bolt used for sale

Slewing ring, slewing ring, ball slewing ring, slewing gear PAGUS Ø 1100 mm x 80 mm Upper ring: Outer diameter: Ø 1125 mm, bolt circle diameter: Ø 1075 mm Lower ring: Outer diameter: Ø 1100 mm, bolt circle diameter: Ø 1060 mm Inner diameter: Ø 975 mm Height: 80 mm 8x bore: Ø 17.5 mm per ring As good as new ! Dimensions: 1125 x 1125 x 80 mm

Spherical roller bearing with bearing housing SKF 22330 CCJA/W33VA405 shaft diameter: Ø 150 mm outer diameter: Ø 320 mm height: 108 mm bearing housing: Ø 388 mm bolt circle: Ø 348 mm, 8x threaded hole: M16 x 2,0, Depth: 45 mm Flange diameter: Ø 520 mm, height: 40 mm bolt circle: Ø 470 mm, 12x bore: Ø 25 mm shaft bushing: Ø 172 mm New ! Dimensions : 520 x 520 x 220 mm

Faceplate PAGUS Outer Ø: 400 mm Flange: 155 mm bolt circle: 134 mm bore Ø: 110 mm height with jaws: 140 mm total height: 190 mm short cone Dimensions: 400 x 200 mm

Faceplate PAGUS Outer Ø: 360 mm bore middle Ø: 20 mm with thread flange: Ø 250 mm Bolt circle inside: Ø 135 mm bolt circle outside: Ø 225 mm bore M8 / M12 and 4 x Ø 12 mm thickness with flange: 55 mm Dimensions: 360 x 360 x 55 mm

Face plate PAGUS outer Ø: 305 mm bolt circle Ø : 280 mm bolt circle flange Ø : 52 / 135 mm bore Ø: 25 mm Thickness: 38 mm grooves: 10 / 18 mm combinable with WZ239 ! Dimensions: 305 x 305 x 38 mm

Grinding spindle EX-CELL-O Type 771.860.5 Serial No.: G 005206 speed: max 6250 rpm bore by grinding spindle shaft: Ø 22 mm shaft diameter: Ø 40 mm, length: 80 mm, thread: M40 x 1.5 mounting flange Diameter: Ø 180 mm bolt circle: Ø 155 mm, 6x bore Ø 13 mm, 3x thread M10 x 1.5 drive flange diameter: Ø 120 mm bolt circle: Ø 80 / 100 mm, 3x thread each M10 x 1.5 used, tested ! Dimensions: 325 x 180 x 180 mm

Intermediate plate for pillar slewing crane, crane foundation plate, indoor crane, workplace crane, crane foundation plate -Pillar slewing crane: intermediate plate/base plate, outside: Ø 1200 mm -Type: ST160 VP1200/DL530 422632 S235 JR -Thickness: 40mm -Bolt circle inside: Ø 530 mm -Outer bolt circle: Ø 1160 -Number: 2x foundation plate available -Price per piece -Weight: 388 kg

Servo motor, permanent magnet motor, spindle motor AMK DH13-120-4-I0F 17,5 kW 1500 rpm 350 V IP54 Shaft diameter: Ø 42 mm Wavelength: 110 mm Groove width: 12 mm Flange diameter: Ø 230 / 260 x 260 mm bolt circle diameter: Ø 265 mm hole diameter: Ø 12.5 mm intermediate flange diameter: Ø 230 / 380 m, thickness: 10 mm bolt circle diameter: Ø 350 mm hole diameter: Ø 9 / 15 mm spare part for cylindrical grinding machine NOMOCO VSR5-230-CNC ! used, checked ! Dimensions: 630 x 380 x 400 mm

High-pressure pump, plunger pump PLATZ® REINIGUNGSSYSTEME GmbH Type 304 920 Q: max. 45 l/min p: max. 100 bar necessary drive power: 8,,2 kW Speed (pump shaft): 450 rpm Connections: Ø 25/ 30 mm ( inside ) Flange diameter: Ø 230 / 300 mm bolt circle diameter: Ø 265 mm 4x threaded bolt: M12 x 1.75, usable length: 35 mm material (pump heads): brass new ! Dimensions: 410 x 320 x 500 mm

number: 37 Positionen : 28 mm condition: neu weight: 35 kg Basic set 2 49 pieces, 28mm system, consisting of: Forceps: 8 x 280604 Bolt: 12 x 280511 Stop: 8 x 280420.N Angle: 4 x 280110.G Threaded bolt 8 x 280543 Stop 8 x 160415 Accessory set. 1 x 163999 Price plus packaging and transport. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

number: 37 Positionen : 28 mm condition: neu weight: 29 kg Basic set 1 37 pieces, 28mm system, consisting of: Clamps: 4 x 280604 Bolt: 8 x 280511 Stop: 6 x 280420.N Angle: 2 x 280110.G Threaded bolt 8 x 280543 Stop 8 x 160415 Accessory set. 1 x 163999 Price plus packaging and transport. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Base plate, for radial drilling machine, clamping plate CSEPEL RFH75 clamping surface: 1700 x 940 mm height: 280 mm web width: 157 mm, 3x 172 mm, 155 mm groove width: 28 / 48 mm, groove depth: 50 mm flange for column: Ø 520 / 800 mm bolt circle diameter: Ø 700 mm, 6x threaded hole: M36 x 4, depth: 100 mm flange for coolant pump: Ø 100 / 145 mm bolt circle diameter: Ø 115 mm, 6x threaded hole: M6 x 1, depth: 10 mm base: 2750 x 1155 mm used, tested ! Dimensions: 2750 x 1155 x 280 mm

Mini Excavator KV 20 Mini Excavator - NEW Finally assembled in Germany with engine Kubota 1105 - 18,2Kw 4 Legs Roof Swing Boom Adjustable Track High/Low Speed Accessories for mini excavators Bridge width 92mm (see picture) Bolt diameter 25mm (see picture) Bolt spacing 85mm (see picture)

Mini Excavator KV20 Mini Excavator - NEW with motor Laidong 385 - 18,4Kw Finally assembled in Germany 4 Legs Roof Swing Boom Adjustable Track High/Low Speed Accessories for mini excavators Bridge width 92mm (see picture) Bolt diameter 25mm (see picture) Bolt spacing 85mm (see picture)

Slewing ring, slewing ring, ball slewing ring, slewing gear PAGUS Ø 485 mm x 42 mm Upper ring: Outer diameter: Ø 595 mm, Bolt circle diameter: Ø 505 mm 6x Bore: Ø 9 mm Lower ring: Outer diameter: Ø 655 mm, Bolt circle diameter: Ø 625 mm 6x Threaded hole: M8 x 1.25 ( in groups of 2, hole spacing: 50 mm ) inner diameter: Ø 485 mm height: 42 mm used, tested ! Dimensions: 655 x 655 x 42 mm

Chuck flange, flange mount, lathe chuck flange, driver flange -Chuck flange: with driving pin -External: O 192 mm -Camlock cone size: 6 (106mm) -Bolt circle: 2 x 160 mm bolt diameter 18 mm -Weight: 6kg

Geared motor BONFIGLIOLI, SIEMENS 73.4 rpm motor: 1LA7080-4AA11 0.55 kW 1395 rpm 230 / 400 V 3AC 50 Hz 60 Hz - operation is possible ! IP55 gearbox: VF 63 P1 P80 B5 ( VF63P1P80B5 ) i: 19 Hollow shaft diameter: Ø 25 mm wavelength: 120 mm groove width: 8 mm 2x Flange diameter: Ø 75 / 110 mm, bolt circle diameter: Ø 90 mm 8x Threaded hole: M8 x 1,25, Depth: 15 mm Intermediate flange diameter: Ø 115 / 180 mm, Bolt circle diameter: Ø 147 mm 4x Hole diameter: Ø 11 mm Motor and gearbox: Aluminium housing New ! Dimensions: 420 x 220 x 250 mm

FULLY AUTOMATIC DOCTOR BLADE SCREENING SYSTEM, Materials filtered : PP-LDPE-LLDPE-HDPE-PS-EPS-XPS-ABS-TPU, Components and technical features, - Filter diameter 400 mm - filtering surface 1.206 sqcm, - Machine central body derived from a single piece, - Electric motor and gearbox, - Nr. 2 scraping impellers for scraping operation complete with blades, - Nr. 2 Breakers for scraping operation (45mm + 8mm), - Nr 1 discharge slide (under the valve), - laser screens from 60 to 300 my (mesh from 230 to 50, - Punched screen from 400 to 2.000 my (mesh from 40 to 10), Electrical panel adaptable to UL/CSA standards, - 1 inverter for motor management, - 1 filter for inverter, - 3 thermoregulators and static relays for resistance management, - 3 thermocouples, - 2 interceptors with Melt probe for alarm and cleaning management, - Fuse protection for the various power supplies, - Machine status reporti ...

FULLY AUTOMATIC DOCTOR BLADE SCREENING SYSTEM, Materials filtered : PP-LDPE-LLDPE-HDPE-PS-EPS-XPS-ABS-TPU, Components and technical features, - Filter diameter 500 mm - filtering surface 1.916 sqcm, - Machine central body derived from a single piece, - Electric motor and gearbox, - Nr. 2 scraping impellers for scraping operation complete with blades, - Nr. 2 Breakers for scraping operation (45mm + 8mm), - Nr. 1 discharge slide (under the valve), - laser screens from 60 to 300 my (mesh from 230 to 50, - Punched screen from 400 to 2.000 my (mesh from 40 to 10), Electrical panel adaptable to UL/CSA standards, - 1 inverter for motor management, - 1 filter for inverter, - 3 thermoregulators and static relays for resistance management, - 3 thermocouples, - 2 interceptors with Melt probe for alarm and cleaning management, - Fuse protection for the various power supplies, - Machine status report ...

FULLY AUTOMATIC DOCTOR BLADE SCREENING SYSTEM, Materials filtered : PP-LDPE-LLDPE-HDPE-PS-EPS-XPS-ABS-TPU, Components and technical features, - Filter diameter 700 mm - filtering surface 3.807 sqcm, - Machine central body derived from a single piece, - Electric motor and gearbox, - Nr. 2 scraping impellers for scraping operation complete with blades, - Nr. 2 Breakers for scraping operation (80mm + 8mm), - Nr 1 discharge slide (under the valve), - Nr. 2 hydraulic pistons for lid opening, - laser screens from 60 to 300 my (mesh from 230 to 50, - Punched screen from 400 to 2.000 my (mesh from 40 to 10), Electrical panel adaptable to UL/CSA standards, - 1 inverter for motor management, - 1 filter for inverter, - 3 thermoregulators and static relays for resistance management, - 3 thermocouples, - 2 interceptors with Melt probe for alarm and cleaning management, - Fuse protection for the vario ...

Spicer Type 176/174-003 Drive Axle Price per piece Condition: New Final Drive Ratio: 1:6.23 10-Bolt Hub with an approximate bolt circle diameter of 340 mm Shipping Weight: 565 kg per piece Availability: 2 units Tags: Steering axle, truck drive axle, Dana R-ITA-703441

Standard chemical pump, Centrifugal pump without motor, Water pump, Chemical pump KSB CPKN - C1 025 - 200 Q: 3,0 m3/h H: 50.0 m n: 2905 rpm shaft diameter: Ø 24 mm, Wavelength: 50 mm Groove width: 8 mm Input: Inner Diameter: Ø 41 mm flange diameter: Ø 90 / 150 mm bolt circle diameter: Ø 110 mm hole diameter: Ø 17,5 mm output: Inner diameter: Ø 25 mm flange diameter: Ø 68 / 114 mm bolt circle diameter: Ø 85 mm hole diameter: Ø 13.5 mm Material (pump housing): Stainless steel ( 1.4408 ) New ! Dimensions: 465 x 295 x 340 mm

Pneumatic swing actuator FESTO DSM-16-270-P-FW-A-B 547575 pmax: 10 bar drive bottle: Ø 16 / 38 mm bolt circle diameter: Ø 28 mm, 4x M4 x 0,7, 4x Ø 4.5 mm flange: 70 x 70 mm bolt circle diameter: Ø 80 mm, 4x M5 x 0.8 used, checked! Dimensions: 80 x 70 x 90 mm

Geared motor REXROTH GKR04-2MHGR-071-34 0,12 KW 11.2 rpm Gear ratio: I = 60 Motor: MDEMAXX071-34 0.12 KW 670 rpm 230 / 400 Volt 3AC 50 Hz 60 Hz - operation is possible ! IP55 drive shaft with hexagon socket: 27 mm flange1: Diameter: Ø 75 / 105 mm bolt circle diameter: Ø 92 mm, hole diameter: Ø 6, 5 mm flange2: Diameter: Ø 75 mm Bolt circle diameter: Ø 90 mm, 4x threaded hole: M6 x 1.0, depth: 15 mm gear foot: 105 x 75 mm hole spacing: 60 / 85 mm 4x U-hole: Ø 7 x9 mm all threaded holes: M8 x 1.25, depth 15 mm used, tested ! dimensions: 340 x 240 x 180 mm

Description: Coromant Capto extension adapter, quantity = 4 pieces ISO: C8-391.01-80 100A Product data: - Machine direction adapter interface -Coromant Capto (bolt and segment clamping) -size C8 - Facing adjustment - Coromant Capto (bolt clamping) -size C8 - Code for cooling lubricant supply - 3: axial concentric and radial entry - Cooling lubricant outlet - 1: axial concentric exit - Coolant pressure - 80 bar - Recording diameter - 80 mm - Functional diameter - 55 mm - Recording diameter, workpiece side - 80 mm - Functional length - 100 mm - Body diameter - 80 mm - Length body diameter - 110 mm - Torque - 170 Nm - Tool design - steel - Mass (weight) - 3.7 kg Approx. Onsite Dimension. (l x w x h): 400 x 300 x 200 mm, weight approx.: 15 kg

Description: Coromant Capto on milling arbor holder, quantity = 1 piece ISO: C8-391.05C-16 050 Product data: - Machine direction adapter interface -Coromant Capto (bolt and segment clamping) -size C8 - Facing adjustment - Arbor -ISO 6462 -A/B (center bolt/washer) -metric: 16 - Code for cooling lubricant supply - 3: axial concentric and radial entry - Cooling lubricant outlet - 4: axially concentric on circle - Coolant pressure - 80 bar - Functional diameter - 55 mm - Recording diameter - 80 mm - Recording diameter, workpiece side - 16 mm - Angle position of holder, workpiece side - 0 deg - Functional length - 50 mm - Body diameter - 80 mm - Length body diameter - 50 mm - Torque - 22 Nm - Speed, max. (-81, -82: Maximum speed) - 14,000 1/min - Tool design - steel - Mass (weight) - 2.095 kg Approx. Onsite Dimension. (l x w x h): 300 x 200 x 100 mm, weight approx.: 5 kg

Description: Coromant Capto extension adapter, quantity = 1 piece ISO: C8-391.01-80 200 Product data: - Machine direction adapter interface -Coromant Capto (bolt and segment clamping) -size C8 - Facing adjustment - Coromant Capto (bolt clamping) -size C8 - Code for cooling lubricant supply - 3: axial concentric and radial entry - Cooling lubricant outlet - 3: axial concentric and radial entry - Coolant pressure - 80 bar - Recording diameter - 80 mm - Functional diameter - 55 mm - Recording diameter, workpiece side - 80 mm - Functional length - 200 mm - Body diameter - 80 mm - Length body diameter - 200 mm - Torque - 170 Nm - Tool design - steel - Mass (weight) - 7.332 kg Approx. Onsite Dimension. (l x w x h): 300 x 200 x 100 mm, weight approx.: 10 kg

Description: Coromant Capto on milling arbor holder, quantity = 1 piece ISO: C8-391.05C-22 030M Product data: - Machine direction adapter interface -Coromant Capto (bolt and segment clamping) -size C8 - Facing adjustment - Arbor -ISO 6462 -A/B (center bolt/washer) -metric: 22 - Code for cooling lubricant supply - 3: axial concentric and radial entry - Cooling lubricant outlet - 4: axially concentric on circle - Coolant pressure - 80 bar - Functional diameter - 55 mm - Recording diameter - 80 mm - Recording diameter, workpiece side - 22 mm - Angle position of holder, workpiece side - 0 deg - Functional length - 30 mm - Body diameter - 80 mm - Length body diameter - 30 mm - Torque - 45 Nm - Speed, max. (-81, -82: Maximum speed) - 14,000 1/min - Tool design - steel - Mass (weight) - 1.86 kg Approx. Onsite Dimension. (l x w x h): 300 x 200 x 100 mm, weight approx.: 5 kg

Description: Coromant Capto on milling arbor holder, quantity = 1 piece ISO: C8-391.05C-27 030M Product data: - Machine direction adapter interface - Coromant Capto (bolt and segment clamping) -size C8 - Facing adjustment - Arbor -ISO 6462 -A/B (center bolt/washer) -metric: 27 - Code for cooling lubricant supply - 3: axial concentric and radial entry - Cooling lubricant outlet - 4: axially concentric on circle - Coolant pressure - 80 bar - Functional diameter - 55 mm - Recording diameter - 80 mm - Recording diameter, workpiece side - 27 mm - Angle position of holder, workpiece side - 0 deg - Functional length - 30 mm - Body diameter - 80 mm - Length body diameter - 30 mm - Torque - 80 Nm - Speed, max. (-81, -82: Maximum speed) - 14,000 1/min - Tool design - steel - Mass (weight) - 1.91 kg Approx. Onsite Dimension. (l x w x h): 300 x 200 x 100 mm, weight approx.: 5 kg

Precision Shaper fence for cutting tool to Max D = 250 mm with fine adjustment The locking bolt hole spacing: 330 mm Diameter extraction: 120 mm with Multieinstellsystem with safety rulers: L = 500 mm, 155 mm high

Accessories: -Three-jaw Chuck -Steel holder multi fix A -Lamp -Coolant Technical data: Tip height 120 mm Top width 450 mm Spindle passage 23 mm Spindle inner taper MK 4 Plan travel 150 mm Tailstock MK 2 Quill way 80 mm Manual 9 levels Speed range 2 travel of bolt turn 30 3000 rpm

Weibert Shaper fence NEW! Precision Shaper fence for cutting tool to Max D = 180 mm with fine adjustment The locking bolt hole spacing: 330 mm Diameter extraction: 120 mm with Multieinstellsystem with safety rulers: L = 500 mm, 155 mm high

FOR SALE S.E.M.T. PIELSTICK PC3. 0 NEW ORIGINAL SPARE PARTS HAVE A GDY SIR WE VE BELOW LISTED NEW ORIGINAL SPARE PARTS OF S.E.M.T PIELSTICK PC3 AT OUR STOCK IN TURKEY. IF YOU INTEREST PLS DO NEED HESITATE TO CONTACT WITH US. MAIN BEARING SHELLS STD 2 PAIRS THRUST BEARINGS 1 PAIRS LINER ORING 50PCS CON ROD BOLT 3 PC CON ROD BUSH 3 PCS BARREL PLUNGER 4 PCS PISTON RING KIT H 12 SET VARIOUS PISTON RING 93PCS PCS PISTON PIN RING 20 PCS GASKET OF CYLINDER HEAD KIT 3 PCS EXHAUST VALVE 5 PCS ENJEKTOR LONG SPRING 15 PCS ENJECKTOR SHORT SPRING 12 PCS ENJECTOR NUT 4 PCS ENJECTOR NOZZEL 15 PCS ENJECTOR DELIVERY VALVE 25 PCS LOCATING PIN 16 PCS . Capt. Ayhan Ugurlubay Best of regards; Aliaga marine services E mail: info@aliagamarine.com PHN/fax: + 90 232 618 03 85 Mobile: + 905556084850 ABC.aliagamarine.com TURKEY

Accessories available Tip height 120 mm Top width 450 mm Spindle passage 23 mm Spindle inner taper MK 4 Plan travel 150 mm Tailstock MK 2 Quill way 80 mm Manual 9 levels Speed range 2 travel of bolt turn 30 3000 rpm

MATEC Stappler tipping bucket type 2 The tipping bucket can be locked with a bolt with cotter pin so no tipping is possible. The tipping buckets can be supplied also with a hydraulic tilting device. The blades are 1950 mm wide and type 2 1300 mm deep. The standard blade height is 450 mm. Solid wall or lattice towers can be ordered as accessories. The nominal weight of the shovel is 2000 kg. Each blade has 4 lifting eyes for crane handling. 4 mm thickness, corners and a replaceable wear bar reinforced permit prospecting. Other blade dimensions are possible upon request. Year 2017 New machine Spare parts/service MATEC CH-4952 Eriswil/DE-79618 Rheinfelden Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041  ...

Planetary grinders Manufacturer Precise In a suitcase with extensive zubehoer Rule transformer Tool holder SK40 with interchangeable tightening bolt Control range: 15000 - 45000 rpm Orbital speed 70 - 120 rpm when working horizontally max.: 70 rpm Radial delivery: 0.0001 - 0.002 mm Reception: SK40 electr. Connection: 220 V, 600 W Special price

diameter 200mm, little used, dusted, good condition.4 Bolts with bolt spacing approx. 94mm, Hole circle diameter of the bolts approx. 133mm, the largest diameter of the short cone approx. 106mm, Drawbar in the middle. All information to the best of our knowledge but without any information. Special price

Tool to CNC milling center Steep cone-cone SK 40 Vsadrq with tightening bolt Tool according to the pictures flat rate EUR 6980.00 Built in 2003 In good condition, ready to use. Subject to changes, errors, prior sale! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041 62 966 21 12

A used S O R A L U C E CNC driving stand milling and drilling center FS 16000 Built in 2000 MAIN TECHNICAL DATA: Travel: Longitudinal (X): mm 16000 Senkr. (Z): mm 1600 Cross (Y): mm 1500 Milling and drilling spindle: Tool holder: ISO 50, DIN 69871 Auto. Tool tension: clamping force 15000 N Tightening bolt: DIN 69872 Form B (BT50) Spindle speeds: Special speeds: rpm 20-3000 Feeds: Feed range: mm/min 2-5000 Rapids: X-axis: mm/min 12000 Y- and Z-axis mm/min 15000 The machine is equipped with: - HEIDENHAIN control TNC 426 M. - Operator's platform in the X-direction with sliding door and Viewing windows against chip flight and splashing water. - Operator's console swivels mounted on the stage. - Automatic thermal expansion compensation of the Milling sliders. - Automatically indexing milling head. This milling head enables the fully automatic m ...

Description Polar Mohr Shear Bolt Polar 115

MORI SEIKI SH-500/40 Horizontal Machining Center was built in Japan in 1999 by MORI SEIKI CO., LTD. The machine is equipped with a numerical control type MORI SEIKI MSC-502. The milling machine has a table size of 500 x 500 mm and processes workpieces weighing up to 500 kg. The travel range of its X, Y, Z axes is 630 x 600 x 650 mm, respectively. The machine spindle rotates at 12,000 revolutions per minute. The milling machine is equipped with a magazine for forty tools with a maximum tool diameter of 150 mm, length 360 mm and a weight of 12 kg. The milling center is offered at a price with different types of holders. Technical parameters of the MORI SEIKI SH-500/40 CNC milling machine - CNC control: MORI SEIKI MSC-502 Travel range: - X axis (table travel length): 630 mm - Y axis (vertical movement of the spindle head): 600 mm - Z axis (cross table movement): 650 mm - distan ...

We offer 6x Piston+linder-kit with ring set + bolts + liners with O-rings Al stock immediately available at stock: Piston: 6217-31-2130 Bolt : 6211-31-2410 Ring set: 6217-31-2030 Liner : 6218-21-2210 Net price / rate = 450 plus 19% tax MIW GmbH Motoren-Instandsetzungs-Werk North-West-Ring 8 D-27404 Zeven/Germany Phone: 0049(0) 4281-950583 Fax: 0049(0) 4281-950585 E-mail: info@miw-zeven

We offer 6xpiston+linder-kit with ring set + bolts + liners with O-rings Al stock immediately available at stock: Piston: 6217-31-2130 Bolt : 6211-31-2410 Ring set: 6217-31-2030 Liner : 6218-21-2210 Net price / rate = 450 plus 19% tax MIW GmbH Motoren-Instandsetzungs-Werk North-West-Ring 8 D-27404 Zeven/Germany Phone: 0049(0) 4281-950583 Fax: 0049(0) 4281-950585 E-mail: info@miw-zeven

2019 technically overhauled CBN or DIA grinding in deep grinding Cover / Schalldaemmhaube with viewing window Interior lighting by halogen lamp Separate control cabinet with screen display and operator guidance Special tooth shapes: 10 forms freely programmable and stored Automatic, motorized central lubrication 1 piece of grinding wheel flange Centering pad with bolts ( x16 mm) 1 set centering rings Normal access and user manual Operating tool Colour pigeon blue Grinding range of 60 - 520 mm Saegeleaf thickness max. 6 mm Zaehne numbers 20 - 999 Saegeleaf holder bolt 16 (8) mm Grinding wheel diameter 200 mm Maximum tooth height 32 mm Grinding wheels bore 32 mm Grinding wheel drive 4 kW Grinding wheels Speed 5730 rpm Weight approx. 1150 kg

Schmidt Tempo ASG 1400 Saw blade grinding machine up to 1,400 mm Overhauled and repainted â?¢ Saw blade holder of 250 mm with centering bolt 32 mm with hydraulic clamping nut â?¢ 1 pc saw blade support â?¢ 1 set of centering rings â?¢ 1 pc. grinding wheel flange 150 mm diameter, 32 mm bore â?¢ Large halogen lamp, good illumination, reduced heat formation â?¢ New, up-to-date control panel â?¢ Connection to central dust extraction â?¢ Interchangeable wheel scissors with the required interchangeable wheels for common number of teeth

Schmidt Tempo ASG 2000 Saw blade grinding machine up to 2,050 mm technically overhauled and repainted in 2019. Equipment and accessories: â?¢ Saw blade holder of 250 mm with centering bolt 32 mm, hydraulic clamping nut â?¢ 1 pc saw blade support â?¢ Centering rings bore 32 mm, outer diameter as required â?¢ 1 pcs grinding wheel flange 150 mm Diameter, 32 mm bore â?¢ Large working light â?¢ Interchangeable wheel scissors with interchangeable wheels for need. Tooth numbers Technical data: â?¢ Grinding range 315-2050 mm â?¢ Number of teeth 16 - 1000 â?¢ Tooth height 1 - 50 mm â?¢ Saw blade thickness maximum 20 mm â?¢ Stroke numbers continuously 21-126 Z/min â?¢ Connection value approx. 4.5 kW (400V / 50 Hz)

Saw blade grinding machine up to diameter 3,000 mm Model Schmidt Tempo ASG 3000 2019 technically overhauled and repainted â?¢ Grinding range 315-3050 mm â?¢ Number of teeth 16 - 1000 â?¢ Tooth height 1 - 50 mm - saw blade thickness up to 20 mm â?¢ Stroke numbers continuously 21-126 Rpm - Connection value approx. 4.5 kW (400V / 50 Hz) â?¢ Saw blade holder of 550 mm with centering bolt 32 mm with hydraulic clamping nut â?¢ 1 pc saw blade support â?¢ 2 centering rings bore 32 mm outer diameter as required â?¢ 1 pcs grinding wheel flange 150 mm diameter, 32 mm bore â?¢ Large LED light, good illumination, reduced heat formation â?¢ Interchangeable wheel scissors with the interchangeable wheels for common number of teeth Illustrations: Schmidt Tempo ASG 2000.  ...

Saw blade grinding machine with car. bevel up to 1050 mm by CBN or DIA cut in deep grinding process Schmidt Tempo XL Grinding range 80 to 1050 mm Saw blade thickness up to 10 mm Mounting bolt 16/32 mm Grinding wheel diameter 200 mm Spindle rotary screw up to 5,700 rpm Working speed 3 to 50 z/min Integrated coolant device Dimensions 1,400 x 1,750 x 2,250 mm Weight approx. 1,700 kg

NEW - Unused stock from industrial hall packed in original wooden box Offer valid for acceptance of 115 pieces - partial quantities possible Manufacturer: Coat plates with ventilation slots aluminium natural, upper ribbed and lower end part made of cast aluminium. Aluminum reflector open, removable. VG with thermal protection element and. if necessary, ZG with automatic shut-off installed. 4 Cable entries M20. Connections inside, large side connecting door. Central threaded bolt M10 for ceiling sheet or hanger. Lamp: HST-DE, 400 W Number of lamps: 1-lamp Material of the housing: Aluminium Case color: Aluminum Lamp power: 1 x 400 W System power: 440 W Protection class: I Degree of protection (IP): IP20 Control unit VG, Length: 536 mm Width: 536 mm Height: 692 mm max. weight: 13.8 kg 230 V - 240 V AC

Planscheibein little used condition Manufacturer TG Diameter approx.610mm Body bearing traces (can be easily removed!) Short cone chuck flange for spindle heads DIN 55027 or ISO 702/III (same as old standard DIN 55022) with stand-up bolt and nut nuts. Short cone holder size 8 for bayonet closure Cone-d2 139.735 mm Röhm Bilsing Werner Garant Toss Forkart Schunk rotary lining röhm rotary lining baking rotary lining manufacturer camlock rotary lining baking lining rotary foe flange forda rotary lining rotary lining adapter flange Special price
