used Brochure making machines for sale

DIRECTLY FROM THE PRINT SHOP Offer consists of: - Digital sheet feeder type DSF-2000 (YOC: 2009) - Bookletmaker type DBM 120 S/S (YOC: 2008) - Trimmer type DBM 120 T Technical details: Digital sheet feeder type DSF-2000 - with suction belt vacuum feed - Barcode readable - Up to 120 sheets per minute - Main station capacity 200 mm and transshipment station 60 mm - Weight: 136kg Bookletmaker Type DBM 120 S/S -Sheet by sheet booklet maker with digital dynamic changeover of the format, the stitching heads, the folding unit and the optional trimmer - 10 preset formats and 3 programmable ones - Brochure production length 200 – 450 mm, width 200 – 320 mm - Corner/edge stitching length 139 – 231 mm, width 200 – 320 mm, min. 148mm x 100 mm (with additional equipment) max. 320mm x 225 mm - Weight: 83,01kg Trimmer type DBM 120 T - Front cutter with automatic f ...

Offer consists of: - Gathering tower MC-80a - Staple and folding SPF-11 - Front cutter FC-11 Horizon MC-80a Suction Air Gathering Machine - Model: Suction and blowing air collection tower - Number of stations: 8 per gathering tower - Error avoidance: error, double-blade and jam control - Expandable to 6 towers (48 stations) Programs: - Double cycle (non-stop operation) - Zeroing (1x and 2x) - Brochure program - Selective gathering -Format: max. 740x318mm; min. 160x110mm - Paper weight: 50-260g/sqm - Charging capacity: 50mm/ station - Capacity: up to 5,100 sets/h - Electricity: 400V; 50Hz - 1.86kW - Weight: 229kg - Dimensions: 660x810x1,660mm Horizon SPF-11 Staple and folding unit: - Format setting: manual - Staple heads: 2 Expandable to 4 stitching heads - Stitching options: backstitch, block stitching, corner stitching - Eyelet stitchin ...

3 MONTHS WARRANTY Offer consists of: - Gathering tower VAC-100a - Gathering tower VAC-100m - Stitching and folding SPF-20A - Front cutter FC-20A Horizon VAC-100a / Horizon VAC-100m Suction air gathering machines - Technology: Touch & Work - Model: Suction and blowing air gathering tower - Number of stations: 10 per tower - Error avoidance: error, double blade and jam control - Job memory: 9 memory locations for repeat jobs - Expandability: up to 6 towers (60 stations) Programs: - Dual cycle (non-stop operation) - Zeroing (1x and 2x) - Brochure program - Block program - selective compilation - Format: max. 500x350mm; min. 148x120mm - Paper weight: 40-250g/sqm - Loading capacity: 55mm/ station - Output: up to 9,500 sets/h - Power: 230V/50Hz - 1,86kW - Dimensions: 842x652x1.961mm - Weight: 310kg Horizon SPF-20A Stitching and folding unit:  ...

AVAILABLE FROM MID-NOVEMBER 2023 3 MONTHS WARRANTY Offer consists of: - Gathering tower VAC-100a (YOC: 2008) - Gathering tower VAC-100c (YOC: 2008) - Staple and folding SPF-200A (YOC: 2013) - Front cutter FC-200A (YOC: 2013) Horizon VAC-100a/ VAC-100c Suction Air Gathering Machine - Technology: Touch & Work - Model: Suction and blowing air collection tower - Number of stations: 10 - Error avoidance: error, double-blade and jam control - Job memory: 9 memory locations for repeat jobs - Expandability: up to 6 towers (60 stations) Programs: - Double cycle (non-stop operation) - Zeroing (1x and 2x) - Brochure program - Block program - Selective gathering - Format: max. 500x350mm; min. 148x120mm - Paper weight: 40-250g/sqm - Loading capacity: 130mm/ station - Speed: up to 9,500 sets/h - Electricity: 230V; 50/60Hz - 1.86kW - Dimensions: 842x652x1. ...

3 MONTHS WARRANTY Offer consists of: - Gathering tower VAC-100a - Gathering tower VAC-100c - Staple and folding SPF-20A - Front cutter FC-20A Horizon VAC-100a / Horizon VAC-100c Suction air gathering machines - Technology: Touch & Work - Model: Suction and blowing air collection tower - Number of stations: 10 per gathering tower - Error avoidance: error, double-blade and jam control - Job memory: 9 memory locations for repeat jobs - Expandability: up to 6 towers (60 stations) Programs: - Double cycle (non-stop operation) - Zeroing (1x and 2x) - Brochure program - Block program - Selective gathering - Format: max. 500x350mm; min. 148x120mm - Paper weight: 40-250g/sqm - Charging capacity: 55mm/station - Capacity: up to 9,500 sets/h - Electricity: 230V/50Hz - 1.86kW - Dimensions: 842x652x1.961mm - Weight: 310kg Horizon SPF-20A Staple and fo ...

3 MONTHS WARRANTY Offer consists of: - Gathering tower VAC-100a - Gathering tower VAC-100m - Stitching and folding SPF-20A - Front cutter FC-20A Horizon VAC-100a / Horizon VAC-100m Suction air gathering machines - Technology: Touch & Work - Model: Suction and blowing air gathering tower - Number of stations: 10 per tower - Error avoidance: error, double blade and jam control - Job memory: 9 memory locations for repeat jobs - Expandability: up to 6 towers (60 stations) Programs: - Dual cycle (non-stop operation) - Zeroing (1x and 2x) - Brochure program - Block program - selective compilation - Format: max. 500x350mm; min. 148x120mm - Paper weight: 40-250g/sqm - Loading capacity: 55mm/ station - Output: up to 9,500 sets/h - Power: 230V/50Hz - 1,86kW - Dimensions: 842x652x1.961mm - Weight: 310kg Horizon SPF-20A Stitching and folding unit:  ...

used saddle stitcher Brehmer 1992 year 6 stations 1 station for hard cover 1 trimmer 2 sewing heads in production

3 x 1551 twin headed feeders (6 stations) 1 x 1528 cover feeder Twin headed 1550 stitching unit + 2 stitching heads 1 x 1565 three knife trimmer 1564 single delivery

Stitcher Müller Martini - Presto 3 x double investors 1551 -1 x cover feeder 1528.0417 -Stitching unit Presto - 1550 - three knife trimmer-1522 -Tape delivery -3 x pumps -Format max: 300 x 360 mm -Mechanical speed: 9,000 cycles per hour

Stapling machine nail Multinak S

DIRECTLY FROM THE PRINT SHOP We sell this machine on behalf of our customer and try to realize his asking price. However, we are open to offers from you. Offer consisting of: - Gathering tower S8 - Staples and folding Foldnak 100 - Front trimming trimmer 100 Nail Gathering Tower S8 Specifications: - 8 stations - Stack height cover sheet station: max. 130mm - Stacking height 2-7 station: max. 65mm - Format: min. 105x160mm; max. 364x520mm - Capacity: 5,000 sets/h - Dimensions: 2.140x650x770mm - Weight: 160kg Foldnak 100 Technical details: - Format: min. 140x148.5mm; max. 364x521mm - Capacity max.: 3000 sets/h - Dimensions: 115 x 72 x 118cm (HxWxD) - Weight: 220kg Trimmer 100 Technical details: - Brochure sizes: min. 74x148.5mm; max. 260,5x320 - Max. output: 3000 cuts/h - Brochure thickness max.: 5mm (approx. 50 sheets, 80g/sqm) - Dimensions: 106 ...

long arm cardboard stitcher length & cross stitching stitching arm length 500 mm stitches/min = 250 Machine is preset for specific type of wire - staple size 14x8 - round wire 21 (0.8) / flat wire IV/23 (0.65-0.80) - suitable solid cardboard 2-4mm thickness - specially suited for stitching deep boxes dims H135 x W45 x D80 cm weight 170kg Drive 400V - 50 cycles
