boehringer vdf used for sale

Universal CNC lathe BOEHRINGER NG 200 Manufacturer: BOEHRINGER Type [ type]: NG200 CNC double Control unit: Siemens 840D Year of construction[construction year]: 10/2001 Rotating diameter: 290 mm Turning length: 850 mm Control: SIEMENS 840 D Orbital diameter over bed: 600 mm Revolver 1 Revolver 2 Counter spindle Counter headstock Tailstock C-axis Powered tools Automatic machine doors – newly retrofitted Z-axis resolution: 40nm (2nm interpolated) Travel in Z: 740mm Rapid traverse speed in Z: 25 m/min Centering tip SK 30 X-axis resolution: 125nm (8nm interpolated) Travel in Z: 220mm Rapid traverse speed in Z: 25 m/min Distance between main and counter spindle: 1034mm Drive power: 30-72 kW Torque: 662 Nm Speed range max.: 4500 rpm Spindle head: Size 6/8 DIN 55026 Spindle diameter in the front. Bearing [spindle]: 120 mm Chuck diameter: 200-315mm Spindl ...

turning diameter over bed: 490 mm turning diameter over slide rest: 280 mm turning length: 2000 mm centre height: 245 mm centre distance: 2000 mm spindle bore: 62 mm total power requirement: 7,5 kW weight of the machine ca.: 3,5 t dimensions of machine L x W x H: 3,78 x 1,17 x 1,42 m Accessories: 3-jaw chuck 240 mmø, face plate 400 mmø, MULTIFIX-tool post, solid steady, coolant The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 820 mm turning length: 300 mm turning diameter over slide: 465 mm control: max. torque on the spindle: 3000 Nm turning speeds: 5,6-1120 U/min Feed: 1-5000 mm/min Rapid movement: 5000 mm/min tailstock quill taper MT: 6 3 jaw chuck Forckrath: mm steady: mm main drive motor: 50 kW diameter of main spindle: 170 mm spindle passage: 128 mm tailstock quill diameter: 125 mm tailstock quill stroke: 250 mm z-axis: 3000 mm x-axis: 550 mm total power requirement: 52 kW weight of the machine ca.: 7,1 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

core drilling diameter max.: 200 mm bore depth: 3500 mm swing diameter: 700 mm turning speeds: 475 U/min steady: 275 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

core drilling diameter max.: 200 mm bore depth: 2500 mm swing diameter: 700 mm turning speeds: 475 U/min steady: 370 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

BOEHRINGER NG 180-2 CNC turning center was built in 2006 in Germany. This reliable and efficient machine performs precision machining of workpieces with a maximum diameter of 290 mm using a high-speed spindle and high-quality cutting tools taken from a 12-position turret. The entire turning process is performed with excellent stability, thanks to a vibration- and oscillation-resistant design made of high-quality raw materials. The BOEHRINGER NG 180 CNC lathe is controlled by an intuitive SIEMENS CNC control, whose excellent optimisation allows to maximise production efficiency. The total weight of the machine is 10000 kg. Technical specifications of the BOEHRINGER NG 180-2 lathe - CNC control: SIEMENS SINUMERIK - turning diameter: 290 mm - turning length: 850 mm - 12-position turret head - maximum spindle rotational speed: 4000 rpm - minimum spindle rotational speed: 10 rpm - d ...

turning diameter: 570 mm turning length: 2000 mm control: Sinumerik 805 Siemens swing diameter over face slide: 365 mm main spindle speeds:: 3-2.500 U/min drive of main spindle: 15/19 kW spindle bore: 62 mm spindle head: DIN 55027 No.8 tailstock taper MT: 5 quill stroke: 190 mm pinole diameter: 80 mm feed range - long. and cross: 0,01-50 mm/u total power requirement: 50 KVA weight of the machine ca.: 5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 820 mm turning length: 5000 mm turning diameter over slide: 460 mm control: B2T max. torque on the spindle: 3400 Nm turning speeds: 5,6-1120 U/min Feed: 1-5000 mm/min Rapid movement: 5000 mm/min tailstock quill taper MT: 6 3 jaw chuck Forckrath: 630 mm steady: 525 mm steady: 335 mm main drive motor: 50 kW total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 1020 mm turning length: 4000 mm turning diameter over slide: 720 mm Holder Multifix: control: Siemens type: 805 tailstock quill taper MT: 6 transmission ratio: 2 turning speeds: U/min turning speeds: U/min bed width: 560 mm spindle bore: 200 mm workpiece weight: kg faceplate: 1000 mm make: Forkhardt PSA 1000 3 jaw chuck Forckrath: 500 mm steady: 263 mm steady: 500 mm total power requirement: KVA weight of the machine ca.: t dimensions of the machine ca.: 7,4x2,5x2,5 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 650 mm turning length: 2000 mm turning diameter over slide: 260 mm Holder Multifix: control: Siemens type: Sinumerik tailstock quill taper MT: 5 transmission ratio: 2 turning speeds: 1-2000 U/min spindle bore: 106 mm total power requirement: 38 KW weight of the machine ca.: t dimensions of the machine ca.: 7,4x2,5x2,5 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

core drilling diameter max.: . mm bore depth: . mm swing diameter: . mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 820 mm turning length: 2.000 mm control: SIN 810 D center height over square guideway: 400 mm turning diameter over slide rest: 500 mm x-travel: 540 mm z-travel: 2.100 mm feed x/z-axis: 0,01 - 50 mm/min rapid traverse X-axis: 5,00 m/min rapid traverse Z-axis: 10,00 m/min feeding force facing: 12.500 N power feed longitudinal: 20.000 N spindle turning speed range: 6,4 - 1.600 U/min spindle turning speed - gearbox stage 1: 6,40 - 376 1/min. spindle turning speed - gearbox stage 2: 27,40 - 1.600 1/min. power capacity at 60% / 100 % load: 46,00 / 37,00 KW max. torque at 60% / 100% load: 5.073 / 4.069 Nm constant cutting rate: 1 - 9.999 m/min. spindle head DIN 55027 - Size: 11 spindle diameter in front bearing: 170 mm spindle bore: 128 mm tailstock quill taper MT: 6 diameter of quill: 125 mm quill stroke: 280 mm thread pitch: 0,1 - 400 mm total power requirement: 35,00 kW we ...

centre distance: 1500 mm : 550 serial number: 20-08 documentation: ja digital: ja hollow: 88 mm multifix: ja : Auffang Wannen The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 820 mm turning length: 6000 mm turning diameter over slide: 520 mm Holder Multifix: control: Siemens type: 805 tailstock quill taper MT: 6 transmission ratio: 2 turning speeds: 8-1600 U/min bed width: 560 mm spindle bore: 128 mm faceplate: 600 mm 3 jaw chuck Forckrath: 400 mm steady: 250-500 mm chip conveyor: diameter of quill: 125 mm quill stroke: 280 mm total power requirement: KVA weight of the machine ca.: 12 t dimensions of the machine ca.: 9,5x2,5x2,5 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, p ...

Key data: 610 mm, 375 mm

The machine is in very good condition and still under power. Pick-up can be arranged at short notice.

turning diameter:570 mm turning length:1000 mm dimensions of the machine ca.:3,25 x 2,03 x 1,95 m Tool disc turret for 8 tools with VDI 30. Not for power tools machine manual, technical documentation; Accessories: 3-jaw chuck, various tool holders Video is available

Various machines mostly Wafios or Deiters available! Eg. Wafios UF30 / VDF80 / DF3

Several types available please contact us by email.

Bezel moving, moving bezel, steady rest, Lynette -max. passage: Ø 170 mm -Support: ball bearing -Tip height: 345 mm -Hole spacing: 550 mm -Hole diameter: Ø 21 mm -Drawings: in the photos -Quantity: 1 piece available -Dimensions: 605/80/H670 mm -Weight: 59 kg

Bezel, steady rest, lynette -Bezel: max. opening Ø 170 mm -Centre height: 325 mm -Support: ball bearing -technical drawing: in the photos -Dimensions: 520/260/H590 mm -Weight: 77 kg

turning diameter: 300 mm turning length: 2000 mm swing diameter over bed slide: 520 mm total power requirement: 7,5 kW weight of the machine ca.: 2,8 t dimensions of the machine ca.: 4745 mm x 1340 mm m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

NDT lathe - Böhringer Type VDF 400 Spindle 600-440 mm maximum length 2000mm Tool magazine with 12 tools

Tip height: 265 mm Center width: 1500 mm Circumferential Ø: over bed 540 mm Spindle bore: 65 mm Spindle mount: size 8 Pick-up cone tailstock: 5 MK Spindle speeds: 9 - 1800 rpm Feeds: longitudinal/flat 0.063-2.24/0.032-1.12 mm/rev Thread pitches: 0.35 - 560 mm Electrical connection: 380 V, 11 kW Space requirement: 4580 x 1250 x 1330 mm Weight: 3200 kg

Key data: 430 mm, 1000 mm, 430 mm

Turning length: 1,000 mm Turning diameter over bed: 430 mm Turning diameter over slide: 255 mm Spindle speeds: 19 - 2,000 rpm Spindle bore: 56 mm Equipped with: - Various Multifix tool containers - Coolant device Country of origin: Germany Motor power: 7.5 kW Machine LxWxH: 360 x 103 x 130 cm Machine weight: 1800 kg

workpiece weight: 279 KG length: ca. von Bett bis Lynette mm : 189 € . max: durchlass 369 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

serial number: 1113-23 turning length: 500 mm turning diameter: 220 mm chip conveyor: ja kW : Werkzeugwechsler 12-fach spindle turning speed range: 5000 U/min tail stock: automatisch Control: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

control: SIEMENS 810D turning diameter over bed: 1000 mm centre height: 500 mm centre distance: 2000 mm turning dia. over face-slide: 700 mm spindle bore: 128 mm spindle taper ISO: DIN55027/11 spindle turning speed - stepless: 6.4-1600 U/min tailstock quill taper MT: 6 diameter of quill: 125 mm quill stroke: 280 mm feed - longitudinal/cross: 5000/4000 mm/min rapid traverse longitudinal and cross: 10/5 m/min dimensions of machine: 5600 x 2600 x 2800 mm weight: 9.1 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

core drilling diameter max.: . mm bore depth: . mm swing diameter: . mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

core drilling diameter max.: . mm bore depth: . mm swing diameter: . mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m (60) The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

core drilling diameter max.: . mm bore depth: . mm swing diameter: . mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

core drilling diameter max.: . mm bore depth: . mm swing diameter: . mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m (47) The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

core drilling diameter max.: . mm bore depth: . mm swing diameter: . mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m (61) The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

- Maximum swing 500 mm - 3 x adjustable bronze rollers - 2 Matching steady rest

Inv. Num. : 8761 Type: VDF Producer: Heidenreich & Harbeck Generated: Parameters: Maximum turning length: 1500 mm Equipment: Digital measurement

Center height: 180mm, swing diameter over bed/cross slide: 360mm/190mm, distance between centers: 750mm, speed: 1250rpm, machine dimensions X/Y/Z: approx. 2800mm/1000mm/1300mm, weight: approx. 1750kg. An on-site inspection is possible.

General SKU318M524 LocationBarneveld MakeSchenk Filterbau GMBH TypeVDF No.485.524 Main Features MaterialAluminium/Stainless steel Motor2.2 KW Surface24 m2 Specified Features - Rotating vacuum filter Rotating vacuum filtercheck Filter surface24m2 Drum sizesdia.2400mm x3200mm Motor+/- 2,2 KW Drum speed3 rpm With knife dischargecheck With roll dischargecheck Manual operatedcheck Motor+/- 1,0 KW (belt) With vacuum pumpcheck With vacuum vessel(2x) MaterialAluminium, Stainless steel Information Year of construction1985 With switchgearcheck Floorspace4,9x3,6 M Total height3,0 M Technical specs Extra informationWith pressure rollsRotating vacuum filtersSchenkFilters > Rotating vacuum filtersBrand > Schenk What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You  ...

Precision lathe, lathe, lead screw lathe, lead screw lathe -Manufacturer: VDF Heidenreich Harbeck, lead screw and feed screw lathe type 24R0 -Machine bed: hardened -Turning length: 1230 mm -Rotation diameter over bed: 500 -Turning diameter over support: 290 mm -Spindle bore: Ø 56 mm -Spindle speeds: 19 - 2000 rpm -Wedge bar chuck: Forkardt Ø 250 mm -Tailstock mount: MK4 -Drive: 5.5 kW -Accessories: 1x bezel, 7x Multifix tool holders, see photos -Dimensions: 1180/3050/H1345 mm -Weight: 1907 kg

turning diameter over bed: 520 mm turning diameter over slide rest: 260 mm turning length: 1600 mm turning diameter in the gap: - mm turning speeds: 14 - 710 U/min centre height: 260 mm spindle bore: mm total power requirement: 11,0 KW weight of the machine ca.: 2,9 t dimensions of the machine ca.: 4,0 x 1,4 x 1,6 m Lead screw lathe - 4-jaw chuck 315mm - Multifix tool post size B - Feed in top slide - Steady rest - Machine feet - Chip tray The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 630-640 mm turning diameter over slide rest: ca 380 mm turning length: ca 2000-4000 mm total power requirement: 15 kW weight of the machine ca.: 7-8 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed:570 mm turning diameter over slide rest:365 mm turning length:2.000 mm feed per revolution:0,06 - 58/ 0,03 -28 mm spindle turning speed range:11,2 - 2.240 U/min spindle bore:62 mm spindle head:8 nach DIN 55022 total power requirement:15 kW dimensions of the machine ca.:4,5 x 1,5 x 1,4 m weight of the machine ca.:4,8 t

turning diameter over bed:570 mm turning diameter over slide rest:365 mm turning length:2000 mm feed per revolution:0,06 - 58 / 0,03 - 28 mm spindle turning speed range:11,2 - 2240 U/min spindle bore:62 mm spindle head:8 nach DIN 55022 total power requirement:15 kW weight of the machine ca.:4,8 t dimensions of the machine ca.:4,5 x 1,5 x 1,4 m with digital readout HEIDENHAIN rapid feed, MULTIFIX toolholder system fixed steady dia. 160 mm 3 jaw chuck RÖHM TR 250 coolant attachment diverse toolholders, diverse jaws

Auction-ID: A1-40976-83
