bed milling used for sale

Important and distinguishing design features of the RaptorX SL CNC Router steel base machine RaptorX-SL2200/S15 The application range of the RaptorX- SL CNC milling machine is extremely wide due to the adjustable work surface height (variable bridge clearance: 150mm, 300mm or 400mm) plus the travel range of the Z axis of 300mm (at no extra cost). The Z axis stability is excellent, allowing you to work as accurately on large 3D objects as one can on flat sheet materials. Use the system as a plasma cutting system or a water jet cutting system, appropriate accessories are available. It is possible to work on work-pieces up to a height of 850mm (steel cabinets etc.) or three-dimensional objects up to a height of approx. 400mm (with 400m long milling cutter). This capability is unusual for machines of this size and mold makers usually use a layered construction metho ...

Universal milling machine. Hure head. Table size: 2000x480mm. Longitudinal travel: 1700mm. Cross travel: 400mm. Vertical travel: 575mm. ISO50. Motor power: 20cv. Weight: 5500Kgs. Dimensions: 2550x2380x2680.

Specifications / Technical data S-1400/T 3-axis CNC-portal-machine and engraving machine (Attention: Pictures show the High-Z S-1400 with trapezoidal thread spindles, this differs exclusively by the spindles . With the T-variant of the high-Z CNC fraes machine, you acquire old-fashioned technology with the certain I-meat in TUeV-certified quality (EMC). The High-Z/T is designed for even more accuracy (repeatability about 0.01mm ) and especially for higher travel speeds. Through the ball-circulation spindles used, the High-Z/T portalfraes machine achieves fantastic accuracy and an almost unmeasurable reverse play of about 0.01mm. At the same time, high travel speeds of up to approx. 108mm / second ( 6500 mm / minute ) can be achieved. This means engraving and fraes speeds of up to approx. 4500mm/min can be realized and urgent journeys up to approx. 7000mm/min. Here you can s ...

Table clamping surface: 500 x 1000 mm stroke x: 630 mm traverse path y: 500 mm traverse path z: 460 mm Quill stroke: hand 45 mm spindle retainer: ISA 40 spindle speeds: 31.5-3150 rpm stufenl feeds. adjustable: 1-3000 mm / min rapid traverse: x/y 6 / z 4 m/min. Supply: 380 V, 6/8 kW space: 1800 x 2120/2600 x 2020 mm weight: 3100 kg

5 axis machininng center (milling/turning from bar) multitasking Under power in our warehouse MAKE CHIRON MODEL MILL 800 5 axis CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 ? 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min ...

Table clamping surface: 630 ø mm traverse path x: 600 mm traverse path y: 450 mm traverse path z: 500 mm Quill stroke: hand 80 mm spindle retainer: ISO 40 spindle speeds: 20-3150 rpm stufenl feeds. adjustable: 1-3000 mm / min rapid traverse rate: 4 m / min. Connection: 380V kW space: 2000 + 850 x 2000 x 2000 mm weight: 3300 kg

Universal milling machine. Table size: 1400mmx300mm. Longitudinal travel: 1200mm. Cross travel: 320mm. Vertical travel: 500mm. ISO40. Hure head. Speeds: 12. (40-1800rpm). Motor power: 7Kw.

Stroke x: 600 mm traverse path y: 400 mm traverse path z: 400 mm spindle retainer: ISO 40 spindle speeds: 80-4000 rpm stufenl feeds. adjustable: 0,1-1500 mm / min rapid traverse: x & y/z 4/2.5 m / min. Supply: 380 V, 16 kVA kW space: 2450 x 2200 x 1900 mm weight: 2250 kg

Universal milling machine with automatic movement ram. Table: 1700x700. Longitudinal travel: 1320mm. Cross travel: 1016mm. Vertical travel: 560mm. ISO50. 18 speeds (28-1800rpm) 18,75 Hp. Weight: 6200Kg.

Specifications / Technical Data S-1400/T CNC-Router and CNC-Engraver / Engraving Machine (Attention: Pictures are showing the type with trapezium spindles, thats the only different to the t-series ) With the purchase of the T-variation of High-Z CNC-router you get a proven technology with a certain icing of the cake in TÜV-certified quality. High-Z/T cnc-routers are conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T cnc-machines achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this 3D-cnc-machine you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on ...

Table clamping surface: 500 x 1600 mm table movement x: 1220 mm table movement y: 500 mm table movement z: 500 mm spindle retainer: SK 50 spindle speeds: 56-2800 rpm feeds longitudinal & cross: 10-1800 mm / min feed vertically: 2.5-450 mm / min. Supply: 400 V, 16 kVA kW space: 2000 x 2250 x 2150 mm weight: 4500 kg

Specifications / Technical data S-1000/T Portalfraesmaschine / Engraving machine With the T-variant of the High-Z CNC-Fraese you acquire old-fashioned technology with the certain i-tuepfelchen in TUeV-certified quality (Emc). The High-Z/T Fraese is designed for even more accuracy (repeatability about 0.01mm ) and especially for higher travel speeds. Through the ball-circuit spindles used, the High-Z/T achieves fantastic accuracy and an almost unmeasurable reverse play of about 0.01mm. At the same time, high travel speeds of up to approx. 108mm / second ( 6500 mm / minute ) can be achieved. This is how engraving and fraes speeds of up to approx. 4500mm/min can be realized and urgent journeys up to approx. 7000mm/min. Here you can see a video about empty runs with the new high-Z/T 3D CNC machine. This makes this machine series in the industrial sector just as applicable for work ...

Specifications / Technical Data S-1000/T CNC-Router / CNC-Engraver With the purchase of the T-variation of High-Z CNC-router you get a proven technology with a certain icing of the cake in TÜV-certified quality. High-Z/T was conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T CNC-engraver achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this cnc-machine you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on a unloaded drive with the new High-Z / T. This cnc-router series is usable in the industrial field as well as for works like engraving, milling, dr ...

Specifications / Technical Data S-720/T CNC-Fraesmaschine und Graviermaschine / Fraese With the T-variant of the High-Z CNC Fraes.-and engraving machine you acquire old-fashioned technology with the certain i-Tpuelchen in TUeV-certified quality (EMC). The High-Z/T CNC-Fraese is designed for even more accuracy (repeatability about 0.01mm ) and especially for higher travel speeds. The high-Z/T CNC-Fraese achieves fantastic accuracy and an almost unmeasurable reverse play of about 0.01mm due to the ball's circulation spindles. At the same time, high travel speeds of up to 108mm/second ( 6500mm/ minute) can be achieved. This allows engraving and feeding speeds of up to approx. 4500mm/min and express ingesses up to approx. 7000mm/min. Here you can watch a video of empty journeys with the new High-Z/T. This series of mechanical engineering is just as applicable in the industrial sec ...

Important and distinguishing design features of the RaptorX SL steel base machine The application range of the RaptorX- SL CNC milling machine is extremely wide due to the adjustable work surface height (variable bridge clearance: 150mm, 300mm or 400mm) plus the travel range of the Z axis of 300mm (at no extra cost). The Z axis stability is excellent, allowing you to work as accurately on large 3D objects as one can on flat sheet materials. Use the system as a plasma cutting system or a water jet cutting system, appropriate accessories are available. It is possible to work on work-pieces up to a height of 850mm (steel cabinets etc.) or three-dimensional objects up to a height of approx. 400mm (with 400m long milling cutter). This capability is unusual for machines of this size and mold makers usually use a layered construction method to produce large 3D objects.  ...

Horizontal Milling Machine DIXI, Type 350 Mach. No. 350-16 Control: Dixi CNC 4400 Table dimensions: 810 x 810 mm table load: 2000 kg X/Y/Z: 1000 / 1000/1000 mm B-axis rotating table C-axis vertical round rotating table RPM: 10-3000 U / min Power: 18 kWh Table with 7 T-slots: 18 mm rapid traverse: 20-10000 mm / min taper ISO 50 Weight: 17 tons Accessories: Vertical milling head, vertical round table, angle rack, holders, etc.

Specifications / Technical Data S-400/T CNC portal fraesmachine / engraving machine, TUeV certified Already more than 4500 CNC machines of type High-Z sold worldwide ! With the T-variant of the High-Z CNC-Fraesmaschine you acquire old-fashioned technology with the certain I-T-Tpfelchen The High-Z/T is designed for even more accuracy (repeatability about 0.01mm ) and especially for higher travel speeds. The high-Z/T CNC fraes machine achieves fantastic accuracy and an almost unmeasurable reversal of about 0.01mm due to the ball-circuit spindles used. At the same time, high travel speeds of up to 108mm/second ( 6500mm/ minute) can be achieved. Thus, engraving and fraes speeds of up to approx. 4500mm/min can be realized and fast-moving speeds up to approx. 7000mm/min. This is just as applicable in the industrial sector for work such as engraving, frause, drilling, measuring, cutti ...

Specifications / Technical Data S-400/T CNC-Portal-Router / CNC-Engraving machine with TÜV certification With the purchase of the T-variation of High-Z cnc-router you get a proven technology with a certain icing of the cake in TÜV-certified quality. High-Z/T cnc-routers was conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T 3D-cnc-engravers achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this cnc-machines you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on a unloaded drive with the new High-Z / T. This 3D-milling-machine series is usable in the ...

Specifications / Technical Data S-720 CNC-Router / CNC-Engraver / Milling machine With the High-Z cnc router and engraving machine you purchase an allround talent. If you want to clampand fix complex workpieces on the worksurface, or, or, or clamp work-pieces in a high bench vise (the cnc milling machine sits on a frame-construction, is driven by 2 motors and therefore allows to be positioned above a piece to be processed). Or if you simply want to do engraving- or drillingjobs.you can work on a flat surface, with a pieces of sheet MDF fixed to it. Plane it once and you will be able to work with a precision of +-0,02 mm depth. All cnc routers / milling machines are being delivered with black energy-chains on all axis, which allows a better cabling management. Also, all cnc milling machines are equipped with an emergency stop button. An additional emergency stop you find ...

Universal milling machine with automatic movement ram. Table size: 1600mmx320mm. Longitudinal travel: 1200mm. Cross travel: 300mm. Vertical travel: 600mm. ISO50. Hure head. Equipped with DRO Fagor.

MADE directly from the manufacturer with PREMIUM quality stock items Description: -Conveyor belt / conveyor belt made of rubber for many applications in industry, agriculture and construction industry - new, coated on both sides, open, 2-ply reinforced bottom cover made of PVC, with mounted metal connectors made of stainless steel to the endless connect -Dimensions: 9.152 mm x width 600 mm x thickness length approx. 6.5 mm, surface with tunnels. -With 15 piece rubber studs, 50 mm high, 600 mm long, distance approx. 610 mm,. On request we can cut the belt conveyors / conveyor belts to your individual measurements. (All lengths and widths possible) Additional versions, with pimples, Stollen or structured surfaces available. Statable VAT! Not is your desired size? No problem! We customize for you! More conveyor belts, drive belt and flat belt in all other sizes available immediately ...

AUTOMATIC COPY SHAPER machine type BALESTRINI CP 4 second hand machine Technical Details : machine composed by 4 units : 2+2 shaper units max. working useful length mm.2500 max. working width mm. 500 max. working heigth mm. 180 speed rotation shaper units 8500 rpm speed rotation sanding units 3500 rpm hydraulic pump motor power Hp 5,5 net weigth kgs. 3300 Volt. 380/50

Equipment / Product data of the CNC-Fraesen Type High-Z/TRex series / Type 1224 Drive: 3 buerstenlose brand stepper motors with 4.5 amperes. Pushing through long and up to 120mm high materials possible, as no belt drive is in the way at the end of the X axis! linear guides on all axes of HIWIN / THK ! Multiple ball-bearing ball thread spindles on all axes, brand edging! speed speed max. 12,000 mm/min Working speed max. approx. 8,000 mm/min Technical platform X/Y: 0.005mm (1/10 step); Z: 0.0025mm reverse clearance maximum approx. +/- 10 microns (0.010 mm) Point repeatability: approx. 0.01 mm clamping area 2800 x 1340 mm travel distances: X=2400mm; Y=1200mm; Z= 130 mm contact sensors / reference switches / limit switches on all axes Double secured emergency trigger energy chains for clean cable flush Total mass with motors : LxWxH approx. 3070 x 1800 x 1420 mm Fraes ...

Specifications / Technical Data S-400 Fraes machine / engraving machine With the High-Z CNC-Fraes.- and engraving machine you acquire an all-round talent in TUeV-certified quality (EMC). Whether you want to clamp complex parts on a groove table or, or put factory tins in a high vice (the machine is on a frame construction, is driven in X via 2 motors and thus allows to be placed completely over a part to be machined). or simply want to do engraving or drilling then they simply work on a flat base, on which they then attach e.g. an MDF plate, which they once overfrave plan and are then able to work up to approx. +-0.02mm exactly in depth. All machines are supplied with coloured energy chains on all axes due to improved cable guidance. Furthermore, all machines are protected with a double-secured emergency exit button. Another is located directly at the controller. Basic equip ...

Specifications / Technical Data S-1000 CNC-Fraese and Engraving Machine The almost largest CNC machine of the high-Z series in TUeV-certified quality (EMC). With an external dimension of approx. 1350 x 800mm still handy enough and extremely powerful. With the high-z CNC unit, they acquire an all-round talent. Whether you want to clamp complex parts on a groove table or, or clamp the factory into a high vice (the machine stands on a frame construction, is driven in X via 2 motors and thus allows to be placed completely over a part to be processed). Or just do engraving or drilling then they simply work on a flat surface, on which they then attach, for example, an MDF plate, which they once plan overfraes and are then able to work exactly in depth up to approx. +/- 0.02mm. All CNC portal fraes machines are supplied with coloured energy chains on all axes due to the improved cable ...

Specifications / Technical Data S-1000 CNC-Router and CNC-Engraver This is the biggest machine of our High-Z cnc-router series. With external dimensions of approx. 1350x800mm it is still very handy. With the High-Z 3D-cnc-routers you purchase an allround talent in TÜV-certified quality. If you want to clampand fix complex workpieces on the worksurface, or, or, or clamp work-pieces in a high bench vise (the cnc-machine sits on a frame-construction, is driven by 2 motors and therefore allows to be positioned above a piece to be processed). Or if you simply want to do engraving- or drillingjobs.you can work on a flat surface, with a pieces of sheet MDF fixed to it. Plane it once and you will be able to work with a precision of +-0,02 mm depth. All cnc-machines are being delivered with black energy-chains on all axis, which allows a better cabling management. Also, all cnc-milli ...

STAMA Mod. MC 2 1997-325S pallet (Pendeltisch Peiseler ATK 520) Aufspannflaeche Pallet: 2 x 550 mm x 330 mm Max Werkstueckgewicht: 2x180kgs X = Y = Z 500 300 = 350 mm Min/Max Distance Spindelnase-Tisch: 200-550 mm rapid traverse X, Y, Z = 40/40/45 36 40 36 Werkzeuge ISO-9000 RPM Spindle IKZ CNC SIEMENS 840 c # 2 LEHMANN doppel 4. Achsen IKZ Unter Strom in unserem Lager It machined \\input shafts\\ (car power steering component) Special price for quick removal

Specifications / Technical Data S-400 CNC Router / CNC milling machine / Engraver With the High-Z CNC-router / engraver you purchase an allround talent (optional WIN PCNC Economy, USB or professional). If you want to clampand fix complex workpieces on the worksurface, or, or, or clamp work-pieces in a high bench vise (the cnc milling machine sits on a frame-construction, is driven by 2 motors and therefore allows to be positioned above a piece to be processed). Or if you simply want to do engraving- or drillingjobs.you can work on a flat surface, with a pieces of sheet MDF fixed to it. Plane it once and you will be able to work with a precision of +-0,02 mm depth. All cnc-machines are being delivered with black energy-chains on all axis, which allows a better cabling management. Also, all cnc milling / engraving machines are equipped with an emergency stop button. An additional  ...

Specifications / Technical data S-400/T CNC-Portalfraesmaschine / Engraving machine Granite, marble, slate, soapstone engraving, photoengraving, fraesen... With the T-variant of the High-Z CNC-Fraesmachine you acquire old-guarded technology with the certain i-Tuepfelchen in TUeV-Qualitat. The High-Z/T is designed for even more accuracy (repeatability about 0.01mm ) and especially for higher travel speeds. Through the ball-circulation spindles used, the High-Z/T CNC-Fraes machine achieves a fantastic accuracy and an almost unmeasurable reverse play of about 0.01mm. At the same time, high travel speeds of up to approx. 108mm / second ( 6500 mm / minute ) can be achieved. This means engraving and fraes speeds of up to approx. 4500mm/min can be realized and urgent journeys up to approx. 7000mm/min. Here you can see a video about empty journeys with the new High-Z/T. This makes t ...

Specifications / Technical Data S-400/T CNC-Portal-Router / CNC-Engraving machine Grabite marble soapstione slate engraving photo engraving, milling .. With the purchase of the T-variation of High-Z cnc-router you get a proven technology with a certain icing of the cake. High-Z/T cnc-routers was conceived for once more precision (repetition precision approx. 0,02mm) and especially for higher traverse speed. Because of the used ball screws the High-Z/T 3D-cnc-engravers achieves a fantastic precision and an almost unmeasurable back lash of approx. 0,01mm. At the same time there are high traverse speeds up to approx. 108mm / sec. ( 6.500 mm/min ) possible. With this cnc-machines you're able to carry out an engrave and mill speeds of approx. 4500 mm/min. and express travels up to 6500mm/min. Here's a video on a unloaded drive with the new High-Z / T. This 3D-milling-machi ...

Table size: 460 x 800 mm stroke x: 485 mm traverse path y: 385 mm traverse path z: 380 mm Quill stroke: by hand approximately 70 mm spindle speeds: 50-3150 rpm stufenl feeds. adjustable: 2-1000 mm / min rapid traverse rate: 2 m / min. Port: 3.7/4,4 kW space: 2100 x 1650 x 1730 mm weight: 1850 kg

Important and distinguishing design features of the RaptorX SL steel base gantry machine RaptorX-SL1200/S15 The application range of the RaptorX- SL CNC milling machine is extremely wide due to the adjustable work surface height (variable bridge clearance: 150mm, 300mm or 400mm) plus the travel range of the Z axis of 300mm (at no extra cost). The Z axis stability is excellent, allowing you to work as accurately on large 3D objects as one can on flat sheet materials. Use the system as a plasma cutting system or a water jet cutting system, appropriate accessories are available. It is possible to work on work-pieces up to a height of 850mm (steel cabinets etc.) or three-dimensional objects up to a height of approx. 400mm (with 400m long milling cutter). This capability is unusual for machines of this size and mold makers usually use a layered construction method to produce large ...

Item condition: New. Machine is delivered pre-assembled and tested! Specifications / Specifications S-720/T CNC-Fraesmaschine and G raviermaschine / Fraese With the T-variant of the High-Z CNC Fraes.- and engraving machine you acquire old-fashioned technology with the certain I-Tpfelchen in TUeV-certified quality (EMC). The High-Z/T CNC-Fraese is designed for even more accuracy (repeatability about 0.01mm ) and especially for higher travel speeds. The high-Z/T CNC-Fraese achieves fantastic accuracy and an almost unmeasurable reverse play of about 0.01mm due to the ball's circulation spindles. At the same time, high travel speeds of up to 108mm/second ( 6500mm/ minute) can be achieved. This allows engraving and feeding speeds of up to approx. 4500mm/min and express ingess esons up to approx. 7000mm/min. Here you can watch a video of empty journeys with the new High-Z/T. This i ...

The range of applications of a RaptorX-SL CNC Fraes machine is extremely large due to the maximum adjustable working area (read-through under bridge variable: 150mm, 300mm or 400mm ) and the travel height of 300mm in the Z-axis (at no extra charge). special large foods up to 17,500 mm ( at one scale ) x 3000 mm x 600 mm are possible ! If you are interested, please ask ! So you are able to process plate materials with the greatest stability of the Z-axis just as precisely as 200mm high 3D-parts. Use the system as a plasma cutting system or water jet cutting system, corresponding extensions are available. In the middle range of the machine (between the foottubes ) you can even process parts up to a height of 850mm (beam shrare etc. ) or 3D body up to about 400mm height ( at 400mm long Fraeser ), wherein this is rather unpromising due to the mostly applied layer structure  ...

The application range of the RaptorX- SL CNC milling machine is extremely wide due to the adjustable work surface height (variable bridge clearance: 150mm, 300mm or 400mm) plus the travel range of the Z axis of 300mm (at no extra cost). 3D engraving, bas reliefs in marble etc. Create and mill, what ever you want . The Z axis stability is excellent, allowing you to work as accurately on large 3D objects as one can on flat sheet materials. Use the system as a plasma cutting system or a water jet cutting system, appropriate accessories are available. It is possible to work on work-pieces up to a height of 850mm (steel cabinets etc.) or three-dimensional objects up to a height of approx. 400mm (with 400m long milling cutter). This capability is unusual for machines of this size and mold makers usually use a layered construction method to produce large 3D objects. Considering our  ...

Drilling capacity in steel: 32 mm Drilling capacity in cast: 40 mm Cutter head milling max.: 80 mm Projection: 220 mm Spindle speed: (12) 75-3200 RPM Spindle retainer: MK 4 Quill stroke: 125 mm Table size: 800 x 240 mm Travel (x / y): 555 / 225 mm Milling head swiveling: - 90 ° to + 90 ° Distance from spindle / table: 60-485 mm Head height: 425 mm T - slot size: 14 mm S1 motor power output 100%: 1,1 / 1,5 kW (400 V) Motor power S6 40%: 1.5 / 2.2 kW (400 V) Machine dimensions (W x D x H) : 1140 x 770 x 1500 mm Approximate weight: 287 kg without stand Features: Quick and easy change of speed using the gear selector switch Versatile application possibilities such as drilling, milling, thread cutting, … High running smoothness by polished, running in an oil bath gear gears Right - and the link run device for thread cutting Quill adjustment by means of ...

Vertical machining center Cincinnati Millacron Traverse path x 1270 mm Y: travel 660 mm Z: travel 660 mm CNC control: Acramatic 850SX Table size: 1,370 x 660 mm Table load: 910 kg Rapid traverse x/Y/Z: 15,000 mm / min. Spindle speeds: 60-8,000 rpm. Spindle recording: ISO 40 Distance from spindle - table min/max: 150/880 mm Tool changers: 21 items Equipped with:-cooling device -Hand Council operation -Complete instructions Country of origin: England Spindle motor: 9 kW Machine weight: 8.000 kg Machine WxDxH: 3,600 x 2.900 x 3.000 mm

ROUTER type COSMEC 1000 second hand machine volt. 380 / 50 max. working mm. 1000

Edge Abkappen thrower HolzHer Built in 1978 Weight approx. 220 kg L x W x H: 80 x 60 x 150 cm The machine is in good condition, ready to use. Subject to changes, errors, and intermediate sale! Service/spare parts by MATEC CH-4900 Langenthal/DE-79618 Rheinfelden MATEC system + technik GmbH Mechanical engineering Eisenbahnstrasse 25 CH-4900 Langenthal/Switzerland Tel. 0041 62 966 18 32 Fax 0041 62 966 21 12

CNC portal fraese and 3D engraving machine T-Rex 0712: equipment / product data of cnc-Fraesen Type High-Z/TRex series: Drive: 3 busiest brand stepper motors with 4.5 amperes. Pushing through long and up to 120mm high materials possible, as no belt drive is in the way at the end of the X axis! linear guides on all Y axes from HIWIN / THK ! Multiple ball-bearing ball thread spindles on all axes, brand make! Rapid speed max. approx. 17,000 mm/min working speed max. approx. 12,000 mm/min Technical platform X/Y: 0.005mm (1/10 step); Z: 0.0025mm reverse play maximum approx. +/- 10microns (0.010 mm) Point repeatability: approx. 0.01 mm clamping area of the groove plate / T-slot table: 1650 x 880 mm travel distances: X=1200mm; Y=700mm; Z= 130 mm contact contact sensors / reference switches / limit switches on all axes Double secured emergency release energy chains for cle ...

Standard ALB ear performance: 30 mm Thread cutting performance: M 20 (option) Thread: M 12 Spindle: MK 3 or SK 30 (option) Quill stroke: 100 mm Longitudinal / cross travel: 350/160 mm Distance spindle/cross table: 80 to 450 mm Table area: 600 x 240 mm Column diameter: 110 mm Total height: Max 1,920 mm Weight: 340 kg Motor pole shift bar: 0.8/1.5 kW Spindle speeds, continuous, selectable: 10 spindle speeds: 80-1,400 rpm 10 spindle speeds: 120-2,160 rpm 10 spindle speeds: 160-2,800 RPM Facilities: A versatile, accurate and handy drilling milling machine. The quiet-running drive and a perfect clamping of Quill guarantee good surfaces when milling. The headstock can be swung out. The stage is precise and precisely adjustable. Pitch 0.05 mm. clamping device for both axes. Full motor protection. Machine incl. Cabinet.

Hitachi chain moulder 110 V This article is in good working condition. The chain size is 30 mm and is out of focus. Chain mortiser for fast, clean, and precise nicks or cuts through holes in wood. Ideal for fences, sheds, huts, restoration and much more.

Equipment / Product data of the CNC-Fraesen Type High-Z/TRex series / Type 1215 Drive: 3 busiest brand stepper motors with 4.5 amperes. Pushing through long and up to 120mm high materials possible, as no belt drive is in the way at the end of the X axis! linear guides on all axes of HIWIN / THK ! Multiple ball-bearing ball thread spindles on all axes, brand edging! speed speed max. 12,000 mm/min Working speed max. approx. 8,000 mm/min Technical platform X/Y: 0.005mm (1/10 step); Z: 0.0025mm reverse play maximum approx. +/- 10 microns (0.010 mm) Point repeatability: approx. 0.01 mm clamping area 1860 x 1340 mm travel distances: X=1500mm; Y=1200mm; Z= 130 mm contact contactno-point sensors / reference switches / limit switches on all axes Double-secured emergency trigger energy chains for clean cable Total mass with motors : LxWxH approx. 2180 x 1800 x 1420 mm Fra- Sc ...

3D CNC Router T-Rex 1215 / Technical Data : Equipment / product data CNC-milling machine type High-Z/TRex series: Drive: 3 brushless brand stepping engines with 4,5 ampere. Possibility of sliding through long and up to 120mm high materials, no belt drive at the ende of the X axis! Linear guide on all exis by HIWIN / THK ! Multiple ball-bearing ball-screw spindle on all axes, proprietary brand! Rapid traverse max. ca. 12.000 mm/min Operating speed max. ca. 8.000 mm/min Technical definition X/Y : 0,005mm (1/10 Schritt); Z: 0,0025mm Backlash maximal ca. +/- 10µm (0,010 mm) Repeat accuracy: ca. 0,01 mm Clampin surface of grooven panel / T-slot table 1860 x 1340 mm Travels: X=1500mm; Y=1200mm; Z= 130 mm Non-contact reed sensors / reference switches / limit switches on all axes Double secured emergency-stop button Energy chains for a clean cable routing Total dimensions wi ...

Control: Heidenhain TNC 360 (1992) Table size: 1000 x 1000 mm Table size with front extension: 1345 x 1000 mm Table load max.: 2000 kg Distance spindle centre to column min/max.: 270 ~ 1270 mm Distance spindle nose to table min/max.: 0 - 1100 mm Distance between the upright columns: 1855 mm Table longitudinal travel : 1400 mm Boring ram carriage cross travel: 900 mm Crossrail vertical travel: 850 mm Boring spindle travel: 370 mm Spindle motor rating: 6 KW Spindle speed range: 30 - 1500 rpm Boring spindle diameter: 82 mm Spindle taper: MK 5 Borer diameter: 2 - 70 mm Boring tool diameter: 17 - 450 mm Boring diameter in solid ST 60: 45 mm Boring diameter in solid Cast iron: 70 mm Equipped with: Tooling; Accessories Machine overhauled and retrofitted in 1992 !; Very good

5-axis controlled milling centre Control: E 160 CNC Work piece clamping: 2 axis cradle type with tool-taper clamping Indexing of work piece cradle (A/B) full rotary and tilting controlled Traverses: X 1050 mm Y 420 mm Z 420 mm Spindle motor rating: 9 kW Spindle speeds to: 4000 rpm Gear steps 2 Torque: 450 Nm Pick up magazine tool positions: 15 with 2 places for extra large tools Tool taper: ISO 40 Equipped with: 2 Axis clamping system for parts, taper ISO 50; Vertical milling head ISO 40; Full guarding; Pick up magazine for 15 tools; VERY LITTLE USAGE AND ONLY WITH CUTTING OILS; Excellent

Makita chain moulder 7101, 110V This article is in good and working condition. Chain mortiser for fast, clean, and precise nicks or cuts through holes in wood. Ideal for timber-frame houses, sheds, huts, restoration and much more.

Equiptment / product data CNC-milling machine type High-Z/TRex series / 1224 Drive: 3 brushless brand stepping engines with 4,5 ampere. Possibility of sliding through long and up to 120mm high materials, no belt drive at the ende of the X axis! Linear guide on all axis by HIWIN / THK ! Multiple ball-bearing ball-screw spindle on all axes, proprietary brand! Rapid traverse max. ca. 12.000 mm/min Operating speed max. ca. 8.000 mm/min Technical definition X/Y : 0,005mm (1/10 Schritt); Z: 0,0025mm Backlash maximal ca. +/- 10µm (0,010 mm) Repeat accuracy: ca. 0,01 mm Clampin surface of grooven panel / T-slot table 2800 x 1340 mm Travels: X=2400mm; Y=1200mm; Z= 130 mm Non-contact reed sensors / reference switches / limit switches on all axes Double secured emergency-stop button Energy chains for a clean cable routing Total dimensions with engines : LxBxH ca. 3070 x 1800 x  ...

Qty.1 Second-hand milling (scalping) line Mfc.: Torrington Type: 30" Slap Miller Speed: 500 rpm – 18 fpm Capacity: 1,9 m/dk

Universal milling machine. Table size: 1200mmx320mm. Longitudinal travel: 950mm. Cross travel: 300mm. Vertical travel: 500mm. ISO40. Hure head. DRO Fagor.
