boring and drilling used for sale

1 set of boring bars for main bearing boring mill, carriage via cone, sleeve. Dimensions: DxL 20x940 mm 27x1100 mm 31.5x1400 mm 39.7x1700 mm Sale preferably as a set Price on request

M. No.: 85039 // Model: 371 Equipment / Additional information: Ø max. 15 mm Distance between drills: 60-120 mm

Manafacture: Skoda Type: E25OB23941 Year: 1989 Part weight: up to 25t Dimensions: 2,000 x 2,000 mm electr. adjustable Weight: 10t

Boring mill turntable, used Boring table, used Typ/ type: TI 2 Manufacturer/ make : UNION Year of construction: 1984 Table size: 1800 x 2000 mm ; > 360° Fahrweg/ way : 1250 mm Feed speed: 0.5 to 1600 mm/min Tischbelastung/ table load: 15000 kp Gesamtlänge/ total length: 3500 mm Gesamtbreite/ total width: 2250 mm Weight/ weight: 7 t Feed motor: 6 kW

Jig Boring Machine WMW BKoE 450 x 800 Travel X: 560 mm Travel Y: 400 mm Travel Z: 470 mm Spindle: Ø 90 mm Cone: CM4 Spindle exit: 150 mm Spindle speed: from 50 to 1600 RPM Table size: 450 x 800 mm Maxi loading capacity on table: 400 kg Scale3 axes HEIDENHAIN Automatic descent Voltage: 380 V Width with ends table: 2900 mm / without ends table: 1500 mm Depth:2500 mm Total height: 2600 mm Weight: 4,5 T

Specifications: X-axis 2,750 mm Y-axis 2,500 mm Z-axis 2,320 mm W-axis 700 mm Spindle power 50 kW Spindle diameter 130 mm Spindle speed 1.6 – 1,600 rpm. Tool holder SK 50 Control: CNC HEIDENHAIN TNC426 Table dimensions 2,000 x 1,800 mm max. table load 8 tons B-axis 360 A° Weight approx. 37,000 kg

Technical data of used Schiess Froriep Boring Machine: CNC: Siemens 840 D Maximum transversal travel X axis: 13.770 mm Maximum vertical travel Y axis: 5.000 mm Z axis: 1.780 mm W axis: 950 mm V axis rotating support plane: 2.000 mm Rotating table dimensions: 5.000 x 3.500 mm Fixed table dimensions: 7.500 x 4.300 mm Maximum permissible load on the table: 120 ton Spindle power: 100 kW Spindle revolutions per minute: 710 rpm

Key data: 130 mm, 4000 mm, 2500 mm

TOSHIBA BP-130R22 Year 2007 SPINDLE DIAMETER 5.12" (130mm) TAPER IN SPINDLE #50 VERTICAL TRAVEL, Y-AXIS 100" (2500mm) CROSS TRAVEL, X-AXIS 160" (4000mm) SPINDLE TRAVEL, Z-AXIS 28" COLUMN TRAVEL, W-AXIS 60" TABLE SIZE (BUILT IN B-AXIS) 86.6" X 70.8" TABLE LOAD CAPACITY 44,000 LBS TABLE INDEXING B-AXIS 0.001 DEGREE SPINDLE SPEEDS (3-RANGES) 5-2500 RPM EQUIPPED WITH: TOSNUC 888 CNC CONTROL 60-STATION AUTOMATIC TOOL CHANGER THROUGH SPINDLE COOLANT CHIP & SPLASH ENCLOSURE CHIP CONVEYOR 40/30 HP SPINDLE MOTOR NOTES: INSPECT IN PLANT UNDER POWER

Sr. No.: 70218 Equipment / Additional information: Various tools

Ref. -No.: 10353 Manufacturer: UNION Year of construction: 1986 Type of control: Konventionell Storage location: Halberstadt Country of origin: Deutschland X-Travel: 1600 mm Y-Travel: 1000 mm Z-Travel: 1200 mm W-Axis: 710 mm Spindle Taper: SK 40 Table Load: 2500 kg Max. Size Of Workpiece Lxwxh: Höhe 1400 mm Spindle Speed: 1600 RPM Rapid Traverse: 3,15 m / min Total Power Requirement: 23 kW Weight Of The Machine Ca.: 10,3 t

Ref. -No.: 10354 Manufacturer: UNION Year of construction: 1998 Retrofit: 2000 Type of control: Digitale Steuerung 2D Control: HAIDENHAIN TNC 135 Storage location: Halberstadt Country of origin: Deutschland X-Travel: 1600 mm Y-Travel: 1250 mm Z-Travel: 1475 mm Spindle stroke: 710 mm Table Dimensions (Lengthxwidth): 1250x1400 mm Spindle Speed: 1600 RPM Drive Capacity - Spindle Motor: 30 kW Total Power Requirement: 35 kW

Ref. -No.: 10022 Manufacturer: UNION Year of construction: 2001 Type of control: CNC Control: Heidenhain-Steuerung TNC 310 Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2000 mm Y-Travel: 1600 mm Z-Travel: 2000 mm Machine length: 6950 mm Machine width: 4685 mm Machine Height: 3885 mm Table Height: 1050 mm Spindle Diameter: 110 mm Spindle Taper: ISO 50 Table Dimensions (Lengthxwidth): 1400 x 1600 mm Faceplate speed: 5,6 - 224 RPM Spindle Speed: 5,6 - 1120 RPM Metric thread feeds: 1,25 - 56 mm Drive Capacity - Spindle Motor: 40 kW Weight Of The Machine Ca.: 25 t Bore Depth: W 800 mm Further information: with facing slide 13 inch thread feeds 1 1/8 - 28 Gg / 1 “ YOM: 1990/ Retrofit: 2001

Longitudinal direction ''X''. 4500 mm Transverse direction ''Y''. 3000 mm Spindle stroke ''Z'' 500 mm Astand Spindle Table 160 – 660 mm Table load 2000 kg/m²

Condition: Very good condition

Key data: 130 , 3500 , 2000

CNC SIEMENS 840D X-axis (longitudinal) 3500 mm Y-axis (transverse) 2000 mm Z-axis (vertical) 1250 mm Table length 1800 mm Table width 1800 mm Maximum workpiece weight 12000 kg Spindle diameter 130 mm Maximum spindle speed 800 rpm Magazzino utensili 52 posti Spindle motor 37 kW Year of revision 2005 ------------------- Length x width x height 7200 × 7800 × 4900mm Weight 32000 kg

SKODA W200GNR 1978 /CNC MEFI 836 y.m. 2005 ball screws y 4150mm x 8000mm millng heads floor plates 5600x1885x400 rotary table E20 load 20tons

W160HC with ISO 50 y.m. 1987 xtravel 4000mm y travel 3150mm rotary table S35C load 35tons, 3150 x 2800mm milling heads, tools

Table capacity 80 TONS Clamping plate width mm 3550 length mm 4000 Carriage travel V mm 2000 Heidenhain scale Rotary axe B ROD 700 Table height mm 1460 Table weight kg 52000

Saw-Drill Manufacturer: Pade Model: EV 25 Built in 1995 Sawing unit Drill gear with 5 spindles

Key data: 80 mm, 1700 mm, 1800 mm

Spindle Diameter: 80 mm Spindle Adapter: SK50 Spindle speeds: 11 - 1000 rpm. X-axis: 1700 mm Y-axis: 1800 mm Z-axis: 1800 mm Spindle off (W-axis): 710 mm Table dimensions: 1100 x 900 mm Elbo Digital Readout: On Y-axis and Z-axis Equipped with: -Turntable - Some tool containers Spindle motor: 7.5 KW Machine LxWxH: 5100 x 2650 x 3300 mm Machine Weight: 10 Ton

In-line drilling rig with 8 height- and width-adjustable drilling spindles (optionally up to 12 drilling spindles and an extension to a drilling area of 4,000 mm x 240 mm – without moving the workpiece) VIDEO LINK on request Drive power 0.75 kW per drilling spindle (optionally, the system can be supplied with more powerful drilling spindles - 1 kW / 1.25 kW - 1.5 kW), drilling spindle speeds up to 12,000 rpm - infinitely variable via potentiometer and frequency converter - set speed can be read analogously, drill tension by collets ER25, largest drill diameter 12 mm, drilling feed speed infinitely adjustable, drilling depth of each drilling unit individually infinitely adjustable, largest drill slide stroke 80 mm - Adjustment range for angled holes +/- 30 °, smallest distance from drill center to drill center 110 mm, horizontal adjustment range of the beam of the drilling units  ...

In-line drilling rig with 8 height- and width-adjustable drilling spindles (optionally up to 12 drilling spindles and an extension to a drilling area of 4,000 mm x 240 mm – without moving the workpiece) VIDEO LINK on request Drive power 0.75 kW per drilling spindle (optionally, the system can be supplied with more powerful drilling spindles - 1 kW / 1.25 kW - 1.5 kW), drilling spindle speeds up to 12,000 rpm - infinitely variable via potentiometer and frequency converter - set speed can be read analogously, drill tension by collets ER25, largest drill diameter 12 mm, drilling feed speed infinitely adjustable, drilling depth of each drilling unit individually infinitely adjustable, largest drill slide stroke 80 mm - Adjustment range for angled holes +/- 30 °, smallest distance from drill center to drill center 110 mm, horizontal adjustment range of the beam of the drilling units  ...

In-line drilling rig with 8 height- and width-adjustable drilling spindles (optionally up to 12 drilling spindles and an extension to a drilling area of 4,000 mm x 240 mm – without moving the workpiece) VIDEO LINK on request Drive power 0.75 kW per drilling spindle (optionally, the system can be supplied with more powerful drilling spindles - 1 kW / 1.25 kW - 1.5 kW), drilling spindle speeds up to 12,000 rpm - infinitely variable via potentiometer and frequency converter - set speed can be read analogously, drill tension by collets ER25, largest drill diameter 12 mm, drilling feed speed infinitely adjustable, drilling depth of each drilling unit individually infinitely adjustable, largest drill slide stroke 80 mm - Adjustment range for angled holes +/- 30 °, smallest distance from drill center to drill center 110 mm, horizontal adjustment range of the beam of the drilling units  ...

Horizontal Boring Machine CORNAC C100 Travel X: 1000 mm Travel Y: 1000 mm Travel Z: 1260 mm ixed table Cone SA 50 Spindle: Ø 100 mm Spindle exit: 550 mm Rotation: from 10 to 1250 RPM Table size: 1550 x 980 mm Surfacing plate: Ø 520 mm Spindle motor: 9,5 kW Scale 3 axes HEIDENHAIN Automatic Feeds: X - Y - Z Supplied with a set of cones Voltage: 380 V Dimensions (L x W x H): 4500 x 2100 x 2450 mm Weight: approx 8 T

Inv. Num. : 7631 Type: F80 Produzent: Pfeifer Erzeugt: 1976 Parametern: Maximale Drehzahl der Spindel: 1000 1/min Verfahrwege X-Achse: 1700 mm Verfahrwege Y-Achse: 1800 mm Verfahrwege Z-Achse: 1800 mm Verfahrwege W-Achse: 710 mm Spindeldurchmesser: 80 mm

Monti MCS 100 NEW boring machine :::TECHNICAL SPECIFICATIONS::: CNC Model: Siemens CNC Version: 840D Tool Mount: ISO 50 Spindle power: 24Kw Number of spindle speeds: 4000 Number of tools: 60 X-axis travel: 2500mm Y-axis travel: 1500mm Z Axis Travel: 1700mm Fast feeds linear axes X Y Z: 20m/min Spindle spindle stroke : 600mm Rotary table: yes Table size: 1300 x 1500mm Allowable load on the table: 4000Kg Other technical data: The machine is being built this year Machine equipment: Anthropomorphic robot for tool change management Heidenhain Optical Scales :::D DIMENSIONS AND WEIGHT::: Weight: 23000Kg

Sr. No.: 111000253 // p/n: 1364000

STANKO 2N636GF1 Horizontal boring mill MITSUBISHI controler, new 2013 Spindle 125 mm Table 1600 x 1800 mm Max. horizontal (axial) movement of the spindle (Z') - 1000 mm Max. vertical movement of the headstock (Y)- 1400 mm Max. longitudinal movement of table (Z, W) - 1600 mm Max. lateral movement of table (X) - 1400 mm The largest mass of the processed product - 8 tons Spindle speed - 8 ... 1250 rpm Spindle Drive Electric Motor - 20 kW The weight of the machine is full - 34.6 tons

Key data: 102 mm, 1530 mm, 900 mm

Spindle diameter Ø 102 mm Taper ISO 50 Horizontal spindle travel 710 mm Cross travel (X) 1,530 mm Vertical Travel headstock (Y) 900 mm Longitudinal travel (Z) 1,500 mm Table 1,250 x 1,400 mm R.P.M. 8 – 1,600 (18x) kW 11 Volts 380 Cycles 50 Including: Digital readout

Key data: 102 mm, 1600 mm, 900 mm

Spindle diameter Ø 102 mm Taper ISO 50 Horizontal spindle travel 710 mm Cross travel (X) 1,600 mm Vertical Travel headstock (Y) 900 mm Longitudinal travel (Z) 1,520 mm Table 1,250 x 1,400 mm R.P.M. 8 – 1,600 (18x) kW 11 Volts 380 Cycles 50 Including: 3-axis Digital readout with point to point control Heidenhain 310

Offer 24435 Specifications: - Table surface 1700 x 550 mm - Manual travels X / Y 1300 x 500 mm - Drill Fabr. MAXION , Type: BT 15 GL - Drilling capacity up to 18 mm - Tapping device up to M 10 - Drilling spindle holder MK 2 - Drilling spindle stroke with drilling depth fine adjustment 90 mm - PV 12 pneumatic feed unit - Projection 670 mm - 4 spindle speeds 320 + 560 + 1000 + 1600 rpm -Mot. Drilling unit stroke - Table clamping x + y - Minimum amounts of lubrication - Pneumatic connection 6 bar - Connection 400 V - Space requirement approx. W 1750 x H 1600 x D 1000 mm - Weight approx. 1200 kg - various guide cartridges

Key data: 102 mm, 1600 mm, 1250 mm

Spindle diameter Ø 102 mm Taper ISO 50 Horizontal spindle travel 710 mm Cross travel (X) 1,600 mm Vertical Travel headstock (Y) 1,250 mm Longitudinal travel (Z) 1,500 mm Table 1,250 x 1,400 mm Table load 5 ton R.P.M. 4 – 1,250 (18x) kW 23 Volts 380 Cycles 50

Heidenhain TNC 426 Table 1600 x 2000 mm Max. load 12.500 kg Spindle diameter 130 mm Taper ISO 50 Cross travel (X) 3,500 mm Vertical travel headstock (Y) 1,600 mm Longitudinal travel (Z) 1,250 mm Horizontal spindle travel (W) 850 mm RPM 4 – 1,120 kW 45 Volts 380 Cycles 50 Including: Facing head Ø 720 mm Facing head slide travel 240 mm Machine weight 31,1 ton

Control Heidenhain TNC 426 Mach.no. 11648 Table 1,600 x 1,250 mm Spindle diameter 130 mm Taper ISO 50 Cross travel (X) 2,000 mm Vertical travel headstock (Y) 1,600 mm Longitudinal travel (Z) 1,050 mm Horizontal spindle travel (W) 850 mm RPM 4 – 1,120 kW 45 Volts 380 Cycles 50 Including: Machine weight 26,3 ton

Control Heidenhain TNC 355 Spindle diameter Ø 130 mm Horizontal Spindle Travel (W) 800 mm Taper ISO 50 P.D.B. Table 1,600 x 1,800 mm Max. load 12 Ton Cross travel (X) 3,500 mm Vertical travel headstock (Y) 2,000 mm Longitudinal travel (Z) 1,250 mm RPM 5 – 1,100 kW 32 Volts 400 Cycles 50

Offer 24331 Specifications: - Table surface 1700 x 550 mm - Manual travels X / Y 1300 x 500 mm - Drill Fabr. MAXION , Type: BT 18 STP - Drilling capacity up to 18 mm - Tapping device up to M 16 - Drilling spindle holder MK 2 - Drilling spindle stroke with drilling depth fine adjustment 76 mm - PV 12 pneumatic feed unit - Projection 670 mm - Spindle speeds 100 - 1800 rpm - 200 - 3600 rpm -Mot. Drilling unit stroke -Mot. Table clamping x + y - Minimum amounts of lubrication - Pneumatic connection 6 bar - Connection 400 V - Space requirement approx. W 1750 x H 1600 x D 1000 mm - Weight approx. 1200 kg

Condition: Very good condition

: Viele MK Aufnahmen taper MK: 40 taper MK: 50 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

WE OFFER AN STUNNING EXCELLENT CONDITION WOTAN CNC RAPID 1 WITH HUGE AMOUNT OF OVER 400 TOOLINGS, FOR A SPECIAL WORK. WORKING HOURS: POWER ON: 13692 PROGRAM RUN: 4650 SPINDLE RUN: 4690 AXIS TIME: 4568 HYDRAULIC TIME: 12702 MACHINE HAVE HEIDENHAIN 530 CONTROLS TECHNICAL DETAILS: SPINDLE SPEED : 6,3-1600 U/Min SPINDLE MOVE : Y AXIS : 1250 mm DRILLING SPINDLE MOVE: Z AXIS: 600 mm W : 1000 mm X : 2000 mm B: 360.000 DEGREE SPINDLE DIAMETER: 105mm TOOL HOLDER: ISO 50 WITHOUT TOOL CHANGER CLAMPING: HIDRAULIC MAX TABLE LOAD: 6000 KG TABLE: 1120 X 1400 NUT -BILD 7 ; 22H7 INDEXING 4 X 90 DEGREE TOTAL WEIGHT: 16000 KG DIMENSION OF MACHINE: LENGHT 4800 X BREIT 4665 X HEIGHT 4200

Inv. Num. : 8054 Type: HYDROPTIC 6 Producer: SIP Generated: Parameters: Work table length: 1100 mm Work table width: 842 mm Maximum spindle speed: 2000 1/min Maximum table load (even): 1000 kg X-axis travel: 1000 mm Y-axis travel: 700 mm Z-axis travel: 800 mm Spindle power: 6 kW Machine height: 3205 mm Machine length: 3280 mm Machine width: 2335 mm Machine weight: 10000 kg

1x CNC Table Boring Machine Manufacturer: TOS Type: WHQ Year of Make:1997 Control: Heidenhain TNC 426 in 5-axis X-axis 2000mm Y-axis 1400mm Z-axis 1250mm W-axis. 710 mm B-axis 360 degrees Spindle diameter : 112mm Spindle mount: ISO 50 Spindle speed max: 2000 rpm Table clamping surface: 1400x 1600mm Tool changer: 60 places Chip Conveyor: Yes

RACING Longitudinal travel of the X-axis mast 16,000mm Vertical travel of the Y-axis head 3,000mm Z-axis head transverse travel 1,250mm Cross stroke boring spindle W axis 700mm HEAD DIMENSIONS 410 X 505mm MANDREL Boring spindle diameter 140mm ISO 50 spindle attachment Spindle rotation speed: 5 – 3,000rpm ADVANCES Continuous working axes X, Y, W, Z 0.5 – 6,000mm/min Fast X, Y, Z axes 18,000 mm/min Rapid W axis 10,000mm/min Working thrust 2,000kg ENGINE POWER: Spindle motor in continuous service (S1%) (AC) 42 Kw Axis feed motors (AC) 50 Nm Auxiliary engines 4.5 Kw Machine in excellent condition.

Working area: 6000 x 1000 x 3000 mm (max stroke) Rotary table: 2000 x 2000 - load capacity: 15000 kg Max working feed: 5000 mm/min Max rapid feed: 8000 mm/min Fixings: ▪ Nose: 3000 rpm ▪ Universal Head: 3000 rpm Control: Selca 3045 PD

Working Area: 6000 x 1200 x 3000 (Max Stroke) Max working feed: 8000 mm/min Max rapid feed: 15000 mm/min Fixings: ▪ Indexed head : max rpm: 4000 ▪ Nose: max rpm: 4000 Control: Selca 3045

spindle diameter: 130 mm x-travel: 10000 mm y-travel: 3500 mm z-travel: 1000 mm Control: Heidenhain type: TNC 155 workpiece weight: 300 t turning speeds: 1620 U/min spindle taper ISO: 50 One direction thrust bearing: 2 Angle head: 2 power capacity: 76 kW Plate area: 12000x9600 mm Thickness: 450 mm rotary table:: Colgar type: TRT1500 mm table surface area: 2000x2500 mm Table load: 20000 kg Travel: 2000 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Plate area: 109 m² The floor plate and the table are optional and will be charged extra The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 130 mm x-travel: 7700 mm y-travel: 1500 mm Control: Siemens type: Sinumerik 840 C spindle taper ISO: 130 turning speeds: 1490 U/min power capacity: 45 kW chip conveyor: Angle head: Angle head: Plate area: 9000x6000 mm workpiece weight: 100 t One direction thrust bearing: total power requirement: kW dimensions of the machine ca.: m Panel is optional and we charged extra The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 105 mm x-travel: 2100 mm y-travel: 1500 mm z-travel: 1400 mm Table area: 1750x2000 mm turning speeds: 16-1400 U/min table load: max. 4 t weight of the machine ca.: 18 t The techn. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively.About usMore than 400 of our own machines in the warehouseMore than 12,000 m² of storage space, crane capacity 70 tMore than 1000 items Accessories for your workshopYou want to sell machines, production lines or your company,then contact us. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 150 mm x-travel: 7200 mm y-travel: 3800 mm Plate area: 9000x6000 mm digital readout: AEG ram: diameter: 440 mm ram: horizontal adjustment: 1000 mm spindle travel: 1500 mm threading cutting device:: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Panel is optional and we charged extra The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 102 mm x-travel: 1600 mm y-travel: 1000 mm z-travel: 1600 mm Control: Heidenhain type: TNC 410 table surface area: 1000x1120 mm Table load: 3000 kg spindle stroke: 710 mm spindle turning speed range: 4-1600 U/min main drive motor: 13 kW total power requirement: kW weight of the machine ca.: 12 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 102 mm x-travel: 1600 mm y-travel: 1200 mm z-travel: 1500 mm w-axis: 700 mm Table dimensions: 1250x1400 mm number of spindle speeds: 8-1600 Control: Heidenhain TNC 131 total power requirement: 15 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
