – rated number of strokes: 300 1 / min – oil tank: 200 L – total power: 18.7 kW – engine: 11 kW – voltage: 400 V – weight: 17 tons Hydraulic System – Thick Turret: – instrumentation: station A, B, C, D  ...

Machine Details Warehouse number 1105-03536 Machine type CNC lathe - inclined bed machine Haas brand Type SL 20 THE Year of construction 2006 Control type CNC Control Haas Storage location HAGUENAU Country of origin Delivery time immediately Freight base from location Technical details Turning diameter 584 mm Turning length 533 mm Control Haas Chuck diameter 210 mm Passage 51 mm Circulation diameter 584 mm Speed 4000 rpm Power 407 Nm Power 15 KW Tool changer 12 COMPARTMENT Gear levels 0 Total power requirement 25 kW Machine weight approx. 5 t Space requirement approx. 3.3 X 2 X 1.9 H m Information CNC HAAS LINING SLIDE 210 MM+ TAILSTOCK SPAENEFOEDERER

Machine Details Warehouse number 1105-03592 Machine type lathe - cycle controlled FAT brand Type TUR 630 MN Year of construction 2011 Control type CNC Control Siemens 810D MANUAL TURN Storage location FRANCE Country of origin Poland Delivery time immediately Freight base Freely loaded from location Technical details Turning diameter 370 mm Turning length 3000 mm Top height above bed 630 mm Circulation diameter max. via face slider 370 mm Spindle bore 105 mm Spindle speeds: 2 stages 2 - 2500 rpm Tool holder REVOLVER VDI 40 Control Siemens 810D MANUAL TURN Total power requirement 18.5 kW Machine weight approx. 6 t Information Equipment: REVOLVER 8 COMPARTMENT VDI 40 Chip protection wall automatic coolant device RS 232 interface 3-jaw chuck diameter 315 mm HOLLOW SPINDLE THROUGH. 105 MM automatic lubrication system Brochure LUNETTEN 1 STUCCO

Machine Details Stock-No. 1105-03620 Type of machine CNC Lathe Make SPINNER Type TC 32 Year of manufacture 1999 Type of control CNC Storage location HAGUENAU Country of origin Germany Delivery time Immediate Freight basis ex Site Technical details turning diameter 150 mm turning length 300 mm control SIEMENS 810 D swing diameter 300 mm swing diameter over face slide 150 mm x-axis 400 mm z-axis 285 mm spindle passage 32 mm spindle motor 7.5 kW spindle turning speed - stepless 8000 rpm c-axis 0.001° Turret positions 12-speed VDI 25 work piece power 1.2 kW toolpiece turning speed range 6000 rpm weight of the machine approx. 1.8 t dimensions of the machine ca. 2 X 1 X 1.6 m Additional information CNC CONTROL SIEMENS 810 D

HACO OMATIC 130 DTRH punching machine was built in 2014 in Belgium. The machine is used to punch various size shapes and holes in workpieces weighing up to 150 kg and having a maximum thickness of 6.5, a width of 1500 mm and a length of 4000 mm. The machine operator manually operates the punching machine by loading the workpiece on the working table and changing the punching tools using a special device offered in the price of the machine. The punching process takes place on the brush table of the punching machine, which significantly reduces noise levels and adequately protects the sheet metal surfaces against various types of scratches and nicks. Depending on the choiceed mode, the machine performs between 1,000 and 1,500 punches per minute with a press force of 30 tonnes. The equipment includes amongst others a TPC 69C Graphics CNC controller for graphical programming of the desire ...

Machine Details Warehouse number 1105-03703 Machine type CNC lathe - inclined bed machine Make SOMAB Type TRANSMAB 400 Year of construction 2002 Conventional control type Control NUM 1060 T Storage location FRANCE Country of origin France Delivery time immediately Freight base EX WAREHOUSE Technical details Turning diameter 500 mm Turning length 650 mm Control NUM 1060 T Turning diameter above the face sled 240 mm Turning diameter via transverse guide 320 mm Main drive motor 18/24 kW Spindle speeds 3600 rpm Spindle passage 73 mm Chuck diameter 210 mm Tailstock cone MK 4 Total power requirement 30 kW Machine weight approx. 4 t Space requirement approx. 3.60 X 2 X 2 m Information Machine in inclined bed design with NUM 1060 CONTROL HYDRAULICK CHUK PARTS FAENGER SPAENEFOEDERER 12x revolver VDI 30

Inv. Num. : 6238 Type: HIT-250 MS Producer: HYUNDAI Created: 2004 Parameters: Control system: Siemens Sinumerik 840D turning length: 650 mm turning diameter: 390 mm Maximum turning diameter over bed: 590 mm Maximum spindle speed: 3600 1/min Maximum main spindle power: 15 kW Spindle passage: 80 mm Number of all tools: 12 pieces Number of driven tools in the turret head: 12 pieces Chuck diameter: 250 mm Axis X: 265 mm Axis Z: 660 mm Clamping diameter (counter spindle): 160 mm Spindle passage (counter spindle): 50 mm speed (counter spindle): 4500 1/min Length: 3692 mm Width: 1850 mm Height: 1850 mm Weight: 6450 kg Equipment: C-axis Technical documentation Conveyor Driven tools 2x 3-jaw chuck Cooling Complete coverage of the work area Oil mist separators Housing for clamping rotary knives and cases (8 pcs.)

Machine Details Stock number 1105-03735 Machine type CNC lathe Brand MAZAK Type QT 20 N Year of construction 1995 Control type CNC Control Mazatrol T PLUS Storage location FRANCE Country of origin Japan Delivery time immediately Freight base from site Technical details Turning diameter 440 mm Turning length 451 mm Control Mazatrol T PLUS Turning diameter via bed carriage 300 Tailstock holder MK 4 Quill stroke 130 mm Tailstock displacement 500 mm x-axis 180 mm z-axis 510 mm Spindle bore 62 mm Speed range 12-4500 rpm Total power requirement 40 KVA Machine weight ca. 4,2 t Information WITH MAZATROL T PLUS Good Macschine All prices plus VAT. VAT.. Changes and errors in the technical details and information reserved.

Machine Details Stock number 1105-03806 Machine type CNC lathe - inclined bed machine Make MONFORTS Type RNC 400 AC Year of construction 2001 Control type CNC Control SIEMENS 810 D Storage location FRANCE Country of origin Germany Delivery time by arrangement Freight base from HAGUENAU FRANCE Technical details Turning diameter 420 mm Turning length 600 mm Control SIEMENS 810 D Speed range 70 - 4000 rpm Information With C axis and driven tool holders Tool carrier disc turret VDI 40 (12pcs), bore 40 mm; Power clamping futte DIA 315 MM, chip conveyor coolant device, TAILSTOCK CNC SIEMENS 810 D 24 KW 4000 RPM good condition WITH ACCESSORIES

Universal CNC lathe BOEHRINGER NG 200 Manufacturer: BOEHRINGER Type [ type]: NG200 CNC double Control unit: Siemens 840D Year of construction[construction year]: 10/2001 Rotating diameter: 290 mm Turning length: 850 mm Control: SIEMENS 840 D Orbital diameter over bed: 600 mm Revolver 1 Revolver 2 Counter spindle Counter headstock Tailstock C-axis Powered tools Automatic machine doors – newly retrofitted Z-axis resolution: 40nm (2nm interpolated) Travel in Z: 740mm Rapid traverse speed in Z: 25 m/min Centering tip SK 30 X-axis resolution: 125nm (8nm interpolated) Travel in Z: 220mm Rapid traverse speed in Z: 25 m/min Distance between main and counter spindle: 1034mm Drive power: 30-72 kW Torque: 662 Nm Speed range max.: 4500 rpm Spindle head: Size 6/8 DIN 55026 Spindle diameter in the front. Bearing [spindle]: 120 mm Chuck diameter: 200-315mm Spindl ...

Working range: tube Ø 21,3 – 114,3 mm Wall thickness 2,3 - 11 mm Length: 6-12m Composed of two RFA14 chamfering machines with transport devices between the machines. The task of machines is to chamfer inside and outside both ends of the tubes. The range of diameters of chamfered tubes 21.3-114,3mm and wall thickness of 2.3-11mm in the length range of 6-12m. The task of transport in the area of the chamfering machines is to collect the tubes from the roller table and move them between the chamfering machines. Machine is new, never used.

Machine Details Stock-No. 1105-03860 Type of machine CNC Lathe Make MORI SEIKI Type SL 150 Year of manufacture 1996 Type of control CNC Storage location Warehouse Country of origin Japan Delivery time immediately Freight basis ex Warehouse, free on truck Price Technical details turning diameter 420 mm centre distance 580 mm Turning length max. 500 mm Travel X / Y 230 / 520 mm spindle turning speed range 50 - 5000 rpm spindle nose JIS A2-5 bar diameter round max 42 mm spindle bearing diameter 90 mm tool turret - number of stations 12 (12) Tool Taper 20 x 20 tailstock adjustment 515 mm tailstock quill diameter 85 mm tailstock quill taper MT 4 tailstock travel 120 mm Rapid Travel - Longitudinal/Face 24 / 18 m/min Coolant Tank 160 L connected load 21 kVA Weight of the machine approx. 4.1 t dimensions of the machine approx. 7.5 x 2.5 x 1.8 m Additional infor ...

Machine Details Stock-No. 1105-03874 Type of machine CNC Lathe - Inclined Bed Type Make MORI SEIKI Type SL 15 Year of manufacture 1991 Type of control CNC Storage location FRANCE Country of origin Japan Delivery time by arrangement Freight basis ex stock HAGUENAU FRANCE Technical details Travel -X AXIS 230 mm turning diameter 450 mm turning length 525 mm control FANUC 15TF Spindle Bore: Ø 42 mm Number of Turrets: 1 piece no. of tools in turret 1 12 Stück power capacity 7,5 kW spindle nose A2-5 tailstock quill taper MT 4 feed range 1 - 15000 mm/min Rapid Traverse 15 m/min Additional information Machine in good condition CONTROL FANUC 15 TF CHIP CONVOYER TAILSTOCK NICE MACHINE

Machine Details Stock-No. 1105-03882 Type of machine CNC Lathe - Inclined Bed Type Make ERNAULT TOYODA Type HES 52 Year of manufacture 1987 Type of control CNC Storage location FRANCE Country of origin france Delivery time immediately Freight basis EX WORK Technical details turning diameter 650 mm turning length 1100 mm control FANUC 10 T swing over bed 650 mm Spindle Bore 80 mm spindle turning speed range 7 - 4000 rpm transmission ratio 3 Rapid Traverse 12 m/min main drive 37 kW total power requirement 47 kW Weight of the machine approx. 12 t dimensions of the machine ca. 5 x 2.4 x 2. m Additional information 2-axes CNC-control FANUC 10 T 1 x 12-station turret VDI 50 programmable tailstock 3-jaw power chuck diameter 450 mm swarf conveyor

Machine Details Stock-No. 1105-03886 Type of machine CNC Lathe Make MAZAK Type QT 20 N Year of manufacture 1998 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery time short-term Freight basis ex works Price Technical details turning diameter 440 mm turning length 451 mm control Mazatrol T PLUS turning diameter over bed slide 300 tailstock taper MT 4 Quill Stroke 130 mm tailstock adjustment 500 mm X-AXIS 180 mm Z-AXIS 510 mm Spindle Bore 62 mm turning speed range 12-4500 rpm total power requirement 40 KVA Weight of the machine approx. 4.2 t Additional information NICE MACHINE WITH BAR FEEDER IEMCA SERCI III

Machine Details Stock number 1105-03899 Machine type: CNC lathe - inclined bed machine Make HAAS Type HL 2 Year of construction: 1997 Control type: CNC Control Haas Storage location HAGUENAU FRANCE Country of origin Delivery time: immediately Freight base from location Technical details Turning diameter 250 mm Turning length 520 mm Control Haas Chuck diameter 204 mm Passage 76 mm Swing diameter 420 mm Speed 3400 rpm Power: 407 Nm Power: 15 KW Tool changer 12 SPEED Total power requirement 20 kW Machine weight approx. 4 t Dimensions approx. 3.3 X 2 X 1.9 H m Information CNC HAAS TURRET VDI 12 POSITION LINING DIA 204 MM TAILSTOCK

TRUMPF TruPunch 3000-1300 (S11) punching machine was built in Germany in 2013. The reliable machine with extensive equipment and modern components offers its user unparalleled precision and accuracy in machining both thick and thin sheet metal. In addition to standard punching and marking, the punching machine also allows fast grooving, surface embossing, forming and chipless threading in stainless steel, structural steel and aluminium. On the machine’s sturdy and welded C” shaped structure, sits a specially designed brush table with integrated balls, designed to facilitate the loading and unloading of workpieces. The use of this type of table prevents scratches and nicks from appearing on the surface of the sheet, which results in a significant increase in the quality of the machining. During the entire production process, the sheet is held rigidly by hydraulic clamps fixed to th ...

Key data: 600 mm, 1250 mm, 3000 1/min

Machine Details Stock-No. 1105-03939 Type of machine CNC Lathe - Inclined Bed Type Make GILDEMEISTER DMG Type NEF 600 Year of manufacture 2006 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Germany Delivery time immediately Freight basis EX WORK Price Technical details turning diameter 600 mm turning length 1250 mm control SIEMENS 840 D greates pass round over bed 600 mm centre height 350 mm Spindle Bore 92 mm turning speed range 3500 rpm Rapid Travel - Longitudinal/Face 20 m/min face stroke 400 mm tailstock quill diameter 100 mm Tailstock Quill Stroke 1150 mm tailstock taper MT 5 Turret (X-Stations) 12 turning diameter over slide 410 mm Additional information Acc. 3-Jaw Chuck 315 mm, tailstok turret 8 P ,chip conveyor, coolant CNC Siemens 840 D

CITIZEN CINCOM A20 VIPL CNC lathe built in 2006 ensures the highest precision and efficiency in the production process. During machining, the specially designed bed with its rigid structure and high thermal stability effectively reduces the heat impact, resulting in increased machine life and reliability. All of this, combined with a modular design with a reduced number of parts, makes the CINCOM A20 VIPL CNC lathe ideal for various types of production. Workpieces with a maximum diameter of 20 mm and a length of 135 mm are machined in 7 axes by a powerful main spindle which is synchronised with an AC motor, forming an electrospindle. A bushing driven by a separate AC motor is also synchronised with the machine’s main spindle. The operator’s panel consists of an intuitive FANUC 32i CNC controller, a memory card slot and an electronic wheel located next to the monitor designed to ch ...

Technical information Swing over bed 420 mm Distance centre tot centre 1000 mm Max longitudinal travel Z-axis 1028 mm Max cross travel X-axis 335 mm Spindle coneA2-6 Dia of spindle bore 56 mm Power on the spindle20/25 hp Number of speeds16 - 4000 rpm CommandMazatrol Cam T3 Total power needed18,5 kW - 32,9 kVa Length 3734 mm Width 1893 mm Height 2401 mm Weight 4400 kg Toolchanger yes Number of tools 16x - rotating yes milling tools C-axis Robo flex automatic loading system tooling included Measuring arm included MAZATROL CAM T-3 CNC Accessories Tailstock, Evoquator, Tool Attachments, Presetting Machine weight 4700 kg Axis C Yes

KNUTH PICO TURN CNC lathe built in 2015 in Germany is the ideal choice for small-scale industries focused on unit and small batch production. Due to its extensive machining capabilities, sturdy design and high productivity, this compact size machine performs excellently in, among others, precision arc turning, threading and longitudinal and transverse workpiece turning. All operations are performed by a powerful spindle with variable speed adjustment between 150 and 1750 rpm. The KNUTH PICO TURN CNC lathe is additionally equipped with, among others, an automatic 4-position tool changer, an intuitive SIEMENS SINUMERIK 808D CNC controller and a 3-jaw chuck with a diameter of 125 mm. The total weight of the machine is 400 kg. Technical specifications of the KNUTH PICO TURN mini metal lathe machine - feed rates in the X/Z axis: 500/250 mm - rapid traverse in the X/Z axis: 2000/1000 mm/m ...

CNC lathe GILDEMEISTER CTX ALPHA 300 with bar feeder and parts pick-up device Built in 2010 in good condition. Duty Cycle: 22930 Hours: 7326 Control Heidenhain CNC-Pilot 640 Circulation over bed: 380 mm Circulation via face slide: 290 mm Spindle bore: 73 mm Flat travel ( X ) : 190 mm Longitudinal travel ( Z ) : 335 mm Speed max. 6000 rpm C-axis 360° Number of driven tool stations 12 pos. Tool holder VDI 30 Accessories: 3 jaw chuck hydraulic 170 mm Conveyor Coolant system Hydraulic hollow clamping device Tool drive C-axis Parts pick-up device Bar Feeder Irco RBK10012 Tailstock

MAZAK laser cutting system NTX510 1, 5kW Year of construction: 2000 very well preserved, fully reconditioned MAZAK laser machines with 1500W Panel sizes: 3000 mm x 1500 mm minimal footprint by 2, 9 m x 7 m Small part conveyor completely encapsulated engine cover FE: up to 12 mm VA: up to 6mm Plastic can incl. software including warranty incl. extraction system incl. commissioning + training = optional with automatic loading and unloading.

Key data: 500 mm, 700 mm, 3500 1/min

Make: Spinner Model : TC 110 SMCY Control Siemens 840 D ShopTurn Year of construction 2006 Specifications: Turning diameter 500 mm Circulation diameter 690 mm Turning length 900 mm Y-axis -55/+65 mmmm C-axis 0.001° Spindle passage main spindle 110 mm Spindle passage counter spindle 66 mm Main spindle motor 28 kw High-speed main spindle 3200 rpm. Counter spindle speed 5000 rpm. Rapid traverse x/y/z 24 m/min. Sauter Star Revolver VDI 50 Number of stations 12-fold Driven tools 12 Speed driven tools 4000 rpm. Machine weight approx. 7800 kg Dimensions set-up (L x W x H) with chip conveyor 5500 x 2200 x 1800 mm Accessories: automatic pick-up device Measuring arm Bar feeder preparation Conveyor 3D Renishaw Probe Coolant gun Increased coolant pump Hainbuch Collet Chuck for Main Spindle 3 Jaw chuck counter spindle Various tool holders Documentation

Key data: 600 mm, 1250 mm, 3500 1/min

Machine Details Stock-No. 1105-03997 Type of machine CNC Lathe - Inclined Bed Type Make GILDEMEISTER DMG Type NEF 600 Year of manufacture 2007 Type of control CNC Storage location HAGUENAU Country of origin Germany Delivery time immediately Freight basis EX WORK Price Technical details turning diameter 600 mm turning length 1250 mm greates pass round over bed 600 mm centre height 350 mm Spindle Bore 92 mm turning speed range 3500 rpm Rapid Travel - Longitudinal/Face 20 m/min face stroke 400 mm tailstock quill diameter 100 mm Tailstock Quill Stroke 1150 mm tailstock taper MT 5 Turret (X-Stations) 12 turning diameter over slide 410 mm Additional information acc.: hydr. 3-Jaw Chuck 400 mm, Chip Conveyor, Coolant CNC FANUC 210 IS

Key data: 320 mm, 600 mm, 3500 1/min

Stock-No. 1105-03841 Type of machine CNC Lathe - Inclined Bed Type Make LEADWELL Type LTC 20 Year of manufacture 1990 Type of control CNC Storage location HAGUENAU FRANCE Country of origin taiwan Delivery time by appointment Freight basis EX WORK Price Technical details turning diameter 300 mm turning length 600 mm control Fanuc O- T Travel -X Axis 175 mm Spindle Bore: Ø 50 mm Number of Turrets: 1 piece No. of tools in turret 1 12 pieces power capacity 11/15 kW spindle nose A2-6 tailstock quill taper MT 4 feed range 1 - 15000 mm/min Rapid Traverse 12 / 15 m/min total power requirement 30 kW Additional information CNC FANUC OT turret 12 tols TAILSTOCK CHUCK Chip Convoyer

MAZAK laser cutting system STX510 MKII 2, 5kW very well preserved, fully reconditioned MAZAK laser machines with 2500W Panel sizes: 3000 mm x 1500 mm minimal footprint by 2, 9 m x 7, 3 m Small part conveyor Ball roller table completely encapsulated engine cover casting bed, no foundation necessary FE: up to 20mm VA: up to 10mm ALMG: up to 8mm Plastic can including CAD / CAM software 2018 version including warranty incl. commissioning + training To test power ready to delivery ready to use = optional with automatic loading and unloading MAZAK CELL =.

Key data: 300 mm, 500 mm, 4000 1/min

Machine Details Stock-No. 1105-04001 Type of machine CNC Lathe - Inclined Bed Type Make HARDINGE Type CONQUEST T 51 Year of manufacture 1997 Type of control CNC Storage location HAGUENAU FRANCE Country of origin UK Delivery time Immediatly Freight basis ex warehouse, loaded Technical details turning diameter 300 mm turning length 500 mm control fanuc 18 T max. swing diameter 400 mm spindle head A 2-5 Bar Material Dia. 51 mm turning speed range 4000 rpm spindle drive 11/15 kW Torque 168 Nm Tool Diameter 32 mm Rapid traverse 30 m/min total power requirement 15 kW weight of the machine approx. 3.2 t dimensions of the machine approx. 2.0 x 1.7 x 1.8 m Accessories cooling attachment Additional information FANUC 18T CONTROL 3 JAWE CHUCK + taistock CHIP CONVOYER

Key data: 530 mm, 500 mm, 4000 1/min

Machine Details Stock-No. 1105-04005 Type of machine CNC Lathe Make COLCHESTER Type TORNADO 300 Year of manufacture 1995 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Great Britain Delivery time immediately Freight basis EX WORK Price Technical details turning diameter 530 mm turning length 500 mm control FANUC OT total power requirement 22 kW weight of the machine approx. 3.3 t Additional information GOOD MACHINE CNC CONTROL FANUC OT Cuck Taikstock VDI 40 Turret 12 P Chip Convoyer echnical information Swing over bed 530 mm Swing over cross-slide 330 mm Distance centre tot centre 500 mm Max longitudinal travel Z-axis 20 m/min Max cross travel X-axis 10 m/min Spindle cone A2-8 Dia of spindle bore 90.5 mm Power on the spindle 22 kW Number of speeds 4000 rpm Command Fanuc Total power needed 53 kVa Length 3500 mm Wid ...

Fiber laser machine HLF Power: 4kW Sheet size: 3000 x 1500 mm Changing table Siemens touch screen controller with LAN/USB Siemens drives Precitec auto focus Pro cutter cutting head IPG resonator with 4kW is included: Warranty CAD CAM software Commissioning DTL delivery Training offered

GILDEMEISTER NEF Plus 500 CNC lathe was manufactured in 1997. The machine, designed for precision machining of workpieces with a maximum diameter of 500 mm, has two spindles (main spindle and sub-spindle) of high speed and power, which will improve even the most intensive machining. The installed GRUNDING CNC controller with colour screen and control panel also allows for cycles to control. The total weight of the machine is approximately 3000 kg. Technical specifications of the GILDEMEISTER NEF Plus 500 lathe - CNC control: GRUNDIG - maximum turning diameter (over bed): 500 mm - maximum turning diameter (over saddle): 290 mm - maximum turning length: 1500 mm - main spindle rotational speed range: 80-2800 rpm - main spindle passage: 70 mm - main spindle drive power: 11 kW - maximum sub-spindle rotational speed: 5000 rpm - sub-spindle drive power: 7.5 kW - total power require ...

Key data: 500 mm, 1000 mm, 5000 1/min

Machine Details Stock-No. 1105-04017 Type of machine CNC Lathe - Inclined Bed Type Make MAZAK Type SQT 200 L Year of manufacture 2003 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery time Immediatly Freight basis Ex site Price Technical details turning diameter 360 mm turning length 1000 mm control MAZATROL FUSION 640 T swing diameter 350 mm spindle turning speed - stepless 5000 rpm Spindle Motor 15 kW Bar Material Dia. 51 mm X-Axis 190 mm Z-AXIS 1000 mm weight of the machine approx. 5 t dimensions of the machine approx. 3.6 x 1.8 x 2.0 m Accessories 12 - Tool Turret Tool - Eye tailstock

Key data: 500 mm, 450 mm, 6000 1/min

1 used CNC lathe Make Gildemeister Model CTX 320 V5 Linear Year of manufacture 2004 Control Siemens 840 D ( ShopTurn ) Workspace: Max. circulation diameter over bed 500 mm Circumferential diameter via X-carriage 300 mm Turning length 450 mm Bar passage 60 mm Chuck diameter 170 mm Chuck diameter sub-spindle 165 mm Plane stroke 160 mm Rapid traverse X/Z axis 60/45 m/min Power main drive (100% ED) 16 kW Speed range 6000 rpm Power sub-spindle (100% ED) 7.5 kW Speed range 6000 rpm Number of tool stations 12 Cylindrical shank diameter 30 mm Number of driven tools 12 Drive power (40% ED) 10 kW RPM, max. 5000 min-1 C-axis speed range 0 - 200 min-1 C-axis positioning 0.001 degrees Connected load, total approx. 32 kVA Net weight with chip conveyor approx. 4300 kg Machine with chip conveyor L x W x H 3890 x 1555 x 1890 mm Accessories: Conveyor Pa ...

Key data: 350 mm, 700 mm, 4000 1/min

Machine Details Stock number 1105-04023 Machine Type: CNC Lathe - Inclined Bed Machine Make GILDEMEISTER Type NEF400 / 840D Shopturn Year of construction 2006 Condition Control type: CNC Control Siemens 840D Shopturn Storage location FRANCE Country of origin Germany Delivery time immediately Freight base from Dreieich warehouse Price Technical details Turning diameter 350/270 mm Turning length 700 mm Control Siemens 840D Shopturn Circumferential diameter max. over bed cover 400 mm Travel - z 700 mm Spindle bore 65 mm Spindle speeds max. 4000 rpm Tool holder VDI 30 Turret head 12 pos. Three-jaw chuck diameter 200 mm Spindle holder A6 DIN55026 Pick-up cone in the tailstock quill MK 3 Drive power 15/12 kW Operating voltage 400 V Machine weight approx. 3.0 t Information - Control: Siemens 840D Shopturn - Tool holder VDI 30 APPROX. 12 PIECES - Coolant de ...

Control Fanuc ... i Series Turning diameter ... 600mm Turning length ... 330mm Inclined bed Spindle bore ... 61mm Turret Circumferential diameter over bed ... 600mm Circumferential diameter via support ... 400mm Axis X ... 205mm Axis Z ... 340mm Rapid traverse of the X axis ... 30m/min Rapid traverse of the Z axis ... 36m/min Spin speed... 0-6000 rpm. Max. spindle torque ... 127Nm Main engine power ... 11/15kW Doosan Robot Cell Assembly: 2x LYNX 2100A + ROBOTEC APC7 (Fanuc AM-100 iC6L) - The machines are supplied with chucks and pliers - High pressure cooling 20bar - Arm for picking up workpieces (Ø65 x L130 mm, weight 3 kg) - Automatic door opening - Spindle bladders for cleaning the clamping jaws - Oil separator - OIL SKIMMER - Tool Load Monitor (works with X-, Z-axis and S-spindle) - Workpiece conveyor The machine is in good condition, possible to test un ...
