cartoning used for sale

IWK SC 4 HS High Speed Horizontal Cartoner Cartoning Machine used The machine essentially consists of the following components: • Control cabinet with electrical control • Operation via screen, remote control via touch button • Product feed as pouch feeder • Product feed through XTS product chain (Beckhoff) • Folding carton feeder (folding carton belt with folding box cycloids for folding carton erection) • Product insertion • Folding carton transport by means of folding carton chain • Folding carton closure (sizing from the front, plug-in closure at the back from bottom to top) • Folding carton discharge for good packs and ejection for bad packs • Marking system Laser make Domino • Gluing device make Robatech including granulate container • Vacuum pump make Busch type Mink • Current format in mm 56 x 24 x 90, at 340 cycles / minute

The intermittent cartoning machine It is ideal for packaging blister packs. Equipped: - Blister consolidation station (programmable) and loading on the conveyor to bring to the cleat conveyor - Control station with Laetus Argus reader - Folding station and leaflet distribution - Loading and carton opening station - Embossed mark post on the case (full character set) - Alternating leg case closing station - Non-compliant product ejection station Technical data: Length: 6,000 mm Width: 1,550 mm Height: 1,700 mm Net weight: 4,000 kg Frequency: 50 Hz Voltage: 380/220 V Rated current: 8 A Fuse: 20 A max. Compressed air consumption: 6-10 Nm3 Supply pressure: 5-8 bar Throughput: 300 cartons/min max. Formats: 30 x 15 x 65 mm min. Formats: 75 x 75 x 150 mm max. Format of the leaflet: 100 x 80 mm min. Package leaflet: 210 x 300 mm max. Auction-ID: A1-51318-203

Automatic cartoning machine with alternating motion for vials, jars, tubes, bags, blister packs Equipped: - Adjustable bucket chain with interchangeable shims - Store pre-folded cases - Pre-folded leaflet store - Product introduction station with instructions in the cartons by pusher - Transfer of the cases by chains with adjustable combs. - Case closing station - Evacuation of finished cases - General drive by motor-variator - Protective guards with safety Current tools: Cases with alternating legs Capacity: Case dimensions: Minimum length 50 mm - maximum 170 mm Minimum width (pitch) 18 mm - maximum 100 mm Minimum height 12 mm - maximum 55 mm Maximum production: approximately 120 cartons/minute depending on the nature of the products Total electrical power: 1.5 kW Maximum compressed air pressure: 6 bar Auction-ID: A1-51318-230

Automatic alternating motion cartoning machine for vials, tubes, jars, blister packs, etc. Equipped: - Store pre-folded cases - Suction cup gripping of the cases - Chain with cleats for transferring cases - Closing station for the bottom of the cases - Pre-folded leaflet store - Spoon magazine - Automatic product introduction station with pick and place system - Closing station for the top of the cases - Evacuation of finished cartons on conveyor - General drive by motor-variator - Venturi for vacuum - Protective housing with safety Capacity: Case dimensions: Length: minimum (pitch) 40 mm - maximum 120 mm Width: minimum 40 mm - maximum 90 mm Height: minimum 50 mm - maximum 190 mm Maximum production: 40 cartons/minute Total electrical power: 4 kW Pressure: 6 bar Auction-ID: A1-51318-314

Semi-automatic alternating motion cartoning machine for vials, tubes, jars, blister packs, etc... Equipped: - Store pre-folded cases. - Sheathing by saber. - Chain with cleats for transferring cases. - Closing station for the bottom of the cases. - Manually introduced product entry station by one or two operators. - Closing station for the top of the cases. - Disposal of finished cases. - General drive by motor-variator. - Protective housing with safety. Capacity: Case dimensions: Minimum length (pitch) 20 mm - maximum 115 mm Minimum width 15 mm - maximum 70 mm Minimum height 50 mm - maximum 190 mm Maximum production: 60 cartons/minute Total electrical power: 1 kw Auction-ID: A1-51318-315

Description Uhlmann C200 blister cartoner – modernized and with extensive spare parts package Jandl PharmaTech Solutions offers a used Uhlmann C200 folding box cartoner from 1992 for sale. The machine has been modernized, is in a very neat condition and is immediately ready for use. It is offered with an extensive spare parts package. The cartoner is used for packaging blisters with package inserts in folding cartons. The machine was used in conjunction with an Uhlmann UPS1030 MTI blister machine, which we also offer under item number 03-J030. Machine data Manufacturer: Uhlmann Type: C200 Year of Make: 1992 Item number: 03-J031 Condition: very well maintained, ready for immediate use Modernisation: completed Scope of delivery: Machine with extensive spare parts package Product feeding and cartoning Blister feeder with stacking area Product transport to the sli ...

This machine can independently pick up large jumbo rolls and cut them into DIN A4 with up to 7 blanks and then fill them into boxes. Ideal for all products in the desktop sector, such as copy foils, laser film, synthetic paper, photo papers... etc. The hourly output is 250 boxes with 100 sheets of content per hour in DIN A4 format, processed from a roll directly into the boxes. The machine is still connected to us every day, so it can be tested, or we would also train a machinist on it. We dismantle, pack and load the machine at our expense, so that the buyer only has to take over the transport.
