battenfeld ba used for sale

number of spindles:8 spindle passage:32 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: AF32 S DNT Yob: 1994 Eight-spindle automatic lathe with 8 main spindles max. nominal diameter D=32mm control: Siemens SIMATIC S7 electronic cam control Balluff gripper in position 8 for backworking CNC cross slide position 6 CNC cross slide position 7 Workpiece belt Coolant cooling Schimpke Chip conveyor with magnetic separator Tapping couplings The tooling shown may differ from the scope of delivery! Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

number of spindles:8 spindle passage:32 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: AF32 Dnt Yob: 1993 eight-spindle automatic lathe eight main spindles for bars up to D=32mm Modernized control: Siemens Sinumerik Motors: renewed modern motors suitable for modernized control system Electronic trip dog control: Balluff CNC cross slide position 5 cross CNC cross slide position 6 cross Preparation for gripper in position 8 (gripper optional) Independent feeds Thread cutting couplings integrated bar loader: Pietro CUCCHI; type: rack type magazine The scope of delivery regarding the tooling equipment could be different like pictures.

number of spindles:9 spindle passage:46 mm Article: CNC-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: SC9-46 Yob: 2016 Six-spindle automatic lathe with 6 main spindles with max. nominal throughput D=46mm and 3 counter spindles Main spindles: 6 motor spindles D46mm, 5. 000 rpm, 35 Nm to 80 Nm Cross slide units, transverse: 6 units, in positions I to VI, Slide units, longitudinal: 5 units, in positions I to V, Slide units, longitudinal: 5 units, in positions I to V, Counter spindles: 3 units, one each in positions VI, VIII and IX, 7. 500 rpm Cross slide units, transverse: 2 units, in positions VIII and IX, Control: Siemens SINUMERIK 840SL with double NCU Software: Schütte SICS, Sinomerik Operate 4.5, Safety Integreted, Spindle coupling package ?CP-Expert?, for up to 8 spindle couplings (maximum expansion) Synchronous action package ?Level? 2, incl. cross-mode actio ...

number of spindles:8 spindle passage:20 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: AG20 Yob: 2002 eight-spindle automatic lathe 8 main spindles for bars up to D=20mm control: Siemens 840D 1x polygonal turning/thread milling device (new 2011) 1x polygonal turning/thread milling device for long turning (new 2011) 1x thread cutting/quick drilling spindle (new 2011) 1x pick-up device incl. various pick-up collets 4 cnc-cross slides Double cross slide in position 7 Loading magazine PRA 52/P type 33 (bar length 3m), year 2004 High-pressure system Knoll SF 2000/Turbo-3 up to 100 bar, year 2004 Tool monitoring Brankamp Air conditioning unit Rittal in the front switch cabinet incl. spare parts package with various collets, cams and various tool holders for longitudinal and cross slides The machine has been run with oil and has processed brass Please, con ...

number of spindles:6 spindle passage:20 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: SF20 S Dnt Yob: 1999 Six-spindle automatic lathe with 6 main spindles max. nominal diameter: D=20mm Spindle drum hirth coupled, CNC cross slide in positions 4, CNC cross slide in positions 5, pick up in position 6, sorting chute, 1x independent feed, thread cutting couplings, workpiece belt, Coolant tank with hinged belt chip conveyor Ruez, Oil/steel operation, PLC Siemens S7, Siemens CNC control, Siemens Simodrive 611, The scope of delivery regarding the tooling equipment could be different like pictures. Interface for: IEMCA PRA bar loading magazine (optional: IEMCA PRA40/31/ built in 1997 rear loader)

number of spindles:6 spindle passage:36 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schutte Type: SF32 S Dnt Yob: 2003 Eight-spindle automatic lathe with 6 main spindles max. nominal diameter: D=36mm! Spindle drum with hirth coupling, Elbaron oil mist filter, sorting chute, Interface for: IEMCA PRA bar loading magazine (optional I: IEMCA PRA52/42/F); coolant tank with hinged chip conveyor; Schimpke KSS active cooler, control: Siemens S7-300 PLC; tooling included in delivery may differ from the images; various collets are included in delivery up to D36mm Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

number of spindles:6 spindle passage:32 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schutte Type: SF32 S Dnt Yob: 2003 Eight-spindle automatic lathe with 6 main spindles max. nominal diameter: D=32mm Spindle drum with hirth coupling, Elbaron oil mist filter, sorting chute, Interface for: IEMCA PRA bar loading magazine (optional I: IEMCA PRA52/42/F); coolant tank with hinged chip conveyor; Schimpke KSS active cooler, control: Siemens S7-300 PLC; tooling included in delivery may differ from the images Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

number of spindles:6 spindle passage:32 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schutte Type: SF32 S Dnt Yob: 2000 Eight-spindle automatic lathe with 6 main spindles max. nominal diameter: D=32mm pick-up unit, Spindle drum with hirth coupling, Elbaron oil mist filter, sorting chute, Interface for: IEMCA PRA bar loading magazine (optional I: IEMCA PRA52/42/F); coolant tank with hinged chip conveyor; Schimpke KSS active cooler, control: Siemens S7-300 PLC; tooling included in delivery may differ from the images Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

Manufacturer: Giovanni Cucchi Machine type: Automatic short bar loading magazine for single-spindle / short turning Type: DB-EVO70C Design: Surface loading magazine diameter range: 20-70mm bar length: max. 1500 mm The advantages of DB-EVO barfeeders at a glance: - oriented loading of the bar material possible (e.g. edge upwards) - dry running - no oil flow - significantly reduces vibrations even with material that is not optimally straight due to the unique design of the guide channel - very high speeds even with profile material (e.g. hexagon, square, flat material and special profiles) - short remaining pieces, as no clamping sleeve is used - very short charging time (charging process still during machining) - solid construction - very low wear of the guide channel - external loading - therefore no stop for new bars necessary, low power consumption (start/stop function) Please, contac ...

Package of 3 Schütte S32PC Article: CNC-controlled multi-spindle automatic lathe Manufacturer: Schutte Type: S32PC Yob: 1998 One machine is operational; the other two can be used for spare parts Includes IEMCA PRA40/33/P loading magazine, built in 1997 (rack type loader) Includes IEMCA PRA40/42/F loading magazine, built in 1999 (bundle loader) Includes IEMCA SIR325 loading magazine (integral loader with bundle magazine) tooling included in delivery may differ from the pictures Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

BOMAR Individual 520.360 DANC Bandsaw Machine Fully automatic double bevel sawing machine with double miter, machines in one Compact design with long stroke. Fully automatic Band saws from the Individual series are known for their impressive saw performance and easy operation. • Fully hydraulically controlled (saw feed, lifting, clamping) • Horizontal downward saw frame by means of linear guides • Integrated connector with removable rollers Automatic saw frame height adjustment Driven chip brush Digital angle reading Equipped with automatic cutting pressure control, depending on the material • Infinitely adjustable cutting speed 20-120 mtr./min. • Adjustable carbide saw guides • Control panel easily movable • Heavy duty drive motors • Feed systems with feed stroke 2300mm. (can be extended up to 6000mm) Cutting speed Supply stroke Drive motor Saw blade size Material height ...

" Manufacturer: bedra / Welo / AGIE EDM wire / EDM wire – lots of 16 rolls (different types) Lot of a total of 16 rolls of EDM wire for wire EDM machines. The inventory comes from stock liquidation and includes several manufacturers and wire types. Most of the rolls are unused and in their original packaging, some in polystyrene protective boxes or original boxes. Some rolls are open, but without signs of use and are therefore to be regarded as unused stock goods. The lot includes brass EDM wires and galvanized EDM wires of various diameters. Manufacturers include bedra (Berkenhoff GmbH), Welo GmbH and AGIE. The sale is carried out exclusively as a complete lot with all existing roles as shown. bedra topas® plus • Type: TPLH/300 • Diameter: Ø 0.30 mm • Tensile strength: approx. 800 MPa • Length: approx. 33,600 m • Coil type: P15 • Manufacturer: Berkenhoff GmbH bedra b ...

Miter Band Saw -Mitre cuts up to 60° left -Vice with quick-release device -Belt tension control -Electr. Automatic cooling Cutting diameter 225 mm Saw blade length 2455 mm Table height 850 mm Cutting width 245 x 150 mm Cutting speed 45/90 m/min Saw blade dimensions 2480 x 27 x 0.9 mm Cutting capacity at 60° around 90 mm Cutting capacity at 60° square 90 mm Cutting capacity at 45° Round 145 mm Cutting capacity at 45° square 145 mm Connection voltage 400 volts Total power requirement 1.5 kW Machine weight approx. 0.2 t Dimensions L x W x H 1.43 x 0.72 x 1.7 m Condition: never used / new (5)

BALZAT - Keyway slotting machine is characterized by the following advantages: - Stepless regulation of the shock speed with constant return also during the work process - Easy clamping of the workpieces with standard clamping devices, without additional tool holders - Extreme dimensional accuracy due to self-centering, centrally arranged Knife holder - Feed change is possible during the program sequence - The lower part of the machine is also a container for cutting oil - All components are easily accessible and replaceable

Double Miter Band Saw -Mitre cuts up to 60° left and 45° right -Vice with quick-release device -Belt tension control -Electr. Automatic cooling Cutting diameter 235 mm Saw blade dimensions 2645 x 27 x 0.9 mm Cutting width 280 x 190 mm Cutting speed 45/90 m/min Cutting capacity at 60° round 120 mm Cutting capacity at 60° square 120 mm Cutting capacity at 45° Round 190 mm Cutting capacity at 45° square 170 mm Connection voltage 400 volts Total power requirement 1.1 kW Machine weight approx. 290 kg Dimensions L x W x H 1.2 x 0.8 x 1.2 m

Manufacturer: VEB Pressenwerk Morgenröthe Type: PSHZ 40 Name: Screw press / balancing press (manual) Description: Manually operated screw press (balancing press) in solid cast construction from industrial production. The press works purely mechanically via spindle and hand lever, without hydraulics or electrical components. Suitable for pressing, straightening, assembly and joining operations in the workshop, maintenance and manufacturing. Robust and durable construction from GDR production. Scope of delivery: – Screw press as shown – Press table / support – Press type: Screw press / balancing press – Operation: manual – Size: 40 – Press force: Size 40 (according to experience, corresponds to approx. 40 t press force) – Maximum installation height: 460 mm – Total weight: 1650 kg Dimensions: – Width: 1800 mm – Depth: 1800 mm – Height: 2350 mm Weight: 1650 kg

Technical Specifications & Performance Data This automatic shrink wrapper with welding bar is engineered for reliable multi-row collation and high-quality bundling in beverage production and broader industrial packaging environments. Designed for in-line or 90° infeeds, it handles film-only multipacks as well as packs on a flat pad or tray when configured accordingly, making it ideal downstream of filling, capping, labeling, and rinsing stations. Type: Automatic shrink wrapper with welding bar Condition: NEW Output: Up to 25 bundles/minute (format-dependent) Infeed: In-line or 90° multi-row collation conveyor Film: PE shrink film, plain or printed with register mark alignment Packaging styles: Film-only bundles; optional flat pad or tray capability (configuration dependent) Welding bar: Available with multiple bar widths to match bundle size range Electrical: 50 Hz Dimensions (W x  ...

Year of manufacture: 2007 | Type: Bar loading magazine | Easy changeover of the guide channel in less than approx. 2 minutes. | Complete changeover of the guide elements possible in less than approx. 8 minutes. | Technical details: | Diameter range: 2 mm to 20 mm | Channel Ø 22 mm | Maximum bar length: 3,000 mm | Installation dimensions / dimensions (L x W x H): 3,970 x 480 x 1,250 mm | Weight: approx. 850 kg | Condition: fully functional | The machine can be viewed in operation by appointment. | Subject to changes and errors in the technical data and specifications, as well as prior sale! | Translated with DeepL.com (free version)
