cnc lathe gildemeister used for sale

NEW UNUSED MACHINE WITH DRIVEN TOOLING AND Y-AXIS! Specifications: Spindle: - Spindle hole diameter: 65mm - Bar capacity: 51mm - Chuck: 10” - Max spindle speed: 2600rpm Capacity: - Max. Swing diameter over bed: 600mm - Max. Turning diameter: 420mm - Max. Turning length: 550mm - X-axis: 280mm - Z-axis: 650mm - Y-axis: +/- 50mm - C-axis: yes Feedrate: - Rapid traverse X: 20m/min - Rapid traverse Z: 25m/min Turret: - Positions on turret: 12 - Driven tooling: yes - Tool shank: BMT-55 Tailstock: - Tailstock quill taper: MT-5 - Travel: 600mm Accuracy: - Positioning accuracy: 0.008mm - Repeated positioning accuracy: 0.008mm Machine is equipped with: - Chip conveyor - Tool setter - All tooling in turret included - Tailstock - Tooling as showed in pictures Auction-ID: A1-45752-4

Machine is equipped with: - chip conveyor - renishaw probe system Auction-ID: A1-45752-12

Specifications: - X-axis: 162mm - Z-axis: 750mm - Y-axis: +/- 50mm - C-axis: yes - B-axis: 670mm - sub spindle speed: 4500rpm - sub spindle motor power: 5,5kW - live tooling: yes - live tooling speed: 3000rpm - live tooling type: BMT-55 Machine is equipped with: - Chip conveyor - Bar feeder - live tooling - y-axis - tooling in turret included - pallet with tooling included Auction-ID: A1-45752-10

Specifications: Control: Fanuc 0i-TD Hours: 12009 Capacity: - Swing over bed: 970mm - Swing over cross slide: 600mm - Centre height: 490mm - Width of carriage: 885mm - Width of cross slide: 350mm - Distance between centers: 4300mm - Width of bed: 560mm Headstock: - Chuck size: 605mm - Spindle bore: 153mm - Spindle nose: A2-11 - Spindle speed: 6.5 ~ 600rpm - Spindle power: 22/26kW Turret: - Tool size: 32mm - 4 positions Tailstock: - Quill diameter: 165mm - Quill traverse: 200mm - Tailstock center: MT#6 - Body movement: motorized Machine is equipped with: - 2 chip conveyors - Motorized tailstock body - Steady rest - Tooling as showed in pictures - Auction-ID: A1-45752-7

Machine is equipped with: - chip conveyor - renishaw probe system Auction-ID: A1-45752-13

Fanuc OT-C numerical control Spindle speed: 5000 rpm Capacity: 520 x 340 mm on slide Main Engine: 15 HP Servo motor: 3.7 HP Hydraulic motor: 2 HP Coolant motor: 1/4 HP Total power: 33 kVA Power supply: 220 V three-phase Frequency: 50/60 Hz No tooling included Sold as is Auction-ID: A1-44765-408

Turning length 1.545 mm Turning diameter 500 mm (710mm) X-axis 690 mm Y-axis 230 mm Z-axis 1550 mm B-axis 225° C-axis 360° (0.001°) W-axis 1550 mm Spindle Bore Ø 98 mm R.P.M. 36x 30-3000 KW 30/22 Tapid traverse 26 – 40 m/min Auction-ID: A1-45737-1

CNC LATHE WITH SUBSPINDLE AND Y-AXIS Inv. No. 13.032C1 Make MAZAK Model SQT250MSY Control T-PLUS Center distance 495 mm Max. swing over bed Ø 525 mm Max. swing over cross slide Ø 350 mm Spindle bore Ø 64 mm R.P.M. 35 – 4,000 (16x) kW 18 Volts 380 Cycles 50 Including: 12 pos. A.T.C.(driven tools) Hydraulic chuck Ø250mm Auction-ID: A1-45737-9

CNC LATHE Inv. No. 13.016C1 Make MAZAK Model QUICKTURN 20N Control MAZATROL CAM TZ Center distance 1.037 mm Max. swing over bed Ø 510 mm Max. swing over cross slide Ø 310 mm Spindle bore Ø 80 mm R.P.M. 12 – 3,000 kW 18.5 Volts 380 Cycles 50 Including: 8 pos. A.T.C. Auction-ID: A1-45737-127

turning diameter:1600 mm turning length:12000 mm control:FAGOR 8050 Used CNC Lathe with FAGOR 8050 and extensive accessories. For further technical data and accessories, pls browse the Appendix. Parallellathe WMW mod. 4 GUIDE-WAYS ¦ CNC: FAGOR 8050 ¦ bed: monolithic ¦ centres height: 800 mm ¦ centres distance: 12000 mm ¦ swing over cross-slide: 1250 mm ¦ turret: automatic 4 positions ¦ tailstock: motorized ¦ tailstock connection: hydraulic ¦ platform: diam. 1000 mm ¦ steady rests: nr.02 ¦ chip conveyor Warranty: none Take advantage of the favorable leasing and hire-purchase terms from IKB Leasing. Ask us about it.

turning diameter:270 -300 mm turning length:710 mm total power requirement:43 kW weight of the machine ca.:8,5 t dimensions of the machine ca.:3,16 x 2,15 x 2,15 m The machine does not include a chuck or tools ? the machine was originally purchased without these accessories. The G300 has X, Z, Y, C, SP, and driven tools. A bar feeder can be used, but the machine does not have one.

turning diameter:220 mm turning length:310 mm total power requirement:17 kW weight of the machine ca.:3,3 t dimensions of the machine ca.:2,25 x 1,63 x 1940 m greates pass round over bed:430 mm bore diameter:45 mm centre distance:687 mm slide travel radial ( X-axis ):160 mm slide travel axial ( Z-axis ):310 mm spindle turning speed range:0-6.300 U/min

turning diameter:220 mm turning length:700 / 665 mm total power requirement:17 kW weight of the machine ca.:2,6 t dimensions of the machine ca.:2,63 x 1,98 x 1,94 m greates pass round over bed:430 mm Part length max.:510 slide travel radial ( X-axis ):160 mm bore diameter:45 mm

turning diameter:356 mm turning length:700 mm y-axis:±60 mm spindle drive:18 kW counterspindle motor:15 kW Direct drive for driven tools:5,5 kW Motor starting torque:640 Nm Main spindle mount:A2-8 counter spindle mount:A2-6 Rod passage:80 mm main spindle speeds::4.000 U/min Drehzahl angetriebene Werkzeuge :6.000 U/min rapid traverse speed:30 m/min auf X- und Z-Achse machine weight ab.:5.800 kg 12-station turret, all positions driven C-axis on both spindles Belt-driven and infinitely variable drive on all motors Prismatic guideways on all axes Oil cooler for both spindles, manufacturer Daikin Automatic, dialog-guided programming system MAPPS Automatic monitoring of tool load and tool wear Two Renishaw measuring arms for automatic tool measurement Interfaces: USB, PCMCIA card, and RS-232 port Interface for bar feeder Automatic parts catcher Dual foot pedal for independent opening and clos ...

turning diameter:x. 350 mm turning length:985 mm swing dia.:610 mm clamping range for bar work:77 mm speeds:350 - 4.000 U/min Torque:465 Nm spindle nose:A2 - 8" spindle bore diameter:88 mm chucking diameter:254 mm numbers of tools:12 travel -x axis:190 mm travel -z axis:1.025 mm rapid traverse X-axis:30 m/min rapid traverse Z-axis:33 m/min Tailstock Travel:1.010 mm tailstock taper MT:4

turning diameter:1070 mm turning length:8500 mm total power requirement:62 kW turning diameter over slide rest:800 mm spindle bore:128 mm max. workpiece weight between centers:8000 kg max. workpiece weight:12000 kg bore spindle turning speed range:1,120-01120 U/min tailstock quill diameter:200 mm dimensions of the machine ca.:12 x 2,8 x 2,4 m Machine equiped with Alan Bradley 9 series CNC control - SAUTER 6-postiion revolving head - 360 mm seld centering steady rest - 385 mm rotary work rest (used for gun barrels) - faceplate 800 mm - chip conveyor

turning diameter:480 mm turning length:1250 mm control:H 645 weight of the machine ca.:8 t dimensions of the machine ca.:5 x 2 x 2 m centre distance:1580 mm swing over bed:495 mm swing diameter:üb.Querschlitten ca.350 mm working area:1600 mm control:H645 connected load:50 kW

turning diameter:1600 mm turning length:3000 mm centre height:800 mm turning diameter over bed:1600 mm turning diameter over bed slide:1400 mm turning dia. over face-slide:1200 mm max. workpiece weight between centers:20 to speeds:5,6 -800 1/min transmission ratio:3 spindle bore:112 mm turret (x-stations):8 / VDI 60 travel -x axis:850 mm travel -z axis:3020 mm rapid power traverse in X-and Z direction:6 / 10 m/min power maindrive:46 kW weight of the machine ca.:22 to. dimensions of the machine ca.:7,2 x 4 (3,11) x 2,7 m tech-in lathe, flatbed, tailstock, 8-pos. BARUFFALDI turret with 4 live tools, power 9kW, 4-pos. BARUFFALDI square-headed turret horizontal, C-axis, 3-jaw hydr. chuck SMW Autoblock KNCS 800/165, dia. 800mm, quick adjustment, power cylinder with 2 pressure clamping system, chipconveyor, coolant device, accessories

bar material dia.:65 mm turning length:644 mm turning dia. over bed:600 mm turning diameter over slide:430 mm y-axis:100 (+-50) mm turning speeds:2x 5.000 1/min positive location each:2x C-Achse, 0,001° Grad Sub spindle:ja/yes turret (x-stations):2x 12 VDI 30 Pos. driven tools:2x 12 Pos. turning speeds:2x 4.000 1/min control:FANUC 18 iTB total power requirement:30 kVA weight of the machine ca.:8 t dimensions of the machine ca.:3,5 x 2,5 x 2,3 m turning- milling center with Y-axis, collet device on main and subspindle, high pressure pumps 2x 14bar, parts catcher/conveyor, barloader ENTL 10-65, chip conveyor, lot of accessories approx. 54.500 hours "machine on", 30.500 h "automatic", 14.000 h "feeding"

turning diameter:80 mm turning length:235 mm max. bar capacity:42 mm power capacity - driven tools:1 kW speeds spindle 1:6000 1/min speeds spindle 2:5000 1/min numbers of turret head positions:8 pos drive capacity - spindle motor:SP1 11 / SP2 5,5 kW Tools speed:60-6000 1/min weight of the machine ca.:ca. 3 t dimensions of the machine ca.:2,4 x 1,5 x 1,6 m High Performance CNC Turning- and Milling Center - chipconveyor - subspindle - live tools - C-axis - brake - partscatcher and partsconveyor - tool eye - barloader LNS HYDROBAR MINI-SPRINT approx. 5000 working hours

turning diameter:420 turning length:1230 mm swing over bed:700 mm swing diameter over slide rest:550 mm centre distance:1390 mm y-axis:+/- 60 mm turning speeds:3500 1/min turret (x-stations):12 power capacity:22 / 18,5 kW :1 / 12 x BMT rapid traverse x + z axis:20 / 24 m/min :76 mm total power requirement:50 kVA weight:7,8 t dimensions of the machine ca.:4,10 x 2,05 x 2,21 m CNC lathe with Y-Axis and driven tools, C-axis, tool eye, hydraulic 3-chaw-juck D= 250 mm, reinforced pump 15 bar, pressure-compensated clamping cylinder , 2 step clamping pressure, prepared for steady (without steady), progr. tailstock (dragging device), live tool device (3,7 kW, 3.000 rpm), chipconveyor, 1 pcs. live tool included approx. 15.500 working hours

turning diameter:626 mm turning length:3000 mm Turning diameter:600 mm spindle bore:100 mm spindle turning speed range:2800 U/min weight of the machine ca.:18 t Machine overhold and retrofit in 2003 with SIEMENS 840 D control - NC steady rest - 12-fold revolving head - splash doors - tailstock - coolant device

turning diameter:38 mm Article: CNC lathe Manufacturer: Hanwha Type: STL38H Year of construction: 2013 Control: Siemens 840SL for 8 axes Main spindle: max. turning diameter: 38mm; spindle bore max. 42mm, n max. 6,500 rpm Power max. 23 kW; C-axis with 0.001 degree; stroke Z1 320mm; synchronised guide bush unit; guide bush type JBS or SL38; type collet 173E / F48 Counter spindle: max. pick-up diameter: 38mm, n max. 6,500 rpm Power max. 23 kW; C-axis with 0.001 degree; stroke Z2 320mm; type collet 171E / F42 Tool turret: n max. 6,000 rpm Power max. 2.6 kW; Servo axes: X2, Y2, Z2; Stroke [mm]: X2 = 115, Y2 = 100, Z2 = 120 Bar feeder FMB Turbo 5-55 High-pressure station SFB-301 eco 150bar Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

turning diameter:26 mm Article: High-precision CNC lathe with linear cross slide Manufacturer: Benzinger Type: GOFuture B1 Yob: 2015 Machine was only used for reworking, so only light machining work was carried out! Control: Siemens Sinumerik 840Dsl Main spindle: maintenance-free motor spindle Bar capacity: D26mm Chip processing container with coolant pump: 30l/min at 5bar Loading and unloading device type IB Additional gripper system for placing the workpieces in the correct position on the unloading conveyor Coaxial valve for coolant to the linear tools (3 pieces) Internal clamping device C-axis main spindle for digital control incl. Transmit function Adjusting microscope 16x magnification Coolant supply through the clamping cylinder of the spindle, sealing air, Speed increase of the motor spindle to 8,0000 rpm Nordmann tool monitoring Profibus master interface Hinged belt conveyor Kno ...

turning diameter:26 mm Article: High-precision CNC lathe with linear cross slide Manufacturer: Benzinger Type: GOFuture B1 Yob: 2016 Machine was only used for reworking, i.e. only light machining work was carried out! Control: Siemens Sinumerik 840Dsl Main spindle: maintenance-free motor spindle Bar capacity: D26mm Loading and unloading device type IB Additional gripper system for placing the workpieces in the correct position on the unloading belt Coaxial valve for coolant to the linear tools (3 pieces) Internal clamping device C-axis main spindle for digital control incl. transmit function Adjusting microscope 16x magnification Coolant supply through the spindle clamping cylinder, Sealing air, Speed increase of the motor spindle to 8. 0000 rpm Nordmann tool monitoring Profibus master interface Hinged belt conveyor Knoll Compact coolant device Knoll MBE interface Small fire extinguishin ...

CNC Control: GE FANUC Series 16i-T Number of axes: 2 (with sub-spindle) Main spindle: ASA 5 nose, max. bar passage 42 mm, power 11 kW, max. speed 6,000 rpm Max. rotation diameter: 519.2 mm Max. turning diameter: 308 mm X/Z axis strokes: 189.2 / 406 mm Turret: VDI 30 bidirectional, 16 positions (16 motorized) Sub-spindle: ASA 5 nose, max. bar passage 42 mm, power 7.5 kW, max. speed 6,000 rpm Included equipment: parts catcher, motorized tools and stationary tools (depending on seller) Weight (kg): 5071 Year & Manufacturer: 2001 – HARDINGE

Working space: Max. swing diameter: 300 mm Max. turning diameter: 160 mm Max. turning length: 250 mm Main spindle: Speed range: 60 – 6,000 rpm Main drive power: 5.5 KW Spindle nose: A2 – 5 inches Spindle bore: 50 mm Bar work up to a diameter of max. 40 mm Tool turret: Special version: 12-speed Travels: Turret travel: x – axis: 100 mm z – axis: 290 mm Travel speed: Rapid traverse: x/z – axis: 30 m/min Feed range: 0 – 5,000 mm/min Tailstock: Tailstock travel: 364 mm Quill tip: MK 4 Quill stroke: 75 mm

Manufacturer: SOTOS VOJUS (VOJUS a.s.) Year: 2001 Type: CNC lathe with automatic cycle Numerical control: Siemens Sinumerik 840D ShopTurn Max. turning diameter: Ø 630 mm Diameter above dragger: Ø 420 mm Max. turning length: 3,000 mm Spindle: up to 2,500 rpm – passage Ø 110 mm Fast feeds: longitudinal 10 m/min – transverse 5 m/min Installed power: approx. 26 kW Equipment: Multifix tool holder, 1 bezel, coolant Dimensions (mm): 3000 × 1800 × 1790 Weight (kg): approx. 4500 Remarks: High-capacity CNC lathe for long workpieces. Serial number included in the description.

Manufacturer: INDEX Year: 2005 Type: Moving spindle CNC lathe with motorized tools and C-axis Numerical control: Siemens Sinumerik 840D Powerline Chuck: Ø 160 mm Max. rotation diameter: Ø 180 mm Strokes: X-axis 520 mm / Z-axis 200 mm Fast feeds: X/Z 40 / 30 m/min Moving spindle: 5,000 rpm – 13 kW (100%) / 20 kW (40% ED) – max. torque 105 Nm C-axis: 0.001° resolution Turret: 12 positions – all motorable stations – VDI 30 Motorized tools: up to 6,000 rpm – 8.5 kW Power supply: 400 V / 50 Hz / 3 phases – installed power approx. 25 kW Weight (kg): approx. 4500

CNC Control: SIEMENS 810 D Number of axes: 3 Max. turning diameter: 325 mm Max. turning length: 400 mm Max. passage over the bed: 500 mm X/ Z axis strokes: 215 / 420 mm Spindle speed: 30 – 4,500 rpm Spindle bore: 52 mm Spindle power: 15 kW Turret: 12 VDI 40 positions with motorized tools Chuck: 3-jaw hydraulic Ø 204 mm Tailstock: present, CM4 taper Tailstock sleeve stroke: 130 mm, Ø 80 mm Included equipment: coolant, bar feeder Weight (kg): approx. 4500 Year & Manufacturer: 2000 – HYUNDAI

CNC Control: Fanuc 0T-F (with C Axis) Diameter Above Bed: 500 mm Max Turning Diameter: ~280 mm Max Turning Length: ~500 mm Bar Capacity (Main Spindle): 65 mm Bench Design: 30° or 45° Inclined Spindle Nose: ASA 6" Main Spindle Speed: Up to 4,000 RPM Sub-Spindle Speed: Up to 4,000 RPM C-Axis: 0.001°Turret : 12 stations Tooling type: VDI 40 Speed motorized tools: ~3,000 - 4,000 rpm Lots sold as is, unchecked, with tool and tool holder.

CNC lathe for turning and machining metal parts. CNC control: Fanuc 16 T AA Max. turning diameter: 165 mm Turning length: 100 – 340 mm Diameter above bed: 220 mm Main spindle speed: 50 – 5,000 rpm Main spindle power: 5.5 / 7.5 kW Main spindle bar passing: 65 mm Sub-spindle speed: 50 – 5,000 rpm Sub-spindle power: 3.7 / 5.5 kW Sub-spindle bar passage: 42 mm C-axis: 0.001° Turrets: 2 Tool positions: 2 × 16 Motorized tools: 2 × 16 positions Strokes: X 175 mm / Z 240 – 680 mm Total power: 41 kVA Dimensions (mm): 3,500 × 2,800 × 2,000 Weight (kg): 5,500

SMEC SL 3000 BLMYear of manuf. : 2023 Control : Siemens 828D - ShopTurn Turning diam. : 405 mmTurning length : 956 mm____________Description:Main Spindle:Chuck:SAMCHULLY HS-12 (12 inch)Spindle Speed (Max.):3,000 RPMSpindle Nose:A2-8Motor Power (Cont./Max):18.5 kW / 26 kWMax. Turning Ø x Turning Length:405 mm x 956 mmTool Carrier (X/Z):Number of Tool Stations:12x BMT65Max. Milling Ø:433 mmTravel (X/Z):245 mm / 1,040 mmRapid Traverse (X/Z):24 m/min / 30 m/minTailstock:Quill Ø:110 mmQuill Stroke:100 mmEquipment/Accessories:Additional Equipment:Tool touch probe (Tool Setter, swiveling)Collision Protection:Turret with Hirth couplingYear of Manufacture:2023Weight:5,600 kg (according to configuration nameplate)Chip Management:Chip conveyorElectrical Connection:380 V / 3PH.PE / 50/60 Hz / 42 kVA::

SMEC SL 2000 MYear of manuf. : 2023 Control : Siemens 828D - ShopTurn Turning diam. : 360 mmTurning length : 520 mm____________Description:Main spindle:Speed:6,000 rpmPower (max.):18.5 kWBar capacity:52 mmWorkpiece clamping:3-jaw chuck, Samchully MH-206 V1Tool holder:Technology:12-station turretTool holder:BMT55Tool drive:5,000 rpmFeatures/Accessories:Chip management:Chip conveyorCoolant management:IKZ pump with oil skimmer and high pressure, 10 barTool measurement:Automatic measuring armAutomation:PreparedFinished part removal:Parts catcher with collection boxSetup operation:Electronic handwheel

SMEC SL 2000 MYear of manuf. : 2023 Control : Siemens 828D - ShopTurn Turning diam. : 360 mmTurning length : 520 mm____________Description:Main spindle:Speed:6,000 rpmPower (max.):18.5 kWBar capacity:52 mmWorkpiece clamping:3-jaw chuck, Samchully MH-206 V1Tool holder:Technology:12-station turretTool holder:BMT55Tool drive:5,000 rpmFeatures/Accessories:Chip management:Chip conveyorCoolant management:IKZ pump with oil skimmer and high pressure, 10 barTool measurement:Automatic measuring armAutomation:PreparedFinished part removal:Parts catcher with collection boxSetup operation:Electronic handwheel

EMCO Hyperturn 65Year of manuf. : 2017 Control : Siemens 840Dsl Turning diam. : 500 mmTurning length : 800 mm____________Description:Mainspindle:Technology:MotorspindleSpeed:4.0 00 rpmPower (max.):29 kWTorque (max.):250 NmBarcapacity:76 mmSubspindle:Technology:MotorspindleSpeed:5.000 rpmPower (max.):29 kWTorque (max.):250 NmEjector:PneumaticMovement in Z:800 mmToolcarrier I (X/Y/Z):Technology:Turret with 12 stationsTaper:VDI30Tooldrive:5.000 rpm, 6,7 kW, 25 NmMovement in X/Y/Z:260/100/800 mmEilgang in X/Y/Z:30/12/30 m/minToolcarrier II (X/Z):Technology:Turret with 12 stationsTaper:VDI30Tooldrive:5.000 rpm, 6,7 kW, 25 NmMovement in X/Z:210/800 mmEilgang in X/Z:30 m/minEquipment/Accessory:Chipmanagement:Chip conveyorCoolingmanagement:Internal cooling unit with paperbeltfilter and High-pressure, 40 barRawmaterialfeed I:Robotinterface preparedRawmaterialfeed II:Barloaderinterface prepa ...

with 2 pcs. roller conveyor Auction-ID: A7-45452-19

Control: Siemens Sinumerik 805 Grinding length: 800 mm Grinding width: 300 mm Workpiece height: 300 mm Table load: 800 kg Grinding wheel diameter: 400 mm Grinding wheel width max: 50 mm Operating voltage: 380 V Table dimensions: 800 x 300 mm Total power: 20 kVA Auction-ID: A7-45696-148

CNC Week Homag; 6.00 m in the X-axis; incl. rich accessories such as milling cutters; saws; swivel tools; etc. Then there are some controlled vices; many material suckers / suction pads. The main spindle was renewed once. There was also a software update. Stands unused for about 6 months. Auction-ID: A7-45983-6

CNC MILLING MACHINE Inv. No. 12.565J Make TOS Model FGS 40/50 CNC Mach. No. 43400083 Control Heidenhain TNC 355 Table 400 x 1,250 mm Longitudinal Travel (X) 850 mm Cross Travel (Y) 500 mm Vertical Travel (Z) 500 mm Taper ISO 50 R.P.M. 35 – 1.800 kW 7,5 Volts 380 Cycles 50 Auction-ID: A1-45737-198

Technical data: 2000 overtaken Turning diameter over bed: 1350 mm Turning diameter via slide: 1250 mm Sheet: 1350 mm Clamping on the flat disc: 300-900 mm Turning length: 5000/6000 mm

Wood Turning Lathe Precision device for professional users, with grey cast iron variable speed control high degree of spindle concentricity Spindle can be fixed all 15° LCD speedometer One hand operation of the tailstock and tool rest with quick-release mechanism Voltage: 230V / 50 Hz Engine power: 735W (S1 100%) Tip height: 160 mm Top width: 510 mm Speed ranges: 250-750 m-1, 550-1650 min-1, 1300-3850 min-1 Spindle stock rotation: 180 degrees Headstock thread: M33 DIN800 Morsekonusaufnahme: MK2 / MT2 Quill stroke: 63 mm Weight: 52 kg Dimensions: 1035 x 305 x 449 mm G & HM-D510F

Heavy duty lathe Waldrich Distance between centers: 12000 mm Turning diameter: -Over bed: 2000 mm -Over cross slide: 1640 mm Weight of work piece: max 40 ton Spindle speed range, stepless: 1,5-92,5 rpm Year of manufacturing: 1960

Technical data: Diameter over bed: 1550 mm Diameter over slide: 1600 mm Turning length: 5500 mm Max cross travel: 400 mm

AUTOMATIC HYDRAULIC HORIZONTAL COPY LATHE Type BULLERI 110 / 4 MANDRINS N. 4 DISTANCE BETWEEN MANDRINS mm.320 MAX. WORKING DIAMETER mm.315 MAX. ADMITTED LENGTH mm.1200 MAX. WORKING LENGTH mm.1000 ROTATION SPEED rpm 4850 N.02 CUTTER MOTOR CUTTER MOTOR POWER Hp 7,5 each one HYDRAULIC PUMP MOTOR POWER Hp 1,5

Technical data: with stand, 50 Hz, DAB ED 25% Engine: 3 Capacity: 1.75 A Capacity: 736 W Voltage: 380 V

Tip height: 300 mm centre distance: 1500 mm gr. Turning diameter over bed: 625 mm spindle bore: 105 mm spindle retainer: Gr. 8 mm taper of tailstock Quill: 5 MK spindle speed: 6.6-2000 RPM elect. Supply: 400 V, 15 kW space: 4400 x 2050 x 1820 mm weight: 5200 kg

Swing: 530mm. Swing over carriage: 320mm. Distance between centers: 2000mm. Spindle: 60mm. Equipped with chuck. Equipped with DRO Fagor. Motor power: 10cv.

New lathe. Distance between centers: 1500mm. Swing: 510mm. Swing over carriage: 320mm. Swing over gap: 760mm. Spindle hole: 80mm. CE protections and certificate. Equipped with chuck and steady rest.

Distance between centers: 4500mm. Swing: 825mm. Swing over carriage: 600mm. Swing over gap: 1250mm. Spindle: 80mm. 16 speeds (9-500rpm) Equipped with chuck of 500mm. Equipped with conical device.
