bar turning used for sale

Guildmaster CTX 210 2005 Turning diameter: 290mm Turning length: 300mm Orbital diameter over bed: 380mm Main spindle Speed range: 20-6000 min/-1 Max Torque: 79/72Nm max. feed diameter: 165mm Spindle diameter in front bearing: 90mm Rod diameter: max. 45mm C-axis: 0.04° Holding moment: C:112Nm Tool turret: Number of powered tools: 12 pos. Shank diameter: 30mm Speed range: max. 5000 rpm Clamping diameter driven tools: max. 16mm Travel X-axis: 160mm Z-axis: 305mm Riding pole travel: 370mm Feeds: Rapid response: X 20 m/min Rapid response: Z 30 m/min Rapid response: C 100 m/min

Machine details Bearing number 1105-03132 Machine type CNC lathe - slantbed machine Made GILDEMEISTER Type CTX 400 Built in 2000 Control type CNC Warehouse FRANCE Country of origin Germany Delivery time SOFORT Freight base from location, free loading truck Technical details Turning diameter 570 mm Turning length 635 mm Control Heidenhain CNC Pilot 4290 Turning diameter over bed slide 420 mm Spindle speeds - infinitely 25-5000 rpm Number of driven tools 6 mm Drive 5 kW Information CNC Heidenhain Pilot 4290 C-axis with 5 FESTE vdi holders 1 3 BAKE FOOD 1 X SPAENEFOERDERER WITH REITSTOCK + LNS STANGEN VORCHUB

Merli Clovis 70 heavy lathe. Distance between centers: 8000mm. Swing: 1650mm. Swing in carriage: 1170mm. Bore: 206mm. Bed width: 1000mm. Speeds: 16.(3-300). Maximun weight without steady rest: 15.000Kgs. Maximun weight with 1 steady rest: 20.000Kgs. Equipped with chuck of 1400mm. Equipped with DRO. Equipped with 2 steady rest. Equipped with CE protections and CE certificate for second hand machines.

Key data: 250 mm, 285 mm, 5 1/min

Precision CNC Lathe Spinner SB - CNC with Siemens 840D Control PLC missing, parameters & circuit diagrams available The Spinner SB - CNC was built in 1996 and is equipped with a reliable Siemens 840D control system. This precise lathe is ideal for a wide range of applications and is characterized by its high performance. Specifications: - Manufacturer: Spinner - Type: SB - CNC - Year of construction: 1996 - Control: Siemens 840D - Travels: X 250 mm, Z 285 mm Spindle: - Max. speed: 5,000 rpm - Spindle passage: 42 mm Revolver: - Number of stations: 12 - Tool holder: VDI16 Dimensions and weight: - Dimensions: 2.1 m x 0.8 m x 1.6 m - Weight: 1,500 kg The Spinner SB - CNC is in a used, but very neat condition. All functions have been carefully checked, and the machine is fully functional. The SB-CNC spinner is ideal for precise machining in a variety of appl ...

Key data: 500 mm, 700 mm, 3500 1/min

Make: Spinner Model : TC 110 SMCY Control Siemens 840 D ShopTurn Year of construction 2006 Specifications: Turning diameter 500 mm Circulation diameter 690 mm Turning length 900 mm Y-axis -55/+65 mmmm C-axis 0.001° Spindle passage main spindle 110 mm Spindle passage counter spindle 66 mm Main spindle motor 28 kw High-speed main spindle 3200 rpm. Counter spindle speed 5000 rpm. Rapid traverse x/y/z 24 m/min. Sauter Star Revolver VDI 50 Number of stations 12-fold Driven tools 12 Speed driven tools 4000 rpm. Machine weight approx. 7800 kg Dimensions set-up (L x W x H) with chip conveyor 5500 x 2200 x 1800 mm Accessories: automatic pick-up device Measuring arm Bar feeder preparation Conveyor 3D Renishaw Probe Coolant gun Increased coolant pump Hainbuch Collet Chuck for Main Spindle 3 Jaw chuck counter spindle Various tool holders Documentation

Turning diameter 320 mm Turning length 450 mm Control HEIDENHAIN Circulation diameter over slide 260 mm Travel - x 160 mm Travel - z 450 mm Speed range - main spindle 5,000 rpm Drive power - main spindle 11 / 7.5 kW Max Torque 76 / 112 Nm Turret head (x-fold) 12 pos

Key data: 600 mm, 1250 mm, 3500 1/min

Machine Details Stock-No. 1105-03997 Type of machine CNC Lathe - Inclined Bed Type Make GILDEMEISTER DMG Type NEF 600 Year of manufacture 2007 Type of control CNC Storage location HAGUENAU Country of origin Germany Delivery time immediately Freight basis EX WORK Price Technical details turning diameter 600 mm turning length 1250 mm greates pass round over bed 600 mm centre height 350 mm Spindle Bore 92 mm turning speed range 3500 rpm Rapid Travel - Longitudinal/Face 20 m/min face stroke 400 mm tailstock quill diameter 100 mm Tailstock Quill Stroke 1150 mm tailstock taper MT 5 Turret (X-Stations) 12 turning diameter over slide 410 mm Additional information acc.: hydr. 3-Jaw Chuck 400 mm, Chip Conveyor, Coolant CNC FANUC 210 IS

Inv. Num: 5302 Type: DL 10G Producer: Profika Generated: 2011 Parameters: Control system: FANUC 0iMATE-TD Maximum rotation length: 185 mm Max turning diameter: 170 mm Maximum spindle speed: 3500 rpm Lathe length: 1980 mm Lathe width: 1420 mm Weight: 2750 kg

Key data: 320 mm, 600 mm, 3500 1/min

Stock-No. 1105-03841 Type of machine CNC Lathe - Inclined Bed Type Make LEADWELL Type LTC 20 Year of manufacture 1990 Type of control CNC Storage location HAGUENAU FRANCE Country of origin taiwan Delivery time by appointment Freight basis EX WORK Price Technical details turning diameter 300 mm turning length 600 mm control Fanuc O- T Travel -X Axis 175 mm Spindle Bore: Ø 50 mm Number of Turrets: 1 piece No. of tools in turret 1 12 pieces power capacity 11/15 kW spindle nose A2-6 tailstock quill taper MT 4 feed range 1 - 15000 mm/min Rapid Traverse 12 / 15 m/min total power requirement 30 kW Additional information CNC FANUC OT turret 12 tols TAILSTOCK CHUCK Chip Convoyer

Manufacturer: WEILER Machine Tools Type: DZ 28 CNC Built: 1997 Connection power 25 kW Numerically controlled linear turning center for the production of precision workpieces in the small parts sector. The two machines are driven via a controller. As shown, the machine includes vertical material supply, the machining machine with chip conveyor and control devices, control cabinet and hydraulic unit. The machine was in operation at the site in Germany until production ceased. The machine is dismantled.

Key data: 300 mm, 500 mm, 4000 1/min

Machine Details Stock-No. 1105-04001 Type of machine CNC Lathe - Inclined Bed Type Make HARDINGE Type CONQUEST T 51 Year of manufacture 1997 Type of control CNC Storage location HAGUENAU FRANCE Country of origin UK Delivery time Immediatly Freight basis ex warehouse, loaded Technical details turning diameter 300 mm turning length 500 mm control fanuc 18 T max. swing diameter 400 mm spindle head A 2-5 Bar Material Dia. 51 mm turning speed range 4000 rpm spindle drive 11/15 kW Torque 168 Nm Tool Diameter 32 mm Rapid traverse 30 m/min total power requirement 15 kW weight of the machine approx. 3.2 t dimensions of the machine approx. 2.0 x 1.7 x 1.8 m Accessories cooling attachment Additional information FANUC 18T CONTROL 3 JAWE CHUCK + taistock CHIP CONVOYER

Key data: 530 mm, 500 mm, 4000 1/min

Machine Details Stock-No. 1105-04005 Type of machine CNC Lathe Make COLCHESTER Type TORNADO 300 Year of manufacture 1995 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Great Britain Delivery time immediately Freight basis EX WORK Price Technical details turning diameter 530 mm turning length 500 mm control FANUC OT total power requirement 22 kW weight of the machine approx. 3.3 t Additional information GOOD MACHINE CNC CONTROL FANUC OT Cuck Taikstock VDI 40 Turret 12 P Chip Convoyer echnical information Swing over bed 530 mm Swing over cross-slide 330 mm Distance centre tot centre 500 mm Max longitudinal travel Z-axis 20 m/min Max cross travel X-axis 10 m/min Spindle cone A2-8 Dia of spindle bore 90.5 mm Power on the spindle 22 kW Number of speeds 4000 rpm Command Fanuc Total power needed 53 kVa Length 3500 mm Wid ...

harden machine 1x1x2m temperature max 1200C PLC Wärmebehandlungs Kammeröfen Wärmebehandlungs gienanth Schachtöfen Haubenöfen Härten Anlassen bei niedriger und hoher Temperatur Glühen Normalglühen Austenitisieren Spannungsfreiglühen Vorwärmen vor dem Schmieden Rollenherdöfen Poreba Gurutzpe Tacchi Geminis Tos Amutio cazeneuve Skoda Morando Niles Colchester Heyligenstaedt Kramatorsk Mondiale Safop Cazeneuve Alzmetall mas stankoimport csepel carlton kolb soraluce bergonzi flott Erfurt Weingarten smeral schuler ebu mueller zts kosice wlochy minster Stanko stankoimport glaser huta zygmunt aft donaldson eumuko Elblag Engel Demag Arburg Krauss Maffei Battenfeld Manesty Mazak Voronezh Trumpf Amada Cincinnati Netstal Rose Forgrove Illig Foremost Nissei Sandretto Fette Mazak Mori seiki Haas Okuma Gildemeister Doosan Daewoo traub hwacheon index Wema zeulenroda mueller Erfurt t ...

GILDEMEISTER NEF Plus 500 CNC lathe was manufactured in 1997. The machine, designed for precision machining of workpieces with a maximum diameter of 500 mm, has two spindles (main spindle and sub-spindle) of high speed and power, which will improve even the most intensive machining. The installed GRUNDING CNC controller with colour screen and control panel also allows for cycles to control. The total weight of the machine is approximately 3000 kg. Technical specifications of the GILDEMEISTER NEF Plus 500 lathe - CNC control: GRUNDIG - maximum turning diameter (over bed): 500 mm - maximum turning diameter (over saddle): 290 mm - maximum turning length: 1500 mm - main spindle rotational speed range: 80-2800 rpm - main spindle passage: 70 mm - main spindle drive power: 11 kW - maximum sub-spindle rotational speed: 5000 rpm - sub-spindle drive power: 7.5 kW - total power require ...

ovenn 650 inner dimensions 1x1x2m t max 650 C PLC Auto door Schachtofen Haubenofen Rollenherdöfen Durchstoßöfen Härten Glühen Normalisieren Weichglühen Vergüten Anlassen Entspannen Durchschuböfen Hubbalkenöfen Hubherdöfen Trockenöfen Rollenherdöfen Drehherdöfen Kammeröfen Mehrkammeröfen Verfahrbare zirlguss Haubenöfen Herdwagenöfen Poreba Gurutzpe Tacchi Geminis Tos Amutio cazeneuve Skoda Morando Niles Colchester Heyligenstaedt Kramatorsk Mondiale Safop Cazeneuve Alzmetall mas stankoimport csepel carlton kolb soraluce bergonzi flott Erfurt Weingarten smeral schuler ebu mueller zts kosice wlochy minster Stanko stankoimport glaser huta zygmunt aft donaldson eumuko Elblag Engel Demag Arburg Krauss Maffei Battenfeld Manesty Mazak Voronezh Trumpf Amada Cincinnati Netstal Rose Forgrove Illig Foremost Nissei Sandretto Fette Mazak Mori seiki Haas Okuma Gildemei ...

Lathe was bought fully reconditioned from a reseller in 1996 and has been used since 2010. Mechanically is in good conditions, NC is to be checked.

Furnace (heat treatment machine) 650 T max 650 Celsius inner dimensions 1.5x1.5x2m Poreba Gurutzpe Tacchi Geminis Tos Amutio cazeneuve Skoda Morando Niles Colchester Heyligenstaedt Kramatorsk Mondiale Safop Cazeneuve Alzmetall mas stankoimport csepel carlton kolb soraluce bergonzi flott Erfurt Weingarten smeral schuler ebu mueller zts kosice wlochy minster Stanko stankoimport glaser huta zygmunt aft donaldson eumuko Elblag Engel Demag Arburg Krauss Maffei Battenfeld Manesty Mazak Voronezh Trumpf Amada Cincinnati Netstal Rose Forgrove Illig Foremost Nissei Sandretto Fette Mazak Mori seiki Haas Okuma Gildemeister Doosan Daewoo traub hwacheon index Wema zeulenroda mueller Erfurt tox presso technik dunkes galdabini hare ponar zeulenrdoda eitel

Key data: 500 mm, 1000 mm, 5000 1/min

Machine Details Stock-No. 1105-04017 Type of machine CNC Lathe - Inclined Bed Type Make MAZAK Type SQT 200 L Year of manufacture 2003 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery time Immediatly Freight basis Ex site Price Technical details turning diameter 360 mm turning length 1000 mm control MAZATROL FUSION 640 T swing diameter 350 mm spindle turning speed - stepless 5000 rpm Spindle Motor 15 kW Bar Material Dia. 51 mm X-Axis 190 mm Z-AXIS 1000 mm weight of the machine approx. 5 t dimensions of the machine approx. 3.6 x 1.8 x 2.0 m Accessories 12 - Tool Turret Tool - Eye tailstock

Cazeneuve HB575 rebuilt lathe. Swing over bed: 575mm. Swing over carriage: 300mm. Distance between centers: 4000mm. Spindle nose: 51mm. Motor power: 12,5cv. Equipped with universal chuck of 250mm and steady rest. CE protections in chuck and carriage and CE european certificate for second hand machines. Optional: DRO Fagor or Heidenhain. Optional: CE back guard.

Key data: 500 mm, 450 mm, 6000 1/min

1 used CNC lathe Make Gildemeister Model CTX 320 V5 Linear Year of manufacture 2004 Control Siemens 840 D ( ShopTurn ) Workspace: Max. circulation diameter over bed 500 mm Circumferential diameter via X-carriage 300 mm Turning length 450 mm Bar passage 60 mm Chuck diameter 170 mm Chuck diameter sub-spindle 165 mm Plane stroke 160 mm Rapid traverse X/Z axis 60/45 m/min Power main drive (100% ED) 16 kW Speed range 6000 rpm Power sub-spindle (100% ED) 7.5 kW Speed range 6000 rpm Number of tool stations 12 Cylindrical shank diameter 30 mm Number of driven tools 12 Drive power (40% ED) 10 kW RPM, max. 5000 min-1 C-axis speed range 0 - 200 min-1 C-axis positioning 0.001 degrees Connected load, total approx. 32 kVA Net weight with chip conveyor approx. 4300 kg Machine with chip conveyor L x W x H 3890 x 1555 x 1890 mm Accessories: Conveyor Pa ...

Cazeneuve HB500 rebuilt lathe. Distance between centers: 2000mm. Swing over bed: 500mm. Swing over carriage: 220mm. Motor power: 10cv. Spindle nose: 40,5mm. CE protections in chuck and carriage and CE european certificate for second hand machines. Equipped with universal chuck of 250mm and steady rest. Optional: DRO Fagor or Heidenhain. Optional: CE back guard.

Key data: 330 mm, 635 mm, 210 mm

brand new, toolmaker accuracy DIN 8605 Center height 167 mm Center width 635 mm Circulation diameter. over bed 330 mm Circulation diameter. over cross slides 210 mm Circulation diameter. in the offset 480 mm Main spindle bore 40 mm Speed range 40 - 2500 rpm Cone in tailstock MK 3 Drive power 2.2 kW Standard equipment: - 2-axis digital display ACU-RITE® DRO 203 - Precision spindle bearing thanks to NSK® tapered roller bearings - Quick-change steel holder MULTIFIX® size MA - Chip collection tray with opening flap at the front - Movable steel holder protection - Rear splash and chip protection wall - Feed protection - Spindle cover - Removable bridge - Coolant system - Work area lighting - Thread clock - Large matt chrome-plated scales - Foot brake with brake pedal over the entire length -Operating instructions - CE declaration of conformity

Cazeneuve HB575 rebuilt lathe. Swing over bed: 575mm. Swing over carriage: 300mm. Distance between centers: 750mm. Motor power: 12,5cv. Spindle nose: 51mm. Equipped with universal chuck of 250mm. CE protections in chuck and carriage and CE european certificate for second hand machines. Optional: DRO Fagor or Heidenhain. Optional: Steady rest. Optional: CE back guard

Key data: 600 mm, 2000 mm, 400 mm

brand new, good handling due to feed switch via joystick and rapid traverse, full-fledged manual transmission with large speed range Technical data: Swing over bed 600 mm over support 400 mm Center height 300 mm Bed width 400 mm Center width 2000 mm Spindle bore 80 mm Speed range (21) 20-2000 rpm quill cone MK 5 incl. accessories: - Rear chip splash protection wall - Electr. Locked face plate/chuck protection - Guide and pull spindle cover - Coolant system - Machine light - Rapid traverse longitudinal and transverse/joy-stick - Feed longitudinal and transverse/joy-stick - Interchangeable wheels - 4-fold steel holder -Operating instructions additionally included in the price: - Fixed bezel 20 - 200 mm - Fixed bezel 180 - 340 mm - Mitlauf. Bezel 20 - 200 mm - Main motor 11 kW instead of 7.5 kW - Cross support machined with T-slots - Reduction gear for t ...

Key data: 350 mm, 700 mm, 4000 1/min

Machine Details Stock number 1105-04023 Machine Type: CNC Lathe - Inclined Bed Machine Make GILDEMEISTER Type NEF400 / 840D Shopturn Year of construction 2006 Condition Control type: CNC Control Siemens 840D Shopturn Storage location FRANCE Country of origin Germany Delivery time immediately Freight base from Dreieich warehouse Price Technical details Turning diameter 350/270 mm Turning length 700 mm Control Siemens 840D Shopturn Circumferential diameter max. over bed cover 400 mm Travel - z 700 mm Spindle bore 65 mm Spindle speeds max. 4000 rpm Tool holder VDI 30 Turret head 12 pos. Three-jaw chuck diameter 200 mm Spindle holder A6 DIN55026 Pick-up cone in the tailstock quill MK 3 Drive power 15/12 kW Operating voltage 400 V Machine weight approx. 3.0 t Information - Control: Siemens 840D Shopturn - Tool holder VDI 30 APPROX. 12 PIECES - Coolant de ...

Spindle diameter 3,000 mm Turnerable diameter 3,200 mm Maximum workable height 2,000 mm Weight allowed over spindle 40 ton Pump engine power 63 kW Spindle rotation speed 0.66-62 RPM Machine weight 86,000 kg Dimensions 9.345x5.120x6.030 mm

Ø max. of the piece: 2200 mm Ø clamping of the table: 2000 mm Maximum load on the table: 12000 kg Maximum height of the piece: 1200 mm RAM Stroke (Z): 720 mm Main engine power: 55 kW

Control Fanuc ... i Series Turning diameter ... 600mm Turning length ... 330mm Inclined bed Spindle bore ... 61mm Turret Circumferential diameter over bed ... 600mm Circumferential diameter via support ... 400mm Axis X ... 205mm Axis Z ... 340mm Rapid traverse of the X axis ... 30m/min Rapid traverse of the Z axis ... 36m/min Spin speed... 0-6000 rpm. Max. spindle torque ... 127Nm Main engine power ... 11/15kW Doosan Robot Cell Assembly: 2x LYNX 2100A + ROBOTEC APC7 (Fanuc AM-100 iC6L) - The machines are supplied with chucks and pliers - High pressure cooling 20bar - Arm for picking up workpieces (Ø65 x L130 mm, weight 3 kg) - Automatic door opening - Spindle bladders for cleaning the clamping jaws - Oil separator - OIL SKIMMER - Tool Load Monitor (works with X-, Z-axis and S-spindle) - Workpiece conveyor The machine is in good condition, possible to test un ...

Control SIEMENS Sinumerik 840D Specifications: Workspace - Max. rotation and turning diameter 2,000 mm - Max. turning height 2,000 mm - Face plate diameter 1,600 mm - Max. face plate load 11,200 kg - Chisel slide travel (vertical) 1,400 mm Smallest plunger diameter 330 mm Plunger cross-section 250 x 210 mm - Drive power of the main motor 71 kW - Crossbar adjustment 1,170 mm - Crossbeam support of central face plate to the right 1,170 mm - From the middle of the face plate to the left 25 mm Speed of faceplate: - Number of transmission stages 2 - 1 level 3.15-80 min-1 - 2 Level 12.5-315 min-1 - Lifter and support hydrostatically guided Feeds - X and Z 0.1 2000 mm/min - Rapid traverse X and Z 6,000 mm/min - Weight approx. 24,000 kg - Voltage 400 V 50 Hz - Connected load 175 kW - Space requirement L = 10,000 mm B = ...

Platform diameter 2,800 mm Max turnerable diameter 3,200 mm Maximum height of the workpiece 1,600 mm Weight allowed above platform 16,000 kg Main engine power platform 55 kW Spindle RPM 1.25-63 Spindle No. Crossbar stroke 1,240 mm Horizontal head stroke 1,720 mm Vertical head stroke 1,200 mm Total machine weight 43 ton

platform diameter: 1450 mm (HYDRAULIC - hydraulic spindle) maximum diameter of the piece: 1650 mm maximum height of the piece under the crossbar: 1200 mm - under tool holder: 1000 mm maximum workpiece weight: 11000 Kg mobile crossbar running on the plinth: 900 mm fast movement speed: 400 mm/min. slow displacement speed: 100 mm/min positioning accuracy on the base: +/- 0.1/100 mm main drive engine power: 60 KW platform advancement range: 2-280 rot/min number steps speed change box 3 work support stroke (X-axis): 1542 mm vertical stroke work support sled (Z-axis): 1200 mm sled section: 250x250 mm Milling shaft cone: ISO 50 milling engine power: 22 KW milling shaft speed range: 20-2000 rot/min X-Z axis work feed range: 1-4000 rot/min fast forward: 6000 rot/min C axis feed (slow-regimo milling rotation): 1-360 °/min X, Z, C: 45 N ...

Table diameter: 1,200 mm Maximum turnerable diameter: 1,350 mm Spindle power: 47.7 Kw Maximum turnable height: 950 mm Table capacity: 6 ton Table rotation speed: 2.22 ÷ 200 rpm Vertical RAM wagon stroke: 1,000 mm Vertical turret wagon stroke: 760 mm Tilt vertical wagons: 35 ° Total weight: 16 ton CNC FAGOR 8055 Year 1979 REVISED IN 2009

BOEHRINGER VDF DUS 1000 CNC lathe was built in 1993 in Germany. The machine, designed for machining workpieces with a maximum diameter of 1000 mm, delivers excellent turning results during even the most intensive challenges, thanks to its extremely stable design and reliable components. The spindle is driven by an stepless AC motor, which allows efficient turning in two different, optimally adapted speed ranges. All axes, on the other hand, have powerful servo drives, guaranteeing excellent dynamics and positioning accuracy throughout the machine’s lifetime. This is rounded off by an intuitive SIEMENS CNC control with many functions for easy operation and programming. The BOEHRINGER VDF 1000 DUS lathe weighs approximately 10100 kg. Technical specifications of BOEHRINGER VDF DUS 1000 metal lathe - turning diameter above the bed: 1000 mm - turning diameter over transverse slide: 710 ...

Table diameter 1450mm Maximum working diameter 1600mm Maximum height under the crossbar 1000mm Two balanced RAM Quota viewers Machine working in good condition Machine weight 18 ton This morando vertical lathe is in excellent condition and ready to be installed.

Spindle diameter 2,000 mm Turnerable diameter 2,000 mm MACHINE IN MECHANICAL/ELECTRIC RETROFIT PHASE

CN FAGOR 8055-T Machine equipped with quota viewers, turret 2nd pentagonal wagon Spindle diameter 2,000 mm Maximum turntable height 1,310 mm RAM stroke 1,000 mm Maximum diameter 2,200 mm Spindle Max Speed 150 rpm Nr. 3 wagons type 1 RAM 1 turret 1 side Main engine power 52 kW

Maximum turnerable diameter 1200 mm Maximum permissible diameter 1250 mm Spindle engine power (S1/S6) 55 / 66 Kw Spindle maximum laps 1200 rpm ASA 15" Spindle Attachment Fast speeds 12 m/min X-axis stroke 750 mm Z-axis stroke 750 mm Rated engine torque 20 (X)-20 (Z) Nm Peak engine torque 80(X)-80(Z) Nm Nominal thrust force 1200(X) -120 (Z) N Screw pitch 10 (X) -10 (Z) mm Tools 24 Crown HIRT tool attachment Maximum weight per cell 15 kg Tool change cycle time 10 seconds Maximum weight on tool change ~ 250 Average tool weight ~ 10 Maximum milling tool diameter 150 mm Maximum tool length 350 mm Siemens Sinumerik Control

Ø plateau: 1250 mm Top speed: 500 rpm - 2 ranges Ø false plateau: 1450 mm Maximum piece: 1550 mm Maximum height of the piece: 1200 mm RAM stroke: 800 mm Crossbar stroke: 850 mm Tool warehouse: 10 ATC CNC Siemens 810 D

to turn the cans by 180° for example before and after the pasteurizer/can warmer/can coding suitable for all can types: Standard, Sleek, Slim

Specifications Control Siemens Sinumerik 840 Dsl Main dimensions and travels Face plate diameter 3,500 mm Circumferential diameter (max.) 4,000 mm Workpiece height (max.) 3,000 mm Total height of the machine 7,250 mm Maximum workpiece weight 50,000 kg Table base Y Horizontal table displacement 2,000 mm Crossbar Vertical adjustment of the crossbeam 1,500 mm in 50 steps Crossbeam Support (Right) Horizontal adjustment support -25 + 2170 mm Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool Stations Crossbeam Support (Left) Horizontal adjustment support -25 + 2170 mm Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool Changer Main Drive: Main motor power 100 kW Face plate speed range 1-100 rpm. Maximum torque at the face plate 100  ...

Key data: 4000 mm, 5000 mm

Specifications Control SIEMENS SINUMERIK 840 Dsl Main dimensions and travels Face plate diameter 4,000 mm Circumferential diameter (max.) 5,000 mm Workpiece height (max.) 5,000 mm Total height of the machine 9,250 mm Maximum workpiece weight 80,000 kg Table base Y Horizontal table displacement 2,500 mm Crossbar Vertical adjustment of the crossbeam 3,200 mm in 50 steps Crossbeam Support (Right) Horizontal adjustment support - 2740 + 2740 mm Vertical displacement of the chisel slider 1,800 mm Cross-section of the chisel slider 250x210 mm Side Support (Right) Vertical adjustment support -25 + 2170 mm Horizontal displacement of the chisel slider 1,000 mm Cross-section of the chisel slider 250x210 mm Turning diameter max./min. 4,500/2,500 mm Main Drive: Main motor power 100 kW Face plate speed range 0.63 – 63 rpm. Maximum torque at the  ...

Ø board: 1250 mm Maximum turnerable: 1500 mm Useful height: 1355 mm Vertical crossbar stroke: 800 mm Ram vertical stroke: 1000 mm Toolholder number: 15 Table pruned: 12000 kg CNC Tesla NS 642 C Fast: 8 m/min Power: 40 kW Weight: 27.2 ton

Mori seiki MT 2000 multitasking lathe :::TECHNICAL SPECIFICATIONS::: CNC model: Mori Seiki - CNC version: MSC 501 - Spindle nose: ASA 6 - Spindle power: 22Kw Number of main spindle speeds: 6000 - Turning diameter: 540mm - Bar passage: 65mm - Turning length: 1020mm Number of tools: 60 Tool holder: CAPTO C6 Spindle power: 18Kw Number of spindle speeds: 8000 X-axis travel: 565mm Y-axis travel: +-80mm Z-axis travel: 1077mm Swivel B-axis travel: + - 120 ° degrees Fast feeds for linear axes X Y Z: 24m/min High refrigerant pressure: yes Pressure value: 80bar External tank system with filter: yes Number of tool turrets: 1 Number of tool positions for the first turret: 12 Number of Motorized First Turret: 12 First turret X-axis travel: 155mm First turret Z-axis travel: 1067mm Sub-spindle: yes Spindle nose: ASA 5 Number of counter ...

Ø board: 1,800 mm Maximum working ø: 2,000 mm Max. Turning height: 1,250 mm Max. weight on the table: 15 tons X-axis: 2700 mm Z-axis: 1200 mm Axis C 360 ° Table speed: 3 - 300 rpm Board engine: 60 kw RAM: 250 x 300 mm Work progress: 0 - 2000 mm/min. Nc: FANUC 15 T SERIES ATC: 50 ISO 50 tools Total weight: 58 ton

Key data: 400 mm, 1100 mm, 3500 1/min

Machine Details Stock-No. 1105-04040 Type of machine CNC Lathe Make NAKAMURA Type SC 300 L Year of manufacture 1998 Type of control CNC Storage location FRANCE Country of origin Japan Delivery time by arrangement from the location Freight basis EX WORK Price Technical details turning diameter 350 mm turning length 1150 mm control FANUC 21 t turning diameter over slide 300 mm turning speeds 3500 rpm rapid traverse 20/25 (X,Z) m/min power capacity 22 kW Additional information NICE MACHINE TURNING LENG 1150 CNC FANUC 18 T WITH LIVE TOOLS ANS C AXIS CHIP CONVOYER HYDRAULICK STEADY SMW Technical details and information subject to amendments and errors. 2024 Created with ModulMWS by LogoTech oHG

Code 71139 DESCRIPTION CNC Center lathe with 2 axis Make P B R Model T 30 SNC x 1500 S/N 30 H / 87 Year 1996 Control Siemens Sinumerik 805 Distance between centers 1500 mm Max. swing 630 mm Max. swing over slide 330 mm Spindle bore 105 mm Spindle speed in 2 ranges stepless ( in program ) 7 – 310 / 44 - 2000 rpm Motor power 15 kW Connected load 33 KVA Machine weight 5500 kg Accessories 8 ATC Duplomatic toolholder R 10 Hydraulic 3 chuck Ø 315 mm 1 fixed steady with 320 mm bore 1 open steady cooling equipment Condition Machine is in good condition

Code 81176 DESCRIPTION CNC Center lathe with 2 axis Make P B R Model T 30 SNC x 3000 S/N 30 – S / 80 Year 1995 Control Heidenhain Manual Plus ( 1998 ) Distance between centers 3000 mm Max. swing 630 mm Max. swing over slide 330 mm Spindle bore 105 mm Spindle speed in 2 ranges stepless ( in program ) 7 – 310 / 44 - 2000 rpm Motor power 15 kW Connected load 33 KVA Machine weight 6000 kg Accessories 3 chuck of 315 mm 1 fixed steady 1 open steady cooling equipment Condition Machine is in good condition

Machine Type: CNC Lathe Manufacturer: GILDEMEISTER Type CTX 500 S2 Year of construction 1998 Control CNC Pilot Heidenhain Country of origin Germany Delivery time by arrangement Freight base from location Technical details Turning diameter max. 445 mm Turning length 1,000 mm Control CNC Pilot Heidenhain Circumferential diameter 680 mm Main spindle: Speed range – main spindle 18 - 3,600 rpm/-1 Drive power – main spindle 23 kW Max. torque 650 Nm Spindle nose 220h5 Chuck diameter 315 / 400 Spindle bearing diameter 140 mm Spindle bore 107 mm Tool turret: Number of tool positions 12 pos. Tool holder 40 DIN69880 Travel: x-travel 320 mm z-travel 1,097 mm Tailstock: Quill stroke 120 mm Tailstock mount MK 5 Quill pressure 14 kN Feeds: Rapid traverse X : 24 / Z : 30 m/min Feed force X: 8 / Z: 15 kN Total power requirement 58 kVA Machine weight approx ...

Key data: 490 mm, 515 mm

tock-No. 1105-04043 Type of machine CNC Turning- and Milling Center Make MORI SEIKI Type NL1500SY/500 Year of manufacture 2006 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery time immediately Freight basis ex Warehouse Price Technical details turning diameter 490 mm turning length 515 mm control MSX-850 max. bar capacity 52 mm Travel -X Axis 280 mm Travel -Z AXIS 490 mm max. speed main spindle 6000 min-1 spindle taper 1 A2-6 C - Axis 0.001 ° Spindle bearing diameter 110/75 mm No. of tools in turret 1 12 Shaft Cross Cut 25 x 25 mm Shank diameter 50 / 32 mm Turret Change Time 0.25 s max. spindle speed driven tools 6000 min-1 rapid power traverse in X-and Z direction 30 m/min Rapids C - Axes 400 min -1 drive capacity - spindle motor 18.5 kW power capacity - driven tools 5.5 kW swing diameter over face slide 278 mm gre ...

weight max.: 5 t workpiece diameter: 100-2500 mm gear diameter: 250 mm gear width: 140 mm total power requirement: 0,8 kW weight of the machine ca.: 0,8 t dimensions of the machine ca.: 2,0 x 1,4 x 1,0 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
