cnc 4 used for sale

turning diameter: max. 420 mm turning length: 1250 mm control: INDEX, C 200-4 D swing diameter: 630 mm travel x1: 320 mm travel z1: 1250 mm travel x2: 170 mm travel z2: 1250 mm travel x3: 320 mm travel z3: 1250 mm main spindle speed: max. 3000 U/min main spindle drive: 53 kW spindle passage: 102 mm spindle head: DIN 55026 Gr. 11 max. torque on the spindle: 675 Nm sub spindle - spindle speed range: max. 3000 U/min sub spindle drive: 53 kW sub spindle - spindle passage: 102 sub spindle - spindle head: DIN 55026 Gr. 11 sub spindle - spindle torque: 675 Nm travel sub spindle: 1250 mm feed power: X1 14000/Z1 14000 N rapid traverse: X1 20/Z1 40 m/min feed power: X2 8600/Z2 14000 N rapid traverse: X2 20/Z2 40 m/min feed power: X3 14000/Z3 14000 N rapid traverse: X3 20/Z3 40 m/min numbers of turret head positions: Rev. 1 = 12 numbers of turret head positions: Rev. 2 = 10 numbers of turret head p ...

CNC shearing machine manufactured in 2023. This Durma VS 4006 features a cutting length capacity of 4100 mm and can handle a maximum sheet thickness of 6 mm for structural steel. It includes a powerful 11 kW motor and a rear stop/back gauge range of 1000 mm. If you are looking to get high-quality shearing capabilities, consider the Durma VS 4006 machine we have for sale. Contact us for further details.

new CNC Nestingmachine, Brand: INFOTEC Type: 4621 EVO GO Technical data: Working range X axis: 2150 mm working range Y axis: 4600 mm Working range Z axis: 250 mm X / Y axes speed: 60 m/min Z axis speed: 12m/min Drill head grid 32 12 vertical spindles 8 horizontal spindles 1,7 kW System INFOTEC - EVO GO Automation of horizontal drilling in 18 mm panels (patent pending) Lateral drilling zone (requires drilling unit 12/8/2 LL) - Special unit for the C axis, which allows the transfer of the cut workpieces to the drilling zone. Can be rotated 0-90 degrees. (C-axis required) Optional: - Extension of the working area in the Y-axis up to 4600 mm. (Total length of the machine set with unloading table for EVO GO is: 9100mm). - Lateral drilling range: X: 2150 mm, Y:1300 mm Dimensions of side drilling elements: - 1600 x 600 x 18 mm - maximum, - 500 x 80 x 18 m ...

BYSTRONIC ByStar 4020 laser cutting machine was built in 2011 by the renowned Swiss brand BYSTRONIC. The machine, designed to meet the highest industrial standards, is used for precision cutting and engraving of workpieces with a maximum thickness of 25 mm. Materials made of e.g. steel or aluminium are machined using a laser beam with a maximum power of 6 kW and a thickness of just a few μm. It ensures extremely precise workpiece edges, which are characterised by unprecedented smoothness and absence of irregularities. The offered ByStar 4020 laser cutting machine is also extremely easy to operate. The process parameters are programmed in the intuitive ByVision CNC control, which allows the creation of advanced machining programmes in just a few steps. All this makes the BYSTRONIC laser the perfect choice for any industrial plant. Technical specification of the BYSTRONIC ByStar 402 ...

Inv. Num. : 8329 Type: KMX 413 Producer: MANURHIN Created: 2018 Parameters: Control system: FANUC Hours: 9473 h Max. rod diameter: 16 mm Number of axles: 4 plus 2 pieces Maximum spindle speed: 12000 1/min Spindle bore: 19 mm Spindle stroke: 130 mm Equipment: Collets Bar Feeder Spindle adjustment for 16 mm rod without adjusting the rod end

Circulation/rotation Ø over bed: 475 mm Rotation/rotation Ø via cross slide: 260 mm Sledge path plan: 260 mm centre distance: 1000 / 1500 / 2000 mm power capacity: 22 kW Gear stages. m= manual / e= electric.: 2 e Spindle head DIN 55026 / DIN 55027: A6 / 6 Spindle Ø in front bearing: 115 mm spindle bore: 78 / 70 mm turning speed range (V-constant): 1 - 3.000 U/min feed range flat: 1µ - 1.000 mm/U feed range lengthwise and thread: 1µ - 2.000 mm/U Rapid traverse plan/longitudinal: 5 / 10 m/min diameter of quill: 70 mm quill travel: 120 mm quill inner cone: 5 MK This machine is used for the production of individual parts and small batches from simple to the most complex contours. It is characterised by: --> Ease of operation Precision Working range

Key data: 4000 mm, 2000 mm, 10000 W

4000 x 2000mm with Bytrans Extended

A Gildemeister CNC double-spindle turning and milling center including coolant system and chip conveyor is available. Turning diameter over bed: 640mm, machining diameter: 400mm, center distance: 1930mm, travel X/Z: 550mm/1585mm, travel Y: +/-110mm, B-axis: +/-120° (interpolating), C-axis: 360°. Main spindle: power: 36kW/45kW, speed: 4000rpm, torque: 600Nm-730Nm, bore: 107mm. Milling spindle: Speed: 12000rpm, power: 13.2kW/22kW, torque: 100Nm. Tool places: 60, carrier: turret 12-fold star SW 380, machine dimensions X/Y/Z: approx. 9300mm/4600mm/3100mm, weight: approx. 20000kg, control: Siemens Sinumerik 840D powerline. Documentation available. On-site inspection is possible.

turning diameter:360 mm turning length:520 mm total power requirement:20 kW weight of the machine ca.:3,8 t dimensions of the machine ca.:3 x 2 x 2 m

BYSTRONIC ByStar 4400 laser cutting machine was built in 2006 by the Swiss brand BYSTRONIC. The machine, designed for precision cutting and engraving of sheet metal, is an excellent choice for any industrial plant. The machining process is performed using a stable 4.4 kW laser beam, which is generated by a resonator of the highest energy efficiency. As a result, the edges of the machined workpieces stand out for their unprecedented smoothness and lack of unevenness. ByStar 4400 laser cutting machine is offered with a range of equipment, including among others an intelligent CNC control and a KELLER industrial dust collector. The machine has undergone regular inspections and is ready for further use. BYSTRONIC laser weighs 13500 kg. Technical specifications of the BYSTRONIC ByStar 4400 laser cutting machine - CNC controller: BYSTRONIC ByVision - laser power: 4.4 kW (4400 W) - max ...

A centerless CNC cylindrical grinding machine Tschudin is available. Workpiece diameter min./max.: 1.5mm/100mm, max. grinding length: 250mm, grinding wheel diameter outside/inside: 400mm/203.2mm, grinding wheel peripheral speed: 50m/s, grinding wheel power: 11kW, control wheel diameter outside/inside: 225mm/127mm, speed: 265rpm, inclination: +/-5°, power: 3.7kW. Machine dimensions X/Y/Z: approx. 2000mm/2400mm/1900mm, weight: approx. 6000kg, control: Fanuc 21i-MB. Including Knoll Micro Pur 240 F ultra-fine filter, Streuli SHSRT300-TL142/180 lifting station and Kraft & Bauer FB703S-UV3-TFM70° fire extinguishing system. Documentation available. On-site inspection is possible.

A CNC fine milling machine Iselautomation KG with defective spindle is available. Travel X/Y: 400mm/200mm, machine dimensions X/Y/Z: approx. 1200mm/900mm/1600mm, weight: approx. 500kg. On-site inspection is possible.

Inv. Num. : 8514 Type: CLX 450 TC Producer: DMG Created: 2022 Parameters: Switch-on hours: 13312 h Hours: 8547 h Maximum spindle speed: 5000 1/min X-axis travel: 750 mm Y-axis travel: 200 mm Travel Z axis: 1000 mm Max. workpiece diameter: 400 mm Maximum length of the workpiece: 1100 mm Machine weight: 9200 kg

Turning diameter: 320mm, turning length: 1000mm, spindle clearance: 80mm, speed: 3150rpm, travel X/Z: 265mm/1000mm. Machine dimensions X/Y/Z: approx. 5500mm/2400mm/2400mm, weight: approx. 7000kg, control: Traub System TX-8. Including a tool set, three-jaw chuck and bar chuck with collets. Documentation available. On-site inspection is possible.

A CNC gantry flame cutting machine ESAB is available. Track width: 4000mm, cutting dimensions X/Y: 3000mm/6000mm, track length: 8000mm, track height: 465mm, table height: 700mm, cutting speed: 24m/min, flame cutting table dimensions X/Y: 3100mm/6180mm. Cutting process: Oxyfuel/plasma, Torch: Cooljet-Pro, Plasma source: m3 202 EPP 202 GEN 2, Plasma torch: PT-36. Filter capacity: 9000m³/h, Filter area: 180m², Particle size: 0.1µm. The plasma source cooling system must be repaired. Documentation available. On-site inspection is possible.

Key data: 160 t, 4000 mm

160 ton x 40000mm Multi Axis CNC

A CNC 6-axis laser precision machine for non-contact laser processing and measurement of complex geometries, particularly in the tool and mould making industry, is available. Travel X/Y/Z: 300mm/400mm/500mm, table dimensions X/Y: 300mm/400mm, axes mechanical/optical: 3/3, measurement system: non-contact SI sensor, measurement accuracy: +/-0.01mm, surface finish: Ra under 1µm, operating hours: 21045h, processing hours: 6549h. The laser (Prisma) is defective. Documentation available. An on-site inspection is possible.

The machine is in good technical condition, after prior agreement it is possible to test it. Control system: Fanuc Max. turning diameter: ø65mm Max. workpiece length: 300mm Turret head: 2x12 driven positions Bar feeder: IEMCA master 880 MP Cooling + chip conveyor

X-axis: 320mm, Y-axis: 400mm, Z-axis: 90mm. No defects known, regularly maintained, without accessories or spare parts. The machine has already been dismantled. An on-site inspection is possible, not under power.

pressure: 400 t chamfer lenght: 4100 mm distance between columns: 3550 mm column arm: 510 mm ram stroke speed: 110 mm/sec work speed: 8.4 mm/sec return speed: 130 mm/sec work stroke: 375 mm dayligth: 650 mm table height: 1000 mm table width: 240 mm back stop - adjustable: max. 800 mm oil volume: 400 ltr. voltage: 400 Volt total power requirement: 30.0 kW weight: 26409 kg range L-W-H: 5450 x 2650 x 3470 mm -------------------------------------------------- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection -------------------------------------------------- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 ...

x-travel: 400 mm y-travel: 375 mm z-travel: 250 mm table-size: 600 x 300 mm spindle taper ISO: 40 quill stroke: 50 mm spindle turning speed range: 50-400 , 400 - 3150 U/min CNC-control: TNC 135 voltage: 380 V / 50 Hz feeds: X+Z = 5 -1000 mm/min rapid traverse: X+Z = 2,4 m/min feeds: Y = 5 -670 mm/min rapid traverse feeds: Y = 1,6 m/min measuring system resolution capability: 0,005 mm total power requirement: 3,7 kW weight of the machine ca.: 0,9 t dimensions of the machine ca.: 1,9 x 1,8 x 1,70 m • HEIDENHAIN TNC 135 control, The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CNC Lathe Manufacturer: Gildemeister Type: CTX 420 linear V3 Year of Make: 2003 Control: Heidenhain Plus IT Circumferential diameter over bed: 680 mm Circumferential diameter over face slide: 565 mm Plan travel: 260 mm Longitudinal travel: 635 mm Drive power: 40/ 100% 25/37 kW Speed range from – to: 20 – 5000 rpm Weight approx.: 6500 Kg Equipment: Driven tools: 12 stations Tool carrier: 12-cavity Sauter revolver VDI 30 Partial hollow clamps Tailstock Quill stroke automatic Quill holder: Mk 5 Conveyor Measuring arm Oil mist extraction Errors excepted

Heckert CWK 400 Built in 1995 Control Siemens 840 Travel X/Y/Z 650/650/680 mm Spindle speed up to 10,000 rpm HSK 40 Tool Changer Rotary table 400 x 500 mm, Conveyor Weight 12.5 t.

DMG MORI NEF 400 CNC turning center was built in 2009 in Poland by FAMOT Pleszew S.A. The machine, distinguished by its compact design and high efficiency, is used for precision machining of workpieces with a maximum diameter of 350 mm. The machining process is performed inside a fully illuminated workspace by means of a high-speed spindle and precision cutting tools taken from a 12-position turret. The extremely rigid design eliminates any vibration and oscillation, ensuring maximum process stability during even the most intense challenges. All these features make the DMG NEF 400 the best choice for any industrial plant. The GILDEMEISTER NEF 400 CNC lathe was used for prototyping and worked for a total of 6492 hours. The offer also includes extensive equipment, consisting of, among others, an advanced HEIDENHAIN CNC control, driven tools and a chip conveyor. Technical specificatio ...

Stock number: 4001 PROCESSING Manufacturer: MAZAK, Type: VCN 410A-II Year of Make: 2009 Specifications: Table size 900 x 410 mm Longitudinal movement (X) 560 mm Transverse movement (Y) 410 mm Vertical movement (Z) 510 mm CAT 40 spindle cone Infinitely variable spindle speeds 12000 rpm Spindle motor 11/7.5 Kw Tool changer 30 places Control Mazak Matrix Fabr. Controlled in axes 3 Operating hours spindle 7746 hours Accessories: Cooling by spindle 15 bar Chip conveyance. Tool Measuring Length: 2600 mm, Height: 2800 mm, Width: 2000 mm, Weight: 5010 KG

Laser cutting machine Type: MSF 4001.20Ltk+T500 4kW IPG Manufacturer: MicroStep Year: 2016 Working area: 4000 x 2000mm + space for pipe cutting Laser: 4000 W IPG Linear guides Rexroth Gear racks Precision helical gears ATLANTA on all axes, double-sided driven portal STOBER gearboxes Drives maintenance-free, processor-controlled AC-servos Panasonic Max. positioning speed 130 m/min - one axis, 180 m/min simultaneously 2 axes. Acceleration 10 m/s2 Z-axis positioning speed 50 m/min Z-axis travel 150 mm Z-axis acceleration 0.75 G Position deviation Pa 0.07 mm in accordance with VDI/DGQ 3441 Repeat return accuracy Ps 0.03 mm in accordance with VDI/DGQ 3441 Ambient operating temperature +10 °C to +35 °C Relative humidity 0 to 90 % Machine in very good condition, under power Find more here - .ucymachines/ Contact us at - sales@ucymachines

Key data: 4230 mm, 2100 mm, 850 mm

X-axis: 4,230 mm Y-axis: 2,100 mm Z-axis: 850 mm CNC control: Heidenhain TNC 530 Spindle mount: ISO 50 Spindle speed: 6,000 rpm Tool changer: 30 places Table dimensions: 4,000 x 1,650 mm Stand spacing: 2,300 mm Equipped with: - Angle milling head - Touch probe button - Inner spindle cooling - Double chip conveyors - Cooling system -Operating instructions Country of origin: Taiwan Machine LxWxH: 9,000 x 3,500 x 4,000 mm +/- Machine weight: 30,000 kg

Key data: 650 mm, 1500 mm

Year of construction 2014, commissioning 2017 OSP P300S Controller Travel: X1/X2 axle: 695/235 mm Y-axis: 300 mm Z1/Z2 axle: 1,600/1,461 mm B-axis: -30° to +210° Max. turning diameter: 650 mm Big Bore main spindle 32/22 kW, spindle nose A2-11, max. speed: 3,000 rpm, Max. torque: 955 Nm, bore 112 mm Hollow Clamping Cylinder SMW VNK320-127, Bore 127 mm 3-jaw chuck Forkardt 3QLK 315-88 Z11 Pressure reducing valve 8-70 bar Milling spindle 22 kW, max. speed: 12,000 rpm Tool magazine with 40 tool positions, HSK-A63 Lower turret with 12 tool stations Self-centered bezel on the lower turret Hydraulic bezel SMW SLU-X-3.2-ZS, clamping range: 50-200 mm Programmable tailstock Renishaw RMP Probes Drum trough filter TMF300 with 980 L tank 8 bar circulation pump 70 bar high pressure pump Hinge belt chip conveyor Tool monitoring system for tool life and breakage Tool measur ...

Universal CNC lathe INDEX G 400 RATIO Line Hersteller [manufacturer]: INDEX Type [ type]: G 400 Control unit: Siemens C200-4D incl. milling of cylindrical tracks Incl. handwheel Baujahr[construction year]: 10/2004 Turning length 1250 Main spindle D102 with swing-in gear 1700 Nm Size 11 Hollow Clamping Cylinder 102 ARB-SPI ALIGNMENT. AND SWITCHING DEVICE TOOL CARRIER 1 COMPL. AXES X,Y,Z,B with turning/milling operation Disc turret VDI40 10 stations MILLING SPINDLE HSK A63 Tool carrier axles 2 XZ Disc turret VDI40 10 stations SUB-SPINDLE D102 DIRECT DRIVE 1300Nm Size 11 Hollow Clamping Cylinder 102 ARB-SPI ALIGNMENT. AND SWITCHING DEVICE DISC MAGAZINE ON THE LEFT OF THE HSK63 SINGLE-SWING GEARBOX WITH 32 TOOL HOLDERS DISC MAGAZINE RIGHT COMPL. M.32 TOOL HOLDERS HSK 63A Travel path: X= 320mm Z=1250mm Displacement measuring system X-axis glass mast. (abs) Fe ...

Key data: 660 mm, 983 mm

CONTROL PANEL FANUC F31-IA5 AXIS MOVEMENT X 750 MM / Y ± 210 MM / MM / Z 1.220 MM ROTARY AXIS MOVEMENT B + / - 120 ° / C 360 °/ 0.001 ° MAX. TURNING DIAMETER 660 MM MAX. TURNING LENGTH 983 MM SPINDLE - 1 CHUCK SPİNDLE SPEED 3.000 MIN/-1 CHUCK DIAMETER 12 INC / 315 MM BAR CAPACITY 90 MM TOOL SPINDLE SPEED ( S1 ) 12.000 MIN/-1 TOOL HOLDERS CAPTO C6 NUMBER OF TOOL POSITION 100 SPINDLE - 2 SPİNDLE SPEED RANGE SUP SPİNDLE 3.000 MIN/-1 CHUCK DIAMATER SUP SPINDLE 12 INC / 315 MM WEIGHT OF THE MACHINE 22.300 KG DIMENSIONS OF THE MACHINE 5.33 X 3.27 X 2.93 M

turning length: 4.500 mm greates pass round over bed: 810 - 760 mm swing diameter over slide rest: 740 mm control: SIEMENS - 840 C max. turning diameter: 800 mm turning diameter over slide: 740 mm travel -x2 axis: 875 mm travel -z2 axis: 5.200 mm CNC Turning- and Milling Center | NILES-SIMMONS - N40 MCT 4500 equipped with a turret for driven tools as well as NC steady rest and tailstock. Additional equipment: - Centering points, - Jaw sets, - Clamping jaws, The machine is in a well-maintained condition and can be inspected at any time under power. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: N-40 | N 40 | N40MCT4500 | N40MCT The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Dimensions (L/W/H): 8900x3700x2500 mm Weight: 8300 kg Total power requirement: 11 kw The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Dimensions (L/W/H): 8421x2250x2250 mm Weight: 5500 kg Total power requirement: 11 kw The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 4000 mm, 12000 mm, 12000 W

4000 x 2000mm 12000w

table length: 4000 mm table width: 2000 mm burner heads: 1 laser capacity in Watt: 4 kW Capacity steel: mm Control: MicroStep total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m - Working area: 4000 x 2000 mm + additional space for pipe cutting - Linear guides: Rexroth - Double-sided driven portal via racks: ATLANTA precision helical gearing on all axes - Gearbox: STOBER - Drives: Maintenance-free, processor-controlled AC servos from Panasonic - Maximum positioning speed: 130 m/min (one axis), 180 m/min (two axes simultaneously). Acceleration 10 m/s² Positioning speed of the Z-axis 50 m/min Travel distance of the Z-axis 150 mm Acceleration of the Z-axis 0.75 G Position deviation Pa 0.07 mm according to VDI/DGQ 3441 Repeatability Ps 0.03 mm according to VDI/DGQ 3441 Ambient temperature: +10 °C to +35 °C Relative humidity: 0 to 90% Machine in very g ...

CNC portal milling machine TYPE: LF3550/4000CS Year of manufacture: 1966 / overhauled 2010 Manufacturer: Waldrich Siegen Control: CNC840D-Powerline Routes: X-axis 14,000mm table longitudinal Y-axis 4.480mm slider-transverse Z-axis 3,000mm crossbeam vertical W-Axis 300mm Quill Vertical Max. Passage: transverse 3.200mm high 3.800mm Machine table: Length 14.770mm Width 3,100mm max. table load: 145 to Quill: Tool Taper: ISO60 Power: 100KW Max. torque: max. speed 600 rpm Rapid traverses: X-axis 12m/min Y; Z-axis 6m/min Attachment heads: Voltage: manual Description: Right angle milling head (ISO60) Orthogonal milling head (ISO60) Notes: Table guide hydrostatic

chuck diameter: 500 mm swing diameter over bed slide: 700 mm control: Siemens travel -x axis: 630 mm travel -z axis: 500 mm CNC turning and milling center vertical | EMAG - VMC 450 MT The machine is in very good condition. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VMC450MT | VMC 450MT | VMC-450 | VMC-450MT The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 400 mm turning length: 1100 mm control: Siemens Sinumerik 840D SL greates pass round over bed: 500 mm Swing dia. over traverse guideway: 370 mm Main spindle:: Max. rpm: 5000 min/-1 power capacity - main spindel: 17 / 25.5 kW max. Torque: 345 Nm spindle diameter in front bearing: 130 mm spindle bore: 67 mm chucking diameter: 325 mm spindle nose: A8 axis stroke:: x-axis: 750 mm y-axis: +/- 100 mm z-axis: 1200 mm feeds:: rapid traverse: 40 / 40 / 40 m/min Tailstock:: tailstock: 1200 mm taper of center: Mk 5 tension force: max. 8 kN milling head: b-axis: +/- 120 ° tool taper: HSK A 63 tool piece magazine with: 60 spindle turning speed - stepless: 12000 U/min spindle motor: 10,5 kW max. torque on the spindle: 90 Nm total power requirement: - kVA weight of the machine ca.: 9 t dimensions of the machine ca.: 4,6 x 2,5 x 2,82 m Equipped with: - Siemens 840D SlimLine / Cel ...

A Beyeler press brake, today Bystronic, is available. Working length: 4100mm, press force: 2250kN, max. stroke: 400mm, throat depth: 250mm, installation height: 917mm, rapid traverse down/up: 150mm/s, working speed: 10mm/s, hydraulic pressure: 315bar, oil volume: 815l, max. oil temperature: 65°C, power: 30kW, max. upper tool weight: 400kg, max. workpiece weight: 13kg. Machine dimensions X/Y/Z: approx. 5500mm/2300mm/3350mm, weight: approx. 22000kg, operating hours: approx. 35000h. Including numerous upper tools, blades and lower tools. Documentation available. On-site inspection is possible.

Travel X/Y/Z: 450mm/310mm/300mm, table dimensions X/Y: 840mm/320mm, tool stations: 12, tool holder: SK40, speed: 4000rpm. Machine dimensions X/Y/Z: approx. 2000mm/2000mm/2200mm, weight: approx. 2500kg, control: Heidenhain TNC 155. On site inspection is possible.

CNC lathe Okuma LB 4000 EX – MY C750 Control: OSP-P200L Year of Make: 2008 Turning length: 750 mm Turning diameter: 430 mm Swivel diameter over bed: Ø 670 mm Swivel diameter over slide: Ø 480 mm Speed: 42 – 4,200 rpm Tool turret V12 (all places driven) Equipment: One touch IGF Chip conveyor Touchsetter 3-jaw chuck (Kitagawa B212)

Key data: 640 mm, 1500 mm

Turning/milling center GILDEMEISTER GMX 400 linear Year of Make: 2003 Control: Sinumerik Power line Technical data: Drive power main spindle ISM 90: 36/45 KW (100/40%) Main spindle speed: Torque main spindle: Bar Passage: 90mm Number of magazine slots: 120 pcs. Tool holder milling spindle: HSK 63 Drive power counter spindle ISM 90: 36/45KW (100/40%) Speed of sub-spindle: Torque sub-spindle: Bar Passage: 90mm B-axis / milling spindle: Drive power: Speed: Torque: Tool holder: HSK z3 Lower turret: X-axis: Z-axis: Speed Driven Tools: Number of turret slots: 12 pcs. Tool holder: VDI 40 Accessories: - Chip conveyors - High-pressure system with 20bar - Preparation of 3D probes - Tailstock function counter spindle - Automatic sliding doors

Horizontal BAZ DMG MORI NHX 4000 with 2-fold pallet changer Year of Make: 2017 Control: Celos with Sinumerik 840Dsl Operate Program running hours: 21,000h Technical data: Spindle speed: 10 - 20,000 min-1 (motor spindle speedMASTER)® Drive power: 35/25 KW Torque: 130/85 Nm Tool holder: HSK 63 Number of magazine slots: 60 - Ring magazine Travels: X-axis: 560mm Y-axis: 560mm Z-axis: 660mm C-axis: 0.001° Pallet size: 400x400mm Accessories: 2-fold pallet changer Coolant system for IKZ 70bar Chip conveyor Renishaw 3D - Pushbutton

A CNC vertical machining center Fadal with increased torque is available. Travel X/Y/Z: 1140mm/635mm/61mm, table dimensions X/Y: 1350mm/635mm, rapid traverse X/Y: 25m/min, rapid traverse Z: 17m/min, max. feed rate: 15m/min, positioning accuracy: +/-0.004mm, repeatability: +/-0.0015mm, spindle speed: 10000rpm, tool interface: SK40, max. spindle torque: approx. 360Nm, tool stations: 24. Machine dimensions X/Y/Z: approx. 3300mm/2600mm/3050mm, weight: approx. 6000kg, control: Siemens. Documentation available. On site inspection is possible.

Travel X/Y/Z: 1060mm/610mm/610mm, table dimensions X/Y: approx. 1270mm/610mm, max. table load: 1100kg, spindle power: 18kW, feed rate: 7600mm/min, rapid traverse: 30m/min, tool positions: 24, tool holder: SK40, speed: 12000rpm, positioning accuracy: +/-0.01mm, repeatability: +/-0.005mm. Machine dimensions X/Y/Z: approx. 450mm/3750mm/2800mm, weight: approx. 6700kg, control: Hurco Ultimax 4. Documentation available. On site inspection is possible.

CNC lathe Okuma LB 4000 EX II – M C750 Control: OSP-P300LA Year of Make: 2017 Turning length: 750 mm Turning diameter: 430 mm Swivel diameter over bed: Ø 670 mm Swivel diameter over slide: Ø 480 mm Speed: 42 – 4,200 rpm Tool turret: V12 (all places driven) Equipment: - Chip conveyors - Touchsetter - 3-jaw chuck - Tailstock

Offered is a Traub TND 400. Center distance: 800mm, turning diameter approx. 250mm, travel X/Y approx. 220mm/850mm, spindle bore: 65mm, speed range: 40-4000rpm, 12-position disc turret, tool holder: VDI40 DIN69880, integrated coolant system, dimensions X/Y/Z approx. 3000mm/2000mm/2000mm, weight approx. 4300kg-4500kg. Inspection by appointment possible.

Key data: 250 t, 4100 mm

6 Axis Byvision / Laser Guards
