bed milling used for sale

AUERBACH AX 5 B CNC bed milling machine was built in 2009 in Germany by Auerbach Maschinenfabrik GmbH. It is an extremely efficient machine designed for even the most demanding production challenges. The AUERBACH AX5 B enables the machining of large, heavy workpieces that are used, e.g. in the aerospace and automotive industry. The machining process is performed fully automatically on the rotary table by means of a 5-axis swivel workhead. This solution enables comprehensive machining of workpieces in a single work cycle, without the need for repositioning them. The workhead is equipped with an electro-spindle rotating at a maximum speed of 12000 rpm. It provides the excellent dynamics required for both roughing and finishing operations. The cutting tools, on the other hand, are continuously cooled to increase their overall service life. The AUERBACH AX 5B CNC machining center is offered  ...

This 5-axis SHW UFZ 6L Bed Type Milling Machine was manufactured in 2008. It features an impressive X-axis travel of 6000 mm, Y-axis travel of 2100 mm, and Z-axis travel of 1600 mm. The machine includes an automatic tool changer with a capacity for 150 tools and a robust clamping plate surface of 3600 x 3750 mm. If you are looking to get high-quality milling capabilities, consider the SHW UFZ 6L machine we have for sale. Contact us for further details.

A bed milling machine is offered. Spindle drive: 25kW, table clamping surface X/Y: 1250mm/500mm, travel paths X/Y/Z: 1000mm/500mm/600mm, tool holder: ISO 40, feed rate: 0mm - 3000mm/min. Equipped with CNC control, coolant system, electronic handwheel, machine weight: approx. 4200kg, machine dimensions X/Y/Z: approx. 2800mm/2400mm/2500mm. Inspection possible by arrangement.

CNC milling machine, milling and engraving machine, MECANUMERIC, MECA EASY 1510 – used - : Price ex location: 23.500.-€ (net)! Manufacturer: MECANUMERIC Type: MECA EASY 1510 Year of manufacture: 2015, former DEMONSTRATION MACHINE Three-axis milling machine in flatbed gantry design. Working paths X, Y, Z axes: 1,050 / 1,550 / 200 mm. Table frame wag Bortal: Design as a solid, stress-free, completely welded slahl construction, powder-coated. Heavy table base to accommodate the VAC-CAISSON vacuum table, designed as a cassette, air passage holes in a grid of 10 mm. Feed speed: 300 mm/sec (18 m/min) in rapid traverse and feed mode! Guidance on rails, sliding shoes with upstream ball circulation. Transmission : Precision Ball Screws Ball screw on all axes Maintenance-free, brushless servo drive motors (750 W on X and Y, 300 W on Z) Repeatability: +/- 0.025 mm Mechanic ...

This 4-axis FPT DINO CNC Gantry Milling Machine was manufactured in 2002. It features an impressive X-axis travel of 2,800 mm, Y-axis travel of 1,600 mm, and Z-axis travel of 800 mm. The machine is equipped with an electrospindle capable of speeds up to 18,000 RPM and a robust gantry type cast-iron construction. If you are looking to get high-quality milling capabilities, consider the FPT DINO machine we have for sale. Contact us for further details.

CNC Bed Milling Machine KIHEUNG U1050 Control: Heidenhain iTNC 530 Year of Make: 2014 Internal machine no. 61 X-axis: 2,500 mm Y-axis: 1,050 mm Z-axis: 1,600 mm Tool holder: SK50 DIN ISO Tool magazine: 24-fold Facilities - Chip conveyors - Magnetic clamping plate - Handwheel HR410

This 5-axis SACHMAN TS10 bed type milling machine is manufactured in 2026 and brand new. It features an impressive X-axis travel of 2,500 mm, Y-axis travel of 1,210 mm, and Z-axis travel of 1,200 mm. The machine includes a robust table size of 2,700 x 800 mm and a maximum table load capacity of 3,000 kg. If you are looking to get high-quality milling capabilities, consider the SACHMAN TS10 machine we have for sale. Contact us for further details.

Soraluce SLP-6000Year of manuf. : 2017 Control : Heidenhain TNC 640 Speed : 5000 rpmMovement X/Y/Z : 4500/1800/1300 mm____________Description:In General:Year of manufacture:2017Control system:Heidenhain TNC 640Travel range X/Y/Z:4,500/1,800/1,300 mmSpindle speed:5,000 rpmTool holder:SK 50Milling head (spindle):Technology:Diagonal head with gear spindleIndex:0.001°Speed:5,000 rpmTool holder:SK 50Max. power:43 kWMax. torque:1,045 NmCoolant supply:Coolant + blast airWorking table:Clamping surface:6,000 x 1,100 mmT-slots:6 x 22H12, spacing 140 mmTool magazin:Technology:Chain magazineNumber of stations:40Tool changer:Double gripper (horizontal/vertical)Max. tool diameter:125 (250) mmMax. tool length:400 mmEquipment:Position measurement systems:Direct scalesChip removal:Chip conveyorCoolant supply:Internal coolant system with filter, 20 barWorkpiece measurement:Funk M&H probeSet-up oper ...

Key data: 6500 mm, 2000 mm, 1200 mm

Testa automatica universale: indicizzazione automatica ogni 2,5° × 2,5° per la massima versatilità nelle lavorazioni multiangolo Magazzino utensili: automatico per rapidi cambi utensile e maggiore produttività Grazie alla sua ampia area di lavoro e alla testa universale automatica, la SORALUCE SP8000 è ideale per operazioni di fresatura, alesatura e foratura su componenti di grandi dimensioni destinati ai settori della meccanica generale, energia, stampi e costruzioni industriali. VISIBILE MONTATA FINO A FINE SETTEMBRE 2026!

Bed milling machine Anayak VHPlus 2000 Travel: X: 2,000mm Y: 1,200mm Z: 1,050mm Diagonal milling head 45° Spindle: SK50 Power: Kw 30/35 Spindle speed: 4,000 rpm Coolant system Tool changer: 30 places, chain magazine Control: Heidenhain TNC426 Handwheel Export documentation and export possible for an extra charge. Viewing possible under power. We will be happy to send you further details or arrange an on-site exposure.

Key data: 3050 mm, 800 mm, 850 mm

From location: CNC Bed Milling Machine Manufacturer: TOS Kurim Type: FSS 80 Year of Make: 1991 Control: Heidenhain TNC 407 Two-spindle H-V head that rotates automatically programmatically (horizontal/vertical) • Table clamping surface 800x3000 mm • X-axis working stroke (longitudinal) 3050 mm • Transverse stroke 800 mm • Vertical working stroke 850 (790) mm • Spindle taper ISO 50 • Spindle turning range 9 - 2000 rpm -1 • Working position. continuous 1 - 3000 mm / min -1 • Fast feed .. 8000 mm/min -1 • 22 kW spindle motor • Machine dimensions 7660x3470x2740 • Total machine weight 14400 kg

x-travel: 1900 mm y-travel: 800 mm z-travel: 800 mm Control: control: 426 Heidenhain : dismantled: total power requirement: kW weight of the machine ca.: 12 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1300 mm y-travel: 700 mm z-travel: 700 mm Control: Heidenhain table surface area: 1700x630 mm Table load: 3000 kg turning speeds: 80-3150 U/min spindle taper ISO: 50 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software s ...

x-travel: 3000 mm y-travel: 1350 mm z-travel: 1400 mm spindle taper ISO: 50 turning speeds: 22-1400 U/min Rotary table: 800x600 mm Table dimensions: 2500x1200 mm Feed: 5-3000 mm/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m ball screw The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS ...

x-travel: 3300 mm y-travel: 2200 mm z-travel: 1300 mm w-axis: 350 mm workpiece height: 1700 mm milling spindle diameter: 140 mm diameter of quill: 230 mm milling head speed: 40-2000 U/min transmission ratio: 4 table surface area: 4260x2000 mm T-slot - distance: 175 mm T-slot - width: 28 mm number of T-slots: 11 workpiece weight: 300000 kg milling spindle motor: 30 kW Feed: 5-3000 mm/min control: Fidia total power requirement: kW weight of the machine ca.: 80 t dimensions of the machine ca.: m Machine has been overhauled The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machi ...

x-travel: 4000 mm y-travel: 2000 mm z-travel: 1300 mm Control: Heindenhain type: TNC530i : table surface area: 5200x2000 mm Table load: 30000 kg pinole diameter: 230 mm number of T-slots: 11 T-slot - width: 28 mm T-slot - distance: 175 mm spindle taper ISO: 50 turning speeds: 40-2000 U/min spindle motor: 30 kW transmission ratio: 4 total power requirement: kW weight of the machine ca.: 70 t dimensions of the machine ca.: 10x5,5x5,8 m No. 05592 Maschine wurde überholt machine is retofit The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your bu ...

x-travel: 2000 mm y-travel: 1000 mm z-travel: 1000 mm Control: Heidenhain type: TNC 430 : spindle turning speed range: 15-1450 U/min Table area: 2300x1200 mm Spindle: 200 mm spindle stroke: 200 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Maschine wurde überholt machine is retofit The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team ...

x-travel: 3000 mm y-travel: 800 mm z-travel: 1000 mm Control: Heidenhain type: TNC 155 table surface area: 3000x800 mm turning speeds: 2000 U/min spindle taper ISO: 50 total power requirement: kW weight of the machine ca.: 16 t dimensions of the machine ca.: 7,8x3,85x3,1 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the so ...

x-travel: 2000 mm y-travel: 900 mm z-travel: 800 mm Control: Heidenhain : spindle turning speed range: 20-1000 U/min Table area: 2000x900 mm spindle stroke: 200 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Maschine wurde überholt machine is retofit The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was creat ...

x-travel: 2700 mm y-travel: 1250 mm z-travel: 1150 mm Control: Heidenhain type: TNC 426 : spindle turning speed range: 56-3150 U/min Table area: 3800x1000 mm spindle taper ISO: 50 total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Maschine wurde überholt machine is retofit The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for t ...

x-travel: 4000 mm y-travel: 1350 mm z-travel: (Vert.) 1600 mm Control: Heidenhain iTNC 530 table surface area: 4200 x 1150 mm table load: 13 t tool taper: ISO 50 spindle turning speed - stepless: 0 - 3000 U/min transmission ratio: 2 spindle motor: 28/38 kW feed range: 5000 mm/min rapid traverse: (X/Y) 12 m/min rapid traverse: (Z) 10 m/min weight of the machine ca.: 37 t dimensions of the machine ca.: 12,9 x 6,53 x 3,79 m In January and October 2025 the milling head was overhauled (new bevel gears and bearings). Total costs 51.000,- Euro. Working hours (dated 31. July 2025): Machine on: 38.483 h Auto cycle: 12.798 h Spindle hours: 11.645 h A current geometry measurement report is available. CNC-control HEIDENHAIN iTNC 530 Electronic handwheel 50-position tool changer Controlled universal milling head, indexable 2.5 / 2.5 deg. Coolant device Cooling through the spindle 2 chip convey ...

x-travel: 2500 mm y-travel: 1300 mm z-travel: 900 mm Control: Heidenhain iTNC 530 table surface area: 2500 x 800 mm table load: 5,0 t tool taper: SK 50 DIN69871 spindle turning speed range: 36 - 4000 U/min feed range: 2 - 12000 mm/min main drive: 25 kW total power requirement: 50 kW weight of the machine ca.: 17 t dimensions of the machine ca.: 8,4 x 4,5x 3,8(3,9) m The main engine was overhauled in September 2022 for € 6,000. The machine was partially overhauled in 2007 Scope of overhaul: Feed motors were overhauled New Heidenhain iTNC 530 control system with new main spindle drive (Siemens) Retention of the control cabinet and feed drives Geometric overhaul of the machine Overhaul of the tool changer Defective guideway covers were repaired or replaced The milling head was completely overhauled approx. 3 years ago. Equipment: CNC control Heidenhain iTNC 530 Horizontal/vertical swivell ...

x-travel: 1600 mm y-travel: 800 mm z-travel: 800 mm Control: CNC 432 total power requirement: 22 kW weight of the machine ca.: 17 t dimensions of the machine ca.: 5 x 3,70 x 3 m Nr. 2754 Universal bed milling machine MAHO MH 1600 S Spindle SK-50, Speed range up to 4000 min-1 Max. workpiece weight 3000kg 35,000 switch-on hours, 10,0 0spindle hours, Dimensions 5 x 3.70 x 3 m, Weight 16 tonnes. Automatic swivelling milling head, Fixed table 1800 x 980 mm, 36-fold universal tool changer, Internal coolant supply with paper belt filter, chip conveyor, manual control bar. Working area: 1600 x 800 x 800 Drive: 22 kW Control: Philips CNC 432 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 2000 mm y-travel: 920 mm z-travel: 900 mm table surface area: 2200 x 750 mm table load: 3 t number of T-slots: 6 T - slots - width: 18 mm T - slots distance: 120 mm spindle taper: ISO 50 DIN 69871-B spindle speed max.: 3000 U/min transmission ratio: 1 speeds infinitely variable range 1: 60 - 3000 U/min weight of the machine ca.: 21,6 t feeds longditudinal/cross/vertical: 0 - 5000 mm/min rapid traverse: 15000 mm/min total power requirement: 38 kw weight of the machine ca.: 11 t Pull studs DIN69872-B | IKZ Hours: Control on: 43036 h Machine on: 41311 h Program run 13894 h The machine is already dismantled The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

SACHMAN RP 3 ist eine CNC-Bettfräsmaschine (CNC Bettfräsmaschine) ausgelegt auf Präzision, hohe Genauigkeit und Zuverlässigkeit. Arbeitsmöglichkeiten: Tisch 2000×730 mm, max. Werkstückgewicht 3000 kg, Verfahrwege X 1800 mm, Y 815 mm, Z 802 mm, Spindel–Tisch Abstand 805 mm. Hauptdaten: Spindelaufnahme 50 ISO, Drehzahlen 0–2250 t/min, Vorschübe X/Y/Z 1–5000 mm/min, Eilgang alle Achsen 8 m/min, Frässpindelmotor 15 kW, installierte Leistung 27 kW, Maschinengewicht ca. 8000 kg, Abmessungen L3300×B4700×H2715 mm. Zubehör: Satz Werkzeughalter und Lampe. Erreicht enge Toleranzen; geeignet für Automotive, Uhrmacherei, Werkzeugmaschinenbau, Luftfahrt und Medizintechnik. Technische Daten ohne Gewähr

REIDEN BF 5 L ist eine CNC Bettfräsmaschine, ausgelegt für Präzision, hohe Genauigkeit und Zuverlässigkeit. Arbeitsmöglichkeiten: Tisch 4000×1000 mm, max. Werkstückgewicht 6000 kg; Längsweg X 4000 mm, Querweg Y 1000 mm, Vertikalweg Z 1500 mm; universeller Fräskopf mit 90° Schwenkbereich. Wichtige technische Daten: Spindelaufnahme ISO 50, Spindeldrehzahlen bis 3900 t/min. Die Konstruktion und der universelle Kopf ermöglichen enge Toleranzen; typische Einsatzbereiche: Automotive, Luft- und Raumfahrt und Maschinenbau. Technische Daten ohne Gewähr

MTE K-15 Bed Milling Machine Technical Specifications: Clamping Surface: 1,700 × 750 mm Spindle Speed: 40–3,000 rpm Tool Clamping Force: 1,500 daN Milling Feed Rate: 0–12,000 mm/min Positioning Feed Rate: 15 m/min Positioning Accuracy: < 0.012 mm Repeatability: < 0.007 mm Machine Weight with ATC: approx. 8,500 kg

Lagun X: 3000 - Y: 1000 - Z: 1200 mm CNC Longitudinal travel X-axe: 3000 mm Cross travel Y-axe: 1000 mm Travel Z-axe: 1200 mm Dimensions clamping space- table: 3100 x 800 mm Power on spindle: 22 kW Type of millinghead: BT-50 Max speedrange: 50 > 3000 rpm (840 Nm) Control: Heidenhain iTNC 530 Power needed (KVA): 35 kW Length : 8744 mm Depth: 3765 mm Height: 3352 mm Weight: 14 ton

x-travel: 3500 mm y-travel: 1000 mm z-travel: 900 mm Control: Heidenhain iTNC 530 total power requirement: kW weight of the machine ca.: 21 t dimensions of the machine ca.: 10770 x 4100 x 3150 m Control system: Heidenhain iTNC 530 Operating hours: 54631 h X-axis 3500 mm Y-axis 1000 mm Z-axis 900 mm Drive power 30 kW Speed range 20–3800 rpm Rapid traverse 15 m/min Feed rate 4 m/min Clamping surface 2x 1600 x 960 mm Max. table load 2 x 4000 kg Machine weight (approx.) 21 t Machine dimensions (WxDxH) 10770 x 4100 x 3150 mm Technical data / Accessories Universal bed-type milling and boring machine Milling head position: Vertical, horizontal (top, center, left, right) Heidenhain TS 120 3D touch probe Kekeisen TW 32 drum-type tool changer Knoll hinged-belt chip conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

met spanentransportband Longitudinal travel X-axe: 1050 mm Crosstravel Y -axe: 560 mm Travel Z-axe (Height): 560 mm Dimensions clamping space - table: 1400 x 550 mm Power on spindle: 9 kW Max speedrange: 10 > 6000 rpm Control: Fanuc O-M ACCESSORIES & TOOLING: toolchanger, 32 positions

Table dimensions: 5000 x 2000 mm Auction-ID: A7-32339-6

Table dimensions: 3000 x 1280 mm Including attached clamping table 2000x1200x500 Auction-ID: A7-32339-7

Including attached clamping table 3000x2000x300 Auction-ID: A7-32339-9

Including attached clamping table 3000x2000x300 Auction-ID: A7-32339-8

Key data: 1600 mm, 800 mm

CNC bed milling machine with Heidenhain control 415, good condition, hydraulic tool clamping, coolant device, central lubrication, lighting,.. Travel X1600/y800/z650/ Spindle holder SK 50 Spin elder speed 60-1800rpm Working feed rate 10-3000mm/min Rapid traverse 10m/min Table clamping surface 1800x610mm Machine weight 9500kg Table load 3000kg

Key data: 1300 mm, 630 mm, 630 mm

Bed milling machine Manufacturer: Correa Type: A10 Year of Make: 1988 Control: HEIDENHAIN TNC 355 Travel X/Y/Z: 1,300 x 630 x 630 mm Clamping area: 1,700 x 630 mm Workpiece weight: 3,000 kg Hours: 25,845 Power: 19 kW Spindle Type: ISO 40 Dimensions L/W/H: 3,870 × 2,630 × 2,200 mm Machine weight: 6,800 kg

Key data: 1800 mm, 800 mm, 800 mm

Bed milling machine Manufacturer: Correa Type: A16 Year of Make: 1988 Control: HEIDENHAIN TNC415 Travel distances X/Y/Z: 1,800 x 800 x 800 mm Clamping area: 2,000 x 630 mm Workpiece weight: 3,000kg Hours: 12,103 Power: 19 kW Spindle Type: ISO 50 Dimensions L/W/H:4,886 × 2,720 × 2,500 mm Machine weight: 7,500 kg

Key data: 2800 mm, 1000 mm, 1000 mm

CNC Bed Milling Machine Manufacturer: Zayer Year of manufacture 1989 Control Heidenhain TNC155 Monitor has already been replaced Table size 800 x 3000mm Travel X/Y/Z 2800/1000/1000 24 Way Tool Changer Tool holder SK50 Head swivels over program The machine is in a 100% functional condition. Machine is sold from the Saarland Illingen site. Loading can be done by us for an extra charge

x-travel: 2000 mm y-travel: 1250 mm z-travel: 1108 mm turning speeds: 60 - 4000 U/min spindle motor: 38 / 24 kW tool taper: SK 50 tool change unit: 40 Pos. table surface area: 1600 x 1250 mm table load: 7 t c-axis: +/- 120 ° B-axis (table): 360.000 pos control: Heidenhain ITNC 530 total power requirement: - kVA weight of the machine ca.: 16,5 t dimensions of the machine ca.: 5,5 x 4 x 2,9 m 5-axis machining center with - CNC control Heidenhain iTNC 530 - NC rotary table with B-axis - Automatic swivel milling head (C-Axis) - 40-fold tool changer (SK 50) - Electronic handwheel - 2 Chip conveyor - Coolant device 30 l/min - Coolant through Center The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

MTE” FIXED BED MILLING MACHINE Mod. BF-1700 FEATURES: CONTROL UNIT: • Model: TNC 410 • Brand: HEIDENHAIN MAIN TRANSMISSION: • Spindle speed range: 40 – 2500 rpm • Max spindle speed: 3000 rpm • Taper: SK 50 TRAVEL: • X-axis travel: 1500 mm • Y-axis travel: 1000 mm • Z-axis travel: 1000 mm WORK TABLE: • Table length: 1700 mm • Table width: 1000 mm • Max table load: 5500 kg

MTE” FIXED BED MILLING MACHINE Mod. BF-2700 CARACTERISTICS: • MACHINE LENGTH: 7000 MM • MACHINE WIDTH: 3000 MM • MACHINE HEIGHT: 3000 MM CONTROL UNIT: • MODEL: TNC 410 • BRAND: HEIDENHAIN MAIN DRIVE: • SPINDLE SPEED RANGE: 3000 1/MIN • SPINDLE TAPER: SK 50 TRAVELS : • X-AXIS TRAVEL: 2500 MM • Y-AXIS TRAVEL: 1000 MM • Z-AXIS TRAVEL: 1000 MM WORKING TABLE: • EXTERNAL LENGTH: 2700 MM • EXTERNAL WIDTH: 1000 MM • POWER CONSUMPTION: 40 KW

x-travel: 1250 mm y-travel: 500 mm z-travel: 500 mm Control: Heidenhain tnc 124 serial number: 5277 table size: 1800 - 360 mm taper ISO: 50 weight of the machine ca.: 3 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1200 mm y-travel: 600 mm z-travel: 600 mm control: Sinumerik 840D SIEMENS table-size: 1.420 x 600 mm table load: 2,0 t spindle taper ISO: 50 spindle turning speed range: 4.000 U/min feed: 2.000 mm/min rapid traverse: 10,0 m/min voltage: 400 V total power requirement: 42 kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 3,60 x 2,45 x 2,15 m coolant tank: 1,25 x 1,25 x 0,50 m - Serial-No.: 076 - Control system: SIEMENS Sinumerik 840D - Electric handwheel - Hydraulic tool clamping with foot switch - SEMPUCO universal milling head - Coolant system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Key data: 4000 mm, 1000 mm, 1700 mm

with CNC control, Fabr. FIDIA, Type: M 2, Travels: X-axis: 4000 mm, Y-axis: 1000 mm, Z-axis: 1700 mm, with autom. Tool changer with 10 tool positions, 2 pcs. clamping bracket, Fabr. MECOF

x-travel: 5000 mm y-travel: 1000 mm z-travel: 1400 mm tool taper: ISO 50 spindle turning speed - stepless: 18 - 4000 U/min spindle motor: 22 kW table surface area: 5000 x 1000 mm table load: 10,5 t Control: Heidenhain TNC 530 A-Axis: +177,5 / - 180 ° rapid traverse: 1 - 5000 mm/min distance spindle /table: 125 - 1525 mm total power requirement: 50 kVA weight of the machine ca.: 29 t dimensions of the machine ca.: 13,1 x 5,4 x 3,86 mm medium overhaul in 2023/24, the spindle head and the mechanical components of the machine were refurbished. 5-axis machine - CNC control Heidenhain TNC 530 - MILLING HEAD O - FSQ 4000/750 -- 4000 rpm -- single spindle head with automatically adjustable spindle In a vertical or horizontal position the head can swivel around the cross axis from +177,5° to –180° by 2,5°. Swiveling around cross axis and H/V positioning comes from a regulatory servodrive o ...

x-travel: 1.704 mm y-travel: 1.210 mm z-travel: 1.003 mm Control: Heidenhain TNC 426 total power requirement: 65 kVA weight of the machine ca.: 16 t dimensions of the machine ca.: m Well-maintained CNC bed-type milling machine, subject to regular maintenance and servicing by a specialist company. The machine can be inspected under power and in operation (cutting). CNC Control: Heidenhain TNC 426 (6-axis) [Travel Ranges] X-axis: 1.704 mm (longitudinal) Y-axis: 1.210 mm (transverse) Z-axis: 1.003 mm (vertical) Spindle speeds: 35 – 3.000 rpm Number of gear stages: 2 Tool taper: SK 50 Main motor power: 28 kW Feed rates: 6 – 5.000 mm/min Rapid traverse: 15.000 mm/min Table clamping surface: 2.000 x 800 mm Table load capacity: 6.000 kg [Tool Changer] Max. tool diameter: 125/250 mm Max. tool length: 300 mm Max. tool weight: 25 kg Total power consumption: 65 kVA Machine weight: 16.000 kg Equ ...

CME Manufacturer Model FS-2 Year 2004 CNC HEIDENHAIN TNC-i530 Table Table surface 2,100 x 850 mm. Maximum permissible weight on table 5,500 kg. T-slots 1 in H-7 and 85 in H-10 Distance between slots 140 mm. Routes and advances Longitudinal course (X-axis) 2,000 mm. Transverse course (Y-axis) 1,000 mm. Vertical course (Z Axis) 1,000 mm. Feeds (X/Y/Z) 20,000 mm/min Head Universal/Manual Type ISO-50 DIN69871 head cone Speed range 50-4,000 rpm Head power 22 kW Equipment Automatic tool loader INCLUDED Tool Magazine Positions 20 External cooling INCLUDED 175 l coolant tank with 3 bar motor pump INCLUDED Longitudinal chip evacuator INCLUDED HEIDENHANIN HR-410 Portable Steering Wheel Ethernet connection INCLUDED Mandrel orientation encoder INCLUDED Thermal probe INCLUDED Refrigeration electrical cabinet INCLUDED CE-1 fairing Others Total installed power ...

EURO F2 – Universal Milling Machine Manufacturer EURO Model F2 Machine Type Conventional Milling Machine Milling Configuration Vertical Control System Manual / Conventional X-Axis Travel (Longitudinal) Approx. 800 mm Y-Axis Travel (Cross) Approx. 350 mm Z-Axis Travel (Vertical) Approx.450 mm Working Table Dimensions Approx. 1,200 × 300 mm Spindle Taper ISO 30 Spindle Speed Range Machine Weight Approx. 1,300 kg Auction-ID: A1-51153-49

x-travel:2000 mm y-travel:800 mm z-travel:800 mm table-size:2.000 x 700 mm workpiece weight:3500 kg drive capacity - spindle motor:17 kW spindle cone:50 ISO spindle turning speed range:3000 U/min dimensions of the machine ca.:5265 x 3250 x 2730 m weight of the machine ca.:9 t CNC controller:HEIDENHAIN TNC-426 :manuell used universal bed type milling machine with chip conveyor, automatic 2 position (vertical/horizontal) head 3000Rpm The retrofitting jobs done in this machine, are the same than those done to all of our machines. - Completely repair of the head, replacing bearings, shafts and engaging gears. - Completely replacement of all the bearings of the machine. - Replacing the joining screws of the bodies. - Completely repair of spindles. - Adjustment and repair of axis. - Grinding and adjusting all guides, because of deterioration. - Grinding and adjusting of the guide ways of the ...

x-travel:3600 mm y-travel:1250 mm z-travel:1600 mm table load capacity:8000 kp table clamping surface::4100 x 1050 feed range:10 - 5000 mm/min rapid traverse feeds:10000 mm/min spindle motor:29 kW spindle taper::ISO 50 spindle turning speed range:5 - 4000 U/min total power requirement:70 kW weight of the machine ca.:28 t dimensions of the machine ca.:8,5 x 5,4 x 3,2 m Machine with Heidenhain TNC 430 Steuerung - tool changer 30-fold - milling head indexable 2,5° - 4. axis turn table
