bolt used for sale

Elektromotor SIEMENS, SCHUCKERTWERKE AG 1MA2025-2CA 0,37 kW 2750 rpm 220 / 380 V 3AC 50 Hz IP33 Design: B5 Shaft diameter: Ø 12 mm Shaft length: 35 mm groove width: 4 mm pulley: Ø 89 mm, one groove, groove width: 10 mm flange: Ø 90 / 165 mm bolt circle diameter: Ø 140 mm hole diameter: Ø 9.0 mm used, tested ! Dimensions: 305 x 165 x 220 mm

Elektromotor BALDOR, RELIANCE 34L123S344 0,18 kW ( 0.25 HP / hp ) 1425 / 1725 rpm ( 50 / 60 Hz ) 115 / 230 V 1AC 50 / 60 Hz IP33 shaft diameter: Ø 16 mm wavelength: 48 mm groove width: 5 mm Flange: Ø 114 / 148 mm bolt circle diameter: Ø 150 mm 4x threaded hole with screws ( non-metric ): Ø 9.3 mm, pitch: 3.5 mm, depth: 18 mm New ! with documents ! Dimensions: 290 x 205 x 190 mm

Elektromotor SIEMENS 1LA3070-2AA29 Z 0,37 kW 2765 rpm 220 / 380 V 3AC 50 Hz IP44 Design: B5 Shaft diameter: Ø 12 mm Wavelength: 35 mm groove width: 4 mm pulley: Ø 87 mm, one groove, groove width: 12 mm flange: Ø 92 / 165 mm bolt circle diameter: Ø 140 mm hole diameter: Ø 8.5 mm without control box cover used, tested ! Dimensions: 270 x 165 x 195 mm

Elektromotor VEM, ELMO BARLEBEN Typ 1060.1/3 0,04 kW 1400 rpm 220 V 1AC 50 Hz IP 00 Shaft diameter: Ø 9 mm Shaft length: 20 mm Flange diameter: Ø 50 / 74 mm bolt circle diameter: Ø 63 mm 4x threaded hole: M5 x 0.8, continuous New ! Dimensions: 160 x 90 x 74 mm

Transmission SEW R73 LQ140/1 i: 1 : 29,89 Shaft diameter ( output ): Ø 40 mm Shaft length: 80 mm Groove width: 18 mm internal thread ( shaft ): M16 x 2.0, Depth: 45 mm Hollow shaft diameter ( drive ): Ø 24 mm, with redox coupling flange ( output ): Ø 110 / 140 x 140 mm bolt circle diameter: Ø 165 mm 4x threaded hole: M10 x 1,5, Depth: 22 mm Gear foot: 245 x 230 mm hole spacing (parallel to shaft): 205 mm hole spacing ( transverse to shaft ): 170 mm hole diameter: Ø 17.5 mm New, with documents ! Dimensions: 470 x 240 x 290 mm

Pump replacement motor, three-phase electric motor WILO IPN 50/224-1,5/4-S Impeller: Ø 224 mm engine: AF 90L/4I-11 1,,5 kW 1405 rpm 230 / 400 V 3AC 50 Hz IP55 Flange: Ø 275 / 315 mm bolt circle diameter: Ø 295 mm hole diameter: Ø 10.5 mm used, repaired ! Dimensions: 430 x 315 x 315 mm

Pump replacement motor, three-phase electric motor WILO IPN 40/200-0,75/4G12 Impeller: Ø 200 mm Motor: AF 80/4C-11H 0,75 kW 1370 rpm 230 / 400 V 3AC 50 Hz IP55 Flange: Ø 275 / 315 mm bolt circle diameter: Ø 295 mm hole diameter: Ø 10.5 mm used, tested ! repaired ! Dimensions: 400 x 315 x 315 mm

Servo motor, permanent magnet motor SIEMENS 1HU 3078-0AC01 ( 1HU3078-0AC01 ) 1,8 kW 2000 rpm 183 V 3AC IP54 shaft diameter: Ø 24 mm shaft length: 50 mm groove width: 8 mm flange: Ø 130 / 142 x 142 mm bolt circle diameter: Ø 165 mm hole diameter: Ø 11.5 mm timing belt wheel: Ø 88 mm, width 51 mm, teeth: 28 spare part for machining center HELLER BEA 05 DC used, tested ! Dimensions: 555 x 145 x 190 mm

Servo motor, permanent magnet motor SIEMENS 1HU 3058-0AC01-Z ( 1HU3058-0AC01-Z ) 1,33 kW 2000 rpm 171 V 3AC IP54 Shaft diameter: Ø 19 mm Wavelength: 40 mm Groove width: 6 mm Flange: Ø 95 / 106 x 106 mm bolt circle diameter: Ø 115 mm hole diameter: Ø 9.5 mm spare part for machining center HELLER BEA 05 DC used, tested ! Dimensions: 460 x 130 x 120 mm

DC motor with tachogenerator BAUMÜLLER fGNF 132 MV ( fGNF132MV ) 19,5 / 36.9 / 36.9 / 19.5 kW 1000 / 1840 / 3100 / 6000 rpm 240 / 400 / 400 / 400 V DC external excitation: 310 / 310 / 116 / 58 V DC Flange: Ø 230 / 300 x 260 mm bolt circle diameter: Ø 265 mm 4x Bore: Ø 12 mm Tachogenerator: GHT 612/42 20 V at 1000 rpm with external control box main motor for machining center HELLER BEA 05 DC used, tested ! Dimensions: 1040 x 350 x 260 mm

Servo motor, permanent magnet motor SIEMENS 1HU 3078-0AC01-Z ( 1HU3078-0AC01-Z ) 1,8 kW 2000 rpm 183 V 3AC IP54 shaft diameter: Ø 24 mm shaft length: 50 mm groove width: 8 mm Flange: Ø 130 / 140 x 140 mm bolt circle diameter: Ø 165 mm hole diameter: Ø 11.5 mm timing belt wheel: Ø 88 mm, width 51 mm, teeth: 28 spare part for machining center HELLER BEA 05 DC used, tested ! Dimensions: 550 x 145 x 190 mm

Electric motor, pump replacement motor, single-phase motor SPECK - PUMPS Type: NPY-2051 0,25 kW 2800 rpm 230 V 1AC 50 Hz Design: B34K IP55 Shaft diameter: Ø 10 mm Shaft length: 52 mm Flange diameter: Ø 70 / 105 mm bolt circle diameter: Ø 85 mm 4x threaded hole: M6 x 1.0, depth: 10 mm motor base: 100 x 120 mm hole spacing (parallel to shaft): 80 mm hole spacing ( transverse to shaft ): 100 mm hole diameter: Ø 9.5 mm used, tested ! Dimensions: 250 x 130 x 160 mm

Three-phase electric motor VEM KR 160.2/4 ( KR160.2/4 ) 12.9 kW ( 17.5 hp ) 1450 rpm 220 / 380 V 3AC IP 44 Design: B5 Shaft diameter: Ø 38 mm Wavelength: 80 mm Groove width: 10 mm Flange: Ø 250 / 350 mm bolt circle diameter: Ø 300 mm hole diameter: Ø 18.5 mm used, tested ! Dimensions: 550 x 350 x 380 mm

Submersible pump motor, pump replacement motor, three-phase electric motor KSB UMA 150D 13/21 11,5 kW 2901 rpm 400 V 3AC 50 Hz IP58 shaft diameter: Ø 25 mm, with wedge hub profile, 15 wedges shaft length: 45 mm Flange diameter: Ø 142 mm bolt circle diameter: Ø 110 mm 4x studs: M12 x 1.75, length: 35 mm approx. 11.0 m Connection cable New, with documents ! Dimensions ( without cable ): 910 x 145 x 145 mm

Three-phase electric motor EMOD Type: 90L/6 ( 90L/6 ) 1,1 kW 910 rpm 220 / 380 V 3AC 50 Hz Design: B5 IP55 Shaft diameter: Ø 24 mm Wavelength: 105 mm Groove width: 8 mm Flange diameter: Ø 130 / 200 mm bolt circle diameter: Ø 165 mm 4x bore: Ø 11.5 mm used, tested ! Dimensions: 380 x 200 x 245 mm

Three-phase electric motor EMOD Type: 90L/6 ( 90L/6 ) 1,1 kW 910 rpm 220 / 380 V 3AC 50 Hz Design: B5 IP55 Shaft diameter: Ø 24 / 34 mm Wavelength: 48 / 48 mm Groove width: 8 mm Flange diameter: Ø 130 / 200 mm bolt circle diameter: Ø 165 mm 4x bore: Ø 11.5 mm used, tested ! Dimensions: 385 x 200 x 245 mm

Three-phase electric motor BESEL Type: SKg80-4B 0,0,75 kW 1400 rpm 220 / 380 V 3AC 50 Hz design: B14K IP54 shaft diameter: Ø 19 mm wavelength: 40 mm groove width: 6 mm with adapter sleeve: Ø 34 mm, length: 55 mm, square socket: 13 x 13 mm, depth: 15 mm Flange diameter: Ø 80 / 120 mm bolt circle diameter: Ø 100 mm 4x threaded hole: M6 x 1.0, depth: 15 mm New ! Dimensions: 290 x 150 x 195 mm

Three-phase electric motor BESEL Type: SKf80-4B 0,0,75 kW 1400 rpm 220 / 380 V 3AC 50 Hz Design: B14K IP44 Shaft diameter: Ø 19 mm Wavelength: 40 mm Groove width: 6 mm with adapter sleeve: Ø 34 mm, length: 55 mm, square socket: 13 x 13 mm, depth: 15 mm Flange diameter: Ø 80 / 120 mm bolt circle diameter: Ø 100 mm 4x threaded hole: M6 x 1.0, depth: 15 mm New ! Dimensions: 290 x 150 x 195 mm

Electric motor, single-phase motor VEM EAMR 80 G 2 F ( EAMR80G2F ) 1,1 kW 2870 rpm 220 V 1AC 50 Hz Design: B5 IP54 Shaft diameter: Ø 22 mm, shaft length: 50 mm, groove width: 6 mm Flange diameter: Ø 130 / 165 x 165 mm bolt circle diameter: Ø 165 mm 4x bore: Ø 11 mm New ! Dimensions: 345 x 215 x 195 mm

Three-phase electric motor VEM KPER 160 L4 TWS ( KPER160L4TWS ) 15 kW 1455 rpm 420 V 3AC 50 Hz Type: B5 IP54 Shaft diameter: Ø 42 mm Shaft length: 110 mm Groove width: 12 mm Flange diameter: Ø 250 / 350 mm bolt circle diameter: Ø 300 mm 4x bore: Ø 18 mm used, tested ! Dimensions: 620 x 350 x 415 mm

Three-phase electric motor, two speeds VEM K10R 132 M8-4 TWS ( K10R132M8-4TWS ) 4,3 / 6.5 kW 720 / 1450 rpm 200 V 3AC 50 Hz Design: B5 IP55 Shaft diameter: Ø 38 mm Wavelength: 80 mm Groove width: 10 mm Flange diameter: Ø 250 / 288 x 288 mm bolt circle diameter: Ø 300 mm 4x bore: Ø 18 mm used, tested ! Dimensions: 530 x 288 x 338 mm

Three-phase electric motor, two speeds VEM KPR 132 M8-4 TWS ( KPR132M8-4TWS ) 4,3 / 6.5 kW 720 / 1450 rpm 200 V 3AC 50 Hz Design: B5 IP54 Shaft diameter: Ø 38 mm Wavelength: 80 mm Groove width: 10 mm Flange diameter: Ø 250 / 288 x 288 mm bolt circle diameter: Ø 300 mm 4x bore: Ø 18 mm used, tested ! Dimensions: 530 x 288 x 338 mm

Three-phase electric motor VEM K21R 80 K 4 ( K21R80K4 ) 0,0,55 kW 1410 rpm 230 / 400 V 3AC IP55 Design: B34K Shaft diameter: Ø 19 mm Shaft length: 40 mm groove width: 6 mm Flange diameter: Ø 80 / 120 mm bolt circle diameter: Ø 100 mm 4x threaded bore: M6 x 1.0, depth: 10 mm motor base: 126 x 170 mm hole spacing (parallel to the shaft): 100 mm hole spacing ( transverse to shaft ): 125 mm hole diameter: Ø 10.5 mm New ! Dimensions: 250 x 170 x 190 mm

Three-phase electric motor VEM K21R 100 LX 4 ( K21R100LX4 ) 3,3,0 kW 1420 rpm 400 / 690 V 3AC IP55 Design: B34G Shaft diameter: Ø 28 mm Shaft length: 60 mm groove width: 8 mm Flange diameter: Ø 180 / 250 mm bolt circle diameter: Ø 215 mm 4x bore: Ø 14 mm motor base: 170 x 190 mm hole spacing (parallel to shaft): 140 mm hole spacing ( transverse to shaft ): 160 mm hole diameter: Ø 14 mm New ! Dimensions: 360 x 250 x 265 mm

Three-phase electric motor ELEKTROMOTORENWERK BRIENZ AG Type: F56M-2 0,09 kW 2730 rpm 220 / 380 V 3AC 50 Hz Design: B14K IP54 Shaft diameter: Ø 9 mm wavelength: 20 mm groove width: 3 mm Flange diameter (motor): Ø 50 / 80 mm bolt circle diameter: Ø 65 mm 4x threaded hole: M5 x 0.8, depth: 10 mm timing belt wheel: diameter: Ø 57 mm, width: 12 mm tooth spacing: 5 mm, number of teeth: 36 used, tested ! Dimensions: 210 x 130 x 155 mm

Three-phase electric motor, two speeds ABM, ADAM BAUMÜLLER GmbH MARKTREDWITZ Type: 2.DF1/63 b-4/2 0,12 / 0,18 kW 1390 / 2770 rpm 380 V 3AC 50 Hz Design: B5 IP44 / 54 Shaft diameter: Ø 11 mm Wavelength: 18 mm Groove width: 4 mm Flange diameter: Ø 95 / 140 mm bolt circle diameter: Ø 115 mm 4x bore: Ø 10 mm used, tested ! Dimensions: 210 x 140 x 185 mm

Servo Motor, AC Servo Motor, Permanent Magnet Motor BOSCH SG-B1.016.060-00.000 Z-No.: 1070917157 0,0,95 kW 6300 rpm 4.5 A IP65 Shaft diameter: Ø 14 mm Wavelength: 22 mm Flange: Ø 60 / 70 x 70 mm bolt circle diameter: Ø 75 mm hole diameter: Ø 5.5 mm used, tested ! Dimensions: 165 x 70 x 102 mm

Three-phase electric motor, gearbox replacement motor, without brake VEM ZG1 BMRE 71 K 4 ( ZG1BMRE71K4 ) 0,55 kW 1400 rpm 220 / 380 V 3AC IP 44 Design: B5 Shaft diameter: Ø 19 mm Wavelength: 40 mm Groove width: 6 mm Flange: Ø 180 mm / 164 x 164 mm bolt circle diameter: Ø 165 mm hole diameter: Ø 10.5 mm used, tested ! Dimensions: 290 x 165 x 190 mm

Three-phase electric motor, with forced fan REXROTH MOT-FC-EV2-BV-250M-4-5CB-0055-C3T-HOY 55 kW 1480 rpm 4 00 / 690 V 3AC 50 Hz Design: B5 IP55 Shaft diameter: Ø 65 mm Wavelength: 140 mm Groove width: 18 mm Flange diameter: Ø 450 / 550 mm bolt circle diameter: Ø 500 mm 8x bore: Ø 19 mm external fan: Type G-250A 0.37 kW, 1400 rpm 230 / 400 V 3AC 50 Hz V: 1813 m3/h, P: 80 Pa New ! Dimensions: 1160 x 650 x 600 mm

Electric motor with brake VEM BMREB 90 L 6 ( BMREB90L6 ) 1,1,5 kW 945 rpm 220 / 380 V 3AC 50 Hz IP44 Design: B5 Shaft diameter: Ø 24 mm Wavelength: 54 mm Groove width: 12 mm flange: 210 x 210 mm / Ø 180 mm bolt circle diameter: Ø 215 mm hole diameter: Ø 14 mm New ! Dimensions: 365 x 210 x 230 mm

Three-phase electric motor ENERGO ? X71A4?3 0,55 1370 rpm 220 / 380 V 3AC IP 44 Design: B5 shaft diameter: Ø 19 mm Wavelength: 40 mm Groove width: 6 mm Flange: Ø 130 / 200 mm bolt circle diameter: Ø 165 mm hole diameter: Ø 12.5 mm New ! Dimensions: 285 x 200 x 230 mm

Three-phase electric motor SIEMENS 1MA5106-6BA24 1,3 kW 935 rpm 220 / 380 V 3AC 50 Hz IP54 Design: B5 Shaft diameter: Ø 28 mm Wavelength: 60 mm Groove width: 8 mm flange: Ø 180 / 250 mm bolt circle diameter: Ø 215 mm hole diameter: Ø 14.5 mm used, tested ! Dimensions: 405 x 250 x 285 mm

Three-phase electric motor EP ROMANIA ASI 90 S24F165-4 ( ASI90S24F165-4 ) 1,1 kW 1390 rpm 220 / 380 V 3AC IP 44 Design: B35 Shaft diameter: Ø 24 mm Shaft length: 50 mm Groove width: 8 mm Flange: Ø 201 / 130 mm bolt circle diameter: Ø 163 mm hole diameter: Ø 11 mm < br />motor base: 135 x 192 mm hole spacing (parallel to shaft): 100 mm hole spacing ( transverse to shaft ): 140 mm hole diameter: Ø 9 mm New ! Dimensions: 305 x 250 x 200 mm

Crane motor, spare motor, electric motor, with brake, two speeds DEMAG KBA 80 A ( KBA80A ) 0,035 / 0,25 kW 400 / 1390 rpm 380 V 3AC 50 Hz Shaft diameter: Ø 19 mm Wavelength: 25 mm groove width: 6 mm Flange diameter: Ø 80 / 123 mm bolt circle diameter: Ø 100 mm 4x threaded hole: M6 x 1.0, depth: 10 mm used, tested ! Dimensions: 325 x 160 x 220 mm

Three-phase electric motor CET MOHELNICE Type: 3AP80-2 1,1 kW 2840 rpm 220 / 380 V 3AC 50 Hz IP44 Design: B35 Shaft diameter: Ø 19 mm Shaft length: 40 mm Groove width: 6 mm Flange diameter: Ø 130 / 200 mm bolt circle diameter: Ø 165 mm hole diameter: Ø 12,1 mm Motor base: 126 x 150 mm hole spacing (parallel to the shaft): 100 mm hole spacing ( transverse to the shaft ): 125 mm hole diameter: Ø 9.5 x 12 mm ( slotted hole across the shaft) used, tested ! Dimensions: 365 x 190 x 230 mm

Three-phase electric motor ABB M2AA160M4 11.5 kW 1440 - 1450 rpm 380 - 420 V 3AC 50 Hz 60 Hz - operation is possible IP 55 Design: B5 Shaft diameter: Ø 42 mm Wavelength: 110 mm Groove width: 12 mm Flange diameter: Ø 250 / 350 mm bolt circle diameter: Ø 300 mm hole diameter: Ø 19 mm used, tested ! Dimensions: 610 x 350 x 390 mm

Three-phase electric motor VEM, ELMO type 1260.1/1 0,06 kW 1400 rpm 220 / 380 V 50/ 60 Hz IP 44 Shaft diameter: Ø 9 mm Shaft length: 20 mm Flange diameter: Ø 50 / 82 mm bolt circle diameter: Ø 14.5 mm hole diameter: Ø 65 mm 4x threaded hole: M5 x 0.8, depth: 20 mm new , aluminium housing ! Dimensions: 165 x 105 x 130 mm

Electric motor with brake SEW DV112M8/4/BMG/HR/TF/IS 1,2 / 2,2 kW 700 / 1440 rpm 400 V IP 55 Shaft diameter: Ø 28 mm Flange diameter: Ø 250 mm bolt circle: center-center 155mm Two speeds, new ! Dimensions: 490 x 320 x 250 mm

Three-phase electric motor, with forced fan SIEMENS 1LA71334AA11-Z 7,5 kW 1455 rpm 230 / 400 V IP 55 Shaft diameter: Ø 38 mm Shaft length: 80 mm Groove width: 10 mm Flange diameter: Ø 230 / 300 mm bolt circle diameter: Ø 265 mm hole diameter: Ø 14.5 mm external fan: A2E250 0,125 kW 2600 rpm 230 V 1AC 50 Hz used, tested ! Dimensions: 610 x 300 x 340 mm

Servo motor with tachogenerator BBC F12M2 FD 57348 02 86 0.19 kW 3000 rpm 24 V Shaft: Ø 12 mm bolt circle (flange): Ø 88 mm New ! Dimensions: 185 x 140 x 140 mm

Fan motor, single-phase motor EMERSON F48HXDZP-2106 0,06 kW 1550 rpm 230 V 50 / 60 Hz bolt circle diameter (mounting): Ø 96 mm shaft diameter: Ø 10 mm New ! Dimensions: 160 x 125 x 125 mm

Fan motor, three-phase electric motor VEM KMRB 56 G 4 ( KMRB56G4 ) TGL 11856 0,18 kW 1360 rpm 220 / 380 V IP 54 shaft diameter: Ø 11 mm Flange diameter: Ø 81 mm bolt circle diameter: Ø 65 mm, thread: M5 New ! Dimensions: 180 x 110 x 150 mm

Worm gear VEB Getriebefabrik Coswig ASUG 05 U4-50X80 TGL 45341 i = 80 input speed max: 1500 rpm input power: 0.0.0 23 KW input: shaft diameter: Ø 19 mm, shaft length: 30 mm, groove width: 5 mm flange: 140 x 140 / Ø 110 mm bolt circle diameter: Ø 130 mm, 4x threaded hole: M8 x 1.25 output: hollow diameter: Ø 25 mm, shaft length: 112 mm, groove width: 8 mm 2x gear foot: 118 x 82 mm hole spacing: 110 / 60 mm 4x threaded hole: M8 x 1.25, depth: 20 mm material (housing): Cast iron used, tested ! Dimensions: 230 x 140 x 190 mm

Fan motor VEM EBMOa 63 K2 154/FTII/2 ( EBMOa63K2154/FTII/2 ) TGL 20675 0,25 kW 2830 rpm 220 V IP 44 shaft diameter: Ø 11 mm flange diameter: Ø 90 mm bolt circle diameter: Ø 75 mm, Thread: M5 New ! Dimensions: 200 x 135 x 165 mm

Fan motor VEM EBR 63.2/2 FTII ( EBR63.2/2FTII ) TGL 11856 0,18 kW 2880 rpm 220 V IP 44 shaft diameter: Ø 11 mm Flange diameter: Ø 90 mm bolt circle diameter: Ø 75 mm, thread: M5 New ! Dimensions: 175 x 120 x 155 mm

Servo motor, DC motor, with tachogenerator and brake - Encoder PARVEX T4C4BR0515 2660 rpm 200 V DC 12,4 A IP 55 Shaft diameter: Ø 19 mm Shaft length: 38 mm Groove width: 6 mm Flange diameter: Ø 40 / 76 / 114 mm bolt circle diameter: Ø 95 mm 4x threaded hole: M8 x 1.25, depth: 20 mm tachogenerator: 20 mV per revolution New, with documents ! Dimensions: 445 x 115 x 160 mm

Servo motor with brake, permanent magnet motor STOBER ANTRIEBSTECHNIK EK 502 U EK502UEPE140 1622698 3000 rpm 140 V IP56 shaft: Ø 19 mm flange: 117 x 117 mm, hole spacing: 92 mm, bores: Ø 9 mm Intermediate flange: Ø 200 / 130 mm, bolt circle: Ø 165 mm, bores: Ø 10.5 mm used, tested ! Dimensions: 255 x 200 x 210 mm

Three-phase electric motor VEM KMRB 80 G 4 ( KMRB80G4 ) 1,5 kW 1400 rpm 220 / 380 V 3AC IP44 shaft diameter: Ø 22 mm, drive adapter: Ø 38 mm, 2x drive groove: 12 x 14 mm flange: 165 x 165 mm, PCD: 165 mm, 4x bore: Ø 11 mm Intermediate flange: 223 x 223 mm, bolt circle: 216 mm, 4x bore: Ø 9 mm spare part for milling machine AUERBACH FU 250 x 1000 ! used, tested ! Dimensions: 300 x 223 x 225 mm

Servo motor with brake, permanent magnet motor SIEMENS 1FK6063-6AF71-1EB0 3000 rpm 276 V IP65 Shaft: Ø 24 mm Flange: 126 x 126 mm, hole spacing: 92 mm, bores: Ø 9 mm Intermediate flange: Ø 200 / 130 mm, bolt circle: Ø 165 mm, bores: Ø 10.5 mm used, tested ! Dimensions: 340 x 200 x 210 mm

Three-phase electric motor AEG AM 71 N Y G ( AM71NYG ) 0,18 kW 915 rpm 220 / 380 V 3AC IP 54 shaft diameter: Ø 14 mm shaft length: 30 mm groove width: 5 mm Flange diameter: Ø 160 / 110 mm bolt circle diameter: Ø 130 mm hole diameter: Ø 9.5 mm New ! Dimensions: 235 x 160 x 190 mm
