cnc machine used for sale

Ø plateau: 1250 mm Top speed: 500 rpm - 2 ranges Ø false plateau: 1450 mm Maximum piece: 1550 mm Maximum height of the piece: 1200 mm RAM stroke: 800 mm Crossbar stroke: 850 mm Tool warehouse: 10 ATC CNC Siemens 810 D

Ø board: 1250 mm Maximum turnerable: 1500 mm Useful height: 1355 mm Vertical crossbar stroke: 800 mm Ram vertical stroke: 1000 mm Toolholder number: 15 Table pruned: 12000 kg CNC Tesla NS 642 C Fast: 8 m/min Power: 40 kW Weight: 27.2 ton

Very high-quality CNC – controlled precision sheet metal bending machine with automatic bending sequence calculation - automatic CNC – controlled double-sided pre-bending - Conical bending device - three hydraulically driven rollers (one hydraulic motor per roller) - hydraulic linear under-roll adjustment - hard chrome-plated piston rods - hardened and ground rollers - PILZ® laser protection - BECKHOFF® CNC control with Ethernet technology and large touch screen - DANFOSS® precision hydraulics - Central lubrication system

Very high-quality CNC – controlled precision sheet metal bending machine with automatic bending sequence calculation – automatic CNC – controlled double-sided pre-bending – conical bending device, three hydraulically driven rollers (one hydraulic motor per roll), hydraulic linear sub-roll adjustment – hard chrome-plated piston rods – hardened and ground rollers - PILZ® laser protection - BECKHOFF® CNC – control with Ethernet technology and large touch screen - DANFOSS® precision hydraulics – central lubrication system Maximum bending length 2,000 mm Roll diameter 170 mm Smallest weft diameter = 1.1 x the roll diameter The rollers run in bronze plain bearings. Nominal pre-bending performance over the entire bending length at 5 x D = 5 mm for sheet steel/ST40 Nominal bending performance over the entire bending length at 5 x D = 7 mm sheet steel/ST40 Drive power  ...

Very high-quality CNC – controlled precision sheet metal round bending machine with automatic bending sequence calculation – automatic CNC – controlled double-sided pre-bending – conical bending device, three hydraulically driven rollers (one hydraulic motor per roll), hydraulic linear sub-roll adjustment – hard chrome-plated piston rods – hardened and ground rollers - PILZ® laser protection - BECKHOFF® CNC – control with Ethernet technology and large touch screen - DANFOSS® precision hydraulics – central lubrication system Maximum bending length 2,000 mm Roll diameter 170 mm Smallest weft diameter = 1.1 x the roll diameter The rollers run in bronze plain bearings. Nominal pre-bending performance over the entire bending length at 5 x D = 5 mm for sheet steel/ST40 Nominal bending performance over the entire bending length at 5 x D = 7 mm sheet steel/ST40 Drive  ...

x-travel: 600 mm y-travel: 350 mm z-travel: 140 mm table surface area: 700 x 300 mm spindle taper ISO: 40 spindle turning speed range: 100 - 4000 U/min distance spindle center to column: 395 mm distance spindle nose and table: min. 170 -max. 550 mm control: TNC 407 milling feeds: 3 + 2000 mm/min rapid traverse: 5000 mm/min spindle drive: 5,5 kW total power requirement: 9 kW weight of the machine ca.: 1,9 t dimensions of the machine ca.: 2,5 x 1,8 x 2,2 m • control HEIDENHAIN TNC 407, The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1000 mm swing diameter: 1400 mm turning height: 1400 mm control: SIEMENS 850M total power requirement: 125 kW weight of the machine ca.: 38 t dimensions of the machine ca.: m Stocknumber 1020042 Type of machine CNC VTL Make PIETRO CARNAGHI Type AC 10 CNC Build in 1987 Type of control Siemens 850 M/E Faceplate diameter 1000 mm Max. Swing diameter 1400 mm Turning height max. 1400 mm Total Power (KW) totaal 125 Lenght (mm) 11000 Width (mm) 8000 Height (mm) 6000 Weight 38000 kg Additional information with driven tools with pallet changer The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer Producer Saacke Typ type UW2 CNC Year of construction Construction year 1989 Steuerung control Sinumerik Machine size machine size 3500x3000x2500 mm Spannung Voltage 400 V Machine weight machine weight approx. 2.5 t

grinding diameter: 5 - 255 mm grinding length: 300 mm centre height: 130 mm grinding length at plunge grinding: 50 mm control: SINUMERIK 805 grinding spindle speed: 25 - 1400 U/min work piece spindle speed: 0 - 500 U/min feed of grinding spindle slide cross: 0 - 5000 mm/min table speeds: 0 - 5 m/min grinding wheel diameter: 450 mm total power requirement: 10 kW weight of the machine ca.: 2,3 t dimensions of the machine ca.: 2,65 x 2,2 x 2,35 m Accessories: grinding wheel with flange, 3-jaw chuck, electron. hand wheel The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CNC - Sheet Metal Parts - Roll Straightening Machine for plane straightening and relaxing of thermally cut sheet metal parts, for stamped parts, for sheet metal parts that have been cut to size with the sheet shear. Our roller straightening machine is a purely electric machine, not hydraulics, the electronically controlled servo motors enable automatic CNC – controlled face straightening in the continuous process. CNC – controlled precision sheet metal parts roll straightening machine for sheets from 0.7 mm to a maximum of 14 mm sheet thickness at 500 mm sheet width Largest sheet width 1,500 mm Guideline power over the full width - - Steel sheet quality SR235 from 0.7 mm to 10 mm - Stainless steel sheet from 1 mm to 6 mm Planning by - 19 piece straightening rollers with Ø 50 mm 21 pieces of intermediate rollers with Ø 30 mm 13 pieces of support roller sets with ...

CNC - Sheet Metal Parts - Roll Straightening Machine for plane straightening and relaxing of thermally cut sheet metal parts, for stamped parts, for sheet metal parts that have been cut to size with the sheet shear. Our roller straightening machine is a purely electric machine, not hydraulics, the electronically controlled servo motors enable automatic CNC – controlled face straightening in the continuous process. CNC – controlled precision sheet metal parts roll straightening machine for sheets from 0.7 mm to a maximum of 14 mm sheet thickness at 500 mm sheet width Largest sheet width 1,500 mm Guideline power over the full width - - Steel sheet quality SR235 from 0.7 mm to 10 mm - Stainless steel sheet from 1 mm to 6 mm Planning by - 19 piece straightening rollers with Ø 50 mm 21 pieces of intermediate rollers with Ø 30 mm 13 pieces of support roller sets with ...

Very high-quality CNC – controlled precision sheet metal bending machine with automatic bending sequence calculation – automatic, CNC – controlled double-sided pre-bending – conical bending device Roll diameter 350 mm Smallest weft diameter 1.1 x the roll diameter = 385 mm Maximum bending length 3,000 mm Nominal pre-bending performance over the entire bending length at 5 x D = 18 mm for sheet steel/ST40 Nominal bending performance over the entire bending length at 5 x D = 22 mm sheet steel/ST40 Drive power 22 kW Weight 13,500 kg. Three hydraulically driven rollers (one hydraulic motor per roller) - The rollers run in bronze plain bearings Hydraulic linear sub-roller adjustment Hard chrome-plated piston rods Hardened and ground rollers PILZ® Laser Validation BECKHOFF® CNC – Control with Ethernet technology and large touch screen DANFOSS® Precision Hydraul ...

Very high-quality CNC – controlled precision sheet metal bending machine with automatic bending sequence calculation – automatic, CNC – controlled double-sided pre-bending – conical bending device Roll diameter 350 mm Smallest weft diameter 1.1 x the roll diameter = 385 mm Maximum bending length 3,000 mm Nominal pre-bending performance over the entire bending length at 5 x D = 18 mm for sheet steel/ST40 Nominal bending performance over the entire bending length at 5 x D = 22 mm sheet steel/ST40 Drive power 22 kW Weight 13,500 kg. Three hydraulically driven rollers (one hydraulic motor per roller) - The rollers run in bronze plain bearings Hydraulic linear sub-roller adjustment Hard chrome-plated piston rods Hardened and ground rollers PILZ® Laser Validation BECKHOFF® CNC – Control with Ethernet technology and large touch screen DANFOSS® Precision Hydraul ...

Very high-quality CNC – controlled precision sheet metal bending machine with automatic bending sequence calculation – automatic, CNC – controlled double-sided pre-bending – conical bending device Roll diameter 350 mm Smallest weft diameter 1.1 x the roll diameter = 385 mm Maximum bending length 3,000 mm Nominal pre-bending performance over the entire bending length at 5 x D = 18 mm for sheet steel/ST40 Nominal bending performance over the entire bending length at 5 x D = 22 mm sheet steel/ST40 Drive power 22 kW Weight 13,500 kg. Three hydraulically driven rollers (one hydraulic motor per roller) - The rollers run in bronze plain bearings Hydraulic linear sub-roller adjustment Hard chrome-plated piston rods Hardened and ground rollers PILZ® Laser Validation BECKHOFF® CNC – Control with Ethernet technology and large touch screen DANFOSS® Precision Hydraul ...

Manufacturer GER Model SR150-60 CNC Year 2007 FAGOR 8055i CNC Fixing area on table 1,800 x 550 mm Useful ground surface 1,500 x 680 mm. Longitudinal travel of the table 1,660 mm. Maximum weight on the table 1,700 kg. Automatic cross travel 600 mm. Max. distance from table to center of wheel 625 mm. Variable infinite table speed 2-28 m/min. Cross-table speed 0.02 – 5 m/min Vertical table speed 0.02 – 2 m/min Infinite table speed regulation INCLUDED Maximum width to be ground with a grinding wheel of 80 mm 680 mm. Minimum CNC programmable increment 0.001 mm Spindle speed 1,500 rpm Main motor power spindle 12 kW Total machine power 22 kW Wheel dimensions Ø 400x80x127mm. FAGOR 3-Axis Servo Motors and Regulators (X, Y, Z) included High-density electromagnetic plate INCLUDED Dimensions of the electromagnetic plate 1,500 x 600 mm. Coolant Filtration Equipmen ...

FRORIEP CNC Vertical Boring Mill Double Column REBUILT & CNC RETROFIT IN 1999 FEATURES: SIEMENS 840D CNC CONTROL 2-VERTICAL RAM HEADS CAPACITY: TABLE DIAMETER: 10,000mm TURNING DIAMETER WITH VERTICAL RAMS: 15,000mm MAXIMUM TURNING HEIGHT: 5000mm RAM VERTICAL TRAVEL: 2000mm RAM SWIVEL +/- 30/15 DEG MAXIMUM CUTTING FORCE RIGHT RAIL HD: 25t TABLE LOAD CAPACITY: 200t TABLE SPEED RANGES, INF VARIABLE: 4 TABLE SPEEDS: 0.13 TO 13 RPM CROSS RAIL ELEVATION MOTOR: 40.23 HP NUMBER OF FEEDS, VERTICAL & HORIZ: 30 CROSS RAIL ADJUSTMENT MOTOR 86 HP RAPID TRAVERSE MOTORS: 15.5 HP MAIN MOTOR: 250 HP EQUIPPED WITH: SIEMENS 840D CNC CONTROL NEW 1999 DUAL PENDANT OPERATED CONTROLS 2-VERTICAL CNC CONTROLLED RAMS 10,000mm DIAMETER T-SLOTTED TABLE 4-HEAVY DUTY FACE PLATE TYPE JAWS HYDROSTATIC BEARING SYSTEM FOR TABLE DUAL OPERATORS PLATFORMS DUAL JORGANSEN CHIP CONV ...

X=3500mm Y=2000mm Z=1250mm W=800mm H=360° spindle 130 mm, ISO 50, max. 1600 rpm table 1600 x 1800 mm with a load of 12000 kg with Siemens electric and CNC Heidenhain TNC 415B Oil cooled: Schimpke. Dismantled. The machine has been used very little = in very good technical condition.

Bandsaw machine manufactured in 2015. This Pegas HERKULES X-CNC 300x300 features a maximum cutting diameter of Ø 300 mm and is equipped with a powerful 6.5 kW motor. The machine dimensions are 1500 × 1000 × 1900 mm, and it weighs approximately 1,420 kg. If you are looking to get high-quality cutting capabilities, consider the Pegas HERKULES X-CNC 300x300 machine we have for sale. Contact us for further details.

CSM CNC38TBRE tube and profile bending machine was built in 2008 in China by CHIAO SHENG MACHINERY CO., LTD. The machine is designed for the precision bending of tubes, profiles and bars with a maximum diameter of 38 mm. It enables the production of parts with various shapes and bending radii, used in many industries. A maximum bending angle of 190°, combined with a wide range of bending radii, enables the production of both tight bends and parts with larger bending radii. Bending accuracy of ±0.01° ensures high precision and repeatability of the workpieces. The CSM CNC38TBRE is equipped with an intuitive CNC controller that facilitates day-to-day operation of the machine. The control system features a large memory capacity, allowing numerous user programmes to be stored. The CSM CNC38TBRE tube bending machine weighs 2500 kg. Technical specifications of the CSM CNC38TBRE tube be ...

This 4-axis HUBER River 600 CNC was manufactured in 2017. It features a traverse of 600 x 400 mm in the X and Y directions, and a Z-axis travel of 300 mm. The machine accommodates electrode diameters ranging from 0.3 to 3.0 mm. If you are looking to get high-quality small hole drilling capabilities, consider the HUBER River 600 CNC die-sinking EDM machine we have for sale. Contact us for further details.

CNC centerless grinding machine Monzesi mod Monza 510 CNC 6 axes complete with piece loading and unloading system CNC Fanuc 160i-T Under power in our warehouse in Gussago BS. Mimu machine tools Italy

ORT 3RP48 CN CNC / PLC thread rolling machine scaffolding sleeves threading, shelves studs threading electronic overhaul/retrofit Under power in our warehouse in Gussago BS. Test run possible Mimu Machine Tools

DIEDESHEIM vertical lathe Vertifront 120-12 CNC. Electrics and geometry overhauled in 2007 for approx. 290.000,00 €! Former machine of the company Hoesch Rothe Erde Lippstadt, permanently maintained and maintained. Equipped with two turret supports (5-fold), protective hoods against emulsion vapors, housing see pictures, CE compliant. Details: Type 120-12 CNC Machine number L738 Year of construction 1983 Refurbished 2007 Space requirement approx. 20 sqm Weight approx. 20 to Power consumption approx. 110 kW Headstock Main spindle bearingsØ axial 500 mm radial 240 mm Cross Slide Unit Vertical slide stroke 800 mm (Z-axis) Paddling slide stroke 1,000 mm (X-axis) Basic hydraulics complete, system RING 2x2 axis CNC path control SIEMENS Sinumerik 3 TT Optional accessory 6-fold face plate clamping ideal for thin-walled workpieces ...

Basic features: X axis travel: 6.000 mm Y axis travel: 900 mm Z axis travel (vertical travel): 2000 mm automatic head index 2,5° spindle speed 3.300 rpm spindle taper ISO 50 stolle floor: 7000x1500 mm - nr. 6 T-slots rotary table B axis 360 positions - 5 ton load capacity CNC Heidenhain TNC 426 chip conveyor ATC 60 Total power: 60 kW - 380 V machine in excellent conditions, ready to work. NB: The aforementioned technical data, taken from the manufacturer's technical data sheet, are to be considered non-binding and subject to change without notice.

This 4-axis TOS WHN 9 B CNC boring machine was manufactured in 2007. It features a cross travel of 1370 mm and a longitudinal travel of 1130 mm, with a table clamping surface of 1120 x 990 mm. The machine is equipped with a spindle diameter of 90 mm and a spindle speed range of 9–1120 rpm. If you are looking to get high-quality boring capabilities, consider the TOS WHN 9 B CNC machine we have for sale. Contact us for further details.

This 4-axis TOS WH 10 CNC boring machine was manufactured in 1996. It features a longitudinal travel of 1250 mm, transverse feed of 1100 mm, and vertical travel of 950 mm. The machine has a robust table size of 1000 x 1120 mm and a maximum table load capacity of 3000 kg. If you are looking to get high-quality boring capabilities, consider the TOS WH 10 CNC machine we have for sale. Contact us for further details.

Horizontal turning machine manufactured in 2000. This ZPS S-60 CNC features a maximum machining diameter of 430 mm and a maximum machining length of 750 mm. It offers X/Z-axis travel of 275/820 mm and a spindle speed range of 20 to 3,500 rpm. If you are looking to get high-quality turning capabilities, consider the ZPS S-60 CNC machine we have for sale. Contact us for further details.

CNC Tube Bending Machine manufactured in 2018. This CANSA CNC 51 R1 features a maximum tube diameter of 51 mm and a maximum wall thickness of 4 mm. It includes a mandrel and part configuration software for enhanced bending capabilities. If you are looking to get high-quality bending capabilities, consider the CANSA CNC 51 R1 machine we have for sale. Contact us for further details.

grinding length: 900 mm grinding width: 510 mm workpiece height: 400 mm table surface area: 800 x 400 mm longitudinal feed of the table: max. 980 mm table speed -stepless-: 1 - 35 m/min grinding wheel size: 355 x 51 x 127 mm cross feed of the table: 460 mm cross feed: 1 - 40 mm/Hub vertical feed autom.: 0,005 - 0,04 mm/Hub rapid traverse vertical: 0,5 m/min grinding spindle speed: 1450 U/min grinding spindle drive: 5,6 kW table load capacity: max. 1000 kg total power requirement: 10 kW weight of the machine ca.: 4,4 t Accessories: magnetic plate 800 x 400 mm, various grinding wheels with and without flanges, wet grinding attachment with paper band filter The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

dimensions of the machine ca.:3,5 x 2,0 x 2,5 m

pulling force - max.:100 t total power requirement:87 kW weight of the machine ca.:51 t dimensions of the machine ca.:95 m² m working stroke:2750 mm max. helix angle:+/- 30 ° Working stroke: 2750 mm

MAX CAPASITY 20 T

centre height:500 mm centre distance:2000 mm control:CNC Grundig Numerik total power requirement:400 V, 50 Hz, 22,5 kW weight of the machine ca.:3300 kg dimensions of the machine ca.:2500 x 4000 x 2400 mm

Gantry milling machine GMB 2560 CNC Manufacturer: Fermat GC: 2023 Control Heidenhain ... TNC 640 Table dimensions ... 6000 x 2500mm Axis X ... 6000mm Distance between stand... 3200mm Passage between .dem table and crossbar... 1900mm ISO 50 Spindle speed ... 40-5500 rpm. Max. table load ... 22000kg Axis Y ... 3200mm Axis Z ... 1250mm Machine weight... 88000kg Main engine power ... 41kW Rapid traverse... 10m/min Total Power Requirement ... 83kVA Average of the grinding piece ... 500x450mm The machine is in good condition, possible to test under electricity.

table diameter: 200 mm workpiece height: 100 mm number of wheels: 1 Control: Robot CNC total power requirement: 6 kW weight of the machine ca.: 1,8 t dimensions of the machine ca.: 1,83 x 2,04 x 2,1 m Technical data - Grinding capacity : Ø 0.025 –12.7 [mm] - Bar diameter : Ø 1.0 –12.7 [mm] - Grinding length : W15 (option W20) - Z-axis : 35[mm] Resolution : 0.5 [µm] – X- axis : 25 [ mm] Resolution : 0.1µm – Y-axis : 286[mm] Resolution : 0.5µm – U- axis : 15 [mm] Resolution : 0.1µm Head Motor: 0.70 [kW] Rotation: 300 – 3000 [rpm] Grinding - Raw grinding : 1.5 [kW] Spindle : Ø 60 [mm] Grinding wheel diameter : Ø 200 [mm] Cutting speed : 30 m/sec. - Completion: 0.75 [kW] Spindle: Ø100 [mm] Grinding wheel diameter: Ø150 [mm] Cutting speed: adjustable - Dimensions (L x W x H): 1830 x 2040 x 2100 mm - Weight: approx. 1800 [kg] Accessories - Loading and unloading robots - F ...

MAX DIAM 450 . MAX LENGHT 1600

X-axis: 500 mm Y-axis: 400 mm Z-axis: 400 mm Table dimensions: 700 x 425 mm Spindle Exception: SK 40 Spindle speeds: 1 - 4000 rpm. Spindle stroke: 60 mm Equipped with: - ISO tool holders - Coolant system -Operating instructions Country of origin: Germany Motor power: 5 kW Machine LxWxH: 200 x 200 x 200 cm Machine weight: 2000 kg

CNC controlled three-axis under-table cross-cut saw with additional drilling unit for wood and wood-like materials, but also suitable for sawing aluminium non-ferrous metals and plastics. Closed compact production island, low noise pollution and no chips in the machine environment. Our automatic sawing and drilling machine KA 550 CNC - SAW and DRILL is versatile einsetzbar_ – Only saws in automatic mode and for single cuts - Drilling only - Combines drilling and sawing in a single operation The possibilities to work with the drilling unit include drilling and countersinking, combined drilling + countersinking with a combination tool, drill milling of longitudinal holes – longitudinal holes transversely – rectangular cut-outs. The drill feed speed and the drilling pressure can be sensitively adjusted. Technical data Circular Saw and Drilling Machine KA 550 CNC - SAW an ...

turning diameter: ca. 500 mm swing diameter: ca. 600 mm travel -x axis: ca. 400 mm travel -z axis: ca. 600 mm spindle turning speed range: 2000 U/min spindle drive: 63 kW control: SIEMENS control: SINUMERIK System 3 tool turret: 1 x 12 Pos total power requirement: kW weight of the machine ca.: 9,3 t dimensions of the machine ca.: m - R-version, turret right hand side of 3-jaw chuck - Accessories: hydr. 3-jaw chuck 400 mmø, various toolholders for turret, chip conveyor, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CNC – controlled profile and tube bending machine for demanding and precise bending work with hollow sections and tubes. With our machines, aluminium – steel / stainless steel – various plastics such as PVC window profiles (depending on the application) can be bent with repeatable accuracy, regardless of the material. Depending on the equipment, our machines can also be used for three-dimensional bending work. Our REPANDUS models can work both horizontally and vertically. The models of the REPANDUS series work with a fixed upper roller and two movable lower rollers – this means that the straight end piece is relatively short compared to machine concepts with fixed lower rollers. The machine body is made of vibration-absorbing cast steel Shaft diameter of upper and lower rollers Ø 70 mm Shafts made of special steel – hardened and ground Bending force 190 kN Maximu ...

CNC – controlled profile and tube bending machine for demanding and precise bending work with hollow sections and tubes. With our machines, aluminium – steel / stainless steel – various plastics such as PVC window profiles (depending on the application) can be bent with repeatable accuracy, regardless of the material. Depending on the equipment, our machines can also be used for three-dimensional bending work. Our REPANDUS models can work both horizontally and vertically. The models of the REPANDUS series work with a fixed upper roller and two movable lower rollers – this means that the straight end piece is relatively short compared to machine concepts with fixed lower rollers. The machine body is made of vibration-absorbing cast steel Shaft diameter of upper and lower rollers Ø 70 mm Shafts made of special steel – hardened and ground Bending force 190 kN Maximu ...

grinding length: 4200 mm grinding width: 1300 mm workpiece height: 550 mm Control: Siemens 840D passage width: 1300 mm electro-magnetic table: 4200 x 1300 mm grinding height: 550 mm grinding motor: 306 kW grinding motor turning speeds up to: 370 U/min grinding motor feed, infinitely variable: 0,5-35 m/min coolant flow rate: 2000 l/min weight of the machine ca.: 50 t dimensions of the machine ca.: 11,21 x 5,25 x 3,85 m Equipment / Accessories: - segment head - diameter 1400 mm - for segment dimensions 120/106 x 41 x 250 mm - number of segments: 1 set = 26 pieces - grinding motor adjustment - in steps: 0,002 - 1 mm - continuous: up to 5 mm/min stepless The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Working wheel dimensions (od x id x width): Ø610x80xØ304.8 mm, cnc brand: FANUC, CNC brand: FANUC, CNC model: 21 Oi TB, Maximum length between points: 1060 mm, Max travel Z axis: 750 mm, Maximum length to be rectified: 600 mm, Height of points: 225 mm, Ø min/max to be rectified: 10 - 300 mm, Max. piece weight: 125 Kg, Max travel X axis: 325 mm, Grinding wheel speed: 45 m/s, Main engine power: 11 Kw, Workpiece head speed: from 30 to 1000 rpm, Workpiece holder head cone: MORSE 5, Power of workpiece head motor: 12 Nm, tailstock cone: MORSE 4, Travel of the tailstock quill: 70 mm, Hydraulic movement of the tailstock: 150 mm, Total power: 22 Kw, Long: 2300 mm, Tall: 1900 mm, Width: 2634 mm, Weight: 7750 Kg, Accessories: Cooling equipment with paper filter; MARPOSS meter, positioner and balancer;

Key data: 350 mm, 500 mm, 450 mm

CNC-controlled precision vertical slotting machine with four CNC axes and an electronic control of the rotary cutting table with a positioning accuracy of 0.001°. A machine for the efficient production of: - Fitting grooves (also conical grooves) -Splines - Internal and external gears -Racks CNC control with 10" color screen and touch screen software for roughing – finishing – fine finishing (This achieves surfaces of the highest possible grades.) Lifting range of the push carriage can be programmed up to 350 mm Push-slide speeds 0 to 80 strokes/min infinitely variable Push-slide swivel range +/- 20° Largest workpiece height 640 mm Projection 500 mm Round table size 450 mm Bore in the round cutting table Ø 135 mm Maximum table load 1,250 kg Table travels longitudinal and transverse – 340 x 340 mm Power transmission of the X + Y axis by precision ball screw ...

Generating Grinding Machine Grinding Machine Gleason Pfauter G320 CNC + Promot Automation Hersteller [manufacturer]: Gleason Pfauter G320 + with Promot Automation handling unit Type [ type]: G 320 Control unit: Siemens 840 Incl. control panel Baujahr[construction year]: 10/2001 Module [ ]: 0.5-7.0 Min. workpiece diameter [ ]: 10 mm Max. workpiece diameter [ ]: 380 mm Number of teeth [ ]: 10-600 Vertical carriage stroke "Z" [ ]: 200mm Horizontal carriage stroke "X" [ ]: 230mm Tangential carriage stroke (SHIFTING) "Y" [ ]: 135mm Swivel angle clamping head "A" [ ]: +-45° Tailstock tip stroke [ ]: 125mm tangential slide stroke – dressing [ ]: "V" 180mm radial carriage stroke – dressing [ ]: "U" 110mm Rotation speed – grinding wheel in progress [ ]: 3000rpm max - infinitely variable Egg speed - linear axes [ ]: 10000 mm/min Max. table rotation speed [ ]: 240 RP ...

Danobat RTM-2500 CNC X600 CNC Surface Grinder Grinding Length: 100" Grinding Width: 28" Table Length Dimension: 98.43" Table Width Dimension: 19.690" -Grinding Wheel- Grinding Wheel Diameter: 20" Grinding Wheel Width: 4" Grinding Wheel Bore: 8" -Wheel Head- Angle Adjustment: 0 DEG Wheel Head Motor: 20 HP Wheel Head Speed: 1,200 RPM -EQUIPPED WITH- Fagor 8055 CNC Control Magnetic Swarf Conveyor

CNC Vertical Slot Milling Machine Year of Make: 1989 Workspace: x-axis 1300mm y-axis 150mm z-axis 200mm Tool holder: SK40 Spindle speed: 350 rpm – 4000 rpm Max. groove length: 1200 mm Max. groove width: 40 mm Clamping area: 1300 mm x 300 mm Weight: approx. 3500 kg Coolant Setup Dimensions: 1600 mm x 1500 mm x 1800mm (LxWxH) Hydraulic system Partially overhauled, milling spindle new. Commissioning within a radius of 200 km included in the price.

Distance between points: 1000 mm, Ø max to be rectified: 350 mm, Max travel Z axis: 1.180 mm, Max travel X axis: 350 mm, Height of points: 180 mm, Ø max to be rectified with the left wheel: 350 mm, Left grinding wheel dimensions (od x id x width): Ø450xØ203x80 mm, Working wheel dimensions (od x id x width): 508x203.2x80mm, Right grinding wheel dimensions (od x id x width): Ø300xØ127x40 mm, cnc brand: FANUC, cnc model: 18TC, Main engine power: 7.5 Kw, Maximum weight between points: 120 Kg, Total installed power: 15 KW, Standard peripheral speed: 45 m/s, Automatic grinding head rotation with Hirt 2.5º: +5º_-180º, B axis control system: Incremental encoder + 2.5º Hirt ring, B axis motor: 2.5 Nm at 3000 rpm, X axis speed: 10,000 mm/min, X axis resolution: 0.0005 mm, Z axis speed: 10,000 mm/min, Z axis resolution: 0.005 mm, Z axis table rotation: 0º_9º, Workpiece head cone: MORSE  ...

Key data: 6400 mm, 3 mm

with the following equipment: - Tin cassette - Hydraulic upper beam adjustment - Additional stand unit - Cheeks laser-hardened - Control with swivel arm - Motor stop system type 11 measuring range 20-1250mm - Stop finger 4x - Crowning device, manual - Control on the swivel arm Original price of the machine approx. 269,000 € Machine is repaired, checked, cleaned by a professional and is then fully functional. Test run is carried out.with the following equipment: - Tin cassette - Hydraulic upper beam adjustment - Additional stand unit - Cheeks laser-hardened - Control with swivel arm - Motor stop system type 11 measuring range 20-1250mm - Stop finger 4x - Crowning device, manual - Control on the swivel arm Original price of the machine approx. 269,000 € Machine is repaired, checked, cleaned by a professional and is then fully functional. Test run is carried  ...
