boring and drilling used for sale

Number of vertical independent spindles: 9 Number of horizontal spindles on axis X : (2+2) Number of horizontal spindle on axis Y: (1+1) N° 1 saw blade unit: (ø 100 mm) Router head 3,6 Kw ISO 30 - 12000/24000 rpm Max. thickness of the panel: 50 mm Control: Full Parametric Max weight of the panel: Kg 25 Max panel size: X ,Y 1100, Z 50 mm Min panel size: X 270,Y 150 (70 op.), Z 12mm Number of controlled axes: 3 Panel feeding speed: 25m/min Spindles speed rotation: 3600 rpm Saw blade speed rotation: 7000 rpm Air pressure: 7 bar Diameter of the dust extraction: ø 140 mm Exhaust air consuntion: (2000 mc/ora) - (30 m/s) Max drilling depth in horiz. on X and Y axis: 30 mm Max drilling depth in vertical: 45 mm Max horizontal diameter of the tools: 12 mm Max vertical diameter of the tools: 35 mm Motor power: 1,5 kw Max air consumption: 60 Nlt./min. Total power : 6,4 Kw  ...

High precision drilling and milling machine Aciera 22 VA Good condition from school operations Year of construction approx. 1990 Table 600 x 320 mm Speed 40 - 3600 rpm Speed setting rpm 4 automatic feeds 40-280 80-560 275-1800 550-3600 Spindle diameter 65 mm Drilling spindle stroke 120 mm Spindle holder: Aciera quick-change system Automatic thread cutting Drilling capacity in solid material 25mm Max drilling capacity up to 30mm Height adjustment via hand crank Motor: 1.1 KW Lamp Some quick-change shots Dimension WxDxH 90 x 130 x 185 cm Weight approx. 800 kg Technical information subject to reservation

I sell a Top Dubel drill multi-spindle drill Detel M-13, built in 2007. 3-spindle See good condition. Available the same.

Multi-stand drill Prior sale reserved - errors possible Internal Reference Number: D-1143-1

I sell a drill with cutting units COMEC FM0V8 2000, built in 1997. Working width max. 2000mm Configuration: 0 motors from below 1+1 motors from sides / angular adjustable 2 motors from behind / head angular adjustable 3 motors from above / head angular adjustable 4 pieces of material prints from above 2 cut saws from above / head angular adjustable Atypical 5-spindle drill heads Including 3 x 15mm / 2 x 25mm. Dubel heads in the price. Very good addition. Available the same.

Multi-spindle drilling machine from Bernhard Steinel - Machine Tool Factory Schwenningen/Neckar ran reliably until the end The machine is equipped with a foot pressure switch from Festo a drive motor from Bauknecht and a control box from Siemens Pneumatic lines should be checked/repaired before The machine can be viewed at any time. Transport via freight forwarder can be arranged at short notice -feel free to take a look at the other advertisements or visit us directly at Gerstenstraße 2, 17034 NB The price is net plus 19% VAT If you have any further questions, please call or write. Maschinenhandel Nord new & used machines for industry, trade and commerce

Inv. Num. : 8262 Type: PR 99-20 Producer: Cobalm Created: 2011 Parameters: Axis X: 3400 mm Axis Y: 1900 mm Axis Z: 280 mm Cutting thickness: 200 mm

Automatic multiple drilling machine for chair seats CAMAM mod. FMV/4U with 4 drilling units - N. 4 independent drilling units - Control panel - Year 1996 - CE compliant

Door belt drilling machine for processing aluminium profiles with pneumatic material tensioners and micro spraying device Processing length: max. 2400 mm Wing profile width max. 108 mm Frame profile width: max. 200 mm Profile height: 45-80 mm Spindle speed: 1900 rpm Weight: approx. 500 kg

Quantity: about 190 pieces Type: HSK63 Status: Opportunity Set including numerous HSK63 tool holders, ER collet chucks, cutter holders, face heads, boring heads, adapters, cones and various accessories, presence of mounted carbide cutters, different diameters and lengths, storage in wooden crates

Condition: Very good condition Available: Immediately

Boring power:10 mm weight:590 kg connected load:2 kW dimensions::1500 x 1300 x 2300 mm

Drilling / Jig Boring Machine CONSTANT SUPEMEC type P65 Travel X: 500 mm Travel Y: 300 mm Travel Z: 550 mm Cone: SA40 Spindle speed: from 77 to 1520 RPM Table size: Length 1200 mm x Width 420 mm Maxi distance spindle nose/table: 670 mm Mini distance spindle nose/table: 120 mm Throat depth: 300 mm Variable speed drive for X - Y Voltage: 380 V Width: 1600 mm Depth: 1800 mm Height: 2400 mm Total width with control panel: 2700 mm Weight: 3 T

Auction-ID: A1-45188-198

Table, Drilling and Tapping Machine FLOTT Type TBZ 15 GLFabr. No. 32177027 year of construction 1986Drilling capacity 15 mmSpindle mount MK2Throat depth 195 mmPine stroke 80 mmTable size 275 x 200 mmColumn diameter 70 mmSpindle speed 80 - 4500 rpm. 18 stepsMotor power 0.55 + 0.75 kWNet connection 380 volts, 50 Hz- 6 belt steps from the motor and 2 belt stages to the drilling spindle 2 motor speeds- 3 pieces guide cartridges 0.7mm + 0.8mm and 28G available- Drill head height adjustment via crank with rack on the

automatic CUTTING BORING and MOULDING machine BACCI TTF1 2TM . second hand machine working conditions : Excellent hydraulic drive of all the movements volt. 380/50 CE mark : YES Machine suitable for assembling part of chairs, tables, frames, furniture, wheelchair frames, etc. The BACCI TTF1 2TM performs the operations of cutting , milling and drilling at the end of the piece, either singularly or differently combined . the milling unit is composed of n.02 spindle moulders ( anti-splinter system ) machine composed by 3 working units : 1- Cutting unit : circular saw max.diam. mm.400 motor power Hp 3 2- Boring unit : boring head with 5 mandrins motor power Hp 3 3- Moulding unit . with automatic movement of the carriage on recirculating ball bearings n.02 spindle moulders (anti-splinter) motor power Hp 7,5 spindle diam. mm.35 hydraulic unit motor power Hp 2

Code: 0253 Brand: LARI E LARI - ITALY Model: FR 20 - TA - CE Standard Working center for milling and boring on wood or plastic and composite materials, wooden doors, window frames - CE Standard Technical data: X-axis working stroke 3250 mm Y-axis working stroke with 90° cutter 130 mm Z-axis working stroke with 0° cutter 290 mm Z-axis working stroke with 90° cutter 175 mm X-axis working speed mt/min 40 Y-axis working speed mt/min 30 Z-axis working speed mt/min 30 Hinge boring inserting unit: Male/Female Speed control inverter Probe Tool holder collet ER 25 Power of anuba head drilling electric spindle 2,2 Kw Anuba head inclination -10 +90° Electric spindle for milling: 2,7 Hp at 18,000 rpm Collet chuck ER 32 Variable speed via inverter Inclination from 0 to 90° for both vertical and horizontal machining Machine computer: numerical control - Win ...

Spindle diameter 203.2 mm x-travel 9,000 mm y-travel 4,000 mm Grinding spindle diameter 335 mm Spindle holder ISO 60 Spindle speeds 1-350 / 5-1,200 rpm w-axis 800 mm z-axis 1,200 mm Rapid x-axis 8,000 m/min Rapid y-axis 6,000 m/min RAM Dimensions 530 x 600 mm Main drive 75 kW Total power requirement 165 kW Machine weight approx. 130 t Space requirements approx. 16 x 5.5 x 8.1 m Addition: - hydrostatic guides in x-, y- and w-axis - Telescopic cover for the X-axis of the bed - cumulative Z and W axes - Leveling shoes - Platform Y axis

Travel X-axis 19,000 mm Y-axis 3,500 mm Z-axis 1,000 mm W-axis 1,000 mm V-axis 2,500 mm B-axis 360°/ 0.001 Table size 4,000 x 3,500 mm Maximum permissible weight on the table 65 t Spindle diameter 160 mm Mounting cone in spindle 2079 DIN/ ISO 50 Spindle speed 2.5 - 1,000 rpm Spindle motor power 90 kW RAM cross section 400 x 400 mm Automatic tool changer 60 positions Feed in all axes 1 - 6,000 mm/min Rapid response in all axes 10,000 mm/min Automatic indexing 360,000° Plate field 12,750 x 6,000 mm CNC, electrical and mechanical overhaul by Siemens in 2003

Travel X-axis 9,500 mm Y-axis 4,100 mm Z-axis 950 mm W-axis 900 mm Main spindle speeds (infinitely adjustable): 3.15 - 1000 rpm Spindle motor power 58 kW Feed speed (infinitely adjustable): X-axis 0.1 - 9600 mm/min Y-axis 0.1 - 5600 mm/min Z-axis 0.1 - 5600 mm/min W-axis 0.1 - 5600 mm/min Accessories: Plate field: 6 x 4 m (CNC-controlled B- and V-axis) Table: 2 x 2 m (CNC-controlled B- and V-axis)

Universal milling machine vertically / horizontally from a training workshop Manufacturer Hermle Type FW801 Tool holder SK40 automatic feed in three axes Digital display in three axes Machine technically in very good condition under electricity ready for demonstration Technical data: Travel: x=350mm y=150mm z=220mm Spindle speeds from 50 to 3,150 rpm can be infinitely variable Feed speed infinitely adjustable via rotary pot from 10 to 5,000 mm/min, aisle Special price Used milling machine Hermle FW 801

Dowel drilling and drive-in machine Biesse type F/S Technical data: • Drill head: 21 spindles • Glue guns: 6

CNC unit for routing and boring Brand: Atemag Type: Function Line Soft Touch One With surface copying function with fix spindle ER25 and fix bell Max. drive speed 18,000 R.P.M. Max. tool spindle speed 18,000 R.P.M. Gear ratio i = 1:1 Turning direction left/right Torque max. 10Nm Tool interface: fix ER25 Adjustment distance: 70mm

horizontal slotting machine / high-speed planer Manafacture: Klopp Model: 550 Year of construction: 1982 Planer length: 550mm Weight: approx. 1250 kg

Key data: 8 mm, 1

Koch Drilling and Dowel Inserting Machine Sprint PTP 3/1800 Working field: 1800mm / 2x 900mm Equipment: 1x horizontal drilling station 0.9 kW, drill speed 7200 rpm Drilling depth 30 mm Drill bit holder 10 mm, total drill length 85 mm 2x glue dispensing and dowel insertion station 2x dowels 10x40mm, dowel protrusion 15-20mm Dowel spacing 96mm 2x vibrating conveyor dowel 10×40 mm 1x Glue pump 18:1 2x electronic glue monitoring ELC Workpiece support table 1700 mm 8x workpiece clamping cylinders Center fence for 4 working areas Central lubrication with hand pump for grease lubrication NC positioning of the height adjustment of the drilling and dowel station (z-axis) Axle with position control, travel speed 12m/min Koch Numeric positioning control with 1 NC axis (X) – with PC, operating system Windows XP Professional: English, 10.4" touch panel – VGA graphics + touchs ...

Heidenhain TNC 124 Year of construction 1996 Spindle holder ISO 40 Travel 310 x 170 x 340 mm 16 spindle speeds from 40 - 2500 rpm Infinitely variable feeds Weight approx. 700 kg

TOS W 75

BFT 90/3 SPINDEL 102 , ISO

Universal Milling & Drilling Machine DECKEL MAHO DMU 50 M With control Heidenhain TNC 124 Year of construction: 2001 Travels: X 500 Y 400 Z 400 Speed range: 20 – 4,500 rpm infinitely variable With the following accessories: Manual swivel – rotary table with digital display for C + B axis 700 mm x 500 mm clamping surface Electronic Handwheel for X, Y, Z Axis Splash protection booth Machine light 4 pcs. Height-adjustable machine shoes Coolant system Operating instructions THE MACHINE WAS ONLY USED FOR APPRENTICESHIP TRAINING THE MACHINE IS IN GOOD CONDITION

Universal tool milling machine KUNZMANN WF 4/3 With 3 axes Heidenhain digital display Year of construction: 1996 Travels: X 400 Y 320 Z 400 Speed range: 40 – 2550 rpm With the following accessories: Rigid angle table 800 mm x 360 mm clamping surface Mechanical handwheels for X, Y, Z axle Hydraulic tool clamping Automatic central lubrication pump for X, Y, Z axis Machine light 4-Piece Machine Shoes Coolant system Operating instructions THE MACHINE WAS ONLY USED FOR APPRENTICESHIP TRAINING THE MACHINE IS IN GOOD CONDITION

X axis travel 12.000mm Max height under head 1.800mm Y axis travel 3.200mm Z axis travel 1.000mm W axis travel 2.100mm Table dimensions 12.000 X 3.000mm Max weight on table 60 ton Spindle power 47 Kw Max spindle speed 4.000 Rpm CNC SIEMENS 840 D Head changer with nr.04 heads ATC 60 utensili Rebuilt year 2008

YOM 2009 X axis travel 28.000mm Y axis travel 6.500mm W axis travel 2.000mm Z axis travel 1.500mm Table dimensions 25.000X5.000mm Automatic head changer with Nr. 03 heads Nr.10 planos 5.000X2.500X300mm CNC SIEMENS 840 D nr.03 axes automatic head in continuos, spindle speed max 4.000rpm,56 Kw, HSK A 100 Vertical head max spindle speed 3.000rpm,56 Kw, HSK A 100 Angular head max spindle speed 3.000rpm,56 Kw, HSK A 100 High pressure refrigeration trough spindle (50 bar) ATC 120 positions

SECOND-HAND END-CUT OFF BORING AND MILLING MACHINE BACCI MOD. TTF1 - CE RULES - volt. 380/50 - S/N 333 - year 1995

AUTOMATIC CUTTING , BORING and MOULDING machine model BALESTRINI FTA machine for joining parts of chairs, living rooms, furniture, etc. the FTA machine is made up of 3 automatic operating units : 1st unit : circular saw for cutting workpieces to length 2nd unit : spindle moulder for milling with hydraulic sliding carriage 3rd unit : drilling unit with multiple center distance head . there are 9 work programs that can be selected and they consist of the possible combinations of use of the 3 operating units. only 2 can be used , or 1 , or even the 3 operating units can work in different sequences . Technical data : - Cutting unit (circular saw) diam.mm.400. engine power Hp 3 - Moulding unit (spindle moulder) shaft diameter mm.30 . motor power Hp 5.5 max. tool dimensions mm.160, H=mm.120 . hydraulic sliding carriage - Boring unit . engine power Hp 3 . max. depth drilling mm. ...

Key data: 500 mm, 400 mm, 400 mm

Universal Milling & Drilling Machine DECKEL MAHO DMU 50 M With control Heidenhain TNC 320 Year of Make: 2001 Travel: X 500 Y 400 Z 400 Speed range: 20 – 4,500 rpm infinitely variable With the following accessories: Manual swivel – rotary table with digital display for C + B axis 700 mm x 500 mm clamping surface Electronic handwheel for X, Y, Z axis Splash guard cabin Machine Light 4 Height Adjustable Machine Shoes Coolant Setup Operating instructions

Precision face and boring chuck WMW A 100 - 4 ( A100-4 ) TGL 32680 ( TGL32680 ) Dimensions: 210 x 100 x 85 mm

Face and boring head NAREX Vhu 80 ( Vhu80 ) holder: SK50 in wooden case used, tested ! Dimensions: 420 x 410 x 155 mm

Magnetic swivel table as shown in the pictures. Further information on request

TOS ,W 100 , YEAR 1976, SPINDEL MORSEA

Make: Tos Machine No: F641 Type SPEEDtec CNC brand Siemens CNC type Sinumerik 840D Year of construction 2009 X 1,250 mm Y 1,000 mm Z 600 mm Mounting HSK 100 Motor power 25 kW Speed 12000 RPM Tool Changer Number of pallets 4 Outgoing Aries Including manuals Maximum speed 12,000 RPM Maximum pallet load 4,000 kg Chip transport Magazine slots: 2x 40 , HSK 100 4 tables, 1x 1,000 x 1,250mm / 3x 1,000 x 1,000mm

Demonstration article Slight signs of wear Milling and drilling unit MFB 16 Vario Standard equipment - Keyless chuck B 16 / 1 - 16mm - Tapered mandrel MK 2 / B 16 with IG M10 - Tightening spindle M10 - Emergency stop button / zero-voltage trigger - Tool Kit / Instruction Manual / CE Optional accessory - Coordinate table base plate for MFB 16 Vario - Milling set TITAN, 20 pieces, Ø 3 - 20 mm - Vise 3' / 75 mm for SUPERTURN 550/125 Vario - Collet Set MK 2 (ER 25), 10 pieces, 2 - 16 mm Free delivery throughout Austria Subject to prior sale

Universal face and boring head LENZ type LPA 1SSpindle tool, spindle head similar to WOHLHAUPTER UPA3Tool holder: SK 40 - M16Adjustment accuracy: 0.01 mm- Accessories as shown- Storage boxWeight: approx. 5 kggood condition; used


Universal tool milling machine TOS FNGJ 32 3 Axis Heidenhain Digital Display Year of Make: 1999 Travel: X 600 Y 400 Z 400 Speed range: 40 – 2000 rpm With the following accessories: Rigid angle table 800 x 400 mm clamping surface Vertical milling head Extendable drill quill Various tool holders SK 40 Safeguard Chip tray Machine Light Automatic central lubrication pump for X,Y,Z axis Coolant Setup 4 pcs machine shoes

I am selling this machine. It can be tested when connected. Very good condition. X 11,500, Y 3,150, Z 2,000, clamping M 100. The machine comes with a support column, 6 plates, a rotating table E 20, heads, etc. This is a complete workstation.

SPINDEL 115 , ISO 50 , X,Y,Z - 2000 DRO TABLE 1400 X 1600

Universal tool milling machine DECKEL FP 3 With 3 axes active digital display Heidenhain TNC 11 Year of Make: 1984 Travel: X 500 Y 300 Z 400 Speed range: 25 – 2500 rpm With the following accessories: Rigid angle table 850 mm x 400 mm clamping surface Swivel rotary table 0 450 mm with dividing discs Bumper Sliding vertical milling head Extendable drill quill Stepless feed via potentiometer Various milling mandrels SK 40 / S22 x 2 Chip tray Automatic lubrication pump for X,Y,Z axis Machine Light Coolant Setup 4 pcs machine shoes Operating instructions

Manufacturer ZAYER Model 30 KMU-5000 Year 1999 CNC HEIDENHAIN TNC-430PA Table surface 4,700 x 1,200 mm. Strokes (X/Y/Z) 3,400/1,250/2,000 mm. Shaft Outlet (W Axis) 500 mm. ISO-50 Head Cone Main Motor Power 37 kW 45º Automatic Head INCLUDED Head Rotation 45º Automatic Rotation 0.001º/0.001º Head revolutions 45º 3,000 rpm 45º ISO-50 Head Cone Continuous Twist Head INCLUDED Twist head revolutions 3,000 rpm Twist Head Cone ISO-50 Ram with cane INCLUDED Shank diameter 150 mm. ISO-50 Rod Cone Internal and external cooling head 45º and rod INCLUDED External cooling twist head INCLUDED Semi-automatic head pickup INCLUDED Automatic Loading Tools INCLUDED Loader Positions Htas 60 AITEK Pickup Station for 45º head storage and Twist Head INCLUDED Chip Evacuator INCLUDED HEIDENHAIN HR-410 Portable Steering Wheel RENISHAW MP 16+SP2/1 Piece Measurement Probe Motors + ...

CONTROLS   CNC controls NUM 1060 WORKING RANGE TURNING   swing diameter (max): 2000 mm   workpiece weight max.: 25000 kg CROSS BEAM SLIDE   - rotation speeds (min): 2 /min   - rotation speeds (max): 450 /min ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 4100 mm   space requirements -front/back-: 3500 mm   total height: 5600 mm

3 Axis Digital Display FAGOR Year of Make: 1975 Travel: X 500 Y 200 Z 400 Speed range: 40 – 2000 rpm With the following accessories: Universal table 660 x 380 mm clamping surface Vertical milling head Extendable drill quill Milling cutter protective housing Machine Light Various tool holders SK 40 Chip tray Coolant Setup 4 pcs machine shoes Operating instructions THE MACHINE IS IN VERY GOOD CONDITION
