119,260 used machines on RESALE, but how to find them? Machine Search
maximum number of results exceeded > 1000
please refine your search
used
WEEKE BHX055 vertical machining center with tool changer Type: Weeke BHX 055 Operating hours: 4,340 hours Specifications: CNC controlled machining centre for drilling, milling and sawing & 4-fold tool changer Working range of axes: min. 20070mm, max. 3,050850mm Max. working thickness: 12-60 mm Max.Piece Weight: 35 KG Feed: X, Y: 50 m/min Z: 15 m/min Drilling V13: 5 drilling spindles for vertical drilling in the direction of "X" individually controlled 4 drilling spindles for vertical drilling on the upper side in the direction of "Y" individually controlled 4 Drilling spindle for horizontal drilling in the direction of "X" on the upper side individually controlled 2 drill spindle for horizontal drilling on the upper side in the direction of "Y" individually controlled Mill: 1 milling motor including HSK63 - motor power 5 KW-S1 ( 1,250 / 24,000 RPM ...
used
Description: • , Console , table 'K'  ,  ,- 8 clamping consoles ,  ,  ,- 8 pneumatically lowerable longitudinal stops (rear stop row)  ,  ,- 8 pneumatically lowerable longitudinal stops (centre row of stops)  ,  ,- 1 pneumatically lowerable side stop ruler  ,  ,  , for the right working field  ,  ,- 1 pneumatically lowerable side stop ruler  ,  ,  , for the left working field  ,  ,- ,electronic surveillance of all stop cylinders  ,  ,- 6 Workpiece feeding rails , to ease placing of heavy workpieces attached to the side of the ,  ,  ,  ,  , consoles 1, 3 ,4,5,6 and 8 , - ,LED displays for fast, simple positioning of vacuum clamps and consoles. Chip conveyor belt integrated in the machine frame work table: X = 4500 mm , Y = 1500 mm , Z = 125 mm. ...
used
Description: Rotary table 360.000 x 0.001 ° Pallet size 500 x 630 mm Spindle speeds - infinitely variable 45 - 12500 rpm Spindle motor 52 kW Feed X/Y/Z axis 1 - 60000 mm/min Rapid traverse X/Y/Z 60 m/min Rapid traverse rotary table 20 rpm Tool magazine: Chain magazine 120 tools Tool diameter 95 mm Tool diameter with 2 free spaces 228 mm Tool length - max. 450 mm Description: Horizontal machining centre with SIEMENS SIN840D control, KNOLL coolant system, chip conveyor, coolant through the spindle, 4-fold pallet storage, workpiece set-up station manually rotatable 4x90°, drill breakage control More technical data in the PDF file z-motion: 800 mm, max. workpiece weight between centers: 800 kg, x-motion: 800 mm, y-motion: 800 mm, control: SIN 840D, pallet table size: 500 x 630 mm, taper: HKS 80, turning speed range: 45 - 12500 rpm, feed range: 1 - 60000 mm/min, total power r ...
used
Description: HOLZHER Pro-Master 7123 CNC Machining Centre Max Displacement Speed X-Axis: 100 m/min Y-Axis: 100 m/min Z-Axis: 25 m/min C-Axis: 60 (min^-1) Working Dimensions X: 4,100 mm Y: 1,260 mm Z: 325 mm Spindle DEFECT (More pictures and information will follow shortly) Vacuum Pump: Becker KVT 3.140 Rotary Vane Vacuum Pumps toolchanger positions: 12, x-motion: 4,100 mm, y-motion: 1,260 mm, z-motion: 325 mm, path-feed rate max. X-axis: 100 m/min, path-feed rate max. Y-axis: 100 m/min, Approx. Onsite Dimension. (l x w x h): 5,000 x 2,200 x 2,400 mm, weight approx.: 4,300 kg
used
Description: Rotation diameter over bed 500 mm, over face slide285 mm, in the bed recess 540 mm, length of bed recess 165 mm, permissible workpiece weight with 2 set pieces 800 kg, speed range 11.2 to 2240 rpm, feed length 0.063 to 56 mm, flat 0.0315 to 28 mm, working stroke face slide 345 mm, top slide 125 mm, tailstock quill 190 mm, centre height over flat track 240 mm, bed width 360 mm, digital readout HEIDENHAIN, turning length 1000 mm weight approx.: 3,500 kg, Approx. Onsite Dimension. (l x w x h): 3,000 x 1,600 x 1,700 mm
used
Description: Rotation diameter over bed 640 mm, over the long facing slide 385 mm, in the bed recess 700 mm, permissible workpiece weight with 2 setting pieces 2500 kg, speed range 9 to 1800 rpm, working stroke facing slide 44 mm, top slide 165 mm, tailstock quill 280 mm, centre height over flat track 315 mm, bed width 450 mm, turning length 2000 mm weight approx.: 5,500 kg, Approx. Onsite Dimension. (l x w x h): 4,000 x 2,200 x 2,000 mm
used
Description: Centre height 215 mm Spindle speed max. 1,400 rpm Spindle bore 56 mm Quill diameter 65 mm Quill stroke 150 mm Chuck diameter 250 mm Drehlänge: 750 mm, turning diameter over bed: 430 mm, spindle bore: 56 mm, turning speed range: 1,400 rpm, weight approx.: 2,300 kg, Approx. Onsite Dimension. (l x w x h): 2,700 x 1,200 x 1,500 mm
used
Description: Machine no. 4014 SIN840D control x- travel , 10000 mm y- travel , 1000 mm z- travel , 500 mm Profile length 7,200 mm Profile width 300 mm Profile height 300 mm Workpiece dimensions max. 8,000 x 1,000 x 300 rpm Spindle speeds - continuously variable 1 - 24,000 rpm Drive power 15.00 kW Feed X / Y axis 1 - 60,000 mm / min. Feed Z-axis 1 - 20,000 mm / min. B - axis +/- 180 ° C - axis 360 ° Tool holder HSK-A50 Tool magazine: 24 Tool length - max. 240 mm Tool diameter 95 mm Tool diameter with 2 free spaces 200 mm Saw blade diameter max. 350 mm Working area 7,200 x 300 mm Description: 5-axis high-speed machining centre with SIEMENS SINUMERIK840D control system, RECKERTH high-frequency spindle, 8 carrier units, each with a pneumatically actuated clamping device, arranged in the Y-direction and in the X-direction X-direction via a programme-controlled positioning a ...
used
Description: Technical specifications: machining centre with fixed bridge and 2 moving plates dimensions for each working table: X = 2340 mm Y = 2520 mm working tables can be configured independent (pendular cycle) or single zone with coupled plates by CN the work surface of each of the working tables is constituted by a Lignostone vacuum table with a grid for the installation of the workpiece-holding joints numerical command: AB OSAI10/310 axis strokes: X = 4800 mm Y = 3200 mm Z = 250 mm 8 vertical milling motors 8kW, ETP axis, 18000 rpm (ref axe: TRIAX-004-365) 3 vacuum pumps Becker, 3x250 m³/h electrical panel with air conditioning, dimensions: 1400 x 800 x H 2.100 mm connection 400V, 50Hz, 100 KVA (150A) average working power = 35 kW CE mark vacuum pump: 250 m³/h, serial number: 1,785, total electrical load: 35 kW, 5-axis machining: No, Number of vacuum pump ...
used
Description: Sourced from an automotive manufacturer due to production changes Serial Number: 109303 Control: Siemens Sinumerik 840 DSL ( composed of 15 NC and 4 spindles) ,  ,Machine-specific plain text messages on screen in German language This  ,machine centre is composed as follows: , 2 Centric clamping divices Actuation: , Hydraulic Swivel table: 180º Hydraulic pressure:  ,approx max 100 bar Station 1 (front) , Spindle units: 2 SEMA spindle units type SE55 - HSK 50 for deburring Spindle Bearing inside diameter: 55 mm Sealing with barrier air and labyrinth Tool holder: HSK50 Drive power: 1,5kw at 3000 u/min Tool cooling Dry machining Drive direct via coupling Manual tool change 2 pcs. 4 spindle head for thread forming 4xm10 with IK and ABS tool holder Drive power AC servo motor, 11.0 kW Spindle speed  ,variable: ,max 3 ...
used
Description: Well-maintained PAMA Speedmat 3 130 machining centre with tool and head changer. Control and Serial Number Control: HEIDENHAIN TNC 530 , Serial number: 33C07097 Working area Max. pallet table load capacity: 10,000 kg Table dimensions: 1,600 x 1,600 mm Work spindle diameter: 130 mm Axis travel Axis travel X-axis: 3,000 mm Axis travel Y-axis: 2,000 mm Axis travel Z-axis: 2,200 mm + W-axis max.: 700 mm Table rotation B-axis: 360° Axis speed and Power transmission Feed speed X, Y, Z-axis: 0.5 - 10,000 mm/min Rapid traverse X, Y, Z-axis: 25 m/min Spindle drive speed max.: 4,000 rpm , (the actual speed on the tool varies depending on the processing head) Automatic Universal Milling Head TU 30-360 (the milling head has never been used by the operator) Max. spindle power: 30 kW (from 300 rpm) Spindle torque max.: 950 Nm Spindle speed max.: ...
used
Description: • CNC machining centre (3-axis) • Serial number AL5632 • Total installed power 20 KW • Working area approx. 2600 x 1150 mm • Panel passage height 180 mm • Travelling way X-axis: approx. 3000 mm, Y-axis: 1465 mm, Z-axis: 280 mm • Maximum travel speed in the axes direction x-y-z: 50-40-22.50 m/min • Tool magazine with 10 positions (some elastic nippers are broken) • Electro spindle SCM ISO-30-LD: power 6.60 KW, automatic tool change, for ISO 30 tool holder • Vertical milling group 6.60 KW-max. 12000 rpm, manual tool change • Saw unit to groove in X direction • Vertical drilling spindles in X-axis direction: 9 • Vertical drilling spindles in Y-axis direction: 7 • Horizontal drilling spindles in X-axis direction: 2 + 2 • Automatic lubrication • Remote control panel • 8 consoles with 22 vacuum suction cups total • 4 lifting modules for heavy wo ...
used
Description: • CNC machining centre • Serial number 02030006 • Total installed power approx. 28 KW • Useful working area approx. 3000 x 1300 mm • Panel passage height 110 mm • Travelling way X-axis: 3555 mm, Y-axis: 1735 mm, Z-axis: 270 mm • Maximum travel speed in the axes direction x-y-z: 60-50-18 m/min • Tool magazine with 8 positions •  ,HSD ES919 electrospindle: power 8 KW-max. 24000 rpm, automatic tool change, for ISO 30 tool holder • 0°-90° swiveling saw unit with 1.10 KW motor, saw blade diameter 115 mm • Vertical drilling spindles in X-axis direction: 10 • Vertical drilling spindles in Y-axis direction: 10 • Horizontal drilling spindles in X-axis direction: 2 + 2 • Horizontal drilling spindles in Y-axis direction: 1 + 1 • Saw unit to groove in X direction • CN 12 numerical control on PC • 6 consoles with approx. 35 vacuum suction cups in t ...
used
Description: • CNC machining centre • Serial number 0-250-06-1632 • Total installed power approx. 18 KW • Useful working area approx. 2750 x 1000 mm • Travelling way X-axis: 3455 mm, Y-axis: 1480 mm, Z-axis: 260 mm • Maximum travel speed in the axes direction x-y-z: 80-60-20 m/min • Tool magazine with 8 positions •  ,Electrospindle: power 7.50 KW-max. 24000 rpm, automatic tool change, for HSK F63 tool holder, liquid cooled • Milling / saw group with 1.50 KW motor • Saw unit to groove • Vertical drilling spindles in X-axis direction: 11 • Vertical drilling spindles in Y-axis direction: 8 • Horizontal drilling spindles in X-axis direction: 3 + 3 • NUM 1040 numerical control • Software Windows 95 / HOMAG WOODWOP • 6 consoles with 2 vacuum suction cups each • 6 lifting modules for heavy workpieces • BECKER KVT 3.100 vacuum pump with capacity 100 m³/h ...
used
Description: • 4-axis CNC machining centre • Serial number 521/0-511 5004757 • Total installed power approx. 18 KW • Useful working area approx. 2600 x 1150 mm • Maximum workpiece thickness approx. 100 mm • Maximum travel speed in the axes direction x-y-z-c: 75-75-30-60 m/min • C-Axis • Tool magazine with 6 positions •  ,OMLAT electrospindle: power 6 KW-max. 18000 rpm, automatic tool change, for HSK F63 tool holder • Swiveling saw unit with 1.50 KW motor • Vertical drilling spindles in X-axis direction: 10 • Vertical drilling spindles in Y-axis direction: 5 • Horizontal drilling spindles in X-axis direction: 2 + 2 • Horizontal drilling spindles in Y-axis direction: 1 + 1 • SIEMENS SINUMERIK numerical control • Remote control panel • 6 consoles with 14 vacuum suction in total • 4 lifting modules for heavy workpieces • NASH_ELMO 2BL2041-2AH50-4A-Z ...
used
Description: • 4-axis CNC machining centre • Serial number 471/0-502 5001956 • Total installed power approx. 18 KW • Useful working area approx. 2600 x 1150 mm • Maximum workpiece thickness approx. 100 mm • Maximum travel speed in the axes direction x-y-z-c: 75-75-30-60 m/min • C-Axis • Tool magazine with 12 positions •  ,Electrospindle: power 6 KW-max. 18000 rpm, automatic tool change, for HSK F63 tool holder • Swiveling saw unit with 1.50 KW motor • Vertical drilling spindles in X-axis direction: 10 • Vertical drilling spindles in Y-axis direction: 5 • Horizontal drilling spindles in X-axis direction: 2 + 2 • Horizontal drilling spindles in Y-axis direction: 1 + 1 • SIEMENS SINUMERIK numerical control • Remote control panel • 6 consoles with 14 vacuum suction in total • 6 lifting modules for heavy workpieces • BECKER HOLZHER VP100 vacuum pump A ...
used
Description: • CNC machining centre • Serial number AL5132 • Total installed power 20 KW • Useful working area approx. 2700 x 1000 mm • Maximum travel speed in the axes direction x-y-z: 50-45-22.50 m/min • , 2 x vertical milling unit with manual tool change • Saw unit to groove • Vertical drilling spindles in X-axis direction: 6 • Vertical drilling spindles in Y-axis direction: 5 • Horizontal drilling spindles in X-axis direction: 1 + 1 • Horizontal drilling spindles in Y-axis direction: 1 + 1 • NUM numerical control • Remote control panel • 6 consoles with 2 vacuum suction cups each • BECKER KVT 3.100 vacuum pump with capacity 100 m³/h Approx. Onsite Dimension. (l x w x h): 5,500 x 2,800 x 2,500 mm, weight approx.: 2,900 kg
used
Description: • CNC machining centre • Serial number 0-250-06-2992 • Total installed power approx. 18 KW • Useful working area approx. 3250 x 1300 mm • Travelling way X-axis: 3955 mm, Y-axis: 1685 mm, Z-axis: 260 mm • Maximum travel speed in the axes direction x-y-z: 80-60-20 m/min • Tool magazine with 8 positions •  ,Electrospindle: power 9 KW-max. 24000 rpm, automatic tool change, for HSK F63 tool holder, liquid cooled • Saw unit to groove • Vertical drilling spindles in X-axis direction: 10 • Vertical drilling spindles in Y-axis direction: 11 • Horizontal drilling spindles in X-axis direction: 2 + 2 • Horizontal drilling spindles in Y-axis direction: 1 + 1 • NUM numerical control • Software Windows / HOMAG WOODWOP • Remote control panel • 6 consoles with 22 vacuum suction cups in total • 5 lifting modules for heavy workpieces • BECKER KVT 3.100 ...
used
CNC processing centre Brand: IMA Type: BIMA 310V 120/600 Year: 2004 Technical data: Machining area - in X-direction without gluing 6000 mm - in X-direction motor gluing 5000 mm - in Y-direction 1200 mm - in Y-direction with main spindle + WZ-Ø 20 mm 1300 mm max. clamping height from Upper edge of suction plate Z1 100 mm max. workpiece thickness Z 2 depending on equipment/application Worktable height: approx. 950 mm 1 main spindle with feed stroke pneum. - Drive power: 12 kW in S-1 operation - Tool holder: HSK F63, taper diameter =38 mm - Tool feed: automatic - Pull-in force: 11000 N - Tool weight: max. 6 kg - Direction of rotation: right/left rotation, programmable - Speed range: stepless 1500 - 24000 rpm, programmable - Drive: frequency-controlled three-phase motor Spindle lubrication: unique factory grease lubrication - spindle cooling: water cooling ...
used
CNC processing centre Brand: Vitap Type: Galileo 2 New machine Create great things on small space - the best kind of using 5m² production space With this 3-axis machine you can drill, mill and groove in throughfeed. Vitap Bar Nesting - efficient and time saving - This patented Software processes whole corpus elements out of one longer workpiece. - Just insert the workpiece and when you take the first finished element, the machine contues with the processing of the next element Easy beginn with CNC programming: - TPA makes it easy: drillings, grooves, linear millings, form millings or the millings of letters - The CAD Software shows the processings on a virtual workpiece - Good overview about all processings on the single sides of the workpieces - Mirror function for parallel processings on other positions - Choose reference points via entering the exact position ...
used
with palletech Table size 800 x 800 mm Table NCRT Number of pallets 14 Movement x-Axis 1300 mm y-Axis 1100 mm z-Axis 1000 mm Table indexing 0,001° Number in tools in magazine 237 pieces Maximum spindle speed 35-7.000 min Tool taper DIN 69871A-50 CNC control M-plus
used
Machining Center - Universal HURON KX 15 Bearing No. 1105-01908 Make Huron Type KX 15 Built in 2002 Condition Used machine Control CNC SIEMENS 840D POWERLINE Storage location FRANCE Country of origin Germany Delivery time immediately Freight base EX WORK Technical details x-way 800 mm y-way 1000 mm z-way 550 mm Spindle holder ISO SK 40 Spindle speeds 18000 rpm inner cash supply 30 bar b-axis +20/-100 c-axis 360 Control SIEMENS 840D POWERLINE Factory weight 500 kg Number of tools in the magazine 30 pieces Total power requirement 53 kW Description - 5 AXIS UNIVERSAL MACHINE CNC control SIEMENS 840D Tool changer 30 pcs SK 40 5 axes simultaneously C-axis 360 , A-axis +20/ - 100 " , TABLE BY 630 mm, 30 BARS IKZ additional, accessories SPAENEFOERDERER
used
Chiron FZ18W rotopallet 1999 CNC Siemens 840D X 630 Y 400 Z 425 tables (2) 850x450mm 20 tools ISO 40 / 7100 RPM / 18kW / 140 Nm 40m/min HAWE hydraulics automatic doors swarf conveyor machine can be inspected under power in our warhouse 6 ton 3,6 x 2,25 x 2,85
Table size: 700 x 1200 mm traverse path x/y/z: 600/300/350 mm spindle retainer: SK 40 ISA kl. / gr. Table/spindle distance: 150/540 mm spindle speeds: 45-6000 rpm number of tool stations: 12 pieces feeds: 5000-20000 mm / min rapid traverse rate: 5000-20000 m / min spindle drive: 5.5 kW Electr. Supply: 380 V, 12 kVA kW space: 2350 x 2100 x 2500 mm weight: 3800 kg
used
Table size: 550 x 950 mm traverse path x/y/z: 850/550/550 mm spindle retainer: BT 40 ISA kl. / gr. Table/spindle distance: 100/650 mm spindle speed: 8000 rpm number of tool stations: 24 pièces feeds: x/y 5-10000 / z 5-12000 mm / min rapid traverse: x/y 24 / z 20 m / min spindle drive: 11/15 kW Electr. Supply: 400 V, approx. 20 kVA kW space requirement: 2600 x 2220 x 2700 mm weight: 5200 kg
used
CHIRON MODEL FZ18W MAGNUM 4 axisVertical machining center with rotopallet and double 4th axis20 TOOLSISO 40Toolchange: 2.1 sec Spindle: 20 - 8000 RPM, 18,5k kWX = 625Y = 400Z = 400Rapids 40m/minTable area: 2 x 900 x 470- TSUDAKOMA heavy duty double 4th axis (Japan) 360.000 pos.- original HAWE hydraulic unit - FANUC 0m be inspected under power in our warehouse.Mimu Machine tools Italy
used
3-axis machining center X: 560 mm Y: 500 mm Z: 390 mm Rapid traverse rate: 4 m / min Table load: 800 kg Speed range: 4000 RPM Spindle retainer: SK 40 Headstock speed range: 4000 RPM Spindle drive: 4 kW Control: Dialog 11 Electr. Handwheel Coolant system direct measuring system Documentation Total power: 19 kW Machine weight: approx. 2.8 kg Dimensions (W x D x H): 3.66 x 3.5 x 2.1 m
Table size: 410 x 900 Traverse path x/y/z: 560/410/380 mm spindle retainer: SK 40 spindle speeds: 22-6000 rpm feeds: x & z to 10000, y up to 240 mm / min space: 2600 x 2000 x 2300 mm weight: 3500 kg
used
Table size: 460 x 1000 mm traverse path x/y/z: 762/460/460 mm spindle retainer: MAS BT 40 ISA kl. / gr. Table/spindle distance: 150/610 mm spindle speed: 15000 rpm number of tool positions: 32 pieces spindle drive: 22 kW Electr. Connection: kW 400 V
used
Control MSX-711-MAPPS IV Double pallet changer. Pallet diameter 500 mm. 2 axes NC swivel round table. B-axis 0.001 / 360. A axle +30/-120 - 0.001. travel distances: X 730 mm, Y 850 mm, Z 1,100 mm. preshoot/ejem up to 50,000 mm/min. Spindle holder HSK-63A. Spindle speeds up to 12,000 rpm. Tool magazine positions: 120. IKZ. Probe. tool load measurement. tool breakage control. usw... Little operating hours - Super condition.; Super
used
MSX-711-MAPPS IV CNC Control Twin pallet changer. Pallet diameter 500 mm. 2-Axis NC Rotary / Swivelling table. B-Axis 0.001° / 360°. A-Axis +30°/-120° - 0.001°. Travels : X 730 mm, Y 850 mm, Z 1100 mm. Feeds / Rapids to 50000 mm/min. Spindle taper HSK-63A. Spindle speeds to 12000 rpm. 120 station tool magazine. Coolant through the spindle. Measuring probe. Tool length measurement. Tool breakage control. etc... Low run hours - Superb condition. ; Super
used
CNC,5 axis JOBS,Linx Compact + Heidenhain TNC 530 HSCI Year of construction: 2013 X-2000 Speed up to 60m/min, Force (N) 9000 Acceleration 4.5 m/sec2 Y-3000 Speed up to 60m/min, Force (N) 9000 Acceleration 6.0 m/sec2 Z-1250 Speed up to 60m/min, Force (N) 9000 Acceleration 7.2 m/sec2 C - +/- 200 Straight , Torque 1200Nm ,Max torque with clamped axle 5000 Nm A - -120/+95 Torque 1200Nm, Max torque with clamped axle 5000NM Speed: 15,000 rpm Cone according to HSK-A-100 Weight : 70000 Kg Tool magazine type chain 32 tool positions, Max tool weight 15kg for more info, please call or write an e-mail. Machine is immediately available and in case of serious interest can be visited under power An invoice with VAT will be issued
used
5 axis machininng center (milling/turning from bar) Under power in our warehouse MAKE CHIRON MODEL MILL 800 5 axis CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 – 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs Coolant through spindle 70 bar (see note 4)
used
CNC Horizontal Lathe GURUTZPE Manufacturer: Gurutzpe YOM: 1974 retrofit 2010 Control: Siemens Sinumerik 820 Turning diameter: 1.380 mm Distance between centers 5.000 mm Center height: 600 mm Swing over cross slide: 1.100 mm Max workpiece weight: 17.000 Kg The tailstock is in the offer, stamds next to the machine – not visible on the photo
used
Machining center - vertical PRIMINER DELTA CENTER V6L camp-Nr. 1105-02424 category machining center - vertical make PRIMINER type DELTA CENTER V6L year 2018 State second-hand machine control CNC storage France origin country Germany Delivery time immediately cargo base EX WORK HAGUENAU Technical details x way 600 mm y-way 400 mm z-way 450 mm overall power demand 20 kW machine weight approx. 3.5 t description machine new with aim Electr. Establishment, coolant system IKZ 20 BARS, Techdoc. CNC SIEMENS 828 3D technical specifications DELTA CENTER V6L CNC control SIEMENS 828 3 D Table dimensions mm 750 X 400 MM T-slots 14 x 3 x 125 mm Maximum table load kg 350 X/Y/Z stroke mm 600 / 400 / 450 Distance spindle/table surface mm 80-530 Distance spindle Center / Z axle cover 435 mm Spindle retainer for SK 40 / 120 mm Spindle speed RPM 10,000 Spindle motor kW 20 SK 40 7/ ...
used
CNC WORKING CENTER type ALBERTI EDIT 3000 composition : 1. boring unit ( axe X and Y ) , vertical nad horizontal independent mandrins 2. vertical router 3. horizontal router CNC 90 by TPA volt. 380/50
Table size: 460 x 1000 mm traverse path x/y/z: 762/460/460 mm spindle retainer: MAS BT 40 ISA kl. / gr. Table/spindle distance: 150/610 mm spindle speed: 15000 rpm number of tool positions: 32 pieces spindle drive: 22 kW Electr. Supply: 400 V kW space: 3100 x 2500 x 2750 mm weight: 7500 kg
used
Facilities: -Console machine with cantilever -Pneum.. Workpiece stops with double-acting cylinders -Pneum.. Assembly AIDS -additional editing fields front (4-field machining) -Handheld -C axis -Swivel sawing unit to the grooves in the X - and Y-direction -Horizontal milling unit for lock box -Plate tool changer driving with - laser positioning aid for the cleaner -autom. Central lubrication system Technical data: -Traverse path Max X: 3.259 mm -Traverse path Max Y: 1,483 mm -Maximum Z: travel 325 mm -Speed Max x: 75 m / min -Speed Max Y: 75 m / min -Maximum Z: speed 30 m / min -Workpiece thickness max: 100 mm -Spindle motor power: 7,5 kW -Main spindle speed: 1000-18000 RPM -Recording of main spindle: HSK 63F -Recording spindles: M10 with 11 mm fit -Number of vertical spindles: 14 pieces -Number of horizontal twin spindles in the X direction: 1 piece in the Y-d ...
used
Machine type: CNC centerless grinding machine Make/Model: MIKROSA KRONOS M SPECS CNC Fanuc 21iM grinding wheel max sizes: 250mm wide x 610mm diameter 2 controlled axis on grinding wheel dressing (interpolated) 1 axis on regulating wheel 1 axis on plunge axis (workpiece diameter) Throughfeed grinding: yes Plunge grinding: yes can be inspected under power in our warehouse in Gussago BS (Italy)
used
MCM Clock 600 14 pallet 500x500 CNC FANUC 16iM 15000 RPM Jfmx Supervisor centro di lavoro multipallet FMS multipallet horizontal machining center in FMS under power in our warehouse Mimu machine tools (Italy)
used
C.M.S. CNC Turret Head Machining Center Model TRIAX R-65 Sn 285, 1986 IBH controller modus 1 (2) vacuum tables- each 48” deep x 60” long. (1) five station lathe section. Max. part 6.5” x 45” (2) vacuum pumps 5 hp. each. Total of (30) routers. (6) station turret with (5) routers per station. Consisting of; (2) stations of (5) routers each - 2 ½ hp. each. (4) stations of (5) routers each – 8 hp. each. Digitizing table for flat work or carving. Lathe section for spindle work (fluting, carving). Unit complete with extra parts and lots of tooling.
used
X-AXIS STROKE: 840 MM Y-AXIS STROKE: 860 MM Z-AXIS STROKE: 840 MM TABLE SIZE: 630 X 630 MM TABLE CAPACITY: 1,200 KG SPINDLE POWER: 30/25 KW ROTATION SPEED: 12,000 RPM ATTACHMENT: BT 50 NASOMANDRINO/PALLET DISTANCE: 50-810 MM SPINDLE-PLANK DISTANCE: 150-990 MM TOOL WAREHOUSE: 120 STATIONS MAX. WORKPIECE HEIGHT: 1000 MM CONTROL: MSG-502 YEAR OF BUILD: 2002
used
X-AXIS STROKE MM 2,400 Y-AXIS STROKE MM 960 AXLE STROKE Z MM 800 TABLE SIZE MM 2600X900 ATTACK: BT50 SPEED ROTATION REVOLUTIONS/MIN 12,000 TOOLS N ° 30 FANUC 31I MODEL A CONTROL YEAR: 2012
used
X-AXIS STROKE: MM 1,600 Y-AXIS STROKE: MM 810 Z-AXIS STROKE: MM 630 TABLE SIZE MM 1,750 x 770 ATTACK: ISO40 SPEED ROTATION REVOLUTIONS/MIN 15,000 REFRIGERATION THROUGH THE SPINDLE TOOL N ° 50 CONTROL: SELCA YEAR: 2008
used
YEAR 2012 STROKES X, Y, Z: 800X610X600 MM SPINDLE DISTANCE TABLE 150-720 MM FAST 36 M/MIN SPINDLE BT40 RPM 10,000 (12,000) RPM 30-SEATER TOOL WAREHOUSE CNC FANUC 18I-MD CHIP EVACUATOR ADDUCTION AT HIGH PRESSURE SPINDLE CENTER N ° 2 REVOLVING TABLES WITH ROTATING COUPLING FOR HYDRAULIC CONNECTIONS WITH LOCKING EQUIPMENT.
used
OKUMA MACHINING CENTER MODEL: MX-60HB TABLE: 630X630 mm X-AXIS STROKE: 1000 mm Y-AXIS STROKE: 810 mm Z-AXIS STROKE: 800 mm TOOL WAREHOUSE: 150 SEATS CONTROL: OSP-E100M
used
HORIZONTAL MACHINING CENTER NR. 2 KITAMURA HX500I WITH FATESYSTEM SHUTTLE Features: X-AXIS STROKE: 870 MM Y-AXIS STROKE: 710 MM Z-AXIS STROKE: 660 MM 4TH AXLE (ROTARY TABLE): 0.001-360 ° TABLE: 500 X 500 MM MAX PERMISSIBLE LOAD ON THE BOARD: 800 KG SPINDLE CONE: ISO50 ROTATION SPEED: 12,000 RPM GAMMA CHANGE: 2 GEAR RANGES FAST FEEDS: 50,000 MM/MIN TOOL CHANGE KITAMURA 1:100 SEATS TOOL CHANGE KITAMURA 2:50 SEATS CONTROL: FANUC 16 iM SHUTTLE FASTEM SYSTEM TO 16 STATIONS
used
OKUMA MACHINING CENTER MODEL: MA-400HA TABLE: 400X400 mm Nr. PALLET: 2 X-AXIS STROKE: 560 mm Y-AXIS STROKE: 610 mm Z-AXIS STROKE: 625 mm ATTACK: HSS63 TOOL WAREHOUSE: 60 SEATS CONTROL: OSP-E100M
used
CDL VERT. DAHLIH MODEL: DL-MCV 610 X-AXIS STROKE: 520 mm Y-AXIS STROKE: 330 mm Z-AXIS STROKE: 460 mm TABLE SIZE: 760 x 330 mm SPINDLE SPEED: 5,000 RPM FAST SPEED: 32 m/min ATTACO: BT 40 TOOL NUMBER: 16 CONTROL: FANUC 10M
used
Working size X 3000 ,Y 1000 mm Thickness 60 mm Vertical Boring spindle 29 Horizontal boring spindles in X 8 Horizontal boring spindle in Y 2
