Parallel Lathe CAZENEUVE type HB 575 Between points: 2000 mm Maxi Ø on bench: 575 mm Maxi Ø over saddle: 300 mm Spindle diameter: Ø 51 mm Rotation: from 20 to 1600 RPM Turret TRIPAN 411 3-jaws chuck Ø 200 mm Spindle motor: 15 CV ThreadingsMetric + Whitworth TailstockCM5 Lubricant tank Lubricant pump Supplied with 3 TRIPAN tool holders Voltage: 380 V Length: 3500 mm Width with tank: 1500 mm Total height: 1400 mm Weight: approx 3 T

Profiling Rod for Sibo Taus 2 1/2 Styles Working diameter 18-63mm 5.5kw main motor Minimum workpiece length 470mm Feed speed adjustable via variator Possibility of production of elements such as: billiard cues, handles for brooms, shovels, rakes or chair legs

Manufacturer: EMAG Model: VL 3 mLT Year of Manufacture: 2004 Type of Machine: Vertical Turning Lathe Data of VL3: - Lifetool available for powered tools - Interface for automation - additional inputs and outputs / M-functions - Shuttle operation - Machine was never driven wet (always dry) Electrical Specifications: - Working Voltage: 400/480 V - Control Voltage (General and Valves): 24 VDC - Frequency: 50/60 Hz - Current Supply: 3 AC - Rated Power: 31 kW - Rated Current: 48.40 A - Supply Fuse: 50 A Physical Specifications: - Total Weight: 5500 kg Find more here - / Contact us at -

Manufacturer: EMAG Model: VL 3 HW mLLT Year of Manufacture: 2008 Data of VL3: - Lifetool available for powered tools - Interface for automation - additional inputs and outputs / M-functions - Shuttle operation - Machine was never driven wet (always dry) Electrical Specifications: Current Supply: 3 AC Frequency: 50/60 Hz Working Voltage: 400/480 V Control Voltage - General: 24 VDC Control Voltage - Valves: 24 VDC Connection Value: 38 kW Rated Current: 58 A Supply Fuse: 80 A Physical Specifications: Total Weight: 5500 kg Find more here - / Contact us at -

Manufacturer: Monforts Model: RNC 500 Multi Year of Manufacture: 2007 Type of Machine: CNC Lathe MultiTurn (with driven tools) Tailstock: No Chuck: SMW / KNCS-N-315-91 Control system: 840D sl Bar capacity: max. 500mm Tool holder: Turret VDI 40 (12 pieces) Spindle operating time: approx. 18,000 hours Find more here - / Contact us at -

Manufacturer: Monforts Model: RNC 500 Single Year of Manufacture: 2008 Type of Machine: CNC Lathe SingleTurn (without driven tools) Tailstock: No Chuck: SMW / KNCS-N-315-91 Control: 840D sl Bar capacity: max. 500 mm Tool holder: Disc turret VDI 40 (12 positions) Spindle run time: approx. 18,000 hours Find more here - / Contact us at -

max rod Ø: 20 mm Turning length: 350 mm Turning diameter over bed: 240 mm Speed: 23-4400 1/min 6-station turret 2 longitudinal slides 2 cross slides IEMCA Bar Feeder BOSS 432/32 max. bar length 3,200 mm

7 axes Max. spindle passage: Ø 16 mm Max. headstock stroke: 205 mm MAIN SPINDLE Spindle speed: 10000 1/min Spindle drive power: 3.7 kW Minimum C-axis resolution : 0.001 [degrees] SUB-SPINDLE - Max. rod end Ø: 16 mm - Spindle speed : 9000 1/min - Minimum resolution C-axis : 0.001 [degrees] TOOLS 5x Turning tool holder on linear slide 4x drilling unit incl. drilling holders (front/rear) 3x driven tools for transverse machining on linear slides 4x tools incl. drill holders for reverse side machining Driven Tools Speed : 7500 1/min Conveyor Bar Feeder FMB minimag 18/3200

turning diameter over bed: 250 mm turning diameter over slide rest: . mm centre distance: ca. 400 mm centre height: ca. 125 mm turning speed range: 80 - 3000 U/min number of speeds: 18 spindle bore: 24 mm tailstock quill taper MT: 3 weight: ca. 400 kg dimensions: ca. 1200 x 650 x 1300 mm 4-jaw-chuck diameter: 125 mm including Röhm four-jaw chuck, Ø 125 mm incl. drilling and turning jaws, collet chuck device incl. collets 1-20 mm (exept 5 and 10 mm) with 1 mm gradient Multifix size A with 3 interchangeable holders, chuck protection with shutdown The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Turning diameter 900 mm Turning length 5000 mm

Elma Troyan motor Type: T 100LA 8/4 CB B14F 130-481 380 volt 0,7/1,1 kW 700/1415 rpm

Leroy Somer motor Type: LS80 230/380 volt 1,5 kW 2840 rpm

220/380 volt 2865 rpm 2,2 kW

Freetech motor 0,8/1,1 kW 400 volt 1400/2800 rpm

Type: MI 70 FP F3 30/1 ratio

Carpanelli motor 230/400 volt - 0,25 kW - 1340 rpm 266/460 volt - 0,3 kW - 1600 rpm

AEG motor Type: AM100LS8/4 400V 0,7/1,3 kW 700/1380 rpm

Elprom motor Type: 112M4 B14F165 4 kW 230/400 volt 1420 rpm 30 kg

Efacec universal motors Type: BF5 132M 848 200/230/220/240 volt 2,2/3,3 kW

Type: SW/075T

Aja motor Type: 80/80/4 230 volt 0,8/1,2 kW 1400/2800 rpm

Aja motor Type: 80/80/4 230 volt 0,75/1,17 kW 1400/2800 rpm

Eldrive motor Type: EF 63B 4 1360 rpm

Jinshin motor Type: AEVF - frame: 112M 415 volt 3,7 kW 1430 rpm 40 kg

AEG motor Type: AM80ZCA4/2 230V 0,8/1,2 kW 1425/2800 rpm

Jinshin motor Type: 112M 3,7 kW 220/380V 1430/1720 rpm 45 kg

Leroy Somer Type: LS9013 2,2 kW 220/380V motor 1390/1740 rpm

Elco Cozzi motor Type: CN400 2,2 kW 220/380 volt 1400 rpm

Type: T 132H 4B 220/380V 7,5 kW 1445 rpm

Ansaldo motor Type: A1C 131 1A A000 7,5 kW 2900 rpm 220/380V

Type: C132MB 7,5 kW 380V - 16 amp

Type: T 132 M4 7,5 kW 1460 rpm For Labor 255 lathe

Type: DH 132S 8/4 2,2/3,3 kW 720/1440 rpm For Pinacho lathe SP 90 / 165

Type: AEEEF-PP008 5,5 kW 50 hz - 380V - 12,3 amp 1450 rpm 59 kg

Tsugami BU20 Swiss-type lathe :::TECHNICAL SPECIFICATIONS::: CNC Model: Fanuc CNC Version: 16i - TB Main spindle power: 3.7Kw Main spindle bar passage: 20mm Headstock Stroke (Z1): 170mm Number of main spindle speeds: 8000 Number of linear axes: 7 Number of fixed tool slots for tool plate: 4 Number of live tool slots for tool plate: 3 Sub-spindle: yes Number of counter-spindle revolutions: 8000 Bar Passage: 20mm Number of fixed rear tools: 6 + 6 Refrigerant used: neat oil Chip conveyor: belt Machine equipment: the machine is supplied without bar loader :::D DIMENSIONS AND WEIGHT::: Length: 2712mm Width: 1401mm Height: 1728mm Weight: 3500Kg

Manufacturer:Mario Carnaghi Model: TGF 10/1850 Year of Manufacture: 2000 Type of Machine : Vertical Lathe Technical Specifications: - Table Diameter: 1450 mm - Max. Swing Diameter with Vertical Slide: 1800 mm - Max. Turning Height on Table: 750 mm - Main Spindle Drive Power (AC Motor): 164 kW (variable 720 U/min) - Table Speed Range: 3.5 - 325 RPM - Max. Table Torque: 42,270 Nm - Vertical Travel - Right Slide (Z2” Axis): 800 mm - Slide Section Size: 250 x 250 mm - Rapid Traverse - Z2 Axis: 15,000 mm/min - Horizontal Travel - Right Slide (X2” Axis): 2907.5+120=3027.5 mm - Vertical Travel - Left Slide (Z1” Axis): 800 mm - Horizontal Travel - Left Slide (X1” Axis): 2990+120=3110 mm - Traverse Above Center (X1”, X2”): 120 mm - Axis Feed Rate (X1/X2): 15,000 mm/min - Axial Thrust: 5800 daN - Tool Clamping Force: 5000 daN - Milling Spindle Drive Power: 30 kW - Spindle Speed Ra ...

Circumferential diameter over bed ... 500mm Turning length ... 2000mm Max. workpiece weight ... 300kg Circumferential diameter via support ... 270mm Spindle bore ... 52mm Spindle speed ... 22-2000 rpm Main engine power ... 5.5kW L x W x H ... 3640x1100x1580mm Machine weight ... 1940kg The machine is in good condition, possible to test under power.

UGB-150 widht: 1435mm rangę diameter : ø600 do ø1500mm maks. distance: 1500mm

Key data: 270 mm, 470 mm, 270 mm

Turning length: 470 mm Turning diameter over bed: 270 mm Turning diameter over cross slide: 145 mm Spindle speeds: 56 - 4000 rpm Spindle Passage: 26 mm Digital Readout: On X and Y Axes Country of origin: Netherlands Engine power: 1.75 hp Machine weight: 900 kg Machine LxWxH: 1200 x 460 x 1200 mm

Key data: 430 mm, 1000 mm, 430 mm

Turning length: 1,000 mm Turning diameter over bed: 430 mm Turning diameter over slide: 255 mm Spindle speeds: 19 - 2,000 rpm Spindle bore: 56 mm Equipped with: - Various Multifix tool containers - Coolant device Country of origin: Germany Motor power: 7.5 kW Machine LxWxH: 360 x 103 x 130 cm Machine weight: 1800 kg

Key data: 330 mm, 1000 mm, 330 mm

Turning length: 1,000 mm Turning diameter: 330 mm above bed 160 mm over cross slide Spindle Passage: 52 mm Spindle speeds: 70 - 2,000 rpm Equipped with: - 1x fixed bezel, 1x rotating bezel - Zahrade Theorem - Clamping pallet - Cheek chuck protection - Coolant device Country of origin: Netherlands Machine LxWxH: 1,800 x 650 x 1,400 mm Machine weight: 750 kg

Manufacturer: GILDMEISTER Model: MSL 42 Operating Hours: 3,000 Find more here - / Contact us at -

A WMW lead and feed spindle lathe that was overhauled in 1993 and has not been used since then is available. Center width: 1600mm, turning length: 1600mm, turning diameter: 250mm, turning diameter over bed/cross slide: 450mm/250mm, steel holder surface X/Y: 140mm/140mm, steel cross-section: 25mm/25mm. Speed: 2240rpm, spindle bore: 45mm, faceplate diameter: 450mm, quill stroke: 160mm, max. workpiece weight: 800kg/1250kg, max. journal diameter: 60mm. Including taper turning device, coolant device and quadruple steel holder. Documentation available. On-site inspection is possible. The machine was not used after its overhaul in 1993.

Turning diameter over bed/face slide/crank: 460mm/258mm/785mm, center width: 1016mm, bed width: 300mm, spindle bore: 58mm, speed: 2000rpm, diameter lead screw/quill: 35mm/65mm, quill adjustment: 127mm. Machine dimensions X/Y/Z: approx. 1900mm/850mm/1200mm, weight: approx. 1650kg. Documentation available. On-site inspection is possible. Expected to be available from the end of May 2025.

Center height: approx. 230mm, center width: approx. 1000mm, orbital diameter over bed: approx. 480mm, orbital diameter over support: approx. 200mm, spindle bore: approx. 45mm, spindle speed range: 2000rpm, drive power: 4kW, machine dimensions X/Y/Z: approx. 2400mm/1000mm/1500mm, weight: approx. 1700kg. On-site inspection is possible.

Swing diameter over bed/bed slide: 480mm/340mm, turning length: 800mm, center distance: 1000mm, swing diameter in the recess: 540mm, spindle bore: 52mm, speed: 1400rpm. Quill taper: MK4, manual quill adjustment: 160mm, upper part displacement: 10mm. Machine dimensions X/Y/Z: approx. 2600mm/1100mm/1350mm, weight: approx. 2300kg. On-site inspection is possible.

Turning diameter over bed/face slide: 630mm/340mm, turning length: 2000mm, center height: 290mm, clearance: 70mm, speed: 1180rpm, chuck: 400mm wedge bar chuck, tailstock: MK5, total power requirement: 15kW, machine dimensions X/Y/Z: approx. 5000mm/1350mm/1500mm, weight: approx. 4500kg. Including 2x 340mm steady rests, 2x medium steady rests, face plate with a diameter of 630mm, 2x face plates with cross slots, various tool holders, steady rest box, tool cabinet with additional tools, Heidenhain position indicator and 400mm key bar chuck. Documentation available. On-site inspection is possible.

An old and dismantled Wohlenberg lathe is available. Center width: 4000mm, face plate diameter: 900mm, length: 6000mm, width: 1000mm. On-site inspection is possible.

Center height: 180mm, center width: 800mm, turning diameter over bed/face slide: 380mm/200mm, spindle bore: 52mm, speed: 1500rpm, bed width: 330mm, quill stroke: 180mm, quill holder: MK4, machine dimensions X/Y/Z: approx. 2000mm/850mm/1450mm, weight: approx. 1050kg. On-site inspection is possible.

workpiece weight: 279 KG length: ca. von Bett bis Lynette mm : 189 € . max: durchlass 369 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
