Folder-gluer BOBST MEDIA 100 II-A2

Reference ID PP56956
Category Folder Gluer
Manufacturer Bobst
Model MEDIA 100 II-A2
Year Built 1999
Color -
Impression -
Working Hours -
Speed - -
Max. Size -
Min. Size -
Condition Good
Location Europe
Availability Immediately
Machine Description
Brand: BOBST
Model: MEDIA 100 II-A2
Year of Manufacture: 1999
Origin: Switzerland
Condition: 100% functional
Machine Availability: Can be inspected on site in running condition
Working Formats
Maximum working width: 1000 mm
Minimum working width: 126 mm
Minimum board width before gluing: approx. 100 mm
Maximum unfolded box length: 600 mm
Minimum box length: 60 mm
Maximum format: at least 600 mm
Note: According to the operator, larger boxes may also be produced on this
machine; final confirmation should be checked in the technical documentation.
Example: A format of at least 600 mm can be processed, based on 150 mm x 4
box walls plus glue flap.
Processable Materials
Solid board: 100–600 g/m²
Corrugated board: B, N, F and E flute
Speed and Performance
Mechanical speed: approx. 300–360 m/min
Folding and Box Types
Folding system: Straight line
Crash-lock bottom: available
4- and 6-corner boxes: possible depending on configuration
Control System
Electronic control unit: BOBST CUBE
Gluing System
Lower gluing system: standard lower gluing wheel
Upper gluing system: electronic upper gluing system (e.g. HHS)
Cold glue guns: 6 units
Hot glue gun: 1 unit
Gluing points: gluing from 6 different application points
Additional feature: glue application via container wheel
Envelope gluing cassette: available
Equipment
Prefolder section: available
Crash-lock bottom section: available
Counter / kicker: available
Handypack pressure section: available
Production Capabilities
Envelope production
Advent calendar production
Folding carton box production
Flexible production for various box and packaging types
Machine Weight
Approx. Weight: 4,600–4,800 kg
seller offer No. resale PP56956
