cnc grinding used for sale

Distance between points: 1000 mm, Ø max to be rectified: 350 mm, Max travel Z axis: 1.180 mm, Max travel X axis: 350 mm, Height of points: 180 mm, Ø max to be rectified with the left wheel: 350 mm, Left grinding wheel dimensions (od x id x width): Ø450xØ203x80 mm, Working wheel dimensions (od x id x width): 508x203.2x80mm, Right grinding wheel dimensions (od x id x width): Ø300xØ127x40 mm, cnc brand: FANUC, cnc model: 18TC, Main engine power: 7.5 Kw, Maximum weight between points: 120 Kg, Total installed power: 15 KW, Standard peripheral speed: 45 m/s, Automatic grinding head rotation with Hirt 2.5º: +5º_-180º, B axis control system: Incremental encoder + 2.5º Hirt ring, B axis motor: 2.5 Nm at 3000 rpm, X axis speed: 10,000 mm/min, X axis resolution: 0.0005 mm, Z axis speed: 10,000 mm/min, Z axis resolution: 0.005 mm, Z axis table rotation: 0º_9º, Workpiece head cone: MORSE  ...

Distance between points: 1000 mm, Ø max to be rectified: 400 mm, Maximum length to be rectified: 600 mm, Max travel Z axis: 1300 mm, Max travel X axis: 378 mm, Height of points: 205 mm, Ø of the grinding wheel: 600 mm, Grinding wheel width: 63 mm, Maximum width of grinding wheel: 125 mm, Grinding wheel hole Ø: 203 mm, cnc brand: SIEMENS, cnc model: 840D, Main engine power: 22 Kw, Grinding wheel speed: 45 m/s, tailstock cone: mk5, Counterpoint tour: 100 mm, Workpiece head cone: mk5, Workpiece head rotation: 90º, Maximum piece weight: 300 Kg, Working accuracy of the machine: IT4 ISO, Fine taper adjustment +/-: O, 1 mm/a, speed of the working feed of the table: from 0 to 7.5 m/min, Plan dimensions: 4500x3000x2500 mm, Weight approx.: 8000 Kg

(3) Mikrosa SASL 5 CNC (size similar to Kronos M, MX, L) CNC overhaul and retrofit in progress full overhaul and CNC retrofit (pending) komplett Ueberholung + CNC retrofit Grinding wheel 500mm wide x 610mm dia. CNC 5 axis / 5 axis Mikrosa SASL 5 CNC complete overhaul and retrofit Grinding wheel 500 x 610 mm Regulating wheel 400 x 650mm Fixed center Complete mechanical overhaul Complete electrical overhaul Elimination of hydraulic movements Application CNC Siemens 840D 5 axes controlled in position with digital brushless motors: - Operating wheel axis motor with optical scale - 4 dressing axes: 2 on the grinding wheel, 2 on the regulating wheel - rotating axis with adjustable speed motor on regulating wheel - rotating axis with 55kW AC motor with inverter on grinding wheel to adjust RPM / peripheral speed (m/sec) Set-up for through-feed grinding and still customizable according to custome ...

ELB SURFACE GRINDER 460x2440mm CNC Dresser

Control Other WEISS CNC Tip width [mm] 650 General: Control WEISS CNC Center width 650 mm Center height 200 mm Grinding wheel dimensions 400x60 mm + 500x60 mm Workpiece headstock: Speed 10 -650 rpm Workpiece weight max. 250 (100) kg Grinding diameter max. 390 mm

max. grinding diameter: 0 mm grinding length: 0 mm workpiece length: 970 mm total power requirement: 12 kW weight of the machine ca.: 5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding height: 50 mm grinding width: 120 mm grinding wheel diameter: 600 mm total power requirement: 85 kW weight of the machine ca.: 9500 kg D I S K U S (Germany) CNC Controlled Double Sided Vertical Spindle Surface Grinder with Rotary Workpiece Feed System and IONIC Size Control Model DDS 600 III PLM - CNC Year 1992 erial No. 7924 _______________________________________________________ Grinding wheel Ø x bore x height, each 600 x 150 x 75 mm Approximate Workpiece dimensions: Grinding height, approx. 1.5 – 50 mm Grinding width, appox. 20 - 120 mm Vertical quill adjustment, each, approx. 150 mm Infeed of grinding wheels via CNC 0.0001 mm Feed of workpiece transportation device, infinitely variable 40 – 235 mm/sec Grinding wheel speed, each (30 m/s) 191 - 955 rpm Grin ...

max. grinding diameter: 300 mm grinding length: 500 mm workpiece length: mm Number of axles: 6 St. centre height: 220 mm centre distance: 500 mm x-axis: 500 mm y-axis: 320 mm z-axis: 320 mm total power requirement: 5 kW weight of the machine ca.: t dimensions of the machine ca.: m Height of centres 200 mm Distance between centres / clamping length 750 / 500 mm Table size 290 x 1,600 mm Intermediate table 110 x 1,200 mm X / Y / Z axes 500 / 320 / 320 mm Feed speeds, X, Y & Z axes 0.005 - 5 m/min Grinding head swivelling, vertical axis (B axis) 300 ° Grinding head tilting (C axis) +/- 30 ° Speed range of R axis 0 - 50 rpm Grinding spindle speeds, approx. 5,000 - 10,000 rpm Workpiece holding fixture 50 ISO Indexing 1 - 999 ° Leads 0.5 - 10,000 mm Spindle drive 4 kW Total electrical load, approx. 10 kW - 380 V - 50 Hz Weight, approx. 4,000 kg Accessories / Special Features SCHÜTTE CNC ...

max. grinding diameter: 320 mm grinding length: 500 mm workpiece length: 700 mm total power requirement: 10 kW weight of the machine ca.: 4 t dimensions of the machine ca.: m Height of centres 220 mm Distance between centres / clamping length 750 / 500 mm Table size 290 x 1,600 mm Intermediate table 110 x 1,200 mm X / Y / Z axes 500 / 320 / 320 mm Feed speeds, X, Y & Z axes 0.005 - 5 m/min Grinding head swivelling, vertical axis, manual 200 ° Grinding head tilting, manual +/- 90 ° Speed range of R axis, approx. 0 - 50 rpm Grinding spindle speeds, infinitely variable, approx. 2,000 - 12,000 rpm Workpiece holding fixture 50 ISO Indexing 1 - 999 ° Leads 0.5 - 10,000 mm Spindle drive 4 kW Total electrical load, approx. 10 kW - 380 V - 50 Hz Weight, approx. 4,000 kg Accessories / Special Features SCHÜTTE CNC Continuous Path Control for 4 axes with SIEMENS/BOSCH components and SIEMENS  ...

internal diameter: 120 mm grinding depth: 200 mm swing diameter: mm total power requirement: 4 kW weight of the machine ca.: t dimensions of the machine ca.: m Grinding diameter, internal, max., approx. 3 - 120 mm Grinding depth, approx. 200 mm Height of centres above rotating workpiece slide 132 mm Max. swing Ø in front of rotating workpiece slide, approx. 450 mm Work spindle admission 40 mm Table stroke, max. (Z axis) 480 mm Workpiece cross adjustment (X axis) 50 mm Turret head cross adjustment (U axis) 50 mm Workspindle head swivelling (B axis) -30 / +45 ° (manual) Speeds of workspindle, infinitely variable 75 - 1,300 rpm Grinding spindle speeds 9,500 - 150,000 rpm Grinding spindle drive 4 kW Total electrical load, approx. 8 kW - 380 V - 50 Hz Weight, approx. 3,000 kg Accessories / Special Features TRIPET (Bruetsch) CNC Control for 3 axes (Z, X and U) with electric hand wheel, with ...

GENERAL CHARACTERISTICS:, Grinding Wheel Dimensions: Ø610xØ304,8x508 mm, Regulating Wheel Dimensions: Ø355xØ152,4x508 mm, Ø min/max to be rectified: 3 - 300 mm, Dimensions of the work wheel: Ø610xØ304.8x508 mm, Dimensions of the drive wheel: Ø355xØ152.4x508 mm, Weight: 17000 kg, Power: 100 kW

Hydraulic ruler holder, Automatic grinding wheel balancer, Cover, Hydraulic working grinding wheel cover, Equipment AEROEL measurement, Hydraulic table locking, Hoist for 1,000 kg, Refrigeration in electrical cabinet, Panel tire, Coolant transfer tank, Ø grinding wheel dimensions (od x id x width): Ø 650 x Ø 304,8 x 500mm, Grinding wheel dimensions (od x id x width): Ø 650 x Ø 304.8 x 500mm, Ø min / max to grinding: 3/200 mm, Ø min/max to be rectified: 3/200mm, Regulating wheel width: 500 mm, Regulating wheel speed nº: Infinite, No. of regulating wheel speeds: Infinitas, Min / max regulating wheel speed (r.p.m.): 10/255 r.p.m., Min/max speed of regulating wheel (r.p.m.): 10 / 255 rpm, Dressing (auto / manual): Automatic - CNC, Diamond cutting (auto/manual): Automatic - CNC, Diamond dressing speed: 255 r.p.m., Diamond cutting speed: 255 rpm, Lubrication (auto / manual): Automatic ...

Key data: 4000 mm, 1560 mm, 32

CNC Gear Gringing machine HOFLER H4000 Year 1990 Maximum Workpiece Diameter 4000mm Gear Width 1560mm Module 3-32 Number of Teeth 12-768 Maximum Angle of Teeth 35 R/L Grad Pressure Angle 14-31 Degrees Table Diameter 1900mm Table Bore Diameter 750mm Maximum Workpiece Weight 35000kg Grinding Head Stroke 1600mm Ways hydrostatic Coolant, Filtration System Way Covers: rubber roll-up, metal telescopic and bellows neoprene Power 3 PH / 60 Hz / 230 – 460 V Equipped with: Reutlinger balancer Oil mist extraction system HOFLER TPF-40/1100 measuring machine Year: 1990 Max. Gear Diameter: 4000mm Both machines are in Excellent condition This machine was used to grind the gears for the US nuclear submarine transmissions (gearboxes). The machine was originally purchased new by General Electric for the Lynn Massachusetts Facility. We purchased it from them in excellent c ...

Distance between points: 1000 mm, Height of points: 180 mm, Max. diameter to be rectified: 355 mm, Max. piece weight between points: 300 Kg, Max. weight with plate: 125 Kg, Transverse travel of the carriage (X axis): 350 mm, X-axis speed: 0.01 / 6.000 mm/min, X-axis Resolution: 0.0001 mm, X-axis measurement system: Digital ruler, Longitudinal travel of the carriage (Z axis): 1.300 mm, Z-axis speed: 0.01 / 15,000 mm/min, Z-axis resolution: 0.0001 mm, Z-axis measurement system: Digital ruler, Working wheel dimensions (od x id x width): Ø500 x Ø203 x 80 mm, Main engine power: 7,5 Kw, Angle of rotation of the grinding head: -30º / +210º, Workhead rotation speed: 10 / 800 rpm, Workpiece holder head cone: MORSE 5, tailstock cone: MORSE 4, Ø of the tailstock shank: 60 mm, Course of the counterpoint reed: 40 mm, Control type (CNC/manual): CNC, CNC brand: FAGOR, CNC model: 8040-T, Dimensions ...

G+H precision external cylindrical grinding machine RS 600 CNC / P for machining multiple diameters in a single setup, in plunge or oscillating mode. Grinding table driven by a digital servo axis, ball screw with a 10 mm pitch, axis speed 0.01 mm/min - 15 m/min, positioning via linear scale, resolution 0.001 mm, V-flat slide guide, guideways are Turcite-B coated. Disc feed support driven by a digital servo axis, ball screw with a 5 mm pitch, axis speed 0.01 mm/min - 10 m/min, positioning via linear scale, resolution 0.0005 mm, V-flat slide guide, guideways are Turcite-B coated. Workpiece headstock with digital servo spindle, positionable with initiator for detecting the reference mark, adjustable 0-1000 rpm; 2.7 kW power, MK5 taper bore, max. grinding diameter 260 mm. Tailstock with hydraulically operated quill, fine adjustment of cylindricity, max. center distance 600 mm. Center height  ...

Centerless grinding machine - centerless Ghiringhelli M100 CNC 1A 400x100mm wheel CN 1 axis plunge + through feed grinding The machine can be seen working in our warehouse in Gussago BS. Mimu(dot)com machine tools Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers, cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc., During centerless plunge grinding, the workpiece is ground in one pass, thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece, to work which is given to them with the aid of a tool., The through-feed grinding or also through grinding and longitudinal grinding: pieces, to be worked proceed uninterruptedly with axial feed through the rectification gap., Wheel width: 100, Wheel diam ...

Centreless grinding machine GHIRINGHELLI M2200 CNC 5 axes grinding wheel 200x610 CNC FANUC 5 AXIS Variable speed drive on grinding wheel complete overhaul with electric / electronic retrofit Machine in our warehouse in Gussago BS Mimu machine tools (Italy), Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers, cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc., During centerless plunge grinding, the workpiece is ground in one pass, thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece, to work which is given to them with the aid of a tool., The through-feed grinding or also through grinding and longitudinal grinding: piecesﻠ...

Distance between points: 1000 mm, Height of points: 250 mm, Axis B: Accuracy 0.1 , CNC brand: Kelco , CNC model: 90, Left grinding wheel dimensions (OD x ID x W): Ø400 x Ø127 x 63 mm, Right grinding wheel dimensions (OD x ID x W): Ø400 x Ø127 x 50 mm, Rotation of the workpiece head: -30º +120º , Workpiece holder head cone: MK 5, Max. workpiece weight between points: 150 Kg, tailstock cone: MK 4, Counterpoint reed route: 50 mm, Max tangential speed: 32 m/s, High-frequency internal grinding spindle: Ø120 mm, High-frequency internal grinding spindle brand: WARNER model K 3.000, Main engine power: 7.5 Kw, Total power: 26.5 Kw, Max travel Z axis: 1.150 mm, Max speed Z axis: 15 m / min, Work table rotation: 0º to 9º, Max travel X axis: 320 mm, Max speed X axis: 7.5m/min, Long: 3600 mm, Width: 2000 mm, Weight approx.: 5.000 Kg

Distance between points: 1000 mm, Max external diameter to be rectified: 320 mm, Working wheel dimensions (od x id x width): Ø500 x Ø127 x 80 mm, Max internal diameter to be rectified : 200 mm, Height of points: 175 mm, Control type (CNC/manual): CNC, CNC brand: FANUC, CNC model: 16GC, Maximum length to be rectified: 1000 mm, Max. piece weight: 130 Kg, Maximum length to be rectified in plongeé: 80 mm, Main engine power: 7.5 Kw / 2870 rpm, Ø min/max to be rectified: 2 - 320 mm, Total power: 30 Kw, Indoor power head: 15 Kw, Turning range: 220º, Max. revolutions of the workhead: 30 - 750 rpm, Strain: 380 V / 50 Hz, X-axis feed: 0.0001 – 5,000 mm/min, main engine: 7.5 Kw, Z-axis feed: 0.0001 – 10,000 mm/min, Air pressure: 1.5 - 3 bar, Coolant flow rate: 100 L/min, Max travel Z axis: 1050 mm, Max travel X axis: 275 mm, Max. rotation of workpiece table: 8.5º, Inner cone of workpiece  ...

1 piece surface grinding machine FS 640 SC with Fagor control Make: Geibel&Hotz Year of Make: 2010 Technical data Working Range: Grinding area - Maximum grinding area 600 x 450 mm - Standard magnetic plate dimensions 600 x 400 mm - Clamping surface table to spindle centre 140 - 525 mm - Standard grinding wheel 300 x 50 x 76.2 mm - Table load incl. magnet 600 kg - Power grinding spindle motor approx. 3.7 kW - Total connected load approx. 11 kW - Table speed 2 to 28 m/min - Transverse/vertical speed 100-1000 mm/min Dimensions 3.95 x 3.16 x 2.47 m Machine weight approx. 2.1 t Facilities machine-specific accessories, belt filter system, magnetic separator, extraction Magnetic clamping plate with adhesive force control, automatic dressing incl. compension, Dressing diamond, balancing device, clamping device, 4 grinding wheels

This VOUMARD VM 110 CNC T was manufactured in 2008. A robust internal grinding machine, it features a GE FANUC Series 31i-Model A control, a maximum grinding diameter of 150 mm, and a depth of 80 mm. It supports a longitudinal travel (Z-axis) of 300 mm and a cross travel (X-axis) of 220 mm. Consider the opportunity to buy this VOUMARD VM 110 CNC T internal grinding machine. Contact us for more information.

This JUNKER EJ 29 CNC was manufactured in 2002. A robust cylindrical grinding machine, it features a grinding wheel diameter of 400 mm, motor power of 4.5 kW, and spindle speeds up to 1000 rpm. It can handle grinding lengths up to 600 mm and diameters up to 280 mm. Control is managed via a GE Fanuc Series 21i-T unit. Consider the opportunity to buy this JUNKER EJ 29 CNC cylindrical grinding machine. Contact us for more information.

1 CNC cylindrical grinding machine Make: Buderus Model: CNC-335-I-A Year of Make: 2001 CNC control: Siemens 840C Bore machining range: 150 mm Maximum workpiece depth: 100 mm Largest external processing area: 150 mm Largest swing diameter over table: 310 mm Workpiece spindle speeds: 0 – 3000 rpm. X-axis table lifts: 1050 mm Z-axis: 300 mm Infinitely adjustable feed speed: 0.01 - 10 mm/min Stroke-dependent: 0.0005 - 0.1 mm Workpiece spindle positioning: C-axis Machine weight approx.: 7.5 to.

This JUNKER EJ29 CNC was manufactured in 2002. It features a FANUC 21i-TB CNC control, servo drives for spindle and table axes, and a hydraulic/manual tailstock. The machine can handle workpieces up to 280 mm in diameter and 800 mm in length, with a grinding wheel diameter of 400 mm. Consider the opportunity to buy this JUNKER EJ29 CNC cylindrical grinding machine. Contact us for more information.

VOUMARD Model: CNC 300 Condition: Excellent Year: 2007 Machine type: BU 1000 T L7400 Was recently removed from power due to routine upgrades and was making good parts with full functionality. Siemens 840D CNC Control. Manuals included. Has grinding capability for: Internal diameters External diameters Front faces Back faces Internal tapers External tapers Profiles Drive spigots Face keyways Cams Bilobes and trilobes Internal threads External threads Bearing tracks Travels Display .0001degrees or .0001mm A - 360 degrees - 34 t/min B - -20/+1 degrees - 240 degree/min C- 360 degrees - 500 t/min U- 300mm - 20 m/min X - 300mm - 20 m/min Z travel - 1000mm - 20 m/min 4 position turret Workhead Through Bore - 50mm Rotation Speed - 850 Max workpiece weight - 200 daN at 100 mm from flange Taper - metric 70 Weight - 8000kg

CNC CYLINDRICAL GRINDING MACHINE Fritz Studer AG — Model S22 CNC Hours in picture MACHINE IDENTITY Machine type CNC Cylindrical Grinding Machine Manufacturer Fritz Studer AG Model S22 CNC Serie 004 Serial No. 040.0004 Year of manufacture 2009 Machine base Granitan® S103 mineral casting Control system FANUC 31i-A CNC Configuration Fixed straight wheelhead (OD grinding) WORKPIECE DIMENSIONS Distance between centers 650 mm (25.6") Center height 175 mm (6.9") Max. workpiece weight 150 kg (330 lbs) Max. workpiece length 700 mm Max. workpiece diameter 449 mm GRINDING WHEEL Grinding wheel diameter 610 mm Grinding wheel width 160 mm Grinding wheel speed Up to 3,200 rpm Spindle power 15 kW (20.5 hp) Wheelhead type Fixed straight HSG peripheral speed Up to 140 m/s (optional) AXIS TRAVEL & DYNAMICS X-axis travel 310 mm X-axis max. speed 15,000 mm/min Z- ...

max. wheel diameter:210 mm total power requirement:60 kW weight of the machine ca.:8 t dimensions of the machine ca.:2,85 x 2,60 x 1,80 m grinding slide feed:700 mm grinding slide feeds:1-15.000 m/min max. workpiece weight:150 kg centre height:260 mm grinding wheel diameter:240 mm

grinding length:600 mm grinding width:250 mm workpiece height:380 mm :Sinumerik max. dia. of grinding wheel:300 mm weight:4000 kg total power requirement:12,5 kW grinding wheels:Ø 400 mm max. width of grinding wheel:100 mm grinding wheel hole diameter:127 mm turning speeds:470 - 12030 1/min x-axis:600 mm y-axis:300 mm z-axis:250 mm grinding range:450 x 200 mm distance spindle nose and table:500 mm table load:250 kg dimensions of the machine ca.:2600 x 2100 x 2400 mm switchgear cabinet:1300 x 800 x 2000 mm hydraulical unit::450 x 350 x 500 mm Documents:vorhanden

grinding length:1250 mm grinding width:600 mm workpiece height:730 mm table surface area:1720 x 500 mm headstock: dist. table - spindle center:900 mm max. longitudinal movement:X-1450 feed range:10 - 20.000 mm/min vertical movement:Y-730 mm feed range:0,2 - 3.000 mm/min cross travel:Z-550 mm feed range:5 - 5.000 mm/min power capacity:1500 U/min.- 44 kW / 8000 U/min. - 38 kW kW grinding wheel turining speeds:50-6.000 U/min cutting speed:max. 80 m/sec. weight of the machine ca.:11 t with CNC SIEMENS 840 C auto. dynamic balncing system integrated in the grinding conus profile grinding unit ( on table mounted ) Diamant profile rollers ( dia. max 140 mm , width max. 200 mm, hole 52 H3 ) speed 3000 rpm two magnetic plates ( 1000 x 400 mm, 1200 x 350 mm ) divers Flanges ect.

EMAG WEISS W 11-CNC SL650Year of manuf. : 2020 Control : Sonstige WEISS CNC Centre width : 650 mm____________Description:In Generel:ear of construction:2020Control system:WEISS CNCCentre width:650 mmCentre height:200 mmGrinding wheel dimensions:400x60 mm + 500x60 mmWorkpiece headstock:Speed:10 -650 rpmWorkpiece weight max.:250 (100) kgSanding diameter max.:390 mmMounting:MK4Grinding headstock:Peripheral speed:20 - 50 m/sGrinding disc dimensions right:500 x 60 mmGrinding disc dimensions left:400 x 60 mmX-axis:380 mmZ-axis:700 mmB-axis:torque motor, infinitely variableTailstock:Pinole diameter:50 mmPionole stroke:45 mmMounting:MK 4Cylinder fine adjustment:+/- 0.04 mmEquipment:Positioning sensors:Direct scalesGrinding spindles:2x grinding spindle (left/right)GAP / Crash Controll:Structure-borne sound (Sensotronik)Balancing:MPM balancing deviceWorkpiece measurement:Marposs PF MEAutomat ...

Vertical CNC centre lathe, uses / outdated machine type: Emag VSC 200 control: Siemens 840 C construction year: From the in 1995 to the in 2007 overtakes TECHNICAL DATA: speed area / speeds: [1 / min].: 6,000 Drehmoment:/torque [Nm]: 480 Max dreh-? over bed swing diam .: 290 mms impulse achievement / power: [kW] 34 feed ? / chuck diam. 200 mms revolver / turret: 12-fold, VDI 40, shoemaker powered work witness / driven tools 7.8 kW Verfahrwege: X axis / x-travel: 550 mms Z-Achse/z-travel: 200 mms express way / rapidly travel: (X/Z) [m / min] 30 / 20 prepush / feeds: (X/Z) [m / min]. 11 KN connected load: [KW] 36 kW machine weight: [kg] 6,500 equipment signs: filings sponsor / chip conveyor, crowd
